PEUGEOT Boxer User manual

PEUGEOT BOXER
HANDBOOK

Access to the Handbook
ONLINE
View or download the handbook at the following
address:
http://public.servicebox.peugeot.com/APddb/
Scan this QR Code for direct access.
This symbol indicates the latest
information available.
Select:
– the language,
– the vehicle and body style,
– the issue period of the handbook corresponding to
the date of 1st registration of the vehicle.
MOBILE APPLICATIONS
Install the Scan MyPeugeot App application (content
available o󰀪ine).
Also available in the MYPEUGEOT APP application.

Welcome
Thank you for choosing a Peugeot Boxer or a Peugeot e-Boxer.
This document contains the key information and recommendations you
will need to be able to explore your vehicle in complete safety. We strongly
recommend familiarising yourself with it, as well as the Maintenance and
Warranty Guide.
Your vehicle will be tted with only some of the equipment described in this
document, depending on its trim level, version and the specication for the
country in which it was sold.
The descriptions and illustrations are for guidance only.
Automobiles PEUGEOT reserves the right to modify the technical specications,
equipment and accessories without having to update this document.
If ownership of your vehicle is transferred, please ensure this Handbook is
passed on to the new owner.
Key
Safety warning
Additional information
Environmental protection feature
Left-hand drive vehicle
Right-hand drive vehicle
Location of equipment/button indicated using a
black area
Key
This key will help you identify the specic features of your vehicle:
Van Flatbed cab
Combi, minibus Double cab
Crew cab Tipper truck
Chassis cab
For any work on your vehicle, contact a member of the Manufacturer’s
dealer network, hereinafter referred to as a ‘dealer’, or a qualied
workshop.

2
Contents
■
Overview
■
Eco-driving
1Instruments
Instrument panel 8
Warning and indicator lamps 9
Indicators 13
Vehicle conguration (MODE) 15
Touch screen audio and multimedia system 21
Setting the date and time 21
Trip computer 22
Trip computer 22
2Access
Key 23
Remote control 23
Front doors 26
Sliding side door 26
Rear doors 27
Alarm 27
Electric windows 28
3Ease of use and comfort
Front seats 30
Front bench seat 31
Rear seats 32
Rear bench seat 32
Steering wheel adjustment 33
Mirrors 34
Heating and Ventilation 35
Heating/Manual air conditioning 35
Automatic air conditioning 36
Heating (Electric) 37
Additional heating systems 39
Rear heating/air conditioning 39
Additional programmable heating 40
Front demist - defrost 42
Rear screen de-icing 42
Cab layout 43
Rear ttings 47
Exterior ttings 49
4Lighting and visibility
Lighting control stalk 51
Direction indicators 51
LED daytime running lamps 51
Automatic headlamp dipping 52
Headlamp beam height adjustment 54
Wiper control stalk 54
Changing a wiper blade 55
5Safety
General safety recommendations 56
Hazard warning lamps 56
Horn 56
Pedestrian horn (Electric) 57
Electronic stability control (ESC) 57
Seat belts 60
Airbags 62
Child seats 63
Deactivating the front passenger airbag 65
ISOFIX seats 66
Child lock 68
6Driving
Driving recommendations 69
Starting-switching o󰀨 the engine 72
Battery standby system 73
Parking brake 74
Gearbox 74
Drive selector (Electric) 75
Gear shift indicator 75
Stop & Start 76
Hill start assist 77
Tyre under-ination detection 78
Pneumatic suspension 79
Driving and manoeuvring aids - General
recommendations 80
Road signs recognition 82
Speed limiter 83
Cruise control - Specic recommendations 85
Cruise control 85
Lane departure warning system 86
Blind spot monitoring with trailer detection 89
Active Safety Brake with Collision Risk Alert and
Intelligent emergency braking assistance 90
Rear parking sensors 93
Reversing camera 94
7Practical information
Fuel 96
Compatibility of fuels 97
Charging system (Electric) 97
Charging the traction battery (Electric) 101
Snow chains 103
Towing a trailer 104
Towbar with quickly detachable towball 104
Roof-mounted carrying system 107
Bonnet 107

