PERFECTPRO SLIM 3 User manual

E
NL
D
INSTRUCTION MANUAL
MANUEL DE L'UTILISATEUR
BRUKSANVISNING
GEBRUIKSAANWIJZING
BEDIENUNGSANLEITUNG
F
NO
NL
D
GB

CONTENTS
CONTENT ....................................................................................................................... 1
IMPORTANT SAFETY INSTRUCTIONS ........................................................................ 3
CONTROLS ........................................................................................................... 4
POWER SUPPLY .................................................................................................. 6
GENERAL FUNCTIONS .................................................................................... 9
USING THE DEVICE FOR THE FIRST TIME ............................................................... 9
DAB RADIO MODE ....................................................................................................... 10
Operating the radio – DAB ......................................................................... 10
Selecting a station – DAB ......................................................................... 10
Secondary services – DAB ......................................................................... 10
Display modes – DAB ......................................................................... 11
Finding new stations – DAB ......................................................................... 11
Manual tuning – DAB ......................................................................... 11
Dynamic Range Control (DRC) settings – DAB ........................................ 12
Prune stations – DAB ................................................................................. 12
FM MODE ................................................................................................................. 13
Operating the radio – FM seek station .................................................. 13
Manual tuning – FM .................................................................................... 13
RDS station service – FM ......................................................................... 13
Scan sensitivity setting – FM ......................................................................... 14
PRESET STATIONS ............................................................................................... 14
Storing preset stations ............................................................................ 14
Recalling preset stations ......................................................................... 15
USING BLUETOOTH .................................................................................................. 15
Pairing Bluetooth with your mobile phone ............................................... 15
Playing music from your mobile phone .................................................... 15
Display modes – Bluetooth ............................................................................ 16
Restart Bluetooth pairing ......................................................................... 16
1 2
CONTENTS
USB/SD MODE ................................................................................................... 17
Insert and remove a USB memory device ................................................... 17
Insert and remove a SD card ......................................................................... 17
Playing MP3 and WMA files ............................................................................. 18
File searching ....................................................................................................... 18
Play mode .................................................................................................. 19
Information function ......................................................................... 19
AUX IN MODE ................................................................................................... 20
SETTING THE CLOCK ............................................................................................... 20
SETTING THE ALARM .......................................................................................... 21
Setting the alarm clock ........................................................................................ 21
Switching on/ off the alarm ............................................................................... 21
LOUDNESS ................................................................................................ 22
TONE .............................................................................................................. 22
LANGUAGE SETTING .................................................................................................. 22
SOFTWARE VERSION ................................................................................................. 23
SYSTEM RESET .................................................................................................... 23
BACKLIGHT .......................................................................................................... 24
BLUETOOTH LED ......................................................................................................... 24
NAME ............................................................................................................ 25
WARRANTY ..................................................................................................... 26
SPECIFICATIONS ........................................................................................... 37
WARNING ! WARRANTY BECOMES VOID ONCE THE DEVISE CABINET HAS BEEN
OPENED OR ANY MODIFICATIONS TO THE ORIGINAL DEVICE HAVE BEEN MADE
GB

3
CONTROLS
1. LCD display
2. VOLUME/TONE knob
3. TUNING / SEEK knob
4. SD SLOT
5. USB SOCKET
6. PRESET 2 / FOLDER +
7. PRESET 1 / FOLDER -
8. ON/OFF
9. SOURCE
10. LOUDNESS
11. PRESET 3 / REWIND
12. PRESET 4 / FAST FORWARD
13. PRESET 5 / PLAY / PAUSE
14. MENU
15. INFO
16. BLUETOOTH LED
17. SPEAKER
4
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Clean only with dry cloth.
6. Do not block any ventilation openings. Install in accordance with the instructions.
7. Do not install near any heat sources such as radiators, heat registers, stoves or
 otherapparatus(includingampliers)thatproduceheat.
8. Do not defect the safety purpose of the polarized or grounding – type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade or the third prong
 isprovidedforyoursafety.Iftheprovidedplugdoesnottintoyouroutlet,consult
an electrician for replacement of the obsolete outlet.
9. Protect the power cord from being walked on or pinched particularly at plug,
convenience receptacles, and the point where they exit from the apparatus.
10. Onlyuseattachments/accessoriesspeciedbythemanufacturer.
11. Useonlywiththecart,stand,tripod,bracket,ortablespeciedbythemanufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
12. Unplug this apparatus during lightning storms or when unused for long periods of
time.
13. Referallservicingtoqualiedservicepersonnel.Servicingisrequiredifthe
apparatus has been damaged in any, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
14. Toreducetheriskofreorelectricshock,donotexposethisappliancetorainor
moisture.
15. Do not remove the cover; there are no user-serviceable parts inside.
16. Nonakedamesourcesshallbeplacedontheapparatus.
17. For outdoors use, to avoid electric shock, use battery only during a raining day or
the weather is wet. To prevent electric shock, if the radio has been exposed to rain
or water, the power supply cord and plug must be completely dried before plugging
into the mains socket outlet.
18. The power plug should be close to the apparatus, and easy to be approached that
during emergency, to disconnect the power from the apparatus, just unplug the
power plug from the AC power slot.
19. The marking information is located at the bottom of the apparatus.
20. This apparatus is provided with protection against splashing water (IP65).
21. In case of malfunction due to electrostatic discharge or fast transient (burst),
remove and reconnect the power supply.
1
23
7
8
6
9
10
12
13
11
16
17
14
15
4
5
GB

CONTROLS
18. ANTENNA
19. AUX-IN
20. BATTERY SELECT SWITCH
21. BATTERY COMPARTMENT
22. POWER CORD / PLUG STORAGE
6
POWER SUPPLY
AC operation
Before plugging the AC power cord into the AC socket, make sure the voltage is
correct and the Battery Select switch is set correctly: ALKALINE when using no
batteries or Alkaline batteries / CHARGE NiMH ON when using NiMH rechargeable
batteries.
If you use alkaline batteries in the radio and the Battery Select switch is on
ALKALINE, the batteries will be disconnected automatically when using AC power
supply.
If you use rechargeable NiMH batteries in the radio and the Battery Select switch
is on CHARGE NIMH ON, the NiMH batteries will be charged automatically when
using AC power supply.
AC power cord and plug storage are designed to store the cord and plug when the
radio is not in use or playing on batteries.
Note:
In order to disconnect the unit from the AC mains completely, the AC power cord should
be removed from the mains socket completely. The AC power cord shall remain readily
operable and should not be obstructed during intended use.
In case of malfunction due to electrostatic discharge or fast transient (burst), remove the
power supply and all the batteries then reinstall the batteries and reconnect the power
supply.
Battery operation
1. Toopenthebatterycompartment,rstturnthebatterycoverxturescounter
clockwise to loosen and open the battery cover.
2. This unit can be operated with either Alkaline batteries (6 x 1,5V type IEC LR6 /
UM-3 / AA-size) or NiMH rechargeable batteries (6 x 1,2V PerfectPro Rechargeable
UM3/AA 2300mAh). Set the Battery Select switch in the battery compartment
according to the battery type to be used (ALKALINE or CHARGE NIMH ON).
3. Insert the batteries with correct polarity as indicated in the battery compartment
 (+and-).Closethebatterycoverandfastenthexturesbyturningclockwise.Close
well to prevent moist or dust from entering the compartment.
4. If the unit is not to be used for an extended period of time, it is recommended that
the batteries are removed from the radio.
The approximate power level of the batteries is displayed in the LCD display of the
radio.
When the power level is very low, the indication “Battery Low!” appears and the battery
symbolashesonthedisplay.Thebatteriesshouldthenberechargedorreplacedsoon
to continue normal operation of the radio.
5
GB
18
22
19
20
21

