PEUGEOT 5008 User manual

Handbook

PEUGEOT's SERVICE BOX Internet site permits easy
and free consultation of your vehicle documentation
on line.
Your vehicle lives on the Internet!
Access the latest information available.
Connect to http://public.servicebox.peugeot.com:
Simple and user friendly, SERVICE BOX allows you access:
Please note the following point:
The fitting of electrical equipment or accessories which are not recommended by PEUGEOT may result in a failure
of your vehicle’s electronic system. Please note this specific warning. It is advisable to contact a PEUGEOT dealer
to be shown the recommended equipment and accessories.
●to your Handbook,
●to previous Vehicle documentation.
select your language,
click on the link in the "Private customer access"
zone to consult the Vehicle documentation,
select your vehicle,
finally, click on the item which is of interest to you.
choose its body type then the date of publication
of the handbook,
A window opens giving access to all of the handbooks...

Page reference:
this symbol invites you to refer
to the pages which provide de-
tails of the function.
Key
Protection of
the environment:
this symbol accompanies
advice relating to protection of the en-
vironment.
Information:
this symbol draws your atten-
tion to additional information
for better use of your vehicle.
Warning:
this symbol marks warnings
which it is essential to observe
for your own safety, for the safety of
others or to avoid any risk of damaging
your vehicle.
WELCOME
Thank you for choosing a 5008, a symbol
of confidence, passion and inspiration.
This handbook has been designed to
enable you to make the most of your
5008.
On the first few pages, you will find a de-
tailed summary, followed by a quick refer-
ence guide intended to make it easier for
you to become familiar with your vehicle.
All of the details specific to your 5008,
comfort, safety, driving, are then pre-
sented in this handbook, to increase
your appreciation of the vehicle and to
help you make the most of it
At the end of the handbook, illustra-
tions of the interior and exterior of the
vehicle will assist you in locating equip-
ment or a function by means of the
page indexed.
Each model may only be fitted with
some of the equipment mentioned in
this handbook, depending on the trim
level, model, version and the specifica-
tion for the country in which it is sold.

CONTENT
S
FAMILIARISATION
4
-
24
INSTRUMENTS
a
nd CONTROLS 27-4
1
CHILD
SAFETY 116-127
MULTIFUNCTION
SCREEN
S
42-57
S
AFETY 12
8
-13
9
COMFORT 58-7
5
A
CCESS 76-90
V
ISIBILITY 91-10
1
FITTINGS 102-115
Instrument panels..........................
.
2
7
Indicator and warnin
g
lamps
..........
2
9
I
n
dica
t
o
r
s
........................................
3
7
Adj
ustment
b
uttons
.........................
4
1
C
hil
d
sea
t
s
.....................................
11
6
ISO
FIX child seats
........................
12
3
C
hild loc
k
......................................
1
2
7
Screen A without audio equipment
...
.
t
4
2
S
creen A with audio equipmen
t
......
4
4
S
creen
C
(
Peu
g
eot Connect Sound
)
............
4
6
1
6/9
r
e
tr
ac
t
ab
l
e
co
l
ou
r
sc
r
ee
n
(
Peu
g
eot
C
onnect Navi
g
ation
(
RNEG
))
.......................................
4
9
16/9 hi
g
h definition retractable
co
l
ou
r
sc
r
ee
n
(
Peu
g
eot
C
onnect Media
)
...........
.
5
1
Trip computer
.................................
r
5
4
D
ir
ec
ti
o
n in
d
i
ca
t
o
r
s
.......................
12
8
H
azard warnin
g
lamps
..................
12
8
Ho
r
n
.............................................
.
12
8
T
y
re under-inflation detectio
n
.......
1
2
9
E
SC s
y
stem
..................................
1
3
0
Fr
o
nt
sea
t
be
lt
s
.............................
1
3
2
Airba
g
s ........................................
.
13
6
H
eatin
g
and Ventilatio
n
..................
5
8
M
anua
l
a
i
r con
di
t
i
on
i
n
g
..................
6
0
Rear screen demist/defros
t
............
6
1
Dual-zone digital air conditionin
g
...
6
2
Fr
o
nt
sea
t
s
.....................................
6
5
Rear seats,
2
nd ro
w
.......................
6
9
Access to the
3
r
d
r
ow
.....................
7
1
Rear seats, 3rd ro
w
........................
7
2
S
eat modularit
y
..............................
7
3
M
irr
o
r
s
............................................
7
4
S
teerin
g
wheel ad
j
ustmen
t
.............
7
5
R
emote contro
l
k
e
y
........................
7
6
Ala
rm
..............................................
8
1
El
ec
tri
c
win
do
w
s
.............................
8
3
D
oo
r
s
..............................................
8
5
Boot
................................................
8
7
Fuel
t
a
n
k
.........................................
8
9
M
is
f
uel preventio
n
..........................
9
0
Ligh
t
i
n
g
contro
l
s
.............................
9
1
Au
t
o
m
a
ti
c
ill
u
min
a
ti
o
n
o
f
headlamps................................
9
4
H
eadlamp ad
j
ustmen
t
....................
9
4
Di
rect
i
ona
l
ligh
t
i
n
g
..........................
9
5
W
iper controls
................................
9
6
A
utomatic rain sensitive wipers
......
9
8
C
ourtes
y
lamps ..............................
9
9
I
nter
i
or moo
d
ligh
t
i
n
g
....................
1
0
0
I
nterior
f
ittin
g
s
...............................
10
2
C
entre consol
e
.............................
1
0
4
Rea
r m
u
ltim
ed
i
a
...........................
1
0
7
Panoramic sunroof
.......................
f
1
0
8
Boot
f
ittin
g
s 5 seat version..........
.
10
9
Boot fittin
g
s 7 seat version
............
1
1
0
E
CO-DRIVING 25-2
6