3
Contents
Diesel engines 108
Electric motor 109
Checking levels 109
Checks 111
AdBlue® (BlueHDi engines) 114
Advice on care and maintenance 116
8In the event of a breakdown
Temporary puncture repair kit 118
Spare wheel 119
Changing a bulb 125
Fuses 129
12 V battery / Accessory battery 130
Towing 132
9Technical data
Engine technical data and towed loads 135
Diesel engines 136
Electric motor 137
Weights 138
Dimensions 141
Identication markings 145
Glossary of labels 146
10Special features
Crew cab 148
Chassis cab / Flatbed cab 148
Double cab 154
Drop-side back 157
11Audio system
First steps 162
Steering mounted controls 162
Radio 163
Media 163
Telephone 165
Settings 165
Voice commands 166
12Touch screen audio and telematics system
First steps 169
Steering mounted controls 170
Menus 170
Radio 171
DAB (Digital Audio Broadcasting) radio 172
Media 172
Navigation 174
Telephone 177
Vehicle information 179
Settings 179
Voice commands 180
13ALPINE® X902D system
First steps 184
Menus 185
14Event data recorders
■
Alphabetical index

4
Overview
Presentation
These illustrations and descriptions are intended
as a guide. The presence and location of certain
elements may vary, depending on the version or
trim level.
Instruments and controls
1. Instrument panel with display screen
2. Lighting control and direction indicator stalk
3. Wiper/Screenwash control stalk
Trip computer (Diesel)
4. Vehicle conguration/Headlamps beam
height/Front/rear foglamps
5. Steering mounted controls for the audio
system
6. Driver's front airbag/Horn
7. Ignition switch
8. Additional programmable heating (Diesel)
Heating (Electric)
9. Fusebox
10. Cruise control/speed limiter controls (Diesel)
11. Pneumatic suspension/Reading spotlamps/
Additional rear ventilation (Diesel)
Centre console
1. Audio system/Navigation
2. Heating/Air conditioning
3. Storage compartment/Removable ashtray
4. 12 volt accessory socket (180 W max)
5. USB socket/Cigarette lighter
6. Dynamic stability control (DSC/ASR)
Intelligent traction control (Diesel)
7. Hill Assist Descent Control
8. Lane departure warning system
9. Hazard warning lamps
10. Central locking
11. De-icing/Demisting
12. Gear lever (Diesel)
Drive selector (Electric)

5
Overview
Electric motor
1. Charging connector
2. Traction battery
3. 12 V accessory battery
4. On-board charger
5. Electric motor
6. Charging cable
The charging connector 1 allows 2 types of
charging:
– Accelerated charging in mode 3 using
an accelerated charging unit (Wallbox) and
associated charging cable 6.
– Superfast charging in mode 4 using a fast
public charger.
The 400 V traction battery 2uses Lithium-Ion
technology. It stores and supplies the energy
required for the operation of the electric motor,
air conditioning and heating. Its charge level is
shown on the display integrated into the rear
view mirror.
The 12 V accessory battery 3 powers the
vehicle’s conventional electrical system. It is
recharged automatically by the traction battery
via the on-board charger.
The on-board charger 4 provides accelerated
charging (mode 3) of the traction battery as well
as the recharging of the 12 V accessory battery.
The electric motor 5 provides propulsion in
accordance with the selected driving mode and
driving conditions. It recovers energy during
vehicle braking and deceleration phases.

