Philco PSW81400V User manual

PSW81400V
WASHING MACHINE

!
2
Thank you for choosing this product.
We are proud to offer the ideal product for
you and the best complete range of home
appliances for your daily routine.
Carefully read this manual for correct and
safe appliance use and for helpful tips on
efficient maintenance.
Only use the washing machine after
carefully reading these instructions. We
recommend you always keep this manual on
hand and in good condition for any future
owners.
Each product is identified by a unique
found inside the door opening. This code is
a unique code for your product that you will
need to register the product warranty, or if
you need to contact the Customer Service
Centre.
This appliance is marked according to
the European directive 2012/19/EU
on Waste Electrical and Electronic
Equipment (WEEE).
WEEE contains both polluting substances (which
can cause negative consequences for the
environment) and basic components (which can
be re-used). It is important to have WEEE
subjected to specific treatments, in order to
remove and dispose properly all pollutants, and
recover and recycle all materials. Individuals can
play an important role in ensuring that WEEE
does not become an environmental issue; it is
essential tofollow some basic rules:
WEEE should not be treated as household
waste;
WEEE should be handed over to the relevant
collection points managed by the municipality or
by registered companies. In many countries, for
large WEEE, home collection could be present.
1
. GENERAL SAFETY RULES
2
. INSTALLATION
3
. PRACTICAL HINTS
4
. CLEANING AND MAINTENANCE
5
. QUICK USER GUIDE
6
. CONTROLS AND PROGRAMS
7
. TROUBLESHOOTING AND WARRANTY
Environmental conditions
Contents

!
3
1. GENERAL SAFETY
RULES
This appliance is intended to
be used in household.
A differentuse of this appliance
from household environment
or from typical housekeeping
functions, as commercial use by
expert or trained users, is excluded
even in the above applications. If
the appliance is used in a manner
inconsistent with this it may reduce
the life of the appliance and may
Any damage to the appliance or
other damage or loss arising
through use that is not consistent
with domestic or household use
(even if located in a domestic or
household environment) shall not
be accepted by the manufacturer to
the fullest extent permitted by law.
This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand the
hazards involved.
Children of less than 3 years
should be kept away unless
continuously supervised.
If the supply cord is damaged, it
must be replaced by a special
cord or assembly available from
the manufacturer or its service
agent.
Water pressure must be between
0.05 MPa and 0.8 MPa.
Make sure carpets or rugs do
not obstruct the base or any of
the ventilation openings.
After installation, the appliance
must be positioned so that the
plug is accessible.
The maximum load capacity of
dry clothes depends on the
model used (see control panel).
To consult the product technical
specification please refer to the
website.
Children shall not operate with the
appliance inapporpriate. Cleaning
and user maintenance shall not
be made by children without
supervision.

!
4
The technical details (supply
voltage and power input) are
indicated on the product rating
label.
Make sure that the electrical
system is earthed, complies
with all applicable law and that
the (electricity) socket is
compatible with the plug of the
appliance. Otherwise, seek
qualified professional assistance.
The use of converters, multiple
sockets or extension cords
might cause hazard.
Before cleaning or maintaining
the washing machine, unplug
the appliance and turn off the
water tap.
Do not pull on the power cord
or appliance to unplug the
machine.
Make sure there is no water in
the drum before opening the
door.
Do not expose the washing
machine to rain, direct sunlight
or other weather elements.
Protect from possible freezing.
When moving, do not lift the
washing machine by the knobs
or detergent drawer; during
transport, never rest the door on
the trolley. We recommend two
people lift the washing machine.
In the event of fault and/or
malfunction, turn off the
washing machine, close the
water tap and do not tamper
with the appliance.
Immediately contact the
Customer Service Centre and
only use original spare parts.
Failure to observe these
instruction may jeopardise
appliance safety.
Electrical connections and
safety instructions
WARNING:
water may reach very
high
temperatures during
the
wash cycle.

