Philips CEM2000B/05 User manual

Register your product and get support at CEM2000B
EN Quick Start Guide
6
5mm5mm5mm5mm
5mm
1ab
efg
45
B
hi
d
c
A
b
a
c
d
aa
bcd
ab
ef
cd
gh
b
c
d
32
FUSE
6
CEM2000B_05_QSG_V1.2.indd 1 10/13/2010 4:42:36 PM

Overview of parts 1
These are the supplied parts needed to connect
and install this unit.
aIn-car audio system
bSleeve
cFront panel
dStandard ISO connector
eTrim plate
fRubber cushion
gDisassembly tools
hScrews (4 pieces)
iDAB antenna
Connection
Caution
•Ensure that all loose leads are insulated with
electrical tape.
For cars with ISO connectors 234
1Pull out the ISO connectors from car
dashboard and connect them to the bigger
end of the supplied standard connector.
2Connect the other end of the supplied
standard connector to the unit.
3Connect the antenna and amplier as
illustrated, if applicable.You can connect the
car audio to the amplier through RCA-TO-
RCA cables (not supplied).
Connector Connect to
1ANTENNA Antenna
2FRONT LINE
OUT R (Socket)
Front right speaker
3FRONT LINE
OUT L (Socket)
Front left speaker
4REAR LINE
OUT R (Socket)
Rear right speaker
5REAR LINE
OUT L (Socket)
Rear left speaker
6DAB Antenna DAB Antenna
For cars with ISO connectors 45
Caution
•Be sure to connect the black ground (earth)
lead rst.
1Connect the antenna and amplier as
illustrated, if applicable.
2Cut off the bigger end of the supplied
standard connector.
3Check the car’s wiring carefully and connect
them to the supplied standard connector.
4Connect the supplied standard connector to
the unit.
1Green/black strip Left speaker (Rear)
2White/black strip Left speaker (Front)
3Gray/black strip Right speaker (Front)
4Purple/black strip Right speaker (Rear)
eRED Ignition key +12V DC when
ON/ACC
fBLUE Motor/electric antenna relay
control lead/Amplier relay
control lead
gBLACK Ground
hYELLOW To the +12V car battery
which is energized at all times
Mount in the dashboard 6
1If the car does not have an on-board drive or
navigation computer, disconnect the negative
terminal of the car battery.
If you disconnect the car battery in a car •
that has an on-board drive or navigation
computer, the computer may lose its
memory.
If the car battery is not disconnected, •
to avoid short-circuit, ensure that bare
wires do not touch each other.
2Remove the two screws on the top of the
unit.
3Remove the mounting sleeve with the
supplied disassembly tools.
4Install the sleeve into the dashboard and
bend the tabs outward to x the sleeve.
5Place the supplied rubber cushion over the
end of the mounting bolt.
6Slide the unit into the dashboard until you
hear a click sound.
7Reconnect the negative terminal of the car
battery.
Attach the front panel 6
1Attach the trim plate.
2Insert the right side of the panel in the
chassis until it is correctly engaged.
3Press the left side of the panel until the
mechanism locks it into place.
Turn on
1Press to turn on the unit.
To turn off the unit, press•for over
3 seconds.
Set clock
1Press MENU.
2Press or repeatedly until current time is
displayed.
3Turn to set hour.
4Press to conrm.
5Turn to set minute.
6Press to conrm.
View clock
1Press and hold OPTIONS repeatedly until
the clock is displayed.
Listen to radio
1Press SOURCE repeatedly to select Tuner.
2Press or to select band: [FM1], [FM2],
[FM3], [AM1], or [AM2].
3Press or to tune to a radio station
manually.
To search for a radio station automati-•
cally, press or for over 3 seconds.
Listen to Digital Audio Broadcasts (DAB)
For the rst time when DAB mode is switched on.
1Press SOURCE on the main unit repeatedly
to select DAB/DAB+.
The system performs auto scan.
»
All the available DAB stations is stored.
»
The radio tunes to the first available
»
station.
Play a disc
1Insert a CD with the printed side facing up.
Play starts automatically.
»
Play from USB
1 Slide the USB socket cover marked to
the left.
2 Insert the USB device into the USB socket.
The unit starts playing from the USB
»
device automatically.
© 2010 Koninklijke Philips Electronics N.V.
All rights reserved.
CEM2000B_05_QSG_V1.2
NOTE
Avoid prolonged use of the apparatus with volume above 85 decibels as this may damage your hearing.
