Philco PBC 6027930db User manual

Beverage Cooler
USER'S MANUAL
PBC 6027

Dear customer,
Thank you for buying aPHILCO brand product. So that your appliance serves you well, please read all
the instructions in this user'smanual.

EN - 1
06/2012
Copyright © 2012, Fast ČR, a. s.
CONTENTS
PART 1: BEFORE PUTTING INTO OPERATION................................................................................................. 2
Safety precautions ..................................................................................................................................................................................2
Safety instructions for gas R600a ......................................................................................................................................................4
PART 2: DESCRIPTION OF THE APPLIANCE .................................................................................................... 5
PART 3: INSTALLATION .................................................................................................................................... 6
Transport and unpacking.....................................................................................................................................................................6
Operating conditions.............................................................................................................................................................................6
Placement ..................................................................................................................................................................................................7
Cleaning before use................................................................................................................................................................................8
Electrical connection..............................................................................................................................................................................8
PART 4: CONTROLS .......................................................................................................................................... 9
Setting the temperature.......................................................................................................................................................................9
Racks ............................................................................................................................................................................................................9
PART 5: REGULAR MAINTENANCE................................................................................................................ 11
Cleaning the appliance ...................................................................................................................................................................... 11
Moving the appliance......................................................................................................................................................................... 11
Energy saving tips................................................................................................................................................................................ 12
PART 6: WHAT SHOULD IDO WHEN.............................................................................................................. 13
PART 7: TECHNICAL SPECIFICATIONS........................................................................................................... 14

EN - 2
06/2012
Copyright © 2012, Fast ČR, a. s.
PART 1: BEFORE PUTTING INTO OPERATION
Safety precautions
Symbols:
General advice for the optimal operation of the appliance
General dangers
Hot surfaces
Before you put the appliance into operation
IMPORTANT
This appliance is designed exclusively for storing alcoholic and non-alcoholic beverages. Do not use the
appliance for purposes other than those for which it was designed.
• Carefully study the user'smanual and installation instructions before installing and using the appliance!
This user'smanual includes important information regarding the installation, operation and maintenance
of the appliance. Store the user'smanual also for future reference, or for other owners of the appliance if
the appliance is sold.
If the appliance is transported in ahorizontal position the oil from the compressor may leak into the
cooling circuit. For this reason, allow the appliance to rest in avertical position for 12 hours before
turning it on, so that the oil ows back into the compressor.
After unpacking the appliance, carefully inspect that it has in not been damaged in any way. Also
check that the power cord is not damaged. If you discover any defects, turn o the appliance
and contact the vendor or in the case of adamaged power cord contact the service centre. If the
appliance and all its parts are in order, install it according to the instructions in the relevant chapter.
• When installing the appliance in its place or when moving the appliance, the power cord could be
penetrated or damaged. Check that the power cord is not interfering anywhere.
• Before connecting the appliance to the electrical power source check that the capacity of the system
corresponds to the specications on the appliance'srating label.
• Any kind of home electric wiring necessary for the connection of the appliance must only be carried out
by aqualied electrician.
If you move the appliance from its usual position, it is necessary to understand, that although you
have disconnected the power cord, the components on the rear side of the appliance may remain
very hot for some time.
Do not cover or block the air inow or outow openings. Insucient ventilation will cause bad
operation and damage to the appliance.