!
5
2. INSTALLATION
Remove the 2or 4transportation
screws (A) on the back
and
remove the 2or 4flat washers
,
rubber bungs and plastic spac
er
tubes (B)as illustrated in figure 1.
If the washing machine is built-in
,
unscrew the 3or 4transportati
on
screws (A) and remove the 3or
4
flat washers, rubber bungs
and
plastic spacer tubes (B).
During the removal of the screw
s
occasionally spacer tubes f
all
inside the product, these can b
e
remove by tilting the product forwar
d
and recovering them from the floor o
r
inside the base of the machine.
Cover the open transportation
screw
holes with the 2or 4plastic
caps
included in the instruction bag.
Place the corrugated plastic shee
t,
found on top of the appliance
during
the unpacking process, into the bas
e
of the appliance as shown in figure
2
(according to the model, conside
r
version A, Bor C).
A
A
A
A
B
B
B
B
1
3
2
1
3
1
2
A
C
B
2
WARNING:
keep packaging
materials
away from children.
In some models this operation
will not be necessary, because
the corrugated plastic sheet
will be already placed on the
bottom of the appliance.

!
6
Connect the water hose to the wate
r
supply tap (fig. 3) only using the hos
e
supplied with the appliance (do no
t
reuse old hose-sets).
SOME MODELS may include one o
r
more of the following features:
HOT&COLD (fig. 4):
water mains connection settings with ho
t
and cold water for higher energy savings.
Connect the grey tube to the cold wate
r
tap and the red one to the hot water
tap. The machine can be connected to
the cold water tap only: in this case, some
programs may start afew minutes later.
AQUASTOP (fig. 5):
a device located on the supply tube that
stops water flow if the tube deteriorates;
in this case, a red mark will appear in the
A
replaced. To unscrew the nut, press the
one-way lock device "B".
AQUAPROTECT SUPPLY TUBE WITH
GUARD (fig. 6):
Should water leak from the primary
internal tube "A", the transparent
containment sheath "B" will contain water
to permit the washing cycle to complete.
At the end of the cycle, contact the
Customer Service Centre to replace the
supply tube.
The washing machine should be installed
in its final position such that the water fill
hose is not kinked or trapped. The
corrugated drain hose should be inserted
into suitable drain pipe of between 50 cm
and 85 cm height above the floor using
the curved drain hose support. If an under
sink connection is used the drain hose
must be routed above the sink overfill
opening to prevent back siphoning. Care
must be taken to avoid kinking or trapping
the drain hose (fig. 7). (Note: This accessory
is excluded in some models).
3
1
4
B
A
5
B
A
6
Hydraulic connections
Setting
min 50 cm
max 85 cm
max
max 100 cm
min 4 cm
7
+ 2,5 m

!
7
Level the appliance using the feet as
illustrated in figure 8:
a. turn the nut clockwise to release t
he
screw;
b. rotate the foot to raise or lower it until
it
touchestothe floor;
c. lock the foot, screwing in the nut, until
it
tightens against to the bottom of t
he
washing machine.
Plug in the appliance.
A
B
C
8
T
he detergent draw is split into
3
c
ompartments as illustrated in figure 9:
compartment "1": for prewash detergent;
: for special additives
,
softeners, starch fragrances, etc.;
compartment "2": for washing detergent
.
A
liquid detergent cup is also included I
N
S
OME MODELS (fig. 10). To use it, place
it
i
n compartment "2". This way, liqui
d
de
tergent will only enter the drum at t
he
r
ight time. The cup can also be used fo
r
s
elected.
2
1
9
10
WARNING:
contact the Customer Service Centre
should the power cord need
replacement.
Detergent drawer
WARNING:
only use liquid products; the washing
machine is set to automatically dose
additives at each cycle during the last
rinse.
WARNING:
some detergents are not designed for
use in the dispenser drawer but are
supplied with their own dispenser that
is placedin the drum directly.
WARNING:
installation faults are not covered by
the manufacturers warranty.

