PEUGEOT 108 2017 Technical manual

INDEX - VICS(VEHICLE INSTRUCTION CARD)
PEUGEOT VEHICLES
INDEX PAGE 1
Page Vehicle Details
1Index n/a
2Supplement (Electronic Parking Brake, etc) n/a
3108 4 seats / 3-5 door hatchback
4208 5 seats / 3-5 door hatchback
5208 (NEW) 5 seats / 3-5 door hatchback
62008 5 seats / 5 door MPV
72008 (NEW) 5 seats / 5 door MPV
8308 5 seats / 5 door hatchback
/ 5 door estate
93008 5 seats / 5 door MPV
10 508 / 508 SW 5 seats / 4 door saloon
/ 5 door estate
11 5008 7 seats / 5 door MPV
12 Rifter 7 seats / 5 door MPV
13 Partner Van 3 seats / small panel van
14 Traveller 7 seats / 5 door MPV
15 Expert Van 3 seats / panel van
16 Boxer Van 3 seats / panel van
17 Boxer Van Dropside 3 seats / L3 dropside

LOCATION
The diagrams above indicate example locations of the electronic parking brake (A) which is labelled with the universal icon symbol:
ACTIVATION
The EPB will normally auto activate. If will also activate if seat belts are not being worn, or when luggage placed on top of seats activates the system. To
enable the system to function correctly, fasten seatbelts, and remove luggage from the seats and store it securely in the boot. Pull the switch labelled A to
manually apply the parking brake. The warning lamps on both the switch and instrument panel will light up to confirm its activation.
DEACTIVATION
The EPB will normally auto release. Depress the brake or accelerator pedal to auto release it, or press the switch (A) to manually release it. The
associated warning lamps on both the switch and dashboard instrument panel will go out to confirm its deactivation. Note: seatbelts should be fastened,
and luggage should not be placed on seats.
WHEN DRIVING AWAY
The parking brake will deactivate automatically when driving away, and it also prevents the vehicle from rolling back unintentionally for a few seconds
when starting on a gradient. This works by driving off in a normal way, the parking brake will automatically release and the vehicle will start moving in the
desired direction.
On vehicles fitted with an automatic gear box, you can apply the parking brake when stopping briefly at traffic lights etc., to avoid the vehicle creeping
forward. When you drive off the parking brake will be automatically released.
INFORMATION
Vehicle specifications are subject to change. This vehicle does not include any manufacturer handbooks or manuals.
VEHICLE INSTRUCTION CARD SUPPLEMENT
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
PEUGEOT VEHICLES
Where fitted, the electronic parking brake replaces the mechanical handbrake and is designed to prevent the vehicle from accidently rolling away. This
system offers convenience and safety features in addition to those normally associated with a mechanical handbrake. Please refer to the primary Vehicle
Instruction Guide for information about other operational instructions.
03-03-2017
ELECTRONIC PARKING BRAKE (EPB)
Don’t panic! Despite seeing a new light pop-up on your instrument panel, unless it is red it is likely the car is still running fine, and while there may be a
problem to attend to, proceed with confidence and patience.
RED Indicates a potentially serious problem or safety issue. Attend to it! Red may also indicate an important reminder.
YELLOW or orange means something needs to be serviced or repaired soon. If it is flashing, it is important that you contact your rental agent for advice.
GREEN or blue is only telling you that a system is on or operating normally.
WARNING LIGHTS AND WHAT THEY MEAN
Deadlock / safelock messages shown on the instrument display when the engine is turned off simply indicate that once you exit the vehicle and lock the
doors, they’re effectively deadlocked and anyone left in the car wouldn’t be able to get out in the event of an emergency. The warning is nothing to worry
about and is just a standard advisory message.
DEADLOCKS
A seatbelt warning light may illuminate when the engine is turned on. This may mean that the electronic parking brake (EPB) becomes auto activated to
prevent vehicle movement. To deactivate these warning lights, and turn off the auto activation of the EPB in this instance, ensure all passengers fasten
their seatbelts, and remove any luggage from on top of the seats. For safety secure all luggage inside the boot.
SEATBELT WARNING LIGHTS
Unless indicated otherwise by road traffic signs and/or local road regulations and/or dictated by weather conditions, the Highway Code states that
provided always it is safe to do so, a passenger vehicle may be driven at the following MAXIMUM speeds (MPH):
DRIVING RESTRICTIONS AND/OR CONDITIONS
Drivers are reminded that they are responsible for the consequences arising out of their failure
to comply at all times with the requirements of any applicable Road Traffic Regulations, the
Highway Code and/or to the road conditions prevailing at the time and in the locality through
which they are driving the vehicle.
Europcar accepts no responsibility or liability for any costs, claims, penalties, fines or any other
circumstances arising out of or in connection with the driver’s failure to comply with all and any
road restrictions and/or conditions.

USEFUL INFORMATION ABOUT YOUR VEHICLE
design and production by : Drake Enterprises Limited - [email protected]
CHILD SEATS
FUEL IN CASE OF BREAKDOWN DRIVER'S SEAT
Vehicle specifications are subject to change. When the engine is turned off, ensure that the starter switch is in position II when operating electrical items such
as door mirrors and windows, etc. This vehicle does not include any manufacturer handbooks or manuals.
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
Use hazard lights. Attempt to park
in a safe position.
Use an emergency phone rather
than a mobile as emergency
services will then know the location
of the vehicle.
Never use a child seat in a front
passenger seat which is fitted with
an active airbag (SRS). Follow all
fitting instructions carefully.
Check seat positioning and security
before use.
VEHICLE INSTRUCTION CARD
TYRE PRESSURES (COLD)
CONTROLS
When parked, the handbrake (or electronic
parking brake) should be fully applied with the
vehicle left in first or reverse gear for vehicles
with manual transmission or P (Park) for
vehicles with automatic transmission.
CAUTION!
For assistance after an accident/incident, please call 0800 0280 999
For assistance after a breakdown or help with tyres or windscreens please refer to the numbers on the tax disc holder.
TYRE HELPLINE
In the event of having a punctured tyre
please call the Europcar Tyre Helpline
0800 0280 999 for ANY assistance.
NOTE: Vehicles are not usually supplied
with a tyre repair kit (for vehicles that use
this in lieu of a spare wheel).
VIC-PEU-01 / 08-09-2017
Models are fitted with key / remote control operated central locking. Depress the door locking switch integrated into door
lever. Doors also auto lock when vehicle is in motion.
