Perkins Peregrine
Models WG and WJ
USER’S HANDBOOK
Six cylinder turbocharged diesel engines for automotive
applications
Publication TPD 1314E, Issue 4.
(c) Perkins Group Limited 1997, all rights reserved.
The information is correct at the time of print.
Published in July 1997 by Technical Publications,
Perkins International Limited, Peterborough PE1 5NA, England
This document has been printed from SPI². Not for Resale

ii
This publication is written in
Perkins Approved Clear English
This publication is divided into six chapters:
1 General information
2 Engine views
3 Operation instructions
4 Preventive maintenance
5 Engine fluids
6 Fault diagnosis
The following pages contain a detailed table of contents
This document has been printed from SPI². Not for Resale

User’s Handbook, TPD 1314E, issue 4 iii
Peregrine Models WG and WJ
Contents
1 General information
Introduction . ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... .. 1
Safety precautions .. ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... .. 2
How to care for your engine ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... .. 3
Engine preservation ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... .. 4
Parts and service ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... .. 5
POWERPART recommended consumable products .. ... ... ... ... ... ... ... ... ... ... ... ... ... .. 6
Service literature . ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... .. 8
Training ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... .. 8
Engine identification ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... .. 9
Engine data . ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 10
2 Engine views
Introduction . ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 11
Location of engine parts .. ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 11
3 Operation instructions
How to start the engine ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 13
How to start a warm engine ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 14
How to start a cold engine .. ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 15
How to start an engine with an ether start system .. ... ... ... ... ... ... ... ... ... ... ... ... ... ... 16
How to stop the engine ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 17
Adjustment of engine speed range . ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 17
Engine operation at idle speed ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 17
This document has been printed from SPI². Not for Resale

iv User’s Handbook, TPD 1314E, issue 4
Peregrine Models WG and WJ
Running-in ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 18
Altitude . ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 18
4 Preventive maintenance
Preventive maintenance periods . ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 19
Schedules ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 20
How to drain the cooling system .. ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 21
How to fill the cooling system .. ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 22
How to renew the canister of the coolant filter / inhibitor . ... ... ... ... ... ... ... ... ... ... ... ... 23
How to check the drive belt . ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 24
How to renew the drive belt . ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 24
Fuel pre-filter ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 25
How to renew the fuel strainer and the canister of the fuel filter .. ... ... ... ... ... ... ... ... ... 25
Atomiser fault ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 26
How to renew an atomiser ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 27
How to eliminate air from the fuel system ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 28
How to renew the lubricating oil ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 29
How to renew the canister of the lubricating oil filter ... ... ... ... ... ... ... ... ... ... ... ... ... ... 30
Air filter ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 31
Restriction indicator . ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 31
How to set the valve tip clearances . ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 32
5 Engine fluids
Fuel specification . ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 33
Lubricating oil specification .. ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 34
Coolant specification ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 35
6 Fault diagnosis
Problems and possible causes ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 37
List of possible causes ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 38
This document has been printed from SPI². Not for Resale

User’s Handbook, TPD 1314E, issue 4 1
1
Peregrine Models WG and WJ
General information 1
Introduction
The Peregrine is a new family of engines for automotive applications from Perkins Engines Limited, a world
leader in the design and manufacture of high performance diesel engines.
Perkins approved assembly and quality standards, together with the latest technology, have been applied to
the manufacture of your engine to give you reliable and economic power.
To ensure that you use the relevant information for your specific engine type, refer to "Engine identification"
on page 9.
Danger is indicated in the text by two methods:
Warning! This indicates that there is a possible danger to the person.
Caution: This indicates that there is a possible danger to the engine.
Note: Is used where the information is important, but there is not a danger.
A
This document has been printed from SPI². Not for Resale

