OWNER'S MANUAL
SHALLOW WELL JET PUMPS
P15002 (11-01-2022)
©2022 Pentair. All Rights Reserved.
ENGLISH 1 - 24 FRENCH 25 - 48 SPANISH 49 - 72

P15002 (11-01-22)
TABLE OF CONTENTS
SAFETY INFORMATION ...................................................................................................3
INSTALLATION ..........................................................................................................4
DISCHARGE PIPE AND PRESSURE TANK CONNECTIONS .....................................................................6
ELECTRICAL ............................................................................................................7
START THE PUMP ........................................................................................................9
TROUBLESHOOTING ....................................................................................................10
PARTS INDEX ...........................................................................................................12
WARRANTIES...........................................................................................................22

3
P15002 (11-01-22)
SAFETY INFORMATION
 Wire motor for correct voltage. See
“Electrical” section of this manual and
motor nameplate.
 Ground motor before connecting to
power supply.
 Meet National Electrical Code,
Canadian Electrical Code, and local
codes for all wiring.
 Follow wiring instructions in this
manual when connecting motor to
power lines.
GENERAL SAFETY
DO NOT TOUCH AN OPERATING MOTOR. Modern
motors are designed to operate at high temperatures. To avoid
burns when servicing pump, allow it to cool for 20 minutes after
shut-down before handling.
 DO NOT allow pump or any system component to freeze. To
do so will void warranty.
 Pump water only with this pump.
 Periodically inspect pump and system components.
 Wear safety glasses at all times when working on pumps.
 Keep work area clean, uncluttered and properly lighted;
store properly all unused tools and equipment.
 Keep visitors at a safe distance from the work areas.
Pump body may explode if used as a booster pump
unless relief valve capable of passing full pump flow at 75 psi is
installed.
ELECTRICAL SAFETY
CAPACITOR VOLTAGE MAY BE HAZARDOUS. To
discharge motor capacitor, hold insulated handle screwdriver by
the handle and short capacitor terminals together. Do not touch
metal screwdriver blade or capacitor terminals. If in doubt,
consult a qualified electrician.
SAFETY SYMBOLS
This is the safety alert symbol. When you see this symbol on
your pump or in this manual, look for one of the following signal
words and be alert to the potential for personal injury:
warns about hazards that will cause serious
personal injury, death or major property damage if ignored.
warns about hazards that can cause serious
personal injury, death or major property damage if ignored.
warns about hazards that will or can cause minor
personal injury or property damage if ignored.
The word NOTICE indicates special instructions that are
important but not related to hazards.
CALIFORNIA PROPOSITION 65 WARNING
This product and related accessories contain
chemicals known to the State of California to cause cancer,
birth defects or other reproductive harm.
Hazardous pressure!
Install pressure relief valve in
discharge pipe.
Release all pressure on system
before working on any component.

4P15002 (11-01-22)
INSTALLATION
REPLACING AN OLD PUMP
HAZARDOUS VOLTAGE. Disconnect power to pump
before working on pump or motor.
1. Drain and remove the old pump. Check the old pipe for
scale, lime, rust, etc. Replace, if necessary.
2. Install the pump in the system. Make sure that all pipe
joints in the suction pipe are air-tight and water-tight. If the
suction pipe can suck air, the pump will not be able to pull
water from the well.
3. Adjust the pump mounting height so that the plumbing
connections do not put a strain on the pump body. Support
the pipe so that the pump body does not take the weight of
piping or fittings.
WELL POINT (DRIVEN POINT) INSTALLATION
1. Drive the well, using drive couplings and a drive cap. Drive
fittings are threaded all the way through and allow the pipe
ends to butt against each other so that the driving force of
the maul is carried by the pipe and not by the threads.
The ordinary fittings found in hardware stores are not
threaded all the way through the fitting and can collapse
under impact. Drive fittings are also smoother than
standard plumbing fittings, making ground penetration
easier.
2. Mount the pump as close to the well as possible.
3. Use the fewest possible fittings, especially elbows, when
connecting the pipe from the well point to the pump suction
port. The suction pipe should be at least as large as the
suction port on the pump. Include a check valve if your
pump is not equipped with one (Figure 1).
Support the pipe so that there are no dips or sags in the
pipe, so it doesn’t strain the pump body, and so that it
slopes slightly upward from the well to the pump (high spots
can cause air pockets which can air lock the pump).
Seal the suction pipe joints with PTFE pipe thread sealant
tape. Joints must be air-tight and water-tight. If the suction
pipe can suck air, the pump cannot pull water from the well.
If one well point does not supply enough water, consider
connecting two or three well points to one suction pipe.
4. Proceed to the Discharge Pipe and Tank Connections
section.
CASED WELL INSTALLATION, 2” OR LARGER CASING
1. Mount the pump as close to the well as possible.
2. Assemble the foot valve, strainer, and well pipe (Figure 2).
Make sure that the foot valve works freely.
3. Lower the pipe into the well until the strainer is 5 feet
above the bottom of the well. It should also be at least 10
feet below the well’s water level while the pump is running
in order to prevent the pump from sucking air. Install a
sanitary well seal.
Figure 1: Driven Point Installation Figure 2: Cased Well Installation

