MONOCLIMA REFRIGERATOR
OWNER’S MANUAL
PTL 131 D

Dear customer,
Thank you for buying a PHILCO brand product. So that your appliance serves you well, please read all
the instructions in this user’s manual.
Copyright © 2019, Fast ČR, a. s. Revision 01/2022

Copyright © 2019, Fast ČR, a. s. Revision 01/2022
EN - 1
CONTENTS
PART 1: SAFETY INFORMATION......................................................................................................................3
PART 2: DESCRIPTION OF THE APPLIANCE.................................................................................................12
PART 3: DISPLAY CONTROL...........................................................................................................................13
CONTROLLING THE TEMPERATURE..........................................................................................................................................13
PART 4: FIRST USE AN INSTALLATION .........................................................................................................14
CLEANING BEFORE USE................................................................................................................................................................14
INSTALLATION POSITIONING .....................................................................................................................................................14
LEVELING............................................................................................................................................................................................17
ELECTRICAL CONNECTION..........................................................................................................................................................17
PART 5: DAILY USE .........................................................................................................................................17
PART 6: HELPFUL HINTS AND TIPS...............................................................................................................19
NOISES DURING OPERATION......................................................................................................................................................19
ENERGY SAVING TIPS.....................................................................................................................................................................19
HINTS FOR FRESH FOOD REFRIGERATION............................................................................................................................19
HINTS FOR REFRIGERATION........................................................................................................................................................19
PART 7: CLEANING AND CARE......................................................................................................................20
DEFROSTING .....................................................................................................................................................................................20
TAKING THE APPLIANCE OUT OF SERVICE............................................................................................................................20
PART 8: WHAT TO DO IF... ..............................................................................................................................21
PART 9: REVERSING THE DOOR....................................................................................................................23
PART 10: INSTALLING THE DOOR HANDLE .................................................................................................25
PART 11: DISPOSAL OF THE APPLIANCE.....................................................................................................26
PACKAGING MATERIALS...............................................................................................................................................................26
BEFORE DISPOSAL OF THE APPLIANCE. ................................................................................................................................26
STORAGE INSTRUCTIONS ............................................................................................................................................................27
PLACEMENT OF FOOD IN THE APPLIANCE...........................................................................................................................28
PART 12: PRODUCT INFORMATION SHEET .................................................................................................29
TECHNICAL INFORMATION .........................................................................................................................................................31
TESTING INFORMATION................................................................................................................................................................31
CUSTOMER CARE AND SERVICE................................................................................................................................................31
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING MATERIALS........32
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC APPLIANCES ............................................................................32
This appliance has been tested in accordance with the directives in force in the European Union.
This appliance conforms to the relevant safety provisions for electrical appliances in force in the
European Union.

Copyright © 2019, Fast ČR, a. s. Revision 01/2022
EN - 2
Dear customer:
Thank you for buying this refrigerator. To ensure that you get the best results from your new refrigerator,
please take time to read through the simple instructions in this booklet.
Please ensure that the packing material is disposed of in accordance with the current environmental
requirements.
When disposing of any refrigerator equipment please contact your local waste disposal department for
advice on safe disposal.
This appliance must be only used for its intended purpose.
CAUTION:
The appliance is not intended for use by young children or inrm
persons without supervision.
Young children should be supervised to ensure that they do not play
with the appliance.

