Perle IDS-108FPP series User manual

Perle IDS-108FPP (XT)
Unmanaged 10/100 PoE/PoE+
Ethernet Switches with Fiber Ports
P/N 5500341-10 (Rev I)
Installation Guide

IDS-108FPP Installation Guide 2
Overview
This document contains instructions necessary for the
installation and operation of the Perle IDS-108FPP
unmanaged Ethernet switch. This Ethernet switch is a
8-port RJ-45 switch with PoE/PoE+ capabilities on
ports one through four. The PoE/PoE+ Ethernet ports
function as (PSE) Power Sourcing Equipment and can
each independently power a PD (Powered Device)
using standard UTP cables that carry Ethernet data.
Powered Devices must comply with the IEEE 802.3af
or the 802at-2009 standard for PoE or PoE+ devices.
The IDS-108FPP is available in various copper and
fiber configurations (see table below). The fiber ports
can be either single mode (SM) or multimode (MM)
depending on the model selected and can operate over
different wavelengths and distances. Visit the Perle
website for the most up to date installation guides,
models and specifications.
http://www.perle.com/
Note: xxxxxxxx(XT) indicates models numbers for this
product line.
TP = twisted pair
XT = Industrial Temperature models
Model Port 1-4 Port 5 - 8 Port 9 and 10
IDS-108FPP TP (RJ-45)
PoE/PoE+
TP (RJ-45) empty
IDS-108FPP-xxxxxxxx TP (RJ-45)
PoE/PoE+
TP (RJ-45) 1 or 2 fiber ports
(SC or ST)
IDS-108FPP-XT
(Industrial Temperature
Model)
TP (RJ-45)
PoE/ PoE+
TP (RJ-45) empty
IDS-108FPP-xxxxxxxx-XT
(Industrial Temperature
Model)
TP (RJ-45)
PoE/PoE+
TP (RJ-45) 1 or 2 fiber ports
(SC or ST)

IDS-108FPP Installation Guide 3
Features
•8 port 10/100Base-TX (RJ-45), with 1 or 2 fiber
ports (SC/ST), multi/single mode
•4 PoE/PoE+ PSE capable ports, fully compliant to
IEEE 802.3af/at
•Redundant DC power inputs 18-57 VDC
•Rugged, high strength IP30 aluminum case
•Industrial temperature models
•Din-rail or wall/panel mounting
Note – In this guide the various models will be referred to as
the IDS-108FPP
Getting to know your IDS-108FPP
Switch
Package Contents:
•IDS-108FPP
•DIN-rail mounting clip (pre-installed on the unit)
•This guide
Note – optional panel/wall mounting kits may be ordered for
the IDS-108FPP switch

IDS-108FPP Installation Guide 4
Front View of IDS-108FPP (8 port RJ-45)

IDS-108FPP Installation Guide 5
Front View of IDS-108FPP ( with one or two
fiber ports)

IDS-108FPP Installation Guide 6
Bottom view of the IDS-108FPP (with two ST
fiber ports installed)
Top view of the IDS-108FPP
The IDS-108FPP switch has two power inputs that can
be connected simultaneously. If one power source fails,
the other source acts as a backup, and automatically
powers the switch.

IDS-108FPP Installation Guide 7
Status LED (with two fiber ports)
P1 / P2– Power (Green LED)
•On: Power present
•Off: No Power present
9 / 10 (Port 9 / 10 – Fiber) (Green LED)
•On: Link up
•Flashing: Link up and Ethernet activity detected
•Off: Link down
Ethernet Port Status
Port Link / Speed (Green and Yellow LEDs)
Port Link (Green LED)
•On: Link up
•Flashing: Link up and Ethernet activity detected
Port Speed (Yellow LED)
•On: communicating at 100 Mbps
•Off: communicating at 10 Mbps

IDS-108FPP Installation Guide 8
Views for the IDS-108FPP

IDS-108FPP Installation Guide 9

IDS-108FPP Installation Guide 10
Mounting the IDS-108FPP on a DIN-rail
1. The DIN-rail clip will be fixed to the back panel of
the IDS-108FPP switch when you receive the
product.
2. Position the IDS-108FPP such that the top of the
DIN rail fits into the slot on the top of the DIN-rail
clip, just below the DIN-rail hook and behind the
spring.
3. While pushing down on the unit to compress the
spring, rotate the bottom of the IDS-108FPP toward
the rail. This will snap the bottom of the rail into the
bottom of the clip. See diagram below.
Note: To remove the IDS-108FPP from the DIN-rail,
push down slightly on the IDS-108FPP unit while
pulling the bottom out.

