Pentair Everpure CES Series Technical Document

CES SERIES WATER SOFTENERS
INSTALLATION, OPERATION AND MAINTENANCE GUIDE
NOTES
Do not discard. Give this guide to the owner/operator after installation.
This installation manual contains important information related
to the installation, startup and operation of the Pentair Everpure
2850E, 9500E, 2900E, 2900E-DP, 2900E-TP, 2900E-QP, and 3900E
Series water softeners. In addition to this document, a Control
Valve Manual and Programming Guide (“E” Series models) have
been provided. The Control Valve Manual covers general operating
information, in addition to detailed exploded parts views of the
control valve, valve drive and brine system.
The Programming Guide (only “E” Series models) includes step-by-
step procedures for programming the controller for your specic
application.
Many sections of this manual will apply to all models, whereas some
sections may be more series specic. Specic model differences
will be highlighted. Refer to the general arrangement drawings for
examples of typical plumbing congurations and identication of
various components and their connection points.
OPERATIONAL SPECIFICATIONS
For use on cold water only.
Pressure Requirements:
An operating water pressure between 25 and 125 PSI (1.7 - 8.6 bar).
Note: When daytime water pressure exceeds 80 psi (5.5 bar), the
maximum pressure rating of 125 psi (8.6 bar) can be exceeded. A
pressure regulator must be installed on this system or warranty is
voided.
If pressure is greater, install a pressure regulating valve ahead of
the system. If water pressure is lower, install additional equipment
to maintain a 30 PSI (2.1 bar) minimum operating pressure.
Temperature: 40-100ºF (4-38ºC)
1. Clear (non-turbid) water supplies (less than 5 NTU).
CAUTION
The pressure vessels (mineral tanks) provided with the
system should be protected from the following conditions:
a. Vacuum in excess of 5 ½" Hg (17 Pa) below atmospheric – If
negative pressure should ever exceed 5½" Hg (17 Pa), an
adequate vacuum breaker must also be properly installed.
A vacuum breaker should be installed just prior to the inlet
of the control valve. Systems utilizing multiple controls will
require a vacuum breaker for each control valve.
Improper installation of a vacuum breaker when required, may
void the mineral tank warranty.
INTRODUCTION
The Pentair® Everpure® CES Series water softening systems
provide optimum water characteristics for its specied
applications. These systems can help minimize equipment
downtime and help improve the quality and consistency of your
products. Proper system installation and routine maintenance,
such as relling the brine tank with salt, can ensure years of
trouble-free operation and performance.
Vacuum Breaker Installation
Vacuum Breaker Control Valve
Shut-off
Valve
Base
Tank
2900E SINGLE 2900E DUPLEX PARALLEL 2900E TRIPLEX SERIES 2900E QUADPLEX SERIES
2850E SINGLE 9500E TWIN 3900E SINGLE (HWBP & NHWB)
PENTAIR EVERPURE CES SERIES WATER SOFTENERS INSTALLATION, OPERATION AND MAINTENANCE GUIDE FOODSERVICE.PENTAIR.COM

2 • PENTAIR EVERPURE CES SERIES WATER SOFTENERS INSTALLATION, OPERATION & MAINTENANCE GUIDE FOODSERVICE.PENTAIR.COM
Series Model
Exchange Capacity per Tank
Resin Volume per Tank (cubic foot)
Service
Flow Rate
Drain
Flow
Inlet and Outlet Connection Size (in.)
Drain
Line
Resin Tank Size (in.)
Brine
Tank
Ship Weight (lbs.) Operating Weight (lbs.)
Maximum Medium Minimum
Kilograins Pounds Salt Kilograins Pounds Salt Kilograins Pounds Salt Rated (gpm) 15 psi Pressure Drop Intermittent (gpm) 25 psi Pressure Drop Maximum (gpm) Volume - Max (gal.) Connection Size (in.) Min. Diameter (in.) Size (in.) Salt Capacity (lbs.)
2850E
Single
CES-2850E-60 60 30 50 18 40 12 227 35 3.5 125 1.5 0.75 0.75 12 x52 18 x40 425 200 860
CES-2850E-90 90 45 75 27 60 18 332 42 5.0 162 1.5 0.75 0.75 14 x65 24 x40 750 290 1,420
CES-2850E-120 120 60 100 36 80 24 434 44 7.0 198 1.5 0.75 0.75 16 x65 24 x40 750 360 1,600
9500E
Twin
CES-9500E-60 60 30 50 18 40 12 225 32 3.5 125 1.5 0.75 0.75 12 x52 18 x40 425 360 1,140
CES-9500E-90 90 45 75 27 60 18 328 36 5.0 159 1.5 0.75 0.75 14 x65 24 x40 750 520 1,880
CES-9500E-120 120 60 100 36 80 24 430 39 7.0 195 1.5 0.75 0.75 16 x65 24 x40 750 660 2,190
CES-9500E-150 150 75 125 45 100 30 531 40 9.0 243 1.5 1.00 1.00 18 x65 24 x40 750 840 2,570
2900E
Single
CES-2900E-120 120 60 100 36 80 24 447 60 7.0 195 21.00 1.00 16 x65 24 x40 750 360 1,600
CES-2900E-150 150 75 125 45 100 30 553 69 9.0 249 21.00 1.00 18 x65 24 x40 750 460 1,830
CES-2900E-210 210 105 175 63 140 42 757 74 12 363 21.00 1.00 21 x62 30 x48 1200 630 2650
CES-2900E-300 300 150 250 90 200 60 10 62 80 15.0 426 21.00 1.00 24 x72 30 x48 1,200 920 3,290
2900E
Duplex
Parallel
CES-2900E-120-DP 120 60 100 36 80 24 494 121 7.0 195 21.00 1.00 16 x65 24 x40 750 460 1,990
CES-2900E-150-DP 150 75 125 45 100 30 5106 137 9.0 249 21.00 1.00 18 x65 24 x40 750 880 2,610
CES-2900E-210-DP 210 105 175 63 140 42 7114 148 12.0 363 21.00 1.00 21 x62 30 x48 1,200 1,210 3,690
CES-2900E-300-DP 300 150 250 90 200 60 10 123 159 15.0 426 21.00 1.00 24 x72 30 x48 1,200 1,750 4,780
2900E
Triplex
Parallel
CES-2900E-120-TP 120 60 100 36 80 24 4141 181 7195 21.00 1.00 16 x65 30 x48 1200 794 2380
CES-2900E-150-TP 150 75 125 45 100 30 5159 206 9249 21.00 1.00 18 x65 30 x48 1200 1314 3390
CES-2900E-210-TP 210 105 175 63 140 42 7171 222 12 363 21.00 1.00 21 x62 39 x48 2200 1814 4730
CES-2900E-300-TP 300 150 250 90 200 60 10 185 239 15 426 21.00 1.00 24 x72 39 x48 2200 2644 6270
2900E
Quadplex
Parallel
CES-2900E-120-QP 120 60 100 36 80 24 4188 242 7195 21.00 1.00 16 x65 24 x40 1500 920 3980
CES-2900E -150-QP 150 75 125 45 100 30 5212 274 9249 21.00 1.00 18 x65 24 x40 1500 1760 5220
CES-2900E-210-QP 210 105 175 63 140 42 7228 296 12 363 21.00 1.00 21 x62 30 x48 2400 2420 7380
CES-2900E-300-QP 300 150 250 90 200 60 10 246 318 15 426 21.00 1.00 24 x72 30 x48 2400 3500 9560
3900E
Single
CES-3900E-300-HWBP 300 150 250 90 200 60 10 74 96 15 465 32.00 2.00 24 x72 30 x48 1200 970 3330
CES-3900E-450-HWBP 450 225 375 135 300 90 15 100 129 25 699 32.00 2.00 30 x72 30 x48 1200 1458 4378
3900E
Duplex*
CES-3900E-300-NHWB 300 150 250 90 200 60 10 148 192 15 465 32.00 2.00 24 x72 30 x48 2400 1940 6660
CES-3900E-450-NHWB 450 225 375 135 300 90 15 200 258 25 699 32.00 2.00 30 x72 30 x48 2400 2916 8756
3900E
Triplex*
CES-3900E-300-NHWB 300 150 250 90 200 60 10 222 288 15 465 32.00 2.00 24 x72 30 x48 3600 2910 9990
CES-3900E-450-NHWB 450 225 375 135 300 90 15 300 387 25 699 32.00 2.00 30 x72 30 x48 3600 4374 13134
3900E
Quadplex*
CES-3900E-300-NHWB 300 150 250 90 200 60 10 296 384 15 465 32.00 2.00 24 x72 30 x48 4800 3880 13320
CES-3900E-450-NHWB 450 225 375 135 300 90 15 400 516 25 699 32.00 2.00 30 x72 30 x48 4800 5832 17512
PERFORMANCE SPECIFICATIONS
*Purchasing Requirements: Duplex,2 units; Triplex, 3 units; and Quadplex, 4 units.