Copyright © 2019, Fast ČR, a. s. Revision 01/2022
EN - 3
PART 1: SAFETY INFORMATION
FOR YOUR SAFETY AND CORRECT USAGE, BEFORE
INSTALLING AND FIRST USING THE APPLIANCE,READ THIS USER
MANUAL CAREFULLY, INCLUDING ITS HINTS AND WARNINGS. TO
AVOID UNNECESSARY MISTAKES AND ACCIDENTS,IT IS
IMPORTANT TO MAKE SURE THAT ALL PEOPLE USING THE
APPLIANCE ARE THOROUGHLY FAMILIAR WITH ITS OPERATION
AND SAFETY FEATURES. SAVE THESE INSTRUCTIONS AND BE
SURE THAT THEY REMAIN WITH THE APPLIANCE IF IT IS MOVED
OR SOLD,SO THAT ANYONE USING IT THROUGHOUT ITS LIFE,WILL
BE PROPERLY INFORMED ON ITS USAGE AND SAFETY NOTICES.
FOR THE SAFETY OF LIFE AND PROPERTY,KEEP THE
PRECAUTIONS OF THESE USER'S INSTRUCTIONS AS THE
MANUFACTURER IS NOT RESPONSIBLE FOR DAMAGES CAUSED
BY OMISSION.
●THIS APPLIANCE CAN BE USED BY CHILDREN AGED FROM 8
YEARS AND ABOVE AND PERSONS WITH REDUCED PHYSICAL,
SENSORY OR MENTAL CAPABILITIES OR LACK OF EXPERIENCE
AND KNOWLEDGE IF THEY HAVE BEEN GIVEN SUPERVISION OR
INSTRUCTION CONCERNING USE OF THE APPLIANCE IN A SAFE
WAY AND UNDERSTAND THE HAZARDS INVOLVED.
●CHILDREN AGED FROM 3 TO 8 YEARS ARE ALLOWED TO LOAD
AND UNLOAD REFRIGERATING APPLIANCES.
●CHILDREN SHALL NOT PLAY WITH THE APPLIANCE.
●CLEANING AND USER MAINTENANCE CANNOT BE PERFORMED
BY CHILDREN WITHOUT SUPERVISION.

Copyright © 2019, Fast ČR, a. s. Revision 01/2022
EN - 4
●IF THE SUPPLY CABLE GETS DAMAGED, HAVE IT REPLACED BY A
SPECIALIZED SERVICE CENTER IN ORDER TO AVOID DANGEROUS
SITUATIONS. IT IS PROHIBITED TO USE THE APPLIANCE WHEN THE
SUPPLY CABLE IS DAMAGED.
●CAUTION: IF YOUR MODEL IS EQUIPPED WITH AN ICE MAKER
WITHOUT WATER SUPPLY CONNECTION, FILL IT WITH DRINKING
WATER ONLY.
●WARNING: KEEP VENTILATION OPENINGS,IN THE APPLIANCE
ENCLOSURE OR IN THE BUILTIN STRUCTURE,CLEAR OF
OBSTRUCTION.
●WARNING: DO NOT USE MECHANICAL DEVICES OR OTHER
MEANS TO ACCELERATE THE DEFROSTING PROCESS,OTHER THAN
THOSE RECOMMENDED BY THE MANUFACTURER.
●WARNING: DO NOT DAMAGE THE REFRIGERANT CIRCUIT.
●WARNING: DO NOT USE ELECTRICAL APPLIANCES INSIDE THE
FOOD STORAGE COMPARTMENTS OF THE APPLIANCE,UNLESS
THEY ARE OF THE TYPE RECOMMENDED BY THE MANUFACTURER.
●WARNING: DO NOT STORE EXPLOSIVE SUBSTANCES SUCH
AS AEROSOL CANS WITH A FLAMMABLE PROPELLANT IN THIS
APPLIANCE.
ISO 70001701 MARK 200401
LABELS MEDIA UNDER PRESSURE..

