Performance Tool W53995 User manual

COMPACT 2 SHELF SERVICE CART
OWNER’S MANUAL
Item Number W53995
WARNING
It is the owner and/or operators’ responsibility to study all WARNINGS, operating, and maintenance
instructions contained on the product label and instruction manual prior to operation of this product. The
owner/operator shall retain product instructions for future reference.
The owner and/or operator are responsible for maintenance, maintaining all decals or warning labels and
while in use, maintaining the unit in good working order. If the owner and/or operator are not fluent in English,
the product warnings and instructions shall be read and discussed with the operators’ native language by the
purchaser/owner or his designee. Make sure that the operator comprehends its contents. Safety information
shall be emphasized and understood prior to usage. The product shall be inspected per the operating
instructions.
Users of this product must fully understand these instructions. Each person operating this product must also
be of sound mind and body and must not be under the influence of any substance that might impair their
vision, dexterity or judgment.
Protect yourself and others by observing all safety information.
Failure to comply with instructions could result in personal injury and/or property damage!
If you encounter any problems or difficulties, please contact our customer service department at:
1-800-426-1262 between 6:30 a.m. and 4:30 p.m. Pacific time.

2
SAFETY GUIDELINES / DEFINITIONS
UNPACKING AND INSPECTION
SPECIFICATIONS
IMPORTANT SAFETY INFORMATION
WARNING
READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS AND WARNINGS BEFORE OPERATING THIS
PRODUCT. FAILURE TO DO SO MAY
RESULT IN FIRE, ELECTRICAL SHOCK, PERSONAL INJURY AND/OR
PROPERTY DAMAGE AND WILL VOID WARRANTY.
1.Always use common sense and pay particular
attention to all the DANGER, WARNING,
CAUTION and NOTICE statements of this
manual. The safety instructions provided are
not intended to cover all possible conditions
and practices that may occur when operating,
maintaining and cleaning power tools.
2.Observe work area conditions. Do not use
machines or power tools in damp or wet
locations. Don’t expose to rain or snow. Keep
work area well lighted. Do not use electrically
powered tools in the presence of ammable
gases or liquids. Do not bring combustible
materials near the tools. Power tools create
sparks, which may ignite the dust or fumes.
Do not immerse tool in liquids. Keep work area
clean, well ventilated and well lit. Cluttered
work areas invite accidents.
3.Use personal protective equipment. Wear
ANSI approved safety goggles. Protective
equipment such as dusk mask, non-skid safety
shoes, hard hat, heavy duty work gloves or
hearing protection used for appropriate condi-
tions will reduce personal injuries.
WARNING: Read and understand this entire instruction manual before attempting to assemble, install, operate or
maintain this product. Failure to comply with the instructions may result in serious personal injury and/or property
damage!
The following signal words are used to emphasize safety warnings that must be followed when using this
product:
This instruction manual is intended for your benefit. Please read and follow the safety, installation, maintenance and troubleshooting steps
described within to ensure your safety and satisfaction. The contents of this instruction manual are based upon the latest product information
available at the time of publication. The manufacturer reserves the right to make product changes at any time without notice.
DANGER Indicates an imminently hazardous situation that, if
not avoided, WILL result in death or serious injury.
WARNING Indicates a potentially hazardous situation that, if
not avoided, COULD result in death or serious injury.
CAUTION Indicates a potentially hazardous situation that, if
not avoided, MAY result in minor or moderate injury.
NOTICE Indicates important information, which if not followed,
MAY cause damage to equipment.
After opening the carton, unpack your new product and related parts & accessories. Please inspect it carefully for
any damage that may have occurred during transit. Please check it against the photograph on carton. If any parts
are missing, please call customer service at 1-800-426-1262 between 6:30 a.m. and 4:30 p.m. Pacific time.
WARNING DO NOT operate this product if damaged during shipment, handling or misuse. Do not operate the product until the parts
have been replaced or the fault rectified. Failure to do so may result in serious personal injury or property damage. All damaged parts
must be repaired or replaced as needed prior to operating this product. Check to see that all nuts, bolts and fittings are secure before
putting this product into service. If you have any questions, or require assistance with damaged or missing parts, please contact our
factory customer service department at: 1-800-426-1262.
Please have the serial number, model number, and date of purchase available for reference when calling.
Specifications are subject to change without notice.
Maximum Weight Capacity: ...................................................... 200 Ibs. (100 lbs. / shelf)
Overall Dimensions: .....19 5/8" (L) x 15 3/4" (W) x 33 7/8" (H)(50 cm x 40 cm x 86 cm)
Net Weight: ...............................................................................................18.7 Ibs. (8.5 kg)
Caster Dimension:....................2 1/2" x 3/4" (6.35 cm x 2 cm); locking (x2), swivel (x2)

