PERFECTPRO SOLOWORKER User manual

SOLOWORKER
Operating instruction
Mode d’emploi
Gebruiksaanwijzing
Bedienungsanleitung
Bruksanvisning
GB
F
NL
D
N
3A81YP6L0000A

1
GB
WARNING!
WARRANTY BECOMES VOID ONCE THE DEVICE
CABINET HAS BEEN OPENED OR ANY MODIFICATIONS
OR ALTERATIONS TO THE ORIGINAL DEVICE HAVE
BEEN MADE

2
Important safety instructions
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
ampliers) that produce heat.
Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If
the provided plug does not t into your outlet. Consult an
electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
Only use attachments/accessories specified by the
manufacturer.
Use only with the cart, stand, tripod, bracket, or table
specied by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
Unplug this apparatus during lightning storms or when
unused for long periods of time.

3
GB
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged. liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally,
or has been dropped.
To Reduce the Risk of Fire or Electric Shock, Do not
Expose This Appliance To Rain or Moisture.
The Shock Hazard Marking and Associated Graphical
Symbol is provided on the rear of unit.
Excessive sound pressure on ear-and headphones could
impair the hearing ability. Higher setting that idle on the
equalizer leads to higher signal voltages on the output
for ear and headphones.
The power plug should be close to the radio, and easy to
be approached that during the emergency, to disconnect
the power from the radio, just unplug the power plug from
the AC power slot.
Where the MAINS plug or an appliance coupler is used
as the disconnect device, the disconnected device shall
remain readily operable.
This apparatus is provided with protection against
splashing water (IP64).
Use only the AC/DC adaptor which is provided by the
manufacturer.
The batteries shall not be exposed to excessive heat
such as sunshine, re or the like.
To prevent possible hearing damage, do not listen
at high volume levels for long periods.

4

5
GB
Controls
Headphone socket
Loudspeaker
* 360 DEGREES SOUND
The unique Neodymium speaker located on top of the
radio provides a 360 degrees sound image.
Suggestion: If preferred, place the radio in a corner or
close to a wall for additional sound reection.
LCD display
Volume down
Tuning down button
Menu/Preset button
Power button
Band button
Select/Info button
Tuning up button
Volume up button
Rod antenna
Strap holder
(Note: the strap holder on top of the clip is intended for a
key ring/hook)
Clip
Aux in socket
DC IN socket (micro-USB)
Battery charging LED indicator
Upside indicator for the micro-USB plug
1
2
3
4
5
6
7
8
9
10
11
14
15
16
17
12
13
18

6
Charging the radio
This unit features a built in 1850mAH Lithium rechargeable
battery to power the radio.
Before operating the radio for the first time please fully
charge the battery with a supplied 5V/500 mA AC adaptor.
Carefully insert the mini-usb plug into the DC IN socket on the
rear of your radio. A red dot on the mini-usb plug indicates the
upside of the mini-usb plug. This red dot is also indicated above
the mini-usb socket. Plug the adaptor into a standard mains
outlet and the radio will begin charging the built in battery.
The LED charging indicator next to the DC IN socket will shine
bright red showing charging in progress. This LED indicator will
shine faint when the battery is fully charged. The radio can only
be charged with radio off. Charging time is approx. 4 hours.
The battery life is approx. 4 to 10 hours* listening through
the speaker and approx 6 to 15 hours* with headphones.
Reduced power, distortion, ‘stuttering’ sounds or battery power
indicator in “low” are all signs that the battery needs to be
recharged. Please note that the battery power icon does not
display on the LCD when charging the battery.
IMPORTANT:
The mains adaptor is used as the means of connecting the radio
to the mains supply. The mains socket used for the radio must
remain accessible during normal use. In order to disconnect the
radio from the mains completely, the mains adaptor should be
removed from the mains socket outlet completely.

7
GB
Safety Note:
Never use charge or operate the radio on AC mains power in
rainy or moist conditions to prevent moist from entering the
radio. Always keep the rubber cover on the back well closed
under these conditions.
* Note to battery life:
This is a rough indication only as actual achieved battery
life depends on many factors such as: selected volume,
music type (bass heavy music consumes more energy),
selected music source or radio band, selected EQ settings,
temperature and age of the battery.
Initial operation-DAB
1. Carefully straighten up the rod antenna* and press the
Power button.
2. The display will show “Welcome to Digital Radio” and start
to scan the entire DAB+ channel range and stop at the
rst found station. If the radio has been used before, the
last used station will be selected. Press the Select button
to play the station.
3. Press the Tuning up/down button to display station list and
nd desired station. Press the Select button to select the
station. The radio will tune to the station and display the
station name.
4. Adjust the volume control for comfortable listening.

