PEUGEOT Facelift 2008 User manual

HANDBOOK
2008

Access to the Handbook
ONLINE
View or download the handbook at the following
address:
http://public.servicebox.peugeot.com/APddb/
Scan this QR Code for direct access.
This symbol indicates the latest
information available.
Select:
– the language,
– the vehicle and body style,
– the issue period of the handbook corresponding to
the date of 1st registration of the vehicle.
MOBILE APPLICATIONS
Install the MYPEUGEOT APP application (content
available o󰀪ine).
Also available in the Scan MyPeugeot App
application.
TOUCH SCREEN (depending on availability)
In the Help touch screen application,
select the User Manual tab.
Several types of searches are available to access the
information sought.
For safety reasons, this application is not
accessible while driving above 3 mph (5 km/h).

Welcome
Thank you for choosing a Peugeot 2008 or a Peugeot e-2008.
This document contains the key information and recommendations you
will need to be able to explore your vehicle in complete safety. We strongly
recommend familiarising yourself with it, as well as the Maintenance and
Warranty Guide.
Your vehicle will be tted with only some of the equipment described in this
document, depending on its trim level, version and the specication for the
country in which it was sold.
The descriptions and illustrations are for guidance only.
Automobiles PEUGEOT reserves the right to modify the technical specications,
equipment and accessories without having to update this document.
If ownership of your vehicle is transferred, please ensure this Handbook is
passed on to the new owner.
Key
Safety warning
Additional information
Environmental protection feature
Left-hand drive vehicle
Right-hand drive vehicle
Location of equipment/button indicated using a
black area
For any work on your vehicle, contact a qualied workshop that has
the required technical information, skills and equipment, all of which
a PEUGEOT dealer is able to provide.

2
Contents
■
Overview
■
Eco-driving
1Dashboard instruments
Warning and indicator lamps 12
Indicators 19
Manual test 24
Total distance recorder 24
Lighting dimmer 24
Trip computer 25
Touch screen 26
Remotely operable additional functions (Electric) 28
2Access
Remote control / Key 30
Proximity Keyless Entry and Start 32
Central locking 34
Back-up procedures 35
Doors 37
Boot 38
Alarm 38
Electric windows 40
Sunroof 41
3Ease of use and comfort
PEUGEOT i-Cockpit 43
Front seats 43
Steering wheel adjustment 45
Mirrors 45
Rear bench seat 47
Heating and Ventilation 48
Automatic air conditioning 49
Front demisting/defrosting 52
Rear screen demisting/defrosting 52
Temperature pre-conditioning (Electric) 53
Interior ttings 53
Courtesy lamps 56
Interior ambient lighting 57
Boot ttings 57
4Lighting and visibility
Exterior lighting control stalk 59
Direction indicators 60
Headlamp beam height adjustment 61
Automatic illumination of headlamps 61
Guide-me-home and welcome lighting 62
Automatic lighting systems - General
recommendations 62
Automatic headlamp dipping 63
Wiper control stalk 64
Changing a wiper blade 66
Automatic wipers 66
5Safety
General safety recommendations 68
Event Data Recording system 68
Hazard warning lamps 69
Horn 69
Pedestrian horn (Electric) 69
Emergency or assistance 70
Electronic stability control (ESC) 72
Advanced Grip Control 74
Hill Assist Descent Control 75
Seat belts 76
Airbags 78
Child seats 80
Deactivating the front passenger airbag 82
ISOFIX child seats 83
i-Size child seats 84
Installing child seats 86
Child lock 89
6Driving
Driving recommendations 91
Starting / Switching o󰀨 the engine with the key 93
Starting/Switching o󰀨 the engine with
Keyless Entry and Start 94
Manual parking brake 96
Electric parking brake 96
6-speed manual gearbox 99
Automatic gearbox (EAT6) 99
Automatic gearbox (EAT8) 101
Drive selector (Electric) 103
Driving modes 104
Hill start assist 105
Gear shift indicator 106
Stop & Start 106
Tyre under-ination detection 108
Driving and manoeuvring aids -
General recommendations 110
Shortcuts for driving aids 111
Road signs recognition 112
Speed limiter 116
Cruise control - Specic recommendations 117
Cruise control 118
Drive Assist Plus 119
Adaptive cruise control 119
Lane positioning assist 123
Lane keeping assist 127
Blind spot monitoring 129

