Philips CEM1102 User manual

CEM1102
Register your product and get support at
www.philips.com/welcome
User manual
Always there to help you
Question?
Contact
Philips
CEM1100_UM_55_EN.indd 1 4/15/2013 11:46:16 AM

3
English
9 Product information 20
10 Troubleshooting 21
Contents
1 Important 4
Safety 4
Notice 4
2 Your car audio system 5
Introduction 5
What’s in the box 6
Overview of the main unit 7
Overview of the remote control 8
3 Get started 9
Install the car audio 9
Install remote control battery 12
Turn on 12
Set clock 13
4 Listen to radio 13
Tune to a radio station 13
Store radio stations in memory 14
Tune to a preset station 14
5 Playaudioles 14
Play a disc 14
Play options 15
Connect external sound source 15
6 Adjust sound 16
Adjust volume 16
Mute 16
Turn Dynamic Bass Boost (DBB) on/off 16
Turn on/off MAX sound 16
Select preset equalizer 16
Switch music listening zone 16
Other sound settings 16
7 Adjust system settings 17
Turn beep sound on/off 17
Turn demo mode on/off 17
Dimmer 17
Dance 17
Rear Aux 17
Reset 18
8 Additional information 18
Detach the front panel 18
Replace fuse 18
Remove the unit 19
CEM1100_UM_55_EN.indd 3 4/15/2013 11:46:16 AM

4
•Do not place any sources of danger on the
apparatus (e.g. liquid lled objects, lighted
candles).
Notice
The making of unauthorized copies of copy-
protected material, including computer
programs, les, broadcasts and sound
recordings, may be an infringement of
copyrights and constitute a criminal offence.
This equipment should not be used for such
purposes.
Windows Media and the Windows logo
are trademarks, or registered trademarks of
Microsoft Corporation in the United States
and/or other countries.
This apparatus includes this label:
Recycling
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
When you see the crossed-out wheel bin
symbol attached to a product, it means the
product is covered by the European Directive
2002/96/EC:
1 Important
Safety
•Read and understand all instructions
before you use your apparatus. If damage is
caused by failure to follow instructions, the
warranty does not apply.
•This apparatus is designed for negative
ground (earth) 12 V DC operation only.
•To ensure safe driving, adjust the volume to
a safe and comfortable level.
•Improper fuses can cause damage or
re. When you need to change the fuse,
consult a professional.
•Use only the supplied mounting hardware
for a safe and secure installation.
•To avoid short circuit, do not expose the
apparatus, remote control or remote
control batteries to rain or water.
•Never insert objects into the ventilation
slots or other openings on the apparatus.
•Clean the apparatus and frame with a soft,
damp cloth. Never use substances such as
alcohol, chemicals or household cleaners
on the apparatus.
•Never place any objects other than discs
into the apparatus.
•Never use solvents such as benzene,
thinner, cleaners available commercially, or
anti-static sprays intended for discs.
•Visible and invisible laser radiation when
open. Avoid exposure to beam.
•Risk of damage to the apparatus screen!
Never touch, push, rub or strike the screen
with any object.
Caution
•Use of controls or adjustments or performance of
procedures other than herein may result in hazardous
radiation exposure or other unsafe operation.
•The apparatus shall not be exposed to
dripping or splashing.
EN
CEM1100_UM_55_EN.indd 4 4/15/2013 11:46:17 AM

5
English
2 Your car audio
system
Congratulations on your purchase, and
welcome to Philips! To fully benet from the
support that Philips offers, register your product
at www.philips.com/welcome.
Introduction
With the in-car audio system, you can enjoy
your drive while listening to:
•FM or AM (MW) radio
•Audio from CD or MP3 disc
•Audio from external devices
The unit supports the following media format:
Never dispose of your product with other
household waste. Please inform yourself about
the local rules on the separate collection of
electrical and electronic products.The correct
disposal of your old product helps prevent
potentially negative consequences on the
environment and human health.
Your product contains batteries covered by the
European Directive 2006/66/EC, which cannot
be disposed of with normal household waste.
Please inform yourself about the local rules on
separate collection of batteries.The correct
disposal of batteries helps prevent potentially
negative consequences on the environment and
human health.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and old
equipment.
Any changes or modications made to this
device that are not expressly approved by
Philips Consumer Lifestyle may void the user’s
authority to operate the equipment.
2013 © Koninklijke Philips Electronics N.V. All
rights reserved.
Specications are subject to change without
notice.Trademarks are the property of
Koninklijke Philips Electronics N.V. or their
respective owners. Philips reserves the right
to change products at any time without being
obliged to adjust earlier supplies accordingly.
EN
CEM1100_UM_55_EN.indd 5 4/15/2013 11:46:18 AM

