Phenyx PTU-71 User manual

Mid-Level UHF Dual Channel
Wireless Microphone System


3
4
7
8
9
10

4
Box contents
Dual UHF Wireless receiver with mixed XLR and1/4 ” outputs
-
6.5mm to 3.5mm audio cable adapter
-
Two antennas
-
Two handheld microphones
-
OR one headset & one lavalier microphone & one bodypack
Four AA battery
-
User’s manual
-
System Overview
The PTU-71 is a dual wireless microphone system designed to offer
excellent sound quality and ease of use. The system utilizes
PLL-synthesized technology to offer high level of frequency stability
and accuracy. This is a reliable wireless system with up to 100 channel
selections and up to 80m/260ft operating distance in wide open space,
which makes it ideal for live performance, public address, interviews,
sermons, entertainment events, karaoke, and more.
Receiver
Front Panel
Power Switch
PHENYX
P
U 17
T
8
4
3 6 7
9
5
1
2
1110
Channel A (CHA)adjustable volume control
2
CHA incremental selection
3 CHA Infrared synchronization setup
4
LCD display screen
5
IR window (Play to the infrared transmitter
signal to the frequency synchronization)
6
CHB incremental slection
7 CHA decremental selection
8
CHB Infrared synchronization setup
9 CHB decremental selection
10
CHB adjustable volume control
11

5
Back Panel
Power jack CHA antenna
2 CHA balanced XLR output
3
CHB balanced XLR output Unbalanced1/4 “ output
54 CHB antenna
6
Handheld Microphone
When turn on the transmitter, the battery
power icon is on the right of the LCD display.
If the battery icon indicates that battery
power is low, the batteries must be replaced to
maintain normal operation.
1
3
2
4
IR window (Play to the infrared transmitter signal to
the frequency synchronization)
LCD display
Power switch
Battery compartment

Bodypack
The Phenyx UHF bodypack is to be used with the Phenyx lavalier
Secure the bodypack to clothing, belt or pocket.
microphones & headsets.
6
Hand-help Tr ans mitte
4
13
4
6
7
5
123
IR
(a) For a lavalier microphone, clip the microphone to clothing
about 1 foot under the mouth.
(b) For a headset, install headset comfortably on head so the
microphone can be placed close to the mouth.
Connect the microphone audio connector to the bodypack
microphone input
Turn the bodypack on by press the ON/MUTE/OFF button.
The operating mode indicator will light up (green), indicating
that the bodypack is on.
Press SET button on receiver. You will see LCD screen shows
“IR---” status. Open the battery compartment cover, and aim the
transmitter’s IR at the receiver’s IR window. Once the pair up is
completed, you can see the same group and channel number display
on the receiver screen and the bodypack screen.
Press up or down button to select the desired frequency, then align the
two IR windows and press “SET” to confirm setting and pair up again.
Press again, operating mode indicator will turn red, which indicates
that bodypack is on MUTE. Long press to turn off the bodypack.
4
2
3
3

Set Up
7
Operation
Install fresh batteries in the transmitters (fresh to the section relative to the
specific transmitter you are using).
Connect the AC power adapter to a wall outlet and to the back of the receiver.
Screw antenna A, B in, and position them 60 degrees apart from each other.
Connect one of the two outputs available at the back panel to the next stage
in your system. Typically, use the1/4”output to connect to unbalanced
equipment such as consumer level receivers, amplifiers, and mixers. Connect to
professional equipment using the XLR output (cable not included).
Make sure the volume of your speaker is off, turn on the receiver and the
transmitters. Press SET button. You will see LCD screen shows “IR---”
status. Aim the transmitter’s IR at the receiver’s IR window. Once the pair up
is completed, frequency will be shown on the LCD screen. On top of frequency,
you can also see group number and channel number.
Press up or down button to select the desired frequency, then press
“SET” again to confirm setting and pair up.
You can use multiple receivers at the same time, and set all the transmitters
to different channels. There are 100 channel selections available for this system!
For better result, keep the transmitter at least 2’away from the receiver but
within the transmitter’s range (80m/260ft). Keep the transmitters in a direct line
of sight with the receiver whenever possible.
Electronics devises such as mobile phones, radios, and other transmitting devices
may interfere with the wireless system transmitters. Please keep transmitter and
receiver away from those devices and other possible interfering sources.