PENTAIR EVERPURE CES SERIES WATER SOFTENERS INSTALLATION, OPERATION & MAINTENANCE GUIDE FOODSERVICE.PENTAIR.COM • 3
Series Model
Cartons or Bags of Each Item
Control Valve(s)
and
Accessories
Mineral
Tank(s)
Brine
Tank Resin
Gravel
Bags Pounds per Tank
2850E
Single
CES-2850E-60 1 1 1 2 2 15
CES-2850E-90 1 1 1 3 1 25
CES-2850E-120 1 1 1 4 2 35
9500E
Twin
CES-9500E-60 1 2 1 4 4 15
CES-9500E-90 1 2 1 6 2 25
CES-9500E-120 1 2 1 8 4 35
CES-9500E-150 12110 450
2900E
Single
CES-2900E-120 1 1 1 4 2 35
CES-2900E-150 1 1 1 5 2 50
CES-2900E-210 1 1 1 7 4 80
CES-2900E-300 1 1 1 10 5125
2900E Duplex
Parallel
CES-2900E-120-DP 2 2 1 8 4 35
CES-2900E-150-DP 2 2 1 10 450
CES-2900E-210-DP 2 2 1 14 880
CES-2900E-300-DP 2 2 1 20 10 125
2900E Triplex
Parallel
CES-2900E-120-TP 3 3 1 12 635
CES-2900E-150-TP 3 3 1 15 650
CES-2900E-210-TP 3 3 1 21 12 80
CES-2900E-300-TP 3 3 1 30 15 125
2900E Quadplex
Parallel
CES-2900E-120-QP 4 4 2 16 835
CES-2900E -150-QP 4 4 2 20 850
CES-2900E-210-QP 4 4 2 28 16 80
CES-2900E-300-QP 4 4 2 40 20 125
3900E Single
CES-3900E-300-HWBP 1 1 1 10 2125
CES-3900E-450-HWBP 1 1 1 15 5250
CES-3900E-300-NHWB 1 1 1 10 2125
CES-3900E-450-NHWB 1 1 1 15 5250
UNPACKING AND INSPECTION
Your Pentair Everpure water softener should arrive on one or more shipping skids. Locate your specic model in the table below. Verify that
the specic quantities of boxes or bags indicated have arrived with the system and are undamaged:

4 • PENTAIR EVERPURE CES SERIES WATER SOFTENERS INSTALLATION, OPERATION & MAINTENANCE GUIDE FOODSERVICE.PENTAIR.COM
INSTALLATION
MINERAL TANK and CONTROL VALVE
1. Refer to the general arrangement drawings for typical
installation examples. The installation area should be reasonably
level, smooth, and capable of supporting the operating weight
of the system, including salt. See specication table on page 2
for operating weights. All systems include up to four (4) mineral
tanks and up to four (4) brine tanks. When determining the best
location, consider ease of access for:
a. Control valve adjustments and service
b. Replenishing the brine tank with salt
2. Position the mineral tank(s) in the desired location.
3. CES-3900-450-HWBP and CES-3900E-450-NHWB – 30" (762
mm) diameter mineral tank requires the installation of a ange
adaptor. Lubricate the ange adaptor O-ring with a silicone
based lubricant. Ensure your lubricant is NSF-approved. Position
the O-ring in the grooved area of the ange adaptor. Secure the
ange adaptor with the hardware provided. Tighten the bolts in
the order shown in the illustration below. Tighten to 11 ft-lbs.
111
53
7
10 9
4
812
6
2
4. This step is optional but is strongly recommended for larger
systems, so minimal mineral tank movement will be required
after lling the mineral tank with media. This does not apply to
3900E systems. Lubricate the O-rings on the base of the control
valve (or second tank adaptor) with a silicone based lubricant.
Ensure that your silicone based lubricant is NSF approved.
While centering distributor tube into the center port on the
control valve (or second tank adaptor) base, carefully engage
the threads on the control valve (or second tank adaptor) with
threads on the mineral tank. Screw control valve (or second
tank adaptor) tight. Adjust (rotate) mineral tank so control valve
(or second tank adaptor) faces the desired direction. Without
moving the mineral tank, remove the control valve (or second
tank adaptor.
IMPORTANT: Inspect distributor assembly for damage or missing
parts. Some models have a single point strainer, whereas other
models have a hub and lateral design. Inspect both types prior to
loading media. Ensure the laterals are secure.
5. Cover end of distributor tube with tape, plastic bag, etc. This
prevents media from entering distributor tube.
6. Position the distributor assembly in the tank and verify the
distributor tube height using the appropriate illustration below.
IMPORTANT: 2850E and 9500E Series only – distributor tube
should be ush with tank top, or slightly below. See example
below.
IMPORTANT: 2900 Series only - Distributor tube should be 0.25”
to 0.75” (6.35 mm to 19.05 mm) below top of tank. See example
below.
3900 Series Only – Distributor tube should be ush with tank top
(tank ange), or slightly above [+0.375” max. (+9.25 mm max.)].
See example below.

