User manual
Always there to help you
Register your product and get support at
CE153DR
Question?
Contact
Philips

1EN
Contents
1 Safety 2
2 Your car audio system 3
Introduction 3
What's in the box 3
Overview of the system 4
3 Install the car audio system 6
Connect wires 7
Mount into the dashboard 8
Attach the front panel 10
4 Get started 11
For the rst time use 11
Set the time format 11
Set the clock 11
Select a source 11
Select a listening zone 12
Mute the button beep 12
5 Listen to FM/MW radio stations 12
Switch to FM/MW radio mode 12
Select a tuner region 12
Select a tuner sensitivity 13
Search for a radio station 13
Store radio stations in memory 13
Play with RDS 13
6 Listen to DAB radio stations 15
Switch to DAB mode 15
Scan for on-air stations 15
Program radio stations 16
Display DAB information 16
Set up for weak reception 17
Use the DRC (Dynamic Range Control) 17
Disable the DAB reception 17
Reset the DAB tuner 17
Remove invalid stations 17
Check the current version of DAB
rmware 17
7 Play from a storage device 18
Control play 18
Switch tracks 19
8 Play from an iPod/iPhone 19
Compatible iPod/iPhone models 19
Connect your iPod/iPhone 19
Control play 20
Charge your iPod/iPhone 20
9 Use Bluetooth devices 21
Connect a device 21
Play audio from a Bluetooth device 22
Make a call 22
10 Listen to an external player 23
11 Adjust sound 23
12 Additional information 24
Reset the system 24
Replace the fuse 24
Upgrade the rmware 24
13 Product information 25
14 Troubleshooting 26
General 26
About the Bluetooth device 27
15 Notice 28
Compliance 28
Care of the environment 28
Trademark notice 28
Copyright 29
Contents

2EN
1 Safety
Read and understand all instructions before you
use this device. If damage is caused by failure to
follow instructions, the warranty does not apply.
• Modication of the product could result
in hazardous radiation of EMC or other
unsafe operation.
• The device is designed for negative ground
(earth) 12 V DC operation only.
• To ensure safe driving, adjust the volume to
a safe and comfortable level.
• Improper fuses can cause damage or
re. When you need to change the fuse,
consult a professional.
• Use only the supplied mounting hardware
for a safe and secure installation.
• To avoid short circuits, do not expose the
device to rain or water.
• The device shall not be exposed to
dripping or splashing.
• Do not place any sources of danger on
the device (e.g. liquid lled objects, lighted
candles).
• Never insert objects into the ventilation
slots or other openings on the device.
• Clean the device with soft, damp cloth.
Never use substances such as alcohol,
chemicals or household cleaners on the
device.

3EN
2 Your car audio
system
Congratulations on your purchase, and
welcome to Philips! To fully benet from the
support that Philips offers, register your product
at www.philips.com/welcome.
Introduction
With this system, you can:
• enjoy audio from a USB storage device,
SD/SDHC card, iPod/iPhone, and external
player,
• charge your iPod/iPhone,
• listen to radio stations, and
• make phone calls via Bluetooth.
You can enrich sound output with these sound
effects:
• Dynamic bass boost (DBB)
• Digital sound control (DSC)
Playable media:
• USB storage device
• Compatibility: USB 2.0, USB 1.1
• Class support: MSC (Mass Storage
Class)
• Maximum capacity: 32 GB
• SD/SDHC card
• Maximum capacity: 32 GB
• Files
• File system: FAT16, FAT32
• Maximum number of folders: 99
• Maximum number of tracks/les: 999
• Maximum level of directory: 8
• .mp3 les
Sampling frequencies: 32 kHz, 44.1 kHz,
48 kHz
Bitrates: 8-320 kbps and variable
bitrates
• .wma les
Versions:V4,V7,V8,V9 (L1 and L2)
Sampling frequencies: 44.1 kHz, 48 kHz
Bitrates: 64-192 kbps and variable
bitrates
• ID3 tag V2.0 or later
• Unsupported les:
AAC, WAV, and PCM les
DRM protected WMA les (.wav, .m4a,
.m4p, .mp4, and .aac)
WMA les in lossless format
What's in the box
Check and identify the contents of the package:
a Main unit (with a sleeve)
b Carrying case (with front panel included)
c Trim plate
d Disassembly tool X 2
e ISO male connector X 2
f User manual
abc
fed