Passive arming of electronic engine immobiliser and alarm. Visible VIN plate.
Models are centrally locked. Use the key or remote control to unlock / open.
Internal electic adjustment via control pad on bottom right of dashboard.
Electric front operated via control switches on the driver’s door. Hinged rear windows..
If fitted - retractable electric roof operated by roof mounted switchgear.
Located on the edge of the rear doors, twist the button to activate it. Check from inside that the doors are securely locked.
Ensure gear selector is in neutral and handbrake is on. Place ignition key in starter switch. Use a normal starting routine.
(For keyless models, keep the key in your pocket or handbag, depress clutch and press engine start/stop button to start the
engine). Select desired gear. Release handbrake and brake pedal and gently press the accelerator to move the vehicle.
Centrally locked. Located on rear nearside. Lightly press the rear edge of fuel flap to open it. Twist off the cap anticlockwise.
Pull bonnet release lever located to the lower right of the instrument panel. Unhook catch under bonnet.
The rear seat is divided into 50:50 sections which can be flat folded separately. To release the seat press the seat unlocking
catch and fold the seat down. To return the seat to normal use, raise the seat and push it firmly to engage the seat lock.
Check it is locked before using the seat.
Lift the recess cover inside the boot to access the spare tyre (temporary spare). The tools and jack are with the wheel. Move
the vehicle to firm / level ground. Turn the engine off, select first gear (manual) or P (automatic). Apply the handbrake or
parking brake. Loosen the wheel nuts (do not remove them). Only use the specific reinforced jack points on the underside
of the vehicle. Crank the jack to lift the vehicle. Undo wheel nuts and change the wheel. Lower the vehicle. Tighten the wheel
nuts. For any assistance in the event of having a punctured tyre, or should the vehicle not be supplied with a spare
wheel and tyre or a tyre repair kit, please call the Europcar Tyre Helpline 0800 0280 999.
To change gears press the foot operated brake pedal and move the lever forwards or backwards through the gate.
Select Nfor neutral, Rfor reversing (the vehicle must be at a complete standstill before this gear can be selected). For
normal driving select Ewhere the transmission will use all available forward gears automatically (a ‘kickdown ‘ facility is
provided when the accelerator is pressed all the way to the floor past the normal acceleration point forcing the transmission
to select a lower gear to obtain maximum acceleration. Release pressure on the accelerator to return to normal accelerator
use). Use M+ or M- to manually select gears only. Whenever the vehicle is at a standstill fully apply the handbrake.
PEUGEOT 108
Tilt
Height
Legroom
3 door: Tilt seat to access rear
seats
4 SEATS
3-5 DOOR HATCH
Ensure you use the correct fuel
type. Only use unleaded petrol
in petrol vehicles (see inside of
filler flap).
Fuel Tank Capacity:
35.0 litres
Check tyre pressure regularly
Legal minimum tread depth is 1.6 mm
165/65 R14
165/60 R15
Check the tyre pressure table found on
the inside of driver’s door B-pillar (or fuel
filler cap).
Vehicle is fitted with tyre pressure sensors.
Vehicle supplied with either a temporary
spare wheel or a tyre repair kit.
1 3 5
2 4 R
1Heating & Ventilation
2Hazard Lights
3Starter Switch
4Headlights
5Sidelights
6Indicators
7Wipers
8Rear Screen Wipers
9Horn
10 Bonnet Release
11 Heated Rear Screen
12 Rear Fog Lamp
1
2
3
4 / 5 / 6 / 9 / 12
IMPORTANT: the oil level must
be checked every 1000 miles.
10
7 / 8
11
R
N
E
M+
M-
or
Locking the doors?
Anti-theft system?
Opening the boot?
Adjusting door mirrors?
Opening the windows?
Operating the sunroof?
Using child door locks?
Starting the engine?
Opening fuel filler cap?
Releasing the bonnet?
Folding the rear seats?
How to change a tyre?
How to drive an
automatic?

USEFUL INFORMATION ABOUT YOUR VEHICLE
design and production by : Drake Enterprises Limited - [email protected]
CHILD SEATS
FUEL IN CASE OF BREAKDOWN DRIVER'S SEAT
Vehicle specifications are subject to change. When the engine is turned off, ensure that the starter switch is in position II when operating electrical items such
as door mirrors and windows, etc. This vehicle does not include any manufacturer handbooks or manuals.
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
Use hazard lights. Attempt to park
in a safe position.
Use an emergency phone rather
than a mobile as emergency
services will then know the location
of the vehicle.
Never use a child seat in a front
passenger seat which is fitted with
an active airbag (SRS). Follow all
fitting instructions carefully.
Check seat positioning and security
before use.
VEHICLE INSTRUCTION CARD
TYRE PRESSURES (COLD)
CONTROLS
When parked, the handbrake (or electronic
parking brake) should be fully applied with the
vehicle left in first or reverse gear for vehicles
with manual transmission or P (Park) for
vehicles with automatic transmission.
CAUTION!
For assistance after an accident/incident, please call 0800 0280 999
For assistance after a breakdown or help with tyres or windscreens please refer to the numbers on the tax disc holder.
TYRE HELPLINE
In the event of having a punctured tyre
please call the Europcar Tyre Helpline
0800 0280 999 for ANY assistance.
NOTE: Vehicles are not usually supplied
with a tyre repair kit (for vehicles that use
this in lieu of a spare wheel).
VIC-PEU-02 / 14-04-2019
Remote control operated central deadlocking. Depress the central locking button on the lower centre console to lock the
doors from the inside.
Passive arming of electronic engine immobiliser and alarm. Visible VIN plate.
Centrally locked. Use the remote control to unlock or open by using the internal remote release.
Internal manual adjustment via levers on the front doors. OR electric internal adjustment operated via a control knob on the
driver’s door.
Electric operated via control buttons on the driver’s door.
Some models may be fitted with an electric tilt / slide panoramic sunroof operated via roof mounted switchgear.
Located on the edge of the rear doors, turn the key slot to activate it, or press the central locking button on the centre
console. Check from inside that the doors are securely locked.
Ensure gear selector is in neutral and handbrake is on. Place ignition key in starter switch. Use a normal starting routine.
Select desired gear. Release handbrake and brake pedal and gently press the accelerator to move the vehicle. Some
models feature auto start/stop technology whereby the engine turns off when stationary and idle, to restart either lift the
brake (auto models) or depress the clutch (manual).
Models have a centrally locked fuel cap located under a flap on rear nearside. Lightly press the edge of the flap to open it,
and twist off the fuel cap anticlockwise.