5
P15002 (11-01-22)
4. Install a priming tee, priming plug, and suction pipe to the
pump (Figure 2). Connect the pipe from the well to the pump
suction port, using the fewest possible fittings, especially
elbows, as fittings increase friction in the pipe. Include a
foot valve (Figure 2). The suction pipe should be at least
as large as the suction port on the pump. Use PTFE pipe
thread sealant tape on threaded
pipe joints.
Support the pipe so that there are no dips or sags in the
pipe, so it doesn’t strain the pump body, and so that it
slopes slightly upward from the well to the pump (high spots
can cause air pockets which can air lock the pump).
Seal the suction pipe joints with PTFE pipe thread sealant
tape. Joints must be air-tight and water-tight. If the suction
pipe can suck air, the pump cannot pull water from the well.
5. Proceed to the Discharge Pipe and Tank Connections
section.
INSTALLATION FOR SURFACE WATER
1. The pump should be installed as close to the water as
possible, with the fewest possible fittings (especially
elbows) in the suction pipe. The suction pipe should be at
least as large as the suction port on the pump.
2. Assemble a foot valve and suction pipe (Figure 3). Make
sure that the foot valve works freely. Use PTFE pipe thread
sealant tape on threaded pipe joints. Protect the foot valve
assembly from fish, trash, etc, by installing a screen around
it.
3. Lower the pipe into the water until the strainer is five feet
above the bottom. It should also be at least 10 feet below
the water level in order to prevent the pump from sucking
air.
4. Install a priming tee, priming plug, and suction pipe to the
pump (Figure 3). Support the pipe so that there are no dips
or sags in the pipe, so it doesn’t strain the pump body, and
so that it slopes slightly upward from the well to the pump
(high spots can cause air pockets which can air lock the
pump).
Seal the suction pipe joints with PTFE pipe thread sealant
tape. Joints must be air-tight and water-tight. If the suction
pipe can suck air, the pump cannot pull water from the well.
5. Proceed to the Discharge Pipe and Tank Connections
section.
Figure 3: Surface Water Installation
INSTALLATION

6P15002 (11-01-22)
DISCHARGE PIPE AND PRESSURE TANK CONNECTIONS
PRE-CHARGE TANK CONNECTION
1. Install two tees in the pump discharge port (Figure 4). The
pipe size must be at least as large as the discharge port.
2. Run a pipe or reinforced hose from one arm of the first tee
to the port on the pre-charged tank.
3. Connect the other end of the discharge tee to your plumb-
ing system.
4. Check the pre-charge of air in the tank with an ordinary tire
gauge. The pre-charge should be 2 PSI less than the cut-in
setting of the pump’s pressure switch. The pre-charge is
measured when there is no water pressure in the tank. Your
new pump has a 30/50 PSI switch, so adjust the tank pre-
charge pressure to 28 PSI.
5. Proceed to the Electrical section for hookup information.
STANDARD TANK CONNECTION
1. Install one tee in the pump discharge port (Figure 5).
2. Run a pipe from the pump discharge port to the inlet port
of your tank. The pipe size must be at least as large as the
discharge port.
3. Remove the 1/8” NPT pipe plug from the pump Air Volume
Control (AVC) port. Run tubing from the pump’s AVC port to
the port on the AVC mounted on the tank. See instructions
provided with tank and AVC for details. AVC port location
will vary, depending on your pump model (Refer to Parts
Index).
4. Proceed to the Electrical section for hookup information.
SEALING PIPE JOINTS
Use only PTFE pipe thread sealant tape for making all threaded connections to the pump itself. Do not use pipe joint
compounds on plastic pumps as they can react with the plastic in pump components. Make sure that all pipe joints in the
suction pipe are air tight as well as water tight. If the suction pipe can suck air, the pump will not be able to pull water from the
well.
Figure 4: Pre-Charged Tank Connections Figure 5: Standard Tank Connections

