PFS KP60 User manual

United States Stove
Company
Project # 18-409
Model: KP60
AKA: AP60, VG60
Type: Pellet-Fired Room Heater
May 31, 2018
Revised: September 7, 2021
ASTM E2779 Standard Test Method for
Determining Particulate Matter
Emissions from Pellet Heaters
Contact: Mr. Brandon Barry
227 Industrial Park Road
South Pittsburg, TN 37380
[e-mail]
[phone] ext. 4513
Prepared by: Sebastian Button,
Laboratory Supervisor
11785 SE Highway 212 – Suite 305
Clackamas, OR 97015-9050
[phone]
WWW.PFSTECO.COM

Project # 18-409
Model: KP60
Page | 1
Revision Summary
Date: May 31, 2018 – Original Issue
Date: September 7, 2021 – The following revisions were made per request from EPA:
-The “Run Narrative” section was edited to discuss negative filter weights reported during test Run
1, see page 9.
-The test data sheets in Appendix A were updated to show train precision percentage data, see
page 21 of Non-CBI Report.
-Warranty information that is provided with the Owner’s Manual has been included in Appendix B,
see page 67 of Non-CBI Report.

Project # 18-409
Model: KP60
Page | 2
Contents
Affidavit ......................................................................................................................................................... 3
Introduction ................................................................................................................................................... 4
Notes ......................................................................................................................................................... 4
Pellet Heater Identification and Testing ........................................................................................................ 5
Test Procedures and Equipment .................................................................................................................. 6
Results .......................................................................................................................................................... 7
Summary Table ......................................................................................................................................... 7
Test Run Narrative .................................................................................................................................... 8
Run 1 ..................................................................................................................................................... 8
Test Conditions Summary............................................................................................................................. 8
Appliance Operation and Test Settings .................................................................................................... 8
Settings & Run Notes ................................................................................................................................ 8
Appliance Description ................................................................................................................................... 9
Appliance Dimensions............................................................................................................................... 9
Test Fuel Properties .................................................................................................................................... 12
Pellet Fuel Analysis ................................................................................................................................. 13
Sampling Locations and Descriptions ......................................................................................................... 14
Sample Points ......................................................................................................................................... 14
Sampling Methods ...................................................................................................................................... 15
Analytical Methods Description ................................................................................................................... 15
Calibration, Quality Control and Assurances .............................................................................................. 15
Appliance Sealing and Storage................................................................................................................... 15
Sealing Label .......................................................................................................................................... 15
Sealed Unit.............................................................................................................................................. 16
List of Appendices ....................................................................................................................................... 17

Project # 18-409
Model: KP60
Page | 3
Affidavit
PFS-TECO was contracted by United States Stove Company to provide testing services
for the KP 60 Pellet-Fired Room Heater (See Appliance Specifications section for full
breakdown of series models) per ASTM E2779, Determining PM Emissions from Pellet
Heaters. All testing and associated procedures were conducted at PFS-TECO’s
Portland Laboratory on 4/23/2018. PFS-TECO’s Portland Laboratory is located at 11785
SE Highway 212 – Suite 305, Clackamas, Oregon 97015. Testing procedures followed
ASTM E2779. Particulate sampling was performed per ASTM E2515, Standard Test
Method for Determination of Particulate Matter Emissions Collected by a Dilution
Tunnel.
PFS-TECO is accredited by the U.S. Environmental Protection Agency for the
certification and auditing of wood heaters pursuant to subpart AAA of 40 CFR Part 60,
New Source Performance Standards for Residential Wood Heaters and subpart QQQQ
of 40 CFR Part 60, Standards of Performance for New Hydronic Heaters and Forced Air
Furnaces, Methods 28R, 28WHH, 28 WHH-PTS, and all methods listed in Sections
60.534 and 60.5476. PFS-TECO holds EPA Accreditation Certificate Numbers 4 and
4M (mobile). PFS-TECO is accredited by IAS to ISO 17020:2012 “Criteria for Bodies
Performing Inspections, By A2LA to ISO 17025:2005 “Requirements for Testing
Laboratories”, and by Standards Council of Canada to ISO 17065:2012 “Requirements
for Bodies Operating Product Certification Systems”.
The following people were associated with the testing, analysis and report writing
associated with this project.
Sebastian Button, Laboratory Supervisor

