OWNER’S MANUAL
Vertical Jet Pumps
© 2013 Pentair Ltd. All Rights Reserved. AE757-1 (REV 01/16/13)
293 WRIGHT STREET, DELAVAN, WI 53115 WWW.AERMOTOR.COM
PH: 8002301816
INSTALLATION AND OPERATION
Models VNA2 Series Multi-Stage
Horsepower Range: 1 - 2 H.P.
60 Cycle
Single Phase Installations
Owner’s Record
Pump Model:
Pump Serial No.:
Pump Date Code:
Motor H.P. Voltage Phase
Date of Installation:
Owner:
Installer:
Installer Phone Number:

Safety 2
READ AND FOLLOW
SAFETY INSTRUCTIONS!
This is the safety alert symbol. When you see this
symbol on your pump or in this manual, look for
one of the following signal words and be alert to the
potential for personal injury:
warns about hazards that will cause serious
personal injury, death or major property damage if
ignored.
warns about hazards that can cause serious
personal injury, death or major property damage if
ignored.
warns about hazards that will or can cause
minor personal injury or property damage if ignored.
The label NOTICE indicates special instructions which
are important but not related to hazards.
Carefully read and follow all safety instructions in this
manual and on pump.
Keep safety labels in good condition.
Replace missing or damaged safety labels.
Make workshops childproof; use padlocks and master
switches; remove starter keys.
California Proposition 65 Warning
This product and related accessories
contain chemicals known to the State of California to
cause cancer, birth defects or other reproductive harm.
ELECTRICAL SAFETY
Capacitor voltage may be hazardous.
To discharge motor capacitor, hold insulated handle
screwdriver BY THE HANDLE and short capacitor
terminals together. Do not touch metal screwdriver
blade or capacitor terminals. If in doubt, consult a
qualified
electrician.
GENERAL SAFETY
Do not touch an operating motor. Modern
motors are designed to operate at high temperatures. To
avoid burns when servicing pump, allow it to cool for 20
minutes after shut-down before handling.
Do not allow pump or any system component to freeze.
Freezing may damage system, leading to injury or
flooding. Allowing pump or system components to freeze
will void warranty.
Relief valve must be capable of passing full pump flow at
75 PSI.
Pump water only with this pump.
Periodically inspect pump and system components.
Wear safety glasses at all times when working on pumps.
Keep work area clean, uncluttered and properly lighted;
store properly all unused tools and equipment.
Keep visitors at a safe distance from the work areas.
WARNING
Hazardous pressure!
Install pressure relief
valve in discharge pipe.
Release all pressure on
system before working on
any component.
WARNING
Hazardous voltage.
Can shock, burn, or
cause death.
Ground pump before
connecting to power
supply. Disconnect power
before working on pump,
motor or tank.
Wire motor for correct
voltage. See “Electrical”
section of this manual and
motor nameplate.
Ground motor before
connecting to power
supply.
Meet National Electrical
Code, Canadian
Electrical Code, and local
codes for all wiring.
Follow wiring
instructions in this
manual when connecting
motor to power lines.

Table of Contents 3
Page
General Safety .....................................................................................................2
Warranty..............................................................................................................3
Installation........................................................................................................4-7
Electrical...........................................................................................................8-9
Operation .....................................................................................................10-11
Maintenance.................................................................................................12-13
Troubleshooting.................................................................................................14
Repair Parts .................................................................................................15-16
Limited Warranty
AERMOTOR warrants to the original consumer purchaser (“Purchaser” or “You”) of the products listed below, that they will be
free from defects in material and workmanship for the Warranty Period shown below.
Product Warranty Period
Jet pumps, small centrifugal pumps, submersible pumps and
relatedaccessories
whichever occurs first:
12 months from date of original installation, or
18 months from date of manufacture
Pro-Source™ Composite Tanks 5 years from date of original installation
Pro-Source™ Steel Pressure Tanks 5 years from date of original installation
Pro-Source™ Epoxy-Lined Tanks 3 years from date of original installation
Sump/Sewage/Effluent Products 12 months from date of original installation, or
18 months from date of manufacture
Our warranty will not apply to any product that, in our sole judgement, has been subject to negligence, misapplication,
improper installation, or improper maintenance. Without limiting the foregoing, operating a three phase motor with single phase
power through a phase converter will void the warranty. Note also that three phase motors must be protected by three-leg,
ambient compensated, extra-quick trip overload relays of the recommended size or the warranty is void.
Your only remedy, and AERMOTOR’s only duty, is that AERMOTOR repair or replace defective products (at AERMOTOR’s
choice). You must pay all labor and shipping charges associated with this warranty and must request warranty service through the
installing dealer as soon as a problem is discovered. No request for service will be accepted if received after the Warranty Period
has expired. This warranty is not transferable.
AERMOTOR SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL, INCIDENTAL, OR CONTINGENT
DAMAGESWHATSOEVER.
THE FOREGOING LIMITED WARRANTIES ARE EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESS AND IMPLIED
WARRANTIES, INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE. THE FOREGOING LIMITED WARRANTIES SHALL NOT EXTEND BEYOND THE DURATION
PROVIDED HEREIN.
Some states do not allow the exclusion or limitation of incidental or consequential damages or limitations on the duration of an
implied warranty, so the above limitations or exclusions may not apply to You. This warranty gives You specific legal rights and
You may also have other rights which vary from state to state.
This Limited Warranty is effective June 1, 2011 and replaces all undated warranties and warranties dated before June 1, 2011.
AERMOTOR
293 Wright Street • Delavan, WI U.S.A. 53115
Phone: [phone] • Fax: [phone] • Web Site: aermotor.com

