Pentax R-2500DN Series User manual

TOTAL STATION
R-2500DNSERIES
R-2501DN,R-2502DN
R-2503DN,R-2505DN
INSTRUCTION MANUAL
Basic Procedures
TI Asahi Co.,Ltd.
International Sales Department
4-3-4 Ueno Iwatsuki-Ku,Saitama-Si
Saitama,339-0073 Japan
Tel, [phone]
Fax, [phone]
E-mail : [email protected]
PENTAX
Ⓡ

CONTENTS
General
CONTENTS
Exemption clause
Copyright
PRECAUTIONS REGARDING SAFETY
Warning
Usage Precautions
1
4
4
5
5
8
1. BASIC OPERATION
1.1 Names of parts
1.2 Standard equipment
1.3 Unpacking and packing
1.4 Removing and attaching the Battery
1.5 How to charge the Battery
1.6 Inserting and Removing of various SD cards
1.6.1 Inserting SD card
11
11
12
12
12
13
16
16
16
17
18
18
19
19
19
20
21
22
22
23
1.6.2 Removing SD card
1.6.3 Inserting SD card for camera data
1.6.4 Removing SD card for camera data
1.6.5 Suitability of SD card
1.7 Inserting and Removing of various USB cables
1.7.1 Connecting USB cable
1.7.2 Removing USB cable
1.7.3 Inserting USB cable for camera data
1.7.4 Removing USB cable for camera data
1.8 About recorded data
1.8.1 About measure data
1.8.2 About photography data
2. DISPLAY AND KEYBOARD
2.1 Display and keyboard
2.2 Operation key
2.3 Function Key
2.4 Alphanumeric input
2.5 Laser pointer
25
25
25
26
30
30
3. PREPARATION FOR SURVEYING
3.1 Centring and Levelling of the Instrument
3.2 Laser plummet
3.3 Levelling with circular vial
3.4 Levelling with the plate vial
3.5 Eyepiece adjustment
31
31
31
33
33
33
34
34
3.6 Target sighting
3.7 Attachment and detachment of tribrach
4. TURNING THE POWER ON
4.1 Turning the power on and off
4.2 Adjusting LCD contrast
36
36
36
1

4.3 Adjusting illumination brightness
4.4 Adjusting reticle illumination
37
37
5. ANGLE MEASUREMENT
5.1 Measuring an angle
38
38
38
39
39
40
41
5.2 Resetting the horizontal angle to 0
5.3 Holding the horizontal angle
5.4 Inputting an arbitrary horizontal angle
5.5 Displaying the % slope of the vertical angle
5.6 Changing the horizontal angle from clockwise to counter clockwise
6. DISTANCE MEASUREMENT
6.1 Target setting
6.2 Distance measurement
6.3 Quick Mode
42
42
43
44
7. CORRECTION MODE
45
45
46
47
48
7.1 Changing the target constant
7.2 Changing the temperature
7.3 Changing the atmospheric pressure
7.4 Changing the ppm value
8. INITIAL SETTING
8.1 Overview
49
49
49
49
49
50
50
50
8.2 Entering the mode for initial setting 1
8.3 Entering the mode for initial setting 2
8.4 Entering the mode for initial setting 3
8.5 Entering the mode for initial setting 4
8.6 Entering the mode for initial setting 5
8.7 Entering the mode for setting of data and time
8.8 Example of changing an initial setting content
(selection of atmospheric correction)
8.9 Initial setting 1
8.10 Initial setting 2
8.11 Initial setting 3
8.12 Initial setting 4
8.13 Initial setting 5
51
52
53
55
55
55
56
8.14 Setting of date and time
9. ACCESSING THE FUNCTIONS
9.1 Accessing by help key
9.2 Accessing by 007
57
57
57
10. DIGITAL CAMERA
10.1 Turning the camera On and Off
10.2 Taking pictures
59
59
60
60
61
62
10.2.1 Taking pictures and measuring distance at the same time
10.2.2
10.2.3
Taking pictures without measuring distance
Zooming
2