EN - 3
06/2012
Copyright © 2012, Fast ČR, a. s.
Operating the appliance
• Use the appliance only for the purposes for which it has been designed.
• This appliance is designed only for household use, for storing alcoholic and non-alcoholic beverages.
• The temperature inside the appliance may rise or fall slightly and so these appliances are not suitable for
storing products (e.g. medicines), which require astable temperature.
Do not use any other electric appliances (e.g. heating elements, electric ice cream machines, etc.)
inside the appliance. There is adanger of explosion!
Do not place food inside the appliance containing ammable propulsion gases (e.g. sprays) and no
explosives, contaminants or volatile substances. There is adanger of explosion!
• Do not use the base, racks, door of the appliance, etc. as astep or as asupport. There is adanger of injury
to persons or damage to the appliance.
• Ensure that the plastic parts of the appliance and the door gasket seals are not soiled with oil or grease. The
plastic parts and the gasket seals would then become porous.
Children in the household
• Never leave packaging and its parts with children. There is adanger of poisoning or suocation by the
cardboard boxes and plastic sheets!
• This appliance is in no way atoy for children!
• For appliances with door locks: do not leave keys within the reach of children!
• If you will no longer be using the appliance, remove the doors, gasket seals and store it in asafe place. In
this way you will prevent the danger of children becoming trapped inside the appliance.
Maintenance and cleaning
Before you begin with regular or exceptional maintenance, disconnect the appliance'spower cord
or turn o the fuse or circuit breaker. Never pull the electric power cord, only pull on the power plug.
Do not clean the appliance using asteam cleaning device! The steam may come into contact with
the electric components inside the appliance, where ashort circuit could occur. There is adanger of
electric shock!
General instructions
• This appliance must not be used by persons (including children) with physical, sensory or psychological
impairments or by inexperienced persons, unless properly trained or schooled in the safe use of the
appliance, or unless they have been properly supervised by aperson who will be responsible for their
safety. Children should be supervised so as not to play with the appliance.
• This appliance has been tested in accordance with the directives in force in the European Union.
• The tightness of the cooling circuit has been veried.
• This appliance conforms to the relevant safety provisions for electrical appliances in force in the European
Union.
Technical safety
• The appliance contains acooling gas, ISOBUTHAN (R600a). Only transport or move the appliance with the
utmost care, prevent excessive impacts and shaking to prevent damaging the appliance. If the cooling
circuit becomes damaged and the cooling gas may be escaping, there is arisk of an explosion, which may
be ignited by aspark or ame. If the appliance shows signs of damage, it must not be put into operation.
In such acase contact the service centre, ventilate the room where the appliance is located and prevent
the spreading of ames or other interference with the appliance.

EN - 4
06/2012
Copyright © 2012, Fast ČR, a. s.
Safety instructions for gas R600a
Measures in case of an unexpected release
If ventilation is possible, allow the material to evaporate.
Characteristics of the gas
The gas is highly ammable, it is necessary to completely prevent contact with an open ame and hot surfaces.
Because the R600a gas is heavier than air, it may become very concentrated at the level of the ground, where
ventilation is weak.
First aid
Inhalation
Take the aected person from the contaminated area to a warm, well ventilated location. Staying in
a contaminated location for a long time may cause suocation, or potentially loss of consciousness. If
necessary, provide mouth-to-mouth resuscitation and in exceptionally serious situations, under expert
medical supervision, give oxygen.
Contact with the skin
Accidental contact with the skin is not hazardous to health. Thoroughly wash the aected area with water. The
liquid spray or dispersed liquid may cause frost bite, wash the aected area with large amounts of water and
contact amedical doctor.
Contact with the eyes
If eyes have been aected, wash out with large amounts of water, while trying to keep the eyes open, and call
aspecialised doctor as soon as possible. If contact or inhalation of the R600a gas occurs, contact your medical
doctor.

EN - 5
06/2012
Copyright © 2012, Fast ČR, a. s.
PART 2: DESCRIPTION OF THE APPLIANCE
Description of the control panel
• "RUN"
The indicator light will turn on when the appliance is running.
• LIGHT button (Internal lighting)
To turn on / o the internal light.
• POWER button (On / O)
To turn the appliance on / o (press and hold down the button for approximately 3 seconds).
• DISPLAY
To display the temperature inside the appliance.
• Up button
To increase temperature. Each time it is pressed the temperature will increase by 1 °C.
• Down button
To decrease temperature. Each time it is pressed the temperature will decrease by 1 °C.

EN - 6
06/2012
Copyright © 2012, Fast ČR, a. s.
PART 3: INSTALLATION
Transport and unpacking
If the appliance is transported in ahorizontal position the oil from the compressor may leak into the cooling
circuit. For this reason, allow the appliance to rest in avertical position for 12 hours before turning it on, so that
the oil ows back into the compressor.
Remove the external packaging, remove the protective plastic lm from the surface of the appliance (if used)
and clean the external parts of the appliance with an agent designed for this purpose. Do not use steel wool or
any coarse agents, which could irreparably damage the surface of the appliance. Carefully remove all papers
and adhesive tape from the appliance, doors and other parts packed in polystyrene. Remove documents and
accessories from inside the appliance.
The packaging material is recyclable and is marked with a recycling symbol. For disposal follow the local
regulations. Packaging materials (plastic bags, polystyrene parts, etc.) must be kept out of the reach of children,
because they present apossible source of danger.
Carefully inspect the appliance. If you discover any faults, stop the installation and contact the vendor.
Operating conditions
Proper operation of the appliance is guaranteed only if the following conditions are met:
• The temperature in the room where the appliance is located conforms to the climate class stated on the
appliance'srating label.
• Maximum ambient relative humidity: 90%.
• The appliance must be placed at asucient distance from heat sources (e.g. baking ovens, central heating,
direct sunlight, etc.).
• The appliance must be located in such aplace that it is protected against the eects of weather.
• Regular maintenance is performed according to the instructions in this user'smanual.
• The ventilation openings in the cover of the appliance must not be covered by anything.
• Correct installation (e.g. levelling, the capacity of the system correspond to the specications on the rating
label of the appliance).
Table – Climatic class
Climatic class Ambient
temperature
SN +10 °C to +32 °C
N +16 °C to +32 °C
ST +16 °C to +38 °C
T +16 °C to +43 °C

