OWNER’S MANUAL
Shallow Well Jet Pumps
© 2013 Pentair, Ltd. All Rights Reserved. SX960 (Rev. 03/21/13)
Exclusive distributor in the Kingdom
SAMNAN FOR TRADE AND MAINTENANCE
P.O. BOX 4784, TARIG BIN ZIAD STREET
RIYADH 11412, KINGDOM OF SAUDI ARABIA
PH: 4477777 FAX: 4475555
Important
For best possible performance and continuous, satisfactory
operation, read these instructions before installing your new pump.
Should service be required, this manual can be a valuable guide.
It should be kept near the installation for ready reference.
Record nameplate data from pump on blank nameplate inside this
manual for future reference.
USA
293 WRIGHT STREET, DELAVAN, WI 53115 WWW.STARITE.COM
PH: 2627285551
2400 0496
HN and SN Series

Safety 2
Important Safety Instructions
SAVE THESE INSTRUCTIONS - This manual contains
important instructions that should be followed during
installation, operation, and maintenance of the product.
Save this manual for future reference.
This is the safety alert symbol. When you see this
symbol on your pump or in this manual, look for one of
the following signal words and be alert to the potential
for personal injury!
indicates a hazard which, if not avoided, will
result in death or serious injury.
indicates a hazard which, if not avoided,
could result in death or serious injury.
indicates a hazard which, if not avoided,
could result in minor or moderate injury.
NOTICE addresses practices not related to
personalinjury.
The manufacturer cannot anticipate every possible
circumstance that might involve a hazard. The warnings
in this manual, and the tags and decals affixed to the unit
are, therefore, not all-inclusive. If you use a procedure
or operating technique that the manufacturer does not
specifically recommend, you must satisfy yourself that it
is safe for you and others. You must also make sure that
the procedure or operating technique that you choose
does not render the system unsafe.
To avoid risk of serious bodily injury and property
damage, read and follow all safety instructions in this
manual and on equipment carefully before installing this
pump. Keep safety labels in good condition; replace if
missing or damaged.
Electrical Safety
Risk of electric shock. Can shock, burn or
kill. All wiring should be done by a qualified electrician.
• Wiremotorforcorrectvoltage.See“Electrical”
section of this manual and motor nameplate.
• Groundmotorbeforeconnectingtopowersupply.
• MeetNationalElectricalCodeandlocalcodesfor
allwiring.
• Followwiringinstructionsinthismanualwhen
connecting motor to power lines.
General Safety
Risk of explosion. The pump body may
explode if used to boost pressure above the pressures
shown in Specifications. Do not use this pump with inlet
pressure greater than 70 psi (483 kPa). If not already in
the piping system, install a pressure relief valve in the
pump discharge line capable of passing the full pump
flow at maximum rated pressure. If local code requires
installation of a pressure relief valve capable of handling
the full pump flow at a pressure less than 100 psi
(689kPa), follow the code requirements.
Risk of fire or explosion. To avoid risk of
fire and explosion, Pump Water Only with this pump. Do
not pump salt water, flammable liquids or chemicals. Do
not use the pump near gas pilot lights or where chemical
or gas fumes are present. Use of an electric pump with
liquids other than water or in an atmosphere containing
chemical or gas fumes may ignite those liquids or
gases and cause injury or death due to an explosion
and/orfire.
Risk of burns. If water is trapped in the pump
during operation it may turn to steam. Trapped steam
canleadtoanexplosionandburns.Neverrunthepump
with the outlet closed or obstructed.
Risk of freezing. Do not allow pump, piping,
or any other system component containing water to
freeze.Freezingmaydamagesystem,leadingtoinjuryor
flooding. Allowing pump or system components to freeze
will void warranty.
Nottobeusedbypersons(includingchildren)
having diminished capacity or a lack of experience
unless they have been given supervision
orinstruction.
Children must be supervised to ensure that they do
not play with the appliance.
Only service agent or qualified person should
replace power cord to avoid injury.
A complete power disconnect switch must be
incorporated in the fixed wiring.
Pump approved liquids only with this pump.
Periodically inspect pump and system components.
Wear safety glasses at all times when working on pumps.
Keep work area clean, uncluttered and properly lighted;
store properly all unused tools and equipment.
Keep visitors at a safe distance from the work areas.
Makeworkshopschildproof;usepadlocksandmaster
switches; remove starter keys.