CONTENT
S
ALPHABETI
C
AL
INDEX
3
25-329
D
RIVING 140-17
0
CHECK
S
171-17
8
P
RACTICAL
INFORMATION 179-21
3
T
ECHNICAL
D
ATA 214-22
2
AUDIO EQUIPMENT
a
nd TELEMATICS 223-32
4
Electric parking brak
e
...................
14
0
H
ill
s
t
a
rt
ass
i
st
..............................
14
5
H
ead-up displa
y
...........................
14
8
Dis
t
a
n
ce
ale
r
t
...............................
1
5
0
Speed limiter
................................
r
15
2
C
r
u
i
se
co
ntr
ol
...............................
1
5
4
M
anual
g
earbo
x
............................
15
6
Gear efficiency indicator
...............
r
15
6
6
-speed electronic
g
ear control
g
earbo
x
......................................
15
7
A
utomatic
g
earbo
x
.......................
1
6
1
S
top
&
S
tar
t
..................................
16
4
P
ar
ki
n
g
sensors
............................
1
6
7
P
ar
ki
n
g
space sensors
.................
16
9
B
o
nn
et
..........................................
17
2
R
unnin
g
out o
f
f
uel
(
Diesel
)
..........
17
3
P
etro
l
en
gi
nes
..............................
1
7
4
Di
ese
l
en
gi
nes
..............................
17
5
C
heckin
g
levels
............................
17
6
C
h
ec
k
s
.
.........................................
17
7
T
emporar
y
puncture repa
i
r
kit
......
1
7
9
Changing a whee
l
.........................
1
8
8
C
han
g
in
g
a bul
b
...........................
1
9
4
C
han
g
in
g
a
f
us
e
...........................
19
9
12 V Batter
y
..................................
2
0
6
E
ner
gy
econom
y
mo
de
................
20
8
C
hanging a wiper blad
e
...............
20
8
Towin
g
the vehicl
e
.......................
.
20
9
Towing a trailer
.............................
r
21
0
Fittin
g
roof bars
.............................
2
1
1
V
er
y
cold climate scree
n
..............
21
2
A
ccesso
ri
es
..................................
21
3
P
etro
l
en
gi
nes
..............................
21
4
P
etrol weights
...............................
21
5
D
iesel en
g
ines.............................
.
21
6
D
iesel wei
g
hts
..............................
21
7
Di
m
e
n
sio
n
s
...................................
2
2
1
Identification markin
g
s
..................
22
2
E
mer
g
enc
y
or ass
i
stanc
e
.............
22
3
Peu
g
eot Connect Media
...............
2
2
7
Peugeot Connect Navigation
(
RNE
G)
.......................................
27
1
Peu
g
eot
C
onnect
S
ound
(
RD5
)
...
30
3
V
ISUAL
SEARCH
3
30-33
4

FA
M
4
EXTERIOR
Welcome lighting
This additional exterior and interior lighting,
controlled remotely, makes your approach
to the vehicle easier when the light is poor.
93
Stop & Start
This system puts the engine temporarily
into standby during stops in the traffic (red
lights, traffic jams, etc...). The engine re-
starts automatically as soon as you want
to move off. The Stop & Start system
reduces fuel consumption and exhaust
emissions and provides the comfort of
complete silence when stationary
164
Directional lighting
This lighting automatically provides addi-
tional visibility when cornering.
95
Panoramic sunroof
This roof provides incomparable visibility
and light in the passenger compartment.
108

5
EXTERIOR
Visual and audible front and/or rear
parking sensors
This system warns you if an obstacle is
detected behind or in front of the vehicle
in reverse or forward gear.
167
Parking space sensor
This system measures the size of the
parking space available between two ve-
hicles or obstacles.
169
Temporary puncture repair kit
This kit is a complete system, consisting
of a compressor and an integrated seal-
ant product, for the temporary repair of
a tyre.
179
When washing your vehicle in a car
wash:
- remove the aerial,
- fold back the mirrors.

