GENERAL INSTRUCTIONS
Reciprocating pumps of both the plunger and cup
type are positive displacement in principle. Due to
positive displacement characteristics, problems may
arise through improper installation or application.
When new or unusual installations are planned, or
the material to be pumped is a liquid other than cold
water, the customer should consult the factory for
additional information.
Positive displacement pumps must have a proper
size and operable type of pressure regulating valve
or pressure relief valve piped into the discharge line.
This is mandatory to prevent damage to pump and
piping or possible injury to personnel. Do not install
any valves or shutoff devices in the by-pass line from
pressure regulator to tank or supply.
All pumps should be installed level. For mobile
applications the maximum angle of intermittent
operation should be no more than 5 degrees in any
one direction.
CALIFORNIA PROPOSITION 65 WARNING:
This product and related
accessories contain chemicals known to the State
of California to cause cancer, birth defects or
other reproductive harm.
INSTALLATION
Install suction piping one pipe size larger than suction
tapping in pump. Reduce piping size at pump with a
reducer coupling. A suction surge arrester will assure
smoother operation. Keep suction piping as short
and simple as possible with a minimum of lift when
operating under suction lift conditions. Avoid any high
points in suction line. Suction piping must not have
any air leaks. Check suction piping assembly for leaks
by using 20-80 psi air pressure and soap bubbles or
submerging assembly under water.
Use suction strainer and screen of adequate size
to avoid restriction of pump suction. Strainer mesh
should be sufficiently small to prevent passage of
trash which may lodge under pump valves. Keep
screen clean with a regular maintenance schedule to
avoid starving pump suction. Many pump problems
and most plunger cup failures are directly traceable to
a starved suction condition.
When pumping liquids that are heated, reduce
pump speed to avoid suction problems. Be sure
that discharge line is properly protected by means
of a pressure regulating valve and a discharge surge
arrester of proper size, capacity and pressure rating.
The discharge line should be of comparable size to
discharge tapping in pump. Discharge line velocity
should not exceed 5 feet per second for most
satisfactory operation.
Nozzle capacity or demand should not exceed 90%
of pump capacity for satisfactory regulating valve
operation. Nozzling in excess of this capacity may
cause unstable pressure regulator operation. It is
also preferred to nozzle in excess of 50% of pump
capacity to reduce the rate of erosion or wear on the
regulating valve and seat.
When lower system capacity demands are required,
the pump speed should be reduced by changing drive
ratios. This will reflect savings in power consumption,
while reducing valve wear and extend pump life.
If line shock or water hammer is encountered, a
second surge arrester should be installed in the
discharge line adjacent to the spray gun or nozzles.
Under some conditions it may also be desirable to
isolate pump from piping with a suitable high pressure
hose. This will eliminate transmission of line vibration
to the pump and minimize possible failure of piping,
pipe threads and pump casting.
Never pipe the bypass from a pressure regulating
valve back into the pump suction. When the discharge
line is shut off, the complete bypass is circulated
back into the pump suction with a resulting rapid
temperature rise which will destroy plunger cups and
gaskets.
Avoid freezing by draining all water from pump and
system in cold weather. Make sure that the drive is
adequate for the horsepower required and is properly
aligned and tensioned. With belt drives, the pulley
on both the motor and pump should be located as
closely as possible to the bearing to reduce bearing
and shaft bending loads. Make sure that all bolts,
nuts, set screws and keys are properly tightened and
pump belts and pulleys are properly protected by
guards according to code.
DIRECT DRIVE ENGINE DRIVEN PUMPS
It is desirable to align the Dodge®Para-Flex®
couplings as accurately as possible to minimize
flexing. After any repositioning, recheck both parallel
and angular alignments by mounting indicators,
near the O.D. of the flange, and rotate the shaft 360
degrees. A good installation indicator reading should
exceed .030". Flange should be positioned on shaft
to obtain 3-1/16" measured from adapter to rear of
clamp ring. Adaptor bolts should be torqued to 300lbs
and clamp ring bolts to 400lbs.
STARTING PUMP
Fill pump crankcase with recommended oil to the
level mark on the oil saber. Oil recommendations are
covered in lubrication section of pump instructions.
Replace all drain plugs in pump and piping. Inspect
tank to be sure that no foreign material is in tank
or suction line. Fill tank at least half full or connect

23833A034 06/04/14
3
suction to water supply. Open valve if present in
suction line. If pumping from a pit, make sure that
suction line is completely submerged. Make sure
all valves, including spray gun or nozzles, are open
in discharge line. Spray gun may be anchored to
discharge back into the tank. Completely back off
pressure adjusting screw on pressure regulating valve.
CAUTION: When pumping from a pit or under a
suction lift condition, remove the cylinder end caps
and pour water into each cylinder. This will assure that
water is present in the cylinder to lubricate cups.
After starting, close discharge valve or spray gun
slowly while watching pressure gauge to make sure
relief valve or unloader is operating properly. Adjust
relief valve or unloader to desired pressure. See
regulator instructions. Cycle nozzles, or gun, on and
off to be sure that pressure adjustment and regulator
operation is satisfactory. Nozzle capacity should
not exceed 90% of pump capacity for satisfactory
regulating valve operation.
LUBRICATION
Fill gear case with Mobilgear 630 or equal additive
to 3-1/2 qts for D35 Series and 5-1/2 qts for D50-60
Series. Maintain oil level at the mark on oil dipstick.
NOTE: After first 30 hours of operation, drain oil from
gear case (preferably drain at operating temperature),
replace plug and fill gear case with kerosene to
normal oil level. Operate at full speed at zero pressure
for two minutes then drain, replace plug and refill
crankcase with new oil. Change oil every 300 hours
thereafter. Check oil level daily and add oil as needed.
ADDITIVES FOR CRANKCASE OIL
Use of molybdenum disulfide (MoS2) is highly
recommended as an additive to the gear case oil in
back geared pumps and speed reducers. The additive
is compatible with all known oils. It appears to be so
effective in reducing wear and friction that power train
life may be doubled between overhauls.
• D35 volume MoS2concentrate or dispersion “M”
for 5% – 6 fl. oz.
• D35 volume MoS2concentrate or dispersion “M”
for 10% – 12 fl. oz.
• D50-60 volume MoS2concentrate or dispersion
“M” for 5% – 9 fl. oz.
• D50-60 volume MoS2concentrate or dispersion
“M” for 10% – 18 fl. oz.
SERVICE
Disconnect electrical leads to motor, or remove spark
plug leads on engine.
REMOVING PLUNGERS: BELL SHAPED
CUPS
Place plunger at front end of cylinder and remove
valve assembly, if required, to provide clearance for
pulling plunger. Remove socket head cap screw,
thread plunger removal tool onto plunger stud and pull
plunger out of cylinder liner.
REPLACING PLUNGER CUPS
(MODELS D35-12D, D50-12, D60-10)
Remove nut from plunger stud and remove worn cup.
Apply non-hardening sealing compound and replace
with new cup. Thread nut back onto plunger stud and
tighten nut to a snug compression loading.
CAUTION: Do not overtighten nut on plunger cup,
as this will cause excessive squeeze at the cup heel
resulting in rapid cup wear.
Before installing the plunger in the cylinder, the ring
gasket seal between the plunger and rod should be
inspected and replaced if worn. Inspect cylinders for
linear grooving and replace cylinders if necessary.
New cups will rapidly cut or wear out in groove
cylinders.
Thread the plunger removal tool onto the plunger stud
making it flush with the plunger nut. Lubricate plunger
cup with Molykote®or Lubriplate®and check to be
sure that the ring gasket is installed in plunger stud.
Retract plunger rod by rotating pump crankshaft.
Install plunger by driving plunger assembly back into
cylinder. Replace plunger rod socket head cap screw.
REPLACING PLUNGERS
V-RING PACKING (MODEL D35-12AVD)
Move plunger to the front end of the cylinder and
remove valve assembly if required to provide
clearance for pulling plunger. Remove cap screw and
with plunger at extended position, back off piston rod
and insert tool until large diameter catches behind
stud. Force plunger assembly from liner by rotating
crankshaft slowly. Inspect cylinders for linear grooving
and replace cylinders if necessary. New packing will
rapidly cut or wear out in grooved cylinders.