Warranty 3
Limited Warranty
STA-RITE®warrantstotheoriginalconsumerpurchaser(“Purchaser”or“You”)oftheproductslistedbelow,thattheywillbefree
from defects in material and workmanship for the Warranty Period shown below.
Product Warranty Period
Water Systems Products — jet pumps, small centrifugal pumps,
submersible pumps and related accessories
whichever occurs first:
12 months from date of original installation,
or 18 months from date of manufacture
Pro-Source™ Composite Tanks 5 years from date of original installation
Pro-Source™ Steel Pressure Tanks 5 years from date of original installation
Pro-Source™Epoxy-LinedTanks 3 years from date of original installation
Sump/Sewage/EffluentProducts 12 months from date of original installation, or
18 months from date of manufacture
Our warranty will not apply to any product that, in our sole judgement, has been subject to negligence, misapplication, improper
installation, or improper maintenance. Without limiting the foregoing, operating a three phase motor with single phase power
throughaphaseconverterwillvoidthewarranty.Notealsothatthreephasemotorsmustbeprotectedbythree-leg,ambient
compensated, extra-quick trip overload relays of the recommended size or the warranty is void.
Youronlyremedy,andSTA-RITE’sonlyduty,isthatSTA-RITErepairorreplacedefectiveproducts(atSTA-RITE’schoice).Youmust
pay all labor and shipping charges associated with this warranty and must request warranty service through the installing dealer
assoonasaproblemisdiscovered.NorequestforservicewillbeacceptedifreceivedaftertheWarrantyPeriodhasexpired.This
warranty is not transferable.
STA-RITESHALLNOTBELIABLEFORANYCONSEQUENTIAL,INCIDENTAL,ORCONTINGENTDAMAGESWHATSOEVER.
THEFOREGOINGWARRANTIESAREEXCLUSIVEANDINLIEUOFALLOTHEREXPRESSANDIMPLIEDWARRANTIES,
INCLUDINGBUTNOTLIMITEDTOTHEIMPLIEDWARRANTIESOFMERCHANTABILITYANDFITNESSFORAPARTICULAR
PURPOSE.THEFOREGOINGWARRANTIESSHALLNOTEXTENDBEYONDTHEDURATIONEXPRESSLYPROVIDEDHEREIN.
Some states do not allow the exclusion or limitation of incidental or consequential damages or limitations on the duration of an
implied warranty, so the above limitations or exclusions may not apply to You. This warranty gives You specific legal rights and
You may also have other rights which vary from state to state.
ThisLimitedWarrantyiseffectiveJune1,2011andreplacesallundatedwarrantiesandwarrantiesdatedbeforeJune1,2011.
STA-RITE INDUSTRIES
293 Wright Street • Delavan, WI U.S.A. 53115
Phone: [phone] • Fax: [phone] • www.sta-rite.com

Specifications • Installation 4
Replacing An Old Pump
Risk of electric shock. Can shock, burn or
kill. Disconnect power to pump before working on pump
or motor.
1. Drain and remove the old pump. Check the old pipe
for scale, lime, rust, etc., and replace it if necessary.
2. Installthepumpinthesystem.Makesurethatall
pipe joints in the suction pipe are air-tight as well
as water tight. If the suction pipe can suck air, the
pump will not be able to pull water from the well.
3. Adjust the pump mounting height so that the
plumbing connections do not put a strain on the
pump body. Support the pipe so that the pump body
does not take the weight of piping or fittings.
You have just completed the well plumbing for your
new shallow well jet pump. Please go to Discharge
Pipe and Tank Connections.
Well Point (Driven Point) Installation
1. AsshowninFigure1,drivethewellusing“drive
couplings”anda“drivecap”.“Drivefittings”are
threaded all the way through and allow the pipe
ends to butt against each other so that the well
driving force is carried by the pipe and not by the
threads. The ordinary fittings found in hardware
stores are not threaded all the way through the
fittingandcancollapseunderimpact.“Drive
fittings”arealsosmootherthanstandardplumbing
fittings, making ground penetration easier.
2. Mountthepumpasclosetothewellaspossible
3. Use the fewest possible fittings (especially elbows)
when connecting the pipe from the well point to
the pump suction port. The suction pipe should be
at least as large as the suction port on the pump
(include a check valve if your pump is not equipped
withone–seeFigure1).
Support the pipe so that there are no dips or sags in
thepipe,soitdoesn’tstrainthepumpbody,andso
that it slopes slightly upward from the well to the
pump (high spots can cause air pockets which can
air lock the pump).
You have just completed the suction piping for your new
shallow well jet pump. Please go to Discharge Pipe and
Tank Connections.
Figure 1 - Typical well point installation
2346 0512
To household water system
Suction pipe from well
Check valve
Drive coupling
Pump priming tee and plug
Priming tee
and plug
Drive point
below water
level
Drive point
Not to scale
Typical installation
Sealing Pipe Joints
UseonlyPTFEpipethreadsealanttapeorPTFE-based
joint compounds for making all threaded connections
to the pump itself. Do not use pipe joint compounds
on plastic pumps: they can react with the plastic in
pumpcomponents.Makesurethatallpipejointsin
the suction pipe are air tight as well as water tight. If
the suction pipe can suck air, the pump will not be
able to pull water from the well.
Table I – Specifications
Model HP KW Minimum Head,
Meters
Maximum Head,
Meters
Maximum Head,
Feet
Maximum
Working
Pressure, PSI
Maximum
Working
Pressure, BAR
Maximum Flow,
GPM@Ft. Head
Maximum Flow,
LPM@M Head
HND-SA 3/4 0.7
10
47 155 100 6.9
21@70 79@21
HNE-SA 1 0.9 28@70 106@21
HNF-SA 1-1/2 1.2
SNC-SA 1/2 0.5 42 160 150 10.2 9@70 34@21
SND-SA 3/4 0.7 44 162 14@70 53@21
MaximumWaterTemperature:140°F(60°C)
Motorisratedforcontinuousoperation.

