PEUGEOT 4008 User manual

Handbook

Familiarisation
Electronic key: Keyless Entry
and starting
This system allows you to lock, unlock and
start the vehicle while keeping the key on your
person and in the defined zone.
64
Welcome lighting
This additional exterior and interior lighting,
controlled remotely, makes your approach to
the vehicle easier when the light is poor.
136
Exterior Stop & Start function
(Auto Stop & Go)
This system puts the engine temporarily into
standby during stops in the traffic (traffic
lights, traffic jams, etc...). The engine restarts
automatically as soon as you want to move
off. The Stop & Start system reduces fuel
consumption and exhaust emissions, as well as
noise levels when stationary.
119
The door sill finishers are fragile. Do not
use them as a step.

.
5
Familiarisation
Temporary puncture repair kit
This kit is a complete system, consisting of a
compressor and a sealant cartridge, for the
temporary repair of a tyre.
170
Panoramic sunroof
This large glazed area provides incomparable
visibility and light in the passenger
compartment.
78
Reversing camera
This system is activated automatically on
engaging reverse and provides an image in the
colour screen.
130
Exterior
Front and rear parking sensors
This system warns you of the presence of
obstacles in front of or behind the vehicle when
manoeuvring forwards or backwards.
127

6
Familiarisation
Opening
A. Folding/unfolding the key.
B. Unlocking the vehicle.
C. Locking the vehicle.
Remote control
65
Unlocking
With the electronic key on your person and in
one of the defined zones A , press one of the
buttons B or C to unlock the vehicle, then pull
on the handle to open the door.
Locking
With the electronic key on your person and in
one of the defined zones A , press one of the
buttons B or C to lock the vehicle.
Keyless Entry and
Starting system
60
64

.
7
Familiarisation
Opening
Boot
Opening
After unlocking the vehicle with the remote
control or the Keyless Entry and Starting
system, press the handle A .
Closing
Pull the handle B downwards.
Fuel tank
A. Opening the filler flap.
71 207
B. Removing the filler cap.
C. Hooking the filler cap.
Capacity of the fuel tank: approximately 60 litres.
Bonnet
A. Interior release lever.
B. Exterior safety catch.
C. Bonnet stay.
204

8
Familiarisation
Interior
4-wheel drive system with
electronic control*
This system allows the selection of a
transmission mode, according to the driving
conditions.
CVT gearbox
This system offers driving combining a fully
automatic mode and a manual mode.
Digital air conditioning
This automatic air conditioning system maintains
the desired comfort level and adequate air
circulation in the passenger compartment.
Audio and communication
systems
These systems benefit from the following
technologies: radio, CD player, USB player,
Bluetooth system, satellite navigation system
with colour screen, auxiliary sockets.
AUDIO-TELEMATIC system
122
113
92
283
223
AUDIO-CD system
* Depending on version.

.
9
Familiarisation
Instruments and controls
1. Door mirror controls.
Electric window controls.
2. Bonnet release.
3. Fusebox.
4. Manual headlamp height adjustment.
Side switch panel.
5. Side adjustable air vent.
6. Instrument panel.
7. Lighting and direction indicator control
stalk.
8. Steering wheel adjustment control.
9. Controls for Bluetooth system or telephone.
10. Controls for Audio-CD and Audio-telematic
systems.
11. Driver's airbag.
Horn.
12. Cruise control switches.
13. Parking brake.

10
Familiarisation
Instruments and controls
1. Heated seat control.
2. Gear lever, CVT gearbox.
3. Steering lock and ignition.
4. Wiper / screenwash control stalk.
5. Steering mounted control paddles for the
CVT gearbox.
6. Windscreen demisting vent.
7. Passenger's airbag.
8. Glove box.
Passenger's airbag deactivation switch.
Back-up starting unit (with the "Keyless
Entry and Starting" system).
9. Front door glass demisting vent.