3
Contents
Active Safety Brake with Collision Risk Alert and
Intelligent emergency braking assistance 131
Distraction detection 134
Parking sensors 136
Visiopark 1 - Visiopark 2 138
7Practical information
Compatibility of fuels 144
Refuelling 144
Misfuel prevention (Diesel) 145
Electried vehicles - General recommendations 145
Charging system (Electric) 146
Charging the traction battery (Electric) 154
Towing device 158
Towing device with quickly detachable towball 159
Roof bars 161
Snow chains 162
Very cold climate screen 162
Energy economy mode 163
Bonnet 164
Engine compartment 165
Checking levels 166
Checks 168
AdBlue® (BlueHDi) 170
Free-wheeling 172
Advice on care and maintenance 173
8In the event of a breakdown
Warning triangle 176
Running out of fuel (Diesel) 176
Tool kit 176
Temporary puncture repair kit 178
Spare wheel 180
Changing a bulb 183
Fuses 185
12 V battery / Accessory battery 185
Towing the vehicle 189
9Technical data
Engine technical data and towed loads 192
Petrol engines 193
Diesel engines 194
Electric engines 195
Dimensions 196
Identication markings 196
10Touch screen 10" &
Bluetooth Radio & Telephone
First steps 197
Steering mounted controls 198
Menus 198
Radio 199
DAB (Digital Audio Broadcasting) radio 201
Media 201
Telephone 202
Applications 206
Settings 207
Frequently asked questions 208
11PEUGEOT i-Connect Advanced -
PEUGEOT i-Connect
First steps 211
Customisation 214
Steering mounted controls 215
Applications 215
Voice commands 216
Navigation 217
Connectivity 218
Mirror Screen 220
Media 221
Phone 223
Settings 224
Help 225
12Vehicle data recording and privacy
■
Alphabetical index
■
Appendix

4
Overview
Instruments and controls
These illustrations and descriptions are intended
as a guide. The presence and location of certain
elements may vary, depending on the version or
trim level.
1. Courtesy lamp/Front reading lamps
Emergency and assistance call buttons
Sunroof
Warning lamps display for seat belts and front
passenger airbag
2. Interior rear view mirror
3. Instrument panel
4. Fusebox
5. Electric windows
Electric door mirrors
6. Bonnet release
7. Front passenger airbag
8. Glove box
1. Touch screen
2. Switching the engine on/o󰀨
3. Central controls
4. USB socket(s)
5. Storage compartment or Wireless
smartphone charger
6. Storage compartment/12 V socket
7. Gearbox or drive selector
8. Electric parking brake
9. Choice of driving mode
Advanced Grip Control
10. Hill Assist Descent Control
Steering-mounted controls
1. Exterior lighting controls/Direction indicators/
Service indicator
2. Wiper/Screenwash/Trip computer controls
3. Automatic gearbox control paddles
4. Audio system controls
A. Select the instrument panel display mode

5
Overview
B. Voice commands
C. Decrease/Increase volume
D. Select previous/next media
Conrm a selection
E. Access the Telephone menu
Manage calls
F. Select an audio source
G. Display the list of radio stations/audio tracks
5. Horn/Driver front airbag
6. Controls for Cruise control/Speed limiter/
Adaptive cruise control
Side controls
1. LED technology headlamps beam height
adjustment
2. Lane positioning assist
3. Alarm
4. Electric child lock
Central controls
1. Heated seats
2. With Touch screen 10" & Bluetooth Radio &
Telephone:
Direct acces to the Driving menu
With PEUGEOT i-Connect Advanced -
PEUGEOT i-Connect:
Access to the Shortcuts for driving aids
3. With Touch screen 10" & Bluetooth Radio &
Telephone:
Access to the touch screen menus
With PEUGEOT i-Connect Advanced -
PEUGEOT i-Connect:
Access to the HOME pages
4. With Touch screen 10" & Bluetooth Radio &
Telephone:
Direct access to the Climate menu
With PEUGEOT i-Connect Advanced -
PEUGEOT i-Connect:
Direct access to the Climate application
5. Touch screen on/o󰀨/Adjust volume
6. Interior air recirculation
7. Thermal comfort system switch-o󰀨
8. Maximum air conditioning
9. Hazard warning lamps
10. Central locking
11. Front demisting/de-icing
12. Rear screen de-icing
Electric motor
1. Charging connectors
2. Traction battery
3. Accessory battery
4. Heat pump
5. On-board charger
6. Electric motor
7. Charging cable
The charging connectors 1enable 3 types of
charging:

6
Overview
– Domestic charging in mode 2 using a
domestic socket and associated charging cable
7.
– Accelerated charging in mode 3 using an
accelerated charging unit (Wallbox).
– Superfast charging in mode 4 using a fast
public charger.
The 400 V traction battery 2uses Lithium-Ion
technology. It stores and supplies the energy
required for the operation of the electric motor,
air conditioning and heating. Its charge level is
represented by an indicator and a reserve power
warning lamp on the instrument panel.
The 12 V accessory battery 3powers the
vehicle’s conventional electrical system. It is
recharged automatically by the traction battery
via the on-board charger.
The heat pump 4provides passenger
compartment heating and regulates traction
battery and on-board charger cooling.
The on-board charger 5manages the domestic
charging (mode 2) and accelerated charging
(mode 3) of the traction battery as well as the
recharging of the 12 V accessory battery.
The electric motor 6provides propulsion in
accordance with the selected driving mode and
driving conditions. It recovers energy during
vehicle braking and deceleration phases.
Labels
“Ease of use and comfort - Rear bench seat -
Rear head restraints” section:
"Ease of use and comfort - Front ttings -
Wireless smartphone charger" section:
"Lighting and visibility - Exterior lighting
control stalk" and "In the event of a
breakdown - Changing a bulb" sections:
"Safety - General safety recommendations -
Installing electrical accessories" section:
"Safety - Child seats - Deactivating the front
passenger airbag" section:
"Safety - ISOFIX mountings" section:
i-Size
TOP TETHER
"Driving - Electric parking brake" section:
"Driving - Stop & Start" section:
"Practical information - Compatibility of
fuels" section:
"Practical information - Charging system
(Electric)" section:
"Practical information - Charging the traction
battery (Electric)" section:
"Practical information - Bonnet" section:

7
Overview
"Practical information - Checking levels -
Engine coolant" section:
"In the event of a breakdown - Temporary
puncture repair kit" section:
"In the event of a breakdown - Spare wheel"
section:
"In the event of a breakdown - 12 V battery/
Accessory battery" section:
24V
12V

8
Eco-driving
Eco-driving
Eco-driving refers to a range of everyday
practices that allow the motorist to optimise
the vehicle's energy consumption (fuel and/or
electricity) and CO2emissions.
Optimise your use of the gearbox
With a manual gearbox, move o󰀨 gently and
change up promptly. While accelerating, change
up early.
With an automatic gearbox, favour automatic
mode. Do not depress the accelerator pedal
heavily or suddenly.
The gear shift indicator prompts you to engage
the most suitable gear. Whenever this indication
is displayed on the instrument panel, follow it
straight away.
With an automatic gearbox, this indicator
appears only in manual mode.
Drive smoothly
Maintain a safe distance between vehicles, use
engine braking rather than the brake pedal and
press the accelerator gradually. These practices
help to save on energy consumption, reduce
CO2 emissions and decrease general tra󰀩c
noise.
Favour the use of the "Eco" driving mode by
selecting it using the "DRIVE MODE" control.
With an EAT8 gearbox, with the gear selector in
mode D, and except in Sport mode, favour "free-
wheeling" by gradually lifting your foot fully o󰀨
the accelerator pedal in order to save fuel.
When the tra󰀩c is owing smoothly, select the
cruise control.
Control the use of electrical equipment
Before moving o󰀨, if the passenger compartment
is too warm, ventilate it by opening the windows
and air vents before using the air conditioning.
At speeds above 31 mph (50 km/h), close the
windows and leave the air vents open.
Consider using equipment that can help keep
the temperature in the passenger compartment
down (e.g. sunroof blind, window blinds).
Unless automatically regulated, switch o󰀨 the air
conditioning as soon as the desired temperature
has been reached.
Switch o󰀨 the demisting and defrosting functions,
if they are not managed automatically.
Switch o󰀨 the heated seat as soon as possible.
Adapt your use of the headlamps and/or
foglamps to the level of visibility, in accordance
with current legislation in the country in which
you are driving.
Avoid running the engine before moving o󰀨,
particularly in winter (other than in severe wintry
conditions: temperature below -23°C). The
vehicle will warm up much faster while driving.
As a passenger, avoid connecting your
multimedia devices (e.g. lm, music, video
game) to help reduce the consumption of energy.
Disconnect all portable devices before leaving
the vehicle.
Limit the causes of excess consumption
Spread loads throughout the vehicle. Place the
heaviest items in the boot as close as possible to
the rear seats.
Limit the loads carried in the vehicle and
minimise wind resistance (e.g. roof bars, roof
rack, bicycle carrier, trailer). Preferably, use a
roof box.
Remove roof bars and roof racks after use.
At the end of winter, remove snow tyres and ret
summer tyres.
Avoid using Sport mode for too long, in order to
limit your energy consumption.
Comply with the servicing instructions
Check tyre pressures regularly, with the tyres
cold, referring to the label in the door aperture on
the driver's side.
Carry out this check in particular:
– before a long journey.
– at each change of season.
– after a long period out of use.
Do not forget the spare wheel and, where
applicable, the tyres on your trailer or caravan.
Have your vehicle serviced regularly (e.g. engine
oil, oil lter, air lter, passenger compartment
lter, etc.). Observe the schedule of operations in
the manufacturer's service schedule.
With a BlueHDi Diesel engine, if the SCR system
has a fault, your vehicle will emit pollution. Visit
a PEUGEOT dealer or a qualied workshop
as soon as possible to restore your vehicle's
nitrogen oxide emissions to legal levels.