7
P15002 (11-01-22)
ELECTRICAL
MOTOR SWITCH SETTINGS
DISCONNECT POWER BEFORE WORKING ON PUMP, MOTOR,
PRESSURE SWITCH, OR WIRING.
1/2 HP motors are dual voltage and are factory set to 115 V. 3/4 &
1 HP motors are also dual voltage, but are factory set to 230 V.
Motor terminal board (located under the motor end cover) should
look like that shown below. Use the instructions to set your
motor to match your power source.
NEVER connect a motor set to 115 V to a 230 V
power source.
PLUG TYPE VOLTAGE SELECTOR
Voltage is set to 230 V . To change to 115 V:
1. Make sure power is off.
2. Pull the voltage change plug off of the tabs.
3. Move the voltage change plug to the 115 V position. The plug
will now cover 2 metal tabs and the arrow on the plug will
line up with the 115 V arrow on the label (see Figure 7).
4. Attach the incoming power leads to the two outer screws on
the pressure switch as shown in Figure 6.
5. Attach the ground wire to one of the grounding
connections, shown in Figure 6.
6. If there are other wires, they should be capped.
7. Reinstall the motor end and pressure switch covers.
DIAL TYPE VOLTAGE SELECTOR
Voltage is set to 230 volts . To change to 115 V:
Figure 6: Voltage set to 230 V, Plug Type
Figure 7: Voltage set to 115 V, Plug Type
1. Make sure power is off.
2. Turn the dial counter-clockwise until 115 shows in the dial
window as shown in Figure 9.
Figure 8: Voltage set to 230 V, Dial Type
Figure 9: Voltage set to 115 V, Dial Type
3. Attach the incoming power leads to the two outer screws on
the pressure switch as shown in Figure 8.
4. Attach the ground wire to the grounding connections as
shown in Figure 8.
5. If there are other wires, they should be capped.
6. Reinstall the motor end and pressure switch covers.

8P15002 (11-01-22)
ELECTRICAL
Hazardous voltage . Can shock, burn, or kill.
Connect ground wire before connecting power supply wires. Use
the wire size (including the ground wire) specified in the wiring
chart. If possible, connect the pump to a separate branch circuit
with no other appliances on it.
Explosion hazard. Do not ground to a gas
supply line.
WIRING CONNECTIONS
FIRE HAZARD. Incorrect voltage can cause a
fire or seriously damage the motor and voids the warranty. The
supply voltage must be within ±10% of the motor nameplate
voltage.
 Dual-voltage motors are factory wired for 230 volts. If
necessary, reconnect the motor for 115 volts, as shown. Do
not alter the wiring in single voltage motors.
 Install, ground, wire, and maintain your pump in compliance
with the United States National Electrical Code (NEC) or the
Canadian Electrical Code (CEC), as applicable, and with all
local codes and ordinances that apply. Consult your local
building inspector for code information.
CONNECTION PROCEDURE
1. Connect the ground wire first as shown in Figure 6. The
ground wire must be a solid copper wire at least as large as
the power supply wires.
2. There must be a solid metal connection between the
pressure switch and the motor for motor grounding
protection. If the pressure switch is not connected to the
motor, connect the green ground screw in the switch to the
green ground screw under the motor end cover. Use a solid
copper wire at least as large as the power supply wires.
3. Connect the ground wire to a grounded lead in a service
panel, to a metal underground water pipe, to a metal well
casing at least ten feet (3 m) long, or to a ground electrode
provided by the power company or the hydro authority.
4. Connect the power supply wires to the pressure switch as
shown in Figure 6.
WIRING CHART – RECOMMENDED WIRE AND FUSE SIZES
MOTOR HP VOLTS MAX.
LOAD AMP
BRANCH
FUSE
RATING AMP
DISTANCE IN FEET(METERS) FROM MOTOR TO SUPPLY
0-100 (0-30) 101-200 (31-61) 201-300 (62-91) 301-400 (92-122)
AWG WIRE SIZE (MM
2
)
1/2 115/230 8.5/4.3 15/15 14/14 (2/2) 12/14 (3/2) 10/14 (5.5/2) 8/14 (8.4/2)
3/4 115/230 11.4/5.7 20/15 14/14 (2/2) 10/14 (5.5/2) 8/14 (8.4/2) 6/12 (14/3)
1115/230 12.2/6.1 25/15 12/14 (3/2) 8/14 (8.4/2) 8/14 (8.4/2) 6/12 (14/3)
FP4000, FP4100, 2800E, 3100P SERIES
HORSEPOWER VOLTS
MAX.
LOAD
AMP
BRANCH
FUSE
RATING AMP
DISTANCE IN FEET(METERS) FROM MOTOR TO SUPPLY
0-100 (0-30) 101-200 (31-61) 201-300 (62-91) 301-400 (92-122)
AWG WIRE SIZE (MM
2
)
1/2 115/230 8.5/4.2 15/15 14/14 (2/2) 12/14 (3/2) 10/14 (5.5/2) 8/14 (8.4/2)
3/4 115/230 11.0/5.5 20/15 12/14 (3/2) 10/14 (5.5/2) 8/14 (8.4/2) 6/14 (14/2)
1115/230 12.0/6.0 20/15 12/14 (3/2) 10/14 (5.5/2) 8/14 (8.4/2) 6/14 (14/2)
FP4150 AND 2200C SERIES