!
8
3. PRACTICAL HINTS
When sorting laundry, make sure:
-have eliminated metallic objects such as
hair clips, pins, coins, from laundry;
- to have buttoned pillow cases, closed
zips, tied loose belts and long robe
ribbons;
- to have removed rollers, hooks or clips
from curtains;
- to have carefully read clothing washing
labels;
- to have removed any persistent stains
using specific detergents.
When washing rugs, bedcovers or other
heavy clothing, we recommend you avoid
the spinning cycle.
To wash wool, make sure the item can be
machine washed. Check the fabric label.
A guide environmentally friendly and
economic use of your appliance.
Maximise The Load Size
Achieve the best use of energy, water,
detergent and time by using the
recommended maximum load size.
Save up to 50% energy by washing a full
load instead of 2 half loads.
Do you needto pre-wash?
For heavily soiled laundry only!
SAVE detergent, time, water and
between 5 to 15% energy consumption
by NOT selecting Prewash for slight to
normally soiled laundry.
Is a hot wash required?
Pretreat stains with stain remover or soak
dried in stains in water before washing to
reduce the necessityof ahotwash
programme. Save energy by using alow
temperature wash programme.
SAVE energy and time by selecting a
highspin speed to reduce thewater
content in laundry.
Following is a quick guide with tips and
recommendations on detergent use at the
various temperatures. In any case, always
read the instructions on the detergent for
correct use and doses.
Load tips
Helpful suggestions for the user
When washing heavily soiled whites,
we recommend using cotton
or above and a
normal washing powder (heavy duty)
that contains bleaching agents that at
medium/high temperatures provide
excellent results.
the type of detergent used needs to be
appropriate for the type of fabric and
level of soiling.
Normal powders ar
or colour fast fabrics with high soiling,
coloured fabrics with light levels of
soiling.
For washing at temperatures below
we recommend the use of liquid
detergents or detergents specifically
labeled as suitable for low temperature
washing.
For washing woolor silk, only use
detergents specifically formulated for
these fabrics.

!
9
4. CLEANING AND
MAINTENANCE
To clean the washing machine exterior, use
a damp cloth, avoiding abrasives, alcohol
and/or solvents. To maintain a good wash
performance we recommend that the soap
drawer and pump filters are regularly
cleaned. A monthly service wash, using a
proprietary cleaner is also recommended.
We recommend you clean the drawer to
avoid accumulating detergent and
additive residue.
To do this, extract the drawer using slight
force, clean it with running water and
reinsert it inits housing.
Ensure the siphon cap is correctly
refitted.
The washing machine comes with a
special filter able to trap large residue,
such as buttons or coins, which could
clog the drain.
ONLY AVAILABLE ON CERTAIN MODELS:
pull out the corrugated hose, remove the
stopper and drain the water into a
container.
Ensure all the water has been emptied
from the drum.
Before unscrewing the filter, we
recommend you place an absorbent cloth
under it to keep the floor dry. A small
amount of water will come out of the filter
as you remove it - this is normal.
Turn the filter counter-clockwise to the
limit stop.
Remove and clean the filter; when
finished, replace it turning it clockwise.
The filter handle will be locked when it is
not possible to turn any further and the
handle is horizontal. Smearing a small
amount of liquid soap on the filter seal will
help refitting.
Repeat the previous steps in reverse
orderto reassemble all parts.
Should the washing machine be stored in
an unheated room for a long period of
time, drain all water from tubes.
Unplug the washing machine.
Detach the tube from the drainage
system and clip on the rear of the
machine and lower it, fully draining water
into a bowl.
Secure the drain tube with the drainage
system and clip on the rear of the
machine when finished.
Keep the door glass and gasket clean.
Drawer cleaning
Filter cleaning
Suggestions for mo v es or
p
rolonged disuse
The manufacturers warranty only
covers faults within the product of a
mechanical or electrical nature.
Faults caused by handling,
installation or miss use are not
covered and may incur a charge for
any repair visit to resolve.