23833A034 06/04/14 4
V-rings should be lubricated with Molykote for ease in
assembly. Do not use a graphite type grease.
When installing each V-ring plunger assembly, rotate
crankshaft until piston rod is at the most extended
position. Place copper gasket in position in the stud
and use a small amount of Permatex®to hold in place.
Insert plunger assembly into liner and drive slowly into
place. Cap screw should then be inserted and torqued
to 25 ft/lb.
REPLACING PLUNGERS
SINGLE LIP CUP (MODEL D35-8PP)
Move plunger to front end of cylinder and remove
suction valve if required for clearance for pulling
plunger. Remove socket head cap screw and rotate
crankshaft to retract plunger rod from cylinder. Insert
V-ring packing tool into rear of cylinder and force
plunger assembly from cylinder by slowly rotating
crankshaft. Inspect cylinders for linear grooving and
replace cylinders if necessary. New cups will rapidly
cut or wear out in grooved cylinders.
Grease the O-ring and install in the groove on cup
follower. With a flat plate behind cup, hold the cup
and follower firmly in a vise with follower boss in hole
in cup. Use a thin blunt tool and carefully push entire
circumference of O-ring to the back of the groove
and under the lip of the cup. Assemble all parts onto
socket head cap screw and apply Lubriplate®to the
outside of cup. With plunger rod in forward position,
insert plunger assembly into cylinder and tighten cap
screw.
REPLACING CYLINDER LINERS
Remove plungers and rotate crankshaft until piston
rod is in rear position. Insert puller through the inside
of cylinder and pilot over piston rod. Insert disc into
slots on puller and slip plate over threads on puller.
Screw nut onto thread on puller and snug up. Tighten
nut until liner breaks loose. Loosen nut, slip disc out
of slot and remove puller. Repeat to remove remainder
of cylinder liners.
Reasonable care and judgment should be used
when installing the new tapered cylinder shell. Clean
out any accumulation of loose rust or corrosion in
tapered cylinder slots. Insert shells into position by
hand and drive into position firmly. Never use a hand
or hydraulic arbor press to install cylinder shells. If
extreme pressures are used during installation, parts
will be very difficult to remove for later replacement
and liners may be distorted.
REPLACING SEATS: CENTER POST
VALVES
Remove the valve and cylinder caps which provide
access to both the suction and discharge valves.
Remove the stainless steel shoulder screw, which
serves as a valve guide and spring retainer, spring
and valve from the pump fluid end. Assemble stud,
retainer and three screws. Insert screw heads through
holes in valve seat. Rotate retainer to the right until
heads catch and secure in place by screwing down
stud firmly by hand. Place plate over stud and screw
on nut. Torque slowly until seat breaks loose. Suction
valve seats in similar manner, except two stud lengths
are joined using coupling.
NOTE: Valve seats are usually distorted and cannot be
reused unless face is reground to flat condition.
Inspect tapered valve seat bore in fluid end for rust
and wipe out excess. Place a new lower seat in
tapered hole and drive lower seat firmly into place.
Repeat for upper seat being sure to also inspect
the tapered bore in housing for rust. Reassemble
the valve, spring and spring retainer, and verify that
springs are in correct location. When upper and lower
valve seats are the same size, the heavier spring is
always installed on the upper or discharge valve.
NOTE: Be sure that shoulder screw is bottomed in
valve seat and the valve disc is installed on valve with
flat face down.
Inspect O-ring on valve and cylinder caps. Replace
if they show signs of wear. Lubricate O-rings and
replace cap, bar and nuts.

23833A034 06/04/14
5
REPLACING SEATS: CAGED VALVES
Remove spring retaining bar, spring and flat valve.
When removing upper valve seat, pass head of puller
through hole in valve seat before the slide wedge is
inserted alongside puller bolt. Draw down on the nut
at the top of the bolt. When removing lower seats,
drop puller bolt through opening for upper seat and
remove in same manner using the slide wedge on
pumps where lower seats are same size as upper
seats.
Place new lower seat in tapered hole in cylinder body.
Hold a soft brass or hardwood round bar against
slot and drive into place. The knocker stem is in
two pieces so that it can be shortened for installing
discharge valves after suction valves have been
installed.
REPLACING PLUNGER ROD SEALS
The rod seal assembly contains two seals and two
oil seals with lips facing the power end. The oil seal
can be replaced without taking the fluid end off by
removing the cylinder and piston to allow access to oil
seal housing. Unscrew the two Allen screws and place
them into the other two tapped holes. Gradually screw
them in to push oil seal housing off the retainer. After
assembling new seals in oil seal housing, an assembly
thimble should be used on the end of the crosshead
rod for sliding the oil seal housing back into the
retainer. Check gasket and replace if damaged.
REMOVING CRANKSHAFT AND
PINION SHAFT
Remove plunger assemblies and remove connecting
link caps. Move the link-crosshead assembly as far
forward as possible. On some models, it may be
necessary to remove the fluid cylinder body to obtain
clearance for crankshaft removal.
Secure separation of the crankshaft gear and gear
case so that crankshaft will be held in place against
pinion shaft. Remove both crankshaft bearing caps.
Hold crankshaft at ring gear and left-hand link journal
to prevent dropping into bearing bores and remove
from gear case by moving crankshaft to the right until
left end can be swung free.
To remove pinion shaft, observe inside of gear case
to see if small sheet metal plates are in front of each
bearing. These plates must be removed prior to
the bearing caps.
Tap the end of the pinion shaft extension to remove
the bearing cup at the opposite end. After removing
pinion shaft, the remaining bearing cup can be
removed by gently tapping against the peripheral
edge of the cup with a brass rod.
REPLACING PINION SHAFT AND
SHIMMING BEARINGS
After installing the link-crosshead assemblies and
moving them toward the fluid end as far as possible,
tap the right-hand pinion shaft bearing cup into
position using the bearing cap. Place pinion shaft in
position and tap left-hand bearing cup into place.
Replace sheet metal plates, if used on this model
pump.
Cover the shaft keyway to protect lip of oil seal. Slide
on the open bearing cap with a .030" shim. Tighten
the four cap screws to recommended torque.
Install other cap using total shim thickness. Tighten
cap screws holding pinion or crankshaft caps to gear
case. Rotate pinion shaft back and forth, applying
about 15 lbs. axial force to properly seat tapered
rollers. Measure end-play by using an indicating
gauge.
Subtract recommended end-play (.005"– .009") from
actual end-play. This is the amount of shim that must
be removed. After excess shim thickness has been
removed, replace caps and retighten cap screws.
Measure end-play, and if end-play is not within limits
recommended, add or subtract shims as required.
Pinion bearing shims are made of .002" layers bonded
together. Start separation of layers by heating edge,
then peel back.
REPLACING CRANKSHAFT AND
SHIMMING BEARINGS
Press the bearing cups into the caps. Place one
cap into position on the right side with cap screws
engaged about one turn. Install crankshaft, left end
first, and push both bearing caps into place. Extreme
care should be exercised to avoid damage to gear
teeth, bearings and link journals.
For quiet operation and long life, the crankshaft
and bearings must be installed with .003" to .005"
preload. To adjust, loosen the four cap screws on the
pinion shaft bearing cap. Place about a .045" shim
on the right crankshaft bearing cap and tighten the
five cap screws. Install the left cap without shims
and secure with two cap screws. Torque at 13 ft/lbs
and rotate the crankshaft. Retorque the cap screws.
Repeat three times to properly seat the tapered roller
bearings. Measure the shim gap remaining between
the bearing cap and the gear case. Required shim
thickness for this cap is equal to the average gap
measurement plus .031" for D35 and .022" for D50-60
Series. Insert correct shim thickness under left bearing
cap and tighten cap screws. Next, install connecting
links and caps, and torque cap screws.