87
When the rechargeable NiMH batteries are being charged. The battery symbol in the
LCD display will animate. The charging and animation will stop automatically when the
batteries are full.
Warning:
Danger of explosion if a battery is incorrectly replaced. Replace only with the same
or equivalent type.
Always make sure the Battery Select switch is set to the correct position.
An Alkaline battery is not rechargeable. Never attempt charging Alkaline batteries.
Do not mix up different battery types.
Do not mix up charged and uncharged batteries.
 Donotexposethebatteriestoexcessiveheatsuchassunshine,reorthelike.
Batteries should not be disposed of by incineration and with household waste.
Disposable batteries should be taken to a suitable recycling centre if possible.
Note: Charging conditions of the rechargeable batteries and mobile phones
This radio supports recharging of mobile phones from the USB host socket and also
supports recharging of rechargeable NiMH batteries. The table below shows how the
charging will function when a mobile phone is connected to the USB socket and/or
rechargeable NiMH batteries are inserted.
Charging speed
Modes Mobile phone connection Mobile phone NiMH batteries
(inserted)
Standby Mobile phone disconnected Not connected Quick charge
Mobile phone connected Charge Slow charge
Radio On mode Mobile phone disconnected Not connected Quick charge
Mobile phone connected Charge Stop charging
Note:
When the radio is playing a USB stick, due to additional power consumption of this
function, the charging of the batteries will stop in order to maintain normal functioning
and quality of the USB playback. Once the USB stick is removed normal charging will
continue.
Note:
To fully charge the rechargeable NiMH batteries, the radio will need about 7 hours when
it is in the quick charge mode, or about 16 hours when it is in slow charge mode.
IMPORTANT INFORMATION ON CHARGING AND USING
RECHARGEABLE BATTERIES
1. Recharge the batteries in any case at least every 2 months.
2. Make sure the Battery Select switch next the battery compartment is set to the
“CHARGE NiMH ON” position.
3. Put the batteries in the compartment whilst paying attention to the correct polarity of
the batteries (+ and -).
4. First use: Charge new batteries in one continuous, uninterrupted, charge until they
 arefull.Thisrstchargemaytakelongerthannormal.Forlongerbatterylifeitis
advised to always recharge in one continuous, uninterrupted charge until batteries
are full and to not recharge again whilst the batteries are still full.
5. New batteries will only reach their full capacity after some time of use (several
charge – discharge cycles).
6. Leave the complete group of batteries in place inside the radio and do not use
these batteries or a few of them for other purposes. This will result in a mix of (fully)
charged and (partly) empty batteries. This can seriously damage the batteries and
radio when recharged.
7. It is advised to only charge batteries at room temperatures between 5 degrees C –
35 degrees C. In lower or higher temperatures full charge cannot be achieved.
8. Depending on the capacity of the batteries, charging from “empty” to “full” can take
several hours, even up to 10 hours or more.
9. Do not charge batteries when the radio is hot or exposed to heat or heat sources.
10. It is advised to clean the metal contacts of the batteries and of the charger inside
the radio e.g. with a contact-spray from time to time.
11. Do not use a mix of old and new rechargeable batteries.
12. Do not use a mix of rechargeable and non-rechargeable batteries.
13. Do not use a mix of full and empty rechargeable batteries.
14. Do not use batteries that have a different mAh capacity.
15. Do not use damaged, deformed or leaking batteries.
16. Battery level indication is an approximate indication only and can vary with battery
type used.
17. Batteries can become hot during charging.
18. In cold conditions the capacity of batteries will be much lower than when used at
normal room temperature
19. Batteries (even when supplied with the radio), as being consumables, do not fall
under the warranty conditions of the radio.
20. It is advised to use Perfectpro rechargeable batteries as the radio and its charger
were developed for use with these batteries.
GB

109
GENERAL FUNCTIONS
1. Switching on and off
Press the ON/OFF button to turn the radio on or in standby.
2. Switching among DAB / FM / Bluetooth / AUX IN / USB / SD modes
Press the SOURCE button to switch between modes.
3. Tuning the Radio
Tune the radio using the TUNING/SEEK knob on the right.
4. Adjusting the Volume
Adjust the volume with the VOLUME/TONE knob on the left.
5. Adjusting the Tone
Press and hold the VOLUME/TONE knob on the left for about 3 seconds and rotate
it to adjust the Bass and Treble.
6. Bluetooth paring
Press the SOURCE button to Bluetooth mode. Then open the Bluetooth setup
menu in mobile phone, search and connect to the Bluetooth device name “PP Slim
3”. Once the mobile phone name is showed on the LCD, you can start streaming
music to mobile phone.
7. Playing music stored in a paired mobile phone from the Slim 3 radio in
Bluetooth mode
Press the REWIND, FAST FORWARD and PLAY/PAUSE buttons (Preset buttons
3, 4 and 5)
8. Charging a mobile phone from the Slim 3 radio
Connect the mobile phone to the USB socket on the left side with an appropriate
cable (not included with the radio).
USING THE DEVICE FOR THE FIRST TIME
1. Placetheradioonaatsurface.
2. Carefully extend the antenna located on the top of the radio. Adjust the antenna so
it is vertically extending above the radio.
3. Plug the AC power cord into the AC socket. The radio will start up and the display
will show “WELCOME TO DIGITAL RADIO” for a few seconds. Then the radio will
automatically perform an auto scan of the Band III DAB channels and the FM band
in the background.
4. Whenthescaniscompleted,the5strongestFMstationsandtherst5DAB
stations will be stored as presets. The radio will switch to standby with the updated
clock and date showing on the display.
5. If no signals are found, the clock will not be updated. It may be necessary to
relocate the radio to a position giving better reception.
DAB RADIO MODE
Operating the radio – DAB
1. Carefully extend the antenna. Press the ON/OFF button to switch on the radio.
2. Select the DAB waveband by pressing the SOURCE button.
3. Therststation(innumeric-alphaorder0…9…A…Z)inthelistofstationsfoundwill
be played. The display will show the station name.
If the radio has been used before, the last used station will be selected.
4. If no signals are detected, “No stations available” will be displayed. It may be
necessary to relocate the radio to a position giving better reception.
 Youshouldthencarryoutanautoscantondstations,pleaserefertothesection
“Find new stations - DAB”.
Selecting a station – DAB
1. Press the ON/OFF button to switch on the radio.
2. Select DAB waveband by pressing the SOURCE button. The display will show
“Now tuning” for a few seconds.
3. The display shows the name of the radio station currently selected.
4. Rotate the TUNING/SEEK knob to scroll through the list of available stations.
5. When the desired station name appears on the display, press the TUNING/SEEK
knobtoselectthestation.Thedisplaywillshow“Nowtuning”whiletheradionds
the new station.
Note: If after selecting a station the display shows “No stations available”, it may be
necessary to relocate the radio to a position giving better reception.
Secondary services – DAB
1. Certain radio stations have one or more secondary services associated with them.
If a station has a secondary service associated with it, then the secondary service
will appear immediately after the primary service as you turn the TUNING/SEEK
knob.
2. Press the TUNING/SEEK knob to select the secondary service.
Most of secondary services do not broadcast continually and if the selected service
is not available, the radio will re-tune to the associated primary service.
GB

1211
Display modes – DAB
In DAB mode, the radio can display a range of information on the display.
1. Press the INFO button to cycle through the various modes.
a. Scrolling text Displays scrolling text message such as artist/track
name, phone in number, etc.
b. Signal strength Displays the signal strength of radio reception. The
 clearunlledrectangleindicatesminimumsignallevel
required for satisfactory reception.
c. Program type Displays type of station being listened to e.g. Pop,
classic, News, etc.
d. Multiplex name Displays name of multiplex to which the current station
belongs.
e. Channel & frequency Displays channel number and frequency for the
currently tuned DAB station.
f. Bit rate & audio type Displays the digital audio bit rate.
g. Time & date Displays the current time (24 hour clock) and date.
Finding new stations – DAB
Fromtimetotime,newstationsmaybecomeavailable.Youmayproceedtondnew
stations as follows:
1. Press the MENU button, “Full scan” shows on the display.
2. Press the TUNING/SEEK knob, the radio will perform a scan of the Band III DAB
channels.
As new stations are found, the station counter on the right-hand side of the display will
increase and stations will be added to the list.
Manual tuning – DAB
Manual tuning allows you to tune the radio directly to various DAB Band III channels.
1. Press the MENU button, the display shows “Full scan”.
2. Rotate the TUNING/SEEK knob until the display shows “Manual tune”. Press the
TUNING/SEEK knob.
3. Rotate the TUNING/SEEK knob to select the desired DAB channel. Press the
TUNING/SEEK knob to tune the chosen frequency.
4. The signal strength display with an open bar shows the minimum signal strength
needed for good DAB reception. The signal strength bars will go up or down showing
the changing signal strength as you adjust the antenna or the radio position.
5. When a DAB signal is found, the display will show the name of the station. Any new
radio stations found will be added to the list stored in the radio.
6. Repeat step 1 to step 5 for other channels with new stations if available.
7. Press the TUNING/SEEK knob to return to normal DAB service.
Dynamic Range Control (DRC) settings – DAB
DRC can make quieter sounds easier to hear when the radio is used in a noisy
environment.
1. In DAB mode, press the MENU button, the display shows “Full scan”.
2. Rotate the TUNING/SEEK knob until the display shows “DRC value”. Press the
TUNING/SEEK knob.
3. Rotate the TUNING/SEEK knob to select required DRC setting (default is Off).
DRC Off DRC is switched off. Broadcast DRC will be ignored.
DRC Low DRC level is set to low that sent by broadcaster.
DRC High DRC is set as sent by broadcaster.
4. Press the TUNING/SEEK knobtoconrmthesetting.Thedisplaywillreturnto
normal radio display.
Note: Not all DAB broadcasts use the DRC function. If the broadcast does not provide
DRC information, the DRC setting in the radio will have no effect.
Prune stations – DAB
If you move to a different part of the country, some of the listed stations might no longer
be available. Also, from time to time, some DAB services may stop broadcasting, or may
change location or frequency. The Prune stations function will delete the unavailable
DAB stations from your station list.
1. In DAB mode, press the MENU button, the display shows “Full scan”.
2. Rotate the TUNING/SEEK knob until the display shows “Prune”.
3. Press the TUNING/SEEK knob to enter the setting.
4. Rotate the TUNING/SEEK knob to select between “Yes” or “No” (default is No).
Select “Yes” to enable this function if required, otherwise, select “No”.
5. Press the TUNING/SEEK knobtoconrmyoursetting.Thedisplaywillreturnto
normal radio display.
Note: If you have moved the radio to a different part of the country, you should also carry
out a search for new stations (please see the section “Finding new stations – DAB”).
GB

