Philco PW 15 K User manual

PW 15 K
WINE COOLER
USER’S MANUAL

Dear customer,
thank you for buying aPHILCO brand product. So that your appliance serves you well, please read
all the instructions in this user’smanual.

EN - 1
07/2016
Copyright © 2016, Fast ČR, a. s.
CONTENTS
PART 1: IMPORTANT SAFETY INSTRUCTIONS ............................................................................................. 2
PART 2: OVERVIEW ......................................................................................................................................... 6
PART 3: BEFORE INSTALLING THE APPLIANCE............................................................................................ 7
PART 4: INSTALLING THE APPLIANCE .......................................................................................................... 7
PART 5: AMBIENT TEMPERATURE ................................................................................................................. 7
PART 6: MOVING YOUR APPLIANCE.............................................................................................................. 7
PART 7: BEFORE FIRST USE ............................................................................................................................ 8
PART 8: OPERATION........................................................................................................................................ 8
PART 9: AUTOMATIC DEFROSTING ............................................................................................................... 9
PART 10: OPERATING NOISES........................................................................................................................ 9
PART 11: TIPS FOR SAVING ENERGY............................................................................................................. 9
PART 12: CLEANING AND MAINTENANCE ................................................................................................... 9
PART 13: TROUBLESHOOTING..................................................................................................................... 10
PART 14: SPECIFICATIONS ........................................................................................................................... 10
PART 15: INFORMATION SHEET................................................................................................................... 11

EN - 2
07/2016
Copyright © 2016, Fast ČR, a. s.
PART 1: IMPORTANT SAFETY INSTRUCTIONS
ACKNOWLEDGMENT
Thank you for purchasing our product. We hope you enjoy using the many features and bene ts it provides.
Before using this product please study this entire Instruction Manual carefully. Keep this manual in a safe place
for future reference. Ensure that other people using the product are familiar with these instructions as well.
WARNINGS
Thisapplianceisintendedtobeusedinhousehold.
This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made
by children without supervision.
If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualied persons in order to avoid a hazard.
The appliance shall not be exposed to rain.

EN - 3
07/2016
Copyright © 2016, Fast ČR, a. s.
WARNING
Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of
obstruction.
WARNING
Do not use mechanical devices or other means
to accelerate the defrosting process, other than
those recommended by the manufacturer.
WARNING
Do not damage the refrigerant circuit.
WARNING
Do not use electrical appliances inside the food
storagecompartmentsoftheappliance,unlessthey
are of the type recommended by the manufacturer.
Do not store explosive substances such as aerosol
cans with a ammable propellant in this appliance.
For the details concerning the method of cleaning,
please see section “Cleaning and maintenance” on
pages 9.

EN - 4
07/2016
Copyright © 2016, Fast ČR, a. s.
For disposal of the appliance
To prevent possible harm to the environment or
human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable
reuse of material resources and the ammable
insulation blowing gases. And the disposal should
only be done through public collection points.
For installation, servicing
Appliance should be placed on a horizontal oor
and keep the ventilation freely. Don’t try to replace
or repair any components by yourself, ask the service
agency for help if necessary.
For handling
Always handle the appliance to avoid any damage.
INSTALLATION:
DO NOT INSTALL THIS APPLIANCE IN AREAS THAT
ARE TOO HUMID OR TOO COLD, SUCH AS THE
OUTBUILDINGS, GARAGES OR WINE CELLARS.

EN - 5
07/2016
Copyright © 2016, Fast ČR, a. s.
IMPORTANT SAFETY INSTRUCTIONS
• This appliance is intended to be used
exclusively for the storage of wine.
• Do not place heavy objects on the top of the
appliance.
• Unplug the appliance from the mains socket
when not in use or before cleaning.
• Do not stand or support yourself on the base
or doors, etc.
• Do not store food in the appliance as the
interior temperature may not be cool enough
to prevent spoilage.
• Always carry, store and handle the appliance
in a vertical position.
Dispose of your old appliance
The appliance contains refrigerant and gases in
the insulation.
Refrigerant and blowing gases must be disposed
of professionally. Ensure that tubing of the
refrigerant circuit is not damaged prior to proper
disposal.