Copyright © 2019, Fast ČR, a. s. Revision 01/2022
EN - 5
THIS APPLIANCE IS INTENDED FOR DOMESTIC USE ONLY AND
NOT IN SIMILAR PREMISES SUCH AS
 KITCHENETTES IN SHOPS,OFFICES AND OTHER WORKPLACES;
APPLIANCES USED BYGUESTSIN HOTELS, MOTELS, AND OTHER
ACCOMMODATION FACILITIES; APPLIANCES USED IN BEDAND
BREAKFAST FACILITIES; APPLIANCES USED IN CATERING AND
OTHER SIMILAR NONVENDING ENVIRONMENTS.
ONLY SOME REFRIGERATOR MODELS ARE EQUIPPED WITH ICE
MAKER. INTEGRATED ICE MAKERS MUST BE INSTALLED BY THE
MANUFACTURER OR ITS SERVICING ORGANIZATION ONLY.
●THE FOLLOWING GOES FOR SELECTED MODELS EQUIPPED
WITH AN ICE MAKER WITH WATER CONNECTION: CAUTION: CAN
ONLY BY CONNECTED TO DRINKING WATER SUPPLY.
●CAUTION: THE APPLIANCE MUST BE FASTENED IN
ACCORDANCE WITH THE MANUAL TO PREVENT DANGER CAUSED
BY ITS INSTABILITY.
●CAUTION:THE COOLING SYSTEM CONTAINS REFRIGERANT
UNDER HIGH PRESSURE. DO NOT MANIPULATE WITH THE SYSTEM.
THE SYSTEM MAY BE REPAIRED BY AUTHORIZED PERSONS ONLY.

Copyright © 2019, Fast ČR, a. s. Revision 01/2022
EN - 6

WARNING :
RISK OF FIRE / FLAMMABLE MATERIALS
CONTAINS COOLING GAS ISOBUTANE
R600A
REFRIGERANT
THE REFRIGERANT ISOBUTENE R600A IS CONTAINED WITHIN
THE REFRIGERANT CIRCUIT OF THE APPLIANCE,A NATURAL GAS
WITH A HIGH LEVEL OF ENVIRONMENTAL COMPATIBILITY,WHICH
IS NEVERTHELESS FLAMMABLE. DURING TRANSPORTATION
AND INSTALLATION OF THE APPLIANCE,ENSURE THAT NONE OF
THE COMPONENTS OF THE REFRIGERANT CIRCUIT BECOMES
DAMAGED. THE REFRIGERANT R600A IS FLAMMABLE.
●WARNING  REFRIGERATORS CONTAIN REFRIGERANT AND
GASES IN THE INSULATION. REFRIGERANT AND GASES MUST
BE DISPOSED OF PROFESSIONALLY AS THEY MAY CAUSE
EYE INJURIES OR IGNITION. ENSURE THAT TUBING OF THE
REFRIGERANT CIRCUIT IS NOT DAMAGE PRIOR TO PROPER
DISPOSAL.
THE SYMBOL

IS A WARNING AND INDICATES THE
REFRIGERANT AND INSULATION BLOWING GAS ARE FLAMMABLE.

Copyright © 2019, Fast ČR, a. s. Revision 01/2022
EN - 7
WARNING : RISK OF FIRE / FLAMMABLE MATERIALS
IF THE REFRIGERANT CIRCUIT SHOULD BE DAMAGED:
 AVOID OPENING FLAMES AND SOURCES OF IGNITION.
 THOROUGHLY VENTILATE THE ROOM IN WHICH THE APPLIANCE
IS SITUATED.
IT IS DANGEROUS TO ALTER THE SPECIFICATIONS OR MODIFY
THIS PRODUCT IN ANY WAY.
ANY DAMAGE TO THE CORD MAY CAUSE A SHORT CIRCUIT, FIRE,
AND/OR ELECTRIC SHOCK.
●CAUTION: THE COOLING SYSTEM CONTAINS REFRIGERANT
UNDER HIGH PRESSURE. DO NOT MANIPULATE WITH THE
SYSTEM.
THE SYSTEM MAY BE REPAIRED BY AUTHORIZED PERSONS ONLY.
●CAUTION:WHEN PLACING THE APPLIANCE IT MUST BE ENSURED
THAT THE SUPPLY CORD DOES NOT GET CAUGHT OR DAMAGED.
●CAUTION:DO NOT PLACE PORTABLE MULTIPLE SOCKET-
OUTLETS OR PORTABLE EXTENSION CABLES TO THE REAR SIDE OF
THE APPLIANCE.
ELECTRICAL SAFETY
1. THE POWER CORD MUST NOT BE LENGTHENED.
2. MAKE SURE THAT THE POWER PLUG IS NOT CRUSHED OR
DAMAGED.
A CRUSHED OR DAMAGED POWER PLUG MAY OVERHEAT AND
CAUSE A FIRE.
3. MAKE SURE THAT YOU CAN ACCESS THE MAIN PLUG OF THE
APPLIANCE.
4. DO NOT PULL THE MAIN CABLE.