1096 0697
Pump
Body
From
Well
Dirt and Scale Plug Pump and Pipes!
Use New Pipe for Best Results.
Clean Flow!
1100 0697
No Sags
Sags Allow Air Pockets
If Air Pockets Form, Water Won’t Flow.
Keep Pipe Straight and Angled up to Pump.
1101 0697
Figure 1: No Dirt or Scale in Suction
Pipe
Figure 2: Foot Valve Must Work Freely
Figure 3: No Air Pockets in Suction
Pipe
Installation 4
Figure 4: Suction Pipe Must Not Leak
BEFORE YOU INSTALL YOUR PUMP
NOTE: For proper performance, pump MUST be matched to ejector and
to well depth. Use shallow well installation for wells up to 25 ft depth to
water and deep well ejector for depths up to 130 ft.
Step 1. Long runs and many fittings increase friction and reduce flow.
Locate pump as close to well as possible: use as few elbows and
fittings as possible.
Step 2. Be sure well is clear of sand. Sand will plug the pump and void the
warranty.
Step 3. Protect pump and all piping from freezing. Freezing will split pipe,
damage pump and void the warranty. Check locally for frost pro-
tection requirements (usually pipe must by 12” below frost line and
pump must be insulated).
Step 4. Be sure all pipes and foot valve are clean and in good shape.
Step 5. No air pockets in suction pipe.
Step 6. No leaks in suction pipe. Use PTFE pipe thread sealant tape to seal
pipe joints.
Step 7. Match pump to well.
IMPORTANT: Flow into well must at least equal flow out through
pump!
Step 8. Unions installed near pump and well will aid in servicing. Leave
room to use wrenches.
Step 9. Plug 1” drive port when installing on shallow well.
SHALLOW WELL/CENTRIFUGAL INSTALLATION
No ejector is used in this case, plug the smaller of the two inlet ports,
using the larger for the suction pipe. Refer to Figure 6 for installation tips.
Maximum depth to water for shallow well/centrifugal operation is 25 feet.
NOTE: To avoid pump overloading and motor failure, install a flow control
valve at the discharge to limit flow to 20 gallons per minute.
1102 0697
No Air Leaks
in Suction Pipe.
Pipe Joint
Compound Will
Damage Plastic.
If Air Flows
Water Won’t
Use PTFE Tape
Be sure
entire
well
point is
below
water.
Drive
Coupling
Drive
Point
Check
Valve
1" NPT
Plug
Well
Casing
1" NPT
Plug
Well
Casing
Foot
Valve &
Strainer
Foot
Valve &
Strainer
Shallow well is less
than 25' (7.6M)
to water with
pump running.
Deep well is more
than 25' (7.6M)
to water with
pump running.
822 0697
Figure 5: Double Pipe Deep Well Figure 6: Cased Shallow Well
and Drive Point Shallow Well
Be sure
entire
well
point is
below
water.
Drive
Coupling
Drive
Point
Check
Valve
1" NPT
Plug
Well
Casing
1" NPT
Plug
Well
Casing
Foot
Valve &
Strainer
Foot
Valve &
Strainer
Shallow well is less
than 25' (7.6M)
to water with
pump running.
Deep well is more
than 25' (7.6M)
to water with
pump running.
822 0697

Installation 5
PIPING IN THE DEEP WELL
See Figures 7 and 8.
NOTE: Deep well installations are either single pipe (2” wells) or double
pipe (4” and larger wells). In a double pipe installation, the larger pipe is
the suction pipe and the smaller pipe is the drive pipe (very deep wells
may use suction and drive pipes of the same diameter).
Plastic pipe is ideal for double pipe installations. Due to its light weight, it
is easy to handle and does not usually require a block and tackle for instal-
lation and removal.
PLASTIC PIPE INSTALLATION – DOUBLE PIPE
NOTE: Use PTFE pipe thread sealant tape on all male threads on plastic
pipe and fittings to prevent air leaks in suction piping.
Step 1. Inspect ejector to make sure that nozzle and venturi openings are
clean and clear.
Step 2. Inspect pipe for any foreign matter or obstructions.
IMPORTANT: Make sure that no foreign matter enters pipe open-
ings while installing pump.
Step 3. Make sure foot valve operates freely: attach to ejector with a close
nipple. Use PTFE pipe thread sealant tape on male threads.
Step 4. Install nozzle and venturi in deep well ejector.
Step 5. Using PTFE pipe thread sealant tape on male threads, install spe-
cial plastic pipe adapter (supplied with ejector) by screwing adapt-
er into 1-1/4” tapped hole in ejector body (see Figure 7A).
Step 6. Thread a 1” plastic pipe adapter into the 1” tapped hole in ejector
body (see Figure 7A).
Step 7. Install sufficient plastic pipe in well casing to place ejector at the
proper depth. (Your well driller should supply this information.)
IMPORTANT: as a guide, the ejector should be set at least 10 to
20 feet below the lowest water level with pump running, if possi-
ble, but always at least five feet from the bottom of the well.
Step 8. Tighten all hose clamps securely on plastic pipe. Use two clamps
per joint to prevent air leaks into suction pipe. Clamp screws
should be on opposite sides of the pipe. Fill pipes with water to
make sure that foot valve and connections do not leak.
Step 9. Install sanitary well seal on top of well casing; use steel nipple
through well seal as shown in Figure 7A.
IMPORTANT: align locating lugs on adapter flange and pump
base so that pump discharge will be aligned with piping.
Step 10. Install 1” nipple in one side of adapter flange. Slide threadless
coupling down over drive pipe from well. Thread adapter flange
onto suction pipe from well and align nipple and drive pipe.
Step 11. Slide threadless coupling up and secure nipple to drive pipe.
Step 12. Remove paper backing from adhesive gasket. Apply gasket to
adapter flange, making sure that holes line up.
Step 13. Align locating lugs on pump base with locating lugs on adapter
flange; attach pump to flange with cap screws provided.
Step 14. See “Discharge Pipe Sizes” for information regarding correct dis-
charge pipe size.
Figure 7
Pump
Pump
Gasket
Gasket
Adapter Flange
Adapter Flange
Threadless
Coupling
Sanitary
Well Seal
Steel Pipe Nipple
Coupling
1" Plastic Drive Pipe
1" Plastic Pipe Adapter
Ejector Assembly
Foot Valve & Strainer
1-1/4" Plastic Suction Pipe
Special 1-1/4" Plastic Pipe
Adapter. (Supplied with Ejector)
Sanitary
Well Seal
1" Drive Pipe
Ejector Assembly
Foot Valve & Strainer
1-1/4" Suction Pipe
Threadless Coupling
A-OFFSET INSTALLATION
PLASTIC PIPE SHOWN
B-OVER THE WELL INSTALLATION
STEEL PIPE SHOWN
474 0194
Pump Pump
Gasket
Gasket
Adapter Flange
Adapter Flange
Threadless
Coupling
Sanitary
Well Seal
Steel Pipe Nipple
Coupling
1" Plastic Drive Pipe
1" Plastic Pipe Adapter
Ejector Assembly
Foot Valve & Strainer
1-1/4" Plastic Suction Pipe
Special 1-1/4" Plastic Pipe
Adapter. (Supplied with Ejector)
Sanitary
Well Seal
1" Drive Pipe
Ejector Assembly
Foot Valve & Strainer
1-1/4" Suction Pipe
Threadless Coupling
A-OFFSET INSTALLATION
PLASTIC PIPE SHOWN
B-OVER THE WELL INSTALLATION
STEEL PIPE SHOWN
474 0194

