Hypro®Series 9260P, 9262 & 9263
Form L-1561
Rev B
Original Instruction Manual
9260 Series
Cast Iron, Polypropylene & Stainless Steel Series
Centrifugal Pump
KEEP FOR FUTURE REFERENCE

Contents
EU Language .........................................................................................................................................................................3
Introduction.................................................................................................................................................................4
Description.....................................................................................................................................................4
Intended Uses............................................................................................................................................................4
Purpose of Manual.....................................................................................................................................................4
Misuses...........................................................................................................................................................4
 PumpIdentication.....................................................................................................................................................5
Pump Technical Data..................................................................................................................................................5
Fluid Pumping Application........................................................................................................................................10
Tools................................................................................................................................................................10
Lifting, Transport, and Intermediate Storage............................................................................................................10
AssemblyandInstallation........................................................................................................................................................11
Assembly.........................................................................................................................................11
Installation......................................................................................................................................11
Plumbing Diagram....................................................................................................................................................12
Commissioning, Start-Up, Operation, Shutdown...................................................................................................................14
Information.....................................................................................................................................14
Start-Up, Operation, Shutdown................................................................................................................................14
Maintenance and Servicing..................................................................................................................................................15
Information............................................................................................................................15
Disposal......................................................................................................................15
Cleaning............................................................................................................................15
Maintenance, Routine Servicing, and Inspection.....................................................................................................15
Troubleshooting.................................................................................................................................16
Replacement Parts...................................................................................................................................................17
Declaration of Incorporation.................................................................................................................................................19
Warranty............................................................................................................................................20
- 2 -

- 3 -
EU Languages
DO NOT attempt to install or operate your pump before reading the manual. Original copies of the manual for Hypro
pumpsareprovidedinEnglish.Tondacopyinyournativelanguage,gotowww.hypropumps.com.
Vor dem Ablesen des Handbuches versuchen Sie NICHT, Ihre Pumpe zu installieren. Originale des Handbuches fur
Hypro-PumpenwerdenaufenglischzurVerfugunggestellt.ZueineKopieinIhrerMuttersprachenden,zu
www.hypropumps.com zu gehen (German)
N’essayez pas d’installer votre pompe avant de lire le manuel. Des exemplaires originaux du manuel pour des pompes
de Hypro sont fournis en anglais. Pour trouver une copie dans votre langue maternelle pour aller a
www.hypropumps.com (French)
NON tentare di installare la vostra pompa prima di leggere il manuale. Esemplare originale del manuale per Hypro
pompe sono in inglese. Per trovare una copia nella vostra lingua andare a www.hypropumps.com (Italian)
Непытайтесьустановитьвашнасосдочтенияруководства.Оригинальныекопииэтогоруководствадлянасосы
Hyproнаанглийскомязыке.Найтикопиюнавашроднойязыкперейтикwww.hypropumps.com(Russian)
NO intente instalar su bomba antes de leer el manual. Copias originales del manual para Hypro se provee de bombas
en ingles. Para encontrar una copia en tu idioma nativo ir a www.hypropumps.com (Spanish)
NIEprobowaćinstalowaćpompyprzedjejodczytanieminstrukcji.OryginalnekopieinstrukcjiobsługipompHyprosą
dostarczanewjęzykuangielskim.Abyuzyskaćkopięwtwoimojczystymjęzykuprzejdźdowww.hypropumps.com
(Polish)
Takmayacalışmayınokumadanoncepompanınmanuel.OrijinalkopyalarınıHypropompalarıicinIngilizceolarak
sunulmuştur.Birkopyasınıbulmakicinyereldilgitwww.hypropumps.com(Turkish)
Nao tente instalar a bomba antes de ler o manual. As copias originais dos manuais para Hypro bombas sao
fornecidos em Ingles. Para encontrar uma copia em sua lingua nativa ir para www.hypropumps.com (Portuguese)
VERGEETNIETuwpompvoorhetlezenvanhethandboek.ExemplarenvandehandleidingvoorHypropompenzijn
beschikbaarinhetEngels.Opzoeknaareenexemplaarinuweigentaalganaarwww.hypropumps.com(Dutch)