Pull bonnet release lever located on left hand side of front passenger footwell. Unhook catch under bonnet.
The rear seat is divided into 60:40 sections which can be folded separately. To release the seat press the seat unlocking
catch and fold the seat down. To return the seat to normal use, raise the seat and push it firmly to engage the seat lock.
Check it is locked before using the seat.
Vehicles are not normally supplied with a spare wheel or tyre repair kit. For any assistance in the event of having a
punctured tyre, or should the vehicle not be supplied with a spare wheel and tyre or a tyre repair kit, please call the
Europcar Tyre Helpline 0800 0280 999. Lift the recess cover inside the boot to access the standard or temporary spare
tyre. The tools and jack are with the wheel. Move the vehicle to firm / level ground. Turn the engine off, select first gear
(manual) or P (automatic). Apply the handbrake or parking brake. Loosen the wheel nuts (do not remove them). Only use
the specific reinforced jack points on the underside of the vehicle. Crank the jack to lift the vehicle. Undo wheel nuts and
change the wheel. Lower the vehicle. Tighten the wheel nuts.
To change gears press the button on the shift lever and move the lever forwards or backwards in the gear gate. Select N
for neutral, Pwhen leaving the vehicle, Rfor reversing (the vehicle must be at a complete standstill before this gear can be
selected). For normal driving select Dwhere the transmission will use all available forward gears automatically (a ‘kickdown
‘ facility is provided when the accelerator is pressed all the way to the floor past the normal acceleration point forcing the
transmission to select a lower gear to obtain maximum acceleration. Release pressure on the accelerator to return to normal
accelerator use). Move the lever to lower left to use the tiptronic + and - settings to manually change gear up or down by
pushing the lever forward or backward. Whenever the vehicle is at a standstill apply the handbrake.
PEUGEOT 208
Tilt
Height
Legroom
3 door: Tilt seat to access rear
seats
5 SEATS
3-5 DOOR HATCH
Ensure you use the correct fuel
type. Only use unleaded petrol
in petrol vehicles (see inside of
filler flap).
Fuel Tank Capacity:
50.0 litres
Check tyre pressure regularly
Legal minimum tread depth is 1.6 mm
195/55 R16
205/45 R17
Check the tyre pressure table found on
the inside of driver’s door B-pillar (or fuel
filler cap).
1Heating & Ventilation
2Hazard Lights
3Starter Switch
4Headlights
5Sidelights
6Indicators
7Wipers
8Rear Screen Wipers
9Horn
10 Bonnet Release
11 Heated Rear Screen
12 Rear Fog Lamp
13 Handbrake
1
2
3
4 / 5 / 6 / 12
9 9
10
7 / 8
Important: the oil level must be
checked every 1000 miles.
11
or
P
R
N
D
Locking the doors?
Anti-theft system?
Opening the boot?
Adjusting door mirrors?
Opening the windows?
Operating the sunroof?
Using child door locks?
Starting the engine?
Opening fuel filler cap?
Releasing the bonnet?
Folding the rear seats?
How to change a tyre?
How to drive an
automatic?
1 3 5
2 4 6
R
+
-
13

USEFUL INFORMATION ABOUT YOUR VEHICLE
design and production by : Drake Enterprises Limited - [email protected]
CHILD SEATS
FUEL IN CASE OF BREAKDOWN DRIVER'S SEAT
Vehicle specifications are subject to change. When the engine is turned off, ensure that the starter switch is in position II when operating electrical items such
as door mirrors and windows, etc. This vehicle does not include any manufacturer handbooks or manuals.
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
Use hazard lights. Attempt to park
in a safe position.
Use an emergency phone rather
than a mobile as emergency
services will then know the location
of the vehicle.
Never use a child seat in a front
passenger seat which is fitted with
an active airbag (SRS). Follow all
fitting instructions carefully.
Check seat positioning and security
before use.
VEHICLE INSTRUCTION CARD
TYRE PRESSURES (COLD)
CONTROLS
When parked, the handbrake (or electronic
parking brake) should be fully applied with the
vehicle left in first or reverse gear for vehicles
with manual transmission or P (Park) for
vehicles with automatic transmission.
CAUTION!
For assistance after an accident/incident, please call 0800 0280 999
For assistance after a breakdown or help with tyres or windscreens please refer to the numbers on the tax disc holder.
TYRE HELPLINE
In the event of having a punctured tyre
please call the Europcar Tyre Helpline
0800 0280 999 for ANY assistance.
NOTE: Vehicles are not usually supplied
with a tyre repair kit (for vehicles that use
this in lieu of a spare wheel).
VIC-PEU-03 / 14-04-2019
Remote control operated central deadlocking. Depress the central locking button to lock the doors from the inside.
Passive arming of electronic engine immobiliser and alarm. Visible VIN plate.
Centrally locked. Use the remote control to unlock or open by using the internal remote release.
Internal manual adjustment via levers on the front doors. OR electric internal adjustment operated via a control knob on the
driver’s door.
Electric front and rear operated via control buttons on the driver’s door.
Some models may be fitted with an electric tilt / slide panoramic sunroof operated via roof mounted switchgear.
Located on the edge of the rear doors, turn the key slot to activate it, or press the central locking button on the centre
console. Check from inside that the doors are securely locked.
Ensure gear selector is in neutral and electronic parking brake is on. Place ignition key in starter switch. Press the engine
start/stop button to start or stop the engine. For keyless models, just keep the key in your pocket or bag, and use the engine
start/stop button. Select desired gear. Release electronic parking brake and brake pedal and gently press the accelerator
to move the vehicle. Models feature auto start/stop technology whereby the engine turns off when stationary, gears are in
neutral and foot pedals are not depressed, to restart press the accelerator (auto models) or depress the clutch (manual).
Models have a centrally locked fuel cap located under a flap on rear nearside. Lightly press the edge of the flap to open it,
and twist off the fuel cap anticlockwise.
Pull bonnet release lever located on left hand side of front passenger footwell. Unhook catch under bonnet.
The rear seat is divided into 60:40 sections which can be folded separately. To release the seat press the seat unlocking
catch and fold the seat down. To return the seat to normal use, raise the seat and push it firmly to engage the seat lock.
Check it is locked before using the seat.