Installation 5
Cased Well Installation,
2” or Larger Casing
1. Mountthepumpasclosetothewellaspossible.
2. Assemble the foot valve, strainer, and well pipe (see
Figure2).Makesurethatthefootvalveworksfreely.
3. Lowerthepipeintothewelluntilthestrainerisfive
feet above the bottom of the well. It should also be
atleast10feetbelowthewell’swaterlevelwhilethe
pump is running in order to prevent the pump from
sucking air. Install a sanitary well seal.
4. Install a priming tee, priming plug, and suction pipe
tothepump(seeFigure2).Connectthepipefrom
the well to the pump suction port, using the fewest
possible fittings – especially elbows – as fittings
increase friction in the pipe (however, include a foot
valve–seeFigure2).Thesuctionpipeshouldbeat
least as large as the suction port on the pump. Use
PTFEpipethreadsealanttapeoraPTFE-basedpipe
joint compound on threaded pipe joints. Support the
pipe so that there are no dips or sags in the pipe, so
itdoesn’tstrainthepumpbody,andsothatitslopes
slightly upward from the well to the pump (high
spots can cause air pockets which can air lock the
pump).
You have just completed the suction piping for your new
shallow well jet pump. Please go to Discharge Pipe and
Tank Connections.
Installation for Surface Water
1. The pump should be installed as close to the
water as possible, with the fewest possible fittings
(especially elbows) in the suction pipe. The suction
pipe should be at least as large as the suction port on
the pump.
2. Assemble a foot valve and suction pipe (see
Figure3).Makesurethatthefootvalveworksfreely.
UsePTFEpipethreadsealanttapeoraPTFE-based
pipe joint compound on threaded pipe joints. Protect
the foot valve assembly from fish, trash, etc, by
installingascreenaroundit(seeFigure3).
3. Lowerthepipeintothewateruntilthestraineris
five feet above the bottom. It should also be at least
10 feet below the water level in order to prevent the
pump from sucking air.
4. Install a priming tee, priming plug, and suction pipe
tothepump(seeFigure3).Supportthepipesothat
therearenodipsorsagsinthepipe,soitdoesn’t
strain the pump body, and so that it slopes slightly
upward from the well to the pump (high spots can
cause air pockets which can air lock the pump).
You have just completed the plumbing for your new
shallow well jet pump. Please go to Discharge Pipe and
Tank Connections.
2348 0512
Suction pipe from well
Check
valve
Screen
10’ min.
Pump priming tee and plug
Priming
tee and
plug
To household
water system
Foot valve
5-10’
Figure 3: Surface Water Installation
Not to scale
Typical installation
2347 0512
Suction pipe from well
Sanitary
well seal
Check
valve
Foot
valve
10’ min.
Pump priming tee and plug
Priming
tee and
plug
Well
casing
To household
water system
5-10’
Figure 2: Cased Well Installation
Not to scale
Typical installation