23833A034 06/04/14 6
Check for adequate side clearance of links on
crankshaft. Some shims must be moved from one
end to the other until sideways movement of all links
can be seen. Check the torque of cap screws on all
bearing caps.
RECONDITIONED CRANKSHAFTS
When the crank throws are slightly damaged, they can
sometimes be reconditioned for further use. This can
be done by sandpapering and polishing until all ridges
are completely removed. The final polishing operation
should be with very fine emery cloth. If the surface is
badly damaged, the crankshaft can often be salvaged
by “metalizing” the crank throw, regrinding and
polishing to the original diameter.
SERVICING CONNECTING LINKS
The connecting rod link is furnished with replaceable
split sleeve bearing inserts at the crank throw. Do not
attempt to re-fit connecting links to the crankshaft
bearings by filing or grinding the mating faces of the
link cap where it contacts the link. Always be sure
that the proper side of the link is placed upward
when attaching it to the crankshaft. The upper side
contains an oil hole at the crosshead end of the link.
This oil hole must be up to allow proper oil feeding
to the crosshead pin bushing. The wrist pin is then
press-fitted into the crosshead and slip-fitted through
the bronze bushing. Use an arbor press to force in
the wrist pin, checking to see if the link is free to
rotate after the wrist pin is pressed in. Verify that both
sides of the wrist pin do not protrude beyond the
crosshead.
The crosshead end of the connecting link is fitted with
a bronze bushing. New replacement link bushings are
reamed to the proper size for immediate installation.
If the bushing is removed from an old link, it may
be necessary to ream the replaced bushing to the
proper inside diameter after it is pressed into the link.
When placing the bushing on the link, be sure that the
oil holes in the bushing and link are in line after the
bushing is pressed into position.
CROSSHEAD AND PISTON RODS
Repair parts for the crosshead and piston rod are
supplied as a complete unit. If either of these parts
becomes worn, it is necessary to replace both the
crosshead and piston rod. It is not practical to attempt
to tighten a loose piston rod in a crosshead. Under
normal conditions a crosshead will not wear, nor will
the bore of the crankcase wear to the extent that
oversize crossheads will be required. A clearance of
.002" to .004" is standard for the crosshead.
RECOMMENDED TORQUE VALUES
(foot-pounds)
FASTENER LOCATION
Link Bearing Caps - 40
Crankshaft End Caps - 20
Pinion Bearing End Caps - 20
Fastener Plunger Assembly
to Piston Rod Nut and Cap Screw- 25
Valve Cover Clamps - 50
Cylinder Cover Clamps - 50

23833A034 06/04/14
7
D35-8PP-2H & D45-12PP
INDUSTRIAL PUMPS PARTS LIST
41
45
39
35
37
42
43
44
48
49
26
28
27 29 30
31
32
21 22 19 17 15 13 14 23
12
11
40 38 36 34
33 46 50
47
24 25
20
9
10
812 3 4 5 18
16
7
6
Cap Screw 18832A000 (3 req) Cap Screw 18832A000 (3 req)
Retainer 18833A001 (3 req) Retainer 18833A000 (3 req)
Spring 11829A000 (3 req) Spring 18462A000 (3 req)
Valve 18834A001
(3 req)
Valve 18834A000
(3 req)
Valve Seat 18835A001 (3 req) Valve Seat 18835A000 (3 req)
DISCHARGE VALVE AND SEAT COMPLETE NO. 18925A001K SUCTION VALVE AND SEAT COMPLETE NO. 18925A000K

23833A034 06/04/14 8
D35-8PP-2H & D45-12PP
INDUSTRIAL PUMPS PARTS LIST
Catalog Number of Industrial Pump (Helical Gears) D35-8PP-2H D45-12PP
Item Description Qty. Eng. No. Eng. No.
1 GEAR CASE 1 04663E000 04663E000
2 GASKET, FOR GEAR CASE LID 1 06222C000 06222C000
3 CAP SCREW, 5/16"-18 UNC x 7/8" 8 19100A005 19100A005
4 LID, FOR GEAR CASE 1 04664B000 04664B000
5 VENT AND OIL FILTER PLUG 1 17388A000 17388A000
6 OIL GAUGE WITH O-RING 1 17360A010K 17360A010K
7 CYLINDER LINER 3 18806A001 18806A001
PLUG, 1-1/4" PIPE 1 05022A041 05022A041
PLUG, 2" PIPE 2 05022A048 05022A048
O-RING, FOR CYLINDER LINER 3 05876A085 05876A085
8 PINION SHAFT WITH HELICAL PINION 1 19816B000 19816B000
SHIM PLASTIC FOR PINION SHAFT .003" THICK 4 05231A074 05231A074
SHIM PLASTIC FOR PINION SHAFT .015” THICK 4 05231A075 05231A075
9 CONE, BEARING, PINION SHAFT 2 05674A013 05674A013
CUP, BEARING, PINION SHAFT 2 05675A009 05675A009
10 CAP, OPEN, PINION SHAFT 1 04563A001 04563A001
CAP, CLOSED, PINION SHAFT 1 04741B000 04741B000
OIL SEAL, OPEN END OF PINION SHAFT 1 05710A017 05710A017
CAP SCREW, 3/8"-UNC x 1", BEARING CAPS 18 19101A009 19101A009
WASHER SEAL, FOR 3/8" CAP SCREWS 18 14946A003 14946A003
11 CRANKSHAFT WITH HELICAL GEAR 1 19817C000 19817C000
12 CONE, BEARING, FOR CRANKSHAFT 2 05674A015 05674A015
CUP, BEARING, FOR CRANKSHAFT 2 05675A011 05675A011
CAP, BEARING, FOR CRANKSHAFT 2 18466B001 18466B001
SHIM PLASTIC, 4-17/32" I.D.,
6-1/32" O.D., .003" THICK
6 05068A017 05068A017
SHIM PLASTIC, 4-17/32" I.D.,
6-1/32" O.D., .015" THICK
5 05068A015 05068A015
13 CROSSHEAD AND PISTON ROD 3 06361B002 06361B002
14 LINK AND BUSHING AND CAP SCREWS 3 11651C002 11651C002
15 BUSHING, FOR LINK 3 B1619A000K B1619A000K
16 BEARING, HALVES REG., FOR LINK 3 11647A012K 11647A012K
17 WRIST PIN, CROSSHEAD TO LINK 3 M1525A001 M1525A001
18 CAP SCREW, FOR LINK 6 06106A040 06106A040
WASHER, LOCK 6 05454A025 05454A025
19 HOUSING, OIL SEAL 3 24959A001 24959A001
OIL SEAL 6 22835A004 22835A004
20 RETAINER, OIL SEAL HOUSING 3 24958A000 24958A000
SCREW, ALLEN 6 06106A034 06106A034
GASKET, SEAL HOUSING 3 05059A434 05059A434
KIT FOR REF. NO. 19 & 20 1 24648A000 24648A000
Catalog Number of Industrial Pump (Helical Gears) D35-8PP-2H D45-12PP
Item Description Qty. Eng. No. Eng. No.
21 SPRING, FOR RETAINER FOR OIL SEAL WIPER 3 M01643A000 M01643A000
22 GASKET, VELLUMOID, FOR OIL SEAL ASSEMBLY 3 05059A058 05059A058
23 DRAIN PLUG, MAGNETIC 3/4" 1 17481A002 17481A002
24 CAP SCREW, 3/4"-10 UNC x 3"
CYLINDER BODY TO GEAR CASE
4 06106A038 06106A038
LOCK WASHER, 3/4", FOR REF. 24 4 05454A003 05454A003
25 CAP SCREW, 5/8"-11 UNC x 2"
CYLINDER BODY TO GEAR CASE
4 19105A008 19105A008
26 CAP SCREW, PLUNGER TO PISTON ROD 3 16654A006 16654A006
27 FOLLOWER, FOR PLUNGER 3 † 20161A001 17537A000
28 O-RING, FOR PLUNGER FOLLOWER NOT REQ NOT REQ
29 PLUNGER CAP (FLAT) 3 † 13046A026 06086A011
30 O-RING, FOLLOWER TO BACKUP RING 3 05876A022 05876A022
31 RING, BACKUP, FOR PLUNGER 3 20162A001 17535A000
32 STUD, PLUNGER 3 20163A000 17533A000
33 CYLINDER BODY 1 18791F000 18791F000
34 NUT, 1/2”-13 UNC, FOR STUD REF. 36 6 19109A097 19109A097
35 NUT, 1/2”-13 UNC, FOR STUD REF. 37 6 19109A097 19109A097
36 STUD, FOR VALVE CAP CLAMPS 6 05659A548 05659A548
37 STUD, FOR CYLINDER CAP CLAMPS 6 05659A548 05659A548
38 CLAMP, VALVE CAP 3 M01517A000 M01517A000
39 CLAMP, CYLINDER CAPS 3 M01517A000 M01517A000
40 VALVE CAP, DISCHARGE 3 17390A000 17390A000
41 O-RING, FOR VALVE CAPS 3 05876A064 05876A064
42 CYLINDER CAP, SUCTION 3 17391A000 17391A000
43 O-RING, FOR CYLINDER CAPS 3 05876A065 05876A065
44 SUCTION VALVE AND SEAT COMPLETE 3 18925A000K 18925A000K
45 DISCHARGE VALVE AND SEAT COMPLETE 3 18925A001K 18925A001K
46 LID, OVER PLUNGERS 1 M01820A000 M01820A000
47 MACHINE SCREW, FOR LID OVER PLUNGERS 2 148850001 148850001
WASHER, STEEL, FOR REF. 47 MACHINE SCREW 2 05030A020 05030A020
48 DRAIN PLUG, 3/8” PIPE 3 06136A000 06136A000
49 DRAIN PLUG, 1” PIPE 3 06206A000 06206A000
† The parts above are used on newer D35-8PP-2H pumps. It can be differentiated by the follower and
cup. Use 06737A031 if your cup is all rubber and no fabric. The 13046A026 contains fabric and
rubber. Use 20161A000 & 05876A040 O-ring if your follower has an O-ring groove on the outside
diameter. The 20161A001 follower has no groove and does not need an O-ring groove on the
outside diameter. This does not apply to D45-12PP.