.
11
Familiarisation
Centre console
A. Rear view mirror, manual or automatic.
B. Courtesy lamp / Map reading lamps.
C. Microphone for Audio-CD et Audio-
telematic systems.
D. Control for panoramic sunroof blind.
E. Sunshine/rain sensor.
1. Central adjustable air vents.
2. Screen for the Audio-CD system or colour
screen for the Audio-telematic system.
3. START/STOP button.
Ignition switch.
4. Audio-CD system or Audio-telematic
system.
5. Central switch panel.
6. Temperature sensor.
7. Manual or digital heating / air conditioning
controls.
8. Gear lever, manual or CVT gearbox.
9. Cigarette lighter / 12 V accessory socket.
10. Portable ashtray.
11. Control for 4 wheel drive system.
12. Cup holder.
13. Front armrest.

12
Familiarisation
Sitting comfortably
Front seat
79
Manual adjustments
1. Seat forwards-backwards adjustment.
2. Driver's seat cushion height adjustment.
3. Seat backrest angle adjustment.
4. Head restraint adjustment.
Electric adjustments
1. Seat forwards-backwards adjustment.
2. Driver's seat cushion height and angle
adjustment.
3. Seat backrest angle adjustment.
80

.
13
Familiarisation
Sitting comfortably
Front armrest
82
Steering wheel adjustment
1. Release the steering wheel adjustment
mechanism.
2. Adjust for height and reach.
3.
Lock the steering wheel adjustment mechanism.
For your comfort, the front armrest is adjustable
longitudinally.
87
It also has two storage spaces; these can be
fitted with accessory sockets.
101 As a safety precaution, these
operations must only be carried out
when stationary.

1
Familiarisation
Sitting comfortably
Door mirrors
A. Selection of the mirror to adjust.
B. Adjusting the position of the mirror glass in
four directions.
C. Folding / Unfolding.
85-86
Rear view mirror
Manual day/night model
1. Selection of the "day" position of the mirror.
2. Adjustment of the mirror.
Automatic day/night model
87
A. Brightness detection in automatic day/night
mode.
B. Adjustment of the mirror.
1. Fastening the buckle.
2. Height adjustment.
Front seat belts
150

.
15
Familiarisation
Seeing clearly
Lighting
Ring A
Ring B
Wipers
131
Control A: windscreen wipers
138
Control B: rear wiper
141
Dipped / main beam headlamps.
Sidelamps.
Automatic illumination of headlamps.
Lighting off.
Front and rear foglamps.
Wash-wipe.
Intermittent wipe.
Park.
Switching On / Off "AUTO"
) Push the stalk downwards and release it.
140

16
Familiarisation
Ventilation
Digital air conditioning: we recommend use of automatic operation by pressing the "AUTO" button.
Recommended interior settings
I require...
Manual Air Conditioning
Air distribution Air flow Air recirculation /
Intake of outside air Temperature Manual A/C
HOT
COLD
DEMISTING
DEFROSTING

.
17
Familiarisation
Monitoring
A. Speedometer dial.
B. Instrument panel screen.
C. Rev counter dial.
D. Lighting dimmer.
E. INFO button.
Used to cycle through the different
information in the instrument panel screen.
Instrument panel
A. Passenger's airbag deactivation warning
lamp.
Central switch panel
155
1. With the ignition on, the orange and red
warning lamps come on.
2. With the engine running, these warning
lamps should go off.
If warning lamps remain on, refer to the page
concerned.
25
24
Warning lamps
145
151
B. Hazard warning lamps.
C. Front passenger's seat belt not fastened or
unfastened.

18
Familiarisation
Monitoring
A. Manual headlamp adjustment.
Side switch panel
137
1. Open the glove box.
2. Insert the key.
3. Select the position:
"OFF" (deactivation), with "rear facing"
child seat,
"ON" (activation), with front passenger or
"forwards facing" child seat.
4.
Remove the key keeping the switch in the new position.
Passenger's front airbag
155
B. Deactivation of the ASC/TCL system.
127
C. Deactivation of the parking sensors.
148
Passenger safety
120
D. Deactivation of the Stop & Start
(Auto Stop & Go) function.