6
Eco-driving
Eco-driving
Eco-driving refers to a range of everyday
practices that allow the motorist to optimise
the vehicle's energy consumption (fuel and/or
electricity) and CO2emissions.
Optimise your use of the gearbox
With a manual gearbox, move o󰀨 gently and
change up promptly. While accelerating, change
up early.
The gear shift indicator prompts you to engage
the most suitable gear. Whenever this indication
is displayed on the instrument panel, follow it
straight away.
Drive smoothly
Maintain a safe distance between vehicles, use
engine braking rather than the brake pedal and
press the accelerator gradually. These practices
help to save on energy consumption, reduce
CO2 emissions and decrease general tra󰀩c
noise.
If the vehicle has the steering-mounted
"CRUISE" control, use cruise control at speeds
above 19 mph (30 km/h) when the tra󰀩c is
owing smoothly.
Control the use of electrical equipment
Before moving o󰀨, if the passenger compartment
is too warm, ventilate it by opening the windows
and air vents before using the air conditioning.
At speeds above 31 mph (50 km/h), close the
windows and leave the air vents open.
Consider using equipment that can help keep
the temperature in the passenger compartment
down.
Unless automatically regulated, switch o󰀨 the air
conditioning as soon as the desired temperature
has been reached.
Switch o󰀨 the demisting and defrosting functions,
if they are not managed automatically.
Switch o󰀨 the heated seat as soon as possible.
Adapt your use of the headlamps and/or
foglamps to the level of visibility, in accordance
with current legislation in the country in which
you are driving.
Avoid running the engine before moving o󰀨,
particularly in winter (other than in severe wintry
conditions: temperature below -23°C). The
vehicle will warm up much faster while driving.
As a passenger, avoid connecting your
multimedia devices (e.g. lm, music, video
game) to help reduce the consumption of energy.
Disconnect all portable devices before leaving
the vehicle.
Limit the causes of excess consumption
Spread loads throughout the vehicle.
Limit the loads carried in the vehicle and
minimise wind resistance (e.g. roof bars, roof
rack, bicycle carrier, trailer). Preferably, use a
roof box.
Remove roof bars and roof racks after use.
At the end of winter, remove snow tyres and ret
summer tyres.
Comply with the servicing instructions
Check tyre pressures regularly, with the tyres
cold, referring to the label in the door aperture on
the driver's side.
Carry out this check in particular:
– before a long journey.
– at each change of season.
– after a long period out of use.
Do not forget the spare wheel and, where
applicable, the tyres on your trailer or caravan.
Have your vehicle serviced regularly (e.g. engine
oil, oil lter, air lter, passenger compartment
lter, etc.). Observe the schedule of operations in
the manufacturer's service schedule.
With a BlueHDi Diesel engine, if the SCR system
has a fault, your vehicle will emit pollution. Visit
a PEUGEOT dealer or a qualied workshop
as soon as possible to restore your vehicle's
nitrogen oxide emissions to legal levels.
When lling the fuel tank, do not continue after
the third cut-out of the nozzle, to avoid overow.
You will only see the fuel consumption of your
new vehicle settle down to a consistent average
after the rst 1,900 miles (3,000 kilometres).
Optimising the driving range (Electric)
The vehicle’s electrical consumption depends
heavily on the route, the vehicle speed and your
driving style.
Drive smoothly and maintain a steady speed.
Anticipate the need to slow down and brake
smoothly, whenever possible using engine
braking.

7
Eco-driving
Use the air conditioning rather than the heating
to demist the passenger compartment.
To heat the passenger compartment, select a
temperature between 16°C and 22°C.
You can monitor the real-time consumption of
electrical current on the display integrated into
the rear view mirror.