4EN
Overview of the system
a
• Unlock the front panel.
b
• For .wma and .mp3 tracks on a storage
device, press to select the previous
folder.
• Press and hold to access the system
menu.
• In DAB mode, press to access the
DAB menu.
• Press to select a tuner band.
ab cd e
tsrq ponm lk jihfg
uv
c
• Return to the previous menu.
• For iPod/iPhone, press repeatedly to
select a control mode: control play on
the iPod/iPhone or on this product.
• During a call, press and hold to transfer
the phone call to mobile phone.
d LCD screen
e
• Connect to a USB storage device.
• Connect to a compatible iPod/iPhone.

5EN
f AUDIO-IN
• Connect to the audio output socket
(usually the headphone socket) of an
external device.
g
• Start, pause, or resume the play of
tracks.
• In FM/MW radio mode, press to select
the preset radio station of No. 6.
• In radio mode, press and hold to store
the current radio station at channel
No. 6.
h
• In FM/MW radio mode, press to select
the preset radio station of No. 5.
• In FM/MW radio mode, press and hold
to store the current radio station at
channel No. 5.
i
• In FM/MW radio mode, press to select
the preset radio station of No. 4.
• In FM/MW radio mode, press and hold
to store the current radio station at
channel No. 4.
• For .wma and .mp3 tracks, press
repeatedly to select a play mode:
play all tracks randomly ([SHUFFLE
ALL]), play tracks in the current
folder or album randomly ([SHUFFLE
FLD]/[SHUFFLE ALB]), or play all
tracks in sequence ([SHUFFLE OFF]).
j
• In FM/MW radio mode, press to select
the preset radio station of No. 3.
• In FM/MW radio mode, press and hold
to store the current radio station at
channel No. 3.
• For .wma and .mp3 tracks, press
repeatedly to select a repeat mode.
k
• In FM/MW radio mode, press to select
the preset radio station of No. 2.
• In FM/MW radio mode, press and hold
to store the current radio station at
channel No. 2.
• For .wma and .mp3 tracks on a storage
device, press to access the folder list.
l
• In FM/MW radio mode, press to select
the preset radio station of No. 1.
• In FM/MW radio mode, press and hold
to store the current radio station at
channel No. 1.
• For .wma and .mp3 tracks on a storage
device, press to access the track list.
• Press to access the music menu of an
iPod/iPhone.
m /DISP
• Press repeatedly to display available
information about the current track.
• Press repeatedly to display available
information that is transmitted by a
DAB/RDS radio station.
• Press and hold to display the set clock.
n AS/SOURCE
• Press repeatedly to select a source.
• In FM/MW radio mode, press and hold
to activate the automatic search of
radio stations.
o
• Press repeatedly to select a preset
sound equalizer.
• Press and hold to activate the setup of
bass, treble, balance, and fader.
p
• Press to turn on the product.
• Press and hold to turn off the product.
• Press to mute or restore sound.
• Press to conrm an option.
• Rotate to switch between menu
options.
• Rotate to adjust the volume level.