1413
FM MODE
Operating the radio – FM seek station
1. Press the ON/OFF button to turn on the radio.
2. Select the FM waveband by pressing the SOURCE button.
3. IfthisisthersttimetoswitchtoFMmode,thestationinpreset1willbeplayed.
If the radio has been used before, the last listened station will be played.
4. To seek a station, press the TUNING/SEEK knob. The scan stops automatically
 whenitndsastationofsufcientstrength.
5. After a few seconds, the display will update and show the station name if RDS
information is being received.
6. Tondotherstations,presstheTUNING/SEEK knob again.
7. To seek station in an opposite direction, rotate the TUNING/SEEK knob clockwise
(to scan from low frequency to high frequency) or rotate anti-clockwise (to scan
from high frequency to low frequency), and press the TUNING/SEEK knob.
8. When the waveband end is reached, the radio will recommence tuning from the
opposite waveband end.
Manual tuning – FM
1. Press the ON/OFF button to turn on the radio.
2. Select the FM band by pressing the SOURCE button.
3. Rotate the TUNING/SEEK knob to reach the required FM station.
The radio will change the frequency in steps of 50 kHz.
4. Rotate the rubber antenna to get the best reception. If the radio is tuned to a station
 ofsufcientsignalstrengthwithRDSinformationpresent,thedisplaymaychange
to show the station name.
5. When the waveband end is reached, the radio will recommence tuning from the
opposite waveband end.
RDS station service – FM
RDS (Radio Data System) is an information system which inaudible digital information
is transmitted in addition to the normal FM radio program. When the radio is receiving a
RDSstationandthereceptionstrengthissufcient,thestationnamewillappearinthe
display. It may take some time before the RDS information is available.
Calling up RDS information
When you are listening to a FM station with RDS system, repeatedly press the INFO
button to cycle through the information. This will only function if the reception level is
sufcientandclear.
a. Radio text (RT) Displays the message about the station being listened
to as ticker text.
b. Program type (PTY) Displays the type of station being listened to, e.g. Pop,
Classic, News, etc.
c. Frequency Displays the frequency of the station being listened to.
d. Signal level Displays the signal strength.
e. Time & date Displays the current time (24 hour clock) and date.
Scan sensitivity setting – FM
The radio will normally scan all stations from FM broadcasts including the weaker
signals.However,youmaywishtheAuto-scantondonlythosestationswithstrong
enough signals to give good reception.
1. Press the ON/OFF button to turn on the radio.
2. Select the FM band by pressing the SOURCE button.
3. Press the MENU button, the display shows “Scan setting”.
4. Press the TUNING/SEEK knob.
5. Rotate the TUNING/SEEK knob to select between “All stations” or “Strong station”
(default is Strong stations).
 The“Strongstation”optionwillallowtheradiotondstrongsignalsonlywhen
scanning.
6. Press the TUNING/SEEK knobtoconrmyoursetting.Thedisplaywillreturnto
normal radio display.
PRESET STATIONS
Storing preset stations
There are 5 memory presets in the radio, 5 for DAB and 5 for FM. Presets are
remembered by the radio in the event of a power failure.
1. Press the ON/OFF button to turn on the radio.
2. Press the SOURCE button to select the desired waveband.
3. Tune to the required station.
4. Press and hold the required PRESET button until the radio beeps and shows for
example “Preset 01 Stored”.
5. Repeat step 3 and 4 for the remaining presets.
6. Stations stored in the preset memories can be over-written by following the above
procedure.
GB

Recalling preset stations
1. Press the ON/OFF button to turn on the radio.
2. Press the SOURCE button to select the desired waveband.
3. BrieyPresstherequiredPRESET button, the display will show, e.g. "P1", in the
 rstline.
USING BLUETOOTH
Pairing Bluetooth with your mobile phone
1. Press the ON/OFF button to turn on the radio.
2. Select Bluetooth mode by pressing the SOURCE button.
3. The LCD display will show “Not connected” when radio is not yet paired with your
mobile phone. Also the blue Bluetooth LED on the front panel will be blinking at
this moment.
4. In your mobile phone open the Setting menu and select Bluetooth, then select “PP
Slim 3” in the Bluetooth devices list (Bluetooth pairing instructions may vary per
type of mobile phone, please check your mobile phone manual).
5. When Bluetooth pairing is successful, the LCD display will show “Bluetooth
Connected” in the 1st line, and your mobile’s name in the 2nd line for about 2
seconds.
The blue Bluetooth LED on the front panel will stop blinking when the radio is
connected to a mobile phone.
6. After all, the LCD display will show the connected mobile phone’s name in the 1st
line to indicate the connected device to the radio.
Playing music from your mobile phone
1. Press the ON/OFF button to turn on the radio.
2. Select Bluetooth mode by pressing the SOURCE button.
3. Start playing music by using the media players in the paired mobile phone.
4. Playback can be controlled from the mobile phone or by pressing the REWIND,
FAST FORWARD, and PLAY/PAUSE buttons (preset buttons 3, 4 and 5) on the
radio.
5. After the music playback starts, the name of the song will be displayed in the LCD.
Display modes – Bluetooth
In Bluetooth mode, the radio can display a range of information of the current playing
music on the display. Press the INFO button to cycle through the various types.
a. Title Displays scrolling song’s name of the current playback music.
b. Artist Displays the artist’s name of the current playback music.
c. Album Displays the album name of current playback music.
d. Status Displays the playback status. E.g. playing or stopped.
e. Music info Displays the music format and sampling rate of current playing
song. E.g. “AAC” is the format of the song; “44100Hz” is the
sampling frequency of the song.
f. Time & date Displays the current time and date.
Restart Bluetooth pairing
The Bluetooth function can be set to operate in different ways as below:
1. In Bluetooth mode, press the MENU button to enter the system setting.
2. Rotate the TUNING/SEEK knob to select “Disconnect BT” options, and press the
TUNING/SEEK knob to select the setting.
3. The LCD display will show “Please wait” for a few seconds in order to disconnect
the current connection with the mobile phone device.
4. The LCD display will show “Not connected” and the radio’s Bluetooth is free for any
mobile phone connection as it is in discoverable mode now.
The blue Bluetooth LED on the front panel will be blinking at this moment.
Note: “Disconnect BT” is the option that forcing the Bluetooth of this radio to disconnect
from your mobile phone and entering the “discoverable mode”. This is the way to allow
the Bluetooth pairing to another device. If no new device is paired, the Bluetooth will
automatically try to connect to the last device when it is switched off and on again.
The Auto-Power management function will be activated in Bluetooth mode. If there is no
signal* from Bluetooth for a period of over 15 minutes, the radio will automatically switch
to standby mode. Pressing the ON/OFF button will wake up the unit.
* Also when the incoming signal from the external device is too low and cannot be
detected for a period of over 15 minutes by the Auto-Power management, the radio will
switch to standby mode.
To prevent this raise the output level of the external device enough to be detected.
GB
1615

