Philips Ac3039 User manual

1

A

B

C

D

E

F

2

AC3033/AC3036

AC3039

3000 038 71722

EN User manual 1

DA Brugervejledning 17

DE Benutzerhandbuch 33

ES Manual del usuario 51

FI Käyttöopas 68

FR Mode d’emploi 84

IT Manuale utente 101

NL Gebruiksaanwijzing 118

NO Brukerhåndbok 136

SV Användarhandbok 152

3

11

7

15

21 22

3’

+

23

19

5

13

9

17

6

14

10

18

4

12

8

16

20

1EN

English

Contents

1 Important ��2

Safety ��2

Electromagnetic elds (EMF) ��4

Recycling ��4

Simplied EU declaration of conformity ��4

2 Your air purier ��4

Product overview (g a) ��4

Controls overview (g b) ��5

3 Getting started ��5

Installing the lter ��5

Understanding Wi-Fi indicator ��6

Wi-Fi connection ��6

4 Using the air purier ��7

Understanding the air quality light �� 7

Turning on and o ��8

Changing the mode setting ��9

Switching the display indicator ��9

Using the light on/o function ��9

Checking the lter status ��9

5 Cleaning and maintenance ��10

Cleaning schedule ��10

Cleaning the body of the air purier ��10

Cleaning the particle sensor �� 11

Cleaning the surface of the lter (g s) �� 11

Replacing the lter �� 12

Filter reset �� 13

6 Storage ��13

7 Troubleshooting ��13

8 Guarantee and service ��16

Order parts or accessories ��16

2EN

1 Important

Safety

Read this user manual carefully before you use the appliance, and save it for

future reference�

Danger

• Do not clean the appliance with water, any other liquid, or a

(ammable) detergent, nor let them enter the appliance, to

avoid electric shock and/or a re hazard�

• Do not spray any ammable materials such as insecticides

or fragrance around the appliance�

Warning

• Check if the voltage indicated on the appliance corresponds

to the local power voltage before you connect the

appliance�

• If the power cord is damaged, you must have it replaced by

Philips, a service center authorized by Philips, or similarly

qualied persons in order to avoid a hazard�

• Do not use the appliance if the plug, the power cord, or the

appliance itself is damaged�

• This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if

they have been given supervision or instruction concerning

use of the appliance in a safe way and understand the

hazards involved�

• Children shall not play with the appliance�

• Cleaning and maintenance shall not be made by children

without supervision�

• Do not block the air inlet and outlet, e�g� by placing items on

the air outlet or in front of the air inlet�

• Make sure that foreign objects do not fall into the appliance

through the air outlet�

3EN

English

Caution

• This appliance is not a substitute for proper ventilation,

regular vacuum cleaning, or use of an extractor hood or fan

while cooking�

• Always place and use the appliance on a dry, stable, level,

and horizontal surface�

• Leave at least 20cm free space around the appliance and

leave at least 30cm free space above the appliance�

• Do not sit or stand on the appliance� Do not place anything

on top of the appliance�

• Do not place the appliance directly below an air conditioner

to prevent condensation from dripping onto the appliance�

• Only use the original Philips lters specially intended for this

appliance� Do not use any other lters�

• Combustion of the lter may cause irreversible human

hazard and/or jeopardize other lives� Do not use the lter as

fuel or for similar purpose�

• Avoid knocking against the appliance (the air inlet and

outlet in particular) with hard objects�

• Do not insert your ngers or objects into the air outlet or the

air inlet to prevent physical injury or malfunctioning of the

appliance�

• Do not use this appliance when you have used indoor

smoke-type insect repellents or in places with oily residues,

burning incense, or chemical fumes�

• Do not use the appliance near gas appliances, heating

devices or replaces�

• Always unplug the appliance when you want to move, clean

appliance, replace the lter or carry out other maintenance�

• The appliance is only intended for household use under

normal operating conditions�

• Do not use the appliance in wet surroundings or in

surroundings with high humidity or high ambient

temperatures, such as the bathroom, toilet, or kitchen, or in

a room with major temperature changes�

• The appliance does not remove carbon monoxide (CO)

or radon (Rn)� It cannot be used as a safety device in case

of accidents with combustion processes and hazardous

chemicals�

4EN

Electromagnetic elds (EMF)