6EN
q
• For .wma and .mp3 tracks on a storage
device, press to select the next folder.
• In DAB mode, press and hold to access
the list of stored stations.
• In a mode other than DAB mode,
press and hold to activate the selection
of listening zones.
• Press to select a tuner band.
r /
• Tune to a radio station.
• Press to skip to the previous/next
track.
• Press and hold to rewind a track or
search fast forward.
s
• Press to enable or disable the MAX
Sound feature.
• Press and hold to enable or disable
the DBB (dynamic bass boost) sound
effect.
t
• Press to answer or redial a call.
• Press to hang up a call.
• Press and hold to reject an incoming
call.
u
• Insert an SD/SDHC card.
v RESET
• Press to reset the product.
3 Install the car
audio system
Caution
•Use the controls only as stated in this user manual.
Always follow the instructions in this chapter in
sequence.
These instructions are for a typical installation.
However, if your car has different requirements,
make the adjustment accordingly. If you have
any question regarding installation kits, consult
your local retailer.
Note
•This system is designed for negative ground (earth) 12V
DC operation only.
•Always install this system in the car dashboard. Other
locations can be dangerous as the rear of the system
heats up during use.
•To avoid short-circuit: before you connect, make sure
that the ignition is off.
•Make sure that you connect the yellow and red power
supply leads after all other leads are connected.
•Make sure that all loose leads are insulated with
electrical tape.
•Make sure that the leads do not get caught under
screws iron parts that will move (e.g. seat rail).
•Make sure that all ground (earth) leads are run to a
common ground (earth) point.
•Use only the supplied mounting hardware for a safe
and secure installation.
•Improper fuses can cause damage or re. When you
need to change the fuse, consult a professional.
•When you connect other devices to this system, make
sure that the rating of the car circuit is higher than the
total fuse value of all the connected devices.
•Never connect speaker wires to the metal body or
chassis of the car.
•Never connect speaker wires with stripes to one
another.

7EN
Connect wires
Note
•Make sure that all loose leads are insulated with
electrical tape.
•Consult a professional to connect wires as instructed
below.
1 Check the car's wiring carefully and
connect them to the the supplied ISO
male connectors.
ISO male connectors Connect to
1 Green strip,
black-edged green
strip
Rear left speaker
2 White strip,
black-edged white
strip
Front left speaker
3 Gray strip, black-edged
gray strip
Front right speaker
4 Purple strip, black-
edged purple strip
Rear right speaker
e Red strip Ignition key +12V
DC when ON/
ACC
f Blue strip Motor/electric
antenna relay
control lead
g White-edged blue
strip
Amplier relay
control lead
h Black strip Ground
i Yellow strip To the +12V car
battery which is
energized at all
times
2 Connect other wires if necessary.
Sockets or
connectors on rear
panel
External sockets or
connectors
1 USB connector A USB storage device
or iPod/iPhone
2 Purple strip OE remote control
module
3 FM/MW radio
antenna socket
FM/MW radio
antenna
4 DAB radio receiver
socket
DAB radio receiver
5REAR R Rear right speaker
6REAR L Rear left speaker
7 For ISO male
connectors
ISO male connectors
g
b
a
fedc

8EN
Tip
•The pin arrangement for the ISO connectors depends
on the type of your vehicle.To avoid damage to the
unit, connect properly.
Connect the DAB radio receiver
Note
•The DAB radio receiver and DAB radio antenna are
not bundled. Consult your local retailer for purchase.
•Make sure that no lead other than the DAB radio
antenna contacts the antenna connector of the DAB
radio receiver.
•Risk of injury: Never install the DAB radio receiver and
its accessories on the airbag cover.
•Risk of overheating: Do not x the DAB radio receiver
to the metal surface of the main unit.
•Risk of electromagnetic interference: Do not install the
DAB radio receiver over any sensors or vents.
•Risk of short circuit, malfunction, or damage to this
product: Do not alter the cable of DAB radio receiver
or dismantle the receiver box.
•Risk of damage to the DAB radio receiver: Never pull
its cable when you remove it.
1 Connect the DAB radio receiver to the
main unit.
2 Connect a DAB radio antenna to the DAB
radio receiver.
3 Secure the DAB radio receiver to your car.
Mount into the dashboard
• If the car does not have an on-board drive
or navigation computer, disconnect the
negative terminal of the car battery.
• If the car battery is not disconnected, to
avoid short-circuit, make sure that the bare
wires do not touch each other.
1 Make sure that the car dashboard opening
is within these measurements:
183 mm
53mm
5mm

9EN
2 Remove the mounting sleeve with the
supplied disassembly tools.
3 Install the sleeve into the dashboard and
bend the tabs outward to x the sleeve.
183 mm
53.5 mm
4 Slide the unit into the sleeve until you hear
a "click".
5 Attach the trim plate.
6 Reconnect the negative terminal of the car
battery.