Vehicles are not normally supplied with a spare wheel or tyre repair kit. For any assistance in the event of having a
punctured tyre, or should the vehicle not be supplied with a spare wheel and tyre or a tyre repair kit, please call the
Europcar Tyre Helpline 0800 0280 999. Lift the recess cover inside the boot to access the standard or temporary spare
tyre. The tools and jack are with the wheel. Move the vehicle to firm / level ground. Turn the engine off, select first gear
(manual) or P (automatic). Apply the electronic parking brake. Loosen the wheel nuts (do not remove them). Only use the
specific reinforced jack points on the underside of the vehicle. Crank the jack to lift the vehicle. Undo wheel nuts and change
the wheel. Lower the vehicle. Tighten the wheel nuts.
To change gears press the button on the shift lever and move the lever forwards or backwards. Select Nfor neutral, P
when leaving the vehicle, Rfor reversing (the vehicle must be at a complete standstill before this gear can be selected).
For normal driving select Dwhere the transmission will use all available forward gears automatically (a ‘kickdown ‘ facility is
provided when the accelerator is pressed all the way to the floor past the normal acceleration point forcing the transmission
to select a lower gear to obtain maximum acceleration. Release pressure on the accelerator to return to normal accelerator
use). Use the D + and - settings or the steering wheel mounted paddle shift levers to manually change gears up or down.
Whenever the vehicle is at a standstill apply the electronic parking brake.
PEUGEOT 208 NEW
Tilt
Height
Legroom
3 door: Tilt seat to access rear
seats
5 SEATS
3-5 DOOR HATCH
Ensure you use the correct fuel
type. Only use unleaded petrol
in petrol vehicles (see inside of
filler flap).
Fuel Tank Capacity:
45.0 litres
Check tyre pressure regularly
Legal minimum tread depth is 1.6 mm
R16
R17
Check the tyre pressure table found on
the inside of driver’s door B-pillar (or fuel
filler cap).
Vehicles feature a remote tyre pressure
monitoring system.
1Heating & Ventilation
2Hazard Lights
3Engine Start/Stop
4Headlights
5Sidelights
6Indicators
7Wipers
8Rear Screen Wipers
9Horn
10 Bonnet Release
11 Heated Rear Screen
12 Rear Fog Lamp
13 Electronic Parking Brake
14 Paddle Shift Gear Levers
1
23
4 / 5 / 6 / 12
9
10
7 / 8
Important: the oil level must be
checked every 1000 miles.
11
or
P
R
N
D
Locking the doors?
Anti-theft system?
Opening the boot?
Adjusting door mirrors?
Opening the windows?
Operating the sunroof?
Using child door locks?
Starting the engine?
Opening fuel filler cap?
Releasing the bonnet?
Folding the rear seats?
How to change a tyre?
How to drive an
automatic?
1 3 5
2 4 6
R
+
-
13
14

USEFUL INFORMATION ABOUT YOUR VEHICLE
design and production by : Drake Enterprises Limited - [email protected]
CHILD SEATS
FUEL IN CASE OF BREAKDOWN DRIVER'S SEAT
Vehicle specifications are subject to change. When the engine is turned off, ensure that the starter switch is in position II when operating electrical items such
as door mirrors and windows, etc. This vehicle does not include any manufacturer handbooks or manuals.
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
Use hazard lights. Attempt to park
in a safe position.
Use an emergency phone rather
than a mobile as emergency
services will then know the location
of the vehicle.
Never use a child seat in a front
passenger seat which is fitted with
an active airbag (SRS). Follow all
fitting instructions carefully.
Check seat positioning and security
before use.
VEHICLE INSTRUCTION CARD
TYRE PRESSURES (COLD)
CONTROLS
When parked, the handbrake (or electronic
parking brake) should be fully applied with the
vehicle left in first or reverse gear for vehicles
with manual transmission or P (Park) for
vehicles with automatic transmission.
CAUTION!
For assistance after an accident/incident, please call 0800 0280 999
For assistance after a breakdown or help with tyres or windscreens please refer to the numbers on the tax disc holder.
TYRE HELPLINE
In the event of having a punctured tyre
please call the Europcar Tyre Helpline
0800 0280 999 for ANY assistance.
NOTE: Vehicles are not usually supplied
with a tyre repair kit (for vehicles that use
this in lieu of a spare wheel).
VIC-PEU-04 / 24-06-2018
Remote control operated central deadlocking. Depress the central locking button on the centre console to lock the doors
from the inside.
Passive arming of electronic engine immobiliser and alarm. Visible VIN plate.
Centrally locked. Use the remote control to unlock or open.
Electric internal adjustment operated via a control pad on the driver’s door.
Electric front and rear operated via switches on the driver’s door.
Some models may be fitted with an electric tilt / slide panoramic sunroof operated via roof mounted switchgear.
Located on the edge of the rear doors, turn the key slot to activate it, or press the central locking button on the centre
console. Check from inside that the doors are securely locked.
Ensure gear selector is in neutral and parking brake is on. Place ignition key in starter switch. Or for keyless starting keep
the key in your pocket or handbag, and press the engine start/stop button adjacent to the gear lever to start or stop the
engine. Select desired gear. Release parking brake and brake pedal and gently press the accelerator to move the vehicle.
Vehicles feature auto start/stop technology whereby the engine turns off when vehicle is stationary, gears are in neutral and
foot pedals are not depressed - to instantly restart either depress the brake (auto models) or depress the clutch (manual).
Models have a centrally locked fuel cap located under a flap on rear nearside. Press the edge of the flap to open it, and twist
off the cap anticlockwise. Press the flap closed.
Pull bonnet release lever located on lower right hand side of front passenger footwell. Unhook catch under bonnet.
The rear seat is divided into 66:33 sections which can be flat-folded separately. To release the seat press the seat unlocking
catch and fold the seat down. To return the seat to normal use, raise the seat and push it firmly to engage the seat lock.
Check it is locked before using the seat.
Vehicles are not normally supplied with a tyre repair kit or spare wheel. For any assistance in the event of having a
punctured tyre, or should the vehicle not be supplied with a spare wheel and tyre or a tyre repair kit, please call the
Europcar Tyre Helpline 0800 0280 999. Lift the recess cover inside the boot to access the tyre epair kit and tools. Move
the vehicle to firm / level ground. Turn the engine off, select first gear (manual) or P (automatic). Apply the parking brake.
Loosen the wheel nuts (do not remove them). Only use the specific reinforced jack points on the underside of the vehicle.
Crank the jack to lift the vehicle. Undo wheel nuts and change the wheel. Lower the vehicle. Tighten the wheel nuts.