This Philips appliance complies with all applicable standards and regulations

regarding exposure to electromagnetic elds�

Recycling

This symbol means that this product shall not be disposed of with

normal household waste (2012/19/EU)�

Follow your country’s rules for the separate collection of electrical and

electronic products� Correct disposal helps prevent negative consequences for

the environment and human health�

Simplied EU declaration of conformity

Hereby, Philips Consumer Lifestyle B�V� declares that the radio equipment type

AC3033/AC3036/AC3039 is in compliance with Directive 2014/53/EU� The full

text of the EU declaration of conformity is available at the following internet

address: www�philips�com

2 Your air purifier

Congratulations on your purchase, and welcome to Philips!

To fully benet from the support that Philips oers, register your product at

www�philips�com/welcome�

Product overview (g a)

AControl panel

BGas sensor

CAir outlet

DParticle sensor

ENanoProtect lter Series 3 (FY3430/30)

FBack cover

5EN

English

Controls overview (g b)

Control buttons

Filter status/reset button Display switch button

Power on/o button Mode switch button

Light on/o button

Display panel

Wi-Fi indicator Auto mode

Turbo mode Sleep mode

Indoor Allergen Index display PM2�5 display

Gas pollution display Filter cleaning alert

Filter replacement alert

3 Getting started

Installing the lter

Remove all packaging of the lter before rst use�

Note: Make sure the air purier is unplugged from the electrical outlet before

installing the lter�

1 Pull the back cover and remove it from the appliance (g c)�

2 Pull the lter from the appliance (g d)�

3 Remove all packaging materials of the air purication lter (g e)�

4 Put the lter back into the appliance (g f)�

5 Reattach the back cover (g g)�

6EN

Understanding Wi-Fi indicator

Wi-Fi icon status Wi-Fi connection status

Blink in orange Connecting to the smartphone

Stable in orange Connected to the smartphone

Blink in white Connecting to the server

Stable in white Connected to the server

O Wi-Fi function disabled

Wi-Fi connection

Setting up the Wi-Fi connection for the rst time

1 Download and install the Philips “Clean Home+”app from the

App Store or Google Play�

2 Put the plug of the air purier in the power socket and touch

to turn on the air purier�

»The Wi-Fi indicator blinks orange for the rst time�

3 Make sure that your smartphone or tablet is successfully connected to

your Wi-Fi network�

4 Launch the “Clean Home+” app and click on “Connect a New Device”

or press the “+” button on the top of the screen� Follow the onscreen

instructions to connect the air purier to your network�

Note:

• This instruction is only valid when the air purier is being set up for the rst

time� If the network has changed or the setup needs to be performed again,

see Chapter “Reset the Wi-Fi connection” on page 7�

• If you want to connect more than one air purier to your smartphone or

tablet, you have to do this one by one�

• Make sure that the distance between your smartphone or tablet and the air

purier is less than 10 m without any obstructions�

• This App supports the latest versions of Android and iOS� Please check

www�philips�com/cleanhome for the latest update of supported operating

systems and devices�

7EN

English

Reset the Wi-Fi connection

Note:

• Reset the Wi-Fi connection when your default network has changed�

1 Put the plug of the air purier in the power socket and touch to turn on

the air purier�

2 Touch and simultaneously for 3 seconds until you hear a beep�

»The air purier goes to pairing mode�

»The Wi-Fi indicator blinks orange�

3 Follow the steps 3-4 in “Setting up the Wi-Fi connection for the rst time”

section�

4 Using the air purifier

Understanding the air quality light

The air quality light automatically goes

on when the air purier is switched on,

and lights up all colors in sequence�

After approximately 30 seconds, the

particle sensor selects the color that

corresponds to the surrounding air

quality of airborne particles�

The color of the air quality light is

determined by the highest index among PM2�5, IAI and Gas readings�

IAI

The professional-grade AeraSense sensor

detects the level of indoor air allergen and

with numerical feedback from 1 to 12 the

potential risk level of indoor air allergens can

be displayed� 1 indicates best air quality�

Air quality light color Air quality level

Blue Good

Blue-purple Fair

Purple-red Poor

Red Very poor

IAI level Air quality light color

1-3 Blue

4-6 Blue-purple

7-9 Purple-red

10-12 Red

8EN

PM2�5

AeraSense sensing technology

accurately detects and quickly

responds to even the slightest particle

change in the air� It provides you with

reassurance with real-time PM2�5

feedback�

Most of the indoor air pollutants

fall under PM2�5 – which refers to airborne particle pollutants smaller than

2�5 micrometers� Common indoor sources of ne particles are tobacco smoke,

cooking, burning candles� Some airborne bacteria and the smallest mold

spores, pet allergen and dust mite allergen particles also fall under PM2�5�

GAS

With an advanced gas sensor, a display

ranging from L1 to L4 shows the level change

of potential harmful gases (incl� VOC, odor,

etc�) detected� L1 indicates best air quality�

Turning on and o

Note:

• For optimum purication performance, close doors and windows�

• Keep curtains away from the air inlet or air outlet�

1 Put the plug of the air purier in the power socket�

2 Touch to switch on the air purier�

»The air purier beeps�

»The “ ” displays on the screen during warming up� Then the air

purier shows the IAI/PM2�5/Gas level after measuring the air quality�

»The air purier operates in the auto mode with IAI displayed on the

screen (g h)�

3 Touch and hold the button for 3 seconds to switch o the air purier�

Note: If the air purier stays connected to the electrical outlet after turning

OFF, the air purier will operate under the previous settings when turned ON

again�

PM2�5 level Air quality light color

≤12 Blue

13-35 Blue-purple

36-55 Purple-red

>55 Red

Gas level Air quality light color

L1 Blue

L2 Blue-purple

L3 Purple-red

L4 Red

9EN

English

Changing the mode setting

You can choose Auto mode, Turbo mode or the Sleep mode by touching the

button�

Auto mode ( ): In Auto mode, the dual-sensor sense the air quality in real-

time and the appliance automatically adjusts the fan speed in accordance

with the ambient air quality, the control panel can automatically adjust display

screen brightness according to the ambient light (g i)�

Turbo mode ( ): In Turbo mode, the air purier operates on the highest

speed (g j)�

Sleep mode ( ): In Sleep mode, the air purier operates quietly at a low

speed� After 3 seconds, the screen dims (g k)�

Switching the display indicator

Note: The appliance displays IAI level by default�

• Touch the button to switch display indicator among PM2�5 /Gas /IAI

(g l & g m & g n)�

Using the light on/o function

With

the light sensor, the control panel can automatically turn on, turn o or

dim according to the ambient light� The control panel will be o or dim when the

ambient light is dark� You can touch any button to wake up all lights� Then, if no

further operation, all lights will be o or dim again to match with the ambient

light (g

o

)�

You can touch the light on/o button manually to turn o all lights and the

control pa

nel� Touch any button to wake up all lights (g p)�

Checking the lter status

• Touch the lter status check/reset button to check the lter service life

status (g q)�

»The percentage of remaining service life of the lter displays on the

screen�

Icon color Filter life indication Display (%)

Blue Optimal service life 16-100

Blue-purple Good service life 9-15

Purple-red Service life almost reaches the end 4-8

Red Service life ends, replace the lter 0-3

Note: The appliance goes back to normal display if no operations after

3 seconds�

10 EN

5 Cleaning and maintenance

Note:

• Always unplug the appliance before you clean it�

• Never immerse the appliance in water or any other liquid�

• Never use abrasive, aggressive, or ammable cleaning agents such as

bleach or alcohol to clean any part of the appliance�

• Never use any liquids (including water) to clean the lter�

• Do not attempt to clean the particle sensor and gas sensor with a vacuum

cleaner�

Cleaning schedule

Frequency Cleaning method

When necessary

Wipe the fabric part of the appliance with

a damp cloth, wipe the plastic part of the

appliance with a soft, dry cloth

Clean the air outlet cover

Every two months Clean the particle sensor with a dry cotton

swab

The displays on the screen� Clean the surface of the lter

Cleaning the body of the air purier

Regularly clean the inside and outside of the air purier to prevent dust from

collecting�

1 Wipe the fabric surface gently with a damp cloth (for AC3033/AC3039

only)�

2 Use a soft, dry cloth to clean both the interior and exterior of the air

purier and the air outlet�

Note:

• The fabric covered on the appliance can not be removed�

• Do not use hot water, alcohol, harsh cleaners to clean the fabric�

11EN

English

Cleaning the particle sensor

Clean the particle sensor every 2 months for optimal functioning of the

appliance�

Note:

• If the air purier is used in a dusty environment, it may need to be cleaned

more often�

• If the humidity level in the room is very high, condensation may develop

on the particle sensor and the air quality light may indicate a more poor air

quality even though the air quality is actually good� If this occurs, clean the

particle sensor�

• The gas sensor doesn’t need to be cleaned�

1 Switch o the air purier and unplug from the power socket�

2 Pull the back cover and remove it from the appliance (g c)�

3 Clean the particle sensor with a damp cotton swab (g r)�

4 Dry all parts thoroughly with a dry cotton swab�

5 Reattach the back cover (g g)�

Cleaning the surface of the lter (g s)

Filter alert light status Action

The lter cleaning alert displays on

the screen�

Clean the surface of the lter with a

vacuum cleaner�

1 Switch o the air purier and unplug from the power socket�

2 Pull the back cover and remove it from the appliance (g c)�

3 Pull the lter from the appliance (g u)�

4 Clean the surface of the lter with a vacuum cleaner (g t)�

5 Put the lter back into the appliance (g f)�

6 Reattach the back cover� (g g)

7 Put the plug of the air purier in the power socket�

8 Touch the button to switch on the appliance�

9 Touch and hold the lter status check/reset button for 3 seconds to

reset the lter cleaning time�

10 Wash your hands thoroughly after cleaning the lter�

12 EN

Replacing the lter

Understanding the healthy protection lock

This air purier is equipped with a lter replacement indicator to make sure

that the air purication lter is in optimal condition when the air purier is

operating� When the lter need to be replaced, the lter replacement alert

lights up red�

If the lter is not replaced in time, the air purier will stop operating and

automatically lock to protect the air quality in the room� Replace the lter as

soon as possible�

Replacing the lter

Note:

• The lter is not washable or reusable�

• Always turn o the air purier and unplug from the electrical outlet before

replacing the lters (g v)�

Filter alert light status Action

The lter replacement alert

lights up

Replace the NanoProtect lter Series 3

(FY3430/30)