USB/SD MODE
NEVER USE THE USB SOCKET OR AUX-IN SOCKET IN RAINY OR MOIST
CONDITIONS TO PREVENT MOIST FROM ENTERING THE RADIO!! KEEP THE
RUBBER COVER CLOSED UNDER THESE CONDITIONS.
USB memory devices and Secure Digital (SD, SDHC) cards can be used with the radio
forplaybackofMP3andWMAles.
The radio has been tested with a range of SD cards up to 2GB and SDHC cards and
USB memory devices up to 32GB. However, there are many different SD card and USB
memory device variants available and not all of them can be guaranteed to work in this
radio.MemorymustusetheFATorFAT32lingsysteminordertooperateinthisradio.
Audio formats supported for playback are MP3 and WMA. Playback does not support
lesencodedusingWMAlossless,WMAvoice,WMA10professional,orlesofany
format that have DRM protection.
The SD card slot and USB socket are located on the side behind the rubber cover. Make
sure the rubber cover is closed well after use to prevent moist and dirt from entering the
radio.
The USB memory device or SD card should not be removed during playback as damage
orcorruptionoflesmayoccur.
SD cards and USB memory devices are not included with this radio.
Note: When the radio is playing a USB stick, due to additional power consumption
of this, the charging of the batteries will stop in order to maintain normal functioning
and quality of the USB playback. Once the USB stick is removed normal charging will
continue.
Insert and remove a USB memory device
Carefully insert a USB memory device into the USB socket.
To remove the USB memory device, simply pull the device out.
Insert and remove a SD card
To insert a SD card into the radio, hold the “golden” contacts side facing towards you (front
of the radio) and push carefully into the SD Card slot.
Close the rubber cover to prevent moist or dust from entering into the sockets and slot.
To remove the card, push the card slightly and it will pop out, allowing removal.
Playing MP3 and WMA les
1. Press the ON/OFF button to turn on the radio.
2. Press the SOURCE button to select the USB or SD mode.
The display shows “READING”. It may take some time before the radio has read in
 thefoldersandlesdataonthememorydevice.
3. AfterreadingtheUSBmemorydeviceorSDcard,theradiowillstarttoplaytherst
 le(song)intherstfolder.
If no USB memory device or SD card is inserted, the display will show “NO USB
STICK” or “NO SD CARD” respectively.
4. To pause the playback, press the PLAY/PAUSE button.
Press the PLAY/PAUSE button again to resume the playback from pause position.
5. Toskiptothenextle,presstheFAST FORWARD button.
6. Toskiptothepreviousle,presstheREWIND button.
7. Whiletheleisplaying,pressandholddowneithertheFAST FORWARD button
or REWIND button.Releasethebuttonwhenthedesiredpartoftheleisreached.
8. To skip to the next folder, presses the FOLDER + button.
9. To skip to the previous folder, presses the FOLDER - button.
File searching
1. Press and hold the TUNING/SEEK knob for a few seconds until the display shows
 thecurrentfoldernumberandthetotalfoldernumberintherstline.
The second line shows the name of the current folder.
2. Rotate the TUNING/SEEK knob to search the desired folder. Press the TUNING/
SEEK knob to select the folder.
 Thedisplaywillshowtherstleoftheselectedfolder.
3. Rotate the TUNING/SEEK knobtosearchthedesiredle.PresstheTUNING/
SEEK knobtoselectthele.Theradiowillstarttoplaytheselectedle.
Track
Playing folder
Total Folder
Repeat 1
Repeat folder
ALBUM info.
ARTIST info.
PLAY
PAUSE
CLOCK info.
Repeat All
Random
GB
1817

Theradiosupportsalimitednumberoffoldersandlesinthesearching:
Mode Max.no.offolderssupported Max.no.oflessupported
Stop 999(withfoldername) 9999(withlename)
Play 999 9999
  (1-99withfoldername) (1-999withlename)
  (100-999withoutfoldername) (1000-9999withoutlename)
Play mode
During USB memory device or SD card is playing,
1. Press the MENU button,
2. Rotate the TUNING/SEEK knob until the display shows “Play mode”. Press the
TUNING/SEEK knob.
3. Rotate the TUNING/SEEK knob to the desire play mode and press the TUNING/
SEEK knobtoconrm.
The radio will step through the following options:
Repeat 1 Repeat Folder Repeat All Random Normal Play
Repeat1 Repeatedlyplaytheleyouarelisteningto.
RepeatFolder Repeatedlyplaytheleswithinthefolderyouarelisteningto.
RepeatAll RepeatedlyplayalllesintheUSBmemorydeviceorSDcard.
Random PlayalllesintheUSBorSDcardonceinrandomorder.
The selected Play Mode is indicated on the right of the top line of the display by an icon.
No icon is shown when in Normal Play mode.
Information function
During USB memory device or SD card playback, press the INFO button to cycle
throughthefollowinginformation(onlyifthisinformationispresentwiththeleonthe
memory device):
File name (song) Folder name Artist name Album name Totalno.ofles
on the USB stick or SD card Bit Rate Clock time and Date Normal playback
status (play time)
AUX IN MODE
A 3.5mm stereo Aux In socket is provided on the side behind the rubber cover, for
connecting an external audio device such as MP3 player or CD player (not included with
this radio).
1. Connect an audio SOURCE to the Aux In socket on the backside of the radio.
2. Press the SOURCE button to select AUX input. Display will show “AUX IN”.
3. Play the external player.
4. Adjust the volume of both the radio and the player for comfortable listening.
5. After use, close the rubber cover to prevent moist or dust from entering into the
sockets and radio.
Notes: Never use the AUX-IN socket in rainy or moist conditions to prevent moist from
entering the radio. Keep the rubber cover closed under these conditions.
The Auto-Power management function will be activated in AUX mode. If there is no
signal* from the AUX input jack for a period over 15 minutes, the unit will automatically
switch to standby mode. The operation indicator and the LCD will go off in such case.
Pressing the ON/OFF button will wake up the unit.
* Also when the incoming signal from the external device is too low and cannot be
detected for a period of over 15 minutes by the Auto-Power management, the radio will
switch to standby mode.
To prevent this raise the output level of the external device enough to be detected.
SETTING THE CLOCK
The clock can only be set when the radio is in standby mode. If no buttons are pressed
for 5 seconds, the radio will exit the clock setup and the setting is cancelled.
1. Press and hold the TUNING/SEEK knobfor12secondsuntilthehourdigitsash
on the display.
2. Rotate the TUNING/SEEK knob to set the hour.
3. Press the TUNING/SEEK knobtoconrm,theminutedigitsash.
4. Rotate the TUNING/SEEK knob to set the minute.
5. Press the TUNING/SEEK knobtoconrm,thedayashesonthedisplay.
6. Rotate the TUNING/SEEK knob to set the current day.
7. Press the TUNING/SEEK knobtoconrm,themonthashes.
8. Rotate the TUNING/SEEK knob to set the current month.
9. Press the TUNING/SEEK knobtoconrm,theyearwillthenashonthedisplay.
10. Rotate the TUNING/SEEK knob to set the current year.
11. Press the TUNING/SEEK knobtoconrm,“SYNCLOCKON”ashes.
12. Rotary the TUNING/SEEK knob to select “SYNCLOCK ON” or “SYNCLOCK OFF”.
13. Press the TUNING/SEEK knobtoconrmandnishtheclocksetting.
GB
2019