To change gears press the button on the shift lever and move the lever forwards or backwards in the gear gate. Select N
for neutral, Pwhen leaving the vehicle, Rfor reversing (the vehicle must be at a complete standstill before this gear can
be selected). For normal driving select D (M) where the transmission will use all available forward gears automatically (a
‘kickdown ‘ facility is provided when the accelerator is pressed all the way to the floor past the normal acceleration point
forcing the transmission to select a lower gear to obtain maximum acceleration. Release pressure on the accelerator to
return to normal accelerator use). Use the M+ and M- settings to manually change gear up or down by pushing the lever
forward or backward. Whenever the vehicle is at a standstill apply the parking brake. Use the rotary grip control dial to select
various driving modes for different road surfaces.
PEUGEOT 2008
Tilt
Height
Legroom
5 SEATS
5 DOOR CROSSOVER SUV
Ensure you use the correct fuel
type. Only use unleaded petrol
in petrol vehicles (see inside of
filler flap).
Fuel Tank Capacity:
45.0 litres
Check tyre pressure regularly
Legal minimum tread depth is 1.6 mm
195/60 R16
205/50 R17
Check the tyre pressure table found on
the inside of driver’s door B-pillar (or fuel
filler cap).
When using the spacesaver spare wheel
driving speed and travel distance are
restricted.
1
2
3
4 / 5 / 6 / 12
99
10
7 / 8
Important: the oil level must be
checked every 1000 miles.
11
or
P
R
N
M
Locking the doors?
Anti-theft system?
Opening the boot?
Adjusting door mirrors?
Opening the windows?
Operating the sunroof?
Using child door locks?
Starting the engine?
Opening fuel filler cap?
Releasing the bonnet?
Folding the rear seats?
How to change a tyre?
How to drive an
automatic?
1 3 5
2 4 6
R
+
-14
10
1Heating & Ventilation
2Hazard Lights
3Engine Start / Stop
4Headlights
5Sidelights
6Indicators
7Wipers
8Rear Screen Wipers
9Horn
10 Bonnet Release
11 Heated Rear Screen
12 Rear Fog Lamp
13 Grip Control Dial
14 Electronic Parking Brake
13
Lumbar

USEFUL INFORMATION ABOUT YOUR VEHICLE
design and production by : Drake Enterprises Limited - [email protected]
CHILD SEATS
FUEL IN CASE OF BREAKDOWN DRIVER'S SEAT
Vehicle specifications are subject to change. When the engine is turned off, ensure that the starter switch is in position II when operating electrical items such
as door mirrors and windows, etc. This vehicle does not include any manufacturer handbooks or manuals.
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
Use hazard lights. Attempt to park
in a safe position.
Use an emergency phone rather
than a mobile as emergency
services will then know the location
of the vehicle.
Never use a child seat in a front
passenger seat which is fitted with
an active airbag (SRS). Follow all
fitting instructions carefully.
Check seat positioning and security
before use.
VEHICLE INSTRUCTION CARD
TYRE PRESSURES (COLD)
CONTROLS
When parked, the handbrake (or electronic
parking brake) should be fully applied with the
vehicle left in first or reverse gear for vehicles
with manual transmission or P (Park) for
vehicles with automatic transmission.
CAUTION!
For assistance after an accident/incident, please call 0800 0280 999
For assistance after a breakdown or help with tyres or windscreens please refer to the numbers on the tax disc holder.
TYRE HELPLINE
In the event of having a punctured tyre
please call the Europcar Tyre Helpline
0800 0280 999 for ANY assistance.
NOTE: Vehicles are not usually supplied
with a tyre repair kit (for vehicles that use
this in lieu of a spare wheel).
VIC-PEU-05 / 03-02-2020
Remote control operated central deadlocking. Depress the central locking button on the centre console to lock the doors
from the inside.
Passive arming of electronic engine immobiliser and alarm. Visible VIN plate.
Centrally locked. Use the remote control to unlock or open. Some models feature a configurable floor height.
Electric internal adjustment operated via a control pad on the driver’s door.
Electric front and rear operated via switches on the driver’s door.
Some models may be fitted with an electric slide panoramic sunroof with blind, operated via roof mounted switchgear.
Located on the edge of the rear doors, turn the key slot to activate it, or press the central locking button on the centre
console to lock the doors. Check from inside that the doors are securely locked.
Ensure gear selector is in neutral and parking brake is on. Keyless starting - keep the key in your pocket or bag, and press
the engine start/stop button to start or stop the engine. Select desired gear. Release parking brake and brake pedal and
gently press the accelerator to move the vehicle. Vehicles feature auto start/stop technology whereby the engine turns off
when vehicle is stationary, gears are in neutral and foot pedals are not depressed - to instantly restart either depress the
brake (auto models) or depress the clutch (manual).
Models have a centrally locked fuel cap located under a flap on rear nearside. Press the edge of the flap to open it, and twist
off the cap anticlockwise. Press the flap closed.
Pull bonnet release lever located on lower right hand side of front passenger footwell. Unhook catch under bonnet.
The rear seat is divided into 66:33 sections which can be flat-folded separately. To release the seat press the seat unlocking
catch and fold the seat down. To return the seat to normal use, raise the seat and push it firmly to engage the seat lock.
Check it is locked before using the seat.
Vehicles are not normally supplied with a tyre repair kit or spare wheel. For any assistance in the event of having a
punctured tyre, or should the vehicle not be supplied with a spare wheel and tyre or a tyre repair kit, please call the
Europcar Tyre Helpline 0800 0280 999.
To change gears press the button on the shift lever and move the lever forwards or backwards in the gear gate. Select N
for neutral, Pwhen leaving the vehicle, Rfor reversing (the vehicle must be at a complete standstill before this gear can
be selected). For normal driving select D (M) where the transmission will use all available forward gears automatically (a
‘kickdown ‘ facility is provided when the accelerator is pressed all the way to the floor past the normal acceleration point
forcing the transmission to select a lower gear to obtain maximum acceleration. Release pressure on the accelerator to
return to normal accelerator use). Use the M+ and M- settings to manually change gear up or down by pushing the lever
forward or backward. Whenever the vehicle is at a standstill apply the parking brake. Use the rotary grip control dial to select
various driving modes for different road surfaces.
PEUGEOT 2008 NEW
Tilt
Height
Legroom
5 SEATS
5 DOOR CROSSOVER SUV
Ensure you use the correct fuel
type. Only use unleaded petrol
in petrol vehicles (see inside of
filler flap).
