PetPal PA 300 User manual

1
TM
TM
PetPal
PetPal
Training Systems
Training Systems
PetPal PA300
Electronic Dog Trainer
Owner’s Manual

2

3
TABLE OF CONTENTS
• Table of Contents......................................... 3
• Introduction.................................................. 4
• Package Contents......................................... 5
• Model Features............................................. 5
• Parts and Functions...................................... 6
• Turning ON and OFF................................... 10
• Adjusting and Positioning
Your Collar for Proper Fit............................ 11
• Testing.......................................................... 12
• Reprogramming ........................................... 13
• Important Safety Notes ................................ 14
• Maintenance................................................. 15
• Warranty ...................................................... 15
• FCC Compliance.......................................... 15
• Contact Information..................................... 16

4
Congratulations and thank you for purchasing our
PetPalTM Training Systems Collar. The PetPalTM
series represents the absolute latest technological
advancement in the Electronic Dog Training World. It
offers Maxx-Range™, the industry’s only internally
woven antenna in the collar. With up to a 300 yard
range, they are perfect for household use. PetPalTM
series collars feature sixteen levels of stimulation
intensity, with an easy ‘no-look’ clicking intensity
selection dial. Easy one hand operation allows for
maximum control and safety. This model includes
both the Continuous Stimulation and the Beep
function. The collars are 100% waterproof and can be
worn even when the dog is submerged. The PetPalTM
Series Dog Training Collar is durable, safe and very
humane when used correctly. The automatic safety
shut-off feature stops the stimulus from both the
transmitter and the receiver to prevent accidental or
prolonged stimulation.
INTRODUCTION
IMPORTANT NOTE:
Please read this owner’s manual in its entirety before
operating this unit. Should you have any questions
about our collars or their operation please contact our
Customer Service department (see back page for
address and phone number information).

5
PACKAGE CONTENTS
• Transmitter
• Collar Receiver
• Test Light
• Owner’s Manual
• 3 Volt Batteries for collar included
• Transmitter battery not included (Transmitter uses a
9 volt battery)
MODEL FEATURES
• Digital Technology
• Up to 300 yard range
• Lightweight, compact collar and transmitter
• 16 adjustable intensity levels of Constant
Stimulation
• Beeping Tone
• Gentle Touch System™ Extra Mild Stimulation
• MAXX-Range™ Invisible, Embedded Collar
Antenna
• Built in safety shut-off

6
Transmitter
(PA300 shown)
PARTS & FUNCTIONS
Intensity
Selection Dial
Antenna
LED
Indicator
Light
Magnet
Indicator
(Red Mark
in back)
Constant
Stimulation
Button
Beep
Button
Lanyard
attachment
Battery
compartment
(in back)

7
PARTS & FUNCTIONS CONT.
Intensity Selection Dial
The intensity selection dial allows you to choose between
sixteen different levels of stimulation for very precise control.
Transmitter Antenna
Be sure to check that the antenna is securely fastened to the
transmitter before each use. Hand-tightened only. Be careful
when screwing the antenna into the transmitter: over-
tightening can cause damage to the antenna or the antenna
mount.
Magnet Indicator (Red Mark)
The RED mark indicates the location of the magnet in the
transmitter. The indicator is used to turn the receiver ON/OFF
and for ID programming.
Transmitter Indicator Light
When any of the buttons on the transmitter is pushed, the RED
light will turn on to indicate that the transmitter is being
operated. When the battery is low, the RED light will flash
rapidly.
Remote Training Buttons
. Pressing the “CONT” button gives a Continuous Stimulation.
Pressing the “BEEP” button emits an audible beep.
Important Note:
There is a delay on the remote buttons, and the user
must press and hold the button for at least 1/2 second
in order to emit a shock or beep. This feature was
added to prolong battery life.