EN - 7
06/2012
Copyright © 2012, Fast ČR, a. s.
Placement
The location for the placement of the appliance must meet the requirements in the paragraph "Operating
conditions" and must have astable oor with aload bearing capacity corresponding to the weight of the
appliance.
This appliance is may be built-in.
In such acase, adhere to the dimensions below.
From the front From the side From above
Level the appliance using the adjustable feet, ensure there is agap between the bottom edge of the appliance
and the ground, so that there is sucient circulation of the cooling air, by which you will ensure the optimal
performance of the cooling circuit.
• Check whether any cooling circulation pipes have been damaged during the installation.
• Use the appliance only for the purposes for which it has been designed.
• The appliance must be located on arigid and even surface.
• In this way you will ensure free circulation of the coolant and eective operation of your appliance.
• If possible, place the appliance into acool, well ventilated and dry room.
• Do not locate the appliance in direct sunlight or in aroom with ahigh temperature, in the vicinity of any
sources of direct heat, such as heating, an oven, astove, etc. – this would mean that the compressor would
need to work alot harder resulting asubstantially higher power consumption level.
If it is not possible to prevent the installation in the vicinity of aheat source, we recommend the insertion of an
appropriate insulating board (do not use asbestos) between the appliance and the heat source; or at least to
maintain the following minimum distances:
• From agas or electric stove 3 cm;
• From aheater or oven, etc. 30 cm;
• From another cooling appliance 2 cm.

EN - 8
06/2012
Copyright © 2012, Fast ČR, a. s.
Do not place any appliances on the appliance, which release heat on to the appliance, such as microwaves
ovens, toasters, etc.
Never cover the ventilation grill. Pull out the power plug by pulling on the plug itself, never pull on the cord
when disconnecting the appliance.
Before turning on the appliance allow it to stand in its nal location for 12 hours, the coolant circuit
will stabilise in this way and no operating problems will occur. Before connecting the appliance to
the power grid check that it is perfectly dry inside – especially in the corners.
Danger warning
The coolant may be highly ammable, depending on its composition. The coolant circuit was hermetically
closed and sealed and was tested many times for possible leaks. Any unqualied tampering with the product
may cause are hazard. Check that there is no mechanical interruption or eect on the coolant circulation,
namely in the accessible parts around the compressor.
Only professionally qualied persons may work on the cooling system.
Cleaning before use
Check that you have removed from the appliance all adhesive tape used to hold accessories .Then clean all the
inside parts using lukewarm water with aneutral cleaning agent, vinegar or sodium carbonate – in this way
you will remove the characteristic odour of new parts – then dry carefully. Do not use detergents or aggressive
agents, which could damage the surfaces.
Electrical connection
Before connecting the power plug to the power socket, check that:
• Your hands are completely dry.
• The voltage and frequency shown on the rating label of the appliance corresponds to that in the home
power grid (permitted tolerance from -6% to +6% for nominal voltage, for use with dierent voltages, use
avoltage changer with the corresponding parameters).
• The power cord and the plug are not damaged or caught under heavy objects.
• The power cord is not excessively tensioned, it is not permitted to use an extension cord.
Do not connect the appliance to avoltage rectier (e.g. solar power plant) or use an extension cord.
The appliance must be connected to aworking grounding lead.
If the power socket of the home system is not grounded in accordance with the current legal
regulations, connect the appliance after consulting aspecialised technician to the grounding lead
itself.
The manufacturer takes no responsibility for injuries caused as a result of not following these
instructions.
If you do not correctly level the appliance during the installation, the door may not close shut and
seal properly, which may cause problems with the cooling, ice build up or moisture. Levelling the
appliance is very important.
Level the appliance using the levelling feet – turn them clockwise to lift the appliance and turn
them anticlockwise to lower the appliance.

