Perenio PECWS01 User manual

Installation and Operation Manual
for Perenio® PECWS01
Door & Window Sensor
August, 2019

Installation and Operation Manual for Perenio®
PECWS01 Door & Window Sensor
©Perenio IoT spol s r.o. All rights reserved Doc Version: 2.1.0
Page 3of 31
Introduction
The Door & Window Sensor is activated when the door or the window where it is
installed opens or closes. It can be used as a part of the Perenio Smart Building
Management System after being connected via the Control Gateway.
The present Manual contains a detailed description of the Door & Window Sensor, as
well as instructions for its installation and operation.
Copyrights
Copyright of ©Perenio IoT spol s r.o. All rights reserved.
The Perenio® trademark is owned by Perenio IoT spol s r.o. (hereinafter referred to
as the Perenio IoT). All other similar trademarks and names, as well as logos and other
symbols are the property of their respective owners*.
All materials under Perenio® tradename contained therein are protected in
accordance with international and local laws including Acts on copyrights and related
rights.
Any reproduction, copying, publication, as well as further distribution or public display
of materials contained in the present document (whether in full or in part) shall not be
allowed until an appropriate permission of the copyright owner is obtained. Any
unauthorized usage of materials contained therein may lead to civil liability and
criminal prosecution in accordance with applicable laws.
Any eventual mentioning of other company names and equipment in the present
document is made solely for the purpose of clarifying and describing the device
operation and shall not infringe on the third party’s intellectual property rights.
*ZIGBEE is the registered trademark of ZigBee Alliance; iOS is the registered trademark of CISCO TECHNOLOGY, INC.;
Android is the registered trademark of Google Inc.; Google Play is the trademark of Google Inc.; App Store is the
registered trademark of Apple Inc.; Linux is the registered trademark of Linus Torvalds.

Installation and Operation Manual for Perenio®
PECWS01 Door & Window Sensor
Doc Version: 2.1.0 ©Perenio IoT spol s r.o. All rights reserved
Page 4of 31
Responsibility and Technical Support
The present document is prepared in accordance with all necessary requirements and
contains detailed information on the device installation, configuration and control valid
as of the date of its issue.
Perenio IoT reserves the right to modify the device and make corrections or changes
to this document without prior notice of the User, and shall not be responsible for any
potential negative consequences which may arise from the use of an outdated version
of the document, as well as for any possible technical and/or typographical errors,
either omitted or accidental, or any related damage that may result from the document
transfer or the use of devices.
Perenio IoT shall make no guarantee with respect to any data contained herein
including but not limited to the device merchantability and fitness for a particular
purpose.
For any technical issues, please contact your local Perenio IoT representative or the
Tech Support Department at perenio.com.
The most common problems may be found in Section 7 of the present document and
at perenio.com where you can also download the latest version of this Installation
and Operation Manual.
Manufacturer:
Perenio IoT spol s r.o.
Na Dlouhem 79, Ricany –Jazlovice 251 01, Czech Republic
perenio.com

Installation and Operation Manual for Perenio®
PECWS01 Door & Window Sensor
©Perenio IoT spol s r.o. All rights reserved Doc Version: 2.1.0
Page 5of 31
Conformance to Standards
The device is CE certified and complies with requirements of the
following Directives of the European Union:
2014/53/EU Radio Equipment Directive (RED);
2004/30/EC Electromagnetic Compatibility Directive.
The device has passed all procedures of assessments established
in Technical Regulations of the Customs Union and conforms with
standards of the Customs Union
The device complies with the requirements of Restriction of the Use
of Certain Hazardous Substances in Electronic and Electrical
Equipment (2011/65/EU Directive)
The device complies with the requirements to the level of
electromagnetic interference by the Federal Communications
Commission
The national conformity mark of the Ukraine indicating that the
device meets requirements of all applicable technical regulations
The device and supplied batteries must not be disposed of as a
household waste in accordance with the Waste Electrical and
Electronic Equipment Directive (2002/96/EC)
For the purpose of protection of the environment and human
health, both the device and batteries must be disposed of in
accordance with approved instructions on safe disposal. For more
information on proper disposal, please contact your device supplier
or local authorities responsible for waste management
Details on available Certificates are specified in Section 6 of the present document.
For copies of Certificates and Reports, please visit a corresponding Section at
perenio.com.