EN - 6
07/2016
Copyright © 2016, Fast ČR, a. s.
PART 2: OVERVIEW
CONTROL PANEL
1. Light button ;
2. °C and °F Switch button ;
3. Temperature setting display
4. Temperature setting buttons (+)
5. Temperature setting buttons (–)
Description of the part
1. Cabinet
2. Chrome shelf
3. Two line bottom wine rack
4. Adjustable feet
5. Door Hinge protector
6. Door gasket
7. Tempered glass door

EN - 7
07/2016
Copyright © 2016, Fast ČR, a. s.
PART 3: BEFORE INSTALLING THE APPLIANCE
Before connecting your appliance to the power supply, check that the voltage stated on the rating label of your
appliance corresponds to the voltage in your home. A dierent voltage could damage the appliance.
The plug is the only way to unplug the appliance and should therefore be accessible at all times. To turn o
main power to the appliance, detach the plug from the outlet. Do not immerse the appliance, the power cord
or the plug in water or other liquid.
The appliance must be grounded. The manufacturer is not responsible for damages that may occur as a result
of usage without grounding.
PART 4: INSTALLING THE APPLIANCE
This appliance is designed to be free standing only.
Install the appliance in a dry, well ventilated room.The installation location should neither be exposed to direct
sunlight nor near a heat source, e.g. a cooker, radiator, etc.
To ensure adequate ventilation for the appliance, allow a minimum of 10 cm of airspace on each side of the
cabinet.
For uneven surfaces, front feet can be aligned.
PART 5: AMBIENT TEMPERATURE
This appliance is designed to operate in ambient temperature between 10°C and 32°C.If these temperatures
are exceeded, i.e. colder or warmer, the appliance will not operate correctly.
PART 6: MOVING YOUR APPLIANCE
• Make sure that the appliance is unplugged from the mains socket. Remove all bottles and shelves to avoid
any shock.
• Always move the appliance vertically.
• After moving, wait for 30 minutes before plugging in the appliance.
Your appliance uses isobutane (R600a) as a refrigerant. Although R600a is an environmentally friendly and
natural gas, it is explosive. Therefore you should be careful during shipment and installation to prevent your
appliance’s cooler elements from being damaged. In the event of a leak caused by damage to the cooler
elements, move your appliance from open ame or heat sources and ventilate the room where the appliance
is located for a few minutes.

EN - 8
07/2016
Copyright © 2016, Fast ČR, a. s.
PART 7: BEFORE FIRST USE
• Remove all packaging.
• Clean the inside of the appliance with warm water and a little liquid detergent to remove manufacturing
and transportation dust.
PART 8: OPERATION
Ensure that the appliance is placed on a at and stable surface.
Plug the appliance into the mains socket. The display will show the current actual temperature of the internal
cabinet.
Allow the appliance to cool down for 2–3 hours before placing wine bottles in the appliance.
Selecting the temperature
The temperature can be set from 4°C to 18°C. The default factory temperature is set at 12°C.
1. Repeatedly press / to select the required temperature.
• Each time you press / the temperature will be increased or decreased by 1°C.
2. The temperature selected will ash on the display for approximately 3 seconds, then the display will return
to the current actual temperature of the internal cabinet.
• The current actual temperature will vary depending on the quantity of bottles stored and how often
the door is opened.
• Toview the set temperature,press / ,the set temperaturewill ash on the display for approximately
3 seconds and then return to the current actual temperature of internal cabinet.
• The temperature display can be switched between Celsius (°C) and Fahrenheit (°F) by pressing °F/°C.
The corresponding indicator light °C or °F will illuminate.
Interior lights
Press to turn the interior lights on or o.
The interior light will automatically turn o after approximately 10 minutes if you leave the light on.
Tips for storing wine
Store wine in sealed bottles.
Do not overload the appliance. The maximum number of bottles that can be stored is 15, depending on the
size of bottles.
To achieve the maximum capacity of the appliance, the bottles should be laid out as shown.
Standard 750ml Bordeaux bottle
300 mm
190 mm 39 mm 71 mm
70 mm

EN - 9
07/2016
Copyright © 2016, Fast ČR, a. s.
PART 9: AUTOMATIC DEFROSTING
Ice build-up on the inner back wall during compressor operation will defrost automatically when the
compressor has cycled o.
Defrost water will drain out through the drain outlet into a drain pan from where it will evaporate.
PART 10: OPERATING NOISES
Normal noises
• Motors are running.
• Refrigerant is owing through the tubing.
PART 11: TIPS FOR SAVING ENERGY
For the most energy ecient use of your appliance:
• Ensure your appliance has adequate ventilation as recommended in the installation instructions.
• Keep door openings to a minimum.
• Open the appliance as briey as possible.
• Ensure that the door is always closed properly.
PART 12: CLEANING AND MAINTENANCE
• Unplug the appliance from the mains socket before cleaning.
• Remove all bottles and shelves from the appliance.
• Clean the appliance with a soft cloth, warm water and detergent. Clean shelves with a slightly damp cloth.
Dry thoroughly.
• Do not use any abrasive or cleaning agents.
The interior LED lights in the appliance cannot be replaced by the user. If the LED lights stop working, please
contact the local authorised service agent.