FA
M
6
OPENING
Remote control ke
y
A. Unfolding/Folding the key.
Normal locking
(press once; fixed lighting of
the direction indicators).
Deadlocking the vehicle
(press twice in succession;
fixed lighting of the direction
indicators).
Complete or selective unlocking
of the vehicle
(rapid flashing of the direction
indicators).
or
76
When the light is poor, detected by a sen-
sor, the remote switching on of the dipped
beam headlamps and sidelamps makes
your approach to the vehicle easier.
This function can be programmed via
the configuration menu.
93
89
Fuel tank
1. Opening the fuel filler flap.
2. Opening and hooking the fuel filler
cap.
The type of fuel to be used is indicated
on the inner face of the fuel filler flap.
Capacity of the tank: approximately 60 litres.
Welcome li
g
htin
g
On Diesel vehicles, the fuel
filler neck incorporates a mis-
fuel prevention device which
prevents filling with petrol.

FA
M
7
OPENING
Boot Panoramic sunroof
1. Opening the blind.1. Unlocking the vehicle.
2. Opening the boot.
87 108
2. Closing the blind.

FA
M
8
INTERIOR
Electric parking brake
This combines the functions of automatic
application on switching off the engine and
automatic release on acceleration.
Manual application/release is possible.
140
Audio and communication systems
This equipment benefits from the latest tech-
nology: MP3 compatible Peugeot Connect
Sound (RD5), Peugeot Connect USB, Blue-
tooth, Peugeot Connect Navigation (RNEG)
or Peugeot Connect Media Navigation
(RT6) with 16/9 retractable colour screen,
JBL audio system, auxiliary sockets.
227
Head-up display
This system projects certain information
into the field of vision of the driver: speed,
cruise control/speed limiter and Distance
alert.
148
Dual-zone digital air conditioning
This system allows different levels of
comfort to be set for the driver and front
passenger. It then controls these levels
automatically according to the ambient
conditions.
62
Peugeot Connect
Navigation (RNEG)
271
303
Peugeot Connect Sound (RD5)
Peugeot Connect
Media Navigation (RT6) Peugeot Connect USB
250,
310
Bluetooth 255,
291,
313
PEUGEOT
Assistance
223

FA
M
9
INSTRUMENTS AND CONTROLS
1. Audio and telematics system
steering mounted control stalk.
2. Steering lock and ignition.
3. Wipers/screenwash/trip computer
control stalk.
4. Instrument panel.
5. Driver’s airbag.
Horn.
6. Gear lever.
7. Electric parking brake.
8. 12 V accessory socket.
9. Centre console.
10. Panoramic sunroof control.
11. Handbook storage compartment.
12. Manual headlamp adjustment.
Instrument panel navigator
associated with the Peugeot
Connect Media Navigation (RT6).
13. Alarm switch.
Parking sensors switch.
Dynamic stability control switch
(ESP/ASR).
Stop & Start deactivation switch.
14. Door mirror controls.
Electric window controls.
Child lock.
15. Front door window demist/defrost
vent.
16. Windscreen demist/defrost vent.

FA
M
1
0
INSTRUMENTS AND CONTROLS
1. Steering wheel adjustment.
2. Cruise control/speed limiter
switches.
3. Lighting and direction indicator
control stalk.
4. Central adjustable air vents.
5. Head-up display.
6. Multifunction screen.
7. Passenger’s airbag.
8. Side adjustable air vent.
9. Glove box - Audio/video sockets -
Passenger’s airbag deactivation.
10. Bonnet release.
11. 12 V accessory socket.
12. Heating/air conditioning controls.
13. Audio and telematics system.
14. Switches:
- head-up display,
- hazard warning lamps,
- Distance alert,
- central locking.