8
Instruments
Instrument panel
1. Speedometer (mph or km/h)
2. Display screen
3. Fuel gauge (Diesel)
4. Coolant temperature (Diesel)
5. Rev counter (rpm x 1,000) (Diesel)
Electric vehicles
The fuel gauge, coolant temperature
gauge and rev counter are inactive.
Level 1 display screen
In the lower part:
– Time.
– Outside temperature.
– Miles/Kilometres travelled.
– Trip computer (range, consumption, etc.)
(Diesel).
– Headlamp beam height.
– Programmable overspeed alert.
– Speed limiter or cruise control (Diesel).
– Gear shift indicator (Diesel).
– Stop & Start (Diesel).
In the upper part:
– Date.
– Service indicator.
– Alert messages.
– Function status messages.
– Vehicle conguration.
Level 2 display screen
In the left-hand part:
– Time.
– Outside temperature,
– Warning or status lamps.
– Speed limiter or cruise control (Diesel).
In the right-hand part:
– Date.
– Service indicator.
– Trip computer (range, consumption, etc.)
(Diesel).
– Alert messages.
– Function status messages.
– Vehicle conguration.
– Headlamp beam height.
– Miles/Kilometres travelled.
Brightness of the
instruments and controls
The brightness of the instruments and
controls can be adjusted using the MODE
button, with the sidelamps on.
For more information on Vehicle conguration
(MODE), refer to the corresponding section.
Display integrated into the
rear view mirror (Electric)
The interior rear view mirror contains a
dedicated display showing information about the
electrical system. It comes on when the ignition
is switched on and when the vehicle is being
charged.

9
Instruments
1
1. Traction battery charge level (%)
2. Remaining range (miles or km) or time
remaining before charging completes
3. Traction battery voltage (V)
4. Traction battery incoming/outgoing current
(A)
5. Drive selector position (D, N or R)
6. Vehicle status
7. Information messages and alerts
The level of current 4generated by the traction
battery is in proportion to the power used by the
electric motor.
If the level of current shown is negative, the
traction battery is currently being charged (either
by the charging system or by energy recovery
during driving).
You can temporarily deactivate
the display by pressing the button
located at the base of the rear view mirror.
The display is reactivated automatically every
time the ignition is switched on.
Warning and indicator
lamps
Displayed as symbols, the warning and indicator
lamps inform the driver of the occurrence of a
malfunction (warning lamps) or of the operating
status of a system (operation or deactivation
indicator lamps). Certain lamps light up in two
ways (xed or ashing) and/or in several colours.
Associated warnings
The illumination of a lamp may be accompanied
by an audible signal and/or a message displayed
in a screen.
Relating the type of alert to the operating status
of the vehicle allows you to determine whether
the situation is normal or whether a fault has
occurred: refer to the description of each lamp
for further information.
When the ignition is switched on
Certain red or orange warning lamps come on
for a few seconds when the ignition is switched
on. These warning lamps should go o󰀨 as soon
as the engine is started.
For more information on a system or a function,
refer to the corresponding section.
Warning lamp continuously
lit
The illumination of a red or orange warning lamp
indicates the occurrence of a fault that needs
further investigation.
If a warning lamp remains lit
The references (1), (2) and (3) in the warning
and indicator lamp description indicate whether
you should contact a qualied professional in
addition to the immediate recommended actions.
(1): You must stop the vehicle.
Stop as soon as it is safe to do so and switch o󰀨
the ignition.
(2): Contact a PEUGEOT dealer or a qualied
workshop.
(3): Go to a PEUGEOT dealer or a qualied
workshop.
List of warning and
indicator lamps
Red warning/indicator lamps
Coolant temperature
On H in the red zone or xed with the
needle in the red zone.
The coolant temperature is too high and/or has
abnormally increased.
Carry out (1), then wait until the engine has
cooled down before topping up the level, if
necessary. If the problem persists, carry out (2).
Engine oil pressure
Flashing, for a few seconds, accompanied
by a message in the display.
The engine oil quality is deteriorated.
Change the engine oil as soon as possible.
After a second alert level, engine performance
will be limited.