1 Switch o the air purier and unplug from the power socket�

2 Pull the back cover and remove it from the appliance (g c)�

3 Pull the lter from the appliance (g d)�

4 Remove all packaging materials of the new lter (g e)�

5 Put the new lter into the appliance (g f)�

6 Reattach the back cover (g g)�

7 Put the plug of the air purier in the power socket�

8 Touch the button to switch on the appliance�

9 Touch and hold the lter status check/reset button for 3 seconds to

reset the lter lifetime counter�

10 Wash your hands thoroughly after replacing the lter�

Note: Do not smell the lter as it has collected pollutants from the air�

13EN

English

Filter reset

You can replace the lter even before lter replacement alert ( ) displays on

the screen� After replacing a lter, you need to reset the lter lifetime counter

manually�

1 Touch the power button for 3 seconds to turn o the appliance and

unplug from power socket�

2 Put the power plug in the power socket�

3 Within 15 seconds after power on, touch and hold and button for

3 seconds to reset the lter lifetime counter (g w)�

6 Storage

1 Turn o the air purier and unplug from the power socket�

2 Clean the air purier, particle sensor and the surface of the lter (see

chapter ‘Cleaning and maintenance’)�

3 Let all parts air dry thoroughly before storing�

4 Wrap the lter in air tight plastic bags�

5 Store the air purier, lter in a cool, dry location�

6 Always thoroughly wash hands after handling the lter�

7 Troubleshooting

This chapter summarizes the most common problems you could encounter

with the appliance� If you are unable to solve the problem with the information

below, contact the Consumer Care Center in your country�

Problem Possible solution

The appliance

does not work

properly�

• Check if the back cover is properly installed�

• The lter replacement alert has been on continuously

but you have not replaced the corresponding lter� As a

result, the appliance is now locked� In this case, replace

the lter and long press to reset the lter lifetime

counter�

14 EN

Problem Possible solution

The airow that

comes out of

the air outlet

is signicantly

weaker than

before�

• The surface of the lter is dirty� Clean the surface of the

lter (see the chapter “Cleaning and maintenance”)�

The air quality

does not improve,

even though the

appliance has

been operating

for a long time�

• Check if the packing material is removed from the lter�

• The lter has not been placed in the appliance� Make

sure that the lter (FY3430/30) is properly installed�

• The particle sensor is wet� The humidity level in your

room is high and causes condensation� Make sure that

the particle sensor is clean and dry (see the chapter

“Cleaning and maintenance”)�

• Room size is large or the outdoor air quality is poor�

For optimum purication performance, please close the

doors and windows when operating the air purier�

• There are indoor pollution resources� For instances,

smoking, cooking, incense, perfume or alcohol�

• Filter reaches the end of life� Replace the lter with a

new one�

The color of the

air quality light

always stays the

same�

• The particle sensor is dirty� Clean the particle sensor

(see the chapter “Cleaning and maintenance”)�

The appliance

produces a

strange smell�

• The rst few times you use the appliance, it may

produce a plastic smell� This is normal� However, if the

appliance produces a burnt smell even if removing

lters, contact your Philips dealer or an authorized

Philips service center� The lter may produce smell after

being used for a while because of the absorption of

indoor gases� It’s recommended that you reactivate the

lter by putting it in direct sunlight for repeated use� If

odor still exists, replace the lter�

15EN

English

Problem Possible solution

The appliance is

extra loud�

• It's normal if the appliance runs at the Turbo mode�

• In the Auto mode, if the appliance is too loud, maybe

the appliance runs at high speed because air quality

becomes worse, or your personalized setting in App

triggers a higher fan speed� You can choose the Sleep

mode, or change the settings in the App�

• If there is abnormal sound, contact the Consumer Care

Center in your country�

• If anything drops into air outlet, it may also cause

abnormal loud sound� Immediate turn o appliance,

turn appliance upside down, to get foreign objectives

out of appliance�

The appliance still

indicates that I

need to replace a

lter, but I already

did�

• Perhaps you did not reset the lter lifetime counter�

Switch on the appliance� Then touch and hold the reset

button ( ) for 3 seconds�

Error code “E1”

