Performance Tool W85027 User manual

PNEUMATIC ROLLING BAR STOOL
OWNERS MANUAL
Stock Number W85027
On occasion, after printing of our literature is completed, our manufacturers may make changes and/or modifications to
merchandise which will not be reflected in this manual. Although we strive to maintain complete and accurate
information, it is possible in some instances, that the product may differ slightly from printed specifications. Illustrations
are intended for reference only. Actual merchandise may vary. Wilmar is not responsible for typographical errors.
Please read these instructions carefully and retain them for future use.

2
Capacity: .................................................................................................................................. 250 lbs.
Seat Height:........................................................................................................................... 19 - 24 in.
Casters: .......................................................................................................................................... 2 in.
Seat:................................................................................................... 13 in. diameter x 2-1/4 in. deep
SAFETY GUIDELINES / DEFINITIONS
UNPACKING AND INSPECTION
SPECIFICATIONS
IMPORTANT SAFETY INFORMATION
Specifications are subject to change without notice.
1. DO NOT exceed rated capacity. Overloading the stool can cause
damage to or failure of the stool.
2. Use only on hard, level surface capable of sustaining the load. Use of
stool on other than hard level surfaces can result in stool instability.
3. DO NOT stand on stool. Serious injury can result if the tool tips over
or you accidentally come in contact with the stool.
4. DO NOT expose to heat. Parts of the unit are under pressure.
5. Do not alter this product in any way.
6. Keep your work area clean and well lit. Cluttered work areas invite
accidents.
7. Keep bystanders, children, and visitors away while operating stool.
Distractions can cause you to lose control.
8. Stay alert. Watch what you are doing, and use common sense when
operating a stool. Do not use a stool while tired or under the inu-
ence of drugs, alcohol or medication. A moment of inattention while
operating stool may result in serious personal injury.
9. Store idle stool out of reach of children and other untrained persons.
Stools are dangerous in the hands of untrained users.
10. Stool service must be performed only by qualied repair personnel.
Service or maintenance performed by unqualied personnel could
result in a risk of injury.
11. When servicing a stool, use only identical replacement parts - refer
to attached, product-specic parts list and diagram. Follow instruc-
tions in the Care & Maintenance section of this manual. Use of
unauthorized parts or failure to follow maintenance instructions may
create a risk of injury and may void any applicable warranty.
12. Maintain labels and nameplates on the stool. These carry important
information. If unreadable or missing, contact Performance Tool for
a replacement.
13. The warnings, precautions, and instructions discussed in this
manual cannot cover all possible conditions and situations that
may occur. The operator must understand that common sense and
caution are factors, which cannot be built into this product, but must
be supplied by the operator.
WARNING: This product and its packaging contain a chemical known
to the State of California to cause cancer, birth defects, or other
reproductive harm.
WARNING: Read and understand this entire instruction manual before attempting to assemble, install, operate
or maintain this stool. Failure to comply with the instructions may result in serious personal injury and/or property
damage!
The following signal words are used to emphasize safety warnings that must be followed when using this stool:
WARNING
READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS AND WARNINGS BEFORE OPERATING THIS
EQUIPMENT. FAILURE TO DO SO MAY RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE AND
WILL VOID WARRANTY.
This instruction manual is intended for your benefit. Please read and follow the safety, installation, maintenance and troubleshooting steps
described within to ensure your safety and satisfaction. The contents of this instruction manual are based upon the latest product information
available at the time of publication. The manufacturer reserves the right to make product changes at any time without notice.
DANGER Indicates an imminently hazardous situation that, if
not avoided, WILL result in death or serious injury.
WARNING Indicates a potentially hazardous situation that, if
not avoided, COULD result in death or serious injury.
CAUTION Indicates a potentially hazardous situation that, if
not avoided, MAY result in minor or moderate injury.
NOTICE Indicates important information, which if not
followed, MAY cause damage to equipment.
After opening the carton, unpack your stool and related parts & accessories. Please inspect it carefully for any
damage that may have occurred during transit. Please check it against the photograph on carton. If any parts are
missing, please call customer service at 1-800-426-1262 between 6 a.m. and 5 p.m. Pacific time.
WARNING DO NOT operate this stool if damaged during shipment, handling or misuse. Do not operate the stool until the parts
have been replaced or the fault rectified. Failure to do so may result in serious personal injury or property damage. All damaged parts
must be repaired or replaced as needed prior to operating this stool. Check to see that all nuts, bolts and fittings are secure before
putting this stool into service. If you have any questions, or require assistance with damaged or missing parts, please contact our
factory customer service department at: 1-800-426-1262.
Please have the serial number, model number, and date of purchase available for reference when calling.