FA
M
11
SITTING COMFORTABLY
Driver's seat
Forwards-backwards Height
Manual ad
j
ustment
65
Electric ad
j
ustment
66
Seat back angle

FA
M
12
SITTING COMFORTABLY
Front seats
Head restraint height and angle
Lumbar
67
Steerin
g
wheel ad
j
ustment
1. Releasing the adjustment mechanism.
2. Adjustment of height and reach.
3. Locking the adjustment mechanism.
As a safety precaution, these operations
must only be carried out when stationary.
75
Centre console
This has a large storage area (with re-
cesses for 2 bottles, ...) for the front
passengers and, according to version,
a multimedia system for the rear pas-
sengers.
104,
107

1
3
SITTING COMFORTABLY
Door mirrors
Adjustment
A. Selection of the mirror to be adjusted.
B. Adjustment of the position of the
mirror in the four directions.
74
R
ear v
i
ew m
i
rro
r
Manual model
1. Selection of the "day" position of the
mirror.
2. Adjustment of the mirror.
75
Automatic day/night model
1. Adjustment of the mirror.
75
F
ront seat
b
e
l
ts
1. Fastening the buckle.
132
2. Height adjustment.
Also...
C. Folding/
Unfolding.

FA
M
14
SEEING CLEARLY
Li
g
htin
g
Ring A
Lighting off.
Ring B
Sidelamps.
Dipped/main beam headlamps.
Rear foglamp.
or
Front and rear foglamps.
Automatic illumination of
headlamps.
92
Direction indicators
Raise or lower the lighting stalk passing
the point of resistance; the corresponding
direction indicators will flash for as long as
the stalk remains in this position.
"Motorway" function
Press the lighting stalk up or down once,
without passing the point of resistance;
the corresponding direction indicators
will flash three times.
This function can be used at any speed,
but it is particularly useful when changing
lane on high-speed roads.
128
Wi
p
ers
Stalk A: windscreen wipers
Switching on "AUTO"
)Press the stalk down and release it.
Switching off "AUTO"
)Push the stalk up and return it to po-
sition "0".
98
Ring B: rear wiper
Park.
Intermittent wipe.
Wash-wipe.
97
91

FA
M
15
Digital air conditioning: we recommend use of the fully automatic mode by pressing the "AUTO" button.
V
ENTILATION
Recommended interior settin
g
s
I require...
Heating or Manual Air Conditioning
Air distribution Air flow Air recirculation/
Intake of outside air Temperature Manual A/C
HOT
COLD
DEMISTING
DEFROSTING

FA
M
1
6
MONITORING
Instrument
p
anel
A. With the ignition on, the needle
should indicate the level of fuel re-
maining.
B. With the engine running, its associated
low level warning lamp should go off.
C. With the ignition on, the oil level indicator
should display "OIL OK" for a few seconds.
If the levels are not correct, top up the
levels which are low.
27
1. With the ignition on, the orange and
red warning lamps come on.
2. With the engine running, these
warning lamps should go off.
If warning lamps remain on, refer to the
page concerned.
29
Switch panels
Lighting of the indicator lamp indicates the
status of the corresponding function.
A. Parking space
sensors. 169
165
81
167
131
127
148
128
B. Deactivation of Stop &
Start.
C. Volumetric alarm.
D. Visual and audible
parking sensors.
E. ESP OFF.
F. Child lock.
G. Head-up display.
H. Hazard warning lamps.
Lower
Central
150
I. Distance alert.
86
J. Central locking.

FA
M
17
PASSENGER SAFETY
Passen
g
er's front airba
g
1. Insert the key.
2. Select the position:
"OFF" (deactivation), with "rear facing"
child seat,
"ON" (activation), with front passenger
or "forwards facing" child seat.
3. Remove the key keeping the switch
in the new position.
137
f
ront airba
g
A. Front and/or rear seat belts not fas-
tened/unfastened warning lamp.
B. Front left seat belt warning lamp.
C. Front right seat belt warning lamp.
D. Rear right seat belt warning lamp.
E. Rear centre seat belt warning lamp.
F. Rear left seat belt warning lamp.
G. Passenger's front airbag deactivated
warning lamp.
H. Passenger's front airbag activated
warning lamp.
133
Child lock
(
lockin
g
of the rear doors
)
Lighting of the indicator lamp indicates the
status of the corresponding function.
127
7 seat version (3rd row)
I. Rear right seat belt warning
lamp.
J. Rear left seat belt warning
lamp.

FA
M
1
8
ARRANGING YOUR SEATS
Ri
g
id panel
P
utt
i
n
g
t
h
e seats
b
ac
k
i
n p
l
ace
)Raise the seat back and push it
rearwards until it locks.
From the boot
)Pull the strap Bto release the seat
and push the seat back forwards
gently.
Foldin
g
the seats in the 2nd row
)Pull the strap Aupwards firmly to re-
lease the seat and continue to pull
until the seat is fully folded.
Access to the 3rd row seats
)Close the aircraft style tables on the
2nd row seats if they are open.
)Hold the control Dup, the seat is
released and the seat base rises to
the seat back.
)Push the seat back forwards, holding
the control Dforwards.
7170
71
7 SEAT VERSION
)After folding the seats, slide the
catch C.