23833A034 06/04/14
9
D35-12D-2H
INDUSTRIAL PUMP PARTS LIST
41
45
39
35
37
42
43
44
48
49
26
28
27 29 30
31
32
21 22 19 17 15 13 14 23
12
11
40 38 36 34
33 46 7
47
24 25
20
9
10
812 3 4 518
16
6
Valve Clamp 11818A000 (3 req) Valve Clamp 11828A000 (3 req)
Retainer
11817A000 (3 req)
Retainer
11827A000 (3 req)
Locknut 11904A001 (3 req) Locknut 11904A001 (3 req)
Valve Spring
18462A000 (3 req)
Valve Spring
11029A000 (3 req)
Valve 17552A001(3 req) Valve 17553A001(3 req) Valve Seat 06272A000 (3 req) Valve Seat 06271A000 (3 req)
SUCTION VALVE AND SEAT COMPLETE NO. 11902A001K DISCHARGE VALVE AND SEAT COMPLETE NO. 11903A001K

23833A034 06/04/14 10
D35-12D-2H
INDUSTRIAL PUMP PARTS LIST
Catalog Number of Industrial Pump (Helical Gears) D35-12D-2H
Item Description Qty. Eng. No.
1 GEAR CASE 1 04663E000
2 GASKET, FOR GEAR CASE LID 1 06222C000
3 CAP SCREW, 5/16"-18 UNC x 7/8" 8 19100A005
4 LID, FOR GEAR CASE 1 04664B000
5 VENT AND OIL FILTER PLUG 1 17388A000
6 OIL GAUGE WITH O-RING 1 17360A001
7 O-RING, FOR OIL GAUGE 1 000790031
8 PINION SHAFT WITH HELICAL PINION 1 19816B000
SHIM PLASTIC FOR PINION SHAFT .003" THICK 4 05231A074
SHIM PLASTIC FOR PINION SHAFT .015” THICK 4 05231A075
9 CONE, BEARING, PINION SHAFT 2 05674A013
CUP, BEARING, PINION SHAFT 2 05675A009
10 CAP, OPEN, PINION SHAFT 1 04563A001
CAP, CLOSED, PINION SHAFT 1 04741B000
OIL SEAL, OPEN END OF PINION SHAFT 1 05710A017
CAP SCREW, 3/8"-UNC x 1", BEARING CAPS 18 19101A009
SEAL WASHER, FOR 3/8" CAP SCREWS 18 14946A003
11 CRANKSHAFT WITH HELICAL GEAR 1 19817C000
12 CONE, BEARING, FOR CRANKSHAFT 2 05674A015
CUP, BEARING, FOR CRANKSHAFT 2 05675A011
CAP, BEARING, FOR CRANKSHAFT 2 18466B001
SHIM PLASTIC, 4-17/32" I.D., 6-1/32" O.D., .003" THICK 6 05068A017
SHIM PLASTIC, 4-17/32" I.D., 6-1/32" O.D., .015" THICK 5 05068A015
13 CROSSHEAD AND PISTON ROD 3 06361B002
14 LINK AND BUSHING AND CAP SCREWS 3 11651C002
15 BUSHING, FOR LINK 3 B01619A001
16 BEARING, HALVES REG., FOR LINK 3 11647A012K
17 WRIST PIN, CROSSHEAD TO LINK 3 M01525A001
18 CAP SCREW, FOR LINK 6 06106A040
WASHER, LOCK 6 05454A025
19 HOUSING, OIL SEAL 3 24959A001
OIL SEAL 6 22835A004
20 RETAINER, OIL SEAL HOUSING 3 24958A000
SCREW, ALLEN 6 06106A034
GASKET, SEAL HOUSING 3 05059A434
KIT FOR REF. NO. 19 & 20 1 24648A000
21 SPRING, FOR RETAINER FOR OIL SEAL WIPER 3 M01643A000
Catalog Number of Industrial Pump (Helical Gears) D35-12D-2H
Item Description Qty. Eng. No.
22 GASKET, VELLUMOID, FOR OIL SEAL ASSEMBLY 3 05059A058
23 DRAIN PLUG, MAGNETIC 3/4" 1 17481A002
24 CAP SCREW, 3/4"-10 UNC x 3"
CYLINDER BODY TO GEAR CASE
4 06106A038
LOCK WASHER, 3/4", FOR REF. 24 4 05454A003
25 CAP SCREW, 5/8"-11 UNC x 2"
CYLINDER BODY TO GEAR CASE
4 19105A008
26 CAP SCREW, PLUNGER TO PISTON ROD 3 16654A006
27 NUT 3 17512A000
28 WASHER LOCK 3 06107A013
29 CUP 3 06086A010
30 FOLLOWER 3 17511A000
31 WASHER 3 05030A128
32 STUD, PLUNGER 3 17545A000
33 CYLINDER BODY 1 18782F000
34 NUT, 1/2”-13 UNC, FOR STUD REF. 36 6 19109A097
35 NUT, 1/2”-13 UNC, FOR STUD REF. 37 6 19109A097
36 STUD, FOR VALVE CAP CLAMPS 6 05659A059
37 STUD, FOR CYLINDER CAP CLAMPS 6 05659A059
38 CLAMP, VALVE CAP 3 17438A000
39 CLAMP, CYLINDER CAPS 3 17438A000
40 VALVE CAP, DISCHARGE 3 17390A000
41 O-RING, FOR VALVE CAPS 3 05876A064
42 CYLINDER CAP, SUCTION 3 17391A000
43 O-RING, FOR CYLINDER CAPS 3 05876A065
44 SUCTION VALVE AND SEAT COMPLETE 3 11902A001K
45 DISCHARGE VALVE AND SEAT COMPLETE 3 11903A001K
46 LID, OVER PLUNGERS 1 M01820A000
47 MACHINE SCREW, FOR LID OVER PLUNGERS 2 148850001
WASHER, STEEL, FOR REF. 47 MACHINE SCREW 2 05030A020
48 DRAIN PLUG, 3/8" PIPE 3 06136A000
49 DRAIN PLUG, 1" PIPE 3 06206A000
50 CYLINDER LINER 3 18806A003
PLUG, 1-1/4” PIPE 1 05022A047
PLUG, 2” PIPE 2 05022A048
O-RING, FOR CYLINDER LINER 3 05876A085