9
Eco-driving
When lling the fuel tank, do not continue after
the third cut-out of the nozzle, to avoid overow.
You will only see the fuel consumption of your
new vehicle settle down to a consistent average
after the rst 1,900 miles (3,000 kilometres).
Optimising the driving range (Electric)
The vehicle's consumption of electrical energy
greatly depends on the route, speed and driving
style, as well as the use of the heating/air
conditioning.
Try to remain in the "ECO" zone on the power
indicator, by driving smoothly and maintaining a
steady speed.
Program a destination into the vehicle's GPS
navigation system to optimise consumption
during a journey.
Anticipate the need to slow down, and brake
smoothly, whenever possible using engine
braking with the regenerative braking function,
which will move the power indicator into the
"CHARGE" zone.
Use the air conditioning rather than the heating
to demist the passenger compartment.

10
Dashboard instruments
Matrix instrument panel
Dials
Petrol / Diesel
Electric
1. Coolant temperature indicator (°C) (Petrol or
Diesel)
Thermal comfort consumption indicator
(Electric)
2. Analogue speedometer (mph or km/h)
3. Matrix display
4. Rev counter (x 1,000 rpm), graduation
depends on the engine (Petrol or Diesel)
Power indicator (Electric)
5. Fuel gauge (Petrol or Diesel)
Charge level indicator (Electric)
Matrix display
The matrix display can be personalised using a
system of pages.
1. Cruise control / speed limiter settings
Display of speed limit signs
2. Gear shift indicator (arrow and recommended
gear)
Selector position and gear on automatic
gearbox (Petrol or Diesel)
Drive selector position (Electric)
3. Personalisable area:
– Digital speedometer (mph or km/h)
– Display of driving aids
– Trip computer information
– Power ow / vehicle charge state (Electric)
4. Service indicator, then total distance recorder
(miles or km)
Remaining range (Electric)
These functions are displayed in turn when
the ignition is switched on.
Driving mode selected (other than "Normal"
mode)
Choosing the displayed
page
► Turn the thumbwheel on the left of the
steering wheel to display and scroll through the
various pages.
► Press the thumbwheel to conrm.

11
Dashboard instruments
1
If you do not press the thumbwheel, the selected
page is automatically applied after a few
moments.
Digital instrument panels
With PEUGEOT i-Connect Advanced -
PEUGEOT i-Connect
This head-up 2D or 3D digital instrument panel
can be personalised.
Depending on the display mode selected, some
information is hidden or presented di󰀨erently.
Example with the "Dials" display mode:
Petrol / Diesel
Electric
1. Remaining range (miles or km)
2. Fuel gauge (Petrol or Diesel)
Charge level indicator (Electric)
3. Digital speedometer (mph or km/h)
4. Cruise control/speed limiter settings
Display of speed limit signs
5. Gear shift indicator (arrow and recommended
gear)
Selector position and gear on automatic
gearbox (Petrol or Diesel)
Drive selector position (Electric)
Driving mode selected (other than "Normal"
mode)
6. Rev counter (x 1,000 rpm) (Petrol or Diesel)
Power indicator (Electric)
7. Total distance recorder (miles or km)
8. Coolant temperature indicator (°C) (Petrol or
Diesel)
The default pages are as follows:
– Dials.
– Minimal.
– Energy ows (Electric).
– Driving aids.
– Navigation (depending on equipment).
– Personal 1.
– Personal 2.
Information displayed on
the instrument panel
The information displayed on the instrument
panel (e.g. warning lamps, indicators) may have
a xed or variable location depending on the
page or the driving aid activated.
For the functions that have indicator lamps for
both operation and deactivation, there is only
one dedicated location.
Display language and units
These depend on the touch screen
settings.
When travelling abroad, the speed must be
shown in the o󰀩cial units of the country you
are driving in (mph, miles or km/h, km).
Choice of the displayed page
By default, pages are memorised in the
instrument panel.
► Turn the thumbwheel on the left of the
steering wheel to display and scroll through the
various pages on the instrument panel.
► Press the thumbwheel to conrm the page.
The new page is applied immediately.
If there is no action on the thumbwheel, the
selected display page is applied automatically
after a few moments.
When a message is displayed in a
temporary window, pressing this