EN - 9
06/2012
Copyright © 2012, Fast ČR, a. s.
PART 4: CONTROLS
Each compartment of the appliance (left and right) is controlled independently.
Insert the power plug into aproperly grounded power socket.
If the power supply is interrupted, the previously set temperature will be automatically deleted and the factory
set temperature will be set.
7 °C - Left compartment
12 °C - Right compartment
Setting the temperature
Use the up/down buttons to set the desired temperature of the appliance. Each time the up/down buttons are
pressed, the temperature will increase/decrease by 1 °C. The set temperature will ash on the LED display for
5 seconds, then the temperature inside the appliance will be shown.
Both compartments: You can set the temperature in the range from 5 °C to 18 °C.
To show the set temperature, press and hold the respective button for about 5 seconds and the set temperature
will ash on the screen for about 5 seconds.
Flashing LED indicator light = Set temperature
Lit LED light = Temperature inside the appliance
Racks
• To prevent damaging the doors or gasket seals, open the doors wide open when removing the racks.
• For easier handling of bottles, it is necessary to pull the rack out by at least a1/3. The sides of the racks are
equipped with protective stoppers, which prevent bottles from falling from the racks.
When removing / inserting the racks from / into the rails, lift one side of the rack as shown in the picture below
and pull the rack out towards yourself, or push it in when inserting it, until one side is securely seated in the rail.

EN - 10
06/2012
Copyright © 2012, Fast ČR, a. s.
NOTE:
• Before reconnecting the power plug into apower socket, wait 3 to 5 minutes. Otherwise you could
damage your appliance. If you attempt to turn on the appliance before the end of this time delay, the
appliance will not turn on.
• If you turn on the appliance for the rst time or after arestart, or after it has been out of operation for
along time, there may be atemperature dierence between the temperature inside the appliance
and on the LED display. This is anormal event caused by the duration of the activation period. Leave
the appliance turned on for several hours and the temperatures will stabilise during operation.

EN - 11
06/2012
Copyright © 2012, Fast ČR, a. s.
PART 5: REGULAR MAINTENANCE
Cleaning the appliance
Before commencing to clean the refrigerator disconnect it from the power source.
• Wipe the internal surface of the appliance with asoft sponge lightly dipped in atable salt solution. Add 2
tablespoons of table salt into 1 litre of warm water.
• Wash the racks in warm water with asmall amount of kitchen dishwashing liquid, rinse and wipe dry. Allow
the wooden racks (if the wine cooler has them) to dry completely before returning them to the wine cooler.
• All parts that you wash with asoft sponge lightly dipped in water must be properly wiped dry.
• Wipe the outer surface with asoft sponge lightly dipped in water with asmall amount of dishwashing
liquid. Wipe dry using aclean cloth.
WARNING:
Do not use steel wool or sponges with steel wool on stainless steel surfaces. They could damage the
surface.
Do not use cleaning waxes, concentrated cleaning agents, bleaches or cleaning products containing
kerosene on the plastic or rubber parts.
Never use paper towels or window cleaners on the plastic parts.
The use of steam cleaning appliances is extremely dangerous and so is strictly forbidden.
Power outage
Most power outages are rectied within afew hours and should not have an eect on the temperature inside
the appliance if you limit its ventilation. However, in the event of an extended power outage it is necessary to
take appropriate steps to prevent the contents inside the appliance from spoiling.
TAKING OUT OF OPERATION FOR AN EXTENDED PERIOD
If you are not going to use the refrigerator for an extended period of time, do the following:
Disconnect the refrigerator from the power source by pulling it out of the power socket. Clean out the inside
and dry it out as described in the part Cleaning the refrigerator. Leave the door open to prevent an unpleasant
odour forming inside.
Moving
• Before moving it, it is necessary to remove all contents from the appliance.
• Secure freely moving parts inside the appliance (racks), e.g. using adhesive tape.
• To prevent damage, screw in the levelling feet.
• Secure the door, e.g. using adhesive tape.
• Ensure that the appliance always remains in avertical position while being transported. To prevent the
appliance from damage during transport you can cover it with ablanket or another soft textile.