9
P15002 (11-01-22)
ELECTRICAL
WIRING CHART – RECOMMENDED WIRE AND FUSE SIZES
HORSEPOWER VOLTS
MAX.
LOAD
AMP
BRANCH
FUSE
RATING
AMP
DISTANCE IN FEET(METERS) FROM MOTOR TO SUPPLY
0-100
(0-30)
101-200
(31-61)
201-300
(62-91)
301-400
(92-122)
AWG WIRE SIZE (MM
2
)
3/4 115/230 14.8/7.4 20/15 12/14 (3/2) 8/14 (8.4/2) 6/14 (14/2) 6/12 (14/3)
1115/230 19.2/9.6 25/15 10/14 (5.5/2) 8/14 (8.4/2) 6/12 (14/3) 4/10 (21/5.5)
FP4800 AND 4800S SERIES
HORSEPOWER VOLTS
MAX.
LOAD
AMP
BRANCH
FUSE
RATING
AMP
DISTANCE IN FEET(METERS) FROM MOTOR TO SUPPLY
0-100
(0-30)
101-200
(31-61)
201-300
(62-91)
301-400
(92-122)
AWG WIRE SIZE (MM
2
)
1/2 115 7.2 15 14 (2) 12 (3) 10 (5.5) 8 (8.4)
3/4 115 8.6 15 14 (2) 10 (5.5) 8 (8.4) 6 (14)
1115 10.5 15 14 (2) 10 (5.5) 10 (5.5) 6 (14)
FP4105, 2800, 2802, 2803 SERIES

10 P15002 (11-01-22)
START THE PUMP
PREPARING TO START THE PUMP
NEVER RUN PUMP DRY. Running pump without
water may cause pump to overheat, damaging seal and possibly
causing burns to persons handling pump. Fill pump with water
before starting.
NEVER RUN PUMP AGAINST CLOSED DISCHARGE. To
do so can boil water inside pump, causing hazardous pressure in
unit, risk of explosion and possibly scalding persons
handling pump.
1. Remove the priming plug from the priming tee and fill the
pump. Fill all piping between the pump and the well and
make sure that all piping in the well is full. If you have also
installed a priming tee in the suction piping, remove the
plug from the tee and fill the suction piping.
2. Replace all fill plugs.
3. Power on. Start the pump. If you don’t have water after 2 or
3 minutes, stop the pump and remove the fill plugs.
Refill the pump and piping. You may have to repeat this
several times in order to get all the trapped air out of the
piping. A pump lifting water 25’ may take as long as 15
minutes to prime.
4. After the pump has built up pressure in the system and
shut off, check the pressure switch operation by opening
a faucet or two and running enough water out to bleed off
pressure until the pump starts. The pump should start
when pressure drops to 30 PSI and stop when pressure
reaches 50 PSI.
5. Run the pump through one or two complete cycles to verify
correct operation. This will also help clean the system of
dirt and scale dislodged during installation.
WINTERIZING THE PUMP
To prepare the pump for freezing temperatures:
1. Shut off power to the pump.
2. Relieve system pressure. Open a faucet and let it drain until
water stops flowing.
3. Drain the pump. Your pump may have a separate drain plug.
Remove this plug and let it drain.
Your pump may only have a plug or connection on the side of
the pump. Remove this and let the pump drain. Some water
will remain in the pump. A small amount of water left in the
pump will not harm it if it freezes.
Figure 10: Priming The Pump