8
Note:
Due to the conductivity of the human body the reception of
DAB stations may not be possible or become unstable when
the antenna touches your body or is very close to your body.
Service information-DAB
The Service Information display-Technical information on the
current status of the station being broadcast.
While listening to DAB, continually press the Select/Info
button to cycle through information on:
a. Radio text-Displays text messages such as the artist or
track name, phone in number, trafc alerts, etc.
b. Program type (PTY)-Displays the type of station being
listened to such as Pop, Classic, News etc.
c. Multiplex Name-Displays the name of the DAB multiplex
to which the current station belongs as well as its broadcast
frequency.
d. Signal strength-Displays the signal strength for the station
being listened to.
e. Bit rate and audio type-Displays the digital bit rate and
audio coding information for the station being listened to.
f . Date-Displays the current date.

9
GB
Menu functions-DAB
Press and hold the Menu button to enter the menu list. Press
the Tuning up/down button to choose from the following
options: EQ setting/Full scan/Manual tune/DRC value/Station
order/Prune/System.
A) Full scan: scan the whole DAB network in your area. Radio
will tune to the rst station found after the scanning is completed.
B) Manual tune: press the Tuning up/down button to scroll
through the whole DAB channel. Press the Select button
to select required channel.
C) EQ setting: The sound on your radio can be adjusted to
suit your personal taste for the material that you are listening
to. The radio has 5 preset equalizer modes. Alternatively,
you may set the treble and bass levels to your own preferences.
Press the Tuning up/down buttons to cycle through the
preset mode. Press the Select button to conrm your selection.
a) Normal: no tone modication is applied
b) Rock
c) Soul & Jazz
d) Classical
e) Spoken word
f ) Personal: select this mode and you can go to ‘Personal
setup’ to adjust the treble/bass tone.
Personal setup: If you nd the preset equalizer functions not
to your liking, you may set up a custom treble and bass as
following:
1) Follow the step above to enter ’Personal setup’.

10
2) Press the Tuning up/down button to select Treble or Bass.
Then press the Select button to enter the adjustment mode.
3) Press the Tuning up/down button to adjust the treble or
bass level (-10 and +10). Press the Select button to conrm
the setting.
Note:
To quickly cancel the effect of Personal, press the Tuning
up/down button until ‘Normal’ is highlighted on the display
and press the Select button. The treble and bass settings
will be memorized for the next time that you wish to use the
Personal setup.
D) DRC (Dynamic Range Control): The DRC facility can make
quieter sounds easier to hear when your radio is used in
a noisy environment. Use the Tuning up/down button to
highlight the required DRC setting. Current setting is marked
with an asterisk.
DRC Off: No compression applied.
DRC High: Maximum compression applied.
DRC Low: Medium compression applied.
Note:
Not all DAB broadcasts are able to use the DRC function. If
the broadcast does not support DRC, then the DRC setting
in the radio will have no effect.
E) Station order: your radio has 3 station order settings from
which you can choose. The station order settings are as
following.

11
GB
Alphanumeric: sorts the station list alpha-numerically
0…9 A…Z
Ensemble: organizes the station listed by DAB multiplex.
Valid: shows only those stations for which a signal can
be found.
The current setting is indicated by an asterisk.
F) Prune: If you move to a different part of the country, some
of the stations which were listed may no longer be available.
Also, from time to time, some DAB services may stop
broadcasting, or may change location or frequency.Stations
which cannot be found, or which have not been received
for a very long time are shown in the station list with a
question mark.
The Prune stations function will delete the marked DAB
stations from your station list.
1) Press the Select button to enter prune station function.
2) Press the Tuning up/down button to select YES to cause
the stations lists to be pruned, eliminating unavailable
stations. If you do not wish to prune stations, select NO
and the display will revert to the previous menu.
G) System: press the Select button to select from the following
settings
● Time/Date
Manual setting the clock
1) Press the Tuning up/down button until ‘Set Time/Date’ is
highlighted. Then press the Select button to enter the time
setup. The day digits will ash.