6
What’s in the box
Check and identify the contents of your
package:
aMain unit (with a sleeve)
bRemote control
cFront panel
dTrim plate
eCarrying case for front panel
fISO male connector
gRubber cushion
hScrew x 1 pc
iDisassembly tools x 2 pcs
jUser manual
a
f
c
b
j
i
cccccc
h
g
c
EN
CEM1100_UM_55_EN.indd 6 4/15/2013 11:46:19 AM

7
English
d/
• Turn the unit on or off.
• Conrm selection.
• Mute or unmute sound.
• Rotate to adjust volume.
eZONE /
• Select tuner band.
• Select MP3/WMA folder.
• Switch music listening zone.
Overview of the main unit
aSOURCE
• Select audio source.
bMENU
• Access system menu.
c
• Return to previous menu.
m
n gopq
f adc b
sr
lk j
e
hi
EN
CEM1100_UM_55_EN.indd 7 4/15/2013 11:46:21 AM

8
Overview of the remote
control
aVOL +/-
• Adjust volume.
b/
• Select tuner band.
• Scroll up/down menu.
• Select MP3/WMA folder.
c/
• Tune to a radio station
• Skip track.
• Fast backward/forward playback
dSOURCE
• Select audio source.
eEQ
• Select equalizer (EQ) settings.
fOFF / /
• Turn the unit on or off.
• Mute or restore volume.
a
b
d
c
e
f
f
• Eject disc.
gMP3 LINK
• Connect external audio device.
h
6281'
• Turn on or off Maximizing volume.
• View clock.
iDBB
• Turn on or off Dynamic Bass Boost
(DBB) sound.
• Access to tuner auto store.
j
• Select preset radio station No.6.
• Start play.
• Pause or resume play.
kREP / SHUF
• Select preset radio station No.3/4.
• Access to repeat play.
• Access to shufe play.
l/
• Select preset radio station No.1/2.
• Search for track/folder.
m/
• Tune for radio station.
• Skip/search for track.
• Fast backward/forward playback.
nDISP
• Display current status.
• Select the dimmer high or low.
oEQ / AUDIO
• Select equalizer (EQ) setting.
• Access audio setting menu.
p
• Unlock the panel.
qBAND
• Select tuner band.
rRESET
• Restore default settings.
sDisc slot
EN
CEM1100_UM_55_EN.indd 8 4/15/2013 11:46:22 AM

9
English
Note on the power supply lead (yellow)
•When you connect other devices to this
apparatus, ensure that the rating of the car
circuit is higher than the total fuse value of
all the connected devices.
Notes on speaker connection
•Never connect speaker wires to the metal
body or chassis of the car.
•Never connect speaker wires with stripes
to one another.
Connection: for cars with ISO
connectors
Caution
•Ensure that all loose leads are insulated with electrical
tape.
Note
•Consult a professional to connect CEM1100 as
instructed below.
1Connect the supplied male connector to
the unit.
2Check the car’s wiring carefully and
connect them to the the supplied male
connector.
Note
•Risk of danger! Please consult a professional to perform
the below steps!
3 Get started
Caution
•Use the controls only as stated in this user manual.
Always follow the instructions in this chapter in
sequence.
If you contact Philips, you will be asked for the
model and serial number of your apparatus.The
model number and serial number are on the
bottom of your apparatus.Write the numbers
here:
Model No. __________________________
Serial No. ___________________________
Install the car audio
These instructions are for a typical installation.
However, if your car has different requirements,
make the corresponding adjustment. If you have
any questions regarding installation kits, consult
your Philips car audio dealer.
Caution
•This unit is designed for negative ground (earth) 12 V
DC operation only.
•Always install this unit in the car dashboard. Other
locations can be dangerous as the rear of the unit heats
up during use.
•To avoid short-circuit: before you connect, ensure that
the ignition is off.
•Ensure that you connect the yellow and red power
supply leads after all other leads are connected.
•Ensure that all loose leads are insulated with electrical
tape.
•Ensure that the leads do not get caught under screws
orin parts that will move (e.g. seat rail).
•Ensure that all ground (earth) leads are run to a
common ground (earth) point.
•Use only the supplied mounting hardware for a safe
and secure installation.
•Improper fuses can cause damage or re. When you
need to change the fuse, consult a professional.
EN
CEM1100_UM_55_EN.indd 9 4/15/2013 11:46:23 AM