ISSUE REASON SOLUTION
Transmitter battery indi-
cator is rapidly fiashing
or continuously ON
The batteries are low Replace with fresh
batteries
A howling noise (also
known as “feedback”)
can be heard from the
speakers
The microphone is too
close to the speaker
Increase the dis-
tance between the
microphone and the
speaker
Avoid pointing the
microphone directly at
the speaker
No sound coming to the
receiver
The wireless microphone
is outside of the receiver’s
range
Keep wireless
microphone within
operating range of the
receiver
The wireless transmitter is
off or muted (switch set to
“OFF” or “MUTE”)
Turn wireless micro-
phone on. Replace
batteries if necessary
Sound reaches the
receiver,
but no sound coming
from the receiver
Volume control too low
Output is not (or wrongly)
connected Verify all connections
to the rest of your system.
Try different connection
cables if availble.
8
Turn up the output
volume by turning the
volume control buttons
in the front of the
receiver clockwise.

9
Carrier frequency range: UHF 645 – 685 MHZ (Depends on local regulations)
Frequency stability: 0.003%
Dynamic range: >105dB
Frequency response: 50Hz – 18kHz
Audio output level:1/4interface: 0-500mV; XLR Interface: 0 – 500mV
Working distance: 80m/260ft
Operating temperature: -10℃ --- +50℃
Output impedance: XLR connector: 200Ω
RF sensitivity: -105dBm
Image rejection: >110dB
Spurious rejection: >90dB
Power: 5W
Power requirement: DC 12- 15V, Current: 300mA, External power adaptor.
Dimension:210mm x 160mm x 45mm
Weight: 775g (27.3oz)
Modulation mode: FM
Maximum deviation: 75kHz
Handheld dimension: 249mm x 51mm diameter (9.8 x 2 in)
Handheld weight: 306g (10.8oz) (without batteries)
Power: 2 AA alkaline batteries
Battery life: About 8 hours with original batteries

Our Warranty to you:
Phenyx T e c h n o l o g y (“Phenyx”) warrants Phenyx products against evident de-
fects in material and workmanship for a period of one year from the date of origi-
nal purchase for use. This warranty is valid exclusively in the US and applies only
to the original owner. If you discover a defect covered by this warranty, Phenyx
will repair or replace the product at our sole discretion using new or refurbished
components. Performance of repairs or replacements under this Warranty is sub-
ject to registration of your product at www.phenyxusa.com/registerproduct.
Product failures not covered by this warranty:
This warranty covers defects in manufacturing that arise from the correct use of
the device. It is limited to defects in materials or workmanship and does not cover
electrical or mechanical damage resulting from abuse, misuse, unauthorized
modification, lack of reasonable care, extreme heat, cold, damage due to natural
forces, or corrosive environments. This warranty does not cover the normal wear
and tear on covers, housing, connectors, and accessories.
Limits of liability:
If your Phenyx product fails or does not perform as warranted, your sole recourse
shall be to replace or repair it as described above. Phenyx will not be liable to you
or anyone else for any damages that result from the failure of this product. These
damages include, but are not limited to, the following: lost profits, lost savings,
lost data, damage to other equipment, and incidental or consequential damages
arising from the use of or inability to use this product. IN NO EVENT PHENYX
SHALL BE LIABLE FOR MORE THAN THE AMOUNT OF YOUR PURCHASE
PRICE, NOT TO EXCEED THE CURRENT LIST PRICE OF THE PRODUCT.
How to obtain service under this warranty:
Please contact us at [email protected] with any questions or concerns
about your product and a Phenyx representative will contact you to provide assis-
tance.