Copyright © 2019, Fast ČR, a. s. Revision 01/2022
EN - 8
5. IF THE POWER PLUG SOCKET IS LOOSE, DO NOT INSERT THE
POWER PLUG. THERE IS A RISK OF ELECTRIC SHOCK OR FIRE.
6. YOU MUST NOT OPERATE THE APPLIANCE WITHOUT THE
INTERIOR LIGHTING LAMP COVER.
7. THE FRIDGE IS ONLY APPLIED WITH POWER SUPPLY OF
SINGLE PHASE ALTERNATING CURRENT OF 220~240V/50HZ.
IF FLUCTUATION OF VOLTAGE IN THE DISTRICT OF USER IS SO
LARGE THAT THE VOLTAGE EXCEEDS THE ABOVE SCOPE,FOR
SAFETY SAKE, BE SURE TO APPLY A.C. AUTOMATIC VOLTAGE
REGULATOR OF MORE THAN 350W TO THE FRIDGE.
THE FRIDGE MUST EMPLOY A SPECIAL POWER SOCKET INSTEAD
OF COMMON ONE WITH OTHER ELECTRIC APPLIANCES. ITS PLUG
MUST MATCH THE SOCKET WITH GROUND WIRE.
DAILY USE
●DO NOT STORE FLAMMABLE GAS OR LIQUIDS IN THE
APPLIANCE, THERE IS A RISK OF AN EXPLOSION.
●DO NOT OPERATE ANY ELECTRICAL APPLIANCES IN THE
APPLIANCE E.G. ELECTRIC ICE CREAM MAKERS,MIXERS ETC..
●WHEN UNPLUGGING ALWAYS PULL THE PLUG FROM THE
MAINS SOCKET,DO NOT PULL ON THE CABLE.
●DO NOT PLACE HOT ITEMS NEAR THE PLASTIC COMPONENTS
OF THIS APPLIANCE.
●DO NOT PLACE FOOD PRODUCTS DIRECTLY AGAINST THE AIR
OUTLET ON THE REAR WALL.
●STORE PREPACKED FROZEN FOOD IN ACCORDANCE WITH THE
FROZEN FOOD MANUFACTURE’S INSTRUCTIONS.
●THE APPLIANCES MANUFACTURES STORAGE
RECOMMENDATIONS SHOULD BE STRICTLY ADHERED TO. REFER
TO RELEVANT INSTRUCTIONS FOR STORAGE.

Copyright © 2019, Fast ČR, a. s. Revision 01/2022
EN - 9
●DO NOT PLACE CARBONATED OR FIZZY DRINKS IN THE
FREEZER COMPARTMENT AS IT CREATES PRESSURE ON THE
CONTAINER,WHICH MAY CAUSE IT TO EXPLODE,RESULTING IN
DAMAGE TO THE APPLIANCE.
●FROZEN FOOD CAN CAUSE FROST BURNS IF CONSUMED
STRAIGHT FROM THE FREEZER COMPARTMENT.
●DO NOT PLACE THE APPLIANCE IN DIRECT SUNLIGHT.
●KEEP BURNING CANDLES,LAMPS AND OTHER ITEMS WITH
NAKED FLAMES AWAY FROM THE APPLIANCE SO THAT DO NOT
SET THE APPLIANCE ON FIRE.
●THE APPLIANCE IS INTENDED FOR KEEPING FOOD STUFF AND/
OR BEVERAGES IN NORMAL HOUSEHOLD AS EXPLAINED IN THIS
INSTRUCTION BOOKLET. YOU SHOULD TAKE CARE WHEN MOVE
IT AS THE APPLIANCE IS HEAVY.
●DO NOT REMOVE OR TOUCH ITEMS FROM THE FREEZER
COMPARTMENT IF YOUR HANDS ARE DAMP/WET, AS THIS COULD
CAUSE SKIN ABRASIONS OR FROST/FREEZER BURNS.
●NEVER USE THE BASE,DRAWERS,DOORS ETC. TO STAND ON OR
AS SUPPORTS.
●FROZEN FOOD MUST NOT BE REFROZEN ONCE IT HAS BEEN
THAWED OUT.
●DO NOT CONSUME ICE POPSICLES OR ICE CUBES STRAIGHT
FROM THE FREEZER AS THIS CAN CAUSE FREEZER BURN TO THE
MOUTH AND LIPS.
●TO AVOID ITEMS FALLING AND CAUSING INJURY OR DAMAGE
TO THE APPLIANCE,DO NOT OVERLOAD THE DOOR RACKS OR
PUT TOO MUCH FOOD IN THE CRISPER DRAWERS.