Fuel Tank Capacity:
41.0 litres
Check tyre pressure regularly
Legal minimum tread depth is 1.6 mm
215/65 R16
215/60 R17
215/55 R18
Check the tyre pressure table found on
the inside of driver’s door B-pillar (or fuel
filler cap).
When using the spacesaver spare wheel
driving speed and travel distance are
restricted.
11
1
3
4 / 5 / 6 / 12 / 13
9 9
10
7 / 8
153
Important: the oil level must be
checked every 1000 miles.
2
or
P
R
N
M
Locking the doors?
Anti-theft system?
Opening the boot?
Adjusting door mirrors?
Opening the windows?
Operating the sunroof?
Using child door locks?
Starting the engine?
Opening fuel filler cap?
Releasing the bonnet?
Folding the rear seats?
How to change a tyre?
How to drive an
automatic?
1 3 5
2 4 6
R
+
-
14
1Heating & Ventilation
2Hazard Lights
3Engine Start / Stop
4Headlights
5Sidelights
6Indicators
7Wipers
8Rear Screen Wipers
9Horn
10 Bonnet Release
11 Heated Rear Screen
12 Rear Fog Lamp
13 Front Fog Lamp
14 Electronic Parking Brake
15 Paddle Shift Levers
Lumbar

USEFUL INFORMATION ABOUT YOUR VEHICLE
design and production by : Drake Enterprises Limited - [email protected]
CHILD SEATS
FUEL IN CASE OF BREAKDOWN DRIVER'S SEAT
Vehicle specifications are subject to change. When the engine is turned off, ensure that the starter switch is in position II when operating electrical items such
as door mirrors and windows, etc. This vehicle does not include any manufacturer handbooks or manuals.
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
Use hazard lights. Attempt to park
in a safe position.
Use an emergency phone rather
than a mobile as emergency
services will then know the location
of the vehicle.
Never use a child seat in a front
passenger seat which is fitted with
an active airbag (SRS). Follow all
fitting instructions carefully.
Check seat positioning and security
before use.
VEHICLE INSTRUCTION CARD
TYRE PRESSURES (COLD)
CONTROLS
When parked, the handbrake (or electronic
parking brake) should be fully applied with the
vehicle left in first or reverse gear for vehicles
with manual transmission or P (Park) for
vehicles with automatic transmission.
CAUTION!
For assistance after an accident/incident, please call 0800 0280 999
For assistance after a breakdown or help with tyres or windscreens please refer to the numbers on the tax disc holder.
TYRE HELPLINE
In the event of having a punctured tyre
please call the Europcar Tyre Helpline
0800 0280 999 for ANY assistance.
NOTE: Vehicles are not usually supplied
with a tyre repair kit (for vehicles that use
this in lieu of a spare wheel).
PEUGEOT 308
VIC-PEU-06 / 11-02-2018
Remote control operated central deadlocking. Press the central locking button on the centre console to lock them from the
inside. Doors will auto lock when vehicle moves.
Passive arming of electronic engine immobiliser and alarm. Visible VIN plate.
Centrally locked. Use the remote control to unlock or open by using the internal remote release (hatchback only).
Internal electric internal adjustment operated via a control pad on the driver’s door.
Electric front and rear operated via control buttons on the driver’s door.
Some models may be fitted with an electric tilt / slide panoramic sunroof operated via roof mounted controls.
Located on the edge of the rear doors, turn the key slot to activate it. Or press the central locking button on the centre
console. Check from inside that the doors are securely locked.
Ensure gear selector is in neutral and parking brake is on. Place ignition key in starter switch. Or for keyless starting keep
the key in your pocket or handbag, and press the engine start/stop button adjacent to the gear lever to start or stop the
engine. Select desired gear. Release parking brake and brake pedal and gently press the accelerator to move the vehicle.
Vehicles feature auto start/stop technology whereby the engine turns off when vehicle is stationary, gears are in neutral and
foot pedals are not depressed - to instantly restart either depress the brake (auto models) or depress the clutch (manual).
Vehicles have a centrally locked fuel cap located under a flap on rear offside. Press the edge of the flap to open it, and twist
off the cap anticlockwise.
Pull bonnet release lever located on left hand side of front passenger footwell. Unhook catch under bonnet.
The rear seat is divided into 66:33 sections which can be folded separately (flat folding in the estate - some models also
have floor rails to help secure loads). To release the seat press the seat unlocking catch and fold the seat down. To return
the seat to normal use, raise the seat and push it firmly to engage the seat lock. Check it is locked before using the seat.
Vehicles are not normally supplied with a tyre repair kit or spare wheel. For any assistance in the event of having a
punctured tyre, or should the vehicle not be supplied with a spare wheel and tyre or a tyre repair kit, please call the
Europcar Tyre Helpline 0800 0280 999. Lift the recess cover inside the boot to access the spacesaver spare tyre. The
tools and jack are with the wheel. Move the vehicle to firm / level ground. Turn the engine off, select first gear (manual) or
P (automatic). Apply the handbrake or parking brake. Loosen the wheel nuts (do not remove them). Only use the specific
reinforced jack points on the underside of the vehicle. Crank the jack to lift the vehicle. Undo wheel nuts and change the
wheel. Lower the vehicle. Tighten the wheel nuts.
To change gears press the button on the shift lever and move the lever forwards or backwards in the gear gate. Select N
for neutral, Pwhen leaving the vehicle, Rfor reversing (the vehicle must be at a complete standstill before this gear can be
selected). For normal driving select Dwhere the transmission will use all available forward gears automatically (a ‘kickdown
‘ facility is provided when the accelerator is pressed all the way to the floor past the normal acceleration point forcing the
transmission to select a lower gear to obtain maximum acceleration. Release pressure on the accelerator to return to normal
accelerator use). Move the lever to lower left to use the manual + and - settings to manually change gear up or down by
pushing the lever forward or backward. Whenever the vehicle is at a standstill apply the electronic parking brake.
Tilt
Height
Legroom
5 SEATS
5 DOOR HATCH / 5 DOOR ESTATE
Ensure you use the correct fuel
type. Only use unleaded petrol
in petrol vehicles (see inside of
filler flap).
Fuel Tank Capacity:
53.0 litres
Check tyre pressure regularly
Legal minimum tread depth is 1.6 mm
195/65 R15
205/55 R16
225/45 R17
225/40 R18
235/35 R19
Check the tyre pressure table found on
the inside of driver’s door B-pillar (or fuel
filler cap).