!
10
5. QUICK USER GUIDE
This washing machine automatically adjusts
the level of the water to the type and
quantity of washing. This system gives a
reduction in energy consumption and a
saving in washing times.
Turn on the washing machine and select
the required program.
Adjust the washing temperature if
necessary and press the required "option"
buttons.
Press the START/PAUSEbutton to start
washing.
If there is a break in the power supply
whilst the machine is operating, when
the power is restored, the machine will
restart from the beginning of the phase it
was in when the power was lost.
At the end of the programme, the
message "End" will appear on the display
or, on some models, all wash stage
indicator lights will turn on.
Turn off the washing machine.
For any type of wash, see the program
table and follow the operating sequence
as indicated.
Water pressure:
min 0.05 Mpa / max 0.8 Mpa
(0.05 MPa dispenses approximately 1 litre
of water in 10 seconds)
Spin r.p.m.: See rating label.
Power input / Power current fuse amp /
Supply voltage: See rating label.
6. CONTROLS AND
PROGRAMS
A
GF H C E D B
I
L
A
Programme selector with OFF
po
sition
B
START/PAUSE button
C
DELAY START button
D
OPTIONS button
E
RAPID / STAIN LEVEL button
F
TEMPERATURE SELECTION
bu
tton
G
SPIN SPEED button
H
NIGHT & DAY button
F+G
KEY LOCK
I
Digital display
L
DOOR LOCKED indicator light
Program selection
Wait until the DOOR LOCKED light has
gone out before opening the door.
Technical data

!
11
Press the START/PAUSE button to start
the selected cycle.
Once a programme is selected the
programme selector remains stationary on
the selected programmetill cycle ends.
"End"will appear in the display at the
end of the program and the DOOR
LOCKED light will go off, it is now
possible to open the door.
Switch off the washing machine by
turning the selector to OFF.
Press to start the selected cycle.
PAUSING THE MACHINE
Keep the START/PAUSEbutton pressed
for about 2seconds (some light indicators
and the residual time display will flash,
showing that the machine is paused).
Press the START/PAUSEbutton again to
re-start the programme from the point it
had been paused at.
CANCELLING THE PROGRAMME
To cancel the programme, set the
selector tothe OFF position.
This button allows you to pre-programme
the wash cycle to delay the start of the
cycle for up to 24 hours.
WARNING:
the plug because the machines
calibrates the systems during the first
seconds: touching the display, the
this case, remove the plug and repeat
the operation.
PROGRAMME selector with OFF
position
When the programme selector is turned
the display lights up to show the settings
for the programme selected.
For energy saving, at the end of the
cycle or with an inactivity period, the
display level contrast will decrease.
N.B.: To switch the machine off, turn
the programme selector to the OFF
position.
The programme selector must be
returned to the OFF position at the end
of each cycle or when starting a
subsequent wash cycle prior to the next
programme being selected and started.
START/PAUSE button
Close the door BEFORE selecting the
button START/PAUSE.
When the START/PAUSE button has
been pressed, the appliance can take
few seconds before it starts working.
For safety reasons, in some wash
cycle phases, the door can be opened
only if the level of the water is below
its lower edge and if the temperature
are met, wait for the DOOR LOCKED
light to switch off before opening the
door.
DELAY START button
Wait until the DOOR LOCKED light has
gone out before opening the door.