Copyright © 2019, Fast ČR, a. s. Revision 01/2022
EN - 10
INSTALLATION
IMPORTANT!
●FOR ELECTRICAL CONNECTION CAREFULLY, FOLLOW THE
INSTRUCTIONS GIVEN IN THIS MANUAL. UNPACK THE APPLIANCE
AND CHECK IF THERE ARE DAMAGES ON IT.
●DO NOT CONNECT THE APPLIANCE IF IT IS DAMAGED. REPORT
POSSIBLE DAMAGES IMMEDIATELY TO THE PLACE YOU BOUGHT
IT. IN THIS CASE RETAIN PACKING.
●IT IS ADVISABLE TO WAIT AT LEAST FOUR HOURS BEFORE
CONNECTING THE APPLIANCE TO ALLOW THE OIL TO FLOW BACK
IN THE COMPRESSOR.
●ADEQUATE AIR CIRCULATION SHOULD BE AROUND THE
APPLIANCE, LACKING THIS LEADS TO OVERHEATING. TO
ACHIEVE SUFFICIENT VENTILATION, FOLLOW THE INSTRUCTIONS
RELEVANT TO INSTALLATION.
●WHEREVER POSSIBLE THE BACK OF THE PRODUCT SHOULD
NOT BE TOO CLOSE TO A WALL TO AVOID TOUCHING OR
CATCHING WARM PARTS COMPRESSOR, CONDENSER TO
PREVENT THE RISK OF A FIRE, FOLLOW THE INSTRUCTIONS
RELEVANT TO INSTALLATION.
●THE APPLIANCE MUST NOT BE LOCATE CLOSE TO RADIATORS
OR COOKERS.
●MAKE SURE THAT THE MAINS PLUG IS ACCESSIBLE AFTER THE
INSTALLATION OF THE APPLIANCE.
●PLACE ALL PACKAGING MATERIALS OUT OF THE REACH OF
CHILDREN, THERE IS A RISK OF SUFFOCATION.