12
Dashboard instruments
thumbwheel will cause this window to
disappear immediately.
Settings for displayed pages
The available settings operations are: addition,
deletion and layout of pages.
It is possible to memorise up to 5 pages.
The colour can also be congured according to
the selected driving mode.
The settings are changed via the
Settings > Customization touch screen
application.
Settings for a "Personal" display page
In the two additional personal pages, the types of
information available are as follows:
– Dynamic (Torque, Boost, Power).
– G-metres.
– Engine temperatures (Petrol or Diesel).
– Rev counter (Petrol or Diesel).
– Energy ows (Electric).
– Power indicator (Electric).
– Accessories consumption (Electric).
– Media.
– Trip computer.
– Driving aids.
– Navigation.
The type of information selected in the
"Personal 1" page is not available in the
"Personal 2" page.
The settings are changed via the
Settings > Customization touch screen
application.
For more information on Personalisation -
Instrument Panel, refer to the corresponding
section for the Audio equipment and telematics
systems.
Warning and indicator
lamps
Displayed as symbols, the warning and indicator
lamps inform the driver of the occurrence of a
malfunction (warning lamps) or of the operating
status of a system (operation or deactivation
indicator lamps). Certain lamps light up in two
ways (xed or ashing) and/or in several colours.
Associated warnings
The illumination of a lamp may be accompanied
by an audible signal and/or a message displayed
in a screen.
Relating the type of alert to the operating status
of the vehicle allows you to determine whether
the situation is normal or whether a fault has
occurred: refer to the description of each lamp
for further information.
When the ignition is switched on
Certain red or orange warning lamps come on
for a few seconds when the ignition is switched
on. These warning lamps should go o󰀨 as soon
as the engine is started.
For more information on a system or a function,
refer to the corresponding section.
Persistent warning lamp
If a red or orange warning lamp comes on, there
may be fault which needs further investigation.
If a lamp remains lit
The references (1), (2) and (3) in the warning
and indicator lamp description indicate whether
you should contact a qualied professional in
addition to the immediate recommended actions.
(1): You must stop the vehicle.
Stop as soon as it is safe to do so and switch o󰀨
the ignition.
(2): Contact a PEUGEOT dealer or a qualied
workshop.
(3): Go to a PEUGEOT dealer or a qualied
workshop.
List of warning and
indicator lamps
Red warning/indicator lamps
STOP
Fixed, associated with another warning
lamp, accompanied by the display of a
message and an audible signal.
A serious fault with the engine, braking system,
power steering or automatic gearbox or a major
electrical fault has been detected.
Carry out (1) and then (2).

13
Dashboard instruments
1
Engine self-diagnostics system (Petrol or
Diesel)
Fixed.
A major engine fault has been
detected.
Carry out (1) and then (2).
Maximum coolant temperature (Petrol or
Diesel)
Fixed with display blocks lit in red
(with matrix instrument panel).
or
Fixed (except on matrix instrument panel).
The temperature of the cooling system is too
high.
Carry out (1), then wait until the engine has
cooled down before topping up the level, if
necessary. If the problem persists, carry out (2).
Engine oil pressure (Petrol or Diesel)
Fixed.
There is a fault with the engine lubrication
system.
Carry out (1) and then (2).
System malfunction (Electric)
Fixed.
A fault involving the electric motor or
traction battery has been detected.
Carry out (1) and then (2).
Cable connected (Electric)
Fixed when the ignition is switched on.
The charging cable is connected to the
vehicle's connector.
Fixed when the ignition is switched on,
accompanied by a message.
It is not possible to start the vehicle while the
charging cable is connected to the vehicle’s
connector.
Disconnect the charging cable and close the
ap.
Traction battery overheating (Electric)
Fixed, combined with the STOP
warning lamp, accompanied by the
display of a message and an audible signal.
The traction battery's temperature is too high.
Carry out (1).
Evacuate the vehicle as quickly as possible
and move to a safe distance.
Carry out (2).
Traction battery malfunction (Electric)
Fixed, combined with the Service
warning lamp, accompanied by the
display of a message.
The traction battery has a fault.
Carry out (2).
12 V battery charge
Fixed.
The battery charging circuit is faulty
(e.g. dirty terminals, loose or severed alternator
belt).
Carry out (1).
If the electric parking brake stops working,
immobilise the vehicle:
► With the manual gearbox, engage a gear.
► With the EAT6 automatic gearbox, move the
gear selector to position P.
► With the EAT8 automatic gearbox or drive
selector, t the chock against one of the wheels.
Clean and tighten the terminals. If the warning
lamp does not go o󰀨 when the engine is started,
carry out (2).
Door(s) open
Fixed, associated with a message
identifying the access.
A door or the tailgate is not properly closed
(speed less than 6 mph (10 km/h)).
Fixed, associated with a message
identifying the access, accompanied by
an audible signal.
A door or the tailgate is not properly closed
(speed above 6 mph (10 km/h)).
Seat belts not fastened/unfastened
Fixed or ashing, accompanied by an
increasing audible signal.
A seat belt has not been fastened or has been
unfastened.
Manual parking brake
Fixed.
The parking brake is applied or not
properly released.
Electric parking brake
Fixed.
The electric parking brake is applied.
Flashing.
Application/release is faulty.