21
SETTING THE ALARM
The alarm can only be set when the radio is in standby mode. If no buttons are
pressed for 10 seconds, the radio will exit the alarm setup and the setting is cancelled.
Or press the MENU button during alarm setup, the radio will also return to standby mode
without saving the adjusted alarm settings.
Setting the alarm clock
1. Press the MENU button for about 3 seconds, the display shows “ALARM SET” and
 thehourdigitsashonthedisplay.
2. Rotate the TUNING/SEEK knob to set the hour.
3. Press the TUNING/SEEK knobtoconrm.Theminutedigitsash.
4. Rotate the TUNING/SEEK knob to set the minute.
5. Press the TUNING/SEEK knobtoconrm.
6. Thedisplaywillthenshow“ALARMSOURCE”.Youmaychoose“BUZZER”,“DAB”,
“FM RADIO”, “USB” or “SD”. Rotate the TUNING/SEEK knob to select. If “DAB” is
 selected,thelastlistenedstationwillbeplayedwhenthealarmres.
7. Press the TUNING/SEEK knobtoconrm.
8. The display will then show “VOL XX”. Rotate the TUNING/SEEK knob to change
the alarm volume.
9. Press the TUNING/SEEK knobbuttontoconrm.
Note: When USB or SD has been set as alarm source, the radio will automatically start
repeat all play back during alarm period.
Note: If USB or SD has been set as alarm source and the related mass storage device
isnotcorrectlyinsertedintotheUSBorSDsocket,systemwillrebuzzeralarmwhen
the alarm is activated.
Switching on/ off the alarm
To switch the alarm on, press the MENU buttonbriey.Thealarmiconwillbeshown
at the top left corner. To switch the alarm off, press the MENU buttonbrieyagain.The
alarm icon will be disappeared.
Press the ON/OFF buttontoturnoffthealarmwhenitisring.
22
LOUDNESS
The Loudness function enables to get compensation on lower and higher frequency.
The effect will be more audible when the radio is in a lower volume level (Dynamic
Loudness).
1. Press the LOUDNESS button to enable the loudness, the display shows
“Loudness On”.
2. Press the LOUDNESS button again to disable the loudness, the display shows
“Loudness Off”.
TONE
The Tone function enables the user to adjust the lower and higher sound frequencies.
1. Press the ON / OFF button to turn on the radio.
2. Press and hold the VOLUME/TONE knob for about 3 seconds, the display shows
“BASS 0”.
3. Rotate the VOLUME/TONE knob to set the desired Bass level.
4. Press the VOLUME/TONE knobtoconrm,thedisplayshows“TREBLE0”.
5. Rotate the VOLUME/TONE knob to set the desired Treble level.
6. Press the VOLUME/TONE knobtoconrmandreturntonormaldisplay.
LANGUAGE SETTING
Theradiocanbeconguredtoadifferentlanguage.
1. Press the ON/OFF button to turn on the radio.
2. Press the MENU button, and then rotate the TUNING/SEEK knob until the display
shows “System”.
3. Press the TUNING/SEEK knob; rotate the TUNING/SEEK knob until the display
shows “Language”.
4. Press the TUNING/SEEK knob to enter the language adjustment menu.
5. Rotate the TUNING/SEEK knob until the desired language appears on the display
(default is English).
6. Press the TUNING/SEEK knobtoconrmyourchoice.Thedisplaywillchangeto
the chosen language.
GB

SOFTWARE VERSION
The software display cannot be altered and is just for your reference. You can only view
the software version in DAB, FM or Bluetooth mode.
1. Press the ON/OFF button to switch on the radio.
2. Press the SOURCE button to select FM or DAB, or Bluetooth mode.
3. Press the MENU button until the display shows “Full Scan” at DAB, or "Scan
setting" at FM, or "Disconnect BT" at Bluetooth mode, and then rotate the TUNING/
SEEK knob until the display shows “System”.
4. Press the TUNING/SEEK knob; rotate the TUNING/SEEK knob until the display
shows “SW version”.
5. Press the TUNING/SEEK knob to view the software version.
6. Press the TUNING/SEEK knob back to the last menu, and press the TUNING/
SEEK knob again to return to the normal radio display.
Notes: USB socket inside battery compartment is for upgrading the software of the
device.
SYSTEM RESET
If the radio fails to operate correctly, or some digits on the display are missing or
incomplete, carry out the following procedure.
1. Press the ON/OFF button to switch on the radio.
2. Press the MENU button,
3. Rotate the TUNING/SEEK knob until the display shows “System”. Press the
TUNING/SEEK knob.
4. Rotate the TUNING/SEEK knob until the display shows “Factory reset”. Press the
TUNING/SEEK knob.
5. Rotate the TUNING/SEEK knob to select between “Yes” or “No”.
Select “Yes” if you wish to reset the radio; otherwise, select “No” to cancel the
selection.
6. Press the TUNING/SEEK knob to cause the factory reset.
7. A full reset will be performed. All presets and the station list will be erased. All
settings will be set to the default values.
The display will show “WELCOME TO DIGITAL RADIO” for a few seconds, and
then the radio will automatically perform an auto scan of the Band III DAB channels
and the FM band.
In case of malfunction due to electrostatic discharge; reset the product as above to
resume normal operation. If you are not able to perform the reset operation as above,
remove and reconnect the power supply.
BACKLIGHT
LCDbacklightconguration
1. Press the ON/OFF button to turn on the radio.
2. Press the MENU button, and then rotate the TUNING/SEEK knob until the display
shows “System”.
3. Press the TUNING/SEEK knob; rotate the TUNING/SEEK knob until the display
shows “LCD backlight”.
4. Press the TUNING/SEEK knob to enter the LCD backlight adjustment menu.
5. Rotate the TUNING/SEEK knob to select “on” in order to keep backlight always
lightened when the radio is turned on with AC power supply;
6. Or rotate the TUNING/SEEK knob to select “off” (by default) so that the backlight
will be lightened for about 10 seconds whenever a button is pressed with AC power
supply.
7. Press the TUNING/SEEK knobtoconrmyourchoice.
Note: The LCD backlight option “on” is only functional when the radio is powered by AC
power supply. When the radio is powered by battery power supply, the LCD backlight
is switched to option “off” – 10 seconds lightened when a button is pressed. When the
radio is connected to mains AC power again, the last user setting will be applied again.
BLUETOOTH LED
Bluetooth LED conguration
Press the ON/OFF button to turn on the radio.
Press the MENU button, and then rotate the TUNING/SEEK knob until the display
shows “System”.
Press the TUNING/SEEK knob; rotate the TUNING/SEEK knob until the display shows
“Bluetooth LED”.
Press the TUNING/SEEK knob to enter the Bluetooth LED adjustment menu.
Rotate the TUNING/SEEK knob to select “on” in order to keep backlight always
lightened when the radio is turned on with AC power supply;
Or rotate the TUNING/SEEK knob to select “off” (by default) so that the backlight will be
lightened for about 10 seconds whenever a button is pressed with AC power supply.
Press the TUNING/SEEK knobtoconrmyourchoice.
Note: The Bluetooth LED option “on” is only functional when the radio is in Bluetooth
mode. If the Bluetooth LED option is set to “off”, this blue LED will be turned off either
mobile phone is connected (not blinking) or not connected (blinking).
GB
2423

NAME
This radio is supporting users to customize the radio’s name. If the radio has been
renamed, the new name of the radio will be shown when the radio is turning off or
entering to standby.
1. Press the ON/OFF button to turn on the radio.
2. Press the MENU button, and then rotate the TUNING/SEEK knob until the display
shows “System”.
3. Press the TUNING/SEEK knob; rotate the TUNING/SEEK knob until the display
shows “Name”. Press the TUNING/SEEK knob.
4. Rotate the TUNING/SEEK knob to select the letters. The maximum length of new
name is 16 letters’ long.
5. Press the TUNING/SEEK knobtoconrmthecurrentselection.Bypressingthis
TUNING/SEEK knob, the cursor will be moved to next position for selection.
6. Press the P3/ or P4/ to move the cursor to left or right cyclically.
7. Repeat step 4 to step 6 to edit the new radio name.
8. To complete editing the new radio name, you can either edit all the 16 letters or
press the MENU button.
9. Whennishingeditingtheradioname,theLCDwilldisplay“Conrmchanges”
 intherstline,anddisplay“OK”tosavethechangesor“Cancel”todiscardthe
changes.
10. Toconrmthechanges,rotatetheTUNING/SEEK knob until “OK”, and then press
the TUNING/SEEK knob to exit. After this action, the radio will save the new name.
11. To cancel the changes, rotate the TUNING/SEEK knob until “Cancel”, and then
press the TUNING/SEEK knob to exit. After this action, the radio will discard the
changes and keep the current radio name as for display.
12. Whennexttimetheradioisturningoff,theLCDwillshow“Welcome”intherstline
and the new name in the second line.
13. Whentheradioisturningoff,theLCDwillshow“Goodbye”intherstlineandthe
new name in the second line.
If there were no user operating by the panel buttons for more than 20 seconds during
editing, the radio would automatically exit the rename function without saving any of the
changes.
Notes: The default radio name is empty. And the new edited name will be lost and back
to default after executing factory reset in the menu.
Notes: The radio is supporting maximum 16 letters as the new name of the radio
WARRANTY
This radio has a 2 year limited warranty.
WARNING ! Warranty becomes void once the radio cabinet has been opened or
any modications or alterations to the radio have been made !
The terms of the warranty of this radio do not cover the following:
- Damage caused by misuse, abuse, neglect, alterations, accidents or unauthorized
repair.
- Normal wear and tear.
- Batteries
GB
2625