10
Connector Connect to
1 ANTENNA Antenna
2 FRONT LINE OUT R
(Socket)
Front right
speaker
3 FRONT LINE OUT L
(Socket)
Front left
speaker
4 REAR LINE OUT R
(Socket)
Rear right
speaker
5 REAR LINE OUT L
(Socket)
Rear left
speaker
6 OE REMOTE (Purple) OE Remote
7 TEL MUTING (Blue) To cellular
phone system
8 REAR AUX LINE OUT
R (Socket)
Rear Aux right
9 REAR AUX LINE OUT
L (Socket)
Rear Aux left
Tip
•The pin arrangement for the ISO connectors depends
on the type of vehicle you drive. Be sure to make
proper connections to prevent damage to the unit.
5($5 )5217
5
/
5( $5$8;
/5
5
/
8
9
7
9
1 Green/black
strip
Left speaker (Rear)
2 White/black
strip
Left speaker (Front)
3 Gray/black strip Right speaker (Front)
4 Purple/black
strip
Right speaker (Rear)
e Red Ignition key +12V DC
when ON/ACC
f Blue Motor/electric antenna
relay control lead
g Blue/white Amplier replay control
lead
h Black Ground
i Yellow To the +12V car
battery which is
energized at all times
3 Connect the antenna and amplier as
illustrated, if applicable.
EN
CEM1100_UM_55_EN.indd 10 4/15/2013 11:46:24 AM

11
English
Note
•If the unit is not xed by sleeve but by the supplied
screws, skip this step.
5Place the supplied rubber cushion over the
end of the mounting bolt.
6Slide the unit into the dashboard until you
hear a click sound.
183 mm
53.5 mm
Mount into the dashboard
1If the car does not have an on-board drive
or navigation computer, disconnect the
negative terminal of the car battery.
• If you disconnect the car battery in
a car that has an on-board drive or
navigation computer, the computer
may lose its memory.
• If the car battery is not disconnected,
to avoid short-circuit, ensure that the
bare wires do not touch each other.
2Ensure that car dashboard opening is
within these measurements:
3Remove the mounting sleeve with the
supplied disassembly tools.
4Install the sleeve into the dashboard and
bend the tabs outward to x the sleeve.
183 mm
53mm
5mm
EN
CEM1100_UM_55_EN.indd 11 4/15/2013 11:46:25 AM

12
Install remote control battery
Caution
•Risk of explosion! Keep batteries away from heat,
sunshine or re. Never discard batteries in re.
•Risk of decreased battery life! Never mix different
brands or types of batteries.
•Risk of product damage! When the remote control is
not used for long periods, remove the batteries.
•Perchlorate Material - special handling may apply. See
www.dtsc.ca.gov/hazardouswaste/perchlorate.
Forrst-timeuse:
Remove the protective tab to activate the
remote control battery.
To replace the remote control battery:
1Open the battery compartment.
2Insert one CR2025 battery with correct
polarity (+/-) as indicated.
3Close the battery compartment.
Turn on
To turn on the unit,
•Press .
•To turn off the unit,
•press and hold until the unit is turned
off.
7Reconnect the negative terminal of the car
battery.
Attach the front panel
1Attach the trim plate.
2Insert the right side of the panel in the
chassis until it is correctly engaged.
3Press the left side of the panel until the
mechanism locks it into place.
EN
CEM1100_UM_55_EN.indd 12 4/15/2013 11:46:27 AM