11
P15002 (11-01-22)
TROUBLESHOOTING
SYMPTOM POSSIBLE CAUSE(S) CORRECTIVE ACTION
Motor will not run.
Disconnect switch is off.
Fuse is blown or circuit breaker tripped.
Starting switch is defective.
Wires at motor are loose,
disconnected, or wired incorrectly.
Pressure switch contacts are dirty.
Be sure switch is on.
Replace fuse or reset circuit breaker.
DISCONNECT POWER; Replace starting switch.
Refer to instructions on wiring (Page 8). DISCONNECT POWER; check
and tighten all wiring.
Capacitor voltage may be hazardous. To discharge capacitor,
hold insulated handle screwdriver BY THE HANDLE and short capacitor
terminals together. Do not touch metal screwdriver blade or capacitor terminals.
If in doubt, consult a qualied electrician.
DISCONNECT POWER and le contacts with emery board or nail le.
Motor runs hot and
overload kicks off.
Motor is wired incorrectly.
Voltage is too low.
Pump cycles too frequently.
Refer to instructions on wiring.
Check with power company. Install heavier wiring if wire size is too small (See
Electrical / Wiring Chart).
See section below on too frequent cycling.
Motor runs but no
water is delivered*
* (Notice: Stop
pump; then check
prime before
looking for other
causes. Unscrew
priming plug and
see if water is in
priming hole).
Pump in new installation did not pick up
prime through:
1. Improper priming priming
2. Air leaks
3. Leaking foot valve or check valve
Pump has lost prime through:
1. Air leaks
2. Water level below suction pipe inlet
Foot valve or strainer is plugged.
Ejector or impeller is plugged.
Check valve or foot valve is stuck shut.
Pipes are frozen.
Foot valve and/or strainer are buried in
sand or mud.
Water level is too low for shallow well
setup to deliver water.
In new installation:
1. Re-prime according to instructions.
2. Check all connections on suction line, AVC, and ejector with soapy water or
shaving cream.
3. Replace foot valve or check valve.
In installation already in use:
1. Check all connections on suction line and shaft seal.
2. Lower suction line into water and re-prime. If receding water level in well
exceeds 25’ (7.6M), a deep well pump is needed.
Clean foot valve or strainer.
Clean ejector or impeller.
Replace check valve or foot valve.
Thaw pipes. Bury pipes below frost line. Heat pit or pump house.
Raise foot valve and/or strainer above bottom of water source.
Clean foot valve and strainer.
A deep well jet package may be needed (over 25 ft. to water) to deliver water.
Pump does not
deliver water to full
capacity.
Water level in well is lower than
estimated.
Steel piping (if used) is corroded or limed
causing excess friction.
Piping is too small in size.
Packed well point.
A deep well jet will be needed if your well is more than 25’ (7.6M) depth to water.
Replace with plastic pipe where possible, otherwise with new steel pipe.
Use larger piping.
Backush well point or sink new point.
Pump delivers
water but does
not shut off or
pump cycles too
frequently.
Pressure switch is out of adjustment or
contacts are welded together.
Faucets have been left open.
Venturi, nozzle or impeller is clogged.
Standard pressure tank is waterlogged
and has no air cushion.
Pipes leak.
Foot valves leak.
Air charge too low in pre-charged tank.
DISCONNECT POWER; adjust or replace pressure switch.
Close faucets.
Clean venturi, nozzle or impeller.
Drain tank to air volume control port. Check AVC for defects. Check all
connections for air leaks.
Check connections.
Replace foot valve.
DISCONNECT POWER and open faucets until all pressure is relieved.
Using tire pressure gauge, check air pressure in tank at valve stem located on
the tank. If less than pressure switch cut-in setting (30-50 PSI), pump air into
tank from outside source until air pressure is 2 PSI less than cut-in setting
of switch. Check air valve for leaks (use soapy solution) and replace core if
necessary.
Air spurts from
faucets.
Pump is picking up prime.
Leak in suction side of pump.
Well is gaseous.
Intermittent over-pumping of well.
(Water drawn down below foot valve.)
When pump has picked up prime, it should pump solid water with no air. Suction
pipe is sucking air. Check joints for leaks with soapy water.
Consult factory about installing a sleeve in the well.
Lower foot valve if possible, otherwise restrict pump discharge