displays on the

screen�

• The motor has malfunctions� Contact the Consumer

Care Center in your country�

16 EN

Problem Possible solution

The Wi-Fi setup is

not successful�

• If the router your purier is connected to is dual –

band and currently it is not connecting to a 2�4GHz

network, please switch to another band of the same

router (2�4GHz) and try to pair your purier again� 5GHz

networks are not supported�

• Web authentication networks are not supported�

• Check if the purier is within range of the Wi-Fi router�

You can try to locate the air purier closer to the Wi-Fi

router�

• Check if the network name is correct� The network

name is case-sensitive�

• Check if the Wi-Fi password is correct� The password is

case-sensitive�

• Retry the setup with the instructions in section ‘Set up

the Wi-Fi connection when the network has changed’�

• The Wi-Fi connectivity can be interrupted by

electromagnetic or other interferences� Keep the

appliance away from other electronic devices that may

cause interferences�

• Check if the mobile device is in airplane mode� Make

sure to have the airplane mode deactivated when

connecting to the Wi-Fi network�

• Consult the help section in the App for extensive and

up-to-date troubleshooting tips�

8 Guarantee and service

If you need information or if you have a problem, please visit the Philips

website at www�philips�com or contact the Philips Consumer Care Center

in your country (you can nd its phone number in the worldwide guarantee

leaet)� If there is no Consumer Care Center in your country, go to your local

Philips dealer�

Order parts or accessories

If you have to replace a part or want to purchase an additional part, go to your

Philips dealer or visit www�philips�com/support�

If you have problems obtaining the parts, please contact the Philips Consumer

Care Center in your country (you can nd its phone number in the worldwide

guarantee leaet)�

17DA

Dansk

Indhold

1 Vigtigt ��18

Sikkerhed ��18

Elektromagnetiske felter (EMF) ��20

Genbrug ��20

Forenklede EU-overensstemmelseserklæring ��20

2 Din luftrenser ��20

Produktoversigt (g� a) ��20

Oversigt over betjeningsknapper (g� b) �� 21

3 Kom godt i gang ��21

Montering af lteret �� 21

Om Wi-Fi-indikator �� 22

Wi-Fi-forbindelse �� 22

4 Brug af luftrenseren �� 23

Forklaring af luftkvalitetslyset �� 23

Sådan tændes og slukkes apparatet �� 24

Ændring af tilstandsindstillingen �� 25

Skift af displayindikator �� 25

Sådan bruger du lampens tænd/sluk-funktion �� 25

Kontrollér lterets status �� 25

5 Rengøring og vedligeholdelse ��26

Rengøringsskema ��26

Rengøring af luftrenserens kabinet ��26

Rengøring af partikelsensor ��27

Rengøring af lterets overade (g� s) ��27

Udskiftning af lteret ��28

Filternulstilling ��29

6 Opbevaring ��29

7 Fejlnding ��29

8 Garanti og service �� 32

Bestilling af dele eller tilbehør �� 32

18 DA

1 Vigtigt

Sikkerhed

Læs denne brugsvejledning omhyggeligt igennem, inden apparatet tages i

brug, og gem den til eventuelt senere brug�

Fare

• Undlad at rengøre apparatet med vand eller andre væsker

eller (brandbart) rengøringsmiddel eller at lade disse

trænge ind i apparatet for at undgå elektrisk stød og/eller

brandfare�

• Sprøjt ikke brændbare materialer som f�eks� insektgift eller

parfume omkring apparatet�

Advarsel

• Kontrollér, om den angivne netspænding på apparatet

svarer til den lokale netspænding, før du slutter strøm til

apparatet�

• Hvis netledningen beskadiges, må den kun udskiftes af

Philips, et autoriseret Philips-serviceværksted eller en

tilsvarende kvaliceret fagmand for at undgå enhver risiko�

• Brug aldrig apparatet, hvis netstik, netledning eller selve

apparatet er beskadiget�

• Dette apparat kan bruges af børn fra 8 år og opefter og

af personer med reducerede fysiske, sensoriske eller

mentale evner eller manglende erfaring og viden, hvis de

er blevet instrueret i sikker brug af apparatet og forstår de

medfølgende risici�

• Lad ikke børn lege med apparatet�

• Rengøring og vedligeholdelse må ikke foretages af børn

uden opsyn�

• Luftindtag og -udtag må ikke blokeres, f�eks� ved at stille ting

på luftudtaget eller foran luftindtaget�

• Sørg for, at fremmedlegemer ikke falder ind i apparatet

gennem luftudgangen�

Philips AC3039 User manual

Popular Air Cleaner manuals by other brands