8
PARTS & FUNCTIONS CONT.
Collar Receiver
LED
Indicator
Light
Red Mark
(Magnetic
Switch
Indicator)
Collar Belt with
Embedded
Receiver
Antenna
Electrodes
Battery
Compartment
Cap
Magnet

9
Collar LED Indicator Light
The red LED light on the collar unit will flash to
indicate the unit is ON. When the battery in the collar
unit has a sufficient charge, the red LED light will
flash about once every two seconds while the unit is
ON. When the collar battery has a low charge and
needs to be replaced, the red LED will flash rapidly
(about 3 times every 2 seconds) while the unit is ON.
Battery Compartment Cap
The collar requires two 3 volt batteries (included in
package).
Electrodes
Electrodes should make good contact with the skin.
For more information on the proper fit of the collar,
see page 11.
Collar Belt with Embedded Receiver Antenna
The embedded collar antenna is woven into the collar
belt, and it is about 4 inches long. You should be able
to feel the embedded antenna on the nylon belt.
PARTS & FUNCTIONS CONT.
WARNING
Do not cut the part of the collar belt that has the em-
bedded antenna. Doing so will damage the antenna
and may result in severely decreased receiver range.

10
TURNING THE UNIT ON AND OFF
Turning the Collar Unit ON
1. Hold the Red Mark (Magnet
Indicator) on the back of the
transmitter directly against the Red
Mark (Magnet Indicator) on the
side of the collar receiver. You can
also use the magnet on the belt to
turn the collar ON.
2. A small red LED light (next to the Red Mark) will light up
solid for about 1 second, and then will begin to flash.
3. You may remove the Transmitter away from the Collar
Unit as soon as the LED light starts flashing
4. The Collar Unit is now ON. The LED light should
continue to flash to indicate the ON status. (Note: The
Transmitter is always in a permanent sleep state. It is only
ON when a button is being pressed and held for at least
1/2 second, and it does not need to be turned off by the
user).
Turning the Collar Unit OFF
1. Hold the Red Mark (Magnet Indicator) on the back of the
transmitter directly against the Red Mark (Magnet
Indicator) on the side of the collar receiver. You can also
use the magnet on the belt to turn the collar ON.
2. A small red LED light (next to the Red Mark) will light up
solid for about 1 second, and then will begin to flash.
3. You may remove the Transmitter away from the Collar
Unit as soon as the LED light starts flashing
4. The Collar Unit is now OFF. The LED light should no
longer flash, which indicates that the collar is now OFF.

11
ADJUSTING & POSITIONING YOUR
COLLAR FOR PROPER FIT
Proper collar tightness and position
are very important to insure safety
and correct functioning every time
you use the collar.
• All electronic collars need to fit very
snugly to work properly. They must
be just tight enough to allow the
“prongs” or electrodes to make good
skin contact. In most cases, you should be able to fit
no more than two fingers between the collar belt and
your dog’s neck.
• Proper fit of the collar should allow the dog to breath
normally. The collar should never be so tight on the
dog’s neck that it restricts the dog’s normal breathing
pattern.
• If your collar is too loose, you may get inconsistent
stimulation due to improper prong contact with the
skin. This can directly affect whether or not the dog
will receive a correction at the right times. Always
check for good “prong” contact if it appears that your
dog is not responding to the stimulation.
• A loose collar can also promote skin irritation from
moving or rubbing too much on a dog’s neck while
they are running or training. A proper snug fit will
help prevent this from occurring.
• For proper positioning of your collar receiver box, it
should be placed on the front center of the dog’s neck.

12
TESTING
To Test the Electronic Stimulation:
1. Place the tester firmly on the
Collar Unit electrodes as shown.
2. Set the intensity level (a setting of
4 or less may not light the tester
due to its low intensity level).
3. Push the ‘CONT’ button.
4. The tester light will continue to light while the CONT
button is pressed (the higher the intensity level, the
brighter the test light becomes).
Selecting Proper Intensity Level
The first and most important step in training your dog
with your PetPalTM Training System is determining the
correct Intensity Level to provide the proper training
stimulation without over-shocking your dog.
To do this, turn the Collar Unit ON and properly place it
on the dog’s neck. Place the Intensity Selection dial so
that the System is set on Level One. Press the “Cont.”
Button. If there is no reaction from your dog, increase
the Intensity Level in increments of one until the dog
feels the stimulation. You should be able to tell when the
dog feels the shock by outward signs of discomfort or
confusion on it’s face. (Note: Some dog’s may require
more or less stimulation depending upon their individual
nature or size.)