IDS-108FPP Installation Guide 11
Wall Mounting the IDS-108FPP
1. Remove the DIN-rail clip from the rear panel on the
IDS-108FPP.
2. Attach the wall mount plates to the IDS-108FPP as
shown below using the screws provided in the kit.
3. Use the wall mount plates as a guide to mark the
spots where the screws will be.
4. Drive the screws into the wall leaving about 2 mm of
the screw protruding from the wall to allow room for
sliding the wall mount panel between the wall and
the screws.
5. Fix the screws to the wall and then insert the four
screw heads through the large parts of the keyhole
shaped screw openings.
6. Pull the IDS down to lock the IDS-108FPP to the
wall mount.
7. Tighten the four screws securely to the wall.
Note: For the best results use screws that have the following
attributes:
Head diameter .5 - .6 mm
Shaft diameter 3 - 3.5 mm

IDS-108FPP Installation Guide 12
Note: the dimensions are in mm
Wiring up the IDS-108FPP
Power sources must be off prior to beginning the power
connection steps.
Ensure that the voltage and current ratings of the intended
power source are appropriate for the IDS-108FPP as
indicated on the product label.
Ensure that the installation and electrical wiring of the
equipment is performed by trained and qualified personnel
and that the installation complies with all local and national
electrical codes
This unit should be installed in a restricted access location
where access can only be gained by service personnel or
users who have been instructed about the reasons for the
restrictions applied to the location and about any precautions
that shall be taken; and access is through the use of a tool or
lock and key, or other means of security, and is controlled by
the authority responsible for the location.

IDS-108FPP Installation Guide 13
Hazardous Location Warnings
(safe conditions for use:)
This equipment shall be installed in an enclosure that
provides a degree of protection not less then IP54 in
accordance with EN 60079-15 and accessible only by the
use of a tool.
The equipment shall only be used in an area of not more than
pollution degree 2, as defined in IEC 60664-1.
These devices are open-type devices that are to be installed
in an enclosure with tool removable cover or door, suitable
for the environment.
This equipment is suitable for use in Class I, Division 2,
Groups A,B,C,D or only non hazardous locations only.
WARNING –EXPLOSION HAZARD – Do not disconnect
equipment unless power has been removed or the area is
known to be non-hazardous
WARNING EXPLOSION HAZARD – Substitution of any
components on this switch may impair suitability for Class I,
Division 2.
Transient protection shall be provided that is set at a level not
exceeding 140% of the peak rated voltage value at the
supply terminals to the equipment.
Connecting the IDS-108FPP to ground
If your installation requires additional grounding, follow
this procedure.
Grounding the chassis requires the following items:
•One grounding lug (not provided)
•One 12AWG wire (not provided)
1. Follow the grounding lug manufacturer’s
instructions for attaching the ground wire to the
grounding lug.
2. Attach the grounding lug to the chassis and secure
with the grounding screw provided.

IDS-108FPP Installation Guide 14
Connecting Power to the IDS-108FPP
1. Conductors suitable for use in an ambient
temperature of 95°C must be used for the Power
Supply Terminal.
2. Ensure the power source is off prior to connection.
3. Strip both (12AWG) wires 5mm (3/16th inch).
4. Loosen the terminal block screws and connect the
positive wire (+) into the + terminal and the negative
(-) wire into the - terminal.
5. Tighten terminal screws (0.51Nm torque).
6. Ensure the wires are securely fastened.
7. Re-insert the Terminal block connector if removed.
8. Turn on power source.
9. Check that the P1 LED is On.
10.If desired connect P2 (power source 2, beginning
again at Step 1).
11.One individual conductor for each clamping point.
Connecting PoE/PoE+ devices
•Supports IEEE 802.3af (Type 1) and IEEE 802at-
2009 (Type 2) standards.
•For PoE devices up to 15.4 Watts per port.
•For PoE+ devices up to 30 Watts per port.
Connect the copper cables from each TP port (RJ-45)
on the IDS-108FPP switch to compliant Powered
Devices (PDs).
See below for RJ-45 pinouts on ports 1 through 4.