3
PACKAGING CONTENTS
# Description Quantity
1 Padded Seat 1
2 Base Frame 1
3 Pneumatic Cylinder 1
4 Seat Bracket/Handle 1
5 Base Cover 1
6 Caster Wheels 5
7 M6 x 12 Machine Screws 4
1
4
5
6
1
2
3
4
5
6
7
Seat
Black plate
Screw (4pcs)
Lifter
Plastic cover
Base
Caster(5pcs)
2
3
7
1. Place the Seat Bracket (4) on the underside of the Padded Seat (1). Align the holes in the Seat
Bracket (4) with the 4 holes in the center of the Padded Seat (1) and hand tighten with the 4
machine screws (7). Use a #2 phillips screwdriver for nal tightening.
2. Hand thread the 5 Caster Wheels (6) onto Base Frame (2). Tighten with a 14 mm open end or
adjustable wrench.
3. Place the Base Cover (5) over the center of the Base Frame (2).
4. Insert the Pneumatic Cylinder (3) into the center opening in the Base Frame (2), then place the
Seat assembly from step 1 onto the thinner end of the Pneumatic Cylinder (3). Press down to
ensure a tight and secure t.
ASSEMBLY INSTRUCTIONS

LIMITED WARRANTY
PERFORMANCE TOOL® extends only the following warranties, and only to original retail purchasers. These warranties
give specific legal rights. Except where prohibited by local law, the law of the State of Washington governs all
warranties and all exclusions and limitations of warranties and remedies. There may be other rights which vary from
state to state.
PERFORMANCE TOOL® warrants the product to be free from defects in materials and workmanship under normal use
and service. A defective product may be returned for a free replacement within 90 days from the date of purchase,
provided that product is returned to place of purchase immediately after discovery of defect. After 90 days and up to
one year from date of purchase, PERFORMANCE TOOL® will replace at no charge any parts which our examination
shall disclose to be defective and under warranty. These warranties shall be valid only when a sales receipt showing
the date of purchase accompanies the defective product or defective part (s) being returned. For part (s) after 90 days,
please remit your request, postage prepaid to:
PERFORMANCE TOOL, P.O. Box 88259 Tukwila, WA 98138
These warranties exclude blades, bits, punches, dies, bulbs, fuses, hoses, and other consumables which must be
replaced under normal use and service. These warranties shall not apply to any product or part which is used for a
purpose for which it is not designed, or which has been repaired or altered in any way so as to affect adversely its
performance or reliability, nor shall these warranties apply to any product or part which has been subject to misuse,
neglect, accident or wear and tear incident to normal use and service.
PERFORMANCE TOOL® does not authorize any other person to make any warranty or to assume any liability in
connection with its products.
Except for warranties of title and the limited express warranties set forth above, PERFORMANCE TOOL® makes no
express or implied warranties of any kind with respect to its products. In particular, PERFORMANCE TOOL® makes no
implied warranty of merchantability and no implied warranty of fitness for any particular purpose, except that for goods
purchased primarily for personal, family or household use and not for commercial or business use, PERFORMANCE
TOOL® makes an implied warranty of merchantability (and, if otherwise applicable, an implied warranty of fitness for a
particular purpose), but only for the particular qualities or characteristics, and for the duration, expressly warranted
above.
The laws on limitation of implied warranties may differ from state to state, so the above limitations may not apply in all
cases.
PERFORMANCE TOOL® shall not be liable for consequential, incidental or special damages resulting from or in any
manner related to any product, or to the design, use, or any inability to use the product. The sole and exclusive remedy
for a defective product or part shall be the repair, or replacement thereof as provided above. The laws on limitation of
remedies or on consequential, incidental or special damages may vary from state to state, so the above limitations may
not apply in all cases.
© Copyright 2016 WILMAR CORPORATION, P.O. Box 88259 Tukwila, WA 98138