1
2User’s Handbook, TPD 1314E, issue 4
Peregrine Models WG and WJ
Safety precautions
These safety precautions are important.
You must refer also to the local regulations in the country of use. Some items only apply to specific
applications.
Only use these engines in the type of application for which they have been designed.
zDo not change the specification of the engine.
zDo not smoke when you put fuel in the tank.
zClean away fuel which has been spilt. Material which has been contaminated by fuel must be moved to a
safe place.
zDo not put fuel in the tank while the engine runs (unless it is absolutely necessary).
zDo not clean, add lubricating oil, or adjust the engine while it runs (unless you have had the correct training;
even then extreme caution must be used to prevent injury).
zDo not make adjustments that you do not understand.
zEnsure that the engine does not run in a location where it can cause a concentration of toxic emissions.
zOther persons must be kept at a safe distance while the engine or auxiliary equipment is in operation.
zDo not permit loose clothing or long hair near moving parts.
zKeep away from moving parts during engine operation.
Warning! Some moving parts cannot be seen clearly while the engine runs.
zDo not operate the engine if a safety guard has been removed.
zDo not remove the filler cap of the cooling system while the engine is hot and while the coolant is under
pressure, because dangerous hot coolant can be discharged.
zDo not use salt water or any other coolant which can cause corrosion in the closed coolant circuit.
zDo not allow sparks or fire near the batteries (especially when the batteries are on charge) because the
gases from the electrolyte are highly flammable. The battery fluid is dangerous to the skin and especially
to the eyes.
zDisconnect the battery terminals before a repair is made to the electrical system.
zOnly one person must control the engine.
zEnsure that the engine is operated only from the control panel or from the operator's position.
zIf your skin comes into contact with high-pressure fuel, obtain medical assistance immediately.
zDiesel fuel and lubricating oil (especially used lubricating oil) can damage the skin of certain persons.
Protect your hands with gloves or a special solution to protect the skin.
zDo not wear clothing which is contaminated by lubricating oil. Do not put material which is contaminated
with oil into the pockets.
zDiscard used lubricating oil in a safe place to prevent contamination.
zEnsure that the control lever of the transmission drive is in the "out-of-drive" position before the engine is
started.
zThe combustible material of some components of the engine (for example certain seals) can become
extremely dangerous if it is burned. Never allow this burnt material to come into contact with the skin or with
the eyes.
zAlways use a safety cage to protect the operator when a component is to be pressure tested in a bath of
water. Fit safety wires to secure the plugs which seal the hose connections of a component which is to be
pressure tested.
Continued
This document has been printed from SPI². Not for Resale

1
User’s Handbook, TPD 1314E, issue 4 3
Peregrine Models WG and WJ
zDo not allow compressed air to contact your skin. If compressed air enters your skin, obtain medical help
immediately.
zTurbochargers operate at high speed and at high temperatures. Keep fingers, tools and other objects away
from the inlet and outlet ports of the turbocharger and avoid contact with hot surfaces.
zFit only genuine Perkins parts.
How to care for your engine
This handbook has been written to assist you to maintain and operate your engine correctly.
To obtain the best performance and the longest life from your engine, you must ensure that the maintenance
operations are done at the intervals indicated in Chapter 4, Preventive maintenance. If the engine works in a
very dusty environment or other adverse conditions, certain maintenance intervals will have to be reduced.
Renew the filter canisters and lubricating oil regularly in order to ensure that the inside of your engine remains
clean.
Ensure that all adjustments and repairs are done by personnel who have had the correct training. Perkins can
provide training at the Perkins Customer Training Department, Peterborough.
The terms "left side" and "right side" apply when the engine is seen from the flywheel end.
Warning! Read the "Safety precautions" on page 2 and remember them. They are given for your protection
and must be applied at all times.
This document has been printed from SPI². Not for Resale