SPECIFICATIONS
Technical data
This device is noise-suppressed according to the applicable EU directives.
ThisproductfulllstheEuropeandirectives2006/95/EC,2005/32/ECand2004/108/EC.
This device conforms to the safety regulation DIN EN 60065 (VDE 0860) and therefore
the international safety regulation IEC 60065.
Never open the device casing. The manufacturer will not accept any liability for damage
resulting from improper handling. The type plate is located on the bottom of the device.
Environmental note
This product has been manufactured with high quality parts and materials,
which can be reused and recycled.
Therefore, do not throw the product away with normal household waste
at the end of its service life. Take it to a collection point for the recycling
of electrical and electronic device. This is indicated by this symbol on the
product, in the operating manual and on the packaging.
Pleasendoutaboutcollectionpointsoperatedbyyourlocalauthority.
Help protect the environment by recycling used products.
Power supply
Mains operation: AC 230 V ~ 50/60Hz
Battery operation: 6 x AM3/AA/LR6
(Batteries of PerfectPro brand are highly recommended to be used)
Power consumption (mains supply)
Operation: < 24 W (MAX)
Standby: < 1 W
Frequency coverage
FM 87.50MHz – 108.00 MHz
DAB 174.928MHz – 239.200MH
Speaker
Size1xØ77mm
Impedance 8 ohms
Output Power
Nominal 1 x 7W
Aux in socket
Ø3.5mm
TABLE DES MATIÈRES
TABLE DES MATIÈRES .................................................................................. 1
INSTRUCTIONS DE SECURITE IMPORTANTES .................................................. 3
COMMANDES .................................................................................................. 4
ALIMENTATION ELECTRIQUE .................................................................................. 6
FONCTIONS PRINCIPALES .................................................................................. 9
PREMIERE UTILISATION DE LA RADIO ......................................................... 9
MODE DAB ............................................................................................. 10
Utilisation de la radio – DAB .................................................................................. 10
Sélection d’une station – DAB .............................................................. 10
Affichage – DAB .................................................................................. 11
Recherche de nouvelles stations – DAB ...................................................... 11
Recherche manuelle de stations – DAB ..................................................... 12
Réglages Dynamic Range Control (DRC) – DAB ............................................. 12
Suppression de stations “Prune" – DAB ........................................................... 13
MODE FM ................................................................................................. 13
Utilisation de la radio – Recherche automatique de stations - FM .............. 13
Recherche manuelle de stations – FM ...................................................... 14
Système d’informations RDS – FM ............................................................. 14
Réglage de la sensibilité – FM ...................................................................... 14
PRESELECTION DE STATIONS ............................................................................. 15
Mémoire de stations présélectionnées ............................................................ 15
Rappel de stations présélectionnées ............................................................. 15
MODE BLUETOOTH ..................................................................................... 15
Connexion Bluetooth avec votre téléphone portable ....................................... 15
Ecoute de musique à partir de votre téléphone portable .................................. 16
Affichage – Bluetooth .................................................................................. 16
Renouveler la connexion - Bluetooth ............................................................ 16
MODE USB/SD .................................................................................................. 17
Insertion et retrait d’un périphérique de stockage USB .................................... 18
Insertion et retrait de carte SD .................................................................................. 18
LecturedechiersMP3etWMA..................................................................................19
Selectionner un fichier .................................................................................. 20
Mode lecture .................................................................................................................. 20
Function d’information ................................................................................................... 21
F
127

32
TABLE DES MATIÈRES
MODE AUX IN....................................................................................................... 21
REGLAGE DE L’HEURE ET DE LA DATE .......................................................... 22
REGLAGE DE L’ALARME .................................................................................. 22
Réglage de l’alarme ............................................................................... 22
Activer/Désactiver l’alarme ............................................................................... 23
SONORITE ...................................................................................... 23
REGLAGE DE LA TONALITE .................................................................................. 23
SELECTION DE LA LANGUE .................................................................................. 24
VERSION DU LOGICIEL .................................................................................. 24
REINITIALISATION DU SYSTEME ..................................................................... 25
ECLAIRAGE DE L’ECRAN .................................................................................. 25
LED BLUETOOTH .................................................................................. 26
OPTION MESSAGE D’ACCUEIL .................................................................................. 26
GARANTIE ......................................................................................... 28
INFORMATIONS ........................................................................................ 29
AVERTISSEMENT : LA GARANTIE PREND FIN LORSQUE LE BOITIER
DE LA RADIO A ETE OUVERT OU LORSQUE LA RADIO A ETE MODIFIEE
DE QUELQUE MANIERE QUE CE SOIT PAR L’UTILISATEUR FINAL.
INSTRUCTIONS DE SECURITE IMPORTANTES
1. Lisez attentivement et complètement le mode d’emploi de la radio.
2. Conservez soigneusement ce mode d’emploi.
3. Tenez compte de tous les avertissements.
4. Suivez toutes les instructions.
5. Nettoyez la radio exclusivement avec un linge propre et sec.
6. N’obstruez pas les ouvertures de ventilation. Installez la radio conformément aux
instructions.
7. N’installez pas la radio à proximité de sources de chaleur (radiateurs de chauffage,
grilles de ventilation, fours et autres appareils (amplis compris) qui génèrent de la
chaleur.
8. Netentezjamaisdemodierleschesetprisespolarisesoucomportantun
plot de terre destiné à garantir votre sécurité. Une prise polarisée possède deux
contacts, dont l’un est plus large que l’autre. Une prise à plot de terre possède deux
contacts et un plot de mise à la terre. Le contact le plus large ou le plot de terre est
 prvupourassurervotrescurit.Silachefournienes’adaptepasdanslaprise
de courant de votre installation, consultez un électricien pour le remplacement de la
prise de courant.
9. Protégez le cordon d’alimentation de la radio de manière à éviter tout dommage à
celui-ci, en particulier au niveau de la prise de courant et de la sortie de la radio.
10. Utilisez exclusivement les pièces et accessoires prévus par le fabricant.
11. Utilisez la radio exclusivement sur un support mobile, un présentoir, un trépied, un
support mural ou une table recommandé par le fabricant ou vendu avec la radio.
Lors de l’utilisation d’un support mobile, soyez prudent en déplaçant l’ensemble
support/radio, de façon à éviter de vous blesser en cas de chute de la radio.
12. Retirezlacheducordond’alimentationdelaradiodelaprisedecourantpendant
un orage ou lorsque la radio n’est pas utilisée durant un certain temps.
13. Coneztouterparationoutoutentretienunpersonnelquali.Unerparation
 ouunentretienestncessairelorsquelaradio,lecordond’alimentationoulache
a été endommagé, lorsqu’un liquide a été renversé sur la radio et a pénétré dans
celle-ci, lorsque des objets sont tombés sur la radio et ont pénétré dans celle-
ci, lorsque la radio a été exposée à la pluie ou à l’humidité, lorsque la radio ne
fonctionne pas normalement ou lorsque la radio est tombée d’une certaine hauteur.
14. And’vitertoutrisqued’incendieoud’lectrocution,n’exposezpaslaradiola
pluie ni à l’humidité.
15. Ne tentez jamais de démonter la radio. Celle-ci ne comporte aucun élément qui soit
réparable par l’utilisateur.
16. Ne posez jamais sur la radio des objets dégageant de la chaleur ou présentant une
 ammenue.
17. Lors d’une utilisation à l’air libre par temps humide ou pluvieux, faites fonctionner
 laradiosurpilesand’vitertoutrisqued’lectrocution.Andeprvenirle 
risque d’électrocution lorsque la radio a été exposée à l’eau ou à la pluie, le cordon
 d’alimentationainsiquelachedoiventtrecompltementschsavantd’insrer
 lacheducordond’alimentationdelaradiodansuneprisedecourant.
18. Laprisedecourantdoittreprochedelaradioetrestertoujoursaccessible,
 desortequeseulelachedelaradiodoittreretiredelaprisedecourantencas
d’urgence.
19. Les informations légales concernant la radio se trouvent sur la face inférieure de
celle-ci.
20. Cette radio est protégée contre les projections d’eau (IP65).
21. En cas de perturbations provoquées par une décharge électrostatique ou une
 pointedetension,lacheducordond’alimentationdelaradiodoittreretireun
bref instant de la prise de courant et réinsérée ensuite dans celle-ci.
F