Installation and Operation Manual for Perenio®
PECWS01 Door & Window Sensor
Doc Version: 2.1.0 ©Perenio IoT spol s r.o. All rights reserved
Page 6of 31
Table of Contents
Introduction .................................................................................................. 3
Copyrights..................................................................................................... 3
Responsibility and Technical Support.................................................................4
Conformance to Standards...............................................................................5
Table of Contents ........................................................................................... 6
1 General Description and Specifications............................................................8
1.1 General Purpose..................................................................................... 8
1.2 Technical Specification .......................................................................... 10
1.3 Scope of Delivery ................................................................................. 11
1.4 Packaging and Labelling ........................................................................ 12
1.5 Safe Operation Rules ............................................................................ 12
1.6 Standalone Operation of Perenio® Sensors .............................................. 13
2 Installation and Setup ................................................................................ 14
2.1 First Installation and Configuration ......................................................... 15
2.2 Changing the Room or Location for the Sensor ......................................... 20
2.3 History and Push-Notifications................................................................ 21
2.4 Battery Replacement ............................................................................ 21
3 Maintenance and Repair.............................................................................. 23
4 Warranty Obligations.................................................................................. 24
5 Storage, Transportation and Disposal of Devices ............................................ 27
6 Other Information...................................................................................... 28
7 Troubleshooting......................................................................................... 30
8 Glossary................................................................................................... 31
Figures and Tables
Figure 1 –Door & Window Sensor Exterior......................................................... 8
Figure 2 –Door & Window Sensor Components .................................................. 9
Figure 3 –Scope of Supply ............................................................................ 11
Figure 4 –Examples of Installation of the Door & Window Sensor........................ 14

Installation and Operation Manual for Perenio®
PECWS01 Door & Window Sensor
©Perenio IoT spol s r.o. All rights reserved Doc Version: 2.1.0
Page 7of 31
Figure 5 –Installation rules for the Sensor and the Magnet.................................16
Figure 6 –Add new device (Sensor) procedure..................................................19
Figure 8 –Positioning of the battery in the Door & Window Sensor.......................22
Table 1 –Basic Technical Specifications of the Door & Window Sensor..................10
Table 2 –Typical Errors and Troubleshooting Methods........................................30
Connection to the Perenio Smart Mobile App
A. SWITCHING ON AND INSTALLATION OF THE DOOR & WINDOW SENSOR ..........15
B. LOGIN TO THE EXISTING USER ACCOUNT ....................................................17
C. CONNECTION TO THE CONTROL GATEWAY ...................................................18

Installation and Operation Manual for Perenio®
PECWS01 Door & Window Sensor
Doc Version: 2.1.0 ©Perenio IoT spol s r.o. All rights reserved
Page 8of 31
1 General Description and Specifications
1.1 General Purpose
The PECWS01 Magnetic Sensor is a device that sends corresponding signals to the
Perenio® Control Gateway when the magnet is moved away from the main part of
the device to a distance of more than 20-30 mm or is returned back to initial state.
The PECWS01 Door & Window Sensor has a number of distinctive features, namely:
Timely notification of a window or door opening;
Connection distance –up to 40 meters;
iOS and Android smartphone compatibility;
Support of ZigBee Protocol;
Impact-resistant casing material;
Installation using 3M Tape or screws;
Ability to adjust the Sensor installation level;
Operation with one battery for up to 2 years;
Small size and stylish design.
Figure 1 –Door & Window Sensor Exterior

Installation and Operation Manual for Perenio®
PECWS01 Door & Window Sensor
©Perenio IoT spol s r.o. All rights reserved Doc Version: 2.1.0
Page 9of 31
Figure 2 –Door & Window Sensor Components
ATTENTION! All Products and the Mobile Application of the Company (including
any future software and hardware whether in-house or third-party developed) are
not intended for emergency responses and cannot be used as fire-extinguishing
equipment and/or for emergency intervention, including but not limited to fires,
flooding, gas leaks or explosions, burglary and theft, as well as natural disasters
and other force majeure circumstances leading to damage and/or losses incurred
by the Client or caused to their estates, personal property and/or other products,
devices, personal data and privacy.
Sensor
Magnet
Reset
Button
Mounting
Panel
Mounting
Holes
Place for
Battery

