Phase Technologies SPF-55 Configuration guide

Install Instructions For:
| (888)phase tk | www.phasetech.com |
SPF–55
SPF–55
SPF–85
SPF–85
SPF–55
SPF–85
© 2005 PhaseTech, Inc. All rights reserved.
#8 Stainless-steel
square-drive screw (x6)
Speaker enclosure
Liquid-tight strain relief
Speaker base
Wire leads
.75" 1/4-20 Stainless-steel bolt
In-ground/security bracket
Box contents
1 In-ground speaker
1 Anti-theft device (2 pieces)
1 Liquid-tight compression fitting
1 Square drive bit
2 Wire nuts
6 #8 stainless-steel square-drive screws
2 .75" 1/4-20 Stainless-steel bolts

SPF–55
SPF–85
Install Instructions For:
| (888)phase tk | www.phasetech.com |
SPF–55
SPF–55
SPF–85
SPF–85
Port option for SPF–55
1. If needed for daisy chaining
drill speaker base and install
second liquid-tight strain relief
(not included).
2. Attach inground/security
brackets to speaker base
using stainless-steel bolts.
5. Attach signal wire to wire
leads. Use wire nuts pro-
vided. For added water
proofing, grease caps
are recommended.
3. Thread signal wire thru
liquid-tight strain relief
and tighten seal.
4. Place speaker base into
hole in ground with the top
rim of the base at ground
level. Back-fill dirt in to
hole, packing the dirt
firmly. For added security,
cement security brackets
into ground.
6. Set speaker enclosure on
speaker base. Use tamper-
resistant stainless-steel
screws to attach
speaker to base (driver
tip and screws provided).
7. Done! To enhance bass performance,
remove port cover on the
underside of speaker enclosure.
Warning: Removing the cover
will expose internal components
to humidity and other potentially
corrosive elements.