!
12
To delay the start use the following
procedure:
- Select the required programme.
- Press the delay start button once to
activate it (h00 appears on the display)
and then press it again to set a 1 hour
delay (h01 appears on the display). The
pre-set delay increases by 1 houreach
time the button is pressed, until h24
appears on the display, at which point
pressing the button again will reset the
delay start to zero.
- Confirm by pressing the START/PAUSE
button. The delay countdown will begin
and when it has finished the programme
will start automatically.
It is possible to cancel the delay start by
turning the programme selector to OFF.
If there is a break in the power supply
whilst the machine is operating, when
the power is restored, the machine will
restart from the beginning of the phase it
was in when the power was lost.
This button allows you to choose between
three different options:
- PREWASHING
This option allows you to make a prewash
and it is particularly useful for heavily
soiled loads (can be used only on some
programmes as shown in the table of
programmes).
We recommend you adjust the quantities
depends on your need in compare with the
recommended quantities shown on the
detergent pack.
- EXTRA RINSE
This option allows you to add one rinse at
the end of the washing cycle and is useful
for people with delicate and sensitive
skin, for which a small amount of
detergent residue can cause irritations or
allergies.
It is advisable to also use this function for
the children clothes and for the washing
of heavily soiled items, which requires a
lot of detergent to be used, or for the
washing of toweling items whose fibres
mostly have the tendency to hold the
detergent.
- HYGIENE +
A
temperature. This option allows deep
cleaning of your clothes by maintaining the
same temperature for the whole wash.
This button allows you to choose between
two different options, depending on the
selected programme.
- RAPID
The button becomes active when
you select the RAPID (14-30-44 Min.)
programme on the knob and allows you to
select one of three durations indicated.
- STAIN LEVEL button
Once the programme has been selected
the wash time set for that programme will
be automatically shown.
This option allows you to choose between
3 levels of wash intensity modifying the
length of the programme, depending on
how much the fabrics are soiled (can only
be used on some programmes as shown
in the table of programmes).
The following options must be
selected before pressing the
START/PAUSE button.
OPTIONS button
If an option is selected that is not
compatible with the selected
programme then the option indicator
light first flashes and then goes off.
RAPID / STAIN LEVEL button

!
13
This button allows you to change the
temperature of the wash cycles.
It is not possible to raise the temperature
over the maximum allowed for the
programme, in orderto protect the fabrics.
If you want carry out a cold wash all the
indicators must be off.
By pressing this button, it is possible to
reduce the maximum speed, and if you
wish, the spin cycle can be cancelled.
If the label does not indicate specific
information, it is possible to use the
maximum spin expected in the program.
To reactivate the spin cycle press the
button until you reach the spin speed you
would like to set.
It is possible to modify the spin speed
without pausing the machine.
This option reduces the intermediate spin
speed to 400 rpm, where applicable,
increase the water level during rinsing
and keep the laundry immersed in water
after the final rinse, in order to spread the
fiber perfectly.
During the phase in which the water is
held in the tub, the relevant indicator light
blink to show that the machine is at a
standstill.
Deselect the option to end the cycle with
a spin dry (which may be reduced or
cancelled using the appropriate button)
and emptying phase.
Thanks to electronic control, the water in
the intermediate phases is emptied
silently, making this option very useful for
washing at night.
Pressing simultaneously the buttons
TEMPERATURE SELECTION and SPIN
SPEED for about 3 seconds, the
machine allows you to lock the keys. In
this way, you can avoid making accidental or
unwanted changes if a button on the display
is pressed accidently during a cycle
.
The key lock can be simply cancelled by
pressing the two buttons simultaneously
again or turning off the appliance.
TEMPERATURE SELECTION
button
SPIN SPEED button
To prevent damage to the fabrics, it is
not possible to increase the speed
over the maximum allowed for the
programme.
An over dosing of detergent can cause
excessive foaming. If the appliance
detects the presence of excessive foam,
it may exclude the spinning phase or
extend the duration of the program
and increase water consumption.
The machine is fitted with a special
electronic device, which prevents the
spin cycle should the load be
unbalanced. This reduces the noise
and vibration in the machine and so
prolongs the life of your machine.
NIGHT & DAY button
This option must be selected before
pressing the START/PAUSE button.
KEY LOCK