10 EN
Attach the front panel
1 Insert the notch on the front panel to the
chassis on the main unit.
2 Press the left end of the front panel
inwards until it is securely locked with a
"click".
Detach the front panel
Note
•Before you insert an SD/SDHC card or reset the
system, detach the front panel.
•Before you detach the front panel, make sure that the
system is turned off.
1 Press to release the front panel.
2 Pull the front panel outwards to remove it.

11EN
4 Get started
For the rst time use
1 Press to turn on the system.
» [PHILIPS] is displayed and then
[SELECT OPERATING REGION]
(select a radio region) scrolls.
2 When one of the following options is
displayed, rotate to select a radio
region that matches your location.
• [AREA EUROPE] (Western Europe)
• [AREA ASIA] (Asia Pacic)
• [AREA M--EAST] (Middle East)
• [AREA AUST] (Australia)
• [AREA RUSSIA] (Russia)
• [AREA USA] (United States)
• [AREA LATIN] (Latin America)
• [AREA JAPAN] (Japan)
3 Press to conrm.
» If a DAB radio receiver is correctly
connected, the system switches the
source to [DAB/DAB+] automatically.
» If no DAB radio receiver is connected,
the system switches the source to
[RADIO] automatically.
• To turn off the system, press and hold
until the screen backlight is off.
Set the time format
1 Press and hold to access the system
menu.
2 Press / repeatedly until [CLOCK
24H] or [CLOCK 12H] is displayed.
3 Rotate to select [CLOCK 24H] or
[CLOCK 12H].
• [CLOCK 24H]: 24-hour time format
• [CLOCK 12H]: 12-hour time format
Set the clock
1 Press and hold to access the system
menu.
2 Press / repeatedly until [CLOCK] is
displayed with time digits blinking.
3 Rotate anti-clockwise to set the hour.
4 Rotate clockwise to set the minute.
Tip
•The system can automatically synchronize its clock
with an RDS station that transmits time signals (see
‘Synchronize the system clock’ on page 15).
Display the clock
Press and hold /DISP until [CLOCK] and
the set clock are displayed.
• To exit the clock display, press any button
or rotate .
Select a source
Press AS/SOURCE repeatedly to select a
source.
• [DAB/DAB+]:When a DAB radio receiver
is connected, you can select this source to
listen to DAB radio stations.
• [RADIO]: Listen to FM/MW radio.
• [FRONT USB]/[REAR USB]:When a USB
storage device or compatible iPod/iPhone
is connected and recognized, you can
select this source to play audio les that
are stored on it.
• [SD/SDHC]:When an SD/SDHC card is
inserted and recognized, you can select this
source to play audio les that are stored
on it.
• [AUX IN]: Listen to the audio that is
transferred through the AUDIO-IN socket.
• [BT AUDIO]:When a Bluetooth player
is connected, you can select this source
to transfer audio from the player to this
system via Bluetooth.

12 EN
Select a listening zone
1 Press and hold until one of the
following options is displayed.
• [ALL]: For all passengers
• [FRONT-L]: For the front-left seat only
• [FRONT-R]: For the front-right seat
only
• [FRONT]: For front passengers only
2 Press / repeatedly to select a
listening zone.
Mute the button beep
The beep sound of buttons is enabled by
default.
1 Press and hold to access the system
menu.
2 Press / repeatedly until [BEEP ON]
or [BEEP OFF] is displayed.
• [BEEP ON]: Enable the beep sound of
buttons.
• [BEEP OFF]: Mute the beep sound of
buttons.
3 Rotate to change the setting.
5 Listen to FM/
MW radio
stations
Switch to FM/MW radio
mode
1 Press AS/SOURCE repeatedly to switch
the source to [RADIO].
2 Press / repeatedly to select a band:
FM1, FM2, FM3, MW1, or MW2.
Select a tuner region
You can select a radio region that matches your
location.
1 Press and hold to access the system
menu.
2 Press / repeatedly until one of the
following options is displayed.
• [AREA EUROPE] (Western Europe)
• [AREA ASIA] (Asia Pacic)
• [AREA M--EAST] (Middle East)
• [AREA AUST] (Australia)
• [AREA RUSSIA] (Russia)
• [AREA USA] (United States)
• [AREA LATIN] (Latin America)
• [AREA JAPAN] (Japan)
3 Rotate to select a region.