13
REPROGRAMMING
1. Hold the Red Mark (Magnet Indicator) on the back
of the Transmitter directly against the Red Mark
(Magnetic Switch Indicator) on the side of the Collar
Receiver.
2. A small red light inside the Collar Receiver will
light up solid for about 1 second, followed by 5
flashes. You must keep the Transmitter next to the
Collar Receiver during this time.
3. Continue to hold the Transmitter against the Collar
Receiver until the LED light stays on solid. The Collar
Receiver is now in the Code Running Mode (the LED
light will stay lit for approximately 8 seconds while it
is in this mode).
4. Remove the Transmitter from the Collar Receiver
and press the BEEP and CONT buttons simultaneously
while it is in the Code Running Mode.
5. When the LED light blinks 4 times, the Collar ID is
now programmed and the Collar Receiver is now ON.
NOTE – Do not remove the Red Mark on the
Transmitter from the Red Mark on the Collar Receiver
until after the LED light stays on solid, or the Collar
Receiver will not go into the Code Running Mode. You
must press the BEEP and CONT buttons
simultaneously while the LED light is lit solid.

14
IMPORTANT SAFETY NOTES
• Before you start training, your dog should be examined
by a veterinarian to assure that your dog is in good health.
• Never leave your dog unattended with the unit on.
Since no electronic device is perfect, there is a very slight
possibility that your dog may receive an unintentional
electric stimulation.
• Your PetPalTM Trainer is a very valuable tool if used
correctly. It is extremely important that you completely
understand all the functions of the collar and how to
properly train with it before placing it on your dog.
• The electrodes on this collar are made with high grade
stainless steel to help prevent any chemical or allergic
reactions with your dog’s skin.
• To prevent neck irritation, the collar should never be
worn for more than 12 hours a day. Changing the
collar location slightly on the dog’s neck daily will also
help prevent irritations. It is important to keep the
collar clean. Clean the electrodes regularly with a mild
anti-bacterial soap.
• If an irritation is found, carefully wash the dog’s neck
with soap and water and then wipe the area with
Hydrogen peroxide. Dry thoroughly and apply an
antibiotic ointment. Consult your veterinarian if the
irritations look severe.

15
MAINTENANCE
• It is very important to periodically clean your PetPalTM
Trainer for maximum performance. Regular cleaning
will also lengthen the life of your unit.
• Clean the PetPalTM Trainer collar box with lukewarm
water and a mild anti-bacterial soap.
• Take care to thoroughly clean the space between the
electrodes and the belt.
• The belt and buckle should be cleaned with water and a
mild soap then allowed to dry completely.
• After each cleaning, always allow the entire unit to
completely dry before use.
WARRANTY
All PetPalTM collars have a one year parts and labor
warranty, effective from the original date of purchase. A
copy of the original sales receipt is required to validate the
date of purchase.
FCC COMPLIANCE
Your PetPalTM Trainer has been manufactured under
complete compliance with the Federal Communication
Commission (FCC). The complex internal structure of each
product has been designed to operate within specific
regulations of FCC specifications. Any unauthorized
modifications to your product is a violation of these
specifications.
The PetPalTM Trainer has been made with State of the Art
equipment. Any fine adjustment should be performed only
by PetPal’s technicians.

16
PetPalTM Training Systems
2872 Walnut Hill Lane
Dallas, Texas 75229
Tel: [phone], (888) LUV-U-DOG
Fax: [phone]
Website: http://www.petpaltraining.com
E-mail: custo[email protected]