23833A034 06/04/14
11
D35-12AVD-2H, D35-AVD-2HL,
D35-12AVD-CP, D35-12AVAB,
D35-12AVAB-CP & D35-12AVABL-CP
INDUSTRIAL PUMPS PARTS LIST
6
7
17
16
543
2
1
8
10
9
25
24
52
49
48
35
26
36
38
40
42
43
47
41
37
39
44
45
46
50
51
31
28
33 34
27
30
32
29 20 21 22 19 18 15 13 14 12
11 23
STYLE VALVE ASSEMBLY YZZ
SUCTION VALVE ASSEMBLY 11902A001K 18925A000K 18925A010K
DISCHARGE VALVE ASSEMBLY 11903A001K 18925A001K 18925A014K
SEAT MATERIAL 420F 420F 316
Item Description Qty. Eng. No. Eng. No. Eng. No.
ASEAT, VALVE SUCTION 3 06272A000 18835A000 18835A003
SEAT, VALVE DISCHARGE 3 06271A000 18835A001 18835A004
B VALVE, SUCTION 3 17552A001 18834A000 18834A000
VALVE, DISCHARGE 3 17553A001 18834A001 18834A001
C SPRING, SUCTION 3 18462A000 18462A000 18462A000
SPRING, DISCHARGE 3 11829A000 11829A000 11829A000
D RETAINER, SUCTION 3 11817A000 18833A000 18833A000
RETAINER, DISCHARGE 3 11827A000 18833A001 18833A001
E CLAMP FOR RETAINER, SUCTION 3 11818A000 — —
CLAMP FOR RETAINER, DISCHARGE 3 11828A000 — —
F LOCK NUT OR CAP SCREW 6 11904A001 18832A000 18832A001

23833A034 06/04/14 12
D35-12AVD-2H, D35-AVD-2HL,
D35-12AVD-CP, D35-12AVAB,
D35-12AVAB-CP & D35-12AVABL-CP
INDUSTRIAL PUMPS PARTS LIST
Item Description Qty. Eng. No.
1 GEAR CASE 1 04663E000
2 GASKET, FOR GEAR CASE LID 1 06222C000
3 CAP SCREW, 5/16"-18 UNC x 7/8" FOR GEAR CASE LID 8 19100A005
4 LID, FOR GEAR CASE 1 04664B000
5 VENT AND OIL FILTER PLUG 1 17388A000
6 OIL GAUGE WITH O-RING 1 17360A010K
8 PINION SHAFT WITH HELICAL PINION 1 19816B000
SHIM, PLASTIC FOR PINION SHAFT .003" THICK 4 05231A074
SHIM, PLASTIC FOR PINION SHAFT .015” THICK 4 05231A075
9 CONE, BEARING, PINION SHAFT 2 05674A013
CUP, BEARING, PINION SHAFT 2 05675A009
10 CAP, OPEN, PINION SHAFT 1 04563A001
CAP, CLOSED, PINION SHAFT 1 04741B000
OIL SEAL, OPEN END OF PINION SHAFT 1 05710A017
CAP SCREW, 3/8"-16 UNC x 1", BEARING CAPS 18 19101A009
SEAL WASHER, FOR 3/8" CAP SCREWS FOR BEARING CAPS 18 14946A003
11 CRANKSHAFT WITH HELICAL GEAR 1 19817C000
12 CONE, BEARING, FOR CRANKSHAFT 2 05674A015
CUP, BEARING, FOR CRANKSHAFT 2 05675A011
CAP, BEARING, FOR CRANKSHAFT 2 18466B001
SHIM PLASTIC, 4-17/32" I.D., 6-1/32" O.D., .003" THICK 6 05068A017
SHIM PLASTIC, 4-17/32" I.D., 6-1/32" O.D., .015" THICK 5 05068A015
13 CROSSHEAD AND PISTON ROD (SLIP FIT WRIST PIN) 3 N/A
CROSSHEAD AND PISTON ROD (PRESSED FIT WRIST PIN) 3 06361B002
14 LINK AND BUSHING AND CAP SCREWS 3 11651C002
15 BUSHING FOR LINK 3 B01619A000K
16 CAP SCREW FOR LINK 6 06106A040
WASHER, LOCK FOR CAP SCREWS FOR LINK 6 05454A025
WIRE FOR CAP SCREWS FOR LINK NO LONGER USED
USE LOCK WASHER 05454A025
N/A
17 BEARING, FOR LINK TO CRANKSHAFT 3 11647A012K
18 WRIST PIN, CROSSHEAD TO LINK FOR SLIP FIT CROSSHEAD 3 M01525A000
WRIST PIN, CROSSHEAD TO LINK FOR PRESSED FIT CROSSHEAD 3 M01525A001
19 OIL ASSEMBLY (NEW STYLE) PICTURE DEPICTS NEW STYLE 1 24648A000
20 HOUSING, OIL SEAL 3 24959A001
WIPER, OIL SEAL FOR PISTON ROD (NEW STYLE) 6 22835A004
RETAINER, OIL SEAL HOUSING 3 24958A000
SCREW, ALLEN, OIL SEAL HOUSING TO RETAINER 6 06106A034
GASKET, BETWEEN OIL SEAL HOUSING AND RETAINER 3 05059A434
21 SPRING, BETWEEN RETAINER & CYLINDER BODY 3 M01643A000
22 GASKET, BETWEEN RETAINER & GEAR CASE 3 05059A058
23 DRAIN PLUG, OIL, MAGNETIC 3/4" PIPE 1 17481A002
24 CAP SCREW, ALLEN HEAD 3/4"-10 UNC x 2-1/2" TO GEAR CASE 4 06106A038
LOCKWASHER, 3/4” FOR CAP SCREW, REF. 24 4 05454A003
25 CAP SCREW, 5/8”-11 UNC x 2” LG. CYLINDER BODY
TO GEAR CASE
4 19105A008
26 CAP SCREW, PLUNGER TO PISTON ROD 3 16654A006
27 FOLLOWER FOR PLUNGER 3 18923A000
28 LOCKWASHER FOR PLUNGER CAP SCREW 3 06107A013
29 “V” PACKING FOR PLUNGER 3 18922A000
Item Description Qty. Eng. No.
30 STUD FOR PLUNGERS 3 18924A000
STUD FOR PLUNGERS, 316 SST FOR AVAB-CP PUMP 3 18924A010
31 RETAINER, SPRING FOR PLUNGERS 3 18879A000
RETAINER, SPRING FOR PLUNGERS, 316 SST FOR AVAB-CP PUMPS 3 18879A003
32 WASHER, COPPER, STUD TO PISTON ROD 3 05030A128
33 SPRING FOR PLUNGERS 3 18920A000
34 RING, PRESSURE FOR PLUNGERS 3 18921A000
RING, PRESSURE FOR PLUNGERS, 316 SST FOR AVAB-CP PUMP 3 18921A002
35 CYLINDER BODY 1 18782F000
CYLINDER BODY, ALUM. BRONZE FOR AVAB & AVAB-CP PUMPS 1 18782F002
36 NUT, 1/2"-13 UNC FOR STUD 6 19109A097
37 NUT, 1/2"-13 UNC FOR STUD 6 19109A097
38 STUD, 1/2"-13 UNC x 3-5/16" FOR VALVE CAP CLAMPS 6 05659A059
39 STUD, 1/2"-13 UNC x 3-5/16" FOR CYLINDER CAP CLAMPS 3 05659A059
40 CLAMP FOR VALVE CAPS 3 17438A000
41 CLAMP FOR CYLINDER CAPS 3 17438A000
42 VALVE CAP, DISCHARGE 3 17390A000
VALVE CAP, DISCHARGE, ALUM. BRONZE FOR AVAB & AVAB-CP PUMPS 3 17390A002
43 O-RING, 2-3/8" I.D., 2-9/16" O.D., 3/32" DIA. 3 05876A064
44 CYLINDER CAP, SUCTION 3 17391A000
CYLINDER CAP, SUCTION, ALUM. BRONZE
FOR AVAB & AVAB-CP PUMPS
3 17391A002
45 O-RING, 2-7/8" I.D., 3-1/16" O.D., 3/32" DIA. 3 05876A065
46 SUCTION VALVE AND SEAT COMPLETE, VALVE Y 3 11902A001K
SUCTION VALVE AND SEAT COMPLETE, VALVE Z 3 18925A000K
SUCTION VALVE AND SEAT COMPLETE FOR AVAB-CP PUMP, VALVE Z 3 18925A010K
47 DISCHARGE VALVE AND SEAT COMPLETE, VALVE Y 3 11903A001K
DISCHARGE VALVE AND SEAT COMPLETE, VALVE Z 3 18925A001K
DISCHARGE VALVE AND SEAT COMPLETE
FOR AVAB-CP PUMP, VALVE Z
3 18925A014K
48 LID, OVER PLUNGERS 1 M01820A000
49 MACHINE SCREW, 1/4"-20 UNC x 1/2" FOR LID OVER PLUNGERS 2 148850001
WASHER, STEEL, 5/16" I.D., 3/4" O.D., 1/16" THICK
FOR MACHINE SCREW, REF. 47
2 05030A020
50 DRAIN PLUG, 3/8" 3 06136A000
DRAIN PLUG, 3/8" 316 SST FOR AVAB & AVAB-CP PUMPS 3 05022A062
51 DRAIN PLUG, 1" 3 06206A000
DRAIN PLUG, 1" ALUM. BRONZE FOR AVAB & AVAB-CP PUMPS 3 05022A064
52 CYLINDER LINER, 2" I.D. FOR ALL PUMPS 3 18806A003
O-RING FOR CYLINDER LINER 3 05876A085
PLUG, 1-1/4" FOR DISCHARGE 1 05022A041
PLUG, 1-1/4” FOR DISCHARGE ALUM. BRONZE
FOR AVAB & AVAB-CP PUMPS
1 05022A065
PLUG, 2" FOR SUCTION 2 05022A048
PLUG, 2" FOR SUCTION ALUM. BRONZE
FOR AVAB & AVAB-CP PUMPS
2 05022A066