EN - 10
07/2016
Copyright © 2016, Fast ČR, a. s.
PART 13: TROUBLESHOOTING
If there is a problem with your appliance, please check the following points before contacting customer service.
Problem Possible Cause Possible Solution
The appliance is not working. The appliance is not plugged in
the mains socket.
Check that the appliance is
properly plugged in the mains
socket.
The appliance is noisy during
operation.
The appliance is not level. Adjust the front feet to level the
appliance.
The appliance is not cool
enough.
Temperature set incorrectly Check temperature and reset if
necessary.
External environment may
require colder temperature.
The door is opened too often. Only open the door when
necessary.
Door seal is worn. Contact a local authorised
service agent.
PART 14: SPECIFICATIONS
Appliance type Wine Cooler
Rated current 0.5A
Input power 85W
Lamp power <1W
Insulation blowing gas Cyclopentane
Class of protection against electric shock I
Refrigerant/Amount R600a/18g
Energy consumption 0.30 kWh/24h
Bottle capacity 15
We apologise for any inconvenience caused by minor inconsistencies in these instructions, which may occur as
a result of product improvement and development.

EN - 11
07/2016
Copyright © 2016, Fast ČR, a. s.
PART 15: INFORMATION SHEET
INFORMAČNÍ LIST: Philco
Obchodní značka Philco:
Brand Philco
Product number PW 15 K
Type of appliance3) 2
Energy eciency class (A+++... low electricity consumption
to G high electricity consumption) A
Electricity consumption per 365 days1) kWh 110
Total available volume: l 46
of which: refrigerator part l 46
of which: freezer part l –
Temperature range +4 to + 18°C
Internal humidity 62.6 – 74.8 %
Climatic class2) N,SN
Installation free standing
Voltage 220-240v/50Hz
Noise level4) dB (re 1pW) 40
Dimensions in mm (h× w × d) 515× 430 × 480
Weight kg 15
NOTE:
This appliance is designed for the single purpose of storing wine.
1) Electricity consumption in kWh / year is based on the results of a normalised test carried out over a period
of 24 hours. Actual electricity consumption depends on the use and location of the appliance.
2) SN: ambient temperatures from +10 °C to +32 °C
ST: ambient temperatures from +18 °C to +38 °C
N: ambient temperatures from +16 °C to +32 °C
3) 1 = Refrigerator without low temperature areas
2 = Appliance is for storing wine
7 = Refrigerator/freezer with low temperature areas *(***)
8 = Upright freezer
4) Noise level according to European norm EN 60704.

EN - 12
07/2016
Copyright © 2016, Fast ČR, a. s.
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED
PACKAGING MATERIALS
Dispose of packaging material at a public waste disposal site.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC APPLIANCES
The meaning of the symbol on the product, its accessory or packaging indicates that this product
shall not be treated as household waste. Please, dispose of this product at your applicable collecti-
on point for the recycling of electrical & electronic equipment waste. Alternatively in some states
of the European Union or other European states you may return your products to your local retailer
when buying an equivalent new product. The correct disposal of this product will help save valu-
able natural resources and help in preventing the potential negative impact on the environment
and human health, which could be caused as a result of improper liquidation of waste. Please ask
your local authorities or the nearest waste collection centre for further details. The improper dis-
posal of this type of waste may fall subject to national regulations for fi nes.
For business entities in the European Union
If you wish to dispose of an electrical or electronic device, request the necessary information from
your seller or supplier.
Disposal in other countries outside the European Union
If you wish to dispose of this product, request the necessary information about the correct disposal
method from local government departments or from your seller.
This product meets all the basic EU regulation requirements that relate to it.
Changes to the text, design and technical specifi cations may occur without prior notice and we reserve the
right to make these changes.
Czech is the original version.
Manufacturer address: PHILCO, Praha 10, Černokostelecká 2111, CZ-10000; CZECH REPUBLIC