Copyright © 2019, Fast ČR, a. s. Revision 01/2022
EN - 11
• THEINTERIOROFYOURREFRIGERATOR/FREEZERMAYSMELL
BEFORE FIRST USE. THIS IS NORMAL. THE ODOR DISAPPEARS AS
SOON AS THE APPLIANCE STARTS TO COOL / FREEZE.
• BEFORECONNECTINGTHEREFRIGERATORIFREEZER,MAKE
SURE THAT THE MAINS VOLTAGE CORRESPONDS TO THE
REQUIREMENTS FOR CONNECTING THE REFRIGERATOR /
FREEZER. IF IN DOUBT, CONSULT A QUALIFIED ELECTRICIAN.
• THEAPPLIANCEMUSTBECONNECTEDTOASOCKETWITHTHE
APPROPRIATE VOLTAGE AND A CORRECTLY INSTALLED FUSE
SOCKET.
• THEREFRIGERATORIFREEZERMUSTNOTBEPLACED
OUTDOORS OR EXPOSED TO RAIN.
• THEREFRIGERATORIFREEZERMUSTBELOCATEDATLEAST
50CM FROM HEATERS, ELECTRIC OVENS, GAS OVENS, ETC.
• IFTHEREFRIGERATORWITHFREEZERISLOCATEDNEXTTOTHE
FREEZER, THERE MUST BE A MIN. 2CM SPACING.
• DONOTPLACEHEAVYOBJECTSONTHEREFRIGERATOR/
FREEZER, DO NOT COVER IT.
• ABOVETHEFRIDGE/FREEZERTHEREMUSTBEAMIN.150MM
FREE SPACE.
• INSTALLTWOPLASTICGUIDESONTHEREFRIGERATOR
/ FREEZER CONDENSER THAT PREVENT THE WALL AND
CONDENSER FROM TOUCHING.
• THISAPPLIANCEISMADEFORDOMESTICUSEANDISONLY
SUITABLE FOR COOLING / FREEZING FOOD. NOT SUITABLE FOR
COMMERCIAL USE AND / OR STORAGE OF SUBSTANCES OTHER
THAN FOOD. THE MANUFACTURER IS NOT LIABLE FOR ANY
LOSSES CAUSED BY IMPROPER USE OF THE APPLIANCE.

Copyright © 2019, Fast ČR, a. s. Revision 01/2022
EN - 12
PART 2: DESCRIPTION OF THE APPLIANCE
View of the appliance
1. Electronic temperature regulator
2. Decorative board (some models have)
3. Storage shelf
4. Crisper cover
5. Crisper
6. Adjustable feet
7. Egg tray
8. Door handle (some models have)
9. Upper door rack
10. Door
11. Lower door rack
NOTE!
Due to continual modication of our products, your refrigerator may be slightly dierent from this
instruction Manual, but its functions and usage methods remain the same.
Note:
• Coolingsection(fridge)-Themostecientuseofenergyisensuredbythecongurationwithdrawers
in the lower part of the appliance and shelves evenly distributed. The direction of door opening does not
aect energy consumption.

Copyright © 2019, Fast ČR, a. s. Revision 01/2022
EN - 13
PART 3: DISPLAY CONTROL
Use your appliance according to the following guidelines, your appliance has functions as control panel
shown in the pictures below.
Controlling the temperature
We recommend that when you start your refrigerator for the rst time, the temperature for the refrigerator is
set to 4°C. If you want to change the temperature, follow the instructions below.
CAUTION!
When you set a temperature, you set an average temperature for the whole refrigerator cabinet.
Temperatures inside each compartment may vary from the temperature displayed on the panel,
depending on how much food you store and where you place them. Ambient temperature may also
aect the actual temperature inside the appliance.
1. Fridge
Press the middle part of button to set fridge temperature between 2°C and 8°C as needed, and control
panel will display corresponding gures according to the following sequence.
2. Super Cool
If want to lock in vitamins and nutrients oresh food and keep food fresh longer,Super Cool will quickly lower
the temperature within the refrigerator compartment, so food will cool faster. You can put the food in the
refrigerator rst, and then use the Super Cool function.
Press the middle part of button for 3 seconds to activate the Super Cool function.
The light will be on. Press the middle part of button for 3 seconds to cancel the super cool function.
Super cool automatically switches off after 40 hours and then the refigerator temperature setting will revert
back to the previous setting.