Pre-Charge Tank Connection
1. Install two tees in the pump discharge port (see
Figure4).Thepipesizemustbeatleastaslargeas
the discharge port.
2. Run a pipe or reinforced hose from one arm of the
first tee to the port on the pre-charged tank.
3. Connect the other end of the discharge tee to your
plumbing system.
4. Check the pre-charge of air in the tank with an
ordinary tire gauge. The pre-charge should be 2 PSI
lessthanthecut-insettingofthepump’spressure
switch. The pre-charge is measured when there is
no water pressure in the tank. Your new pump has
a 30/50 PSI switch, so adjust the tank pre-charge
pressure to 28 PSI.
Congratulations! You have just completed the tank
connection for your jet pump. Please go to Electrical.
Standard Tank Connection
1. Install one tee in the pump discharge port
(seeFigure5).
2. Run a pipe from the pump discharge port to the inlet
port of your tank. The pipe size must be at least as
large as the discharge port.
3. Removethe1/8”NPTpipeplugfromthepumpAir
VolumeControl(AVC)port(seeFigure5).Runtubing
fromthepump’sAVCport(seeFigure5)totheport
ontheAVCmountedonthetank.Seeinstructions
providedwithtankandAVCfordetails.AVCport
location will vary, depending on your pump model
(see Repair Parts).
Congratulations! You have just completed the tank
connection for your jet pump. Please go to Electrical.
Discharge Pipe and Tank Connections 6
2349 0512
Figure 4: Pre-charged Tank Connections
From well
Check
valve
Pump priming
tee and plug
Pressure switch
To household
water system
2350 0512
Figure 5: Standard Tank Connections
From well
Check
valve
Pump priming
tee and plug
Air volume
control
Air volume
control tube
Pressure switch
To household
water system
Not to scale
Typical installation

Pressure Booster System Installation
Risk of explosion. Install a relief valve as
shown capable of passing entire pump flow at 75 PSI.
Pump body may explode if internal pressure exceeds
75PSI.
Risk of explosion and scalding.Neverrun
pump against closed discharge. To do so can boil water
inside pump, causing hazardous pressure in unit, risk of
explosion and possibly scalding persons handling pump.
NOTICE The incoming flow rate must equal or exceed
the minimum pump flow requirement of 6 gallons per
minute or the pump will fail. As a rule, the pump will
not increase the flow rate in the system.
A low pressure safety cutoff switch is recommended to
shut off power to the pump in case of low discharge
pressure caused by plugged nozzle, interruption to the
incoming water supply, etc.
Forpressureswitchadjustmentinstructions,refertothe
values shown in Table II or to the label inside the cover
of the pressure switch.
Thesystemcanbelocatedindoorsoroutdoors.Make
sure that the site is level, solid, well drained, and
protected from the weather and from freezing.
1. Turn off city water to house.
2. Installpipeasshown(Figures6and7).Besure
to include unions and stop valves so that pressure
booster unit can be removed for service without
interrupting household water supply. A spring
loaded check valve ahead of the booster system
and a low pressure cutoff switch after it are
recommended (you may wish to replace the standard
pressure switch with a pressure switch that includes
a low pressure cutoff).
3. UsePTFEtapeonallpipingjointstopreventleaks.
Please go to Electrical for electrical hookup.
Installation 7
2887 0512
Figure 7
Check
valves
Union and gate valve
for service access
Union and
gate valve for
service access
Low
pressure
cutoff
switch
Relief valve
Tee
City water flow in
Pressure
gauge
Pressure
switch
To household
water system
Table II - Pressure switch setting for booster system
If Minimum Incoming
System Pressure Is:
Use Pressure Switch
Rated At: Set Tank Precharge at:
Below20PSI 20/40; set cut-in to
20 PSI 18 PSI
20-30 PSI 30/50; set cut-in to
30 PSI 28 PSI
30-40 PSI 40/60; set cut-in to
40 PSI 38 PSI
User-supplied Components:
LowPressureCutoffSwitch(1) CheckValves(2) GateValves(2)
ReliefValve(1) PressureGauge(1) Unions (3)
Elbow(1) Tees (2) Piping
2882 0512
Figure 6
Check
valves
Union and
gate valve for
service access
Union and
gate valve for
service access
Low pressure
cutoff switch
Relief valve
Tee
City water flow in
Pressure gauge
Pressure
switch
To household
water system
Not to scale
Typical installation