!
14
be constantly informed about the status of
the machine.
13 2 47 9 5 6
8
1) DOOR LOCKED INDICATOR LIGHT
The indicator light is illuminated when the
door is fully closed.
When START/PAUSEis pressed on the
machine with the door closed, the indicator
will flash momentarily and then illuminate.
Wait until the DOOR LOCKED light has
gone out before opening the door.
2) SPIN SPEED
This show the spin speed of the selected
programme that can be changed or omitted
by the relevant button.
3) WASH TEMPERATURE INDICATOR
LIGHTS
This shows the washing temperature of the
selected programme that can be changed
(where allowed) by the relevant button.
If you want carry out a cold wash all the
indicators must be off.
4) CYCLE DURATION
When a programme is selected the
display automatically shows the cycle
duration, which can vary, depending on
the options selected.
Once the programme has started you will
be kept informed constantly of the time
remaining tothe end of the wash.
The appliance calculates the time to the
end of the selected programme based
upon a standard loading, during the cycle,
the appliance corrects the time to that
applicable to the size and composition of
the load.
5) STAIN LEVELINDICATORS LIGHTS
Once the programme has been selected,
the indicator light will automatically show
the stain level set for that programme.
Selecting a different stain level the
relevant indicator will light up.
6) OPTIONS INDICATOR LIGHTS
The indicator lights show the option that
can be selected by the relevant button.
7) KEY LOCK INDICATOR LIGHT
The indicator lightshowthatthe keys
are locked.
8) NIGHT & DAY INDICATOR LIGHT
The indicator light shows the selection of
the relevant option.
9) Kg MODE (function active only on
certain programmes)
During the first minutes of the cycle, the
"Kg MODE" indicator remain on while the
intelligent sensor will weigh the laundry
and adjust the cycle time, water and
electricity consumption accordingly.
Digital Display
Close the door BEFORE selecting the
START/PAUSE button.
If the door is not properly closed,
the light will continue to flash for
about 7 seconds, after which the
start command will be automatically
delete. In this case, close the door
in the proper way and press the
START/PAUSE button.

!
15
Through every wash phase "Kg MODE"
allows to monitor information on the wash
load in the drum and in the first minutes
of the wash it:
- adjusts the amount of water required;
- determinesthe length of the wash cycle;
- controls rinsing according to the type of
fabric selected to be washed it;
- adjusts the rhythm of drum rotation for
the type of fabric being washed;
- recognizes the presence of lather,
increasing, if necessary, the amountof
water during rinsing;
- adjusts the spin speed according to the
load, thus avoiding anyimbalance.

!
16
PROGRAMME
(MAX.) *
1)
2
1
(see control panel)
(MAX.)
2
1
Whites
2)
5 6 7 8 9 10 11 12
()
Cotton
**
2)
5 6 7 8 9 10 11 12
()
Jeans 3 3 3 3 3 3 3 3
5 6 7 8 9 10 11 12
Mixed
2)
2,5 3 3,5 4 4,5 5 5,5 6 ( )
Delicate 2 2 2,5
2,5 2,5 2,5 2,5 3
Rinse - - - - - - - - -
Spin - - - - - - - - -
Drain - - - - - - - - -
Rapid
3)
14' 1 1 1 1,5
1,5 1,5 1,5 2
30' 1,5
2 2,5 2,5 2,5 2,5 2,5 3
44' 3 3 3,5
3,5 3,5 3,5 3,5 4
Dark Colours
2)
2,5 3 3,5 4 4,5 5 5,5 6 ()
Shirts
2)
2,5 3 3,5 4 4,5 5 5,5 6 ()
Silk 1 1 1 2 2 2 2 2,5
Wool 1 1 1 2 2 2 2 2,5
Handwash 1 1 1 2 2 2 2 2,5
Table of programmes