PENTAIR EVERPURE CES SERIES WATER SOFTENERS INSTALLATION, OPERATION & MAINTENANCE GUIDE FOODSERVICE.PENTAIR.COM • 5
IMPORTANT: CES-2900E-300, Single CES-2900E-300-DP, CES-
2900E-300-TP, and CES-2900-300-QP models only – distributor
assembly (hub) should be positioned as close to the center of the
mineral tank lower head as possible. Some mineral tanks have a
rise in the center of the lower head that may require positioning
the distributor assembly slightly off-center.
CES-3900E models only – Distributor assembly (hub) includes
a centering “cup” that allows the distributor assembly to be
positioned in the center of the tank. If the mineral tank has the
rise in the center of the lower head, position the distributor
assembly on this elevated area.
7. Add water to mineral tank. Fill tank at least 12” (304.8 mm)
above distributor slots and/or lateral arms to prevent damage
to distributor assembly when adding media.
8. Add gravel. See table on page 3 for quantities based on model.
DO NOT allow gravel to reposition the distributor assembly.
Check distributor pipe elevation – do not allow it to rise above
the specied level. Rock tank gently to level gravel if required.
WARNING
Gravel dust can be hazardous. Wear suitable dust
protection equipment. Wet bags to minimize dust.
9. Add resin. Use water to help “uidize” resin and speed-up lling
process. Resin does not require leveling.
10. Rinse top of mineral tank to remove resin from mineral tank
opening area and distributor tube.
11. Remove tape or bag from end of distributor tube.
12. Lubricate O-rings on base of control valve with an NSF-approved
silicone based lubricant.
13. Some models include a top collector that attaches to the base
of control valve. A raised edge on the top collector engages a
groove that is machined into the base of the control valve body.
If one has been provided, install it now. See typical examples below.
Most Models 3900E Series Only
14. Attach control valve to mineral tank.
a. 2850E, 9500E, 2900E Series only – Position upper collector
and/or control valve center port (distributor tube pilot) over
distributor tube, and engage. Rotate control valve clock-wise
while engaging threads. When tightened suciently, gap
between control valve base and mineral tank should be 1/16”
(1.59 mm) or less. Follow these same steps for the second tank
adaptor – 9500E Series only.
b. 3900 Series only – Refer to the illustration below. Lubricate
O-rings with an NSF-approved silicone based lubricant.
Position item 31 and 30 on the tank ange. Position item 24 in
the groove on the control valve base. Position upper collector
and control valve center port (distributor tube pilot) over
distributor tube, and engage. Position item 29 (2) over control
valve ange. Align bolt holes (item 29, 30 and tank ange).
Install fasteners loosely. Rotate control valve if required.
Tighten the bolts in the order shown in the illustration below.
Tighten to 11 ft-lbs.
111
53
7
10 9
4
812
6
2
INSTALLATION continued

6 • PENTAIR EVERPURE CES SERIES WATER SOFTENERS INSTALLATION, OPERATION & MAINTENANCE GUIDE FOODSERVICE.PENTAIR.COM
PIPING
1. Refer to the general arrangements drawings (pages 16–23) for
the location of inlet, outlet, drain and brine line connections.
2. At a minimum, the following plumbing components will be
required (not supplied unless noted):
a. Inlet and outlet sample valves (optional).
b. Unions – control inlet and outlet – (optional, but highly
recommended).
c. Pipe and ttings – Typically copper for the inlet, outlet,
bypass, and PVC for the drain line.
WARNING
Protect control valve, meter body and plastic
components from excessive heat. When sweating copper
ttings, pre-sweat the piping/ttings prior to connecting them
to the system.
3. 2850E, 9500E, 2900E, 2900E-DP, 2900E-TP, 2900E-QP and
3900E models only – Attach meter body directly to control valve
outlet. Connect the meter cable to the meter and control valve.
The arrow on the meter should point away from the control valve.
4. Install piping, valves, unions and other plumbing components to
control valve(s).
a. 2900E-DP, 2900E-TP and 2900E-QP Models Only – Use
identical lengths of piping and tting quantities to balance
ow/pressure drop through both mineral tanks.
5. Close all valves. Open bypass valve only. Pressurize plumbing
system and check for leaks. Flush plumbing to remove foreign
material (solder, copper shavings, etc.).
6. Keep all remaining valves closed until instructed to open them.
DRAIN LINE
WARNING
2850E, 9500E, 2900E and 3900E models require the
installation of an external DLFC (drain line ow control) device.
This item can be found in the carton with the control valve. The
DLFC has an arrow on it. The arrow points away from the control
valve when installed. Apply PTFE plumber’s tape to male pipe
threads and attach DLFC to control valve drain port.
INSTALLATION continued
BACKWASH and BRINE LINE CONNECTIONS
System Backwash
Connection Size
& Type
Minimum
Backwash Line
I.D.
Brine Line
Connection Brine Rell Rate (GPM)
2850E Series - 60, 90, 120
9500E Series - 60, 90, 120 3/4" Female NPT 3/4" 3/8" Compression 1.0
2900E Series - 120
2900E Series - 120-DP
2900E Series - 120-TP
2900E Series - 120-QP
1" Female NPT 1" 3/8" Compression 1.0
9500E Series - 150
2900E Series - 150, 210, 300
2900E Series - 150-DP, 210-DP, 300-DP
2900E Series - 150-TP, 210-TP, 300-TP
2900E Series - 150-QP, 210-QP, 300-QP
1" Female NPT 1" 1/2" Compression 2.0
3900E Series - 300-HWBP
3900E Series - 300-NHWB 2" Female NPT 2" 1" Male NPT 2.0
3900E Series - 450-HWBP
3900E Series - 450-NHWB 2" Female NPT 2" 1" Male NPT 5.0
NOTE: Refer to the drawing for your model in the back of this
manual for an image of the drain line connections.
1. Use rigid piping, such as PVC, for the drain piping.
2. The maximum vertical lift from the control drain port is 10 feet.
3. When excessively long horizontal runs are required, up-size the
drain piping as required.
4. Adhere to local and national plumbing codes. In all cases,
DO NOT connect the end of the drain piping directly to the
sewer/drain. Provide an air-gap and vacuum break so the system
is protected from cross contamination and vacuum.
9500E (60, 90, 120)
and 2850E series
3900E series
9500E (150),
2900E, 2900E-DP,
2900E-TP and
2900E-QP series