14
Dashboard instruments
Carry out (1): park on at ground (on a level
surface).
With a manual gearbox, engage a gear.
With an automatic gearbox or drive selector,
select mode P.
Switch o󰀨 the ignition and carry out (2).
Braking
Fixed.
The brake uid level in the braking circuit
has dropped signicantly.
Carry out (1), then top up with uid that complies
with the manufacturer's recommendations. If the
problem persists, carry out (2).
Fixed.
The electronic brake force
distribution (EBFD) system is faulty.
Carry out (1) and then (2).
Orange warning/indicator lamps
Service
Temporarily on, accompanied by the
display of a message.
One or more minor faults, for which there is/are
no specic warning lamp(s), have been detected.
Identify the cause of the fault using the message
displayed on the instrument panel.
You may be able to deal with some faults
yourself, such as changing the battery in the
remote control.
For other faults, such as with the tyre under-
ination detection system, carry out (3).
Fixed, accompanied by the display of a
message.
One or more major faults, for which there is/are
no specic warning lamp(s), have been detected.
Identify the cause of the fault using the message
displayed on the instrument panel, then carry
out (3).
Fixed, accompanied by the message
"Parking brake fault".
Automatic release of the electric parking brake is
unavailable.
Carry out (2).
Service warning lamp xed and
service spanner ashing then
xed.
The servicing interval has been exceeded.
The vehicle must be serviced as soon as
possible.
Only with BlueHDi Diesel engines.
Engine preheating (Diesel)
Temporarily on
(up to approximately 30 seconds in
severe weather conditions).
When switching on the ignition, if the weather
conditions and the engine temperature make it
necessary.
Wait until the warning lamp goes o󰀨 before
starting.
When the warning lamp goes o󰀨, starting will
occur immediately if you press and hold:
– the clutch pedal with a manual gearbox.
– the brake pedal with an automatic gearbox.
If the engine does not start, make the engine
starting request again, while keeping your foot
on the pedal.
Particle lter (Diesel)
Fixed, accompanied by an audible signal
and a message about the risk of particle
lter blockage.
The particle lter is nearing saturation.
As soon as tra󰀩c conditions allow, regenerate
the lter by driving at a speed of at least 37 mph
(60 km/h), with an engine speed of above 2,500
rpm, until the warning lamp goes o󰀨.
Fixed, accompanied by an audible signal
and a message indicating that the
additive level in the particle lter is too low.
The low level in the additive tank has been
reached.
Top up without delay: carry out (3).
Low fuel level (Petrol or Diesel)
Fixed, with the blocks lit red,
accompanied by an audible signal
(with the matrix instrument panel)
or
Fixed, with the reserve level shown in red,
accompanied by an audible signal and the
display of a message (except with the matrix
instrument panel).
When it rst comes on, there are approximately
5 litres of fuel remaining in the tank (reserve).
Until the fuel level is topped up, this alert will
be repeated every time the ignition is switched

15
Dashboard instruments
1
on, with increasing frequency as the fuel level
decreases and approaches zero.
Refuel without delay to avoid running out of fuel.
Never drive until completely empty, as
this could damage the emissions control and
injection systems.
Low traction battery level (Electric)
Fixed, accompanied by an audible signal.
The state of charge of the traction battery
is low.
View the remaining range.
Put the vehicle on charge as soon as possible.
Tortoise mode with limited driving range
(Electric)
Fixed.
The state of charge of the traction battery
is critical.
The engine power gradually decreases.
You must put the vehicle on charge.
If the warning lamp remains lit, carry out (2).
Engine self-diagnostic system (Petrol or
Diesel)
Flashing.
The engine management system has a
fault.
There is a risk that the catalytic converter will be
destroyed.
You must carry out (2).
Fixed.
The emissions control system has a fault.
The warning lamp should go o󰀨 when the engine
is started.
Carry out (3) without delay.
Engine self-diagnostics system (Petrol or
Diesel)
Fixed.
A minor engine fault has been
detected.
Carry out (3).
AdBlue®(BlueHDi)
On for around 30 seconds when starting
the vehicle, accompanied by a message
indicating the driving range.
The driving range is between 1,500 and 500
miles (2,400 and 800 km).
Top up the AdBlue®.
Fixed, on switching on the ignition,
accompanied by an audible signal and a
message indicating the driving range.
The driving range is between 500 and 62 miles
(800 and 100 km).
Promptly top up the AdBlue®, or carry out (3).
Flashing, accompanied by an audible
signal and a message indicating the
driving range.
The driving range is less than 62 miles (100 km).
You must top up the AdBlue®to avoid engine
starting being prevented, or carry out (3).
Flashing, accompanied by an audible
signal and a message indicating that
starting is prevented.
The AdBlue®tank is empty: the legally required
engine immobiliser system prevents the engine
from starting.
To restart the engine, top up the AdBlue®or carry
out (2).
It is essential to add at least 10 litres of AdBlue®
to the tank.
SCR emissions control system (BlueHDi)
Fixed when the ignition is switched
on, accompanied by an audible
signal and a message.
A malfunction of the SCR emissions control
system has been detected.
This alert disappears once the exhaust
emissions return to normal levels.
Flashing AdBlue®warning lamp on
switching on the ignition, with the
Engine self-diagnostics warning lamp on xed,
accompanied by an audible signal and a
message indicating the driving range.
Depending on the message displayed, it is
possible to drive for up to 685 miles (1,100 km)
before the engine immobiliser is triggered.
Carry out (3) without delay, to avoid starting
being prevented.
Flashing AdBlue®warning lamp on
switching on the ignition, with the
Engine self-diagnostics warning lamp on xed,
accompanied by an audible signal and a
message indicating that starting is prevented.
The engine immobiliser prevents the engine from
restarting (the permitted driving limit has been
exceeded after conrmation of a malfunction of
the emissions control system).
To start the engine, carry out (2).