12
2) Press the Tuning up down/button to select correct day.
Press the Select button to conrm the setting. The month
digits will ash.
3) Follow the same procedure above for the month/year/hour/
minute setting. If the radio has been set to use a 12 hour
format, there will be an option for setting AM or PM for the
clock time
Automatically updating the clock
1) Press the Tuning up/down button until ‘Auto update’ is
highlighted. Then press the Select button to enter the
auto-update menu.
2) Press the Tuning up/down button to choose an update
option from ‘Update from Any’, ’Update from DAB’, ‘Update
from FM’, ‘No update.’ Press the Select button to conrm
your choice. The radio will then exit to the main menu display.
Setting the clock format:
The clock display: The clock display can be set to 12 or 24
hour format.
1) Press the Tuning up/down button until ‘Set format’ is highlighted
on the display. Press the Select button to enter the clock
format menu. The current clock format is marked with asterisk.
2) Press the Tuning up/down to select either 12 or 24 format.
Press the Select button to conrm your choice.
● Contrast: the contrast of the display can be adjusted.
Press the Tuning up/down button to adjust the contrast.

13
GB
The contrast level indication on the screen will change at
the same time. When you nd the setting that gives the best
legibility for the location in which the radio is used, press the
Select button to save the setting.
● Language: your radio can be congured to a different language.
Press the Tuning up/down button until your required language
is highlighted on the display. Press the Select button to
conrm your choice.
● Factory reset: by performing a factory reset, all user entered
settings will be erased.
Press the Tuning up/down button to select YES or NO.
Select YES to erase all saved settings and all settings will
revert to factory default.
● Software upgrade
Software updates for your radio may be available in the
future. As software updates become available software and
information on how to update your radio can be found at
www.perfectpro.eu
Important:
Do not perform software updates unless instructed by our
technician.
● SW version: The software display cannot be altered and
is just for your reference. Press the Select button to view
the software version installed in the radio. Press the Select
button again to revert to the previous menu.

14
Operating your radio-FM (Manual tuning)
1. Carefully straighten the rod antenna and turn on the radio
by pressing the Power button.
2. Press the Band button to select FM radio mode.
3. Press the Tuning up/down button to control the frequency
that the radio will tune to. The frequency will change in steps
of 50kHz. When the end of the waveband is reached the
radio will recommence tuning from the opposite end of the
waveband.
4. Press the Volume buttons to adjust the sound level as needed.
Scan tuning-FM
1. Press and hold the Tuning up/down button.
2. The radio will search in an upwards or downwards direction
until it nds a station of sufcient signal strength.
Service information FM RDS
Your radio has a range of display options when in FM mode:
1. Press the Info button cycle through the different options.
a. Radio text-Displays scrolling text messages such as
artist/track name, phone in number etc.
b. Program type-Displays the information for the station
being listened to e.g. Pop, Classic. News, etc.
c. Frequency-Displays the frequency of the FM signal.
d. Audio type-Displays the audio type of the station being
listened to
e. Date-Displays the current date.

15
GB
Note:
If no RDS information is available, then the radio will only be
able to display the frequency.
There will be no text or program type information available
under these conditions. The radio only provides displays
when there is information available.
Menu functions-FM
1. Repeatedly press and release the Menu button until the
radio reverts to normal display (i.e. without showing ‘MEM
Browse’ or ‘MEM Store’ at the bottom of the display).
2. Press and hold the Menu button to enter FM menu list.
Then press the Tuning up/down button to scroll through
the following options: EQ setting/FM Scan zone/FM audio/
System (for the functions of EQ setting and System, please
refer to the above sections described in DAB mode).
A) FM scan zone: Your radio includes a local/distant option
for the auto-search function. By setting the radio to the 'local'
scan option, weaker signals from more distant transmitters
can be ignored by the radio, making stronger signals easier
to nd.Press the Tuning up/down button to choose between
‘Local’ (Strong stations only) and ‘Distant’ (All stations including
distant radio stations) options. Then press the Select button
to conrm the setting. The current setting is indicated with
an asterisk.