Installation and Operation Manual for Perenio®
PECWS01 Door & Window Sensor
Doc Version: 2.1.0 ©Perenio IoT spol s r.o. All rights reserved
Page 10 of 31
1.2 Technical Specification
Table 1 –Basic Technical Specifications of the Door & Window Sensor
Parameter
Value
Item Number
PECWS01
Microprocessor
NXP5169 (ZigBee IC)
Communication
Technology
ZigBee 3.0 (IEEE 802.15.4)
Operating Frequency
2.4 GHz
Connection Radius
up to 40 meters (open area)
ZigBee Antenna
Type: Built-in
Transmitting Power: 5.5 dBm
Receiver Sensitivity: -90 dBm
Antenna Gain: 1.5-1.8 dBi
Repeater: N/A
Distance between the
sensor and the magnet
(Actuation distance)
≥ 25±5 mm
Reset Button
Side panel of the Sensor
Standalone Operation
N/A
Power Type
CR2032 Battery (125 mAh, 3V), 1 pc.
Power Consumption
Standby Mode: not more than 0.0016 mA
Alarm Mode: not more than 19 mA
Battery Level
Yes (Available in the Mobile App)
Operating Temperature
0°C to +45°C
Operating Humidity
10% to 85% (non-condensing)
Storage Temperature
-10°C to +50°C
Storage Humidity
10% to 95% (non-condensing)
Installation
Edge of the door/window frame (for indoor installation
only)
Casing Material
ABS/PC

Installation and Operation Manual for Perenio®
PECWS01 Door & Window Sensor
©Perenio IoT spol s r.o. All rights reserved Doc Version: 2.1.0
Page 11 of 31
Parameter
Value
Color
White
Dimensions (L x W x H)
Sensor size: 45 mm x 30 mm x 19 mm
Magnet size: 45 mm x 15 mm x 19 mm
Weight
24.2g (32.4 g with accessories)
Warranty Period
24 months
Service Life
24 months
Certification
CE, EAC, RoHS, UA.TR
1.3 Scope of Delivery
The following items and accessories are supplied within the Perenio® PECWS01 Door
& Window Sensor package:
1. PECWS01 Door & Window Sensor with a magnet (1 set)
2. Battery (CR2032) (1 pc.)
3. Screws and dowels (1 set)
4. Reset pin (1 pc.)
5. 3M Tape (2 pcs.)
6. 3M Sponge (1 pc.)
7. Quick Start Guide (1 pc.)
8. Warranty Card (1 pc.)
9. Sticker (1 pc.)
1
2
3
4
5
6
Figure 3 –Scope of Supply*
*Images of accessories are provided for informational purposes only

Installation and Operation Manual for Perenio®
PECWS01 Door & Window Sensor
Doc Version: 2.1.0 ©Perenio IoT spol s r.o. All rights reserved
Page 12 of 31
1.4 Packaging and Labelling
The Perenio® PECWS01 Door & Window Sensor is supplied in an individual blister
package of 171 x 126 x 27 mm (L x W x H) containing the full name and marking of
the device, the list of accessories provided and basic technical specifications thereof,
as well as the date of manufacture and information about the Manufacturer of devices.
Weights of the blister package are as follows:
Net weight: 33 g;
Gross weight: 60 g.
1.5 Safe Operation Rules
For the proper and safe operation of Perenio® PECWS01 Door & Window Sensor,
follow the instructions and safety procedures described in the present Manual. The
Manufacturer shall not be liable for any damage caused as a result of improper
operation of devices.
Safe Operation Conditions
1. The device shall be installed indoors only.
2. The User must follow rules for installation and positioning of the Sensor and
the Magnet relative to each other as specified in Section 2 of this Manual.
3. The Users shall observe storage/transportation conditions, as well as the
operating temperature mode of the device as declared by the Manufacturer.
4. The User shall not install the device in the area with high humidity and high
content of dust.
5. The User must not disassemble or attempt to repair the device on their own.
6. The User must not drop, throw or bend the device.
7. In order to avoid personal injury, it shall not be allowed to use the cracked or
in any other way damaged device.
8. Use dry cloth or cloth soaked in a small amount of water for cleaning (don’t
use harsh chemicals/cleaning agents). The device must be powered off before
cleaning.
9. Children shall not be allowed to use the device unsupervised and/or play with it.

Installation and Operation Manual for Perenio®
PECWS01 Door & Window Sensor
©Perenio IoT spol s r.o. All rights reserved Doc Version: 2.1.0
Page 13 of 31
1.6 Standalone Operation of Perenio® Sensors
The Control Gateway in not necessarily required for all Perenio® Sensors in order to
alert Users on potentially dangerous situations.
So, the Door & Window Sensor cannot be used as a standalone device, i.e. when the
door or window opening is detected, it will not give any sound signal. Therefore, its
operation is arranged by sending notifications to the smartphone. However, to run
active scenarios, the User must have an installed Perenio Smart Building
Management System Mobile App and an activated Control Gateway, as well as unite
the above devices in a system.