Electrical 8
Motor Switch Settings
NOTICE Single phase motors are dual voltage and are
factorysettoHIGHvoltsetting.Motorterminalboard
(located under the motor end cover) should look like that
showninFigure8.Usetheinstructionstosetyoursingle
phase motor to match power source.
Risk of electrical shock. Can shock, burn or
kill. Disconnect power before working on pump, motor,
pressureswitch,orwiring.Neverconnectamotorsetto
LOW(115/127)toa220Vpowersource.
To change single phase motor to use 127 V:
1. Turn off power
2. Remove the back motor cover.
3. Usea1/2”wrenchtoturnthevoltageselector
dial counterclockwise until 115 shows in the dial
opening,asshowninFigure9.
4. Reinstall the motor cover.
Risk of electric shock. Can shock, burn
or kill. Disconnect power to motor before working on
pumpormotor.Groundmotorbeforeconnectingto
powersupply.
• Groundmotorbeforeconnectingtoelectricalpower
supply.Failuretogroundmotorcancausesevereor
fatal electrical shock hazard.
• Donotgroundtoagassupplyline.
Risk of fire. Incorrect voltage can cause a fire
or seriously damage the motor and voids the warranty.
The supply voltage must be within ±10% of the motor
nameplate voltage.
Risk of electric shock. Can shock, burn,
or kill. Connect ground wire before connecting power
supply wires. Use the wire size (including the ground
wire) specified in the wiring chart, Table III. If possible,
connect the pump to a separate branch circuit with no
other appliances on it.
Table III - Recommended Fusing And Wiring Data
Model Motor
HP
Volts/ Hertx/
Phase
Max. Load
Amperes
Branch Fuse*
Rating Amps
Distance In Feet From Motor To Fuse/Breaker
0’ to 100’ 101’ to 200’ 201’ to 300’ 301’ to 400’ 401’ to 500’
Wire Size
HND-SA 3/4
127/220/60/1
12.4/6.2 20/15 12/14 10/14 8/14 6/12 6/12
HNE-SA 1 14.8/7.4 8/14 6/14 4/10
HNF-SA 1-1/2 19.9/9.95 25/15 10/14 6/12 4/10
SNC-SA 1/2 9.9/4.95 15/15 14/14 10/14 10/14 6/14 6/12
SND-SA 3/4 12.4/6.2 20/15 12/14 8/14 6/12
*AFusetronisrecommendedinsteadofafuseinanymotorcircuit.
Risk of electrical shock. Can shock, burn or kill. Disconnect power before working on pump, motor,
pressureswitch,orwiring.Neverapply220voltstoamotorsetforLOW(115/127).
Figure 9 - Voltage set to LOW (115/127)
Figure 8 - Voltage set to HIGH (220/230)
Voltage Select
Knob
Ground wire
connection Pressure switch
Power supply connections

Wiring
Risk of fire. Incorrect voltage can cause a fire
or seriously damage the motor and voids the warranty.
The supply voltage must be within ±10% of the motor
nameplate voltage.
NOTICEDual-voltagemotorsarefactorywiredforHIGH
(220/230) volts. If necessary, reconnect the motor for
LOW(115/127)volts,asshownpreviously.Donotalter
the wiring in single voltage motors.
Install, ground, wire, and maintain your pump in
compliancewiththeUnitedStatesNationalElectrical
Code(NEC)ortheCanadianElectricalCode(CEC),as
applicable, and with all local codes and ordinances
that apply. Consult your local building inspector for
codeinformation.
Connection Procedure:
1. Connectthegroundwirefirst,asshowninFigure8.
The ground wire must be a solid copper wire at least
as large as the power supply wires.
2. There must be a solid metal connection between the
pressure switch and the motor for motor grounding
protection. If the pressure switch is not connected
to the motor, connect the green ground screw in the
switch to the green ground screw under the motor
end cover. Use a solid copper wire at least as large
as the power supply wires.
3. Connect the ground wire to a grounded lead in a
service panel, to a metal underground water pipe, to
a metal well casing at least ten feet (3m) long, or to
a ground electrode provided by the power company
or the hydro authority.
4. Connect the power supply wires to the pressure
switch,asshowninFigure8.
Operation
Risk of explosion and scalding.Neverrun
pump against closed discharge. To do so can boil water
inside pump, causing hazardous pressure in unit, risk of
explosion and possibly scalding persons handling pump.
Risk of burns.Neverrunpumpdry.Running
pump without water may cause pump to overheat,
damaging seal and possibly causing burns to persons
handlingpump.Fillpumpwithwaterbeforestarting.
1. Remove the priming plug from the priming tee and
fillthepump(Figure10).Fillallpipingbetweenthe
pump and the well and make sure that all piping in
the well is full. If you have also installed a priming
tee in the suction piping, remove the plug from the
tee and fill the suction piping.
2. Replace all fill plugs.
3. Poweron!Startthepump.Ifyoudon’thavewater
after 2 or 3 minutes, stop the pump and remove the
fill plugs. Refill the pump and piping. You may have
to repeat this several times in order to get all the
trapped air out of the piping. A pump lifting water
25’maytakeaslongas15minutestoprime.
4. After the pump has built up pressure in the system
and shut off, check the pressure switch operation by
opening a faucet or two and running enough water
out to bleed off pressure until the pump starts. The
pump should start when pressure drops to 30 PSI and
stop when pressure reaches 50 PSI. Run the pump
through one or two complete cycles to verify correct
operation. This will also help clean the system of dirt
and scale dislodged during installation.
Nozzle Clean Out (Low Pressure)
Use an icepick or brad awl to clean out the nozzle –
3/16”maximumdiameter(seeFigure11).Besureyou
DONOTenlargetheholeinthenozzle.UsePTFE
pipethreadsealanttapeoraPTFE-basedpipejoint
compound on plug when reassembling to seal it.
Congratulations on a successful installation.
If you encounter problems with the pump, please refer
toTroubleshooting.
Electrical • Operation 9
1465 0497
Figure 11 - Use Icepick or Brad Awl to Clean Out Nozzle
2351 0512
Figure 10 - Prime system
Fill pump and piping
through priming tee