10
Instruments
Temporarily or permanently on, with the
engine running.
A lack of oil or a major malfunction is detected.
Carry out (1) then manually check the level.
If necessary, top up.
If the level is correct, carry out (2).
Battery charge
Fixed.
A malfunction in the charging circuit or the
battery is detected.
Check the battery terminals.
Fixed or ashing, despite the checks.
An ignition or injection malfunction is
detected.
Carry out (2).
Opening detection
Fixed.
One of the vehicle access openings is not
properly closed.
Check that the cab doors, the rear and side
doors and the bonnet are closed.
Power steering
Fixed, accompanied by an audible signal
and a message on the screen.
The power steering has a fault.
Drive carefully at moderate speed, then carry
out (3).
Airbags
Fixed or ashing.
One of the airbags or seat belt
pyrotechnic pretensioners is faulty.
Carry out (3).
Seat belt not fastened
Fixed, then ashing.
The driver has not fastened his seat belt.
Pull the strap then insert the tongue in the
buckle.
Accompanied by an audible signal, then
xed.
The vehicle is moving with the driver's seat belt
unfastened.
Check that the seat belt is fastened correctly by
pulling the strap.
Pneumatic suspension
Fixed.
The system has a fault.
Carry out (3).
Parking brake
Fixed.
The parking brake is applied or not
properly released.
Release the parking brake to switch o󰀨 the
warning lamp, keeping your foot on the brake
pedal.
Braking
Fixed.
The brake uid level is too low.
Carry out (1) then top up with uid that complies
with the Manufacturer's recommendations.
If the problem persists, carry out (2).
Fixed.
The electronic brake force
distribution (EBFD) system is faulty.
Carry out (1) and then (2).
Orange warning/indicator lamps
Service
Temporarily on.
One or more minor faults, for which there
is/are no specic warning lamp(s), have been
detected.
Carry out (2).
Fixed, accompanied by the display of a
message.
One or more major faults, for which there is/are
no specic warning lamp(s), have been detected.
Identify the cause of the fault using the message
displayed in the instrument panel, then carry out
(3).
Anti-lock braking system (ABS)
Fixed.
The anti-lock braking system has a fault.
The vehicle retains conventional braking.
Drive carefully at moderate speed, then carry
out (3).
Collision Risk Alert/Active Safety Brake
Fixed, accompanied by the display of a
message.
The system has been deactivated via the vehicle
conguration menu.
Flashing.
The system activates and brakes the
vehicle momentarily to reduce the speed of
collision with the vehicle in front.
For more information, refer to the Driving
section.

11
Instruments
1
Fixed, accompanied by a message and
an audible signal.
The system has a fault.
Carry out (3).
Fixed.
The system has a fault.
If these warning lamps come on after the engine
is switched o󰀨 and then restarted, carry out (3).
Brake pads
Fixed.
The front brake pads are worn.
Carry out (3) to replace the pads.
DSC / ASR
Flashing.
The system is operating.
The system optimises traction and improves the
directional stability of the vehicle.
Fixed, accompanied by an audible signal
and a message in the screen.
The DSC / ASR or hill start assist system has a
fault.
Carry out (2).
Fixed.
The Intelligent Traction Control has a
fault.
Carry out (2).
Front passenger airbag (OFF)
Fixed.
The front passenger airbag is deactivated.
A "rearward facing" child seat can be installed,
unless there is a fault with the airbags (Airbags
warning lamp on).
Particle lter (Diesel)
Fixed.
The particle lter is regenerating itself.
Leave the engine running until the warning lamp
goes o󰀨 so that regeneration can be completed.
Engine self-diagnostic system
Fixed.
A fault with the engine or the EOBD
emissions control system has been detected.
EOBD (European On Board Diagnosis) is a
diagnostics system which complies with, among
others, the standards on emissions limits of:
– CO (carbon monoxide),
– HC (unburnt hydrocarbons),
– NOx (nitrogen oxides), detected by oxygen
sensors placed downstream of the catalytic
converters and
– particles.
Carry out (3) quickly.
Tyre under-ination detection
Fixed.
A tyre is deated or punctured.
Carry out (1).
Change the wheel or repair the tyre.
Fixed.
A sensor is faulty.
Carry out (3).
Lane departure warning system
Flashing, accompanied by an
audible signal.
The involuntary crossing of a line on the left or
right has been detected.
Turn the steering wheel in the opposite direction
to return to the correct trajectory.
Fixed, accompanied by an audible signal.
The lane departure warning system is
faulty.
Clean the windscreen.
If the problem persists, carry out (3).
Electronic immobiliser
Fixed.
The ignition key inserted is not
recognised.
The engine cannot start.
Change key and carry out (3) to have the faulty
key checked.
On for about 10 seconds when the
ignition is switched on.
The alarm has been triggered.
Carry out (3) to have the locks checked.
Water in Diesel fuel lter(Diesel)
Fixed.
The Diesel lter contains water.
Carry out (2) without delay - risk of damage to
the injection system!
AdBlue
Fixed, then ashing accompanied by a
message in the display.
The driving range is decreasing.
You must quickly top up the AdBlue.
Low fuel level
Fixed, with the needle in zone E.
The fuel reserve is being used.
Refuel without delay.