23833A034 06/04/14
13
D50-12D-3H & D50-12AB
INDUSTRIAL PUMPS PARTS LIST
Item Description Qty. Eng. No.
1 O-RING 3 05876A064
2 VALVE CAP 3 17390A000
VALVE CAP FOR AB PUMP 3 17390A002
3 CLAMP 3 17438A000
4 STUD 6 05659A059
5 HEX NUT 6 19109A097
6SUCTION VALVE AND SEAT COMPLETE 3 11903A002K
7DISCHARGE VALVE AND SEAT COMPLETE 3 11903A001K
8 CAP SCREW 4 19105A008
9 PLUG 1/2" PIPE 3 B01053A000
10 CLAMP 3 17389B000
11 HEX NUT 6 19109A046
12 STUD 6 05659A0560
PLUG 1-1/4" PIPE 1 05022A041
PLUG 3" 2 03210A000
13 PLUG 1" PIPE 3 06206A000
14 0-RING 3 05876A066
15 CYLINDER CAP 3 17392A000
16 CAP SCREW 3 16654A006
NUT 3 17535A000
LOCK WASHER 3 06107A013
17 CUP, NEOPRENE & FABRIC 3 06086A011
18 FOLLOWER 3 17537A000
19 STUD 3 17533A000
WASHER 3 05030A128
20 CYLINDER LINER 3 M01512A004
O-RING FOR CYLINDER LINER 3 05876A095
21 MACHINE SCREW 2 148850001
WASHER 2 05030A020
22 CYLINDER LID 1 M01520A000
23 CYLINDER BODY 1 18639F000
CYLINDER BODY ( FOR AB PUMP) 1 18639F003
24 SPRING 3 M01643A000
25 HOUSING, OIL SEAL 3 24959A001
OIL SEAL 6 22835A004
26 RETAINER, OIL SEAL HOUSING 3 24958A000
SCREW, ALLEN 6 06106A034
Item Description Qty. Eng. No.
26 GASKET, SEAL HOUSING 3 05059A434
KIT FOR REF. NO. 25 & 26 1 24648A000
27 CROSSHEAD 3 06211B041
28 VENT PLUG 1 17388A000
29 SHAFT PINION 1 20164B020K
SPACER 1 20164B022A
CUP BEARING 2 05675A009
30 CONE BEARING 2 05674A013
SHIM FOR PINION SHAFT .003" THICK 4 05231A074
SHIM FOR PINION SHAFT .015" THICK 4 05231A075
CAP CLOSED 1 04741B001
OIL SEAL 1 05710A017
31 CAP OPEN 1 04563A001
WASHER, SEAL 18 14946A003
CAP SCREW 18 19101A009
CUP BEARING 2 05675A012
32 CONE, BEARING 2 05674A017
BEARING CAP 2 04624B002
O-RING FOR BEARING CAP 2 05876A098
SHIM, GREEN .015" 6 05068A018
SHIM, PINK .003" 6 05068A016
33 LID 1 04561B000
34 OIL GAUGE WITH O-RING 1 17360A011K
35 GASKET 3 05059A058
36 CAP SCREW 8 19100A005
37 LID GASKET 1 06201C000
38 GEAR CASE 1 04625E001K
39 PLUG, PIPE MAGNETIC 1 17481A002
40 BEARING TWO HALVES 3 15245A101K
41 LINK 3 17042C002
42 BUSHING 3 B01619A000K
43 CAP SCREW 6 19103A016
LOCK WASHER 6 05454A004
44 CRANK SHAFT WITH HELICAL GEAR 1 20355C022K
45 WRIST PIN 3 M01525A001
46 CAP SCREW 4 06106A038
LOCK WASHER 4 05454A003
1 2 3 4 5 23 22
21
20
46
8
30
31
29 38 37 36 33 28 43
40
34
44
32
39
41274245253524
26
18
19
16
17
13
9
6
14
15
12
11
10
7

23833A034 06/04/14 14
D50-12D-3H & D50-12AB
INDUSTRIAL PUMPS PARTS LIST
Valve Clamp 11828A000 (3 req)
Valve Clamp 11828A000 (3 req)
Retainer 11827A000 (3 req)
Retainer 11827A000 (3 req)
Locknut 11904A001 (3 req)
Locknut 11904A001 (3 req)
Valve Spring
11829A000 (3 req)
Valve Spring
18463A000 (3 req)
Valve 17553A001(3 req)
Valve 17553A001(3 req)
Valve Seat 06271A000 (3 req)
Valve Seat 06271A000 (3 req)
SUCTION VALVE AND SEAT COMPLETE NO. 11903A002K
DISCHARGE VALVE AND SEAT COMPLETE NO. 11903A001K