Vehicles are fitted with an electronic tyre
pressure monitor. Driving speeds and
travel distance are restricted when using a
spacesaver spare wheel.
1Heating & Ventilation
2Hazard Lights
3Starter Switch
4Headlights
5Sidelights
6Indicators
7Wipers
8Rear Screen Wipers
9Horn
10 Bonnet Release
11 Heated Rear Screen
12 Rear Fog Lamp
13 Front Fog Lamp
14 Electronic parking brake
11
2
4 / 5 / 6 / 12 / 13
9
10
7 / 8
Important: the oil level must be
checked every 1000 miles.
1
Locking the doors?
Anti-theft system?
Opening the boot?
Adjusting door mirrors?
Opening the windows?
Operating the sunroof?
Using child door locks?
Starting the engine?
Opening fuel filler cap?
Releasing the bonnet?
Folding the rear seats?
How to change a tyre?
How to drive an
automatic?
9
or
P
R
N
D
1 3 5
2 4 6
R
+
-
14
Lumbar
3

USEFUL INFORMATION ABOUT YOUR VEHICLE
design and production by : Drake Enterprises Limited - [email protected]
CHILD SEATS
FUEL IN CASE OF BREAKDOWN DRIVER'S SEAT
Vehicle specifications are subject to change. When the engine is turned off, ensure that the starter switch is in position II when operating electrical items such
as door mirrors and windows, etc. This vehicle does not include any manufacturer handbooks or manuals.
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
Use hazard lights. Attempt to park
in a safe position.
Use an emergency phone rather
than a mobile as emergency
services will then know the location
of the vehicle.
Never use a child seat in a front
passenger seat which is fitted with
an active airbag (SRS). Follow all
fitting instructions carefully.
Check seat positioning and security
before use.
VEHICLE INSTRUCTION CARD
TYRE PRESSURES (COLD)
CONTROLS
When parked, the handbrake (or electronic
parking brake) should be fully applied with the
vehicle left in first or reverse gear for vehicles
with manual transmission or P (Park) for
vehicles with automatic transmission.
CAUTION!
For assistance after an accident/incident, please call 0800 0280 999
For assistance after a breakdown or help with tyres or windscreens please refer to the numbers on the tax disc holder.
TYRE HELPLINE
In the event of having a punctured tyre
please call the Europcar Tyre Helpline
0800 0280 999 for ANY assistance.
NOTE: Vehicles are not usually supplied
with a tyre repair kit (for vehicles that use
this in lieu of a spare wheel).
Remote control operated central deadlocking. Press the central locking button on the centre console to lock them from the
inside. Doors will auto lock when vehicle moves.
Passive arming of electronic transponder engine immobiliser and alarm.
Centrally locked. Use the key or remote control to unlock / open. Centrally locked. Use the remote control to unlock or open.
Some models feature remote hands-free opening via foot gesture activation of sensors under the flanks of the rear bumper.
Electric internal adjustment operated via a control pad on the driver’s door.
Electric front and rear, operated via control buttons on the driver’s door.
If fitted: Electric tilt / slide operated by roof mounted switchgear.
Use the roof mounted central locking switch / electric child lock to activate it. Check the doors are securely locked.
Ensure gear selector is in neutral and parking brake is on. Place ignition key in starter switch. Or for keyless starting keep
the key in your pocket or handbag, and press the engine start/stop button adjacent to the gear lever to start or stop the
engine. Select desired gear. Release parking brake and brake pedal and gently press the accelerator to move the vehicle.
Vehicles feature auto start/stop technology whereby the engine turns off when vehicle is stationary, gears are in neutral and
foot pedals are not depressed - to instantly restart either depress the brake (auto models) or depress the clutch (manual).
Located under flap on rear offside. Centrally locked. Lift the edge of the flap to open it, and twist off the cap anticlockwise.
Pull bonnet release lever located to the lower right of the instrument panel. Unhook catch under bonnet.
The rear seat is divided into 66:33 sections which can be folded separately. To release the seat press the seat unlocking
catch and fold the seat down. To return the seat to normal use, raise the seat and push it firmly to engage the seat lock.
Check it is locked before using the seat.
Vehicles are not normally supplied with a tyre repair kit or spare wheel. For any assistance in the event of having a
punctured tyre, or should the vehicle not be supplied with a spare wheel and tyre or a tyre repair kit, please call the
Europcar Tyre Helpline 0800 0280 999. Lift the recess cover inside the boot to access the spacesaver spare tyre. The
tools and jack are with the wheel. Move the vehicle to firm / level ground. Turn the engine off, select first gear (manual) or
P (automatic). Apply the handbrake or parking brake. Loosen the wheel nuts (do not remove them). Only use the specific
reinforced jack points on the underside of the vehicle. Crank the jack to lift the vehicle. Undo wheel nuts and change the
wheel. Lower the vehicle. Tighten the wheel nuts.
The shift lever can only be disengaged from Pwhen the brake pedal is pressed. Select Nfor neutral, Pwhen leaving the
vehicle, Rfor reversing (the vehicle must be at a complete standstill before this gear can be selected). For normal driving
select Dwhere the transmission will use all available forward gears automatically (a ‘kickdown ‘ facility is provided when the
accelerator is pressed all the way to the floor past the normal acceleration point forcing the transmission to select a lower
gear to obtain maximum acceleration. Release pressure on the accelerator to return to normal accelerator use). To manually
override normal Dusage use the M + or -selector to select higher or lower gears (use low gears for best engine braking for
driving in hilly terrain or hazardous conditions). Whenever the vehicle is at a standstill apply the handbrake. Use the rotary
grip control dial to automatically select various driving modes.
VIC-PEU-07 / 11-02-2018
PEUGEOT 3008
Tilt Legroom
Height
5 SEATS
5 DOOR CROSSOVER SUV
Ensure you use the correct fuel
type. Only use unleaded petrol
in petrol vehicles (see inside of
filler flap).
Fuel Tank Capacity:
45.0 litres or 50.0 litres (petrol)
Check tyre pressure regularly
Legal minimum tread depth is 1.6 mm
Check the tyre pressure table found on
the inside of driver’s door B-pillar (or fuel
filler cap).
R17, R18, R19
Vehicles are fitted with an electronic tyre
pressure monitor.
Note: driving speeds and travel distances
are restricted when using spacesaver
spare tyres.
Lumbar
Locking the doors?
Anti-theft system?
Opening the boot?
Adjusting door mirrors?
Opening the windows?
Operating the sunroof?
Using child door locks?