Copyright © 2019, Fast ČR, a. s. Revision 01/2022
EN - 14
PART 4: FIRST USE AN INSTALLATION
Cleaning before use
• Beforeusingtheapplianceforthersttime,washtheinteriorandallinternalaccessorieswithlukewarm
water and meutral soap in order to remove the typical smell of a brand new product, then dry thoroughly.
Installation Positioning
WARNING!
Before installing, read the * instruction carefully for your safety and the correct operation of
appliance.
• Positiontheapplianceawayfromsourcesofheatsuchasstoves,radiators,directsunlight,etc.
• Maximumperformanceandsafetyareguaranteedbymaintainingthecorrectindoortemperatureforthe
class of unit concerned, as specied on the rating plate.
• ThisapplianceperformswellfromNtoT.Theappliancemaynotworkproperlyifitisleftforalonger
period at a temperature above or below the indicated range.
Climate class Ambient temperature
SN +10 °Ct o +32 °C
N +16 °C to +32 °C
ST +16°C to +38 °C
T +16°C to +43 °C
Acronym for ambient temperature range, ie SN, N, ST or T, in determining cli mate classes:
1. theextendedtemperatezone(SN)hasatemperaturerangeof10°Cto32°C;
2. the temperate zone (N) has a temperature range of 16°C to 32°C;
3. the subtropical zone (ST) has a temperature range from 16°C to 38°C;
4. the tropical zone (T) has a temperature range of 16°C to 43°C.
IMPORTANT!
It is necessary to have good ventilation around the fridge to allow for the dissipation of heat.For this
reason,sucient clear space should be available around the appliance. It is advisable for there to be
50-70mm separating the back of the fridge to the wall at least 100mm of space on its two sides and
a clear space in front to allow the doors to open 160°.
• Appliancesmustnotbeexposedtorain.Sucientairmustbeallowedtocirculateinthelowrearsection
of the appliance, as poor air circulation can aect performance. Built-in appliances should be positioned
away from heat sources such as heaters and direct sunlight.

Copyright © 2019, Fast ČR, a. s. Revision 01/2022
EN - 15
Installing the rubber supporting
• Screwprovidedinaplasticbagwithyourappliance,youcaninstalltheseaccessoriesaccordingtothe
following procedure.
NOTE:
There is no need to install these accessories under normal usage.
Only under the extreme circumstances, cabinet empty while load on door with total mass of 15
kg and opening the door about 90 degree .this refrigerator may take risk of tipping. Then rubber
supporting pad should be fastened to the lower base cover to steady this appliance.

Copyright © 2019, Fast ČR, a. s. Revision 01/2022
EN - 16
1. Tilt appliance to nd screw hole on the left of lower base cover.
Lower base cover
2. Put screw into the hole of rubber supporting pad.
Screw
Rubber supporting pad
3. Make screw in alignment with the hole on lower base cover. Fasten rubber supporting pad to the base
cover rmly by a cross screw driver (self-provided).
Cross screwdrawer

Copyright © 2019, Fast ČR, a. s. Revision 01/2022
EN - 17
Leveling
• Theapplianceshouldbelevelinordertoeliminatevibration.Tomaketheappliancelevel,itshouldbe
upright and both adjusters should be in stable contact with the oor. You can also adjust the level by
unscrewing the appropriate level adjustment in the front (use your ngers or a suitable spanner).
Electrical connection
CAUTION!
Any electrical work required to install this appliance should be carried out by qualied or
authorized personnel.
WARNING!
This appliance must be grounded. The manufacturer declines any liability should these safety
measures not be observed.
PART 5: DAILY USE
Accessories 1)
Movable shelves/trays
• Variousglass,plasticstorageshelvesorwiretraysareIncludedwithyourappliancedierentmodelshave
dierent combinations and dierent models have dierent features.
• Thewallsoftherefrigeratorareequippedwithaseriesofrunnersothattheshelvescanbepositionedas
desired.
Remove door rack
Hold the left side of the door rack, inward- press the other side and lift this side until it separated from the
liner. Then you can take out the door rack from the liner.
Invard-pressing

Copyright © 2019, Fast ČR, a. s. Revision 01/2022
EN - 18
Installation door rack
First, install the left of the door rack. Second, inward-press the other side and downward-press this side until
installation it.
Invard-pressing
Crisper
• Forstoringfruitandvegetables.
Refrigerator compartment 2)
• Forstoringthefoodthatdoesnotneedtobefrozenanddierentsectionssuitablefordierentkindsof
food.
1) If the appliance contains related accessories and functions.
2) If the appliance contains a freezer compartment