EN - 12
06/2012
Copyright © 2012, Fast ČR, a. s.
Energy saving tips
• Locate the appliance away from sources of heat and out of direct sunlight.
• Ensure sucient ventilation. Under no circumstances should you cover the ventilation openings.
• Only open the door when necessary. Do not leave the door open for along time or open / close the door
too often.

EN - 13
06/2012
Copyright © 2012, Fast ČR, a. s.
PART 6: WHAT SHOULD IDO WHEN...
If the appliance is not working as it should, prior to calling an authorised service centre, read the instructions
below, which will help you remedy the most common problems with the appliance. However, should the
problem persist or you are unable to remedy it yourself, immediately turn the appliance o, disconnect it from
the power socket and contact an authorised service centre.
Under no condition should you repair the appliance yourself.
MALFUNCTION POSSIBLE CAUSE
The appliance is not
working.
The appliance is not connected to the electrical power grid.
The appliance is turned o.
The circuit breaker is activated or the fuse is burned.
The appliance is not
cooling.
Check the temperature settings.
The temperature of the outside environment is too high.
The doors are opened too frequently.
The doors are not properly shut.
The door gasket seals are not sealing properly.
The appliance turns on
and o often.
The temperature in the room is higher than normal.
Alarge amount of food was placed in the appliance.
The doors are opened too frequently.
The doors are not properly shut.
The temperature controller is not set properly.
The door gasket seals are not sealing properly.
The lights are not
working.
The appliance is not connected to the electrical power grid.
The circuit breaker is activated or the fuse is burned.
The light bulb broke.
The light is switched o.
Vibrations. Ensure that the appliance is correctly levelled.
The appliance is too
loud.
The rattling sound may be caused by the owing coolant. This is normal.
At the end of each cycle you will hear abubbling sound caused by the owing
coolant.
The contraction and expansion of the internal walls may cause acracking or
popping sound.
The appliance is not levelled.
The doors are not closing
properly.
The appliance is not levelled.
The door opening direction change was performed incorrectly.
The gasket seal is dirty.
The racks are incorrectly located.

EN - 14
06/2012
Copyright © 2012, Fast ČR, a. s.
PART 7: TECHNICAL SPECIFICATIONS
DESIGNATION PBC 6027
Number of cans / bottles (pcs.) 60/27
Volume (l) 146
Cooling power 5 – 18 °C
Voltage frequency 220-240 V~50 Hz
Power input 140 W
Energy class B
Power consumption (kWh/24h) 0.53
Annual power consumption in kWh 195
Dimensions w/d/h (cm) 60/60/88
Noise level (dB) 42
Weight (kg) 59
Automatic locking of panel No
Coolant R600a
Temperature zones 2
Automatic defrosting yes
Climatic class ST
Colour black
Touch controls yes
LED display yes
NOTE:
All the here mentioned data is subject to change.

EN - 15
06/2012
Copyright © 2012, Fast ČR, a. s.
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED
PACKAGING MATERIALS
Dispose of packaging material at a public waste disposal site.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC APPLIANCES
The meaning of the symbol on the product, its accessory or packaging indicates that this product
shall not be treated as household waste. Please, dispose of this product at your applicable collection
point for the recycling of electrical & electronic equipment waste. Alternatively in some states of
the European Union or other European states you may return your products to your local retailer
when buying an equivalent new product. The correct disposal of this product will help save valuable
natural resources and help in preventing the potential negative impact on the environment and
human health, which could be caused as a result of improper liquidation of waste. Please ask your
local authorities or the nearest waste collection centre for further details. The improper disposal of
this type of waste may fall subject to national regulations for nes.
For business entities in the European Union
If you wish to dispose of an electrical or electronic device, request the necessary information from
your seller or supplier.
Disposal in other countries outside the European Union
If you wish to dispose of this product, request the necessary information about the correct disposal
method from local government departments or from your seller.
This product meets all the basic EU regulation requirements that relate to it.
Changes to the text, design and technical specications may occur without prior notice and we reserve the
right to make these changes.

Chladič nápojů
NÁVOD K OBSLUZE
PBC 6027

Vážený zákazníku,
Děkujeme, že jste zakoupil výrobek značky PHILCO. Aby váš spotřebič sloužil co nejlépe, přečtěte si
všechny pokyny v tomto návodu.