Troubleshooting 10
Symptom Possible Cause(s) Corrective Action
Motorwillnotrun.
Disconnect switch is off. Besureswitchison.
Fuseisblownorcircuitbreakertripped. Replace fuse or reset circuit breaker.
Starting switch is defective. DISCONNECTPOWER;Replacestartingswitch.
Wires at motor are loose, disconnected, or wired
incorrectly.
Refer to Electrical.DISCONNECTPOWER;checkandtightenallwiring.
Risk of electric shock. Can shock, burn or kill. Capacitor
voltage may be hazardous. To discharge capacitor, hold insulated handle
screwdriverBYTHEHANDLEandshortcapacitorterminalstogether.Donot
touch metal screwdriver blade or capacitor terminals. If in doubt, consult a
qualified electrician.
Motorrunshotandoverload
kicks off.
Motoriswiredincorrectly. Refer to instructions in Electrical.
Voltageistoolow. Check with power company. Install heavier wiring if wire size is too small
(SeeFusing/Wiringchart).
Pump cycles too frequently. See section below on too frequent cycling.
Motorrunsbutnowateris
delivered.*
Pump in new installation did not pick up prime
through: In new installation:
1. Improper priming. 1. Re-prime according to instructions.
2. Air leaks. 2.Checkallconnectionsonsuctionline,AVC,andejectorwithshaving
cream.
3.Leakingfootvalveorcheckvalve. 3. Replace foot valve or check valve.
Pump has lost prime through: In installation already in use:
1. Air leaks. 1. Check all connections on suction line and shaft seal.
2. Water level below suction pipe inlet. 2.Lowersuctionlineintowaterandre-prime.Ifrecedingwaterlevelinwell
exceeds25’(7.6m),adeepwellpumpisneeded.
Footvalveorstrainerisplugged. Clean foot valve or strainer.
Ejectororimpellerisplugged. Clean ejector or impeller.
Check valve or foot valve is stuck shut. Replace check valve or foot valve.
Pipes are frozen. Thawpipes.Burypipesbelowfrostline.Heatpitorpumphouse.
Footvalveand/orstrainerareburiedinsandor
mud.
Raise foot valve and/or strainer above bottom of water source. Clean foot
valve and strainer.
Water level is too low for shallow well setup to
deliver water. A deep well jet package may be needed (over 25 ft. to water) to deliver water.
Pump does not deliver water
to full capacity.
Water level in well is lower than estimated. Adeepwelljetwillbeneededifyourwellismorethan25’(7.6m)depthto
water.
Steel piping (if used) is corroded or limed, causing
excess friction. Replace with plastic pipe where possible, otherwise with new steel pipe.
Piping is too small in size. Use larger piping.
Packed well point. Backflushwellpointorsinknewpoint.
Pump delivers water but does
not shut off or pump cycles
too frequently.
Pressure switch is out of adjustment or contacts are
welded together. DISCONNECTPOWER;adjustorreplacepressureswitch.
Faucetshavebeenleftopen. Close faucets.
Venturi,nozzleorimpellerisclogged. Clean venturi, nozzle or impeller.
Standard pressure tank is waterlogged and has no
air cushion.
Draintanktoairvolumecontrolport.CheckAVCfordefects.Checkall
connections for air leaks.
Pipes leak. Check connections.
Footvalvesleak Replace foot valve.
Air charge too low in pre-charged tank.
DISCONNECTPOWERandopenfaucetsuntilallpressureisrelieved.Using
tire pressure gauge, check air pressure in tank at valve stem located on the
tank. If less than pressure switch cut-in setting (30-50 PSI), pump air into
tank from outside source until air pressure is 2 PSI less than cut-in setting
of switch. Check air valve for leaks (use shaving cream) and replace core if
necessary.
Air spurts from faucets.
Pump is picking up prime. When pump has picked up prime, it should pump solid water with no air.
Leakinsuctionsideofpump. Suction pipe is sucking air. Check joints for leaks with shaving cream.
Well is gaseous. Consult factory about installing a sleeve in the well.
Intermittent over-pumping of well (water drawn
down below foot valve). Lowerfootvalveifpossible,otherwiserestrictpumpdischarge.
* Stop pump; then check
prime before looking for
other causes. Unscrew
priming plug and see if
water is in priming hole).