54
COMMANDES
1. Ecrand’afchageLCD
2. Bouton de Volume/Tonalité
3. Bouton de Fréquence/Recherche
4. FENTE CARTE SD
5. PORT USB
6. PREDEFINI 2 / DOSSIER SUIVANT +
7. PREDEFINI 1 / DOSSIER PRECEDENT -
8. ON/OFF
9. SOURCE
10. LOUDNESS (TONALITE)
11. PREDEFINI 3 / REMBOBINER
12. PREDEFINI 4 / AVANCE RAPIDE
13. PREFINI 5 / PLAY / PAUSE
14. MENU
15. INFO
16. LED BLUETOOTH
17. HAUT-PARLEUR
1
23
7
8
6
9
10
12
13
11
16
17
14
15
4
5
COMMANDES
18. ANTENNE
19. AUX-IN
20. INTERRUPTEUR DE SELECTION DU TYPE DE PILES
21. COMPARTIMENT DES PILES
22. CÂBLE D’ALIMENTATION / RANGEMENT DE LA PRISE
F
18
22
19
20
21

76
ALIMENTATION ELECTRIQUE
Utilisation sur courant secteur
● Avantd’insrerlacheducordond’alimentationdelaradiodansuneprisede
courant secteur, assurez-vous que la tension du courant secteur soit correcte et
que l’interrupteur de sélection du type de piles se trouve dans la bonne position :
ALKALINE en l’absence de piles ou lorsque vous utilisez des piles alcalines /
CHARGE NiHM ON lorsque vous utilisez des piles NiMH.
● Lorsquevousutilisezdespilesalcalinesetlorsquel’interrupteurdeslection
du type de piles se trouve positionné sur ALKALINE, les piles seront déconnectées
automatiquement lorsque la radio est utilisée sur courant secteur.
● LorsquevousutilisezdespilesNiMHetlorsquel’interrupteurdeslectiondutype
de piles se trouve positionné sur CHARGE NiMH ON, les piles seront rechargées
automatiquement lorsque la radio est utilisée sur courant secteur.I
● Lespattescourbessituesl’arriredelaradiopermettentderangerlecordon
 d’alimentationetlachelorsquelaradion’estpasutiliseoulorsquecelle-ciest
utilisée sur piles.
Remarque :
Andedconnecterlaradioducourantsecteur,lacheducordond’alimentationdoit
treretireentirementdelaprisedecourant.Lacheetlecordond’alimentation
doivent rester accessibles à tout moment.
En cas de perturbations provoquées par une décharge électrostatique ou une pointe
detension,lacheducordond’alimentationdelaradiodoittreretiredelaprisede
courantetlespilesdoiventtredconnectesunbrefinstant.
Utilisation sur piles
1. Pourouvrirlelogementdespiles,tournezd’abordlesdeuxpattesdexationdu
couvercle du logement dans le sens inverse des aiguilles d'une montre et tirez
ensuite le couvercle vers le bas.
2. La radio est prévue pour fonctionner sur piles alcalines (6 x 1,5V type IEC LR6 /
UM-3 / format AA) ou sur piles NiMH (6 x 1,2V – piles rechargeables PerfectPro
- UM3/AA 2300mAh). Positionnez l’interrupteur de sélection du type de piles sur
ALKALINE ou CHARGE NiMH ON en fonction du type de piles utilisé.
3. Installez les piles dans le logement en respectant la polarité (+ et -). Refermez
 ensuitelecouvercledulogementettournezlesdeuxpattesdexationdanslesens
 desaiguillesd'unemontre.Refermezcorrectementlecouvercleand’viterquede
l'humidité ou de la poussière pénètre dans le logement des piles.
4. Lorsque vous prévoyez de ne pas utiliser la radio pendant un certain temps, il est
recommandé de retirer les piles de celle-ci.
Lacapacitapproximativedespilesestafchel'cranLCDdelaradioaumoyen
d’une icône “Pile”. Lorsque la capacité des piles est très faible, le message “Battery
Low!” (batterie faible) apparaît à l’écran et l’icône “Pile” clignote. Les piles doivent dans
cecastreremplacesourechargessanstarder,defaongarantirlefonctionnement
normal de la radio.
Lorsque des piles NiMH sont rechargées, une animation de recharge apparaît à l’écran
LCD.Leprocessusderechargedespilesetl’animationderecharges’arrteront
automatiquement lorsque les piles sont complètement rechargées.
Avertissement :
● Ilexisteunrisqued'explosionlorsquelespilesnesontpasremplaces 
correctement. Remplacez celles-ci exclusivement par des piles de type identique ou
équivalent.
● Assurez-vousquel’interrupteurdeslectiondutypedepilessetrouvedansla
bonne position.
● Unepilealcalinen’estpasrechargeable.Netentezjamaisderechargerdespiles
alcalines.
● Nemlangezjamaisdiffrentstypesdepiles.
● Nemlangezjamaisdespileschargesetdespilesdcharges.
● Evitezd’exposerlespilesdeschaleursexcessives(soleil,feuousourcede
chaleur similaire).
● Lespilesnepeuventjamaistredtruitesparincinrationniliminesavecles
ordures ménagères.
● Lespilesusagesdoiventtreconesuncentrederecyclageagr.
Remarque: Conditions de recharge des piles rechargeables et des téléphones portables
Cette radio permet de recharger les téléphones portables depuis le port USB et permet
également de recharger les piles rechargeables. Le tableau ci-dessous montre comment
la recharge fonctionne lorsqu’un téléphone portable est connecté au port USB et/ou
lorsque des piles rechargeables sont insérées dans la radio.
Vitesse de charge
Modes Connexion téléphone portable Téléphone Piles
portable rechargeables
NiMH insérées
Standby Téléphone portable déconnecté Non connecté Charge rapide
Téléphone portable connecté Charge Charge lente
Mode Radio On Téléphone portable déconnecté Non connecté Charge rapide
Téléphone portable connecté Charge Ne charge pas
Remarque:
Lorsque la radio lit les pistes d’un périphérique de stockage USB, cette fonction
consommedavantagedepuissance.Lachargedespilesestdoncsuspenduean
d’assurer un fonctionnement normal et une bonne qualité de lecture du périphérique de
stockage USB. Une fois le périphérique de stockage USB retiré, la charge normale des
piles reprend automatiquement.
Pour recharger entièrement les piles NiMH de la radio, il faudra 7 heures en mode de
charge rapide ou environ 16 heures en mode de charge lent.
F