15. FCC RELATED 100
15.1 FCC Statement 100
15.2 FCC radiation exposure statement 100
10.3 Slide Show
10.4 Playing back images
63
64
64
64
65
66
66
67
67
68
69
75
77
10.4.1
10.4.2
Rotating images
Searching images
10.4.3
Deleting images
10.4.4
10.4.5
10.4.6
Adding PointCode to images
Displaying measured data
Zooming images
10.4.7
Moving images
10.5 Setup
10.6 Adjusting the camera settings
10.7 Adjusting Point Mark position
10.8 Correct Center Mode
11. DATA COLLECTOR
80
12. CHECKS AND ADJUSTMENTS
12.1 Plate level
12.2 Circular vial
80
80
81
82
83
84
84
84
85
86
12.3 Vertical reticle
12.4 Perpendicularity of line of sight to horizontal axis
12.5 Vertical 0 point error
12.6 Optical plummet
12.7 Offset constant
12.8 Beam axis and line of sight
12.9 The EDM beam axis
13. APPENDIX
13.1 Warning and Error Messages
13.2 Atmospheric correction
13.3 hPa and mmHg conversion table
13.4 Error when no atmospheric correction is made
13.5 Atmospheric refraction and earth curvature correction
13.6 Distance range
87
87
88
88
89
90
91
92
13.7 Specifications
14. NOTICE TO THE USER OF THIS PRODUCT
14.1 Specifications of Laser Radiation
96
96
14.2 The following labels are affixed to and must remain
attached to this laser product.
14.3 Caution to maintain the safety in compliance with the standard
14.4 Labelling
96
97
98
3

4
Before using this product, be sure that you have thoroughly read and understood this
instruction manual to ensure proper operation. After reading this manual, be sure to keep in a
convenient place for easy reference.
Exemption clause
1) TI Asahi Co.,Ltd. (TIA) shall not be liable for damage caused by Acts of God, fire, alteration or
servicing by unauthorized parties, accident, negligence, misuse, abnormal operating conditions.
2) TIA shall not be liable for changes or disappearance of data, loss of company profit or
interruption of company operation incurred by the use of this product or malfunction of it.
3) TIA shall not be liable for damage caused by usage not explained in the instruction manual.
4) TIA shall not be liable for damage to this product caused by other equipment connected to this
product.
Copyright © 2013 TI Asahi Co.,Ltd.
All Rights Reserved
TI Asahi Co.,Ltd. is a sole proprietor of the PowerTopoLite software.
The PowerTopoLite software and publication or parts thereof, may not be reproduced in any
form, by any method, for any purpose.
TI Asahi Co.,Ltd. makes no warranty, expressed or implied, including but not limited to any
implied warranties or merchantability or fitness for a particular purpose, regarding these
materials and makes such materials available.

5
PRECAUTIONS REGARDING SAFETYxxxx xxxxxxxxx
Safety precautions (Must be followed)
The following items are intended to prevent possible injury to the user or other people and/or
damage to the instrument before it occurs. These safety precautions are important to the safe
operation of this product and should be observed at all times.
Distinctive displays
The following displays are used to distinguish precautions by the degree of injury or damage
that may result if the precaution is ignored.
WARNING
Items indicated by this sign are precautions which, if ignored, would result in serious injury.
CAUTION
Items indicated by this sign are precautions which if ignored may result in injury or material
damage.
• Here “injury” refers to injuries such as cuts, burns or electric shock the treatment of which
will not likely require hospitalization or long-term attention.
• “Material damage” refers to damage to facilities, buildings, acquired data, etc.
Before using this product, be sure that you have thoroughly read and understood this
instruction manual to ensure proper operation. After reading this manual, be sure to keep it in
a convenient place for easy reference.
This instrument complies with the protection requirement for residential and commercial
areas. If this instrument is used close to industrial areas or transmitters, the equipment can be
influenced by electromagnetic fields.
Quick Reference Guide provided in your carrying case contains the following items:
1. Basic Procedures,
2. Power Topo Lite Operating Procedures
WARNING
Do not stare into the laser beam directly as this may result in damage to your eyes.
R-2500DN is a Class IIIa (3R) Laser product. Do not look into the laser radiation aperture
directly as this may result in damage to your eyes.
Never use the telescope to view intense light such as direct sunlight or sunlight reflected
through a prism as this may result in loss of sight.
Do not disassemble, modify or repair this product as there a risk of laser radiation.