!
17
Please read these notes:
*
Maximum load capacity of dry clothes,
according to the model used (see control
panel).
(Only for models with liquid
detergent compartment)
When only a limited number of
articles have stains which require
treatment with liquid bleaching
agents, preliminary removal of
stain can be carried out in the
washing machine.
Pour the bleach into the liquid
bleach container, inserted into the
compartment marked "2" in the
detergent drawer, and set the
special programme RINSE.
When this phase has terminated,
turn the programme selector to
the OFF position, add the rest of
the fabrics and proceed with a
normal wash on the most suitable
programme.
( )
Only with PREWASH option
selected (programmes with
PREWASH option available).
1)
When a programme is selected,
on the display is shown the
display shows the recommended
wash temperature that can be
reduced (where allowed) by the
relevant button.
2)
For the programmes shown you
can adjust the duration and
intensity of the wash using the
STAIN LEVEL button.
3)
Selecting the RAPID program on
the knob, it will be possible to
select with the RAPID button, one
of the three rapid programs
** STANDARD COTTON PROGRAMMES
ACCORDING TO (EU) No 1015/2010 and
No 1061/2010.
COTTON PROGRAMME WITH A
COTTON PROGRAMME WITH A
These programmes are suitable to
clean normally soiled cotton laundry and
they are the most efficient programmes
in terms of combined energy and water
consumptions for washing cotton
laundry.
These programmes have been
developed to be compliant with the
temperature on the wash label on the
garments and the actual water
temperature may slightly differ from the
declared temperature of the cycle.

!
18
T
o clean different types of fabrics
and
va
rious levels of dirt, the washing machi
ne
ha
s specific programs to meet every need
o
f washing (see table of programmes).
W
hites
A
n intensive wash. The final spin at maximu
m
s
peed gives more efficient removal.
C
otton
T
his program is suitable to clean normally
s
oiled cotton laundry and it is the most efficien
t
p
rogram in terms of combined energy
and
w
ater consumptionsfor washing cotton laundry.
Jean
s
Th
is program has been designed to have t
he
h
ighest quality cleaning of fabrics such a
s
den
im: ideal for removing dirt without affecti
ng
t
he elasticity of the fibers.
Th
is innovative programme, allows you to was
h
d
ifferent fabrics and colours together, such a
s
c
ottons, synthetics and mixed fabrics at on
and
provides an excellent cleaning performance
.
C
onsumption on this program is about 40% o
f
M
ixed
T
he washing and rinsing optimise t
he speed
and
rhythm of the drum action and water
l
evels. The gentlespin, ensures a reduc
ed
f
ormation of creases inthe fabric.
D
elicate
T
his program has reduced periods of drum
r
otation during the cycle and is particularly
s
uitable or washing delicate fabrics. T
he
w
ash cycle and rinses are carried out with a
h
igh level of water to ensure the bes
t
pe
rformance.
R
inse
Th
is program performs 3 rinses with
an
i
ntermediate spin (which can be reduced o
r
e
xcluded by using the appropriate button) .
It
i
s used for rinsing any type of fabric, fo
r
e
xample after a wash carried out by hand.
S
pin
The
programme carries out a maximum spin
It
i
s possible to delete or reduce the spin wit
h
t
he SPIN SPEED button.
Drain
T
his programme drains out the water.
R
apid (14-30-44 Min.)
W
ashing cycle suggested for low loads
and
s
lightly dirty. With this program it is recommende
d
t
o reduce the quantity of detergent normall
y
u
sed, in order to avoid unnecessary waste
.
S
electing the RAPID program and acting
on
t
he button you can choose one of thr
ee
p
rograms available.
D
ark Colours
T
his programme allows you to was
h
a
ll together. The rotation movement of t
he
d
rum and the water levels are optimized
,
bo
th during the washing the rinsing phase
.
T
he accurate spin action, ensures
a
r
educed formation of creases inthe fabrics.
S
hirts
T
he washing cycle is optimized to r
educe
t
he creation of creases, keeping
an
ex
cellent washing performance. It is als
o
po
ssible to further reduce the spin speed, t
o
en
sure an easier ironing.
S
ilk
D
edicated program for silk fabrics that c
an
be
wash with a washing machine washable
.
T
he rotations of the drum are delicate, t
he
p
rogram ends with a gentle spin.
W
ool
T
his program performs a wash cycl
e
ded
icated to the wool fabrics that can
be
w
ashed in a washing machine, or t
he
a
rticles to be washed by hand.
H
andwash
P
rogram for hand wash only clothes, t
he
p
rogram ends with 3 rinses and a slow spin.
Description of programmes
WARNING:
New coloured garments should be
washed separately for at least 5 or 6
washes.
Never mix NON COLOURFAST fabrics.