12 P15002 (11-01-22)
PARTS INDEX
FP4822, FP4832/4810S
FP4012/3105P, FP4022/3107P, FP4032/3110P

13
P15002 (11-01-22)
PARTS INDEX
* Not pictured
** Two slots connecting motor to base only
KEY
NO PART DESCRIPTION QTY FP4012-10 FP4022-10 FP4032-10 FP4822-08 FP4832-08
1/2 HP 3/4 HP 1 HP 3/4 HP 1 HP
1Motor 1J218-1651-115 J218-1652 J218-1653 J218-1006 J218-1007
2 Hex Capscrew - 3/8" - 16 x 2" Lg. 4 U30-78ZP U30-78ZP U30-78ZP - -
2 ** Hex Screw - 3/8" - 16 x 1" 2 - - - U30-74SS U30-74SS
2Screw, Socket Head 8 - - - 121P0310 121P0310
* Nut - M6-X1 SS 8 - - - U36-207SS U36-207SS
3 Water Slinger 1 17351-0009 17351-0009 17351-0009 C69-7 C69-7
4 Seal Plate 1 N3-15P N3-15P N3-15P 784S0070 784S0070
5 Seal Plate Gasket 1 U9-390 U9-390 U9-390 111P0490 111P0490
6Shaft Seal 1U109-6B U109-6B U109-6B - -
6A Shaft Seal Stationary Face 1 - - - 111P0510 111P0510
6B Shaft Seal Rotating Face 1 - - - 111P0500 111P0500
7Impeller 1J105-40PNB J105-42PNB J105-22PB 101P1720 101P1730
7A Floating Wear Ring 1 N23-12SS N23-12SS N23-12SS - -
8Priming Bae 1U97-153P U97-153P U97-153P - -
9Diffuser/Venturi/Nozzle
Assembly 1N101-30PA N101-30P N101-29P 101P2900 101P2900
10 Nozzle O-Ring 1 U9-449 U9-449 U9-449 111P1100 111P1100
11 Pump Body - Assembly 1 N76-46P N76-46P N76-46P 723S0850 723S0850
12 Pipe Plug - 1/4" ( ) WC78-40T (2) WC78-40T (2) WC78-40T (2) - -
12 Pipe Plug - SS ( ) - - - 121P6090 (1) 121P6090 (1)
12A Pipe Plug Washer 1 - - - 111P0990 111P0990
13 Barbed Elbow - 90° - 1/4" NPT 1 U111-212T U111-212T U111-212T - -
13 Compression Elbow - 90° 1 - - - 171P4750 171P4750
14 Base 1J104-9F J104-9F J104-9F C4-42P C4-42P
15 Rubber Pad 1C35-5S C35-5S C35-5S - -
16 Tube 1/4" I.D. 1 U37-670P U37-669P U37-669P U37-671P U37-671P
17 Barbed Elbow - 90° - 1/4" NPT 1 - - - - -
18 Pressure Switch 1U217-1202 U217-1202 U217-1202 U217-1202 U217-1202
19 Locknut - 1/2" 1 U36-112ZP U36-112ZP U36-112ZP U36-112ZP U36-112ZP
20 Connector 1L43-5C L43-5C L43-5C L43-5C L43-5C
Seal Kit PP1530 PP1530 PP1530 - -
(Includes 3, 5, and 6)
FLOTEC MODELS