13
English
4 Listen to radio
Tune to a radio station
1Press SOURCE repeatedly to select radio
mode.
2Press BAND or / repeatedly to select
band: [FM1], [FM2], [FM3], [AM1], or
[AM2] .
3Press and hold or until the
frequency digit is ashed.
4Press or to tune to a radio station
manually.
»The radio station is broadcast.
• To search for a radio station
automatically, press or .
Select tuner region
You can select suitable country/region of the
radio.
1Press SOURCE to select radio mode.
2Press MENU repeatedly until [AREA] is
displayed..
3Rotate to select:
• [USA] (United States)
• [LATIN] (Latin America)
• [EUROPE] (Western Europe)
• [RUS] (Russia)
• [M-EAST] (Middle East)
• [ASIA] (Asia Pacic)
• [JAP] (Japan)
• [AUST] (Australia)
4Press to conrm.
Select tuner sensitivity
To receive more radio stations or only stations
with strong signal, you can adjust the tuner
sensitivity.
1Press MENU repeatedly until [LOCAL] is
displayed.
Select country/region
Note
•Select correct country/region for this unit, otherwise
the unit can not work properly.
1Press to turn on the unit.
»[SELECT OPERATING REGION] is
displayed.
2Rotate to select an option:
• [USA] (United States)
• [LATIN] (Latin America)
• [EUROPE] (Western Europe)
• [RUS] (Russia)
• [M-EAST] (Middle East)
• [ASIA] (Asia Pacic)
• [JAP] (Japan)
• [AUST] (Australia)
3Press to conrm.
Set clock
1Press MENU repeatedly until current time
is ashed.
2Rotate to set hour.
3Press to conrm.
4Rotate to set minute.
5Press to conrm.
Set clock format
1Press MENU.
2Press or repeatedly until [CLOCK
FORMAT] is displayed.
3Rotate to select a setting:
• [CLOCK 12H]
• [CLOCK 24H]
View clock
In any mode, press and hold MAX SOUND
until the clock is displayed.
•Press any key to cancel the clock display.
EN
CEM1100_UM_55_EN.indd 13 4/15/2013 11:46:28 AM

14
5 Play audio files
Note
•Ensure that the disc or device contains playable les.
Play a disc
Note
•You cannot play CDs encoded with copyright
protection technologies.
You can play commercially available audio CDs
and these discs:
•CD-Recordables (CD-R)
•CD-Re-writables (CD-RW)
•MP3 CDs
•WMA CDs
Note
•Ensure that the disc contains playable content.
Insert a CD with the printed side facing up.
»Play starts automatically.
• To pause CD play, press .
• To resume CD play, press again.
• To skip to the previous/next track, press
or .
• To search backward/forward rapidly within
the current track, press or for 3
seconds.
Remove the CD
To take out the CD, press on the front panel.
Tip
•If the disc is blocked in the disc compartment, press and
hold until the disc comes out.
2Rotate to select a setting:
• [LOCAL ON] (local on): Only
stations with strong signal can be
broadcast.
• [LOCAL OFF] (local off): Stations
with strong and weak signals can be
broadcast.
Store radio stations in
memory
You can store up to 6 stations in each band.
Store stations automatically
1 In Radio mode, press and hold DBB until
[STORE - - -] is displayed.
2Press to conrm.
»The six strongest stations of the
selected band are saved in preset
channel automatically.
Store stations manually
1Tune to a station that you want to store
(see ‘Tune to a radio station’ on page 134).
2Press a numeric button for 3 seconds.
»The station is saved in the selected
channel.
Tune to a preset station
1Press BAND to select band.
2Press a numeric key to select a preset
station.
EN
CEM1100_UM_55_EN.indd 14 4/15/2013 11:46:28 AM

15
English
Repeat play
1 During play, press REP.
»[REPEAT] is displayed.
2Rotate to select a setting.
• [REP TRK] (repeat one track): play
current track repeatedly.
• [REP FLD] (repeat a folder): play all
tracks in the current folder repeatedly.
• [REP ALL] (repeat all tracks): play all
tracks repeatedly.
Shufeplay
You can play the tracks in random order:
1 During play, press SHUF.
»[SHUFFLE] is displayed.
2Rotate to select a setting:
• [SHUF FLD]: start random play for all
tracks in the current folder.
• [SHUF ALL]: start random play for all
tracks.
• [SHUF OFF]: cancel shufe play.
Connect external sound
source
1Connect the external sound source to
MP3 LINK socket with a 3.5 mm cable.
2Press SOURCE repeatedly until [MP3
LINK] is displayed.
3Operate the external component (refer to
the instructions supplied with the external
component).
Play options
Search for an MP3/WMA track
Search within the current folder
1Press .
»The name of the current track is
displayed.
2Rotate to select anther track in current
folder.
3Press to conrm.
Search in other folder
1Press .
»The name of the current folder is
displayed.
2Rotate to navigate through all folders.
3Press to access the selected folder.
»The unit starts playing the rst song
from the selected folder automatically.
Tip
•To go back to upper level of a folder, press .
View play information
During playing, press DISP repeatedly to view:
•Track number and elapsed play time
•Folder
•File
•Album
•Artist
•Title
EN
CEM1100_UM_55_EN.indd 15 4/15/2013 11:46:28 AM