98
INFORMATIONS IMPORTANTES CONCERNANT LA
RECHARGE ET L’UTILISATION DE PILES RECHARGEABLES
1. Rechargez les piles au moins tous les deux mois.
2. Assurez-vous que l’interrupteur de sélection du type de piles se trouve
positionné sur “CHARGE / NiMH ON”.
3. Installez les piles dans le logement des piles en respectant la polarité (+ et -).
4. Première utilisation : Rechargez les piles neuves en un seul cycle de charge
ininterrompu jusqu’à ce qu’elles soient complètement rechargées. Ce premier cycle
 dechargeprendraplusdetempsqu’uncycledechargenormal.And’augmenter
la durée de vie des piles, il est préférable de toujours recharger celles- ci en
un seul cycle de charge ininterrompu jusqu’à ce qu’elles soient complètement
 recharges.Evitezderechargerlespileslorsqueleurchargeestencoresufsante.
5. Des piles neuves atteindront leur pleine capacité seulement après un nombre de
cycles d’utilisation (décharge-recharge).
6. Lors d’une utilisation fréquente de la radio, laissez le groupe de piles complet dans
 laradio.N’utilisezpaslespilesd’autresns.N’enlevezjamaisquelquespiles
 delaradioenvuedelesutiliserd’autresns.Ilenrsulterainvitablementun
mélange de piles (complètement) rechargées et de piles (partiellement) déchargées.
7. Rechargez les piles à une température ambiante entre 5°C et 35°C. Une
température ambiante supérieure ou inférieure ne permet pas de recharger
complètement les piles.
8. Etant donné la capacité élevée des piles fournies, le cycle de charge complet (piles
vides -> piles pleines) de celles-ci peut prendre environ 10 heures.
9. Ne rechargez pas les piles lorsque la radio est chaude ou exposée à la chaleur ou
à une source de chaleur.
10. Il est conseillé de nettoyer de temps à autre les contacts métalliques des piles et du
chargeur au moyen d’un spray spécial pour composants électroniques.
11. N’utilisez jamais un mélange d’anciennes piles rechargeables et de piles
rechargeables neuves.
12. N’utilisez jamais un mélange de piles rechargeables et de piles non rechargeables.
13. N’utilisez jamais un mélange de piles rechargeables déchargées et de piles
rechargeables complètement rechargées.
14. N’utilisez jamais un mélange de piles présentant des capacités mAh différentes.
15. N’utilisez jamais des piles endommagées, déformées ou présentant des fuites.
16. Lacapacitapproximativedespilesestafchel'cranLCDdelaradioaumoyen
d’une icône “Pile”. Celle-ci est susceptible de varier en fonction du type de piles
dans la radio.
17. Les piles sont susceptibles de devenir chaudes en cours de recharge.
18. Par temps froid, la capacité des piles sera inférieure à la capacité de celles-ci à
température ambiante normale.
19. Etant donné que les piles sont des consommables, celles-ci ne sont pas couvertes
par la garantie de la radio.
20. Il est conseillé d’utiliser des piles rechargeables PerfectPro, étant donné que la
 radioetlechargeurinternesontconuspourtreutilissaveccelles-ci.
FONCTIONS PRINCIPALES
1. Allumage et extinction de la radio
Appuyez sur la touche ON/OFF pour allumer la radio ou remettre celle-ci en mode
Standby (Veille).
2. Sélection du mode DAB / FM / Bluetooth / AUX IN / USB / SD
Appuyez sur la touche Source (touche de sélection de la source audio) pour
passer d’un mode à l’autre.
3. Réglage de la radio sur la station souhaitée
Tournez le bouton de Fréquence/Recherche (bouton de droite).
4. Réglage du volume
Tournez le bouton de Volume/Tonalité (bouton de gauche).
5. Réglage de la tonalité
Appuyez sur le bouton de Volume/Tonalité (bouton de gauche) pendant environ 3
secondes et tournez ensuite celui-ci pour régler les basses et les aiguës.
6. Connexion de la radio à votre téléphone portable via Bluetooth
Appuyez sur la touche SOURCE pour accéder au mode Bluetooth. Sélectionnez
ensuite la radio “PP Slim 3” dans le menu Bluetooth de votre téléphone portable.
 Unefoisquelenomdutlphoneportables’afchesurl’cranLCD,vouspouvez
commencer à écouter la musique votre téléphone
7. Ecoute de musique à partir d’un téléphone portable connecté à la radio Slim 3
en mode Bluetooth
Appuyez sur les touches REMBOBINER, AVANCE RAPIDE et PLAY/PAUSE
(touches de présélection 3, 4 et 5).
8. Recharge de votre téléphone portable à partir de la radio Slim 3
Raccordez votre téléphone portable à la sortie de courant USB (côté gauche de la
radio) au moyen d’un câble approprié (non fourni).
PREMIERE UTILISATION DE LA RADIO
1. Placez la radio sur une surface plane
2. Dépliez soigneusement l’antenne située sur le dessus de la radio et orientez-la
verticalement par rapport à la radio.
3. Insrezlacheducordond’alimentationdansuneprisedecourant.Laradio
s’allumera automatiquement et le message “WELCOME TO DIGITAL RADIO”
(BIENVENUE SUR LA RADIO NUMERIQUE) apparaîtra à l’écran pendant
quelques secondes. La radio effectuera ensuite automatiquement un balayage de
la bande de fréquences DAB et FM.
F

1110
Programmes secondaires – DAB
1. Certaines stations de radio ont un ou plusieurs programmes secondaires
associé(s). Si une station de radio a un programme secondaire associé, alors
ce programme apparaîtra immédiatement après le premier programme lorsque
vous tournerez le bouton de Fréquence/Recherche.
2. Appuyez sur le bouton de Fréquence/Recherche pour sélectionner le programme
secondaire.
La plupart des programmes secondaires ne sont pas diffusés en continu, et si le
programme sélectionné n’est pas disponible, la radio repassera automatiquement
au programme principal associé.
Afchage en mode DAB
EnmodeDAB,laradioestcapabled’afcherdiversesinformations.
1. Appuyez sur la touche Info pour parcourir les différentes informations disponibles.
a.Textedlant AfchedesmessagesdelastationDABquevous
 coutez,souslaformed’untextedlanttelsque
le nom de l’artiste, le nom du morceau
b.Forcedusignal Afchelaforcedusignalderceptiondelastation
DAB que vous écoutez. Le bloc ouvert indique le
niveau minimum du signal nécessaire pour obtenir
une bonne réception.
c.Typedeprogramme Afcheletypedeprogrammequevouscoutez,
par exemple Pop, Classique, Actualités, etc.
d.Nomdumultiplex AfchelenomdumultiplexauquellastationDAB
appartient.
e.Canaletfrquence Afchelenumroetlafrquencedelastation
DAB que vous écoutez.
f.Dbitbinaireettypeaudio Afcheledbitbinaireetleformataudiode
l’émission.
g.Heureetdate Afchel’heureexacte(format24h)etladate.
Recherche de nouvelles stations en mode DAB
De temps à autre, il se peut que de nouvelles stations DAB soient disponibles. Pour
trouver celles-ci :
1. En mode DAB, appuyez sur la touche Menu. “Full scan” (Balayage complet) sera
 ensuiteafchl’cran.
2. Appuyez sur le bouton de Fréquence/Recherche. La radio effectuera alors un
balayage complet des fréquences de la DAB Bande III.
Lorsque la radio trouve de nouvelles stations DAB, celles-ci seront ajoutées à la
liste des stations DAB disponibles.
4. Les 5 stations FM offrant le meilleur signal de réception et les 5 premières stations
DAB disponibles seront alors mises dans la mémoire de stations présélectionnées.
Après ce premier balayage, la radio s’éteindra automatiquement et l’heure et la
 dateactualisesserontensuiteafchesl’cran.
5. En l'absence de réception d'un signal radio, l'heure et la date ne seront pas
 actualises.Ilpeutalorstrencessairedeplacerlaradiodansunautreendroit
offrant une meilleure réception radio.
MODE DAB
Utilisation de la radio en mode DAB
1. Dépliez soigneusement l’antenne. Appuyez sur la touche ON/OFF pour allumer la
radio.
2. Appuyez sur la touche Source (touche de sélection de la source audio) pour
sélectionner le mode DAB.
3. Lapremirestation(dansl’ordrealphanumrique0...9,A...Z)delalistedestations
 seraalorsaudibleetlenomdelastationseraafchl’cran.
Si la radio a déjà été utilisée, la dernière station sélectionnée sera dans ce cas
audible.
4. Lorsqu’aucun signal radio n’a été trouvé, le message “No stations available”
 (Aucunestationdisponible)seraafchl’cran.Ilpeuttrencessairedans
ce cas de placer la radio dans un autre endroit offrant une meilleure réception. Vous
pouvez ensuite effectuer un Auto Scan pour rechercher des stations DAB. Voir le
point “Recherche de nouvelles stations en mode DAB”.
Sélection d’une station en mode DAB
1. Appuyez sur la touche ON/OFF pour allumer la radio.
2. Appuyez sur la touche Source (touche de sélection de la source audio) pour
sélectionner le mode DAB. Le message “Now tuning” (Syntonisation en cours)
apparaîtra pendant quelques secondes à l’écran.
3. LenomdelastationDABtrouveseraensuiteafchl’cran.
4. Tournez le bouton de Fréquence/ Recherche pour parcourir la liste des stations
DAB disponibles.
5. Lorsque le nom de la station DAB souhaitée apparaît à l’écran, appuyez sur le
bouton de Fréquence/Recherche pour sélectionner la station DAB en question.
 L’cranafchera«Nowtuning»lorsquelaradiotrouveunenouvellestation.
Remarque: Siaprsavoirslectionnerunestation,l’cranafche“Nostations
available”(Aucunestationdisponible),ilpeuttrencessairedanscecasdeplacerla
radio dans un autre endroit offrant une meilleure réception.
F