14 P15002 (11-01-22)
PARTS INDEX
* Not pictured
** Two slots connecting motor to base only
KEY NO PART DESCRIPTION QTY 3105P-10 3107P-10 3110P-10 4810S
1/2 HP 3/4 HP 1 HP 1 HP
1Motor 1J218-1651-115 J218-1652 J218-1653 J218-1007
2 Hex Capscrew - 3/8" - 16 x 2" Lg. 4 U30-78ZP U30-78ZP U30-78ZP -
2 ** Hex Screw - 3/8" - 16 x 1" 2 - - - U30-74SS
2Screw, Socket Head 8 - - - 121P0310
* Nut - M6-X1 SS 8 - - - U36-207SS
3 Water Slinger 1 17351-0009 17351-0009 17351-0009 C69-7
4 Seal Plate 1 N3-15P N3-15P N3-15P 784S0070
5 Seal Plate Gasket 1 U9-390 U9-390 U9-390 111P0490
6Shaft Seal 1U109-6B U109-6B U109-6B -
6A Shaft Seal Stationary Face 1 - - - 111P0510
6B Shaft Seal Rotating Face 1 - - - 111P0500
7Impeller 1J105-40PNB J105-42PNB J105-22PB 101P1730
7A Floating Wear Ring 1 N23-12SS N23-12SS N23-12SS -
8Priming Bae 1U97-153P U97-153P U97-153P -
9Diffuser/Venturi/Nozzle Assembly 1N101-30PA N101-30P N101-29P 101P2900
10 Nozzle O-Ring 1 U9-449 U9-449 U9-449 111P1100
11 Pump Body - Assembly 1 N76-46P N76-46P N76-46P 723S0850
12 Pipe Plug - 1/4" ( ) WC78-40T (2) WC78-40T (2) WC78-40T (2) -
12 Pipe Plug - SS ( ) - - - 121P6090 (1)
12A Pipe Plug Washer 1 - - - 111P0990
13 Barbed Elbow - 90° - 1/4" NPT 1 U111-212T U111-212T U111-212T -
13 Compression Elbow - 90° 1 - - - 171P4750
14 Base 1J104-9F J104-9F J104-9F C4-42P
15 Rubber Pad 1C35-5S C35-5S C35-5S -
16 Tube 1/4" I.D. 1 U37-670P U37-669P U37-669P U37-671P
17 Barbed Elbow - 90° - 1/4" NPT 1 - - - -
18 Pressure Switch 1U217-1202 U217-1202 U217-1202 U217-1202
19 Locknut - 1/2" 1 U36-112ZP U36-112ZP U36-112ZP U36-112ZP
20 Connector 1L43-5C L43-5C L43-5C L43-5C
Seal Kit PP1530 PP1530 PP1530 -
(Includes 3, 5, and 6)
SIMER MODELS

15
P15002 (11-01-22)
KEY NO. PART DESCRIPTION QTY. USED 2803
1 HP
1 Capacitor Box Gasket 1 -
2Capacitor 1171P5750
3 Water Slinger 1 102P0540
4 Intermediate Support 1 731S1540
5Shaft Seal 1ZBR39250
6Impeller 1101P1150
7Diffuser 1101P0710
8 Seal Plate O-Ring 1111P0490
9Venturi 1101P0750
10 Venturi O-Ring 1111P0560
11 Nozzle 1101P0720
12 Nozzle O-Ring 1 111P0480
13 Washer 4 121P0810
14 Drain Plug 4171P1180
15 Pump Body 1 731S5600
16 Screw, Pump Body 4 121P1090
17 Hose Barb - 90° 2 U111-212T
18 Pressure Switch Tubing 1U37-669P
19 Motor Foot 1 -
20 Pressure Switch 1U217-1202
21 Connector - 1/2" NSPM 1 J43-13C
SIMER MODELS
PARTS INDEX

16 P15002 (11-01-22)
FP4105/2800, 2802
2800E, 2802E
PARTS INDEX

17
P15002 (11-01-22)
KEY NO PART DESCRIPTION QTY FP4105
1/2 HP
1Capacitor 1171P5620
2 Screw 3.5 x 12.7 11 -
3 Wiring Box and Cover 1 102P2870
4 Wiring Box Cover Gasket 1 -
5Pressure Switch 1U217-1202
6 Hose Barb - 90° 2 U111-212T
7 Connector, 1/2" NSPM 1 J43-13C
*Connector Lock Ring 1U36-112ZP
8 Wiring Box Base Gasket 1 111P1340
9 Motor with Seal Plate 1 -
10 Seal Plate Insert 1 101P1290
11 Seal Plate O-Ring 1 111P0700
12 Shaft Seal 1ZBR39020
13 Impeller 1731S5700
14 Diffuser/Venturi/Nozzle Assembly 1101P3440
15 Nozzle O-Ring 1 111P0480
16 Volute 1731P1000
17 Pressure Switch Tube 1721S3140
18 Motor Foot 1 -
19 Fan 1 -
20 Motor End Cover 1 -
21 Flexible Pipe with Fitting (2800E and 2802E only) 1 ZA005390
FLOTEC MODELS
PARTS INDEX