Installation and Operation Manual for Perenio®
PECWS01 Door & Window Sensor
Doc Version: 2.1.0 ©Perenio IoT spol s r.o. All rights reserved
Page 14 of 31
2 Installation and Setup
Before installation, the User shall select one of the following possible locations and
mounting modes for the device:
On a horizontal surface (box, trunk, cellar door, etc.);
On a vertical surface (door or window frame, etc.);
Using 3M mounting tape or screws.
Also, make sure that the selected location meets the following requirements:
Absence of metal surface in the installation site of the Sensor;
Ability to install the Sensor and the Magnet coaxially (with/without the 3M
Sponge);
Flat and stable surface in the installation site of the Sensor.
NOTE. It is not recommended to install the device in areas with a high level of
noise and a high-frequency interference. Reinforced concrete floors may reduce
the distance of wireless signal transmission. It is recommended to install the Door
& Window Sensor at a minimum distance from the Control Gateway.
Figures below show possible installation locations for the Sensor:
Figure 4 –Examples of Installation of the Door & Window Sensor
* Images of accessories are provided for informational purposes only
For installation of the Door & Window Sensor using 3M tape, it is necessary to prepare
the surface as follows:
1. Wipe the surface of the Sensor to which the 3M tape will be attached with alcohol
and wait until it is dry.
2. Attach the 3M tape to the Sensor surface.
3. Make sure that the place of installation is smooth and free from dust, dirt, etc.

Installation and Operation Manual for Perenio®
PECWS01 Door & Window Sensor
©Perenio IoT spol s r.o. All rights reserved Doc Version: 2.1.0
Page 15 of 31
4. Wipe the surface to which the 3M tape will be attached with alcohol and wait
until it is dry.
5. Attach the device in the place of installation using the 3M tape.
The entire process of setting-up the Sensor can be divided into several key stages:
Logging in to the User Account of the Perenio Smart Mobile App;
Checking for the availability of the CG connected to the mains and the Internet;
Connection of the Sensor to the Control Gateway.
2.1 First Installation and Configuration
In order to connect the Door & Window Sensor to the Control Gateway through the
Perenio Smart Mobile App, it is necessary to perform the following steps:
1. Unpack the Sensor and switch it on (See par. Abelow).
2. Login in to the Perenio Smart Building Management System User Account
(See par. Bbelow).
3. Connect the Sensor to the Control Gateway (See par. Cbelow).
4. Enter the desired Sensor name and select the Room of installation.
5. Install the Sensor in the selected room.
A. SWITCHING ON AND INSTALLATION OF THE DOOR & WINDOW SENSOR
To install the Perenio® PECWS01 Door & Window Sensor, follow steps below:
1. Unpack the device.
2. Choose a suitable installation area for the Sensor and the Magnet (window
frame, door leaf, etc.) as follows:
a. Attach the Sensor on the door or window frame using 3M tape (See
Figure 5-a). You can also mount the Sensor using the screw.
b. Attach the Magnet to the door or window frame at the same level as the
Sensor.
ATTENTION! It is required to install the Sensor and the Magnet in such a way
that concave parts of their bodies are next to each other (See Figure 5-a below).

Installation and Operation Manual for Perenio®
PECWS01 Door & Window Sensor
Doc Version: 2.1.0 ©Perenio IoT spol s r.o. All rights reserved
Page 16 of 31
5-a –Correct positioning
(orientation)
5-b - Incorrect positioning
(orientation)
5-c - Correct positioning
(aligning)
5-d - Incorrect positioning
(aligning)
5-e - Correct positioning
(distance)
5-f - Incorrect positioning
(distance)
Figure 5 –Installation rules for the Sensor and the Magnet
NOTE. The Sensor and the Magnet shall be mounted coaxially so that in the closed
position of the door or the window the Magnet is at a distance of no more than
2 cm from the Sensor.
Concave parts
are next to
each other
Concave parts
are apart
> 2 cm