!
19
7. TROUBLESHOOTING AND WARRANTY
If you believe the washing machine is not working correctly, consult the quick guide
provided below which includes some practical tips on how to fix the most common
problems.
ERROR CODE FORMAT
Error shown Possible causes and practical solutions
E2 (with display)
2 flashes of the LEDs
(without display)
The machine cannotload water.
Make sure the water supply tap is open.
Make sure the drain pipe is at the proper height (see installation section).
Close the water supply tap, unscrew the filler hose from the back of
-
and not blocked.
Check that the filter is not clogged or that there are no foreign bodies
inside the filter compartment that can obstruct the proper flow of
water.
E3 (with display)
3 flashes of the LEDs
(without display)
The washing machine does not drain water.
Check that the filter is not clogged or that there are no foreign bodies
inside the filter compartment that can obstruct the proper flow of
water.
Make sure the home drainage system is not blocked and is allowing
water toflow through without obstruction. Try to drain the water in the sink.
E4 (with display)
4 flashes of the LEDs
(without display)
There is too much foam and/or water.
Ensure the correct amount of detergent is being used and the
detergent is designed for use in a washing machine.
E7 (with display)
7 flashes of the LEDs
(without display)
Door problem.
Make sure the door is correctly closed.
Make sure the clothes inside the drum are not preventing the door
from closing fully.
If the doorislocked, turn off and unplug the washing machine from
the electrical supply socket, wait 2-3 minutes and reopen the door.
Any other code
Turn off and unplug the washing machine, wait a minute. Turn on the
machine and restart a program. If the error occurs again contact an
Authorised Customer Service Centre directly.
Models with a display:
(example: E2 = Error 2).
Models without display: an error is shown by a sequence of flashes of every LED.
The error code is shown by the number of flashes followed by a pause of 5 seconds
(example: two flashes pause 5 seconds two flashes repeating = Error 2).

!
20
OTHER ANOMALIES
Problem Possible causes and practical solutions
The washing machine
does not work / start
Make sure the product is plugged into a working supply socket.
Make sure power is on.
Make sure the wall socket is working, testing it with another
appliance such as a lamp.
The door may not be correctly closed: open and close it again.
Check whetherthe required program was correctly selected and the
start button pressed.
Make sure the washing machine is not in pause or time delay mode.
Water leaked on the
floor near the
washing machine
This may be due to a leak from the seal between the tap, supply
hose and fill valve; inthis case, replace it and tighten the hose
connections correctly.
Make sure the front filter is correctly closed.
The washing machine
does not spin
The machine is fitted with a detection system that protects the load
and product from damage if the load is not balanced before spinning.
This may result in:-
The machine attempts to balance the load, increasing the time of
spin.
Reduction of the speed of spin to decrease vibrations and noise.
The spin cycle aborting to protect the machine and load.
If this is experienced remove the load de-tangle it, reload it and
restart the spin program.
This could be due tothe fact that water has not been completely
drained: wait a few minutes. If the problem persists, see Error 3
section.
Some models include a "no spin" function: make sure it is not
selected.
Check which options are selected and their effect on the spin cycle.
Excessive detergent can impede the spin cycle, ensure the correct
amount of detergent is being used.
Strong vibrations/
noises are heard
during the spin cycle
The washing machine may not be fully levelled: if necessary, adjust
the feet as indicated inthe specific section.
Make sure transport screws, rubber bungs and spacer tubes were
removed.
Make sure there are no foreign objects inside the drum (coins,
hinges, buttons, etc ).
The standard manufacturer warranty covers faults caused by electrical or
mechanical faults in the product due to an act or omission of the manufacturer. If
a fault is found to be caused by factors outside the product supplied, miss-use or
as a result of the instructions on use not being followed, a charge may be
applied.
