Permobil ROHO AirLITE E2605 User manual

ROHO®AirLITE®Cushion
Operation Manual
Supplier: This manual must be given to the user of this product.
Operator (Individual or Caregiver): Before using this product, read the instructions and save for future reference.
shape fitting technology
®

ROHO, Inc.
100 N. Florida Avenue, Belleville, IL 62221-5429 U.S.A.
U.S.A.: 800-851-3449 • Fax [phone] • Customer Care: [email protected]
Outside the U.S.A.: 618-277-9150 • Fax [phone] • [email protected]
permobilus.com
Products in this manual may be covered by one or more U.S. and foreign patents and trademarks. The
following are trademarks and registered trademarks of ROHO, Inc.: AirLITE®, ROHO®, and shape fitting
technology®.
ROHO, Inc. has a policy of continual product improvement and reserves the right to amend specifications
presented in this manual.
© 2014, 2018 ROHO, Inc.
Rev. 04/03/2018
Table of Contents
Intended Use
Important Safety Information 2
Parts Detail
Product Specifications 3
Cushion and Cover Placement 4
Care Instructions 5
Troubleshooting
Storage, Disposal and Recycling
Limited Warranty
6
Español 7
Français 13
Deutsch 19
Italiano 25
Nederlands 31
Dansk 37
Svenska 43
Norsk 49
Suomi 55
Português 61

2
ROHO AirLITE Cushion Operation Manual
Intended Use
The ROHO®AirLITE®Cushion (AirLITE) is a wheelchair support surface with a non-
adjustable, air-filled, segmented-design ROHO AIR FLOTATION™insert encased in
contoured foam. The AirLITE is intended to conform to an individual’s seated shape to
provide positioning. There is a weight limit of 300 lbs. (136 kg), and the cushion must be
properly sized to the individual. The AirLITE must be used with the supplied cover.
ROHO, Inc. recommends evaluation by a clinician who is experienced in seating,
positioning and mobility: 1) to determine whether the cushion is appropriate for the
individual; and 2) to determine whether a solid seat platform is recommended if using the
cushion on a sling-seat wheelchair.
ROHO medical products are intended to be part of an overall care regimen. A clinician
should make product recommendations based upon an evaluation of the individual’s
medical and therapeutic needs and overall condition. A clinician should also evaluate for
visual, reading, and cognitive impairment to determine the need for caregiver assistance
with product use, including providing a large-print manual.
Important Safety Information
Warnings:
-Skin/soft tissue breakdown can occur due to a number of factors, which vary by
individual. Check skin frequently, at least once a day. Redness, bruising, or darker
areas (when compared to normal skin) may indicate superficial or deep tissue
injury and should be addressed. If there is any discoloration to skin/soft tissue,
STOP USE immediately. If the discoloration does not disappear within 30 minutes
after disuse, immediately consult a healthcare professional.
-The cushion and the cover MUST be compatible sizes and MUST be used as
directed in this manual. IF THEY ARE NOT, the benefits provided by the cushion
may be reduced or eliminated, increasing the risk to skin or other soft tissue and
increasing the risk of falling.
-DO NOT use this cushion as a water flotation device (e.g. a Life Preserver). It will
NOT support you in water.
-If you are unable to perform any tasks described in this manual, seek assistance.
-The cushion surface will acclimate to the surrounding temperature. Take
appropriate precautions, especially when the cushion will contact unprotected skin.
-Testing or certification claims, including for flammability, may no longer apply to
this device when it is combined with other products or materials. Check testing and
certification claims for all products used in combination with this device.
Caution: DO NOT expose cushion to high heat, open flames, or hot ashes.

3
ROHO AirLITE Cushion Operation Manual
Sizing (all measurements are approximate):
Smallest Width Smallest Depth Largest Width Largest Depth
in. 13.0 13.0 20.0 20.0
cm 33.0 33.0 51.0 51.0
Average Weight: 2 lbs. (0.9 kg)
Height ranges from 2 in. (5 cm) to 3¾ in. (9.5 cm)
Cushion expected lifetime: 5 years
To order replacement parts, contact your equipment provider or ROHO, Inc.
Product Specifications
Cover: fluid-resistant, two-way stretch top, two-way stretch sides, and non-skid
bottom; refer to cover care label for material content and for compliance to flammability
requirements.
Cushion: non-adjustable, segmented, polyurethane air insert encased in polyurethane and
polyethylene foam
Parts Detail
Operation Manual Product Registration Card
Back
Front
Back
Front
CushionCover
The serial number label is located on
the bottom of the cushion.