IDS-108FPP Installation Guide 15
Ethernet Copper Cabling Requirements
•Category 5 UTP or STP, 5e cables
•24-22 AWG
•Straight through or Ethernet crossover cable
Connect the copper cables from each TP port (RJ-45)
on the IDS-108FPP switch to Ethernet-enabled
devices.
See below for 8 pin RJ-45 pinouts.
Remaining pins not used
Fiber Port Cabling Requirements
Duplex SC or ST connector
•Multimode 50/125 or 62.5/125 micron fiber cable
•Single mode 9/125 micron fiber cable
Simplex (BIDI, single strand) SC connector

IDS-108FPP Installation Guide 16
•Multimode 50/125 or 62.5/125 micron fiber cable
•Single mode 9/125 micron fiber cable
Connect the fiber cable to Port 9 and Port 10 (if
installed) on the IDS and the other cable end to a fiber
compliant device. If you are making your own fiber
cables, remember that the RX on one side needs to go
to TX on the other side and vice versa. See diagram
below.
Switch Properties
•IEEE 802.3 for 10Base-T
•IEEE 802.3u for 100Base-TX and 100Base-FX
•IEEE 802.3x for Flow Control
•IEEE 802.3af Power Over Ethernet
•IEEE 802.3at Power Over Ethernet

IDS-108FPP Installation Guide 17
Technical Specifications
Connection
Dual input terminal block power
Power Input/Consumption 18-57 VDC 7.9A max
Maximum Current Consumption @24VDC
3.2 Amps (4 x PoE) 5.9 Amps (4 x PoE+)
Maximum Power Consumption@24VDC 77 Watts (4 X 15.4 Watts PoE)
143 Watts ( 4 X 30 Watts PoE+)
Reverse Polarity Protection Yes
Interface
RJ-45 8 shielded RJ-45 ports for
10/100Base-TX up to 100 meters
(328ft)
4 of these ports are PoE/PoE+ PSE
capable
Auto-negotiation speed F/H duplex
mode and auto MDI/MDI-
X connection
Fiber Ports One or two fixed fiber ports (ST/SC).
See fiber specifications.
PoE/PoE+ ports Up to 30 Watts per port (@switch)
RJ-45 driving up to four class 4 (IEEE
802.3at type 2) PDs, Alternative-B
(ALT-B), MDI-X pinouts, Power over-
Pins 4,5 Positive and 7,8 Negative.
LED indicators P1 /P2– power 1 / power 2
Ports 1-8 G/Y – Link/Activity/Speed
Port 9/10 –port status (Fiber models
only)
Environmental
Operating Temperature
Commercial Models (IDS-108FPP-xxxxxxxx)
Industrial Models (IDS-108FPP-xxxxxxxx-XT)
0°C to 60°C (32°F to 140°F)
-40°C to 75°C (-40°F to 167°F)
Storage Temperature
Commercial Models (IDS-108FPP-xxxxxxxx)
Industrial Models (IDS-108FPP-xxxxxxxx-XT)
-25°C to 70°C (-13°F to 158°F)
-40°C C to 85°C (-40°F to 185°F)
Operating Humidity 5% to 90% non-condensing
Storage Humidity
5% to 95% non-condensing
Operating Altitude Up to 3,048 m (10,000 ft)

IDS-108FPP Installation Guide 18
Regulatory Approvals
Safety cUL 60950-1, EN 60950-1
Industrial UL 508
Hazardous Locations
ANSI/ISA 12.12.01-2013 Class I
Division 2 Groups A-D
ATEX Class I Zone 2
CENELEC EN 60079-
0:2012+A11:2013
CENELEC EN 60079-15:2010
IEC 60079-0 Ed 6, Revision Date
2013-11-01
IEC 60079-15 – Edition 4 – Issue
Date 2010-01-01
EMI/EMC FCC Part 15 – Class A
CISPR22 :2008 / EN55022:2010
Class A
CISPR 24 :2010 / EN55024:2010
Note: The safety certifications apply only to ambient
temperatures under 60°C (140°F). However, the IDS-
108FPP can function in the environmental conditions
listed above.
Note: If the IDS-108FPP is used in environments
where ambient temperatures will exceed 60°C (140°F),
the IDS-108FPP should be installed in an appropriate
enclosure to ensure that no accidental or deliberate
contact with the IDS-108FPP is possible. Case
temperatures in this ambient could exceed safe levels.