6
Do not aim the laser beam at a person as it is harmful to the eyes and body. Receive the
examination treatment by the doctor when the eyesight or body trouble is doubted by any
chance.
•Electro-Magnetic Compatibility (EMC):
This instrument complies with the protection requirement for residential and commercial
areas. If this instrument is used close to industrial areas or transmitters, the equipment can
be influenced by electromagnetic fields.
• Do not use this product in a coal mine, in a location where there is coal dust, or near
flammable material as there is a risk of explosion.
• Do not disassemble, modify or repair this product as there is a risk of fire, electric shock
and burn injury. If you think the product requires repair, contact the retail outlet where you
purchased it or an authorized repair site.
•Do not charge the BP07 battery with any battery charger other than the BC05 battery
charger as it entails a risk of fire or burn injury from the battery bursting into flames due to
possible differences in voltage or polarity.
•Do not use a damaged electric cord plug or loose electric outlet when charging as there is a
risk of fire or electric shock.
• Do not charge the battery while covered by clothes or similar item as there is a risk of fire
if the clothes ignite.
• Do not use the battery or charger when wet as there is a risk of fire and burn injury due to
short-circuit.
• To prevent making short-circuit when removing the battery and charger from the case and
storing them, apply electrically resistant tape to the poles of the battery. Storing the battery
and charger as it may result in fire or burn injury due to short-circuit.
• Do not throw the battery into fire or expose it to heat as there is a risk of injury if it
explodes.
CAUTION
For your safety, perform the initial and periodical inspection as well as when the
instrument is fixed and adjusted.
When the laser beam enters eyes, an unexpected accident might be caused by blink of eyes.
Do not place the laser product at a height where its laser beam may hit the eyes of car
drivers and pedestrians.
Do not place the laser product at a place where its laser beam may hit a reflecting object
such as a mirror or a glass window. The refection beam of the laser is also harmful to the
human body.
When not performing measurement, cut off the power supply or shade the Objective lens
with Objective cap to prevent the instrument emitting the laser beam.
Keep the laser product in a place where persons who do not have the product knowledge,
such as children, can not touch it by mistake.
• Before disposing of the instrument, destroy its power supply mechanism to prevent it from
emitting the laser beam.
• Do not remove the handgrip without good reason. If it does come off, be sure to attach it
securely to the instrument with screws. If it is not fastened securely, the instrument may
fall when you use the handgrip, leading to possible injury.
• Do not short the poles of the battery or charger as there is a risk of injury or fire.

7
• Do not touch any fluid which may leak from the battery as there is a risk of chemical burn
injury or reaction.
• Do not insert or remove the electric plug with wet hands as there is a risk of electric shock.
• Do not use the case to stand on as it is slippery and unstable and may cause you to fall,
resulting in possible injury.
• Make sure the tripod itself and the instrument on the tripod are both installed securely as
insecure installation may cause the tripod to fall over or the instrument to drop, resulting in
possible injury.
• Do not carry the tripod with the metal shoe pointing toward another person as it may injure
him/her.
• The instrument contains a rechargeable battery and a battery charger.
• It may be illegal to dispose the battery at the end of its useful life.
• Check with your local solid waste officials for details for recycling.

8
Usage precautions xxxx xxxxxxxxx
Surveying instruments are high-precision instruments. In order to assure that the Electronic
Total Station R-2500DN product which you have purchased will provide long-lasting
maximum
performance, the precautions in this manual must be followed. Make sure to follow these
instructions and use this product properly at all times.
[Solar observation]
WARNING
Never view the sun directly using the telescope as this may result in loss of sight.
Never point the objective lens directly at the sun as this may damage internal components.
When using the instrument for solar observation, be sure to attach the specially designed solar
filter (MU64) to the objective lens.
[Laser beam]
Do not stare into the laser beam. R-2500DN is a Class IIIa (3R) Laser product.
[EDM axis]
The R-2500DN EDM is the red visible laser beam and the beam diameter is very small.
The beam is emitted from the objective centre. The EDM axis is designed to coincide with the
telescope sight axis (but both axes may deviate slightly because of intense temperature
changes and a long time lapse).
[Target constant]
Confirm the Target Constant of the instrument before measurement.
If a different constant is to be used, use the correct constant of the target. The constant is
stored in the instrument's memory when turned off.
[Reflectorless and reflector sheet]
• Reflectorless
The measurement range and accuracy of the Reflectorless mode are based on the condition
that laser beam is emitted perpendicular to the white side of a Kodak Gray Card.
The measurement range may be influenced by the shape of the target and its environment.
There is a possibility that the range may vary when the target does not satisfy the
conditions above at survey work.
• There is a possibility that correct distance measurement may not be performed by
dispersion or reduction of laser beam when the laser beam comes into the target from a
diagonal angle.
• There is a possibility that the instrument may not be able to correctly calculate out the
distance when receiving reflected laser beam from forth and back directions in case of
measuring the target on the road.
• There is a possibility that synthesized values are calculated and the distance may become
longer or shorter than the actual one when the operator measures the target of slope or
sphere or rugged shape.