16
2Press EQ / AUDIO again to select a preset
EQ setting:
• [OPTIMAL] (optimal)
• [FLAT] (at)
• [POP] (pop)
• [USER] (user)
• [TECHNO] (techno)
• [ROCK] (rock)
• [CLASSIC] (classic)
• [JAZZ] (jazz)
Switch music listening zone
Philips’ innovative Zone technology enables
driver or passengers to enjoy music with the
best speakers balance and experience more
vivid spacial effect as the artist is intended to
create.You can switch the music listening zone
from driver to passengers for the best speaker
sound settings in car.
1Press ZONE.
»The current setting is displayed.
2Rotate / to select a setting:
• [ALL]
• [FRONT-L] (Front left)
• [FRONT-R] (Front right)
• [FRONT]
Other sound settings
You can also adjust the preset EQ / AUDIO
settings.
1Press EQ / AUDIO for 3 seconds.
2Press or repeatedly to select the item
to be adjusted:
• [BAS] (bass) range: -7 to +7.
• [TRE] (treble)range: -7 to +7.
• [BAL] (balance) range: 12L to 12R.
(L=left speaker, R=right speaker)
• [FAD] (fader) range: 12R to 12F.
(R=rear speaker, F=front speaker)
3Rotate to select a value.
6 Adjust sound
Adjust volume
Turn clockwise/counterclockwise to increase/
decrease volume.
Mute
You can turn off the sound of your audio.
During play, press .
•To resume sound, press again.
Turn Dynamic Bass Boost
(DBB) on/off
1Press DBB and the current setting is
displayed:
»[DBB ON] :The Dynamic Bass Boost
(DBB) function is on.
»[DBB OFF] :The DBB function is off.
2 Press DBB again to change the DBB setting.
Turn on/off MAX sound
1Press
6281'
.
»The current setting displays
»[MAX ON]:The maximum sound
(MAX sound) function is on.
»[MAX OFF]:The maximum sound
function is off.
2Press
6281'
again to select an option.
Select preset equalizer
1Press EQ / AUDIO.
»Current Equalizer setting is displayed.
EN
CEM1100_UM_55_EN.indd 16 4/15/2013 11:46:29 AM

17
English
Dimmer
1Press MENU.
2Press or repeatedly until [DIMMER]
is displayed.
3Rotate to select a setting:
• [DIMM HIGH] (dimmer high)
• [DIMM LOW] (dimmer low)
Dance
You can turn on or off the spectrum on the
LCD display.
1Press MENU.
2Press or repeatedly until [DANCE] is
displayed.
3Rotate to select a setting:
• [DANCE ON] :Turn on the spectrum.
• [DANCE OFF] :Turn off the
spectrum.
Rear Aux
1Press MENU.
2Press or repeatedly until [TEL MUTE]
is displayed.
3Rotate to select a setting:
• [NORMAL] : Mute the telephone,
[MUTE] is displayed.
• [REAR AUX] : Mute the telephone,
[PHONE IN] is displayed.
Note
•To support telephone call with this unit, connect TEL
MUTING wire to your hands-free kit and audio out
jack to the REAR AUX in jack of the unit.
7 Adjust system
settings
Turn beep sound on/off
Each time you press a button, the unit beeps.
You can turn off/on this beep sound.
1Press MENU.
2Press or repeatedly until [BEEP] is
displayed.
3Rotate to select a setting:
• [BEEP ON]:Turn on the beep sound.
• [BEEP OFF]:Turn off the beep sound.
Turn demo mode on/off
1Press MENU.
2Press or repeatedly until [DEMO] is
displayed.
»The screen shows current Demo
mode setting.
3Rotate to select a setting:
• [DEMO ON] :Turn on the demo
mode.When the unit is idle for more
than 10 seconds, all functions are
displayed.
• [DEMO OFF] :Turn off the demo
mode.
EN
CEM1100_UM_55_EN.indd 17 4/15/2013 11:46:29 AM