23833A034 06/04/14
15
D60-10D-3H, D60-10D-3HL & D60-10AB
INDUSTRIAL PUMPS PARTS LIST
Item Description Qty. Eng. No.
1 O-RING 3 05876A064
2 VALVE CAP 3 17390A000
VALVE CAP FOR AB PUMP 3 17390A002
3 CLAMP 3 M01517A000
4 STUD 6 05659A548
5 HEX NUT 6 19109A097
6SUCTION VALVE AND SEAT COMPLETE 3 11903A002K
7DISCHARGE VALVE AND SEAT COMPLETE 3 11903A001K
8 CAP SCREW 4 19105A008
9 PLUG 1/2" PIPE 3 B01053A000
10 CLAMP 3 M01516A000
11 HEX NUT 6 19109A046
12 STUD 6 05659A560
PLUG 1-1/4" PIPE 1 05022A041
PLUG 3" 2 03210A000
13 PLUG 1" PIPE 3 06206A000
VALVE LIFTERS 3 13015A002
14 0-RING 3 05876A066
15 CYLINDER CAP 3 17392A000
16 CAP SCREW 3 16654A006
NUT 3 18458A000
LOCK WASHER 3 06107A013
17 CUP, NEOPRENE & FABRIC 3 06086A012
18 FOLLOWER 3 17534A000
19 STUD 3 17533A000
WASHER 3 05030A128
20 CYLINDER LINER 3 M01512A003
O-RING FOR CYLINDER LINER 3 05876A095
21 MACHINE SCREW 2 148850001
WASHER 2 05030A020
22 CYLINDER LID 1 M01520A000
23 CYLINDER BODY (FOR ALL MODELS EXCEPT D60-10AB) 1 18639F000
CYLINDER BODY (FOR D60-10AB) 1 18639F003
24 SPRING 3 M01643A000
25 HOUSING, OIL SEAL 3 24959A001
OIL SEAL 6 22835A004
26 RETAINER, OIL SEAL HOUSING 3 24958A000
SCREW, ALLEN 6 06106A034
Item Description Qty. Eng. No.
26 GASKET, SEAL HOUSING 3 05059A434
KIT FOR REF. NO. 25 & 26 1 24648A000
27 CROSSHEAD 3 06211B041
PIPE CAP 1 05737A002
28 VENT PLUG 1 17995A000
29 SHAFT PINION 1 20164B020K
SPACER 1 20164B022A
CUP BEARING 2 05675A009
30 CONE BEARING 2 05674A013
SHIM FOR PINION SHAFT .003" THICK 4 05231A074
SHIM FOR PINION SHAFT .015" THICK 4 05231A075
CAP CLOSED 1 04741B001
OIL SEAL 1 05710A017
31 CAP OPEN 1 04563A001
WASHER, SEAL 18 14946A003
CAP SCREW 18 19101A009
CUP BEARING 2 05675A012
32 CONE, BEARING 2 05674A017
BEARING CAP 2 04624B002
O-RING FOR BEARING CAP 2 05876A098
SHIM, GREEN .015" 6 05068A018
SHIM, PINK .003" 6 05068A016
33 LID 1 04561B000
34 OIL GAUGE WITH O-RING 1 17360A011K
35 O-RING, 3/8" I.D. x 9/16" O.D. x 1/16" THICK 3 110-000110-201
36 CAP SCREW 8 19100A005
37 LID GASKET 1 06201C000
38 GEAR CASE 1 04625E001K
39 PLUG, PIPE MAGNETIC 1 17481A002
40 BEARING TWO HALVES 3 15245A101K
41 LINK 3 17042C002
42 BUSHING 3 B01619A000K
43 CAP SCREW 6 19103A016
LOCK WASHER 6 05454A004
44 CRANK SHAFT WITH HELICAL GEAR 1 20355C022
45 WRIST PIN 3 M01525A001
46 CAP SCREW 4 06106A038
LOCK WASHER 4 05454A003
1 2 3 4 5 23 22
21
20
46
8
30
31
29 38 37 36 33 28 43
40
34
35
44
32
39
4127
4245254724
26
17
19
16
18
13
9
6
14
15
12
11
10
7

23833A034 06/04/14 16
D60-10D-3H, D60-10LD-3H & D60-10AB
INDUSTRIAL PUMPS PARTS LIST
Valve Clamp 11828A000 (3 req)
Valve Clamp 11828A000 (3 req)
Retainer 11827A000 (3 req)
Retainer 11827A000 (3 req)
Locknut 11904A001 (3 req)
Locknut 11904A001 (3 req)
Valve Spring
11829A000 (3 req)
Valve Spring
18463A000 (3 req)
Valve 17553A001(3 req)
Valve 17553A001(3 req)
Valve Seat 06271A000 (3 req)
Valve Seat 06271A000 (3 req)
SUCTION VALVE AND SEAT COMPLETE NO. 11903A002K
DISCHARGE VALVE AND SEAT COMPLETE NO. 11903A001K

23833A034 06/04/14
17
THE PUMP MUST BE INSTALLED WITH A PRESSURE RELIEF VALVE IN DISCHARGE LINE
TROUBLESHOOTING
Pump fails to build pressure with discharge closed
Failure to hold pressure with discharge open
Pump is noisy
Pump gets hot
Pressure gauge shows abnormal fluctuation
Regulator chatter
POSSIBLE CAUSE OF PROBLEM
1. Pump not primed X
2. Valve closed in suction line X X
3. Suction line or sediment chamber clogged X X X
4. Air leak in suction line X X X
5. Pressure regulator valve badly worn or not properly adjusted X X
6. Pump plunger cups or valves badly worn X X X
7. Pump cylinder body cracked X X X
8. Holes in discs are too large X
9. Need suction surge arrester X
10. Water in crankcase X
11. Worn connecting link bearings X X
12. Lack of oil in crankcase X X
13. Foaming mixture X X X
14. Regulator plunger sticking X
15. Unloader stuffing box nut too tight X
16. Foreign matter under pump valve X X X
17. Discharge surge arrester inoperative X X
18. Loose plunger rod X
19. Improper preload of crankshaft bearings X X
1. Pump priming is usually not necessary when the
pump is installed correctly. However, there are certain
conditions which may make it necessary to prime the
pump to get the pumping action started. Priming will be
required when it is impossible for the plunger to displace
the air in the pump and replace it with water. This can be
caused by a high suction lift, the valves being stuck on
the seat or by valves sticking due to extreme corrosion.
A pump will not prime readily if someone has tampered
with the valve springs causing them to exert undue
pressure of the valve plates against the valve seats.
2. A gate valve is sometimes installed in the suction line
between a tank or pressure line and the pump sediment
chamber. It will shut off the supply source in order
to clean the sediment chamber or to perform pump
repairs. If this valve is partially or fully closed, it will
interfere with the flow of water to the pump suction. This
may cause severe knocking and vibration of the pump
because the water cannot flow into the cylinder cavities
fast enough.
3. A sediment chamber should be installed in the suction
line between the gate valve and the pump suction. The
strainers in the sediment chambers are sufficient to
allow a free flow of liquid to the pump. If the strainers
become severely clogged, they will completely stop the
flow of liquid to the pump.
4. Any plunger pump operating at a high pressure will
not perform properly nor quietly if a mixture of air and
water is allowed to enter the pump suction. A small air
leak in the suction line will cause the pump to knock
and vibrate excessively by allowing the pump to draw a
certain amount of water mixed with air on each stroke
of the plunger. A large air leak will cause the pump to
lose prime after which it cannot be reprimed until the air
leak is stopped. Air leaks may occur at the joints of the
suction line piping, at the gate valve in the suction line,
at the gasket sealing the cap on the sediment chamber,
by a crack in the suction wall of the cylinder body or by
air drawing past the plunger cups on the suction stroke
if the plunger cups are badly worn.
Explanation of the Service Chart