SINGLE PIPE EJECTOR INSTALLATION
Single pipe installations require (see Figure 8):
a. Galvanized steel pipe
b. Leather packer-type ejector with built-in foot valve
c. Turned couplings (supplied with packer-type ejector)
d. Well casing adapter.
Step 1. Connect ejector to first length of pipe. Use pipe joint compound
sparingly on male threads.
Step 2. Lower pipe into casing. Use special turned couplings (included
with 2” single pipe ejector package) to increase water flow. Use
pipe joint compound sparingly on male couplings threads.
NOTE: Fill pipe with water as each length is added to be sure foot valve
and connections do not leak.
Step 3. Add lengths of pipe until the ejector reaches the proper depth.
(Your well driller should supply this information.)
IMPORTANT: as a guide, the ejector should be set at least 10 to 20 feet
below the lowest water level with pump running, if possible, but always at
least 5 feet above the bottom of the well (see Figure 8).
Step 4. To properly seat the cup seals, after the ejector is correctly posi-
tioned move the assembly up and down slightly. Water pressure in
the casing will then soak the cup seals (see Figure 8). They should
seal within 2-3 hours after installation.
Step 5. With ejector set, install well casing adapter. Remove pipe holder.
Align locating lugs and tighten adapter to form seal with well
casing.
DISCHARGE PIPE SIZES
Step 1. If increasing discharge pipe size, install reducer in pump discharge
port. Do not increase pipe size by stages.
Step 2. When the pump is set away from the points of water use, the dis-
charge pipe size should be increased to reduce pressure losses
caused by friction.
 •Upto100ftrun:Samesizeaspumpdischargeport.
 •100ft.to300ftrun:Increaseonepipesize.
 •300ft.to600ftrun:Increasetwopipesizes.
Figure 8
Well Casing
serves as
Drive Pipe
Suction
Pipe
Venturi
Nozzle
Ejector
JET NO. J32P- 24
Casing Adapter
(Use gasket
between adapter
and pump flange)
Cup
Leathers
Pump
mounted
on Casing
Adapter
5 Feet
or more
10 to 20 Feet
Water level
with pump
running
2357b 0697
Installation 6

Installation 7
PRESSURE TANK INSTALLATION – DEEP WELL
The Pressure Tank provides a reservoir of water under pressure and main-
tains cushion of air pressure to prevent pipe hammering and possible
damage to plumbing components. When water is drawn off through house
fixtures, the pressure in the tank is lowered and the pressure switch starts
the pump.
STANDARD TANK CONNECTION
When a standard tank is used, an air volume control (AVC) adds air to the
tank when it is needed. See Figure 10 for typical standard tank installation.
To connect AVC to pump, thread a 1/4” compression fitting into tapped
hole on the front of the pump. Cut tubing to length to reach AVC; assemble
to fitting on pump and to AVC on tank. See installation instructions provid-
ed with tank and AVC for details.
PRECHARGED TANK CONNECTION
When a precharged tank is used, no AVC is necessary. See Figure 10 for
typical precharged tank installation. A precharged tank contains a factory
provided air charge.
IMPORTANT: your pump pressure switch is set for a 30-50 PSI range and
requires a tank pre-charge of 28 PSI for proper operation (see Figure 11). See
tank owner’s air charge. An annual check on tank charge is recommended.
Figure 9: Pump With Standard Tank
Air Volume
Control
(AVC)
Standard Tank
AVC
Port
2355b 0697
1" Discharge
Relief Valve
Pressure
Regulator
Well Seal
AVC Tubing
Figure 10: Pump With Pre-charged
Tank
20 100
80
60
40
Relief Valve
Pressure
Regulator
1" Discharge
Pre-Charged
Pressure Tank
2358b 0697
Figure 11: Checking Tank Pre-charge
1054 0697
10
20
30
Check Pressure With
Tire Gauge

Electrical 8
Hazardous voltage. Can shock, burn, or kill. Connect ground
wire before connecting power supply wires. Use the wire size (including
the ground wire) specified in the wiring chart. If possible, connect the
pump to a separate branch circuit with no other appliances on it.
Explosion hazard. Do not ground to a gas supply line.
WIRING CONNECTIONS
Fire hazard. Incorrect voltage can cause a fire or seriously
damage the motor and voids the warranty. The supply voltage must be with-
in ±10% of the motor nameplate voltage.
NOTICE: Dual-voltage motors are factory wired for 230 volts. If necessary,
reconnect the motor for 115 volts, as shown. Do not alter the wiring in sin-
gle voltage motors.
Install, ground, wire, and maintain your pump in compliance with the
National Electrical Code (NEC) or the Canadian Electrical Code (CEC), as
applicable, and with all local codes and ordinances that apply. Consult
your local building inspector for code information.
Disconnect power before working on pump, motor, pressure switch, or wiring.
Figure 12: Motor wiring connections through Pressure Switch. Match motor voltage to line voltage
Your Motor Terminal Board (under the motor end cover)
and Pressure Switch look like one of those shown below.
Convert to 115 Volts as shown. Do not change motor
wiring if line voltage is 230 Volts or if you have a single
voltage motor. Connect power supply as shown for your
type of switch and your supply voltage.
Clamp the power cable to prevent strain
on the terminal screws.
Connect the green (or bare copper) ground wire
to the green ground screw.
Motor wires connect here.
Clamp the power cable to prevent strain
on the terminal screws.
Connect the green (or bare copper) ground wire
to the green ground screw.
Motor wires connect here.
3187 0398
Power supply wires connect here.
230 Volt: Connect 2 hot wires (black and red)
here and cap the white (neutral) wire. It does
not matter which wire goes to which screw.
115 Volt: Connect one hot wire (black or red)
to one of these screws (it doesn't matter
which one). Connect the white (neutral) wire
to the other screw. Cap any remaining
black or red wires.
Power supply wires connect here.
230 Volt: Connect 2 hot wires (black and red)
here and cap the white (neutral) wire. It does
not matter which wire goes to which screw.
115 Volt: Connect one hot wire (black or red)
to one of these screws (it doesn't matter
which one). Connect the white (neutral) wire
to the other screw. Cap any remaining
black or red wires.

Electrical 9
WIRING CHART – Recommended Wire and Fuse Sizes
BRANCH DISTANCE IN FEET FROM MOTOR TO METER
MAX. FUSE* 0 51 101 201
MOTOR VOLTS LOAD RATING TO TO TO TO
HP
AMPS AMPS 50 100 200 300
1 115 19.2 25 10 10 8 6
1 230 9.6 15 14 14 14 12
1-1/2 230 12.0 15 14 14 14 12
2 230 11.5 15 14 14 14 12
(*)Time delay fuse or circuit breakers are recommended in any motor circuit.
Connection Procedure:
Step 1. Connect the ground wire first as shown in Figure 12. The ground
wire must be a solid copper wire at least as large as the power sup-
ply wires.
Step 2. There must be a solid metal connection between the pressure
switch and the motor for motor grounding protection. If the pres-
sure switch is not connected to the motor, connect the green
ground screw in the switch to the green ground screw under the
motor end cover with a solid copper wire at least as large as the
power supply wires.
Step 3. Connect the ground wire to a grounded lead in a service panel,
to a metal underground water pipe, to a metal well casing at least
ten feet (3M) long, or to a ground electrode provided by the power
company or the hydro authority.
Step 4. Connect the power supply wires to the pressure switch as shown in
Figure 12.