PENTAIR EVERPURE CES SERIES WATER SOFTENERS INSTALLATION, OPERATION & MAINTENANCE GUIDE FOODSERVICE.PENTAIR.COM • 7
INSTALLATION continued
BRINE TANK
1. Position the brine tank in the desired location. It should be
placed on a at surface, free of debris that could cut or puncture
the bottom.
NOTE: Refer to the drawing for your model in the back of this
manual for an image of the brine line connections.
2. All models except 3900E Series
a. Insert a brass tube support into one end of the brine line.
Connect this to the safety device in the brine well. Tighten the
nut securely.
b. Route the brine line to the control valve(s). Trim to length as
necessary.
c. Insert a brass tube support into the open end of the brine line.
Connect this to the brine valve on the control valve. Tighten
the nut securely.
3900E Series only
d. Connect ¾” (19.05 mm) ID minimum piping to the safety device
in the brine well. Include a non-metallic union for future service.
e. Route the piping to the control valve. Secure or support as
required.
f. Connect the brine line ow control (BLFC) to the brine valve on the
control valve. The arrow should point away from the brine valve.
g. Connect the piping or tubing to the 1” (25.4 mm) NPT
connection on the BLFC. Include a non-metallic union for
future service.
3. Fill the brine tank with water until the water level is 5-6” (127 - 152
mm) deep. Do not add salt until instructed to do so.
ELECTRICAL
2850E, 9500E, 2900E and 3900E (HWBP) Models only
(See Figure 1 and Figure 2 on pgs. 8 and 9.)
1. Remove screw adjacent to the open rectangular area on the
control valve.
2. Open control cover. Pull upper left of valve control to swing open.
3. Remove screw adjacent to the open rectangular area on the
meter cover (dome).
4. Insert meter probe on meter cable into rectangular opening.
Secure with screw.
5. Remove control cover.
6. Attach cord grip to backplate. Route meter cable through cord
grip and connect to P5.
7. Connect the provided 3-wire power cord with power supply to an
un-switched wall outlet.
8. Attach cord grip to backplate. Route power cable through cord
grip and connect to P14.
9. Connect power cable to power supply connected to wall outlet.
The control valve is now powered and may advance to the
service position.
10. Reattach cover. Go to the “Control Adjustments” section.
9500E Models only- Connecting Meter cable
1. Remove screw adjacent to the open rectangular area on the
meter cover (dome).
2. Insert meter probe on meter cable into rectangular opening.
Secure with screw.
3. Remove control cover.
4. Attach cord grip to backplate. Route meter cable through cord
grip and connect to P1. Reattach cover
5. Connect the provided 3-wire power cord to an un-switched wall
outlet. The control valve is now powered and may advance to the
service position. Go to the “Control Adjustments” section.
2900E-DP, 2900E-TP, 2900E-QP and multiple 3900E (NHWB) Models only
1. Remove screw adjacent to the open rectangular area on the
control cover.
2. Open control cover. Pull upper left of valve control to swing open.
3. (See Figure 1 and Figure 2 on pgs. 8 and 9 for the following steps.)
Remove screw adjacent to the open rectangular area on the
meter cover (dome).
4. Insert meter probe on meter cable into rectangular opening.
Secure with screw.
5. Remove control cover.
6. Attach cord grip to backplate. Route meter cable through cord
grip and connect to P5.
7. NETWORK/COMMUNICATION CABLES AND CONNECTIONS: Use
a shielded CAT5 Network/Communication cable. Connect the
network/communication cable rst before programming. Cable
length between timers/units should not exceed 25 feet.
8. Connect each unit in series (do not form a loop) together from
one communication port to the next communication port. It
does not matter which one goes to the next one.
9. Attach cord grip to backplate. Route CAT 5 cable through cord
grip and connect to P3 on circuit board.
10. Install network cable (CAT 5 cable) between circuit boards in P1
and/or P3. Make sure to route CAT 5 cable through cord grip.
11. Repeat steps 1 through 10 on the other control(s).
12. Connect the provided 3-wire power cord with power supply to
an un-switched wall outlet. Attach cord grip to backplate. Route
power cable through cord grip and connect to P14. Connect power
cable to power supply connected to wall outlet. Repeat process
for all control valves. The control valve is now powered and
may advance to the service position. Reattach cover. Go to the
“Control Adjustments” section.