Installation and Operation Manual for Perenio®
PECWS01 Door & Window Sensor
©Perenio IoT spol s r.o. All rights reserved Doc Version: 2.1.0
Page 17 of 31
NOTE. The Sensor may be installed using the screw (supplied).
To align the position of the Sensor and the Magnet (when the door frame is thicker
than the door leaf), the User may use the 3M Sponge supplied with the device.
To clean the Sensor, use a soft cloth with a small amount of water or alcohol.
Cleaning can only be performed after switching off the Sensor.
3. Switch on the Door & Window Sensor by removing the battery isolation film.
4. Install the Sensor onto the removable cover in the selected location.
NOTE. If the LED starts flashing slowly after removal of the battery isolation film,
you can immediately begin connecting it to the Control Gateway skipping Step d
of par. C. CONNECTION TO THE CONTROL GATEWAY, i.e. performing the reset.
After the above Steps 1-4 are successfully completed, the Door & Window Sensor is
considered to be installed and ready for operation.
B. LOGIN TO THE EXISTING USER ACCOUNT
a. Enter your e-mail address and password in the login
screen.
b. Click on the LOG IN button.
NOTE. If the password was lost, the User can restore it by
clicking on a corresponding link on the screen.
To restore a forgotten password, use the e-mail address
linked to your User Account, to which instructions on
changing the password will be sent.

Installation and Operation Manual for Perenio®
PECWS01 Door & Window Sensor
Doc Version: 2.1.0 ©Perenio IoT spol s r.o. All rights reserved
Page 18 of 31
C. CONNECTION TO THE CONTROL GATEWAY
a. Click on the “+” icon in the upper right corner of the
Devices tab, select “Add new device” and then the
“Door & Window Sensor” device in the list;
b. Select the Control Gateway to which the Sensor shall
be connected (This screen will be displayed, only if
there are several Control Gateways activated in the
User Account).
NOTE. The Control Gateway must be connected to the
mains and the Internet, as well as activated in the Perenio
Smart App.
c. Start searching for Sensors;
d. If the LED flashes slowly after the first power on of
the device, proceed to the Step e, otherwise press
and hold the reset button as shown in the picture
above until the LED Indicator starts blinking.
NOTE. Several sensors may be connected to the Control
Gateway at once.
e. After successful connection, enter the Sensor’s name
and select the Room.
С.1. CONNECTION ERRORS
The connection failure of the device may occur due to one
of the following reasons:
a. The device is switched off or at a too long distance from
the Control Gateway (4.5 meters);
b. The Control Gateway is offline;
c. The LED Indicator was blinking before start of the
sensor connection (You should remove the sensor
battery and insert it back into the casing).
NOTE. To eliminate connection failures, follow instructions
specified on corresponding screens of the smartphone.

Installation and Operation Manual for Perenio®
PECWS01 Door & Window Sensor
©Perenio IoT spol s r.o. All rights reserved Doc Version: 2.1.0
Page 19 of 31
The entire process of the Sensor connection in the Mobile App is shown below.
1
2
3
4
5
6
7
8
9
10
11
Figure 6 –Add new device (Sensor) procedure

Installation and Operation Manual for Perenio®
PECWS01 Door & Window Sensor
Doc Version: 2.1.0 ©Perenio IoT spol s r.o. All rights reserved
Page 20 of 31
2.2 Changing the Room or Location for the Sensor
When using the Sensor, it may be necessary to change its installation area. The
following options are possible:
1. Change the room/location (The CG remains the same) as follows:
a. Demount the Sensor and move it to another room;
b. Make sure that the Sensor is at an allowable distance from the Control
Gateway;
c. Install the Sensor in a new room (Use a new 3M tape, if required);
d. Change the Room in Sensor settings in the User Account.
2. Change the room/location (Connection to another CG is required) as follows:
a. Sign in to the Perenio Smart app and select the Location where the Sensor
is activated;
b. In the ‘Devices’tab, select the required Sensor from the list and click on
the icon (Settings);
c. In the pop-up window, choose ‘Disconnect device’;
d. Demount the Sensor and move it to another room/building;
e. Make sure that the Sensor is at an allowable distance from the Control
Gateway;
f. In the User Account, select the Location where you want to move the
Sensor;
g. Initiate the Sensor search by the Control Gateway through the Perenio
Smart application according to par. C. ‘CONNECTION TO THE CONTROL
GATEWAY’;
h. Install the Sensor in a new room (Use a new 3M tape, if required).
NOTE. The User can manually disconnect the Sensor from the Control Gateway.
To do this, press and hold the Reset button on the Sensor until the LED flashes
(It usually takes no more than 5 seconds).
To check that the Sensor was successfully disconnected, you should update the
list in the ‘Devices’tab (Pull the screen down until the progress icon appears and
the data is updated). If the sensor is disconnected, it will disappear from the list
of connected devices.