Repair Parts 11
Ref. Part Description Qty. HND-SA 3/4 HP HNE-SA 1 HP HNF-SA 1-1/2 HP
1Motor 1A100DLL A100ELL A100FLL
2
Capscrew3/8-16x1-1/4”Lg.
HexHd. 4 U30-75ZP –
Capscrew3/8-16x1-1/2”Lg.
HexHd. 2 – U30-76ZP
3Water Slinger 1 17351-0009
4Seal Plate Assembly 1N3-1043P L3-10
5Gasket,SealPlate 1N20-35 C20-21
6Shaft Seal 1 U109-6A
7 Impeller 1 J105-42P J105-8PAN J105-22PA
8VoluteDiffuser 1L1-25P L1-23P
9Gasket,Diffuser 1N20-34
10 QuickConnect,1/4”NPT 1 U11-217P
11 PumpBodyAssembly* 1N176-43B N176-44 N176-44A
11A Venturi 1N32P-75 N32P-64 N32P-65
11B Nozzle 1N34P-21(#47) J34P-44(#54)
12 PipePlug,1/4”NPTHexHd. *U78-941ZPV(3)
13 Capscrew3/8-16x1-1/2”Lg.
HexHd. 2 – U30-76ZP
14 Base 1J4-9
15 Rubber Pad 1 C35-5
16 Tube,1/4”I.D.(lengthvaries) 1 U37-676P U37-672P U37-677P
17 QuickConnectElbow,
1/4”NPT 1 U11-218P
18 Pressure Switch 1 U217-1216
19 Locknut,1/2” 1 U36-112ZPP
20 Connector 1 L43-5C
•
DiffuserScrew,#8-32x3/4” 3 – U30-489SS
DiffuserWasher,#8Ext.Tooth 3 – U43-21SS
Pulsation Plug 1 – U17-1131
•Notillustrated.
*ModelHND-SArequires3pipeplugs;othermodelsrequire4pipeplugs.
HN Series
1
2
3
4
5
6
7
8
11
12
12
12
12
11A
9
10
11B
18
19 20
14
13
15
16
17
2763 0197
Nozzle
Cleanout
Port

Repair Parts 12
Ref. Part Description Qty. SNC-SA 1/2 HP SND-SA 3/4 HP
1Motor 1A100CLL A100DLL
#§2 Water Slinger 1 17351-0009
3Seal Plate 1N3-9
#§4 SealPlateGasket 1N20-35
#§5 Shaft Seal 1 U109-6A
#6 Impeller 1 J105-40P J105-42P
#7 Diffuser 1 L1-25P
#§8 DiffuserGasket 1N20-34
9QuickConnect-1/4”NPT 1 U11-217P
10 PumpBody-Assembly 1N176-43 N176-43B
11A Nozzle 1N34P-17(#43) N34P-21(#47)
11B Venturi 1N32P-66 N32P-75
12 PipePlug-1/4”NPTHexHd. 4U78-941ZPV
13 Base 1J4-9
14 HexCapscrew,3/8-16x1-1/4” 4 U30-75ZP
15 Rubber Pad 1 C35-5
16 Tube,1/4”I.D. 1 U37-676P
17 QuickConnectElbow,1/4”NPT 1 U11-218P
18 Pressure Switch 1 U217-1225 U217-1226
19 Locknut,1/2” 1 U36-112ZP
20 Connector 1 L43-5C
§IncludedinSealandGasketKit.
#IncludedinOverhaulKit.
SNC-SA 1/2 HP SND-SA 3/4 HP
§ SealandGasketOverhaulKit PP1550 PP1550
#Overhaul Kit PP1560 PP1561
1
2
3
4
5
6
7
8
11B
12
12
10
9
12
11A
14 13
17
18
19
15
20
16
2352 0396
12
SN Series