18 P15002 (11-01-22)
PARTS INDEX
* Not pictured
** Two slots connecting motor to base only
KEY NO PART DESCRIPTION QTY 2800 / 2800E 2802 / 2802E
1/2 HP 3/4 HP
1Capacitor 1171P5620 171P5430
2 Screw 3.5 x 12.7 11 - -
3 Wiring Box and Cover 1 102P2870 102P2870
4 Wiring Box Cover Gasket 1 - -
5Pressure Switch 1U217-1202 U217-1202
6 Hose Barb - 90° 2 U111-212T U111-212T
7 Connector, 1/2" NSPM 1 J43-13C J43-13C
*Connector Lock Ring 1U36-112ZP U36-112ZP
8 Wiring Box Base Gasket 1 111P1340 111P1340
9 Motor with Seal Plate 1 - -
10 Seal Plate Insert 1 101P1290 101P1290
11 Seal Plate O-Ring 1 111P0700 111P0700
12 Shaft Seal 1ZBR39020 ZBR39020
13 Impeller 1731S5700 731S2220
14 Diffuser/Venturi/Nozzle Assembly 1101P3440 101P3440
15 Nozzle O-Ring 1 111P0480 111P0480
16 Volute 1731P1000 731P1000
17 Pressure Switch Tube 1721S3140 721S3140
18 Motor Foot 1 - -
19 Fan 1 - 102P0570
20 Motor End Cover 1 - -
21 Flexible Pipe with Fitting (2800E and 2802E only) 1 ZA005390 ZA005390
SIMER MODELS

19
P15002 (11-01-22)
PARTS INDEX
* Seal Kit includes water slinger, shaft seal, seal plate gasket, and diffuser gasket
** Pump Body Assembly includes pump body, venturi, and nozzle
***Overhaul kit includes Seal Kit, impeller, and diffuser
* Seal Kit includes water slinger, shaft seal, seal plate gasket, and diffuser gasket
** Pump Body Assembly includes pump body, venturi, and nozzle
***Overhaul kit includes Seal Kit, impeller, and diffuser
KEY NO PART DESCRIPTION QTY FP4112-08 FP4122-08
1/2 HP 3/4 HP
1Motor 1J218-1651-115 J218-1652
2 Seal Plate 1 N3-9 N3-9
3 Seal Kit* 1 FPP1550 FPP1550
4 Pump Body Assembly ** 1 N176-38 N176-38F
5 Overhaul Kit *** 1 FPP1560 FPP1561
6Pressure Switch 1U217-1202 U217-1202
FLOTEC MODELS
KEY NO PART DESCRIPTION QTY 2805E-02 2810E-02
1/2 HP 3/4 HP
1Motor 1J218-1651-115 J218-1652
2 Seal Plate 1 N3-9 N3-9
3 Seal Kit* 1 FPP1550 FPP1550
4 Pump Body Assembly ** 1 N176-38 N176-38F
5 Overhaul Kit *** 1 FPP1560 FPP1561
6Pressure Switch 1U217-1202 U217-1202
SIMER MODELS

20 P15002 (11-01-22)
PARTS INDEX
FP4155/2205C, FP4157-01/2207C-01, FP4150/2210C
KEY NO PART DESCRIPTION QTY FP4155 FP4157-01 FP4150
1/2 HP 3/4 HP 1 HP
1 Motor and Seal Plate Assembly 1
See Kits Below
1A Motor Flange Screw 4
2 Seal Plate O-Ring 1
3Pressure Switch 1
4Shaft Seal 1
5Impeller 1
6 1/4" NPT x 1/4" Barbed Elbow 2
7Hose 1
8Diffuser 1
9 Diffuser Plate 1
10 Diffuser Plate O-Ring 1
11 Diffuser Plate Washer 3
12 Diffuser Plate Screw 3
13 Venturi 1
14 Nozzle 1
15 Pump Body 1
Seal Kit (Includes 2, 4, 10) 1 RPK-35 RPK-35 RPK-35
Overhaul Kit (Includes 1A, 2, 4, 5, 8, 9, 10, 11 (3), 12 (3), 13, 14) 1 RPK-205SW RPK-207SW RPK-210SW
Pump Body Assembly (Includes 2, 6, 13, 14, 15, 1/4" NPT Plug (2), 1/2" NPT Plug) 1 R176-73 R176-73 R176-73
Pressure Switch 1TC2151 TC2151 TC2151
Pressure Switch Tubing Kit (Includes 6(3), 7) 1 FPASFK FPASFK FPASFK
FLOTEC MODELS