8 • PENTAIR EVERPURE CES SERIES WATER SOFTENERS INSTALLATION, OPERATION & MAINTENANCE GUIDE FOODSERVICE.PENTAIR.COM
Figure 1
POWER SUPPLY , METER CABLE & CAT5 CONNECTIONS
2850/2900 Valves:
3900 Valves:
Communication Cables
Hinge Mount: mount per valve model noted
Meter Cable
Power Supply
Wire Harness
Communication Cables
Power Supply
Meter Cable
Wire Harness
Hinge Mount: mount per valve model noted

PENTAIR EVERPURE CES SERIES WATER SOFTENERS INSTALLATION, OPERATION & MAINTENANCE GUIDE FOODSERVICE.PENTAIR.COM • 9
NXT2 WIRING DIAGRAM
VDM
VDM
IMPORTANT: DO NOT USE P18 TO POWER NON-PENTAIR DEVICES; USE AUX1 & AUX2 INSTEAD
Figure 2

10 • PENTAIR EVERPURE CES SERIES WATER SOFTENERS INSTALLATION, OPERATION & MAINTENANCE GUIDE FOODSERVICE.PENTAIR.COM
CONTROL ADJUSTMENTS
DETERMINING CAPACITY
Refer to the specication table (page 2) for exchange capacity of
each model based on salt dosage.
9500E Models only – The operational mode for this group is metered
immediate. In this case, “reserve capacity” is not required.
2900E-DP, 2900E-TP, 2900E-QP, 3900E-300-NHWB, and
3900E-450-NHWB Models only –The operational mode for this
series can vary based on the application. In most cases, the
system will operate in meter immediate mode, (system 14), so the
regeneration occurs as needed, on only one tank at a time.
2850E, 2900E, 3900E-300-HWBP, and 3900E-450-HWBP Models
only – The operational mode for all single softeners is system 4 -
meter delayed. The unit should be programmed to regenerate at an
off-peak time period, such as 2:00 AM. Since this type of system
only examines the need to regenerate once every 24 hours, a
“reserve capacity” is automatically calculated. The NXT2 controller
automatically calculates the reserve capacity and adjusts based on
daily usage.
PROGRAMMING
2850E, 2900E, 2900E-DP, 2900E-TP, 2900E-QP and 3900E
Models only
Refer to the “3200NXT2 Timer Service Manual” and associated
inserts for detailed programming information. A table has been
provided on page 11–12 to assist with programming specic time
intervals based on model and system capacity.
NOTE: 2900E-DP, 2900E-TP, and 2900E-QP Models only –
The programming of each control varies slightly. One control is
programmed as the “LEAD” and the other as the “LAG”.
9500 Models only: See pages 13–14. Master Programming Mode
2850E, 2900E, 2900E-DP, 2900E-TP, 2900E-QP and 3900E Models only
1. Press and hold the Left and Down buttons simultaneously for 3
seconds to enter Master Programming mode.
2. To navigate, press the Extra Cycle button to advance to the next
value. Press the Left button to retreat to the previous value.
3. Where applicable, use the Down and Up buttons to adjust a
value as desired. When entering data into text elds (such as
Assistance Name) or numerical elds (such as Hardness), press
the Extra Cycle button to advance to the next character/digit and
press the Left button to retreat to the previous character/digit.
Proceed through all available characters/digits to advance to the
next value.
4. To reset/clear a value (such as Assistance Name), while on the
value, press and hold the Down and Up buttons simultaneously
for 5 seconds.
5. To exit Master Programming Mode, progress through all
available values or after 5 minutes of inactivity the timer will
exit automatically. To exit master programming without saving
changes, press the Left button until you return to the service
screen.
6. Depending on the current controller programming, certain
values may not be able to be viewed or set.
7. The timer will display local information, not system information.
8. In the event of a regeneration occurring while displaying master
programming, the regeneration step and time remaining will be
displayed. When regeneration has been completed, the display
will return to the main screen.
NOTE: Refer to page 9 of the “Pentair Fleck NXT2 Timer Service Manual” for more detailed information
Min. – Minimum system capacity – based on 6 lbs (2.72 kg) of salt per Ft3(0.028 M3) of resin.
Med. – Medium system capacity – based on 9 lbs (4.1 kg) of salt per Ft3(0.028 M3) of resin.
Max. – Maximum system capacity – based on 15 lbs (6.8 kg) of salt per Ft3(0.028 M3) of resin.
WITH SOFTENER VALVE CONTROL SETTINGS
The following table includes the recommended time durations
for each regeneration step. These values are based on a typical
application. Under certain conditions, these values may require
some adjustment. Refer to the performance specications table
on page 2 to determine the usable capacity of the system, based on
salt dosage. A detailed description of the “Brine Rinse” and “Brine
Tank Rell” time settings has been outlined below:

PENTAIR EVERPURE CES SERIES WATER SOFTENERS INSTALLATION, OPERATION & MAINTENANCE GUIDE FOODSERVICE.PENTAIR.COM • 11
Series Model
System Setting # Tanks
Trip Point 1 Trip Point 2 Trip Point 3 Valve Regen
Flow
Regen. Type
Capacity Reserve Remote Regneration Remote Signal Duration Day Override/Time- Drive Trip Point Service Duration Standby Duration Trip Point Service Duration Standby Duration Trip Point Service Duration Standby Duration
2850E
Single
CES-2850E-60 4 1 * * * * * * * * * 2850 Down-
ow
Softener Meter
Delayed
Ref.
Spec
Vari-
able
OFF N/A 14 D
CES-2850E-90 4 1 * * * * * * * * * 2850 Down-
ow
Softener Meter
Delayed
Ref.
Spec
Vari-
able
OFF N/A 14 D
CES-2850E-120 4 1 * * * * * * * * * 2850 Down-
ow
Softener Meter
Delayed
Ref.
Spec
Vari-
able
OFF N/A 14 D
2900E
Single
CES-2900E-120 4 1 * * * * * * * * * 2900 Down-
ow
Softener Meter
Delayed
Ref.
Spec
Vari-
able
OFF N/A 14 D
CES-2900E-150 4 1 * * * * * * * * * 2900 Down-
ow
Softener Meter
Delayed
Ref.
Spec
Vari-
able
OFF N/A 14 D
CES-2900E-210 4 1 * * * * * * * * * 2900 Down-
ow
Softener Meter
Delayed
Ref.
Spec
Vari-
able
OFF N/A 14 D
CES-2900E-300 4 1 * * * * * * * * * 2900 Down-
ow
Softener Meter
Delayed
Ref.
Spec
Vari-
able
OFF N/A 14 D
2900E
Duplex
Parallel
CES-2900E-120-DP 14 2 47 5 300 * * * * * * 2900 Down-
ow
Softener Meter
Immediate
Ref.
Spec
Vari-
able
OFF N/A 14 D
CES-2900E-150-DP 14 2 53 5 300 * * * * * * 2900 Down-
ow
Softener Meter
Immediate
Ref.
Spec
Vari-
able
OFF N/A 14 D
CES-2900E-210-DP 14 2 57 5 300 * * * * * * 2900 Down-
ow
Softener Meter
Immediate
Ref.
Spec
Vari-
able
OFF N/A 14 D
CES-2900E-300-DP 14 2 62 5 300 * * * * * * 2900 Down-
ow
Softener Meter
Immediate
Ref.
Spec
Vari-
able
OFF N/A 14 D
Chart continued below.
Series Model
Regen. Time Lock Window #1
Regeneration Cycle Time - Minutes
Meter Type Continous Flow Detect Meter Type Auxillary 1 Meter Type Auxillary 2 Meter Type Push Setting Meter Type Save As Non-Factory Meter Type Lock Settings Meter Type, Enter code:
Cycle
#1
Cycle #2 Cycle
#3
Cycle #4
Pause Backwash
Brine Rinse
(Draw)
Rapid
Rinse
Brine Tank Rell
Min. Med. Max. Min. Med. Max.
2850E
Single
CES-2850E-60 0200 OFF 10 40 50 60 10 4 6 10 0 1.5” P OFF OFF OFF OFF ON 1201
CES-2850E-90 0200 OFF 10 40 50 60 10 6 9 15 0 1.5” P OFF OFF OFF OFF ON 1201
CES-2850E-120 0200 OFF 10 40 50 60 10 8 12 20 0 1.5” P OFF OFF OFF OFF ON 1201
2900E
Single
CES-2900E-120 0200 OFF 10 40 50 60 10 8 12 20 0 2.0” P OFF OFF OFF OFF ON 1201
CES-2900E-150 0200 OFF 10 40 50 60 10 5 8 13 0 2.0” P OFF OFF OFF OFF ON 1201
CES-2900E-210 0200 OFF 10 40 50 60 10 7 11 18 0 2.0” P OFF OFF OFF OFF ON 1201
CES-2900E-300 0200 OFF 10 40 50 60 10 10 15 25 0 2.0” P OFF OFF OFF OFF ON 1201
2900E
Duplex
Parallel
CES-2900E-120-DP 0200 OFF 10 40 50 60 10 8 12 20 0 2.0” P OFF OFF OFF ON ON 1201
CES-2900E-150-DP 0200 OFF 10 40 50 60 10 8 13 21 0 2.0” P OFF OFF OFF ON ON 1201
CES-2900E-210-DP 0200 OFF 10 40 50 60 10 7 11 18 0 2.0” P OFF OFF OFF ON ON 1201
CES-2900E-300-DP 0200 OFF 10 40 50 60 10 10 15 25 0 2.0” P OFF OFF OFF ON ON 1201
*This step does not apply. The programming proceeds to the next step.
MASTER PROGRAMMING MODE continued
2850E, 2900E, and 2900E-DP models only

12 • PENTAIR EVERPURE CES SERIES WATER SOFTENERS INSTALLATION, OPERATION & MAINTENANCE GUIDE FOODSERVICE.PENTAIR.COM
Series Model
System Setting # Tanks
Trip Point 1 Trip Point 2 Trip Point 3 Valve Regen
Flow
Regen. Type
Capacity Reserve Remote Regneration Remote Signal Duration Day Override/Time- Drive
Trip Point Service Duration Standby Duration Trip Point Service Duration Standby Duration Trip Point Service Duration Standby Duration
2900E
Triplex
Parallel
CES-2900E-120-TP 14 3 47 5 300 94 5 300 * * * 2900 Down-
ow
Softener Meter
Immediate
Ref.
Spec
Vari-
able
OFF N/A 14 D
CES-2900E-150-TP 14 3 53 5 300 106 5 300 * * * 2900 Down-
ow
Softener Meter
Immediate
Ref.
Spec
Vari-
able
OFF N/A 14 D
CES-2900E-210-TP 14 3 57 5 300 114 5 300 * * * 2900 Down-
ow
Softener Meter
Immediate
Ref.
Spec
Vari-
able
OFF N/A 14 D
CES-2900E-300-TP 14 3 62 5 300 124 5 300 * * * 2900 Down-
ow
Softener Meter
Immediate
Ref.
Spec
Vari-
able
OFF N/A 14 D
2900E
Quadplex
Parallel
CES-2900E-120-QP 14 4 47 5 300 94 5 300 141 5 300 2900 Down-
ow
Softener Meter
Immediate
Ref.
Spec
Vari-
able
OFF N/A 14 D
CES-2900E -150-QP 14 4 53 5 300 106 5 300 159 5 300 2900 Down-
ow
Softener Meter
Immediate
Ref.
Spec
Vari-
able
OFF N/A 14 D
CES-2900E-210-QP 14 4 57 5 300 114 5 300 171 5 300 2900 Down-
ow
Softener Meter
Immediate
Ref.
Spec
Vari-
able
OFF N/A 14 D
CES-2900E-300-QP 14 4 62 5 300 124 5 300 186 5 300 2900 Down-
ow
Softener Meter
Immediate
Ref.
Spec
Vari-
able
OFF N/A 14 D
3900E
Single
CES-3900E-300-HWBP 4 1 74 * * * * * * * * 3900 Down-
ow
Softener Meter
Delayed
Ref.
Spec
Vari-
able
OFF N/A 14 D
CES-3900E-450-HWBP 4 1 100 * * * * * * * * 3900 Down-
ow
Softener Meter
Delayed
Ref.
Spec
Vari-
able
OFF N/A 14 D
CES-3900E-300-NHWB 14† 1 74† 5† 300† 148† 5† 300† 222† 5† 300† 3900 Down-
ow
Softener Meter
Immediate
Ref.
Spec
Vari-
able
OFF N/A 14 D
CES-3900E-450-NHWB 14† 1 100† 5† 300† 200† 5† 300† 300† 5† 300† 3900 Down-
ow
Softener Meter
Immediate
Ref.
Spec
Vari-
able
OFF N/A 14 D
Chart continued below.
Series Model
Regen. Time Lock Window #1
Regeneration Cycle Time - Minutes
Meter Type Continous Flow Detect Meter Type Auxillary 1 Meter Type Auxillary 2 Meter Type Push Setting Meter Type Save As Non-Factory Meter Type Lock Settings Meter Type, Enter code:
Cycle
#1
Cycle #2 Cycle
#3
Cycle #4
Pause Backwash
Brine Rinse
(Draw)
Rapid
Rinse
Brine Tank Rell
Min. Med. Max. Min. Med. Max.
2900E
Triplex
Parallel
CES-2900E-120-TP 0200 OFF 10 40 50 60 10 8 12 20 0 2.0” P OFF OFF OFF ON ON 1201
CES-2900E-150-TP 0200 OFF 10 40 50 60 10 8 13 21 0 2.0” P OFF OFF OFF ON ON 1201
CES-2900E-210-TP 0200 OFF 10 40 50 60 10 7 11 18 0 2.0” P OFF OFF OFF ON ON 1201
CES-2900E-300-TP 0200 OFF 10 40 50 60 10 10 15 25 0 2.0” P OFF OFF OFF ON ON 1201
2900E
Quadplex
Parallel
CES-2900E-120-QP 0200 OFF 10 40 50 60 10 8 12 20 0 2.0” P OFF OFF OFF ON ON 1201
CES-2900E -150-QP 0200 OFF 10 40 50 60 10 8 13 21 0 2.0” P OFF OFF OFF ON ON 1201
CES-2900E-210-QP 0200 OFF 10 40 50 60 10 7 11 18 0 2.0” P OFF OFF OFF ON ON 1201
CES-2900E-300-QP 0200 OFF 10 40 50 60 10 10 15 25 0 2.0” P OFF OFF OFF ON ON 1201
3900E
Single
CES-3900E-300-HWBP 0200 OFF 10 40 50 60 10 10 14 25 0 3.0” P OFF OFF OFF OFF ON 1201
CES-3900E-450-HWBP 0200 OFF 10 40 50 60 10 6 8 15 0 3.0” P OFF OFF OFF OFF ON 1201
CES-3900E-300-NHWB 0200 OFF 10 40 50 60 10 10 14 25 0 3.0” P OFF OFF OFF ON ON 1201
CES-3900E-450-NHWB 0200 OFF 10 40 50 60 10 6 8 15 0 3.0” P OFF OFF OFF ON ON 1201
* This step does not apply. The programming proceeds to the next step.
† If ran in parallel.
MASTER PROGRAMMING MODE continued
2900E-TP, 2900E-QP and 3900E models only