4
ROHO AirLITE Cushion Operation Manual
Cushion and Cover Placement
Note: Refer to the label on the bottom of the cushion and to the image on the cover to
correctly orient your cushion and cover.
Cushion Placement:
1. Place the cushion directly on the seat.
Note: If a seat insert is used, place it
inside the cover, beneath the foam base.
When possible, use the hook or loop
fasteners to further secure the cushion to the
seating surface.
2. Have the individual sit on the cushion,
making sure the boniest prominences are
supported by the air cells.
Check to make sure that the cushion is
properly sized to the individual and the
wheelchair.
Cover Removal: Unzip the cover. Remove the
cover from the cushion.
Cover Placement:
1. Unzip the cover.
2. Insert the cushion into the cover, front edge
first, with the contoured foam facing up.
3. Close the zipper.
Warnings:
-The AirLITE must be used with the supplied cover.
-Inspect the cover for damage and replace if necessary.
-Inspect the foam portion of the product for damage and replace if necessary.
The seated
figure shows
standard
orientation.
Zipper in Back
Front

5
ROHO AirLITE Cushion Operation Manual
Care Instructions
Cleaning and disinfecting are separate processes. Cleaning must precede disinfection.
Before use by a different individual: clean, disinfect, and check product for proper
functioning.
Note: Before cleaning and disinfecting, remove the cover from the cushion. Remove hook
fastener pieces from the bottom of the cover.
To Clean the Cover: Machine wash in cold water (30°C) with mild detergent,
gentle cycle. Tumble dry low.
To Disinfect the Cover: Hand wash in warm water
(40°C) using 1 part household liquid bleach per 9
parts water, then rinse thoroughly. The cover can also
be machine washed in hot water (60°C) to disinfect.
Tumble dry low.
Follow safety guidelines on bleach container.
To Clean the Cushion: Remove the cover. Wipe gently with a cloth dampened with
water and a household detergent. Rinse cloth and re-wipe. Allow foam to air dry
thoroughly before putting the cover on.
Disinfectants are not effective on porous surfaces such as foam. If the foam
portion of the product becomes soiled or contaminated, DO NOT use with multiple
individuals. Replace soiled or contaminated foam components.
This symbol means, “Wipe with a damp cloth.”
DO NOT:
- machine wash or dry the cushion
- immerse the cushion in water.
- autoclave, steam clean, or expose cushion to temperatures in excess of 150˚F (65˚C)
- use caustic, automatic dishwasher detergents
- use cleaning products containing petroleum or organic solvents such as acetone,
toluene, Methyl Ethyl Ketone (MEK), naphtha, dry cleaning fluids, or adhesive
removers
- expose the cushion to ozone gas or to ultraviolet light cleaning methods
1:9
40C +or

6
ROHO AirLITE Cushion Operation Manual
Troubleshooting
For additional assistance, contact your equipment provider, distributor, or ROHO, Inc.
The cushion feels uncomfortable or
unstable.
- Confirm AirLITE size and orientation.
- Confirm that there are no obstructions
between AirLITE and the seating surface.
- Consult with a clinician.
The cushion slides on the chair. - Make sure the cover’s non-skid bottom
faces the seating surface.
- If a seat insert is used, make sure it is
inside the cover, beneath the foam base.
- When possible, use the hook or loop
fasteners to further secure the cover to the
seating surface.
The cushion exhibits unusual stiffness;
the cushion has been in temperatures
lower than 32ºF (0ºC)
Before use, allow the cushion to warm to room
temperature 72ºF (22ºC).
Storage, Disposal and Recycling
Storage: Clean and disinfect the product before storing. Store the product in a container that
protects the product from moisture, contaminants and damage.
Disposal: The components of the products in this manual are associated with no known
environmental hazards when properly used and when disposed of in accordance with all
local/regional regulations. Incineration must be performed by a qualified, licensed waste
management facility.
Recycling: Contact a local recycling agency to determine recycling options for the product.
For more recycling information, contact ROHO, Inc
Limited Warranty
Limited Warranty Term, from the date the product was originally purchased: AirLITE: 24 months.
The warranty does not apply to punctures, tears or burns, nor does it apply to the removable cover.
See also the Limited Warranty supplement provided with your product, or contact Customer Care.

Item #T22301 Rev. 04/03/2018
Print Date: Qty:
Mailing/Shipping Address:
1501 South 74th Street, Belleville, IL 62223-5900, USA
Administrative Offices:
100 North Florida Avenue, Belleville, IL 62221-5429, USA
U.S.: 800-851-3449 Fax: [phone]
Outside U.S.: 618-277-9150 Fax: [phone]
permobilus .com