IDS-108FPP Installation Guide 19
Fiber Specifications
IDS-108FPP models
Fiber Connector (xx)
Mode
Distance
Wavelength (nm)
TX Power (dB)
RX Power (dB)
Budget
IDS-108FPP None n/a n/a n/a n/a n/a n/a
IDS-108FPP-M2xx2-
(XT) SC/ST MM duplex 2 km 1.2 miles TX: 1310 RX:1310 Min:--6 Max:-0 Min:-17 Max:-0 11
IDS-108FPP-M1SC2U SC MM
simplex
2 km
1.2 miles)
TX: 1310
RX:1550 Min:-15
Max:-8 Min:-28 Max:-3 13
IDS-108FPP-M1SC2D SC MM
simplex
2 km
1.2 miles TX: 1550 RX:1310 Min:-15
Max:-8 Min:-28 Max:-3 13
IDS-108FPP-S2xx20-
(XT) SC/ST SM duplex 20 km 12.4 miles
TX: 1310
RX:1310 Min:-15
Max:-8 Min:-34 Max:3 19
IDS-108FPP-S1SC20U- (XT) SC SM
simplex
20 km
12.4 miles
TX: 1310
RX:1490 Min:--8 Max:-3 Min:-22 Max:-3 14
IDS-108FPP-S1SC20D- (XT) SC SM
simplex
20 km
12.4 miles
TX: 1490
RX:1310 Min:-8 Max:-3 Min:-22 Max:-3 14
IDS-108FPP-S2xx40-
(XT) SC/ST SM duplex 40 km 24.9 miles
TX: 1310
RX:1310 Min:-3 Max:5 Min:-23 Max:-3 20
IDS-108FPP-S1SC40U SC SM
simplex
40 km
24.9 miles
TX: 1310
RX:1490 Min:-3 Max:2 Min:-23 Max:-3 20
IDS-108FPP-S1SC40D SC SM
simplex
40 km
24.9 miles
TX: 1490
RX:1310 Min:-3 Max:2 Min:-23 Max:-3 20
IDS-108FPP-S2xx80 SC/ST SM
duplex 80 km 49.7 miles
TX: 1550
RX:1550 Min: -5 Max: 0 Min-34 Max: -3 29
IDS-108FPP-S2xx120 SC/ST SM
duplex 120 km 74.6 miles
TX: 1550
RX:1550 Min:0 Max:5 Min:-32 Max:-9 32
IDS-108FPP-DM2xx2- (XT)
2 x SC SC/ST MM duplex 2 km 1.2 miles TX: 1310 RX:1310 Min:-6 Max:-0 Min:-17 Max:-0 11
IDS-108FPP-DM1SC2U- (XT)
2 x SC SC MM simplex
2 km
1.2 miles TX: 1310 RX:1550 Min:-15
Max:-8 Min:-28 Max:-3 13
IDS-108FPP-DM1SC2D- (XT)
2 x SC SC MM simplex
2 km
1.2 miles TX: 1310 RX:1550 Min:-15
Max:-8 Min:-28 Max:-3 13
IDS-108FPP-DS2SC20 -(XT)
2 X SC SC SM duplex 20 km 12.4 miles
TX: 1310
RX:1310 Min:-15
Max:-8 Min:-34 Max:3 19

IDS-108FPP Installation Guide 20
IDS-108FPP-DS2ST20- (XT)
2 X ST ST SM duplex 20 km 12.4 miles
TX: 1310
RX:1310 Min:-15
Max:-8 Min:-32 Max:-3 17
IDS-108FPP-DS1SC20U-( XT)
2 x SC SC SM simplex
20 km
12.4 miles
TX: 1310
RX:1550 Min:-8 Max:-3 Min:-22 Max:-3 14
IDS-108FPP-DS1SC20D- (XT)
2 x SC SC SM simplex
20 km
12.4 miles
TX: 1550
RX:1310 Min:-8 Max:-3 Min:-22 Max:-3 14
IDS-108FPP-DS2xx40- (XT)
2 x SC SC/ST SM duplex 40 km 24.9 miles
TX: 1310
RX:1310 Min:-3 Max:-5 Min:-23 Max:-3 20
IDS-108FPP-DS1SC40U
2 x SC SC SM simplex
40 km
24.9 miles
TX: 1310
RX:1550 Min:-3 Max:-2 Min:-23 Max:-3 20
IDS-108FPP-DS1SC40D
2 x SC SC SM simplex
40 km
24.9 miles
TX: 1550
RX:1310 Min:-5 Max:0 Min:34 Max:-3 20
IDS-108FPP-DS2xx80
2 x SC SC/ST SM duplex 80 km 49.7 miles
TX: 1550
RX:1550 Min:-5 Max:0 Min:-34 Max:-3 29
IDS-108FPP-DS2xx120
2 x SC SC/ST SM duplex 120 km 74.6 miles
TX: 1550
RX:1550 Min:0 Max:5 Min:-32 Max:-9 32
For models IDS-108FPP-xxxxxxxx For models IDS-108FPP-xxxxxxxx- T
Contacting Technical Support
Contact information for the Perle Technical Assistance Center
(PTAC) can be found at the link below. A Technical Support Query
may be made via this web page.
www.perle.com/support_services/support_request.shtml
Warranty / Registration
http://www.perle.com/support_services//warranty.shtml
Copyright © 2015 Perle Systems Limited. All rights reserved. No part of this
document may be reproduced or used in any form without written permission from
Perle Systems Ltd.