13EN
Select a tuner sensitivity
To search for radio stations with strong signals
only or more radio stations, you can change the
tuner sensitivity.
1 Press and hold to access the system
menu.
2 Press / repeatedly until [LOCAL
ON] or [LOCAL OFF] is displayed.
3 Rotate to select a setting.
• [LOCAL ON]: Search for radio
stations with strong signals only.
• [LOCAL OFF]: Search for radio
stations with strong and weak signals.
Search for a radio station
Search for a radio station
automatically
Press or to search for the previous or
next radio station with strong signals.
Search for a radio station manually
1 Press and hold or until the
frequency digits start change.
2 Press or repeatedly until the
target frequency is displayed.
Store radio stations in
memory
Note
•You can store a maximum of six stations in each band.
Store radio stations automatically
1 Press or repeatedly to select a band.
2 Press and hold AS/SOURCE until
[STORE---] is displayed.
» After the search is complete, the
rst stored radio station is broadcast
automatically.
• To select a stored radio station, press
, , , , , or .
Store radio stations manually
1 Press or repeatedly to select a
tuner band.
2 Tune to the radio station that you want to
store.
3 Press and hold , , , ,
, or to store the radio station at the
selected channel.
• To select a stored radio station, press
, , , , , or .
Play with RDS
The RDS (Radio Data System) function
operates only in areas with FM stations
broadcasting RDS signals. If you tune to an RDS
station, the station name is displayed.
Enable the RDS function
Note
•The RDS function is enabled by default.
•Only when the RDS function is enabled, RDS related
settings can be accessed.
1 Press and hold to access the system
menu.
2 Press / repeatedly until [RDS ON]
or [RDS OFF] is displayed.

14 EN
3 Rotate to select [RDS ON].
» The RDS function is enabled.
• To disable the RDS function, rotate
to select [RDS OFF].
Select a program type
Before tuning to RDS stations, you can select
a program type to search for programs of the
selected category only.
1 Press and hold to access the system
menu.
2 Press / repeatedly until [PTY] is
displayed.
3 Press to access the list of program
types.
4 Rotate to select a program type, and
then press to conrm.
Item Program
type
Description
1 NEWS News services
2 AFFAIRS Politics and current
affairs
3 INFO Special information
programs
4 SPORT Sports
5 EDUCATE Education and advanced
training
6 DRAMA Radio plays and
literature
7CULTURE Culture, religion and
society
8SCIENCE Science
9VARIED Entertainment programs
10 POP M Pop music
11 ROCK M Rock music
12 EASY M Light music
13 LIGHT M Light classical music
14 CLASSICS Classical music
15 OTHER M Special music programs
16 WEATHER Weather
17 FINANCE Finance
18 CHILDREN Children’s programs
19 SOCIAL Social Affairs
20 RELIGION Religion
21 PHONE IN Phone In
22 TRAVEL Tr avel
23 LEISURE Leisure
24 JAZZ Jazz Music
25 COUNTRY Country Music
26 NATION M National Music
27 OLDIES Oldies Music
28 FOLK M Folk Music
29 DOCUMENT Documentary
30 TEST Alarm Test
31 ALARM Alarm
Use alternate frequencies
If the signal of an RDS station is poor, enable
the AF (Alternate Frequency) function to search
for another station that broadcasts the same
program.
1 Press and hold to access the system
menu.
2 Press / repeatedly until [AF ON] or
[AF OFF] is displayed.
3 Rotate to select a setting.
• [AF ON]: Enable the AF function.
• [AF OFF]: Disable the AF function.
Set the region for AF tuning
You can set the region for AF tuning.
1 Press and hold to access the system
menu.
2 Press / repeatedly until [REGION
ON] or [REGION OFF] is displayed.
3 Rotate to select a setting.
• [REGION ON]: Only RDS stations
in current region can be tuned to
automatically.
• [REGION OFF]: All RDS stations can
be tuned to automatically.