18
8 Additional
information
Detach the front panel
You can detach the front panel to deter theft.
1Press to release the panel.
2Pull the panel towards you to disengage it
from the chassis.
3Store the panel in the supplied carrying
case to protect it from dirt or damage.
Replace fuse
If the fuse is damaged,
1Check the electric connection.
2Buy a fuse that matches the voltage of the
damaged fuse.
Reset
You can reset the unit to its default setting.
1Detach the front panel. (see ‘Detach the
front panel’ on page 19)
2Press the reset button by using a ball-point
pen or a similar tool.
»Preset adjustments such as preset
channels and sound adjustments are
erased.
EN
CEM1100_UM_55_EN.indd 18 4/15/2013 11:46:30 AM

19
English
3Replace the fuse.
Note
•If the new fuse gets damaged again, there may be an
internal malfunction. Consult your Philips dealer.
Remove the unit
You can remove the unit from the dashboard.
1Detach the front panel.
2Pull out the unit by using the disassembly
tools.
EN
CEM1100_UM_55_EN.indd 19 4/15/2013 11:46:32 AM

20
9 Product information
Note
•Product information is subject to change without prior notice.
Power supply 12 V DC (11 V - 16 V), negative ground
Fuse 15 A
Suitable speaker impedance 4 - 8
Maximum power output 50 W x 4 channels
Continuous power output 22 W x 4 RMS (4 10% T.H.D.)
Pre-Amp output voltage 2.5V
Aux-in level 500 mV
Dimensions (W x H x D) 181.5 x 52 x 191.4 mm
Weight 1.47 kg
Radio
Frequency range - FM 87.5 - 108.0 MHz (100kHz per step in auto search
and 50kHz per step in manual search)
Frequency range - AM(MW) 522 - 1620 KHz (9 kHz)
530 - 1710 kHz (10 kHz)
Usable sensitivity - FM 8 µV
Usable sensitivity - AM(MW) (S/N = 20 dB) 30 µV
Supported formats:
•MP3 bit rate (data rate): 32-320 Kbps and variable bit rate
•MP3 sampling frequencies: 8-48 kHz
•WMA V4, V7, V8, V9 (L1, L2)
•ISO9660, Joliet
•WMA sampling frequencies: 32 kHz, 44.1 kHz, 48 kHz
•WMA Bit-rates: 32~192 (kbps), variable bit rates
•Directory nesting up to a maximum of 8 levels
•Number of albums/ folders: CD maximum 99
•Number of tracks/titles/les: CD maximum 999 (depending on number of album)
•ID3 tag v2.0 or later
Unsupported formats:
•Empty albums: an empty album is an album that does not contain MP3/WMA les, and is not be
shown in the display.
•Unsupported le formats are skipped. For example, Word documents (.doc) or MP3 les with
extension .dlf are ignored and not played.
•AAC, WAV, PCM audio les
•DRM protected WMA les (.wav, .m4p, .mp4, .aac)
•WMA les in Lossless format
EN
CEM1100_UM_55_EN.indd 20 4/15/2013 11:46:33 AM

21
English
The CD skips tracks
•Ensure that the CD is not damaged or
dirty.
•Ensure that random mode is deactivated.
Disc cannot be ejected
•Press and hold .
Preset stations lost.
•Battery cable is not correctly connected.
Connect the battery cable to the terminal
that is always live.
10 Troubleshooting
Caution
•Never remove the casing of this apparatus.
To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this
apparatus, check the following points before
requesting service. If the problem remains
unsolved, go to the Philips web site (www.
philips.com/support). When you contact Philips,
ensure that your apparatus is nearby and the
model number and serial number are available.
No power or no sound.
•Car engine is not on.Turn the car engine
on.
•Cable is not correctly connected. Check
connections.
•Fuse is burnt. Replace fuse.
•Volume is too low. Adjust volume.
•If the above solutions cannot help, press
the RESET button.
•Ensure that the track played is of a
compatible format.
Noise in broadcasts.
•Signals are too weak. Select other stations
with stronger signals.
•Check the connection of the car antenna.
•Change broadcast from Stereo to mono.
Cannot play disc
•Ensure that the disc label is inserted with
the printed side facing up.
•Wipe the disc with bre cleaning cloth
from the centre to the edge in a straight
line.
•This disc may be defective. Play another
disc.
•Ensure that the CD is a nalised CD/
CD-R/CD-RW.
•Ensure that the CD is not encoded with
copyright protection technologies.
EN
CEM1100_UM_55_EN.indd 21 4/15/2013 11:46:33 AM