Project # 18-409
Model: KP60
Page | 4
Introduction
United States Stove Company of South Pittsburg, TN, contracted with PFS-TECO to
perform EPA certification testing on KP60 Pellet-Fired Room Heater. All testing was
performed at PFS-TECO’s Portland Laboratory. Testing was performed by Mr.
Sebastian Button.
Notes
• Prior to start of testing, 50 hours of conditioning was performed by the
manufacturer at a medium test setting per ASTM E2779
• Prior to start of testing, the dilution tunnel was cleaned with a steel brush.
• Front filters were changed on sample train A at one hour after the test began.
• A single, integrated test run, in accordance with ASTM E2779 was performed:
o The medium burn rate setting used was the same as the low burn rate
setting, as that is the only setting the yields a burn rate of <50% of the
high burn rate, as required by ASTM E2779.

Project # 18-409
Model: KP60
Page | 5
Pellet Heater Identification and Testing
• Appliance Tested: KP60
• Serial Number: N/A – Prototype Unit
• Manufacturer: United States Stove Company
• Catalyst: No
• Heat exchange blower: Integral
• Type: Pellet Stove
• Style: Free Standing
• Date Received: Wednesday, March 21, 2018
• Wood Heater Aging: March 22, 2018 – April 19, 2018
• Testing Period – Start: Monday, April 23, 2018 Finish: Monday, April 23,
2018
• Test Location: PFS-TECO Portland Laboratory, 11785 SE HWY 212 - Suite
305, Clackamas, OR 97015
• Elevation: ≈131 Feet above sea level
• Test Technician(s): Sebastian Button
• Observers: N/A

Project # 18-409
Model: KP60
Page | 6
Test Procedures and Equipment
All Sampling and analytical procedures were performed by Sebastian Button. All
procedures used are directly from ASTM E2779 and ASTM E2515. See the list below
for equipment used. See Appendix C submitted with this report for calibration data.
Equipment List:
Equipment ID#
Equipment Description
041
Rice Lake 3'x3' floor scale w/digital weight indicator
053
APEX XC-60 Digital Emissions Sampling Box A
054
APEX XC-60 Digital Emissions Sampling Box B
055
APEX Ambient sampling box
057
California Analytical ZRE CO2/CO/O2 IR ANALYZER
109A/B
Troemner 100mg/200mg Audit Weights
107
Sartorius Analytical Balance
051
10 lb audit weight
095
Anemometer
111
Microtector
CC144992
Gas Analyzer Calibration Span Gas
CC332147
Gas Analyzer Calibration Mid Gas

Project # 18-409
Model: KP60
Page | 7
Results
The integrated test run emission rate for test Run 1 was measured to be 1.46 g/hr with
a Higher Heating Values efficiency of 66.2% and a CO emission rate of 0.29
g/min. The calculated first hour particulate emission rate was 2.01 g/hr. The United
States Stove Company Model KP60 Pellet-Fired Room Heater meets the 2020 PM
emission standard of ≤ 2.0 g/hr per CFR 40 part 60, §60.532 (b).
Detailed individual run data can be found in Appendix A submitted with this report.
Summary Table
Run
Number
Date
Segments
Run
Time
(min)
Heat
Output
(BTU/hr)
1st Hr
Emissions
(g/hr)
Integrated
Total
(g/hr)
CO
Emissions
(g/min)
Overall CO
Emissions
(g/min)
Heating
Efficiency
(%HHV)
Overall
Heating
Efficiency
(%HHV)
Setting
BR
1
4/23/2018
H
1.63
60
20700
2.01
1.46
0.20
0.29
68.5%
66.2%
M
0.77
120
9192
0.34
64.2%
L
0.70
180
8476
0.27
65.2%
OA
0.88
360
10800
0.29
66.2%