3
IMPORTANT SAFETY INFORMATION
4.Keep bystanders, children and visitors away
while operating this product. Distractions can
cause you to lose control.
5.Stay alert. Watch what you are doing, and
use common sense when operating this tool.
Do not use this product while tired or under
the inuence of drugs, alcohol, or medication.
A moment of inattention while operating this
product may result in serious personal injury.
Keep proper footing and balance at all times.
Do not reach over or across running machines,
hoses, cords, etc.
6.Dress properly. Do not wear loose clothing or
jewelry. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jew-
elry or long hair can be caught in moving parts.
7.Work Safe. Operate tool a safe distance from
yourself and others in the work area. Keep
proper footing and balance at all times. Do not
overreach, especially on ladders. Be certain
ladders being used are sturdy, stable, on a rm
surface and erected as safe working angles.
Do not reach over or across running machines,
hoses, cords, etc.
8.Inspect tool before every use; do not use if
parts are loose or damaged.
9.Do not alter this product in any way.
10. Use the right tool for the job. Do not attempt
to force a small tool or attachment to do the
work of a larger industrial tool. Don’t use a
tool whose performance is not adequate for
your work. Do not modify this tool and do not
use this tool for a purpose for which it was
not intended.
11. Make certain caster wheels are locked in
position when the Service Cart is stationary.
12. Do not exceed the maximum weight capacity
of 200 Ibs. (100 lbs. / shelf).
13. Use on a at, level surface capable of sup-
porting the Service Cart and the products
within it.
14. Load tools evenly. As much as possible,
distribute the weight of all tools stored in this
Service Cart evenly.
15. Do not use this Service Cart as a stepping
stool or ladder. Never sit, stand or climb on
this Service Cart.
16. Avoid tipping; do not overload or over-stack
this Service Cart. Overloading can damage
drawers and casters and could possibly
result in tipping and personal injury. Over-
stacking can result in tools or other objects
sliding or falling from the Service Cart
and could result in damaged tools and/or
personal injury.
17. Be aware of dynamic loading! Dropping or
bouncing a load may briey create excess
load causing product damage, severe
personal injury, and/or death.
WARNING: This product and its packaging con-
tain a chemical known to the State of California
to cause cancer, birth defects, or other reproduc-
tive harm.

4
ASSEMBLY
WARNING READ ALL WARNINGS IN THIS MANUAL BEFORE ASSEMBLING AND
OPERATING THIS TOOL CART.
1. Slide Legs (#1) into square holes cut in
Tray (#2) until bolt holes are aligned at
top of Legs(#1).
2. Insert Bolt (#9) and Washer (#10) into
hole on Leg (#1) and Tray (#2). Fasten
Bolt (#9) using Spring Washer (#11) and
Washer (#10), BUT DO NOT TIGHTEN
NUT COMPLETELY AT THIS TIME (#9,
#10, #11, #12). Repeat this procedure
on all four corners.
3. Slide Connect Leg (#3) into square
holes cut in bottom Tray (#2) until bolt
holes are aligned at top of Connect
Legs (#3) (The plastic end should be
placed towards the ground).
4. Repeat Step 2 with bottom Tray (#2).
5. Connect with the Legs (#1, #3).
6. Insert Bolt (#6) and Washer (#8) into
hole on leg (#1) and Connect Leg (#3).
7. Fasten Bolt (#6) using Spring Washer
(#7) and Washer (#8), BUT DO NOT
TIGHTEN NUT COMPLETELY. AT THIS
TIME (#6, #7 #8). Repeat this procedure
on four corners.
8. Insert Casters (#4, #5) into the plastic
end of Connect Leg (#3).
NOTE Insert the two Locking Casters (#5) at
the same end of the cart.
9. Now go back and tighten all loose nut
and bolts. (Suggested torque: 60 in./Ib.)