12
Instruments
Flashing.
The system has a fault.
Carry out (2).
Diesel pre-heater
Fixed.
The climatic conditions mean that pre-
heating is necessary.
Wait until the indicator lamp goes o󰀨 before
starting the engine.
Rear foglamps
Fixed.
The button on the MODE control panel is
switched on.
The lamps only operate when the dipped beam
headlamps are on.
Under normal visibility conditions, switch them
o󰀨.
Green warning/indicator lamps
Direction indicators
Direction indicators with audible signal.
The direction indicators are on.
Front foglamps
Fixed.
The button on the MODE control panel is
switched on.
The lamps only operate when the dipped beam
headlamps are on.
Dipped beam headlamps
Fixed.
The lamps are on.
Cruise control
Fixed.
Cruise control is selected.
Manual selection.
Blue warning/indicator lamps
Main beam headlamps
Fixed.
The lamps are on.
Automatic headlamp dipping
Fixed.
The function has been activated via the
"MODE" menu.
Turning the main beam headlamps on and o󰀨 is
automatically controlled according to tra󰀩c and
driving conditions.
Black/white warning lamps
Temperature / Black ice
Fixed, accompanied by a message
in the display.
Climatic conditions can lead to black ice on the
road.
Be extra vigilant and avoid sudden braking.
Date / Time
Fixed.
It is set via the “MODE” menu.
Beam height
Fixed.
The headlamps are adjusted from position
0 to 3 depending on the load transported.
Adjust with the buttons on the MODE control
module.
Service spanner
Fixed.
Service is due.
Refer to the list of checks in the manufacturer's
service schedule then have the service carried
out.
Stop & Start
Fixed.
With the vehicle stationary (tra󰀩c lights,
stop sign, congestion, etc.), the Stop & Start
system puts the engine in STOP mode.
The indicator lamp goes o󰀨 and the engine
restarts automatically in START mode, as soon
as you move o󰀨.
Flashing for a few seconds, then goes o󰀨.
STOP mode is temporarily unavailable.
Gear shift indicator
Fixed.
The next higher gear may be engaged.
Speed limiter
Fixed.
The limiter is activated.
Fixed with "OFF".
The limiter is selected and not active.

13
Instruments
1
Indicators
Service information
When the ignition is turned on and for a few
seconds, the spanner symbolising servicing
information lights up: the display informs you of
the next servicing interval in accordance with the
Manufacturer's servicing schedule.
This information is based on the distance
travelled since the previous service.
Engine oil level
Depending on the engine, the engine oil level is
then displayed, on a scale of 1 (Min) to 5 (Max).
If no scale is displayed, the oil level is
insu󰀩cient; it is essential to top it up to prevent
engine damage.
For the measurement of this level to be valid, the
vehicle must be parked on horizontal ground,
with the engine having been o󰀨 for more than 30
minutes.
If in doubt, check the oil level using the
dipstick.
For more information on Checking levels,
refer to the corresponding section.
After a few seconds, the display returns to its
standard functions.
Engine oil quality
This warning lamp ashes and, if your
vehicle is equipped with this function, a
message is displayed at each start: the system
has detected a deterioration of the engine oil. It
is essential to change the oil as soon as
possible.
This 2nd warning lamp, coupled with the
1st, lights up on the instrument panel if the
oil change has not been carried out, and the
degradation of the oil has exceeded a new
threshold. If this warning lamp comes on at
regular intervals, the oil has to be changed as
soon as possible.
Resetting the service
indicator
A qualied workshop, equipped with the
diagnostic tool, will stop the permanent ashing
of the warning lamp after each service.
If you have serviced the vehicle yourself, reset
the service indicator as follows:
► Insert the key into the ignition switch.
► Turn it to the MAR - ON position.
► Simultaneously depress the brake and
accelerator pedals for more than 15 seconds.
Refer to the checklist in the
manufacturer's service schedule
provided on delivery of the vehicle.
Reminder of the servicing
information
To access the service indications at any
time, briey press the MODE button.
Use the up/down arrows to view service intervals
and engine oil quality.
Pressing the MODE button again allows you to
return to the various display menus.
A long press allows you to return to the home
screen.