15EN
Receive trafc announcement
If you want to receive trafc announcement,
enable the TA (Trafc Announcement) function.
1 Press and hold to access the system
menu.
2 Press / repeatedly until [TA ON] or
[TA OFF] is displayed.
3 Rotate to select a setting.
• [TA ON]: When a trafc
announcement is on air, the system
automatically switches to the tuner
mode and begins to broadcast the
trafc announcement. When the trafc
announcement is over, the system
returns to the previous mode.
• [TA OFF]: Trafc announcement does
not cut in.
Tip
•When a trafc announcement cuts in, you can press
to switch the system to the previous mode.
Synchronize the system clock
You can synchronize the system clock with an
RDS station that transmits time signals.
1 Press and hold to access the system
menu.
2 Press / repeatedly until [CT ON]
or [CT OFF] is displayed.
3 Rotate to select a setting.
• [CT ON]: Synchronize the
system clock with the RDS station
automatically.
• [CT OFF]:The automatic clock
synchronization with RDS station is
disabled.
Tip
•The accuracy of time depends on the RDS station that
transmits time signals.
6 Listen to DAB
radio stations
Note
•Make sure that the DAB radio receiver is securely
connected.
•For optimal reception, securely connect a DAB radio
antenna to the DAB radio receiver and extend it.
•Check with local retailer or go to www.WorldDAB.org
for applicable DAB radio frequencies in your area.
Switch to DAB mode
1 Press AS/SOURCE repeatedly to switch
the source to [DAB/DAB+].
2 Press / repeatedly to select a band:
DAB1, DAB2, or DAB3.
Scan for on-air stations
Note
•The operation does not replace the stations that are
programmed in each band.
1 Press and hold to access the system
menu.
» [DAB SCAN] is displayed.
2 Press .
» [SCANNING] is displayed.
» The product starts scanning for on-air
DAB radio stations.
» The detected stations are saved in the
ash memory.

16 EN
Tune to a detected station
1 Press to exit the system menu.
2 Press again to access the list of detected
stations.
» is displayed.
3 Press / repeatedly or rotate
until the name of the target station is
displayed.
4 Press to start listening.
Program radio stations
You can assign a sequence number to a
detected station. Afterwards, you can quickly
tune to it by pressing the corresponding
numeric button on the main unit.
Note
•Before the programming, make sure that the scanning
is complete.
•You can store a maximum of six stations in each band.
Program stations automatically
1 Press and hold to access the system
menu.
» [DAB SCAN] is displayed.
2 Press / repeatedly until [DAB
STORE] is displayed.
3 Press .
» [STORING] is displayed.
» The product starts programming DAB
radio stations automatically.
» Earlier programmed stations are
replaced with the latest ones.
» After the programming is complete,
the rst programmed station is
broadcast.
• To tune to a programmed radio
station, press its corresponding
numeric button , , ,
, , or .
Program stations manually
1 Tune to the target detected station (see
‘Tune to a detected station’ on page 16).
2 Press / repeatedly to select a band.
3 Press and hold a numeric button ,
, , , , or to assign
a sequence number to the station.
» [SAVED] is displayed.
» The station is programmed with the
sequence number.
4 Repeat the steps above to program more
stations.
• To tune to a programmed radio
station, press its corresponding
numeric button , , ,
, , or .
Display DAB information
The name of current DAB station is displayed.
You can also view the other information.
To cycle through available information, press
DISP repeatedly.
• Dynamic label segment (DLS)
• Signal strength
• Program type (PTY)
• Ensemble name
• Frequency
• Signal error rate
• Bitrate codec
• Time
• Date