1
4User’s Handbook, TPD 1314E, issue 4
Peregrine Models WG and WJ
Engine preservation
Introduction
The recommendations indicated below are designed to prevent damage to the engine when it is withdrawn
from service for a prolonged period. Use these procedures after the engine is withdrawn from service. The
instructions for the use of POWERPART products are given on the outside of each container.
Procedure
1 Completely clean the outside of the engine.
2 When a preservative fuel is to be used, drain the fuel system and fill it with the preservative fuel.
POWERPART Lay-Up 1 can be added to the normal fuel to change it to a preservative fuel. If preservative fuel
is not used, the system can be completely filled with normal fuel but the fuel must be drained and discarded at
the end of the storage period together with the fuel filter canister.
3 Operate the engine until it is warm. Then correct leakages of fuel, lubricating oil or air. Stop the engine and
drain the lubricating oil from the sump.
4 Renew the canister of the lubricating oil filter.
5 Fill the sump to the full mark with new and clean lubricating oil and add POWERPART Lay-up 2 to the oil to
protect the engine against corrosion. If POWERPART Lay-Up 2 is not available, use a correct preservative
fluid instead of the lubricating oil. If a preservative fluid is used, this must be drained and the lubricating oil
sump must be filled to the correct level with normal lubricating oil at the end of the storage period.
6 Drain the coolant system, see "How to drain the cooling system" on page 21. In order to protect the cooling
system against corrosion, fill it with an approved antifreeze mixture because this gives protection against
corrosion, see "Coolant specification" on page 35.
Caution: If protection against frost is not necessary and a corrosion inhibitor is to be used, it is recommended
that you consult the Technical Service Department, Perkins Sales and Service Limited, Peterborough.
7 Operate the engine for a short period in order to circulate the lubricating oil and the coolant in the engine.
8 Clean the engine breather pipe and seal the end of the pipe.
9 Remove the atomisers and spray POWERPART Lay-Up 2 for one to two seconds into each cylinder bore
with the piston at bottom dead centre. Slowly turn the crankshaft one revolution and then fit the atomisers,
complete with new seat washers.
10 Disconnect the air inlet pipe at the rocker cover. Release the cap screws and remove the rocker cover.
Spray POWERPART Lay-Up 2 around the rocker shaft assembly and into the induction ports in the cylinder
head, as indicated on the container label. Fit the rocker cover and connect the air inlet pipe.
Remove the air filter. Then, if necessary, remove the pipe(s) installed between the air filter and the
turbocharger. Seal the air inlet to the turbocharger with waterproof tape.
Continued
This document has been printed from SPI². Not for Resale

1
User’s Handbook, TPD 1314E, issue 4 5
Peregrine Models WG and WJ
11 Remove the exhaust pipe. Spray POWERPART Lay-Up 2 into the turbocharger. It is recommended that
the spray time for the turbocharger is 50% longer than the spray time for the manifold, which is indicated on
the container label. Seal the turbocharger with waterproof tape.
12 Disconnect the battery. Then put the battery into safe storage in a fully charged condition. Before the
battery is put into storage, protect its terminals against corrosion. POWERPART Lay-Up 3 can be used on the
terminals.
13 Seal the vent pipe of the fuel tank or the fuel filler cap with waterproof tape.
14 Remove the drive belts and put them into storage.
15 In order to prevent corrosion, spray the engine with POWERPART Lay-Up 3. Do not spray the area inside
the alternator cooling fan.
Caution: After a period in storage, but before the engine is started, operate the starter motor with the engine
stop control in the "stop" position until oil pressure is indicated. Oil pressure can be indicated either by a gauge
or when a low pressure warning light is extinguished. If a solenoid stop control is used on the fuel injection
pump, it must be disconnected for this operation.
If the engine protection is done correctly according to the above recommendations, no corrosion damage will
normally occur. Perkins are not responsible for damage which may occur when an engine is in storage after a
period in service.
Parts and service
If problems occur with your engine or with the components fitted onto it, your Perkins distributor can make the
necessary repairs and will ensure that only the correct parts are fitted and that the work is done correctly.
Certain components can be supplied by your Perkins distributor through the Perkins POWER COMPONENTS
system. These will enable you to reduce the cost of certain repairs.
This document has been printed from SPI². Not for Resale

1
6User’s Handbook, TPD 1314E, issue 4
Peregrine Models WG and WJ
POWERPART recommended consumable products
Perkins have made available the products recommended below in order to assist in the correct operation,
service and maintenance of your engine and your machine. The instructions for the use of each product are
given on the outside of each container. These products are available from your Perkins distributor.
POWERPART Antifreeze
Protects the cooling system against frost and corrosion. Part number 1 litre 21825166 or 5 litres 21825167.
POWERPART Atomiser thread sealant
To seal the threads of the atomiser into the cylinder head. Currently Hylomar Advance Formulation.
POWERPART Chisel
Allows easy removal of old gaskets and joints. Currently Loctite chisel. Part number 21825163.
POWERPART Compound
To seal the outer diameter of seals. Currently Loctite Forma Gasket No 2. Part number 1861147.
POWERPART Easy Flush
Cleans the cooling system. Part number 2182501.
POWERPART Gasket eliminator
Improves flange sealing when a gasket is not used. It provides a seal with temperature resistance that is
flexible in positions where vibration and pressure occur. Currently Loctite 515. Part number 21826040.
POWERPART Jointing compound
Universal jointing compound which seals joints. Currently Hylomar. Part number 1861155 or 1861117.
POWERPART Lay-Up 1
A diesel fuel additive for protection against corrosion. Part number 1772204.
POWERPART Lay-Up 2
Protects the inside of the engine and of other closed systems. Part number 1762811.
POWERPART Lay-Up 3
Protects outside metal parts. Part number 1734115.
POWERPART Liquid gasket
To seal flat faces of components where no joint is used. Especially suitable for aluminium components.
Currently Loctite 518. Part number 21820518.
POWERPART Nutlock
To retain and seal threaded fasteners and cup plugs where easy removal is necessary. Currently Loctite 242e.
Part number 21820242
POWERPART Platelock
Medium strength anaerobic threadlock for tight fitted metal surfaces. Suitable for metal plated surfaces and
stainless steel. Currently Loctite 243. Part number 21826039.
Continued
This document has been printed from SPI². Not for Resale