16
Dashboard instruments
Automatic functions deactivated (electric
parking brake)
Fixed.
The "automatic application" (on switching
o󰀨 the engine) and "automatic release" (on
acceleration) functions are deactivated.
If automatic application/release is no longer
possible:
► Start the engine.
► Use the control to apply the electric parking
brake.
► Take your foot fully o󰀨 the brake pedal.
► Hold the control pressed in the release
direction for between 10 and 15 seconds.
► Release the control.
► Depress and hold the brake pedal.
► Pull the control in the application direction for
2 seconds.
► Release the control and the brake pedal.
Malfunction (with electric parking brake)
Fixed, accompanied by the
message "Parking brake fault".
The vehicle cannot be immobilised with the
engine running.
If manual application and release commands are
not working, the electric parking brake control is
faulty.
The automatic functions must be used at all
times and are automatically reactivated in the
event of a fault with the control.
Carry out (2).
Fixed, accompanied by the
message "Parking brake
fault".
The electric parking brake is faulty: manual and
automatic functions may not be working.
When stationary, to immobilise the vehicle:
► Pull the electric parking brake control and
hold it for approximately 7 to 15 seconds, until
the indicator lamp lights up on the instrument
panel.
If this procedure does not work, secure the
vehicle:
► Park on a level surface.
► With a manual gearbox, engage a gear.
► With an automatic gearbox or drive selector,
select mode P, then place the supplied chock
against one of the wheels.
Then carry out (2).
Collision Risk Alert/Active Safety Brake
Fixed, accompanied by the display of a
message.
The system has been deactivated via the touch
screen.
Flashing.
The system activates and brakes the
vehicle momentarily to reduce the speed of
collision with the vehicle in front.
For more information, refer to the Driving
section.
Fixed, accompanied by a message and
an audible signal.
The system has a fault.
Carry out (3).
Fixed.
The system has a fault.
If these warning lamps come on after the engine
is switched o󰀨 and then restarted, carry out (3).
Anti-lock braking system (ABS)
Fixed.
The anti-lock braking system has a fault.
The vehicle retains conventional braking.
Drive carefully at moderate speed, then carry
out (3).
Power steering
Fixed.
The power steering has a fault.
Drive carefully at moderate speed, then carry
out (3).
Dynamic stability control (DSC)/Anti-slip
regulation (ASR)
Fixed.
The system is deactivated.
The DSC/ASR system is reactivated
automatically when the vehicle is restarted,
and at speeds above approximately 31 mph
(50 km/h).
At speeds below 31 mph (50 km/h), it can be
reactivated manually.
Flashing.
DSC/ASR system regulation is activated
in the event of a loss of grip or trajectory.
Fixed.
The DSC/ASR system has a fault.
Carry out (3).