17EN
Set up for weak reception
When the current reception gets poor, the
product can automatically switch the source or
mute the speakers according to your setup.
1 Press and hold to access the system
menu.
» [DAB SCAN] is displayed.
2 Press / repeatedly until [DAB
WEAK] scrolls.
3 Rotate to select an option, and then
press to conrm.
• [WEAK MUTE]: Mute the speakers
• [WEAK TO FM]: Switch the source
to an FM radio station with strong
reception that broadcasts the same
program
Use the DRC (Dynamic
Range Control)
DRC adds or removes a degree of
compensation for the differences in the dynamic
range between radio stations.
1 Press and hold to access the system menu.
» [DAB SCAN] is displayed.
2 Press / repeatedly until one of the
following options is displayed.
• [DRC OFF]: No compensation applied.
• [DRC LOW]: Medium compensation
applied.
• [DRC HIGH]: Maximum
compensation applied.
3 Rotate to select an option.
Disable the DAB reception
1 Press and hold to access the system
menu.
» [DAB SCAN] is displayed.
2 Press / repeatedly until
[ANTENNA OFF] or [ANTENNA 12V]
is displayed.
3 Rotate to select an option, and then
press to conrm.
• [ANTENNA OFF]: Disable the DAB
reception.
• [ANTENNA 12V]: Enable the DAB
reception.
Reset the DAB tuner
1 Press and hold to access the system
menu.
» [DAB SCAN] is displayed.
2 Press / repeatedly until
[DAB RESET] is displayed.
• To clear the list of detected and
programmed stations, press to
conrm.
• To exit the system menu, press .
Remove invalid stations
1 Press and hold to access the system
menu.
» [DAB SCAN] is displayed.
2 Press / repeatedly until [PRUNE] is
displayed.
• To remove invalid stations from the list
of scanned stations, press .
• To exit the system menu, press .
Check the current version of
DAB rmware
1 Press and hold to access the system
menu.
» [DAB SCAN] is displayed.
2 Press / repeatedly until
[SW VERSION] is displayed, and then
press .
» The current version of DAB rmware
is displayed.

18 EN
7 Play from a
storage device
This system can play .mp3 and .wma les that
are copied onto a compatible storage device.
Note
•Philips does not guarantee compatibility with all storage
devices.
•NTFS (New Technology File System) le system is not
supported.
1 Connect a compatible USB storage device
or SD/SDHC card.
• For an SD/SDHC card, detach the
front panel rst, insert the card into
the card slot, and then attach the front
panel.
2 Press AS/SOURCE repeatedly to switch
the source.
• [FRONT USB]: For a USB storage
device that is connected to the USB
socket on the front panel
• [REAR USB]: For a USB storage
device that is connected to the USB
connector on the rear panel
• [SD/SDHC]: For an SD/SDHC card
that is inserted into the slot
3 If the play does not start, press .
Control play
Button Function
/ Press repeatedly to select a
folder.
Pause or resume play.
/ Press to play the previous or
next track.
/ Press and hold to rewind a track
or search forward fast.
/DISP Press repeatedly to display
available information about the
current track.
Press repeatedly to select a
repeat mode:
• [REPEAT ONE]: repeat the
current track,
• [REPEAT FLD]: repeat all
tracks in the current folder, or
• [REPEAT ALL]: repeat all
tracks in the storage device.
Press repeatedly to select a play
mode:
• [SHUFFLE ALL]: play all tracks
randomly,
• [SHUFFLE FLD]: play tracks in
the current folder randomly, or
• [SHUFFLE OFF]: play all
tracks in the storage device in
sequence.

19EN
Switch tracks
During play, you can switch tracks or folders
quickly.
Switch tracks directly
1 Press to access the track list.
» The le name of current track scrolls.
2 Rotate to toggle through tracks.
3 Press to play the selected track.
Switch folders for a track
1 Press to access the folder list.
» The name of current folder scrolls.
2 Rotate to toggle through folders.
3 Press to select the folder.
» The system starts playing the rst track
under the folder.
8 Play from an
iPod/iPhone
Note
•During play, no audio signals are transferred through
the headphone socket of your iPod/iPhone.
Compatible iPod/iPhone
models
This car audio system supports the following
iPod and iPhone models.
• iPhone 4S, iPhone 4, iPhone 3GS, and
iPhone 3G
• iPod touch (2nd, 3rd, and 4th generations)
• iPod classic
• iPod nano (3rd, 4th, 5th, and 6th
generations)
Connect your iPod/iPhone
1 Connect an Apple 30-pin USB cable
between
• the USB socket on the front panel or
the USB connector on the rear panel,
and
• your iPod/iPhone.