9
• There is a possibility that the instrument may not be able to correctly calculate out the
distance by collecting the reflected laser beam from a man or a car that comes and goes in
front of the target.
• There is a possibility that the distance may not be correctly measured when measuring a
target in the direction where there is a reflecting object (mirror, stainless board and white
wall, etc.) or under too strong sun light.
• In a situation high accuracy may not be expected, perform the measurement by Reflector
sheet or Prism.
• When using reflector sheet, set the reflector sheet to have its surface be approx. vertical to
the aiming line. If it is positioned not to be approx. right angle, there is a possibility that
correct distance measurements may be impossible by dispersion or reduction of laser beam.
In the following environments, the distance might not be able to be measured.
There is a reflection things (mirror, stainless board and white wall, etc.) in the direction of the
target and under too strong sun light
[Battery & charger]
• Do not use any battery or battery charger that is not approved by Pentax as it entails a risk
of damaging the instrument.
• If water should happen to splash on the instrument or the battery, wipe it off immediately
and allow it to dry in a dry location. Do not put the instrument in the case until it is
completely dry as this may result in damage to the instrument.
• Turn off the power when removing the battery from the instrument as removing the battery
while the power is still on may result in damage to the instrument.
• The battery mark displayed on the instrument is only an estimation of remaining battery
power and is not completely accurate. Replace the battery quickly when it is about to run
out of power as the time a battery lasts on one full charge differs depending on conditions
of ambient temperature, and the measurement mode of the instrument.
• Confirm the battery level remaining before operating.
[About Clock Battery (lithium)]
• Clock battery is a backup battery used for calendar clock function.
• The battery can last about five years with regular use, but it is possible to be shorter
depending on usage.
• When the voltage of the clock battery is low or runs out, the date and time display
incorrectly and indication of "Clock-batt. voltage low" will appear.
• Please contact your the dealer which the purchased was mail for any exchange or return of
the clock battery.
[LD POINT, laser pointer]
When you make a correct direction using the “LD POINT”, aim the laser beam at the wall and
mark the centre and then confirm the discrepancy between the reticle centre and the marked
point beforehand.
[Storage and operating environment]
• To prevent making short-circuit when removing the battery and charger from the case and
storing them, apply electrically resistant tape to the poles of the battery. Storing the battery
and charger as it may result in fire or burn injury due to short-circuit.
• Avoid storing the instrument in places subject to extreme high, low or radically fluctuating
temperature. (Ambient temperature range during use: –20° C to +50° C)

10
• Distance measurements may take longer when atmospheric conditions are poor such as
when heat shimmer occurs. When storing the instrument, always put it in its case and avoid
storage in dusty location or location subject to vibration or extreme heat or humidity.
• Whenever there is a sharp temperature difference between the instrument’s storage and
usage environment, allow the instrument to adjust to the environment for an hour or more
before using it. Make sure to protect the instrument from the sun if the location is subject to
intense direct sunlight.
• The battery should be charged approximately once per month if the instrument is to be
stored for an extended period of time. The instrument should also be removed from its case
occasionally and aired out.
• In addition to these precautions, be sure to handle the instrument properly at all times
following the descriptions given in the various sections of this manual to assure safe and
proper measurements.
[Transporting and carrying the instrument]
• Be careful to protect this instrument from shock of impact and excessive vibration which
may result in damage during transportation and shipment.
• When transporting the instrument, always put it in the case and wrap shock absorbing
material around it and be sure it is handled as “FRAGILE”.
[Checks and repairs]
• Always check the instrument before beginning work and check that the instrument is
maintaining the proper level of precision. Pentax bears absolutely no responsibility for
damages due to survey results obtained from surveys conducted without an initial
instrument check.
• Never disassemble the instrument, battery or charger, even if you do detect an abnormality,
as there is a risk of fire or electric shock due to short-circuit. If you think the product
requires repair, contact the retail outlet where you purchased it or an authorized repair site.