14
Instruments
Menu... Select... Allows you
to...
Service Service
(miles/
km before
service)
Display the
remaining
miles/
kilometres to
be travelled
before the
next service.
Oil change
(miles/km
before oil
change)
Display the
remaining
miles/
kilometres to
be travelled
before the
next oil
change.
For more information on Vehicle
conguration (MODE), refer to the
corresponding section.
Coolant temperature
If the needle is positioned between C (Cold)
and H (Hot): normal operation.
In arduous conditions of use or hot climatic
conditions, the needle may move close to the red
graduations.
If the needle enters the red zone or if the
warning lamp lights up:
► stop immediately, turn the ignition o󰀨. The
cooling fan may continue to run for a while, up to
approximately 10 minutes.
► wait for the engine to cool down to check the
level and if necessary, top it up.
In case of topping up
Be careful, the cooling circuit is under pressure!
To avoid any risk of burns, take a cloth and
unscrew the cap two turns to relieve the
pressure.
When the pressure has dropped, check the level
and remove the cap to top up.
If the needle remains in the red zone,
contact a PEUGEOT dealer or a qualied
workshop.
Check the engine coolant level regularly.
For more information on Checking
levels, refer to the corresponding section.
AdBlue® uid ange
indicators
Once the AdBlue® tank is on reserve or after
detection of a fault with the SCR emissions
control system, when the ignition is switched on,
an indicator displays an estimate of the distance
that can be travelled before engine starting is
prevented.
In the event of a simultaneous system fault and
low AdBlue® level, the shortest-range gure is
the one displayed.
In the event of the risk of non-starting
related to a lack ofAdBlue®
The engine start prevention system
required by regulations is activated
automatically once theAdBlue®tank is empty.
Range greater than 1,500 miles (2,400 km)
When switching on the ignition, there is no
automatic display of range in the instrument
panel.
Range between 1,500 and 375 miles (2,400
and 600 km)
Once the 1,500 miles (2,400 km)
threshold is reached, this indicator
ashes, accompanied by a temporary message
indicating the driving autonomy expressed in
miles or kilometres before the starting of the
engine is blocked.
Each time the ignition is switched on, the alert
will be accompanied by an audible signal.
The reserve level has been reached; it is
recommended that you top up as soon as
possible.
Range less than 372 miles (600 km)