5
ASSEMBLY
1 Leg 2
2 Tray 2
3 Connect Leg 4
4 2 1/2" Non-locking Castor 2
5 2 1/2" Locking Castor 2
6 Bolt (DIA 5 x 10 mm) 4
7 Spring Washer (DIA 5 mm) 4
8 Washer (DIA 5 mm) 4
9 Bolt (DIA 6 x 42 mm) 8
10 Washer (DIA 6 mm) 16
11 Spring Washer (DIA 6 mm) 8
12 Bolt Nut (DIA 6 mm) 8
# Description Qty.

6
OPERATION
1. Set the Service Cart up in the desired location.
2. Make certain to set both Locking Casters (#5) once the Service Cart is in place. To set the brake,
pull up on the tab located on each Locking Caster (#5).
3. Do not exceed the maximum weight capacity of 200 Ibs. (100 lbs. / shelf)
CARE & MAINTENANCE
WARNING Always lock casters before
attempting cleaning or maintenance.
Clean the Service Cart with a damp cloth. Do not
use abrasives, harsh chemicals or detergents as
these will scratch and damage the components
and frame.
Before each use, inspect the general condition
of the Service Cart. Check for loose screws,
misalignment or binding of moving parts, cracked
or broken parts and any other condition that may
affect its safe operation. Do not use damaged
equipment.

1 YEAR LIMITED WARRANTY
PERFORMANCE TOOL® extends only the following warranties, and only to original retail purchasers. These warranties give specific legal
rights. Except where prohibited by local law, the law of the State of Washington governs all warranties and all exclusions and limitations of
warranties and remedies. There may be other rights which vary from state to state.
PERFORMANCE TOOL® warrants the product to be free from defects in materials and workmanship under normal use and service. A
defective product may be returned for a free replacement within 90 days from the date of purchase, provided that product is returned to
place of purchase immediately after discovery of defect. After 90 days and up to one year from date of purchase, PERFORMANCE TOOL®
will replace at no charge any parts which our examination shall disclose to be defective and under warranty. These warranties shall be valid
only when a sales receipt showing the date of purchase accompanies the defective product or defective part(s) being returned. For part(s)
after 90 days, please remit your request, postage prepaid to:
PERFORMANCE TOOL, P.O. Box 88259 Tukwila, WA 98138
These warranties exclude blades, bits, punches, dies, bulbs, fuses, hoses, and other consumables which must be replaced under normal
use and service. These warranties shall not apply to any product or part which is used for a purpose for which it is not designed, or which
has been repaired or altered in any way so as to affect adversely its performance or reliability, nor shall these warranties apply to any
product or part which has been subject to misuse, neglect, accident or wear and tear incident to normal use and service.
PERFORMANCE TOOL® does not authorize any other person to make any warranty or to assume any liability in connection with its
products.
Except for warranties of title and the limited express warranties set forth above, PERFORMANCE TOOL® makes no express or implied
warranties of any kind with respect to its products. In particular, PERFORMANCE TOOL® makes no implied warranty of merchantability
and no implied warranty of fitness for any particular purpose, except that for goods purchased primarily for personal, family or household
use and not for commercial or business use, PERFORMANCE TOOL® makes an implied warranty of merchantability (and, if otherwise
applicable, an implied warranty of fitness for a particular purpose), but only for the particular qualities or characteristics, and for the
duration, expressly warranted above. The laws on limitation of implied warranties may differ from state to state, so the above limitations
may not apply in all cases.
PERFORMANCE TOOL® shall not be liable for consequential, incidental or special damages resulting from or in any manner related to any
product, or to the design, use, or any inability to use the product. The sole and exclusive remedy for a defective product or part shall be the
repair, or replacement thereof as provided above. The laws on limitation of remedies or on consequential, incidental or special damages
may vary from state to state, so the above limitations may not apply in all cases.
© Copyright 2011 WILMAR CORPORATION, P.O. Box 88259 Tukwila, WA 98138