11
1. BASIC OPERATION
1.1 Names of parts

Tophandle

Collimator

cameradisplay

Eyepiecering

Eyepiece

Laserindicator

Platevial

SD&USBcover

Displaypanel

Keyboard

Detachingknob

Levelingscrew
Focusring



Instrumentheightmark

Batterylatch


Batterypack

Telescopetangentscrew

Telescopeclampscrew

Clampscrew


Tangentscrew

Baseplate



DSCobjectivelens


DSCSD&USB


Objectivelens
Laserplummet

Bluetootnantenna






RS-232Cconnector



Circularvial

Detachabletype

12
1.2 Standard equipment
• Instrument
• Carrying case
• BP07 battery
• BC05 battery charger
• AC05 AC adapter
• Power supply cord
• Plumb bob
• Hexagonal wrench
• Adjusting pin
• Screwdriver
• Rain cover
• Quick Reference Guide
• CD-ROM (Basic operation & Special Functions manual)
• USB cable
• SD Card x 2
1.3 Unpacking and packing
[Unpacking the Instrument from the case]
①Set the case down gently with the lid facing upwards.
②Open the latches while pressing down on the lock (safety mechanism)
and open the lid of the case.
③Remove the instrument from the case.
[Packing the instrument in the case]
①Make sure the telescope is fairly levelled and lightly tighten the telescope clamp screw.
②Line up the housing marks (round yellow marks on the instrument) and tighten the upper
and lower clamp screws.
③With the housing marks are facing upward, set the instrument gently in the case without
forcing it. Close the lid to the case and secure the latches.

13
1.4 Removing and attaching the Battery
BatteryA（upside battery）
①The switch of a left-hand side side is made to slide upwards, and a cover is opened.
②It removes shifting a battery upwards.
BatteryB（lower battery）
①Rotate the knob above the battery pack counter clockwise.
②Lift up the battery pack and remove it from the instrument.
[Attaching the Battery]

14
BatteryA（upside battery）
①The switch of a left-hand side side is made to slide upwards, and a cover is opened.
②It attaches putting a battery in slanting down one.
BatteryB（lower battery）
①Place the channel on the bottom of the battery pack.
②Onto the protrusion of the instrument and push the battery pack down into place.
③Turn the knob clockwise.
1.5 How to charge the Battery
The R-2500DN comes with two lithium-ion rechargeable batteries with a typical operating time
between 8 to 10 hours.
Specifications
Battery Type: Lithium ION
Voltage: +6.2VDC to 8.4VDC
Capacity: 2500mAH
[Battery Charger]
AC Adapter
Input: 100-240VAC ~50/60Hz 1.7A
Output: 19.0VDC @ 3.16A
[Charging the battery]
BatteryChargingDescription
Battery Bay 1
Battery Bay 2
LED Status Indicator:
Battery Bay 2
Battery Bay 1
Power for Battery Charger
•Plug the AC cord to AC Adapter
•Plug in AC Adapter to Battery Charger
•Plug the AC wall battery charger into the wall socket and power LED turns ON
•Place your battery in charger bay correctly
•Wait until battery LED indicator turns GREEN for a full charge

15
LED Description
NONE Battery is not seated correctly
GREEN Battery is fully charged
RED Battery is being re-charged
Flashing RED Charge error or bad battery
Afullydischargedbatterywilltakeapproximately2hourstofullychargeand
maynotlighttheLEDstatusindicatorwhenfirstmounted.
[Battery Installation and Replacement]
RemovingthebatteryinusewillcausetheR‐2500DNtorestartorturnOFF.Usethe
batterystatusindicatorindatacollectionsoftwaretoconfirmwhichbatteryis“in
use”beforehot‐swappingbatteries.
•Press button to open battery door compartment
•Use the guide to slide the battery into the R-2500DN
•Swivel the battery door compartment up and push from the bottom until it latches completely
What you need to know
Can I remove one of the
batteries while the R-
2500DN is in use?
Before battery removal, use data collection software
to check which battery is in use. Remove the battery
not in use
How long does it take to
charge a battery? It takes 2 hours to fully charge a battery
How do I know if battery
is fully charged? Battery bay LED turns Green when fully charged
ContactaRecyclingCentertoensureproperdisposaloflithium‐ion
Batteries.

16
1.6 Inserting and Removing of various SD cards
1.6.1 Inserting SD card
①Open the SD & USB cover.
②Insert the SD card(The side with terminal should face the instrument and the cut-off
corner should be up.)
③Insert the SD card to the end. Be sure not to press the card too hard.
④After the SD card is inserted, close the SD & USB cover completely.