17
Dashboard instruments
1
Emergency brake malfunction (with
electric parking brake)
Fixed, accompanied by the
message "Parking brake fault".
Emergency braking does not deliver optimal
performance.
If automatic release is not available, use manual
release or carry out (3).
Hill start assist
Fixed, accompanied by the
message "Anti roll-back system
fault".
The system has a fault.
Carry out (3).
Road signs recognition
Fixed, accompanied by the display of a
message and an audible signal.
The system has a fault.
Carry out (3).
Fixed, accompanied by the display of the
message "Driving Assistance Sensor
blind: Clean sensor, see User Manual ".
The sensor is masked.
Stop as soon as it is safe to do so and switch o󰀨
the ignition.
Clean the front camera.
Lane keeping assist
Flashing.
You are about to cross a broken
lane marking without operating the direction
indicators.
The system is activated, then corrects the
trajectory if it detects a risk of unintentionally
crossing a line or hard shoulder (depending on
version).
For more information, refer to the Driving
section.
Fixed.
The system has been automatically
deactivated or placed on standby.
Fixed, accompanied by the display of the
message "Driving Assistance Sensor
blind: Clean sensor, see User Manual ".
The sensor is masked.
Stop as soon as it is safe to do so and switch o󰀨
the ignition.
Clean the front camera.
Fixed.
The system has a fault.
Carry out (3).
Driver Attention Warning by Camera
(Distraction detection)
Fixed.
The system is deactivated.
Fixed, accompanied by the display of a
message and an audible signal.
The system has a fault.
Carry out (3).
Fixed, accompanied by the display of the
message "Driving Assistance Sensor
blind: Clean sensor, see User Manual ".
The sensor is masked.
Stop as soon as it is safe to do so and switch o󰀨
the ignition.
Clean the front camera.
Lane positioning assist
Fixed, accompanied by the
Service warning lamp.
The system has a fault.
Carry out (3).
Airbags
Fixed.
One of the airbags or seat belt
pyrotechnic pretensioners is faulty.
Carry out (3).
Front passenger airbag (ON)
Fixed.
The front passenger airbag is activated.
The control is set to the "ON" position.
In this case, do not install a "rearward facing"
child seat on the front passenger seat - risk
of serious injury!
Front passenger airbag (OFF)
Fixed.
The front passenger airbag is deactivated.
The control is set to the “OFF” position.
A "rearward facing" child seat can be installed,
unless there is a fault with the airbags (Airbags
warning lamp on).
Parking sensors
Flashing.
The system detects an obstacle.
Fixed, accompanied by the display of a
message and an audible signal.
The system has a fault.
Carry out (3).

18
Dashboard instruments
Fixed, accompanied by the display of the
message "Parking Assistance Sensor
blind: Clean sensor, see User Manual ".
The sensor is masked.
Stop as soon as it is safe to do so and switch o󰀨
the ignition.
Clean the front and/or rear sensors.
Under-ination
Fixed.
The pressure in one or more tyres is too
low.
Check the pressure of the tyres as soon as
possible.
Reinitialise the detection system after adjusting
the pressure.
Under-ination warning lamp
ashing then xed and Service
warning lamp xed.
The tyre pressure monitoring system is faulty.
Under-ination detection is no longer monitored.
Check the tyre pressures as soon as possible
and carry out (3).
Stop & Start (Petrol or Diesel)
Fixed, accompanied by the display of a
message.
The Stop & Start system has been deactivated
manually.
The engine will not switch o󰀨 at the next tra󰀩c
stop.
Fixed.
The Stop & Start system has been
deactivated automatically.
The engine will not switch o󰀨 at the next tra󰀩c
stop, if the exterior temperature is:
– below 0°C.
– above +35°C.
For more information, refer to the Driving
section.
Flashing then xed, accompanied by a
message.
The system has a fault.
Carry out (3).
Automatic headlamp dipping
Fixed, accompanied by an audible signal
and a message.
A function or camera malfunction is detected.
Carry out (2).
Rear foglamps
Fixed.
The lamps are on.
Green warning/indicator lamps
Hill Assist Descent Control
Fixed.
The system has been activated, but the
conditions for regulation are not met (gradient,
speed too high, gear engaged).
Flashing.
The function is regulating the speed of
the vehicle.
The vehicle is being braked; the brake lamps
come on during the descent.
Stop & Start (Petrol or Diesel)
Fixed.
When the vehicle stops, the Stop & Start
system puts the engine into STOP mode.
Flashing temporarily.
STOP mode is momentarily unavailable
or START mode is automatically triggered.
For more information, refer to the Driving
section.
Vehicle ready to drive (Electric)
Fixed, accompanied by an audible signal
when it comes on.
The vehicle is ready to drive and the thermal
comfort systems are available.
The indicator lamp goes out upon reaching a
speed of approximately 3 mph (5 km/h) and
lights up again when the vehicle stops moving.
The lamp will go out when you switch o󰀨 the
motor and exit the vehicle.
Lane positioning assist
Fixed.
The function has been activated.
All conditions have been met: the system is
operating.
For more information, refer to the Driving
section.
Automatic wiping
Fixed.
Automatic windscreen wiping is activated.
Direction indicators
Flashing with audible signal.
The direction indicators are on.