.
19
Familiarisation
Driving safely
This six-speed gearbox offers the choice of the
ease of automatic operation or the pleasure of
manual gear changing.
1. Gear lever.
2. "-" steering mounted control paddle.
3. "+" steering mounted control paddle.
CVT gearbox
Display in the instrument panel
The driving mode selected and/or the gear
engaged appear in the instrument panel
screen.
P. Park.
R. Reverse.
N. Neutral.
D. Drive (Automated mode).
+/- . Manual mode with sequential gear
changes.
Moving off
From position P , with the parking brake applied:
) Press the brake pedal firmly.
) Start the engine.
) Then select position R , D or +/- .
) Release the parking brake.
) Progressively take your foot off the brake
pedal, the vehicle moves off on its own.
113

20
i
Familiarisation
Driving safely
Stop & Start
(Auto Stop & Go) function
Engine going into STOP mode
119
The "AS&G" warning lamp comes on in
the instrument panel or the instrument
panel screen and the engine is put into
standby after a few seconds:
Engine going into START mode
Deactivation / Reactivation
You can deactivate the system at any time
by pressing the "AS&G OFF" button; the
corresponding warning lamp comes on in
the instrument panel or the instrument panel
screen.
120
120
The system is reactivated automatically
every time you start the engine with the
key or with the START/STOP button.
The "AS&G" warning lamp goes off
and the engine restarts automatically:
- with a manual gearbox; when you fully
depress the clutch pedal.
- with a manual gearbox; with the vehicle
stationary and your foot on the brake pedal,
when you put the gear lever into neutral
and release the clutch pedal. In certain condition, START mode may engage
automatically; the "AS&G" warning lamp
flashes then goes off.
In certain circumstances the STOP mode may
not be available; the " AS &G" warning lamp
flashes for a few seconds then goes off.

.
21
Familiarisation
Driving safely
Three transmission modes are available and
selectable manually by the driver according to
requirements:
A. Two wheel drive (2WD),
B. Four wheel drive (4WD AUTO),
C. Four wheel drive (4WD LOCK).
Four wheel drive system
1. " ON / OFF " button: switches cruise control
on and off.
2. " COAST SET " button: programme a driving
speed then decrease the cruise speed.
3. " ACC RES ": increase the cruise speed,
and recall the programmed speed.
4. " CANCEL " button: cruise control off.
Cruise control "CRUISE"
124
In order to be programmed or activated, the
vehicle speed must be higher than 25 mph
(40 km/h), with at least second gear engaged.
122

22
Familiarisation
Eco-driving
Eco-driving is a range of everyday practices that allow the motorist to optimise their fuel consumption and CO2 emissions.
Optimise the use of your
gearbox
With a manual gearbox, move off gently,
change up without waiting and drive by
changing up quite soon. If your vehicle has
the system, the gear shift indicator invites you
to change up; it is displayed in the instrument
panel, follow its instructions.
With an automatic or electronic gearbox,
stay in Drive "D" or Auto "A" , according to
the type of gearbox, without pressing the
accelerator pedal heavily or suddenly.
Drive smoothly
Maintain a safe distance between vehicles,
use engine braking rather than the brake
pedal, and press the accelerator progressively.
These practices contribute towards a reduction
in fuel consumption and CO2 emissions and
also helps reduce the background traffic noise.
If your vehicle has cruise control, make use of
the system at speeds above 25 mph (40 km/h)
when the traffic is flowing well.
Control the use of your
electrical equipment
Before moving off, if the passenger
compartment is too warm, ventilate it by
opening the windows and air vents before using
the air conditioning.
Above 30 mph (50 km/h), close the windows
and leave the air vents open.
Remember to make use of equipment that can
help keep the temperature in the passenger
compartment down (sunroof and window
blinds...).
Switch off the air conditioning, unless it has
automatic digital regulation, as soon as the
desired temperature is attained.
Switch off the demisting and defrosting
controls, if not automatic.
Switch off the heated seat as soon as possible.
Switch off the headlamps and front foglamps
when the level of light does not require their
use.
Avoid running the engine before moving off,
particularly in winter; your vehicle will warm
up much faster while driving.
As a passenger, if you avoid connecting
your multimedia devices (film, music, video
game...), you will contribute towards limiting
the consumption of electrical energy, and so
of fuel.
Disconnect your portable devices before
leaving the vehicle.