PENTAIR EVERPURE CES SERIES WATER SOFTENERS INSTALLATION, OPERATION & MAINTENANCE GUIDE FOODSERVICE.PENTAIR.COM • 13
MASTER PROGRAMMING MODE continued
9500E Series only
When the Master Programming Mode is entered, all available
option setting displays may be viewed and set as needed.
Depending on current option settings, some parameters cannot
be viewed or set. Setting the Time of Day
1. Press and hold either the Up or Down buttons until the
programming icon replaces the service icon and the parameter
display reads DO.
2. Adjust the displayed time with the Up and Down buttons.
3. When the desired time is set, press the Extra Cycle button to
resume normal operation. The unit will also return to normal
operation after 5 seconds if no buttons are pressed
Entering Master Programming Mode
Set the Time Of Day display to 12:01 P.M. Press the Extra Cycle
button (to exit Setting Time of Day mode). Then press and hold
the Up and Down buttons together until the programming icon
replaces the service icon and the Display Format screen appears.
Exiting Master Programming Mode
Press the Extra Cycle button to accept the displayed settings and
cycle to the next parameter. Press the Extra Cycle button at the
last parameter to save all settings and return to normal operation.
The control will automatically disregard any programming
changes and return to normal operation if it is left in Master
Programming mode for 5 minutes without any keypad input.
NOTE: Refer to page 5 of the “Fleck SXT Timer Service Manual” for more detailed information
Series Model Display
Format
Valve
Type
Control
Type
Number
of Tanks
Tank in
Service*
Unit
Capacity
Feedwater
Hardness
Reserve
Selection
Safety
Factor
Fixed
Reserve
Capacity
Day
Override
9500E
Twin
CES-9500E-60 GAL dF1b FI 2 U1 Ref. Spec Enter Water
Hardness
rc 0 0 14
CES-9500E-90 GAL dF1b FI 2 U1 Ref. Spec Enter Water
Hardness
rc 0 0 14
CES-9500E-120 GAL dF1b FI 2 U1 Ref. Spec Enter Water
Hardness
rc 0 0 14
CES-9500E-150 GAL dF1b FI 2 U1 Ref. Spec Enter Water
Hardness
rc 0 0 14
Chart continued below.
Series Model Regeneration
Time
Regeneration Cycle Time - Minutes Flow Meter
Type
Cycle #1 Cycle #2 Cycle #3 Cycle #4
Backwash
(BW)
Brine Draw (BD) Brine Tank Rell (BF) Rapid
Rinse (RR)
Min. Med. Max. Min. Med. Max.
9500E
Twin
CES-9500E-60 2:00 AM 10 40 50 60 4 6 10 10 P1.5
CES-9500E-90 2:00 AM 10 40 50 60 6 9 15 10 P1.5
CES-9500E-120 2:00 AM 10 40 50 60 8 12 20 10 P1.5
CES-9500E-150 2:00 AM 10 40 50 60 10 15 25 10 P1.5
9500E SERIES PROGRAMMING

14 • PENTAIR EVERPURE CES SERIES WATER SOFTENERS INSTALLATION, OPERATION & MAINTENANCE GUIDE FOODSERVICE.PENTAIR.COM
MASTER PROGRAMMING MODE continued
9500E Series only
TANK IN SERVICE* INSTRUCTIONS
If the bottom arrow is pointed down to Tank 1 then program Tank
in Service to U1. If the bottom arrow is pointed up to Tank 2 then
program Tank in Service to U2.
Start-Up Instructions
Refer to page 15 under Commissioning: Mineral Tank Fill - Operational
Check-Out for more details on testing brine ll, draw and oat test.
1. Slowly open the inlet water valve and allow softener to ll with
water.
2. Press and hold “Extra Cycle” button for 5 seconds until the valve
begins to cycle to BW, allow softener to backwash until air is
expelled from softener and water is running clear and smooth
down the drain.
3. Advance control valve to BD Brine Draw by pressing the
“Extra Cycle” button.
4. Advance control valve to RR Rapid Rinse by pressing the
“Extra Cycle” button.
5. Advance control valve to BF Brine Fill by pressing the “Extra
Cycle” button. Allow softener to ll brine tank to the top of the
air check. Once the water level is above the air check press the
“Extra Cycle” button to return the valve back to service
6. Repeat steps 2-5 for the second tank but for step 5 you would
allow the softener to do a complete brine ll cycle and allow the
unit to return to service on its own
7. Open outlet bypass valve.
Control Valve Position Indicators
Safety Brine Valve