Operation 10
PRIMING THE PUMP
NEVER run pump dry. Running pump without water may cause
pump to overheat, damaging seal and possibly causing burns to per-
sons handling pump. Fill pump with water before starting.
NEVER run pump against closed discharge, to do so can boil
water inside pump, causing hazardous pressure in unit and possibly scald-
ing persons handling pump.
NOTE: Open water system faucets before priming pump for the first time.
Step 1. Remove pressure gauge.
a. Close pressure regulator (turn clockwise - see Figure 13).
b. Fill pump and suction pipe with water (Figure 13).
c. Replace pressure gauge, using PTFE pipe thread sealant tape on
thread; tighten gauge.
IMPORTANT: If a priming tee and plug have been provided for a long hor-
izontal run, be sure to fill suction pipe through this tee and replace plug.
(Don’t forget to PTFE pipe thread sealant tape the plug.)
Step 2. Start Pump:
Pressure should build rapidly to 50 pounds per square inch or more
as ejector and pump prime.
IF NO PRESSURE OR NO WATER, REPEAT Step No. 1 (above) two or three
times to remove entrapped air from the suction pipes.
Step 3. If, after priming pump several times, no water is pumped, check the
following:
a. Suction pipe in the water and has no leaks.
NOTE: Air can leak in even where water won’t leak out. Make
sure all joints are tight.
b. Pressure regulator, check valve, or foot valve installed and oper-
ating correctly.
c. Pump trying to lift water more than 25 feet (shallow well) or
more than rated lift for deep well ejector used (including com-
pensation for horizontal offset).
d. Be sure pump is not airlocked. In offset installations, pump suc-
tion port should be highest point in suction pipe; there should
be no sags in suction pipe (run it straight and at a slight angle
upward from well head to pump).
NOTE: For deep well installation, go to Step 4 (Page 11). Shallow well
installations go to Step 6 (Page 11).
20 100
80
60
40
2361a 0697
Figure 13A: Close Regulator
2360a 0697
Figure 13B: Fill Pump with Water
20 100
80
60
40
1030a 0697
1060a 0697
ON
Figure 13D: Adjust Regulator
Figure 13C: Start Pump

Operation 11
Step 4. Once unit has primed and pressure stabilized, slowly open (turn
counterclockwise - Figure 14A) regulator valve until pressure fal-
ters (pressure gauge needle flutters; pump may become noisy - see
Figure 14B). At this point, close (turn clockwise) regulator valve
slightly until pressure stabilizes. This setting provides maximum
flow (Figure 14C).
Step 5. Pump may draw well down far enough at this point to lose its
prime. If so, close regulator valve until pressure is stable throughout
pumping cycle. Close faucets and allow pump to pressurize tank
and shut off.
Step 6. Check system by alternately opening and closing faucets in the sys-
tem. With faucets open , pressure will drop until pump starts; with
faucets closed, pressure will build up until pump shuts off.
Step 7. There are conditions of deep well operation when the regulator
valve may be completely open without any faltering of pressure. In
this case, operate pump with regulator valve open.
HOW TO HANDLE A GASEOUS WELL
In some areas well water contains gases which must be allowed to escape
before the water is used. To deliver gas-free water suspend a pipe, closed
at the bottom and open at the top, so that it surrounds the suction pipe
inlet. (See Figure 15). Since the gases rise in the well casing, the water
sucked down through the pipe and into the pump suction is free of gas.
This type of well must be vented to the outside of any enclosure.
AIR CONTROL IN FLOWING WELLS
Flowing wells or wells with little or no drawdown, could create a special
problem in air control in the operation of your standard tank system.
In such cases, a pre-charged tank (which needs no air control) is
recommended.
Figure 14A: Open Regulator Valve
20 100
80
60
40
2871 0697
Figure 14B: Watch for Pressure Gauge
to Flutter
20 100
80
60
40
2872 0697
Figure 14C: Close Regulator Valve
until Pressure Stabilizes
20 100
80
60
40
2873 0697
Figure 15: Gas/Air Control in Well
Pipe strap or
wire to hold
pipe sleeve
Pipe
sleeve
Pipe
cap
Tail
pipe
Foot
valve
Ejector
2876 0697
Gases
rise to
surface

Maintenance 12
PUMP DISASSEMBLY/ASSEMBLY
Step 1. Turn off power at disconnect switch. Disconnect power lines from
pressure switch.
Step 2. Remove the two cap screws holding the pump to the flange adapt-
er. Don’t disturb the piping in the well.
Step 3. Remove the adapter flange gasket and scrape the surfaces clean.
Step 4. Unscrew and remove the straight barbed fitting at the pressure
switch.
Step 5. Draw a line down the side of the pump with a marker to help
alignment during reassembly. Mark the pump from the motor to
the base volute (see Figure 16).
Step 6. Turn the pump upside down on the bench and block it. Remove
the four cap screws from the base. With a mallet, tap upward on
the base to loosen it. Lift the base off of the intermediate volute
(see Figure 17).
Step 7. To reduce the chance of dropping the pump onto your foot, lay it
down on the bench; block it so it won’t roll.
Step 8. Hold the motor shaft with pliers or vice grips through the opening
in the pump adapter. Unscrew the impeller nut off the end of the
shaft (see Figure 18).
Step 9. The impellers are keyed to the shaft and do not unscrew. Insert
two screw drivers on opposite sides under the exposed impeller
and pry the impeller off (Figure 19) to remove it.
Step 10. Carefully tap a small screwdriver or thin bladed chisel in between
the intermediate volute and the pump adapter in two or three
places around the pump to separate the castings (Figure 20). Do
not mar the sealing surfaces; do not break pieces out of the adapt-
er or volute – the castings are easily damaged.
Step 11. Remove the intermediate volute and slide the impeller spacer off
of the shaft.
Step 12. Remove the impeller. Don’t disturb the shaft keys if you are only
replacing the seal.
Step 13. Rotate the seal spring retainer cup so that the slot lines up with
the shaft keys; remove the cup and spring.
Step 14. Remove the two cap screws holding the adapter bracket to the
motor.
Step 15. With two screwdrivers on opposite sides of the pump, carefully pry
the pump adapter away from the motor. This will pull the seal off
of the motor shaft. Use caution to make sure that the ceramic seal
does not dig into the shaft and scratch the shaft’s sealing surface.
INSTALLATION OF NEW SEAL
Step 1. Clean all gasket surfaces thoroughly before reassembly. Clean the
seal bore cavity in the pump adapter.
Step 2. Wet the rubber seat ring with soapy water and push the stationary
part of the seal into the seal bore cavity. Use a piece of 1” pipe
pressing on a cardboard washer (to prevent damaging seal surface)
as a press. Make sure that the seal half is fully seated in the seal
bore cavity. Remove the cardboard once the seal is in place.
1801 0595
Figure 16
1802 0595
Figure 17
Figure 19
Figure 18
Figure 20