Introduction
Description
Hyprocentrifugalpumpsaredesignedforcreatingandboostingpressureinuidcircuits.Thepumpoperatesbytaking
inuidfromtheinletportafterwhichitisslungbytheimpellerandexpelledthroughtheoutletport.Constructionfeatures
include housings, impellers and seals which come in a variety of materials in order to be resistant to a range of chemicals.
Standardmodelsofcentrifugalpumpsrotateclockwise,whenlookingatthefrontofthepump.
Intended Uses
Hyprocentrifugalpumpsareintendedforcreatingorboostingdynamicpressureinapproveduids.Hyprocentrifugal
pumps should never be used to pump liquids above 140°F (60°C), or below 34°F (1°C). Any uses outside of those
speciedinthismanualareconsideredmisusesandareprohibited.ContactHyprotechnicalserviceaboutanyquestions
regardingspecicacceptableuses.
Purpose of Manual
This manual provides instructions and requirements that must be met when installing, using and maintaining the
product(s)identiedonthecover.
If the product is sold, the seller must pass this manual on to the new owner.
The following special attention notices are used to notify and advise the user of this product of procedures that may be
dangerous to the user or result in damage to the product.
ATTENTION
Attention is used to notify of installation, operation, or maintenance information that is important but not safety related.
Thissymbolisusedtodenotethepresenceofanelectricalhazardthatwillresultinpersonalinjury,deathorproperty
damage.
Thissymbolisusedtodenotethepresenceofahazardthatwillresultinpersonalinjury,deathorpropertydamage.
California Proposition 65 Warning --Thisproductandrelatedaccessoriescontainchemicalsknowntothe
State of California to cause cancer, birth defects or other reproductive harm.
Misuses
Hyprocentrifugalpumpsaredesignedtooperateeffectivelywithinthespeciedspeed,pressureandenvironmental
ranges.Goingoutsideoftheserangeswillvoidthewarrantyandcouldcausedamagetopropertyorseriousinjuryor
death.
• DO NOT runthepumpfasterthanthemaximumspeciedspeed.
• DO NOTrunthepumphigherthanthemaximumspeciedpressure.
• DO NOT run pumps when the liquid has exceeded the maximum or minimum temperature limit (See Intended Uses).
• DO NOT pump non-approved liquids.
• DO NOT pump water or other liquids for human consumption.
• DO NOToperateanypumpundertheinuenceofdrugsoralcohol.
• DO NOT run the pump dry.
- 4 -

- 5 -
Pump Identication
Hypro uses serialized labeling to enable users to precisely identify the pump’s manufacturing date.
Serial Number:
First and second digits: year (14 = 2014)
Third through fth digits: consecutive day of the year the pump was manufactured.
Sixth through tenth digits: unique pump serial number.
Pump Technical Data
(Allspecicationsandperformancedataarebasedonwaterasacarrieruid)
9262C, 9262C-CR, 9262S-C, 9262S-CR
Pump Dimensions
Dim. Inch mm
A 8.25 209.6
B7.60 193.0
C4 101.6
D3.70 94.0
E3.06 77.7
F9.30 236.2
G4.4 111.8
H1.50 38.1
I3.00 76.2
9262C-C, 9262S-C, 9262C-CR and 9262S-CR Pump Specications
Pump Power
Source
Max Flow
Rate (GPM)
[LPM]
Max
Pressure
(PSI)
[BAR]
Max RPM Ports Dry Weight Mounting
Bolts
9262-C
Clutch
88
[333.1] 114
[7.86] 5000
1-1/4" NPT
inlet
1" NPT outlet
23lbs
(10.5kg) 3/8" OR M10
9262C-CR
9262S-C 145
[548.9]
9262S-CR
A
B
C
D
E
F
G
I
H