PENTAIR EVERPURE CES SERIES WATER SOFTENERS INSTALLATION, OPERATION & MAINTENANCE GUIDE FOODSERVICE.PENTAIR.COM • 15
COMMISSIONING
MINERAL TANK FILL – OPERATIONAL CHECK-OUT
1. Manually initiate a regeneration cycle. The control valve will
advance to the backwash position. PARTIALLY open the inlet
isolation valve to allow water to SLOWLY enter the mineral tank
and purge the mineral tank of air.
WARNING
Limit the ow of water into the mineral tank at this
time. Opening the inlet isolation valve too far may expand the
resin bed too greatly and cause resin loss to drain. Observe the
water exiting to drain during this time for the presence of resin.
Throttle inlet isolation valve as required.
2. Once the air is purged, open the inlet valve fully and allow water
to run to drain for ve (5) minutes. Continue to check for the
presence of resin during this time. If resin appears, close inlet
valve and re-check system.
a. Manually advance the control valve to the fast rinse
position. The ow to drain will be the same as in backwash.
Allow the unit to remain in this mode for two (2) minutes. Then
advance valve to next step - brine rell.
WARNING
Observe the water exiting to drain during this time
for the presence of resin. If resin loss is observed, close inlet
isolation valve. Contact technical service –1.800.942.1153.
b. Once in brine rell, no ow will be present at the drain.
Observe the water level in the brine tank - the level will be
ascending.
c. Raise brine oat, ensure there are no leaks and make
sure that the water ow into the brine tank has stopped. Once no
leaks are found, release the brine oat.
d. Fill brine tank with salt.
3. Manually advance the control valve to the brine rinse position.
The ow to drain will be about 1/3 the ow in backwash. Observe
the water level in the brine tank – the level should descend,
and within a few minutes, the air-check should seat. A distinct
change will be heard in the “tone” of the control valve.
WARNING
Observe the water exiting to drain during this time
for the presence of resin. If resin loss is observed, close inlet
isolation valve. Contact technical service – 1.800.942.1153.
Manually advance the control valve to the fast rinse position. This
process can also be used to test the water hardness reduction
of each individual tank in a system. The ow to drain will be the
same as in backwash. Allow the unit to remain in this mode until it
automatically advances to the next step – brine rell.
WARNING
Observe the water exiting to drain during this time
for the presence of resin. If resin loss is observed, close inlet
isolation valve. Contact technical service –1.800.942.1153.
4. Once in brine rell, no ow will be present at the drain. Observe
the water level in the brine tank – the level will be ascending.
5. 2850E, 2900E, 3900E-300-HWBP, and 3900E-450-HWBP
Models only – Allow the control to remain in this step for the
programmed time. The control valve will advance automatically
to service.
9500E Series only see page 14 for additional instructions to
bring softener into service.
2900E-DP, 2900E-TP, 2900E-QP, 3900E-300-NHWB, and
3900E-450-NHWB Models only – Advance the control valve to
the service position. Repeat steps 1–5 on each additional mineral
tank/control valve.
NOTE: The next steps require placing the system “online”. Failure
to follow these steps closely could interrupt the water supply to
the downstream equipment.
VERIFY FLOW METER CONTROL
1. Open manual outlet isolation valve.
2. Close bypass valve.
3. Demand water from a downstream device, or piece of
equipment.
2850E, 9500E, 2900E, 2900E-DP, 2900E-TP, 2900E-QP and
3900E Models only – Observe the ow rate reading on the
display unit of the control valve. If possible, measure the ow
and compare this ow rate to what’s displayed. If the ows are
noticeably different, verify the controller settings – specically
the “Flow Meter Size” setting.
TESTING FOR SOFT WATER
2850E, 9500E, 2900E, 3900E-300-HWBP, and 3900E-450-HWBP
Models only –
1. Open a downstream plumbing xture or soft water sample port
and allow water to run for a few minutes.
2. Collect a sample and test for the presence of hardness – should
be <3 GPG (51.3 mg/L). If hardness is higher, re-check after
several minutes. If a hardness level of <3 GPG (51.3 mg/L) cannot
be attained, re-check bypass valves (fully closed) or refer
to control valve manual troubleshooting section for further
assistance.
3. Close downstream plumbing xture or soft water sample port.
4. System is now in service.
2900E-DP, 2900E-TP, 2900E-QP, 3900E-300-NHWB, and
3900E-450-NHWB Models only –
1. Refer to step 3 of pg. 15 under Commissioning: Mineral Tank Fill -
Operational Check-Out to test for soft water during rapid rinse.

16 • PENTAIR EVERPURE CES SERIES WATER SOFTENERS INSTALLATION, OPERATION & MAINTENANCE GUIDE FOODSERVICE.PENTAIR.COM
2850E SERIES DRAWING
TOP VIEW
FRONT VIEW

PENTAIR EVERPURE CES SERIES WATER SOFTENERS INSTALLATION, OPERATION & MAINTENANCE GUIDE FOODSERVICE.PENTAIR.COM • 17
9500E SERIES DRAWING
TOP VIEW
FRONT VIEW

18 • PENTAIR EVERPURE CES SERIES WATER SOFTENERS INSTALLATION, OPERATION & MAINTENANCE GUIDE FOODSERVICE.PENTAIR.COM
2900E SERIES DRAWING
TOP VIEW
FRONT VIEW

PENTAIR EVERPURE CES SERIES WATER SOFTENERS INSTALLATION, OPERATION & MAINTENANCE GUIDE FOODSERVICE.PENTAIR.COM • 19
2900E-DP SERIES DRAWING
TOP VIEW
FRONT VIEW

20 • PENTAIR EVERPURE CES SERIES WATER SOFTENERS INSTALLATION, OPERATION & MAINTENANCE GUIDE FOODSERVICE.PENTAIR.COM
2900E-TP SERIES DRAWING
TOP VIEW
FRONT VIEW