1
User’s Handbook, TPD 1314E, issue 4 7
Peregrine Models WG and WJ
POWERPART Repel
Dries damp equipment and gives protection against corrosion. Passes through dirt and corrosion to lubricate
and to assist removal of components. Currently Loctite repel. Part number 21825164.
POWERPART Retainer (high strength)
To retain components which have an interference fit. Currently Loctite 638. Part number 21820638.
POWERPART Retainer (oil tolerant)
To retain components which have a transition fit. Currently Loctite 603. Part number 21820603.
POWERPART Silicone adhesive
An RTV silicone adhesive for application where low pressure tests occur before the adhesive sets. Used for
sealing flange where oil resistance is needed and movement of the joint occurs. Currently Loctite 5900. Part
number 21826038.
POWERPART Silicone rubber sealant
Silicone rubber sealant which prevents leakage through gaps. Currently Hylosil. Part number 1861108.
POWERPART Studlock
To permanently retain large fasteners and studs. Currently Loctite 270. Part number 21820270.
POWERPART Threadlock
To retain small fasteners where easy removal is necessary. Currently Loctite 222e. Part number 21820222.
POWERPART Threadlock (heavy duty)
To provide a heavy duty seal to components that have a light interference fit. Currently Loctite 262. Part
number 21820262.
POWERPART Threadlock (hydraulic/pnuematic)
To retain and seal pipe connections with fine threads. Especially suitable for hydraulic and pneumatic systems.
Currently Loctite 542. Part number 21820542.
POWERPART Threadlock (pipe)
To retain and seal pipe connections with coarse threads. Pressure systems can be used immediately.
Currently Loctite 575. Part number 21820575.
This document has been printed from SPI². Not for Resale

1
8User’s Handbook, TPD 1314E, issue 4
Peregrine Models WG and WJ
Service literature
Workshop manuals, installation drawings and other service publications are available. For further information
contact Technical Service, Perkins Group of Companies Limited, Peterborough.
Training
Local training for the correct operation, service and overhaul of engines is available at certain Perkins
distributors. If special training is necessary, contact the Perkins Customer Training Department, Peterborough.
This document has been printed from SPI². Not for Resale

1
User’s Handbook, TPD 1314E, issue 4 9
Peregrine Models WG and WJ
Engine identification
The Peregrine family consists of a range of six cylinder in-line engines which are turbocharged and intercooled.
In this handbook, the different engine types are indicated by their code letters, which are the first two letters of
the engine number as indicated below:
The engine number is stamped on the left side of the cylinder block, (A1). An example of an engine number is
WJ1296N123456.
The components of the engine number are as follows:
WJ1296N123456
WJ = Type code letters
1296 = Build list number
N = Built in the USA
123456 = Engine serial number
If you need parts, service or information for your engine, you must give the complete engine number to your
Perkins distributor.
Code letters Capacity Aspiration system
Litre in3
WG 7,6 466 Turbocharged / intercooled
WJ 8,6 531 Turbocharged / intercooled
A
1
This document has been printed from SPI². Not for Resale