Starting the engine?
Opening fuel filler cap?
Releasing the bonnet?
Folding the rear seats?
How to change a tyre?
How to drive an
automatic?
1
2
3
4 / 5 / 6 / 12
99
10
7 / 8
11
13
14
or
P
R
N
M
1 3 5
2 4 6
R
+
-
1Heating & Ventilation
2Hazard Lights
3Engine Start / Stop
4Headlights
5Sidelights
6Indicators
7Wipers
8Rear Screen Wipers
9Horn
10 Bonnet Release
11 Heated Rear Screen
12 Rear Fog Lamp
13 Grip Control Dial
14 Electronic Parking Brake

USEFUL INFORMATION ABOUT YOUR VEHICLE
design and production by : Drake Enterprises Limited - [email protected]
CHILD SEATS
FUEL IN CASE OF BREAKDOWN DRIVER'S SEAT
Vehicle specifications are subject to change. When the engine is turned off, ensure that the starter switch is in position II when operating electrical items such
as door mirrors and windows, etc. This vehicle does not include any manufacturer handbooks or manuals.
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
Use hazard lights. Attempt to park
in a safe position.
Use an emergency phone rather
than a mobile as emergency
services will then know the location
of the vehicle.
Never use a child seat in a front
passenger seat which is fitted with
an active airbag (SRS). Follow all
fitting instructions carefully.
Check seat positioning and security
before use.
VEHICLE INSTRUCTION CARD
TYRE PRESSURES (COLD)
CONTROLS
When parked, the handbrake (or electronic
parking brake) should be fully applied with the
vehicle left in first or reverse gear for vehicles
with manual transmission or P (Park) for
vehicles with automatic transmission.
CAUTION!
For assistance after an accident/incident, please call 0800 0280 999
For assistance after a breakdown or help with tyres or windscreens please refer to the numbers on the tax disc holder.
TYRE HELPLINE
In the event of having a punctured tyre
please call the Europcar Tyre Helpline
0800 0280 999 for ANY assistance.
NOTE: Vehicles are not usually supplied
with a tyre repair kit (for vehicles that use
this in lieu of a spare wheel).
PEUGEOT 508 / 508 SW
VIC-PEU-08 / 10-01-2019
Remote control operated central deadlocking. Press the central locking button on the centre console to lock them from the
inside. Doors will auto lock when moving off, and auto-lock after 30 seconds if vehicle is not opened.
Passive arming of electronic engine immobiliser after removal of the key from the starter switch. Visible VIN plate. Vehicles
are fitted with an alarm system.
Centrally locked. Use the remote control to unlock or open by using the internal remote release. Some models feature
hands-free foot gesture controlled opening of the tailgate, activated by a sensor underneath the rear bumper.
Internal electric internal adjustment operated via a control knob on the driver’s door.
Electric front and rear operated via control buttons on the driver’s door.
Some models may be fitted with an electric tilt / slide panoramic glass sunroof with blind operated by roof mounted
switchgear.
Located on rear doors, press electronic switch to activate. Or press the central locking button on the centre console. Check
from inside that the doors are securely locked.
Ensure gear selector is in neutral and parking brake is on. Place ignition key in starter switch and use normal starting
routine. Or for keyless starting keep the key in your pocket or bag, and press the engine start/stop button adjacent to the
gear lever to start or stop the engine. Select desired gear. Release parking brake and brake pedal and gently press the
accelerator to move the vehicle. Vehicles feature auto start/stop technology whereby the engine turns off when vehicle is
stationary, gears are in neutral and foot pedals are not depressed - to instantly restart depress the foot pedals.
Most models have a centrally locked fuel cap located under a flap on rear offside. Lightly press the edge of the flap to open
it, and twist off the cap anticlockwise. Press the flap closed.
Pull bonnet release lever located on left hand side of front passenger footwell. Unhook catch under bonnet.
The rear seat is divided into 66:33 sections which can be folded separately. To release the seat press the seat unlocking
catch and fold the seat down. To return the seat to normal use, raise the seat and push it firmly to engage the seat lock.
Check it is locked before using the seat.
Vehicles are not normally supplied with standard space saver spare wheel or tyre repair kit. For any assistance in the event
of having a punctured tyre, or should the vehicle not be supplied with a spare wheel and tyre or a tyre repair kit,
please call the Europcar Tyre Helpline 0800 0280 999.
To change gears press the button on the shift lever and move the lever forwards or backwards in the gear gate. Select N
for neutral, Pwhen leaving the vehicle, Rfor reversing (the vehicle must be at a complete standstill before this gear can be
selected). For normal driving select Dwhere the transmission will use all available forward gears automatically (a ‘kickdown
‘ facility is provided when the accelerator is pressed all the way to the floor past the normal acceleration point forcing the
transmission to select a lower gear to obtain maximum acceleration. Release pressure on the accelerator to return to normal
accelerator use). Press the Mmode button for manual gear selection. Use the steering wheel paddle shift levers to manually
change gear up or down. Whenever the vehicle is at a standstill apply the electronic parking brake.
Tilt
Height
Legroom
5 SEATS
4 DOOR SALOON / 5 DOOR ESTATE
Ensure you use the correct fuel
type. Only use unleaded petrol
in petrol vehicles (see inside of
filler flap).
Fuel Tank Capacity:
62 or 55 litres (petrol / diesel)
Check tyre pressure regularly
Legal minimum tread depth is 1.6 mm
R17 215/55
R18 235/45
R19 235/40
Check the tyre pressure table found on
the inside of driver’s door B-pillar (or fuel
filler cap).
Some models may be fitted with an
electronic tyre pressure monitor.
1Heating & Ventilation
2Hazard Lights
3Engine Start / Stop
4Headlights
5Sidelights
6Indicators
7Wipers
8Rear Screen Wipers
9Horn
10 Bonnet Release
11 Heated Rear Screen
12 Rear Fog Lamp
13 Front Fog Lamp
14 Electronic parking brake
1
2
3
4 / 5 / 6 / 12 / 13
9
10
7 / 8
Important: the oil level must be
checked every 1000 miles.
11
Locking the doors?
Anti-theft system?
Opening the boot?
Adjusting door mirrors?
Opening the windows?
Operating the sunroof?
Using child door locks?
Starting the engine?
Opening fuel filler cap?
Releasing the bonnet?
Folding the rear seats?
How to change a tyre?
How to drive an
automatic?
9
or
P
R
N
D
1 3 5
2 4 6
R
+
-
Lumbar
14