Maintenance 13
Step 3. Make sure that the shaft keys are in place on the shaft. If they are
not, squeeze them in place now with slip joint pliers. Do not tap
them or hit them with a hammer; you could bend the shaft (see
Figure 21). When the keys are correctly installed, the adapter will
pass over the keys without interference.
Step 4. Carefully slide the adapter over the shaft (see Figure 22). Do not
damage the shaft sealing surface; it is highly polished and any
slight scratches or nicks will ruin it.
Step 5. Using the alignment marks made before disassembly, line up the
adapter with the motor and bolt the adapter in place. Tighten the
cap screws evenly.
Step 6. Push the shaft seal and seal spring onto the shaft, after making
sure that the seal faces and shaft are clean. Take care that the
shaft shoulder does not damage the carbon seal face. Follow the
seal spring with the spring holder; compress the spring and give
the spring holder a quarter turn to lock it under the first shaft key
(see Figure 23).
Step 7. Slide the first impeller onto the shaft; follow it with the impeller
spacer. Twist the impeller on the shaft to make sure that the shaft
key is still in place and the impeller is locked to the shaft (the
shaft should turn with the impeller).
Step 8. Install a new volute gasket, lining up the bolt holes with the bolt
holes in the adapter. Make sure the gasket is right side up so that
the water passage holes line up with the water passages in the
volutes.
Step 9. Install the intermediate volute, aligning it with the mark made
before disassembly. Use the long cap screws to check this align-
ment. It cannot be stressed too strongly that all bolt holes and
water passages of all gaskets and volutes MUST line up with each
other, or the pump will not be assembled correctly.
Step 10. Make sure the second shaft key is in place and install the second
impeller. Twist the impeller to make sure that the shaft key is still
in place. Hold the motor shaft with slip-joint pliers or vice-grips
and install and tighten the impeller locknut. Tightening the lock nut
automatically spaces the impeller correctly. Do not overtighten.
Step 11. Install the base volute gasket. Make sure the gasket is right side up
so that the water passage holes line up with the water passages
in the volutes. Install the base volute, using the alignment marks
made before disassembly. Make sure that the pump discharge will
correctly meet the the piping when the pump is reinstalled.
Step 12. Insert the four base capscrews and tighten evenly (see Figure 24).
These should be easy to install if everything is correctly aligned. If
not, don’t force them; go back over your work and find and cor-
rect the misalignment.
Step 13. Reinstall the pressure switch barbed fitting and pressure tube.
Step 14. Reinstall the pump on the adapter flange (use a new gasket) and
reconnect the wiring and grounding. Pump is now ready for
operation.
Use pliers –
with care –
no hammers.
Figure 21
Figure 23
Align
Marks
Figure 22
Make sure
all marks
line up.
Bolts should
be easy to
insert.
1809 0595
Figure 24

Troubleshooting 14
* (Note: Stop pump;
then check prime
before looking
for other causes.
Unscrew priming
plug and see if water
is in priming hole).
SYMPTOM POSSIBLE CAUSE(S) CORRECTIVE ACTION
Motor will not run Disconnect switch is off Be sure switch is on.
Fuse is blown or circuit breaker tripped Replace fuse or reset circuit breaker.
Starting switch is defective DISCONNECT POWER; Replace starting switch.
Wires at motor are loose, Refer to instructions on wiring (Page 8). DISCONNECT POWER; check and
disconnected, or wired incorrectly tighten all wiring.
Capacitor voltage may be hazardous. To discharge
capacitor, hold insulated handle screwdriver BY THE HANDLE and
short capacitor terminals together. Do not touch metal screwdriver
blade or capacitor terminals. If in doubt, consult a qualified electrician.
Pressure switch contacts are dirty DISCONNECT POWER and file contacts with emery board or nail file.
Motor runs hot and Motor is wired incorrectly Refer to instructions on wiring.
overload kicks off Voltage is too low Check with power company. Install heavier wiring if wire size is too small
(See Electrical / Wiring Chart).
Pump cycles too frequently See section below on too frequent cycling.
Motor runs but no Pump in new installation did In new installation:
water is delivered* not pick up prime through:
1. Improper priming 1. Re-prime according to instructions.
2. Air leaks 2. Check all connections on suction line, AVC, and ejector with
soapy water or shaving cream.
3. Leaking foot valve or check valve 3. Replace foot valve or check valve.
Pump has lost prime through: In installation already in use:
1. Air leaks 1. Check all connections on suction line and shaft seal.
2. Water level below suction pipe inlet 2. Lower suction line into water and re-prime. If receding water level
in well exceeds 25’ (7.6M), a deep well pump is needed.
Foot valve or strainer is plugged Clean foot valve or strainer.
Ejector or impeller is plugged Clean ejector or impeller.
Check valve or foot valve is stuck shut Replace check valve or foot valve.
Pipes are frozen Thaw pipes. Bury pipes below frost line. Heat pit or pump house.
Foot valve and/or strainer are Raise foot valve and/or strainer above bottom of water source.
buried in sand or mud Clean foot valve and strainer.
Water level is too low for shallow A deep well jet will be needed if your well is more than 25’ (7.6M)
well setup to deliver water depth to water.
Pump does not Water level in well is lower than A new nozzle and venturi combination may be needed.
deliver water to full estimated
capacity Steel piping (if used) is corroded or Replace with plastic pipe where possible, otherwise with new steel pipe.
(Also check point limed, causing excess friction
3 immediately above) Piping is too small in size Use larger piping.
Pump delivers water but Pressure switch is out of adjustment or DISCONNECT POWER; adjust or replace pressure switch.
does not shut off or contacts are welded together
pump cycles too Faucets have been left open Close faucets.
frequently Venturi, nozzle or impeller is clogged Clean venturi, nozzle or impeller.
Standard pressure tank is waterlogged Drain tank to air volume control port. Check AVC for defects. Check
and has no air cushion all connections for air leaks.
Pipes leak Check connections.
Foot valves leak Replace foot valve.
Pressure switch is out of adjustment Adjust or replace pressure switch.
Air charge too low in pre-charged tank DISCONNECT POWER and open faucets until all pressure is relieved.
Using tire pressure gauge, check air pressure in tank at valve stem
located on the tank. If less than pressure switch cut-in setting (30-50
PSI), pump air into tank from outside source until air pressure is 2 PSI
less than cut-in setting of switch. Check air valve for leaks (use soapy
solution) and replace core if necessary.
Air spurts from faucets Pump is picking up prime When pump has picked up prime, it should pump solid water with no air.
Leak in suction side of pump Suction pipe is sucking air. Check joints for leaks with soapy water.
Well is gaseous Consult factory about installing a sleeve in the well.
Intermittent over-pumping of well. Lower foot valve if possible, otherwise restrict pump discharge.
(Water drawn down below foot valve.)