15
Instruments
1
Once the 372 miles (600 km) threshold is
reached, this indicator ashes,
accompanied by a message indicating the
driving autonomy expressed in miles or
kilometres before the starting of the engine is
blocked.
The alert will be repeated with update of the
remaining range at each increment of 31 miles
(50 km) travelled.
Each time the ignition is switched on, the alert
will be accompanied by an audible signal.
It is imperative to top up as soon as possible
before the tank empties completely. Otherwise
you will not be able to restart the vehicle.
Breakdown related to a lack of AdBlue®
0 mile/km range reached: the AdBlue®tank is
empty. An engine immobiliser system required by
legislation prevents starting of the engine.
Unless the AdBlue®is topped up in the
special additive tank, the vehicle will remain
immobilised.
To be able to restart the engine, you
must add at least 5 litres of AdBlue®. You
can also ask a PEUGEOT dealer or a
qualied workshop to carry out the necessary
top-up.
For more information on the AdBlue®
(BlueHDi engines), and in particular on
topping up, refer to the corresponding section.
In the event of a fault with the SCR
emissions control system
Detection
The Engine self-diagnostic warning lamp
comes on.
Each time the ignition is switched on, the audible
signal and a message conrm an emissions
control fault.
In the case of a temporary fault, the alert shall
disappear as soon as the level of exhaust
emissions returns to compliance with the
standard.
However, after 31 miles (50 km) travelled
with the warning lamp permanently on,
the fault is conrmed.
An engine immobiliser system will be
automatically activated once 250 miles
(400 km) have been travelled since this
conrmation.
Contact a PEUGEOT dealer or a qualied
workshop.
Fault conrmed
In addition to the previous indications, the
range allowed will be displayed in miles or
kilometres in the instrument panel.
The alert will be repeated every 30 seconds with
an update of the range.
Contact a PEUGEOT dealer or a qualied
workshop.
You may not be able to restart the vehicle.
Starting prevented, after the 250 miles
(400 km).
Whenever an attempt is made to start the
engine, the alert is activated and the
starting prevention message is displayed.
In order to be able to restart the engine:
Contact a PEUGEOT dealer or a qualied
workshop.
Vehicle conguration
(MODE)
This control panel gives access to menus in
order to customise some equipment.

16
Instruments
The corresponding information is displayed in
the instrument panel display screen.
Languages available: Italian, English, German,
French, Spanish, Portuguese, Dutch, Brazilian,
Polish, Russian, Turkish and Arabic.
All menus are accessible if the vehicle is
equipped with the audio system.
If the vehicle is equipped with the touch screen
audio and telematics system, some menus are
only accessible via its audio system control
panel.
For safety reasons, some menus are
only accessible with the ignition o󰀨.
This MODE button allows you to:
– access the menus and sub-menus,
– validate your choices, within a menu,
– exit menus.
A long press allows you to return to
the home screen.
This button allows you to:
– scroll up within a menu,
– increase a value.
This button allows you to:
– scroll down within a menu,
– decrease a value.
Menu...
Press... Sub-menu... Press... Select... Validate
and exit
Allows you to...
1Brightness
Increase Adjust the brightness of
the instrument panel and
instruments and controls
(with sidelamps on).
Decrease
2Speed beep
ON Increase Activate/Deactivate the
audible signal indicating that
the programmed speed has
been exceeded and select
the speed.
Decrease
OFF
3Headlamp sensor
Increase Adjust the sensitivity of the
brightness sensor (1 to 3),
which a󰀨ects the headlamps
Decrease

17
Instruments
1
Menu...
Press... Sub-menu... Press... Select... Validate
and exit
Allows you to...
4 Activation of Trip B
ON View a second "Trip B"
distance.
OFF
5 Tra󰀩c sign
ON Activate/Deactivate the
reading of signs.
OFF
6Time setting
Hours/Minutes Increase Set the clock.
Decrease
Format 24 Choose the clock display
mode.
12
7 Date setting
Year/Month/Day Increase Set the date.
Decrease
Menu…
Press... Sub-menu... Press... Select... Validate
and exit
Allows you to...
8Autoclose
ON Activate/Deactivate
automatic closing of the
doors above 12 mph (20
km/h).
OFF

18
Instruments
Menu…
Press... Sub-menu... Press... Select... Validate
and exit
Allows you to...
9Unit
Distance km Choose the distance display
unit.
miles
Consumption
mpg (km/l) Choose the consumption
display unit.
mpg (l/100 km)
Temperature
°C Choose the temperature
display unit.
°F
Tyre pressure psi Choose the tyre pressure
display unit.
bar
kPa
10 Languages List of available
languages
Choose the display
language.
11 Volume of
announcements
(Buzz)
Increase Increase/Decrease the
volume of announcements
or of the warning audible
signal.
Decrease