23833A034 06/04/14 18
5. If the pressure regulator unloading valve is worn, it
will allow too much of the pump capacity to be
bypassed and recirculated back to the tank. By
examining the flow from this valve with the discharge
turned on, it can be determined whether or not the valve
is worn. If a heavy flow continues when the discharge is
turned on, it is usually a good indication of a worn valve
and should be replaced.
6. Worn plunger cups, valves or valve seats will cause a
severe drop in pump capacity pressure. Worn plunger
cups are detected by water leakage past the cups and
immediately should be replaced. Water getting into
the pump crankcase will cause severe corrosion of the
bearings. Worn valves can only be detected by visual
examination of each valve assembly. Abrasive liquid will
cause wire cuts which begin as a very small groove, but
increase rapidly once the valve starts to leak through
this groove. If the valve plates are replaced as soon as
they start to show this cutting action, it will prevent the
valve seat from becoming cut in a similar manner.
7. Pump cylinder bodies withstand an extreme amount
of shock and pulsation while in operation, but if the
pump is allowed to freeze, by not being drained, the
freezing may crack the cylinder body walls in almost
any location. If the crack occurs on the suction valve
or cylinder portion of the body, it may allow a small
amount of air to enter on the suction stroke and cause
noisy operation or a decrease in pumping capacity. If
the crack develops in the walls between the cylinder
cavities or discharge valve cavity, it may allow the water
to flow from one cavity to the adjacent cavity and cause
uneven displacement.
8. The holes in the gun or nozzle discs are continually
subject to wear because of the high velocity of the
liquid through the holes. If the holes become worn, they
may allow a higher rate of discharge than the pump is
able to provide, then a drop in pressure will be noticed.
This can quickly be checked by reducing the number of
nozzles or guns while watching the amount of overflow
from the pressure regulator. If there is considerable
overflow, it is an indication that the regulator valve is
worn rather than the gun or nozzle disc.
9. Suction surge arresters should be installed on the
suction line of reciprocating pumps, 1-1/2" or 2" can
be used. A standing height of 12"-15" will be sufficient
with the top end closed by an ordinary pipe cap.
10. Water may accumulate in the pump crankcase from
two sources; leakage of the plunger cups or an
accumulation of condensation/moisture inside the
crankcase due to changes in weather or the repeated
heating and cooling of the pump. Pumps used
consistently, running for a considerable period of time
to heat the oil and other working parts, will not normally
accumulate water by condensation. Replace the
plunger cups as soon as they start to leak.
11. Worn connecting link bearings are caused by unusual or
adverse operating conditions and are seriously affected
by corrosion if water is present in the crankcase. They
will wear out from overheating if adequate oil is not
provided in the crankcase. It is recommended to drain,
clean and refill with new oil prior to any storage period.
Replace bearings as soon as any damage is discovered
to avoid possible damage to crankshaft.
12. Low oil in the crankcase can quickly cause failure of
the pump's power end and result in extensive repairs.
Oil level should be checked periodically during normal
operation and during all maintenance work.
13. A foaming mixture will sometimes have the same effect
as a small air leak in the suction line. This is because
various quantities of the foam are drawn through the
suction line into the pump disrupting the normal flow of
water.
14. Pressure regulators and unloading valves may become
sluggish in action due to the plunger sticking or fitting
too tightly in its cylinder. This may happen by an
accumulation of chemicals collecting in and around the
plunger or due to excessive corrosion of the plunger
parts. To check this condition, remove and clean the
plunger and cover the parts with a waterproof grease
before assembling.
15. The stuffing box nut on the unloading valve lifting post
should not be tightened to severely grip or bind the
packing on the post. Tighten this nut just enough to
prevent leakage and chatter. The pressure regulator and
unloading valves may chatter or vibrate excessively due
to an unstable operation from nozzling in the high or low
capacity range of the regulator or unloader. The range
should be at least 50% to 90% of pump capacity. With
unloader valves, nozzle capacity should be at least 20%
and not exceed 90% of pump capacity.
16. If foreign matter becomes lodged between the pump
valve and valve seat, a drastic drop in capacity and
considerable surge or pulsation will occur in the
discharge line. Examine each valve if this occurs.
17. When a pump is used for a long period of time, a
waterlogged discharge surge could cause pulsation
at the discharge. The suction should be opened into
the atmosphere to allow air to be drawn through the
pump to recharge the surge arrester. Do this with the
pressure release valve open so the pump operates at no
pressure.
18. Noisy pump operation can be caused by a loose
plunger rod in the crosshead. This noise usually has a
regular cadence timed with each stroke of the plunger.
When this occurs, always replace both the rod and the
crosshead.
19. Increased preload to the crankshaft bearings will reduce
bearing life, require more power and generate more
heat, while insufficient preload may cause a knock,
timed with the crankshaft rotation. Check for loose bolts
on the crankshaft end caps or adjust shims to obtain
proper bearing preload.

23833A034 06/04/14
19
24648A000 KIT
Field installation of these kits will require removal of
the fluid end to replace the existing retainer and seals.
On some fluid ends it may be necessary to hand grind
I.D. of fluid end to fit new kit. The same spring and
gasket is used to hold and seal the retainer.
The rod seal assembly contains two seals, and two
oil seals with lips facing the power end. The oil seal
can be replaced without taking the fluid end off by
removing the piston and the cylinder liner to allow
access to oil seal housing. Unscrew two Allen screws
and place into the other two tapped holes. Gradually
screw them in to push the oil seal housing off the
retainer. After assembling new seals in the oil seal
housing, an assembly thimble should be used on the
end of the crosshead rod for sliding oil seal housing
back into the retainer. Check gasket and replace if
damaged. The thimble should be machined from high
carbon steel and polished on the exterior to reduce
the possibility of seal lip damage. Place two Allen
screws into clearance holes and tighten snug.
ITEM DESCRIPTION QTY. ENG. NO
1 HOUSING, OIL SEAL 3 24959A001
2 OIL SEAL 6 22835A004
3 RETAINER, OIL SEAL HOUSING 3 24958A000
4SCREW, ALLEN 6 06106A034
5 GASKET, SEAL HOUSING 3 05059A434
6 GASKET 3 05059A058
OIL SEAL HOUSING ASSEMBLY
Hand Grind Here
RECOMMENDED THIMBLE
D SERIES CROSSHEAD SEALS
" DIA.
"R
"R ""
"
"
"
"
DIA.
DIA.

1101 MYERS PARKWAY
ASHLAND, OHIO, USA 44805
419-289-1144
WWW.FEMYERS.COM
Warranty Rev. 12/13
STANDARD LIMITED WARRANTY
CENTRIFUGAL & RECIPROCATING PUMPS
Pentair Myers® warrants its products against defects in material and workmanship for a period of 12 months from
the date of shipment from Pentair Myers or 18 months from the manufacturing date, whichever occurs first – provided
that such products are used in compliance with the requirements of the Pentair Myers catalog and technical manuals.
During the warranty period and subject to the conditions set forth, Pentair Myers, at its discretion, will repair or
replace to the original user, the parts that prove defective in materials and workmanship. Pentair Myers reserves the
right to change or improve its products or any portions thereof without being obligated to provide such a change or
improvement for prior sold and/or shipped units.
Seals, piston cups, packing, plungers, liners and valves used for handling clear, fresh, nonaerated water at a
temperature not exceeding 120ºF are warranted for ninety days from date of shipment. All other applications are
subject to a thirty day warranty. Accessories such as motors, engines and auxiliary equipment are warranted by
the respective manufacturer and are excluded in this standard warranty. Under no circumstance will Pentair Myers
be responsible for the cost of field labor, travel expenses, rented equipment, removal/reinstallation costs or freight
expenses to and from the factory or an authorized Pentair Myers service facility.
This limited warranty will not apply: (a) to defects or malfunctions resulting from failure to properly install, operate
or maintain the unit in accordance with the printed instructions provided; (b) to failures resulting from abuse, accident
or negligence; (c) to normal maintenance services and parts used in connection with such service; (d) to units that
are not installed in accordance with applicable local codes, ordinances and good trade practices; (e) if the unit is
moved from its original installation location; (f) if unit is used for purposes other than for what it is designed and
manufactured; (g) to any unit that has been repaired or altered by anyone other than Pentair Myers or an authorized
Pentair Myers service provider; (h) to any unit that has been repaired using non factory specified/OEM parts.
Warranty Exclusions: PENTAIR MYERS MAKES NO EXPRESS OR IMPLIED WARRANTIES THAT EXTEND BEYOND THE
DESCRIPTION ON THE FACE HEREOF. PENTAIR MYERS SPECIFICALLY DISCLAIMS THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR ANY PARTICULAR PURPOSE.
Liability Limitation: IN NO EVENT SHALL PENTAIR MYERS BE LIABLE OR RESPONSIBLE FOR CONSEQUENTIAL,
INCIDENTAL OR SPECIAL DAMAGES RESULTING FROM OR RELATED IN ANY MANNER TO ANY PENTAIR MYERS
PRODUCT OR PARTS THEREOF. PERSONAL INJURY AND/OR PROPERTY DAMAGE MAY RESULT FROM IMPROPER
INSTALLATION. PENTAIR MYERS DISCLAIMS ALL LIABILITY, INCLUDING LIABILITY UNDER THIS WARRANTY, FOR
IMPROPER INSTALLATION. PENTAIR MYERS RECOMMENDS INSTALLATION BY PROFESSIONALS.
Some states do not permit some or all of the above warranty limitations or the exclusion or limitation of incidental or
consequential damages and therefore such limitations may not apply to you. No warranties or representations at any
time made by any representatives of Pentair Myers shall vary or expand the provision hereof.