Repair Parts 15
20 100
80
60
40
Repair Parts – Multi-Stage Jet
Key Part With No. VNA2-100 VNA2-150 VNA2-200
No. Description Kit Used 1 HP 1-1/2 HP 2 HP
1 Motor-115/230V Single Phase 1 A300EH – –
1 Motor-230V Single Phase 1 – A300FH AE300GH
1A Motor Canopy 1 U18-1300 U18-1355 U18-1355
2 Connector 1 J43-13C J43-13C J43-13C
3 Locknut - 1/2” 1 U36-112ZP U36-112ZP U36-112ZP
4 Pressure Switch 1 U217-1216 U217-204E U217-204E
5 Barbed Fitting - Straight 1 U111-211T U111-211T U111-211T
6 Switch Tube - 14-1/2” 1 U37-672P U37-672P U37-672P
7 Pressure Regulator Assembly 1 J212-24 J212-24A J212-24A
7A Pressure Gauge 1 U239-3 U239-8 U239-8
8 Barbed Fitting - Elbow 1 U111-212T U111-212T U111-212T
9 Adapter 1 L2-16A L2-16A L2-16A
10 Capscrew - 3/8”-16x1-1/4” Lg. 2 U30-75ZP U30-75ZP U30-75ZP
11 Shaft Key OH/SG 2 U65-15SS U65-15SS(3) U65-15SS(3)
12 Shaft Seal OH/SG 1 17351-0101A 17351-0101A 17351-0101A
13 Spring Holder OH/SG 1 J24-11 J24-11 J24-11
14 Impeller OH 2 J105-76P J105-74PA(3) J105-74P(3)
15 Spacer - Impeller (1 or 2 required) – J43-23 J43-23 J43-23
16 Intermediate Volute w/Wear Rings & Gasket (1) J101-26 J101-26(2) J101-26(2)
16A Gasket OH/SG (1) J20-11 J20-11 J20-11
16B Wear Ring OH (1) J23-10 J23-10 J23-10
16C Wear Ring OH (1) J23-11 J23-11 J23-11
17 Impeller Stop Nut 1 U36-175SSW U36-175SSW U36-175SSW
18 Base Volute Complete 1 J101-33 J101-33A J101-33A
18A Gasket OH/SG (1) J20-11 J20-11 J20-11
18B Wear Ring OH (1) J23-10 J23-10 J23-10
19 Pipe Plug - 1/4” NPT (1) U78-941ZPV U78-941ZPV U78-941ZPV
20 Capscrew - 3/8”-16x4-1/4” Lg. (4) U30-82ZP – –
20 Capscrew - 3/8”-16x6” Lg. (4) – U30-81ZP U30-81ZP
SERVICE KITS
Seal and Gasket Kit (SG) 1 PP1650 PP1650 PP1650
Overhaul Kit (OH) 1 PP1657 PP1658 PP1659

Repair Parts 16
Casing Adapters – (Not included with pump)
Adapter Flange – (Not included with pump)
1
2
3
489 0194
1
2
4
3
5
6
377 1293
Item 1-Remove paper
backing form gasket before
applying.
Item 2-Align locating lug on
flange with locating lug on
base volute.
Item 1-Remove paper
backing form gasket before
applying.
Item 2-Align locating lug on
flange with locating lug on
base volute.
Pressure Regulator
Key Part
No. Description J212-24 J212-24A
1 Pressure Regulator w/Seat J112-14 J112-14
1A Valve Seat J66-16 J66-16
2 Diaphragm Assembly J220-16B J220-16B
2A Regulator Guide J42-5 J42-5
2B Stem J62-9 J62-9
2C Diaphragm J20-16 J20-16
2D Spring Follower J43-31 J43-31
2E Lock Washer U43-23ZP U43-23ZP
2F Nut 1/4-20 U36-36ZP U36-36ZP
3 Reducer Bushing 1/2x1/8 NPT U78-107DT U78-107DT
4 Pressure Gauge 0-100# U239-3 –
4 Pressure Gauge 0-200# – U239-8
5 Spring J24-13 J24-13
6 Spring Guide J61-5 J61-5
7 Bonnet J52-9 J52-9
8 Capscrew 5/16-18x3/4” Lg. (4) U30-60ZP U30-60ZP
9 Adjusting Screw 5/16-18 U30-69FTZP U30-69FTZP
10 Locknut 5/16-18 U36-205ZP U36-205ZP
Key Part J216-21 J216-22 J216-23
No. Description Qty. 2” 2-1/2” 3”
1 Gasket 1 J20-12 J20-12 J20-12
2 Adapter Body 1 J51-10 J51-9 J51-9
3 Seal Ring 1 J21-17 J21-24 J21-21
4 Lower Flange 1 J16-20ZZP J16-30ZZP J16-24ZZP
5 Capscrew,
3/8-16x1-1/2 Lg. 3 U30-76ZP U30-76ZP U30-76ZP
6 Capscrew,
1/2-13x1-1/4” 2 U30-86PS U30-86PS U30-86PS
Key Part J216-26 J216-27
No. Description Qty. 1-1/4x1 1-1/4x1-1/4
1 Gasket 1 J20-12 J20-12
2 Adapter Flange 1 J2-15 –
2 Adapter Flange 1 – J2-17B
3 Capscrew 2 U30-86ZP U30-86ZP
376 1293
1
1A
2A
2B
2C
2D
4
5
2E 2F
2
3
6
7
8
9
10
20 100
80
60
40

NOTICE D’UTILISATION
Pompes verticales à éjecteur
NOTICE D’INSTALLATION
ET DE FONCTIONNEMENT
Modèles VNA2 - Série multicellulaire
Puissance : De 1 à 2 chevaux
60 cycles
Installation des pompes à moteur monophasé
Dossier du propriétaire
Modèle de la pompe:
N° de série de la pompe:
Code de date de la pompe:
Puissance du moteur (en ch) Tension en volts Phase(s)
Date de l’installation:
Propriétaire:
Installateur:
Numéro de téléphone de l’installateur:
© 2013 Pentair Ltd. All Rights Reserved. AE757-1 (REV 01/16/13)
293 WRIGHT STREET, DELAVAN, WI 53115 WWW.AERMOTOR.COM
PH: 8002301816