1
10 User’s Handbook, TPD 1314E, issue 4
Peregrine Models WG and WJ
Engine data
Number of cylinders ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ..6
Cylinder arrangement ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... .. In line
Cycle .. ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ..Four stroke
Induction system ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... Turbocharged/intercooled
Combustion system ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... Direct injection
Nominal bore:
W ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 109,2 mm (4.301 in)
WJ.. ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 116,6 mm (4.590 in)
Stroke:
WG and WJ ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 135,9 mm (5.350 in)
Compression ratio.. ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ..16.5:1
Cubic capacity:
WG. ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... .. 7,64 litres (466.4 in3)
WJ.. ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... .. 8,71 litres (531.0 in3)
Firing order. ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ..1, 5, 3, 6, 2, 4
Valve tip clearances (cold):
- Inlet.. ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ..0,64 mm (0.025 in)
- Exhaust ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ..0,64 mm (0.025 in)
Lubricating oil pressure.. ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... .. 345 kN/m2 (50 lbf/in2) 3,5 kgf/cm2
(maximum engine speed and normal engine temperature)
Capacity of a typical lubricating oil sump (1):
- Without filter canister ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... . 20,8 litres (36.6 UK pints) 22 US quarts
- With filter canister ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... . 26,4 litres (46.5 UK pints) 28 US quarts
Typical coolant capacity (engine only) ... ... ... ... ... ... ... ... ... ... ... .. 12,8 litres (22.5 UK pints) 13,5 US quarts
Direction of rotation ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... . Clockwise from the front
(1) The capacity of the sump may vary according to the application. Fill to the "Full" mark on the dipstick. Do not exceed the "Full" mark.
This document has been printed from SPI². Not for Resale

User’s Handbook, TPD 1314E, issue 4 11
2
Peregrine Models WG and WJ
Engine views 2
Introduction
Perkins engines are built for specific applications and the views which follow do not necessarily match your
engine specification.
Location of engine parts
Front and left side view
1Atomiser
2 Lubricating oil filler and dipstick
3 Fuel priming pump
4 Fuel strainer
5 Canister for the fuel filter
6 Starter motor
7 Sump for the engine lubricating oil
8 Crankshaft damper
9 Compressor
10 Drive belt
11 Fan
12 Fuel injection pump
A
7
8
9
10
11
12
6
5
3
2
1
4
This document has been printed from SPI². Not for Resale

2
12 User’s Handbook, TPD 1314E, issue 4
Peregrine Models WG and WJ
Rear and right side view
13 Front lift bracket
14 Alternator
15 Tensioner for the drive belt
16 Canister for the coolant filter / inhibitor
17 Coolant pump
18 Coolant inlet connection
19 Lubricating oil cooler
20 Canister for the lubricating oil filter
21 Flywheel housing
22 Flywheel
23 Turbocharger
24 Rear lift bracket
25 Rocker cover and induction manifold
26 Air inlet connection
A
20
21
22
23
24
25
26
19
18
17
16
15
14
13
This document has been printed from SPI². Not for Resale

User’s Handbook, TPD 1314E, issue 4 13
3
Peregrine Models WG and WJ
Operation instructions 3
How to start the engine
Several factors affect engine start, for example:
zThe power of the batteries
zThe performance of the starter motor
zThe viscosity of the lubricating oil
zThe installation of a cold start system
The engine will start with the fuel injection pump in excess fuel at temperatures as low as -20 °C (-4 °F). In
conditions where the temperature is lower than this, an ether start system may be necessary.
Before the engine is started the operator should understand fully the reason for the controls and their use.
Before the engine is started:
zCheck that there is sufficient coolant and, if necessary, add the correct coolant. See Chapter 4, Preventive
maintenance.
zCheck that there is sufficient lubricating oil in the sump and, if necessary, add lubricating oil. See Chapter
4, Preventive maintenance. Ensure that the lubricating oil is of the correct grade for the ambient conditions.
zFill the fuel tank with fuel of the correct specification.
zCheck the air filter and its connections.
zEnsure that all of the electrical connections are tight.
Notes:
zSee Chapter 5, Engine fluids for the correct engine fluids.
zThe procedures to start the engine may vary according to the application. If possible, consult the User's
Handbook for the application.
Caution: If the engine has not run for several weeks, see Caution on page 5.
This document has been printed from SPI². Not for Resale

3
14 User’s Handbook, TPD 1314E, issue 4
Peregrine Models WG and WJ
How to start a warm engine
Ambient temperature more than 15°C (60°F)
1 Apply the hand brake. Ensure that the transmission is in the out-of-drive position. Ensure that the engine
speed control is in the minimum speed position.
2 If the engine is equipped with a manual stop control, ensure that it is in the "run" position.
3 Turn the start key to the "ON" position.
4 Continue to turn the start key to engage the starter motor. If the application has a start button, press and
hold the button.
5 Release the start key (or the button) as soon as the engine starts. The start key will return to the "ON"
position.
Caution: Caution: If the engine does not start within 30 seconds, release the start key and wait two to three
minutes to allow the starter motor to cool. If after three tries the engine does not start, turn the key to the "OFF"
position and locate and correct the problem. Always ensure that the engine and starter motor are stationary
before the starter motor is engaged again.
6 When the engine starts check that the lubricating oil pressure exceeds 69 kPa (10 lbs/in2) 0,70 kgf/cm2
within the first 10 seconds (see "Engine data" on page 10 for the correct lubricating oil pressure). If a gauge is
not fitted, check that the warning light for low oil pressure is extinguished. If this does not occur, stop the engine
and find and correct the fault. Allow the engine to warm at approximately 1000 rev/min for three to five minutes
before load is applied.
This document has been printed from SPI². Not for Resale