12 
1/2 SNC-SA3/4 SND-SA
11A100CLLA100DLL
2§#117351-0009
31N3-9
4§#1N20-35
5§#1U109-6A
#61J105-40PJ105-42P
#71L1-25P
8§#1N20-34
9NPT1/41U11-217P
101N176-43N176-43B
11A1N34P-17 (#43)N34P-21 (#47)
11B1N32P-66N32P-75
12NPT1/44U78-941ZPV
131J4-9
141-1/4×3/8-164U30-75ZP
151C3-55
16.I.D1/41U37-676P
17NPT1/41U11-218P
181U217-1225U217-1226
191/21U36-112ZP
201L43-5C


1/2 SNC-SA3/4 SND-SA
§PP1550PP1550
#PP1560PP1561
1
2
3
4
5
6
7
8
11B
12
12
10
9
12
11A
14 13
17
18
19
15
20
16
2352 0396
12
SN

3/4 HND-SA1HNE-SA1-1/2 HNF-SA
11A100DLLA100ELLA100FLL
2
1-1/4×3/8-16

4U30-75ZP–
1-1/2×3/8-16

2–U30-76ZP
3117351-0009
41N3-1043PL3-10
51N20-35C20-21
61U109-6A
71J105-42PJ105-8PANJ105-22PA
81L1-25PL1-23P
91N20-34
10NPT1/41U11-217P
111N176-43BN176-44N176-44A
11A1N32P-75N32P-64N32P-65
11B1N34P-21 (#47)J34P-44 (#54)
12
NPT1/4

*U78-941ZPV(3)
13
1-1/2×3/8-16

2–U30-76ZP
141J4-9
151C35-5
16I.D1/41U37-676PU37-672PU37-677P
17NPT1/41U11-218P
181U217-1216
191/21U36-112ZPP
201L43-5C

3/4×#8-323–U30-489SS
#83–U43-21SS
1–U17-1131

4HND-SA
HN
1
2
3
4
5
6
7
8
11
12
12
12
12
11A
9
10
11B
18
19 20
14
13
15
16
17
2763 0197
Nozzle
Cleanout
Port


11 



  


 




.
 


 

 11
2AVC 2
33
 11
2
252
7.6      

25



25
7.6 


 


  

AVC 
  



50-30



   







10 



±10%

 
230/220
127/115


CECNEC



8 1


 2




 3
3


 4
.8









.(10 1

  

 2
 3
3


1525
 4


30
50
  


3/16
11
PTFE
PTFE

 
. 
1465 0497
11
2351 0512
10

T

9


 
8



220127/115
127
 1
 2
1/2 3
115
.9
 4



 


 

±10%



.3


3










1000

200101

300201

400301

500401


HND-SA3/4
127/220/60/1
12.4/6.2
20/1512/14
10/148/14
6/12
6/12
HNE-SA114.8/7.4
8/14
6/14
4/10 HNF-SA1-1/219.9/9.9525/1510/146/124/10
SNC-SA1/29.9/4.9515/1514/14
10/14
10/146/14
6/12 SND-SA3/412.4/6.220/1512/148/146/12
Fusetron

.(127/115220
)115/1279
)220/2308



 

8



75
75




 
6





2


 1
76 2





PTFE 3

  
2887 0512
7












T







2






20

40/20
20

PSI 18
PSI 20-30
50/30
30

PSI 28
PSI 30-40
60/40
40

PSI 38

(1(2(2
(1(1(3
(1
6
2882 0512











T








7


.(4T 1

T 2

 3
 4

2

50/30
28

. 

T 1
.(5
 2

NPT1/8 3
AVC5AVC)
AVC 5
AVC 
.(  AVC

. 
2349 0512
4



T





2350 0512
5



T










6


2
 1
.(2 2

 3
10


T 4
2


2
PTFE
(PTFE





.  

 1


3 2
PTFE
(PTFE

.(3
 3
10  

T 4
3




.  
2348 0512




10

T


T





5-10’
3


2347 0512







10

T


T






5-10’
2


5