Sécurité 18
LIRE TOUTES CES INSTRUCTIONS
ET LES SUIVRE!
Ce symbole indique qu’il faut être prudent. Lorsque ce
symbole apparaît sur la pompe ou dans cette Notice,
rechercher une des mises en garde qui suivent, car elles
indiquent un potentiel possible de blessures corporelles :
avertit d’un danger qui causera des blessures
corporelles, la mort ou des dommages matériels importants si
on l’ignore.
avertit d’un danger qui risque de causer des
blessures corporelles, la mort ou des dommages matériels
importants si on l’ignore.
avertit d’un danger qui causera ou qui
risquera de causer des blessures corporelles, la mort ou des
dommages matériels importants si on l’ignore.
Le mot REMARQUE indique des instructions spéciales et
importantes n’ayant aucun rapport avec les dangers.
Lire attentivement toutes les consignes de sécurité contenues
dans cette Notice et collées sur la pompe.
Garder les étiquettes relatives à la sécurité en bon état.
Remplacer les étiquettes relatives à la sécurité si elles
manquent ou si elles ont été endommagées.
Rendre les ateliers à l’épreuve des enfants en posant des
cadenas et des interrupteurs principaux. Enlever les clés des
démarreurs.
Avertissement lié à la Proposition 65 de la Californie
Ce produit et les accessoires connexes
contiennent des produits chimiques reconnus dans l’État
de la Californie comme pouvant provoquer des cancers,
des anomalies congénitales ou d’autres dangers relatifs à la
reproduction.
CONSIGNES DE SÉCURITÉ
CONCERNANT L’ÉLECTRICITÉ
La tension du condensateur peut être
dangereuse. Pour décharger le condensateur du moteur, tenir
un tournevis à manche isolé PAR LE MANCHE et mettre en
court-circuit les bornes du condensateur. Ne pas toucher la
lame métallique du tournevis ni les bornes du condensateur. En
cas de doute, consulter un électricien qualifié.
CONSIGNES DE SÉCURITÉ GÉNÉRALES
Ne pas toucher un moteur qui fonctionne.
Les moteurs modernes sont conçus pour fonctionner par des
températures élevées. Pour ne pas se brûler si on doit intervenir
sur la pompe, la laisser refroidir, avant de la toucher, pendant
20 minutes après l’avoir arrêtée.
Ne pas laisser geler la pompe ni aucun composant du système.
Le gel risque de causer des dommages au système, des
blessures ou une inondation. Laisser geler la pompe ou les
composants du système annulera la garantie.
La soupape de sécurité doit pouvoir laisser passer le débit
maximum de la pompe à une pression de 517,1 kPa (75 lb/
po2).
Ne pomper que de l’eau avec cette pompe.
Périodiquement, inspecter la pompe et tous les composants du
système.
Toujours porter des lunettes de sécurité lorsqu’on intervient sur
une pompe.
Garder la zone de travail propre, non encombrée et bien
éclairée. Tous les outils et tout l’équipement non utilisés
doivent être rangés correctement.
Ne laisser personne s’approcher de la zone de travail.
Pression dangereuse!
Poser une soupape de sûreté
sur le tuyau de refoulement.
Dissiper toute la pression du
système avant d’intervenir sur
un composant.
Tension dangereuse.
Risque de secousses
électriques, de brûlures,
voire de mort.
Mettre à la terre la pompe
avant de la brancher sur le
courant électrique. Couper
l’arrivée de courant avant
d’intervenir sur la pompe,
sur le moteur ou sur le
réservoir.
Câbler le moteur en
fonction de la bonne
tension. Se reporter à la
rubrique «Électricité» de cette
Notice et à la plaque
signalétique du moteur.
Mettre à la terre le
moteur avant de le
brancher sur le courant
électrique.
Conforme au National
Electrical Code, au Code
canadien de l’électricité et aux
codes municipaux pour tous les
câblages.
Respecter les instructions
de câblage figurant dans
cette Notice lorsqu’on branche
le moteur sur le courant
électrique.

Table des matières 19
Page
Consignes de sécurité générale..........................................................................18
Garantie.............................................................................................................19
Installation....................................................................................................20-23
Électricité......................................................................................................24-25
Fonctionnement............................................................................................26-27
Entretien .......................................................................................................28-29
Recherche des pannes .......................................................................................30
Pièces de rechange ......................................................................................31-32
Garantie limitée
AERMOTOR garantit à l’acheteur initial (ci-après appelé l’« Acheteur ») que les produits énumérés dans les présentes sont exempts de
défaut de matériau et de fabrication pendant la durée de la garantie à compter de la durée des garanties indiquées ci-dessous.
Produits Durée des garanties
Pompes à éjecteur, petites pompes centrifuges, pompes submersibles et
tous les accessoires connexes
Selon le premier terme atteint :
12 mois à compter de la date de la première installation ou
18 mois à compter de la date de fabrication
Réservoirs composites Pro-Source™ 5 ans à compter de la date de la première installation
Réservoirs sous pression en acier Pro-Source™ 5 ans à compter de la date de la première installation
Réservoirs revêtus d’époxyde Pro-Source™ 3 ans à compter de la date de la première installation
Produits de puisard/d’égout/d’effluents 12 mois à compter de la date de la première installation ou
18 mois à compter de la date de fabrication
Nos garanties ne s’appliquent pas aux produits ayant fait l’objet de négligence, d’une mauvaise utilisation, d’une mauvaise installation
ou d’un manque d’entretien adéquat. Sans aucune limitation des présentes, la garantie des moteurs triphasés submersibles sera nulle
et non avenue si ces moteurs sont branchés et fonctionnent sur le courant monophasé par l’intermédiaire d’un déphaseur. Il faut
également noter que les moteurs triphasés doivent être protégés par un relais de surcharge tripolaire thermocompensé à déclenchement
extrêmement rapide du calibre recommandé, sinon la garantie sera nulle et non avenue.
Le seul recours de l’Acheteur et la seule responsabilité de AERMOTOR consistent à réparer ou à remplacer (au choix de AERMOTOR)
les produits qui se révéleraient défectueux. L’Acheteur s’engage à payer tous les frais de main d’œuvre et d’expédition du produit
couvert par sa garantie et de s’adresser au concessionnaire-installateur ayant procédé à l’installation dès qu’un problème est découvert
pour obtenir un service sous garantie. Aucune demande de service en vertu de sa garantie ne sera acceptée après expiration de la durée
de sa garantie. Ces garanties ne sont pas transférables.
AERMOTOR DÉCLINE TOUTE RESPONSABILITÉ POUR TOUT DOMMAGE INDIRECT OU FORTUIT QUEL QU’IL SOIT.
LA GARANTIE LIMITÉE SUSMENTIONNÉE EST EXCLUSIVE ET REMPLACE TOUTES LES AUTRES GARANTIES EXPRESSES ET TACITES, Y
COMPRIS, MAIS SANS S’Y LIMITER, LES GARANTIES DE QUALITÉ MARCHANDE ET D’ADAPTATION À UN USAGE PARTICULIER. LA
GARANTIE LIMITÉE SUSMENTIONNÉE NE DOIT PAS ÊTRE PROLONGÉE AU-DELÀ DE LA DURÉE PRÉVUE AUX PRÉSENTES.
Certains états, territoires et certaines provinces ne permettent pas l’exclusion ou la limitation des dommages indirects ou fortuits, ni les
limitations relatives à la durée des garanties tacites. Par conséquent, il se peut que les limitations ou les exclusions stipulées dans les
présentes ne s’appliquent pas dans ce cas. Ces garanties accordent des droits juridiques précis, bien que l’on puisse bénéficier d’autres
droits, selon la province, le territoire ou l’état dans lequel on réside.
La présente garantie limitée est entrée en vigueur le 1er juin 2011 et remplace toute garantie non datée ou antérieure à cette date.
AERMOTOR
293 Wright Street • Delavan, WI U.S.A. 53115
Téléphone : 1 800 230-1816 • Télécopieur : 1 800 426-9446 • Site Web : aermotor.com