Project # 18-409
Model: KP60
Page | 8
Test Run Narrative
Run 1
Run 1 was performed on 4/23/2018 as an attempted integrated test run per ASTM
E2779. The overall test duration was 360 minutes. The particulate emissions rate for the
integrated test run was 1.46 g/hr. The run had an overall HHV efficiency of 66.2%. The
Trian A front filter was changed at 1 hr.
Upon completion of testing, lab analysis of the rear sample filters for the Train A post 1st
hour and Train B samples yielded a negative number (-0.1 mg). This was the result of a
portion of the filter attaching to O-ring seal and pulling away from the filter. This is
reflected in the weight of the catch on the O-rings for this given run (0.5 mg and 0.9 mg,
for Trains A and B, respectively). While this type of result is somewhat infrequent, it is
with this type of occurrence in mind that O-rings are also included in the test analysis.
The negative values report during this run should be considered valid and appropriately
handled. All other test results were appropriate and valid. There were no other
anomalies and all test criteria were met.
Test Conditions Summary
Testing conditions for all runs fell within allowable specifications of ASTM E2779 and
ASTM E2515. A summary of facility conditions, fuel burned, and run times is listed
below.
Runs
Ambient (°F)
Relative
Humidity (%)
Average
Barometric
Pressure
(In. Hg.)
Preburn
Fuel
Weight
(lbs)
Test Fuel
Weight
(lbs)
Test Fuel
Moisture
(%DB)
Test Run
Time
(Min)
Pre
Post
Pre
Post
1
68
73
32.4
27.9
30.07
6.3
12.3
6.0
360
Appliance Operation and Test Settings
The appliance was operated according to procedures as described in the Operations
Manual, found in Appendix B submitted with this report. Detailed run information can be
found in Appendix A submitted with this report.
Settings & Run Notes
Pre-Burn
Test Run
Run 1
Heat Setting #5
High Segment: Heat Setting #5
Medium Segment: Heat Setting #1
Low Segment: Heat Setting #1

Project # 18-409
Model: KP60
Page | 9
Appliance Description
Model(s): KP60, AP60, and VG60
Additional Models Discussion: Certification testing was performed on the model
KP60. The 60 series is also offered branded under several different names, including
Vogelzang and Ashely as the VG60 and AP60, respectively. Models under these
various brand names utilize the same basic design with respect to performance and
emissions controls. All models listed are presumed to have the same emissions
performance as the test specimen provided for certification testing.
Appliance Type: Pellet-Fired Room Heater
Air Introduction System: Air enters the burn chamber by being pulled though the
firepot, via the exhaust blower, see air flow diagram in Appendix D.
Combustion Control: Feed rate is electronically controlled via user-selectable controls.
Baffles: N/A
Flue Outlet: 3-inch exhaust outlet located on the bottom/rear of the appliance.
Appliance Dimensions
KP60 Dimensions
Height
Width
Depth
Firebox
Volume
Weight
32.75”
21”
23.75”
N/A – Pellet
Stove
145 lbs
Appliance design drawings can be found in Appendix D submitted with the CBI copy of
this report.

Project # 18-409
Model: KP60
Page | 10
Appliance Front
Appliance Left

Project # 18-409
Model: KP60
Page | 11
Appliance Right
Appliance Rear

Project # 18-409
Model: KP60
Page | 12
Test Fuel Properties
Test fuel used was purHeat Wood Pellet Fuel, a PFI Certified Premium Pellet Brand. A
sample of pellets was sent to Twin Ports Testing for analysis, see report below.

Project # 18-409
Model: KP60
Page | 13
Pellet Fuel Analysis

Project # 18-409
Model: KP60
Page | 14
Sampling Locations and Descriptions
Sample ports are located 16.5 feet downstream from any disturbances and 1 foot
upstream from any disturbances. Flow rate traverse data was collected 12 feet
downstream from any disturbances and 5.5 feet upstream from any disturbances. (See
below).
Sample Points

Project # 18-409
Model: KP60
Page | 15
Sampling Methods
ASTM E2515 was used in collecting particulate samples. The dilution tunnel is 6 inches
in diameter. All sampling conditions per ASTM E2515 were followed. No alternate
procedures were used.
Analytical Methods Description
All sample recovery and analysis procedures followed ASTM E2515 procedures. At the
end of each test run, filters, O-Rings and probes were removed from their housings,
dessicated for a minimum of 24 hours, and then weighed at 6 hour intervals to a
constant weight per ASTM E2515-11 Section 10.
Calibration, Quality Control and Assurances
Calibration procedures and results were conducted per EPA Method 28R, ASTM
E2515-11 and ASTM E2780-10. Test method quality control procedures (leak checks,
volume meter checks, stratification checks, proportionality results) followed the
procedures outlined.
Appliance Sealing and Storage
Upon completion of testing, the appliance was secured with metal strapping and the
seal below was applied, the appliance was then returned to the manufacturer’s location
at: 227 Industrial Park Road, South Pittsburg, TN 37380 for archival.
Sealing Label