16
B) FM audio: If the FM radio station being listened to has a
weak signal, some hiss may be audible. It is possible to
reduce this hiss by forcing the radio to play the station in
mono rather than auto. Press the Tuning up/down button
to select the options between ‘Mono’ and ‘Auto’. Then press
the Select button to conrm your selection.
Presetting stations-DAB/FM
You may store your preferred DAB and FM radio stations
to the preset station memories. There are 40 memory
presets in your radio 20 for DAB and 20 for FM. Presets are
memorized by your radio in the event of a power failure.
1. Tune to the required station following the above steps.
2. Repeatedly press and release the Menu button until ‘MEM
Store’ is shown at the bottom of the display.
3. Press the Tuning up/down button to select your required
preset number. The preset number ashes on the top right
corner indicating the preset is still empty. Press the Select
button to store the currently tuned station. The display will
show ‘Saved’ when the station is stored to the preset station
memory. Repeat this procedure for the remaining presets.
Alternatively, you can simply press the Select button (without
the use of Tuning up/down button to select your required
preset number) to preset the currently tuned station. The
station will be stored in the remaining empty preset in
sequence (i.e. if preset 1 to 4 are used, the station required
to be preset will be stored in preset 5 automatically).

17
GB
Note:
Stations stored in preset memories may be overwritten by
following the above procedure.
Recalling a preset station-DAB/FM
1. Press the Band button to select the required mode.
2. Repeatedly press and release the Menu button until ‘MEM
Browse’ is shown at the bottom of the display.
3. Press the Tuning up/down button to select your required
station.
Note:
The display will only show the preset number which has
preset stored.
Playing music via auxiliary input socket
A 3.5mm Auxiliary input socket is provided on the rear of the
unit to permit an audio signal to be fed into the unit from any
devices that features a headphone or audio output, such as
an iPod, MP3 or CD player.
1. Press the Band button to select Aux in mode.
2. Connect a stereo or mono audio source (for example, iPod,
MP3 or CD player) to the Auxiliary input socket (marked
'AUX IN').
3. Adjust the Volume control on your iPod, MP3 or CD player
to ensure an adequate signal and then adjust the volume
on the speaker for comfortable listening.

18
4. After use, disconnect your player in order to listen to your
radio conventionally.
Note:
Never use the Aux-In socket in rainy or moist conditions
to prevent moist from entering the radio. Always keep the
rubber cover on the back well closed under these conditions.
Headphone socket
The 3.5 mm stereo headphone socket located on the top of
your radio is provided for use with stereo headphones or an
earpiece. Connecting headphones automatically mutes the
built in speaker.
Important:
Excessive volume levels from earphones and headphones
may cause damage to your hearing.
Note:
Never use the headphone socket in rainy or moist conditions
to prevent moist from entering the radio. Always keep the
rubber cover on top well closed under these conditions.
Key lock
The key lock function is used to prevent unintentional
operation of the radio.
1. Press and hold the Select button until ‘Keys Locked’ is shown
on the display. The power button and all other buttons will
be disabled to prevent accidental operation.
2. To disable the key lock function, press and hold the Select
button again until ‘Keys Unlocked’ is shown on the display.

19
GB
Safety information for internal rechargeable Lithium-ion
battery
The internal rechargeable lithium-ion battery used in this device is able
to supply power for a long period of time. However, even lithium-ion
batteries reach a point where they cannot be recharged. If the battery
does not recharge after several attempts, it may be drained (has a low
charge), please contact [email protected] for repair information.
However, if you do not want us to replace the battery, you will need
to dispose of used batteries/device in accordance to the laws and
regulations in your area. In addition, you can contact your local
electronics retailers or recycling center for disposal.
User Safety Precautions
● Check the room temperature range is 0°C-45° C (32°-113° Fahrenheit)
before charging the battery.
● Do not attempt to disassemble the plastic covering or any parts of the
device, as the materials inside may be toxic and may damage skin
and clothes.
● Do not puncture, crush, modify, throw or cause any unnecessary shock
to your battery, as the battery used in this device may present a
risk of re, explosion, or chemical burn if mistreated.
● Do not leave, charge or use the battery in a car under direct sunlight,
near re or a heated source.
● Do not immerse, throw, wet the battery in water/seawater.
● Do not use or charge the battery if it appears to be abnormally hot,
discoloration, deformation or abnormal conditions is detected during
use, charge or storage.
● Do not leave a charging battery unattended. Keep the battery away
from babies and children.