1100 0697
Figure 1 – Pas de saleté ni de tartre
dans le tuyau d’aspiration
Figure 2 – Le clapet de pied doit
fonctionner librement
Figure 3 – Aucune poche d’air dans le
tuyau d’aspiration
Installation 20
Figure 4 – Le tuyau d’aspiration ne
doit pas aspirer d’air
AVANT D’INSTALLER LA POMPE
REMARQUE : Pour obtenir un bon rendement de la pompe, elle DOIT être appar-
eillée à l’éjecteur et à la profondeur du puits. Se reporter à la rubrique «Installation
sur un puits peu profond» dans le cas des puits dont la surface libre maximum
jusqu’à l’eau est de 7,60 mètres (25 pieds) et à «Éjecteur pour puits
profonds» si la surface libre maximum jusqu’à l’eau est de 40mètres (130 pieds).
1° De grandes longueurs de tuyaux et de nombreux raccords augmentent le
frottement et réduisent le débit. Positionner la pompe aussi près que possible
du puits. Utiliser le moins possible de coudes et de raccords.
2° S’assurer que le puits est débarrassé de sable. La garantie sera annulée si du
sable bouche la pompe.
3° Protéger la pompe et toutes les tuyauteries contre le gel. Le gel fera éclater les
tuyauteries, endommagera la pompe et la garantie sera annulée. Vérifier quelles
sont les conditions locales requises pour protéger l’ensemble de ce système
contre le gel (habituellement, les tuyaux doivent être enterrés à 30 cm
(12 pouces) plus profond que la profondeur de gélivation maximum et la
pompe doit être isolée).
4° S’assurer que toutes les tuyauteries et que le clapet de pied sont propres et en
bon état.
5° Il ne doit y avoir aucune poche d’air dans le tuyau d’aspiration.
6° Il ne doit y avoir aucune prise d’air dans le tuyau d’aspiration. Utiliser du ruban
d’étanchéité en PTFE pour filetage ou de la pâte en bâtonnet pour rendres
étanches les joins des tuyaux.
7° Appareiller la pompe au puits.
IMPORTANT: Le débit de l’eau alimentant le puits doit être au moins égal au
débit de la pompe!
8° Des raccords unions installés près de la pompe et du puits faciliteront l’entre-
tien de la pompe. Prévoir suffisamment d’espace pour pouvoir utiliser des clés à
tuyau.
9° Boucher l’orifice d’eau motrice de 1 po si cette pompe est installée sur un puits
peu profond.
INSTALLATION SUR UN PUITS PEU PROFOND OU
UTILISATION EN TANT QUE POMPE CENTRIFUGE
Dans ce cas, on n’utilise pas d’éjecteur. Boucher le plus petit des deux orifices
d’admission et utiliser l’orifice de plus grand diamètre pour le tuyau d’aspiration.
Se reporter à la Figure 6 pour des conseils relatifs à l’installation. Si cette pompe
est installée sur un puits peu profond ou si elle est utilisée en tant que pompe
centrifuge, la surface libre jusqu’à l’eau doit être de 7,60 mètres (25 pieds).
REMARQUE: Pour ne pas surcharger la pompe et empêcher une panne du moteur,
poser un robinet de limitation de débit sur le tuyau de refoulement de façon à
limiter le débit de la pompe à 75 litres par minute (20 gallons par minute).
Figure 5: Puits profond à tuyaux
jumelés
Figure 6: Puits peu profond tubé et
puits peu profond à pointe filtrante
1096 0697
Pump
Body
From
Well
Dirt and Scale Plug Pump and Pipes!
Use New Pipe for Best Results.
Clean Flow!
Les saletés et le sable boucheront
les orifices et les tuyaux!
Pour obtenir les meilleurs résultats,
n’utiliser que des tuyaux neufs.
Corps de
la pompe
Débit sans obstruction
En provenance
du puits
No Sags
Sags Allow Air Pockets
If Air Pockets Form, Water Won’t Flow.
Keep Pipe Straight and Angled up to Pump.
1101 0697
Pas d’affaissement
Les affaissements favoriseront la formation
de poches d’air et l’eau ne circulera pas.
Garder le tuyau droit et légèrement
incliné vers la pompe.
1102 0697
No Air Leaks
in Suction Pipe.
Pipe Joint
Compound Will
Damage Plastic.
If Air Flows
Water Won’t
Use PTFE Tape
Aucune prise d’air
dans le tuyau
d’aspiration.
En cas de prise
d’air, l’eau ne
circulera pas
De la pâte pour
raccords filetés
endommagera
le plastique.
Utiliser du ruban d’étanchéité en PTFE pour filetage.
Be sure
entire
well
point is
below
water.
Drive
Coupling
Drive
Point
Check
Valve
1" NPT
Plug
Well
Casing
1" NPT
Plug
Well
Casing
Foot
Valve &
Strainer
Foot
Valve &
Strainer
Shallow well is less
than 25' (7.6M)
to water with
pump running.
Deep well is more
than 25' (7.6M)
to water with
pump running.
822 0697
Dans un puits
profond, la surface
libre jusqu’à l’eau
pendant que la
pompe fonctionne
est supérieure à 7,60
mètres (25 pieds).
Tubage
du puits
Clapet
de
pied et
crépine
Be sure
entire
well
point is
below
water.
Drive
Coupling
Drive
Point
Check
Valve
1" NPT
Plug
Well
Casing
1" NPT
Plug
Well
Casing
Foot
Valve &
Strainer
Foot
Valve &
Strainer
Shallow well is less
than 25' (7.6M)
to water with
pump running.
Deep well is more
than 25' (7.6M)
to water with
pump running.
822 0697
Bouchon
de 1 po
NPT
Dans un puits peu
profond, la surface libre
jusqu’à l’eau pendant
que la pompe fonctionne
est inférieure à 7,60
mètres (25 pieds).
Clapet de
pied et
crépine
Tubage
du puits
Pointe
filtrante
Clapet
de non
retour
S’assurer
que toute
la pointe
filtrante
est
enfoncée
sous le
niveau
de l’eau.
Bouchon
de 1 po
NPT
Accouplement
entre pompe
et moteur