Project # 18-409
Model: KP60
Page | 16
Sealed Unit

Project # 18-409
Model: KP60
Page | 17
List of Appendices
The following appendices have been submitted electronically in conjunction with this
report:
Appendix A – Test Run Data, Technician Notes, and Sample Analysis
Appendix B – Labels and Manuals
Appendix C –Equipment Calibration Records
Appendix D – Design Drawings (CBI Report Only)
Appendix E – Manufacturer QAP (CBI Report Only)

Conditioning Data.xlsm
Client: Job #:
Model: Tracking #:
Date(s): Technician:
Average: 342.2 66.2 N/A
0 39.8 - 428 63 N/A
1 35.8 -4.0 447 66 N/A
2 34.2 -1.6 268 63 N/A
3 32.6 -1.6 272 62 N/A
4 31.1 -1.5 272 63 N/A
5 29.5 -1.6 286 66 N/A
6 27.9 -1.6 282 68 N/A
7 24.9 -3.0 459 62 N/A
8 21.0 -3.9 462 64 N/A
9 18.8 -2.2 326 64 N/A
10 16.6 -2.2 336 65 N/A
11 15.1 -1.5 264 65 N/A
12 13.4 -1.7 297 66 N/A
13 36.0 22.6 431 65 N/A
14 32.2 -3.8 458 67 N/A
15 31.2 -1.0 305 65 N/A
16 29.6 -1.6 286 65 N/A
17 29.5 -0.1 283 66 N/A
18 27.9 -1.6 293 66 N/A
19 27.6 -0.3 282 66 N/A
20 26.0 -1.6 292 62 N/A
21 37.6 11.6 439 64 N/A
22 33.9 -3.7 447 67 N/A
23 32.1 -1.8 286 66 N/A
24 30.5 -1.6 279 66 N/A
25 28.9 -1.6 291 66 N/A
26 27.4 -1.5 289 67 N/A
27 25.8 -1.6 275 68 N/A
28 22.1 -3.7 448 67 N/A
29 18.2 -3.9 443 69 N/A
30 16.6 -1.6 283 68 N/A
31 14.9 -1.7 284 68 N/A
32 13.5 -1.4 265 68 N/A
33 12.1 -1.4 283 69 N/A
34 10.8 -1.3 216 69 N/A
35 35.0 24.2 416 66 N/A
36 31.6 -3.4 408 69 N/A
37 29.8 -1.8 274 68 N/A
38 28.2 -1.6 278 69 N/A
39 26.6 -1.6 282 69 N/A
40 24.9 -1.7 278 70 N/A
41 36.0 11.1 382 62 N/A
42 32.3 -3.7 387 64 N/A
43 28.6 -3.7 398 67 N/A
44 24.9 -3.7 401 66 N/A
45 21.0 -3.9 388 66 N/A
46 17.3 -3.7 411 66 N/A
47 13.5 -3.8 398 67 N/A
48 9.8 -3.7 404 68 N/A
49 6.1 -3.7 396 67 N/A
50 2.4 -3.7 394 69 N/A
002
Conditioning Data
United States Stove Company
18-409
KP60
SJB
3/20/18 - 4/19/18
Elapsed Time
(hrs)
Scale Reading
(lbs)
Weight
Change (lbs)
Flue (°F)
Ambient (°F)
Catalyst Exit
(°F)
PFS-TECO Page 1 of 1 Signature/Date:_____________________________

Client: United States Stove Co.
Model: KP60
Job #: 18-409
Tracking #: 002
Test Date:
Techician Signature Date
PELLET TEST DATA PACKET
ASTM E2779/E2515
Run 1 Data Summary
4/23/2018
PFS-TECO
5/11/2018
3/22/2021