1.6.2 Removing SD card
①Open the SD & USB cover.
②Lightly press the SD card slot then release yourself from there.
③The SD card pops up.
④After the SD card is removed, close the SD & USB cover completely.
CAUTION
• Be sure to turn the power off before inserting and removing the SD card.
• Be sure to close/open the SD & USB cover and insert/remove the SD card indoors.
1.6.3 Inserting SD card for camera data
①Please open SD&USB cover. Cover is opened by pressing the white circle part in the
figure. SD&USB plug-in appears.
②Please insert SD card, of which the terminal side is underward, into SD plug-in with SD
notch on the right side.
③Please push SD card till it stops. In this time, please do not force to push it.
④After inserting SD card please be sure to close SD&USB plug-in cover.
SD&USBCover
Direction to insert the
SDcard
SDCard
Cut-offcorner
SlidetheSD&USBcoverto
lefttoopenthecover.

17

• Please be sure to do inserting SD card in state of camera OFF.
• Please be sure to start camera in the state that SD card was inserted.
• Before inserting SD card, please confirm that it is in the horizontal and vertical direction
locking state.
1.6.4 Removing SD card for camera data
①Please open SD&USB cover as same as inserting SD card.
②Please release after pushing the SD card a little in the plug direction.
③SD card will pop out slightly.
④After removing SD card, please do close SD&USB plug-in cover when using.


18
• Please do removing SD card in the state of camera OFF.
1.6.5 Suitability of SD card
• SD card and SD logo is registered trademark.
• The SD cards listed in the following table have been tested by us and it has been confirmed
that the SD cards can be used with the R-2500DN series.
This test has been done with only the Pentax R-2500DN series Total Station, but no other
Pentax Total Stations. When using with other Pentax Total Stations, please contact us to
confirm if it works properly.
Also it has been confirmed that the models mentioned in the following table can be used with
the R-2500DN series Total Station, but it has not been confirmed whether other brand SD
cards, not mentioned here, can be used with the R-2500DN series Total Station.
Please note that the test has been done by us and it is not meant that each SD card
manufacturer guarantees that the SD cards can be used with the Pentax R-2500DN series.
SD（micro SD）Card
Maker Model Capacity
Toshiba SD-C01GTR 1GB
Toshiba SD-MD001GA（microSD）1GB
Panasonic RP-SDM01GL1A 1GB
Be sure to use the adaptor when using a microSD.
• Regardless of the information here, be aware that all the SDHC cards can’t be used with
the R-2500DN Total Stations.
• Test item：The following has been done according to our test standard.
①When data is being sent (with connecting USB), it is necessary to be able to refer to
information in the SD card from PC and to operate the file.
②When writing / reading text, it is necessary to be able to read/write text file.
③Photography should be possible.
④Photographed image data should be viewed on PC and total station.
1.7 Inserting and Removing of various USB cables
1.7.1 Connecting USB cable
①Open the SD & USB cover.
②Insert the USB connector into the USB port in the right direction.

19
③Connect the cable with the computer, power of the station will be on. About the operation
procedure, please refer to “applied function 13-2 data transmission (USB connection)".
CAUTION
• Be sure to turn the power off before inserting/removing the USB cable.
• Be sure to open/close the SD & USB cover and insert/remove the USB cable indoors.
• For clients, the USB port of the station is not functional if the connect target has no host
function. Therefore, the USB memory, printer and card reader cannot be used.
1.7.2 Removing USB cable
①Close the window on the PC screen.
②Please do "safely removing hardware" from icon (the right figure) of the lower right on PC
screen.
③Finish the connecting.(About the means to finish connecting, please refer to “applied
function 16.2 data transmission”.)
④Unplug USB cable from the connector.
⑤After removing USB cable, please do close SD&USB plug-in cover when using.
CAUTION
• About the removing procedure of USB cable, please do follow this order.
• When removable disk does not start even if connection is done by the USB, Please enter
from My Computer and double-click the removable disk.
• If “safely removing hardware” is not done, it is possible to cause data loss. When the file
should have been taken was not taken in by any chance, please do again by the operation
procedure. And, before pressing Finish Key on the image of “USB is in communication” in
this station, please be sure to do “safely removing hardware”.
[Safety Remove Hardware] icon