3
User’s Handbook, TPD 1314E, issue 4 15
Peregrine Models WG and WJ
How to start a cold engine
Ambient temperatures from +15°C (+60°F) to -20°C (-4°F)
1 Apply the hand brake. Ensure that the transmission is in the out-of-drive position.
2 Ensure that the engine speed control is in the minimum speed position.
Engines equipped with a manual stop control: Ensure that the manual stop control is in the "run" position. Then
adjust the engine speed control to the maximum speed position.
3 Turn the start key to the "ON" position.
4 Continue to turn the start key to engage the starter motor. If the application has a start button, press and
hold the button. If the engine is equipped with an electrical stop control, move the engine speed control to the
maximum speed position after the starter motor is engaged.
5 Release the start key (or the button) as soon as the engine starts. The start key will return to the "ON"
position. Then release the engine speed control.
6 When the engine starts check that the lubricating oil pressure exceeds 69 kPa (10 lbs/in2) 0,70 kgf/cm2
within the first 10 seconds (see "Engine data" on page 10 for the correct lubricating oil pressure). If a gauge is
not fitted, check that the warning light for low oil pressure is extinguished. If this does not occur, stop the engine
and find and correct the fault. Allow the engine to warm at approximately 1000 rev/min for three to five minutes
before load is applied.
Caution: If the engine does not start within 30 seconds, release the start key and wait two to three minutes to
allow the starter motor to cool. If after three tries the engine does not start, turn the key to the "OFF" position
and locate and correct the problem. Always ensure that the engine and starter motor are stationary before the
starter motor is engaged again.
This document has been printed from SPI². Not for Resale

3
16 User’s Handbook, TPD 1314E, issue 4
Peregrine Models WG and WJ
How to start an engine with an ether start system
Ambient temperature below -20°C (-4°F)
Warning! Ether is very flammable and is toxic. Apply the safety precautions on the container for the use and
storage of ether and for the disposal of empty containers.
1 Apply the hand brake. Ensure that the transmission is in the out-of-drive position. Ensure that the engine
speed control is in the minimum speed position. Check the ether container to ensure that a supply of ether is
available under pressure.
2 If the engine is equipped with a manual stop control, ensure that it is in the "run" position.
3 Ensure that the engine speed control is still in the idle position.
4 Turn the start key to the "ON" position.
5 Continue to turn the start key (or press the start button, if one is fitted) to engage the starter motor and at
the same time press the ether injection button. Allow one to two seconds for the ether injection system to fill
then release the injection button to release a measured amount of ether into the engine. While the engine is
still at cranking speed move the engine speed control to the maximum speed position.
Caution: Release of ether into the cylinders before the starter motor is engaged may cause damage to the
pistons and piston rings.
6 Release the start key (or the start button, if one is fitted) as soon as the engine starts. The start key will return
to the "ON" position. Then release the engine speed control.
Caution: If the engine does not start within 30 seconds, release the start key and wait two to three minutes to
allow the starter motor to cool. If after three tries the engine does not start, turn the key to the "OFF" position
and locate and correct the problem. Always ensure that the engine and starter motor are stationary before the
starter motor is engaged again.
Note: In extremely cold conditions, it is permissible to inject further ether into the engine if the engine runs
roughly after the initial start.
Caution: Do not inject ether into a warm engine.
7 When the engine starts check that the lubricating oil pressure exceeds 69 kPa (10 lbs/in2) 0,70 kgf/cm2
within the first 25 seconds (see "Engine data" on page 10 for the correct lubricating oil pressure). If a gauge is
not fitted, check that the warning light for low oil pressure is extinguished. If this does not occur, stop the engine
and find and correct the fault. Allow the engine to warm at approximately 1000 rev/min for three to five minutes
before load is applied.
This document has been printed from SPI². Not for Resale
