Philips SE735 User manual

3%?)&5?%.BOOK0AGE&RIDAY$ECEMBER0-
8VHUPDQXDO
%.

ΣΕ435_ΙΦΥ_ΕΝ.βοοκ Παγε 3 Φριδαψ, ∆εχεµβερ 16, 2005 1:15 ΠΜ

3
EN
4 Important Information
4 For your safety
4 Installation requirements
4 Need Help?
5 What’s in the box?
6YourSE735
6 Overview of the handset
9 Overview of the base station
10 Main features of your SE735
12 Connect
13 Install
17 USB Connection
21 Call
26 Phonebook
31 Call log
33 SMS
41 Clock & Alarm
43 Personal Settings
49 Advanced Settings
55 Network Services
58 Games
59 Telephone Answering Machine (TAM)
66 Troubleshooting
69 Information
70 Index
Contents

4
EN Important Information
For your safety
This equipment is not designed to make emergency calls in the event of a power failure. Alternative
arrangements should be made for access to emergency calls.
To avoid damage or malfunction:
- Do not allow the product to come into contact with liquid.
- Do not open it as you could be exposed to high voltages.
- Never use any battery type other than the one supplied.
- Do not hold the handset too close to your ear when the phone is ringing or when activating the
loudspeaker as it may damage your hearing.
- Do not expose the phone to excessive heat caused by heating equipment or direct sunlight.
- Do not drop your phone or allow objects to fall on your phone.
- Do not use any cleaning agents containing alcohol, ammonia, benzene, or abrasives as these may harm the set.
- Active mobile phones in the vicinity may cause interference.
About operating and storage temperatures
- Operate in a place where temperature is always between 0 and 35º C (32 to 95º F).
- Store in a place where temperature is always between -20 and 45º C (-4 to 113º F).
- Battery life may be shortened in low temperature conditions.
Installation requirements
This product requires an electrical supply of 220-240 volts, alternating monophased power, excluding IT
installations defined in standard EN 60-950. In case of power failure, the communication can be lost.
The electrical network is classified as hazardous according to criteria in the standard EN 60-950. The only way
to power down this product is to unplug the power supply unit from the electrical outlet. Ensure the electrical
outlet is located close to the apparatus and is always easily accessible.
The voltage on the network is classified as TNV-3 (Telecommunication Network Voltages), as defined in the
standard EN 60-950.
Need Help?
For more information on troubleshooting:
Troubleshooting: page 66
Please refer to the following website for more information on Philips web support:
Online Support
www.philips.com/support

5
EN
What’s in the box?
The following accessories are included with your SE735:
Power supply for
base station
Belt clip Battery door
Line cord
User Guide
Warranty card
The line adaptor may not be attached to the line cord. In this case, you have to connect the line adaptor
to the line cord first before plugging the line cord to the line socket.
In multihandset packs, you will find one or more additional handsets, chargers with power supply units
and additional rechargeable batteries.
Handset Base station
Quick Start
Guide
2 AAA
rechargeable
batteries
Installation CD
Headset USB cable

6
EN Your SE735
Overview of the handset
headset
jack
LCD Screen
Left Soft key
Talk key
Keypad lock
key
Up/Down Navigation keys
Earpiece
Right Soft key
Hang-up key
Alphanumeric keypad
Case key / Pause key /
Ringer off key
Intercom key
Loudspeaker
key
Microphone
Event LED
USB socketUSB socket

7
EN
Your SE735
Handset keys
Soft key
Press To
mEnter the main menu from stand-by mode.
Select the function displayed on the handset screen directly above it.
Activate mute function during a call.
Switch on the backlight.
>Go to redial list from stand-by mode.
Select the function displayed on the handset screen directly above it.
Initiate a second call, call transfer or consult the phonebook during a call.
Switch on the backlight.
rAnswer an incoming external or internal call.
Insert R for operator services when on the line.
eHang up a call.
Return to stand-by mode.
Long press in stand-by mode to switch off the handset, short press to switch on the
handset again.
uAccess call log from stand-by mode.
Scroll up a menu list or go to the previous phonebook or call log record.
Increase earpiece volume during a call.
Go to the previous character in editing mode.
dAccess phonebook from stand-by mode.
Scroll down a menu list or go to the next phonebook or call log record.
Decrease earpiece volume during a call.
Go to the next character in editing mode.
cInitiate an internal call.
vAnswer an incoming call in handsfree mode.
Activate and deactivate the loudspeaker* during a call.
#Dial # in stand-by mode.
Long press to mute the ringer in stand-by mode.
Long press to insert a pause in dialling mode.
Long press to switch between upper and lower case in editing mode.
*Dial * in stand-by mode.
Long press to activate and deactivate keypad lock.
BACK Short press from menu browsing to return to the previous menu.
*WARNING Handsfree activation can suddenly increase the volume in the earpiece to a very high
level. Make sure the handset is not too close to your ear.
(Right soft key)
(Left soft key)

8
EN Your SE735
Display icons & symbols
In stand-by mode, several icons & symbols may be displayed on the handset.
When there are new events, such as new missed calls, new SMS, voicemail or answering machine messages
received, the following icons, together with the number of occurrences are displayed in the middle of the
handset screen.
The handset is registered and within range of the base station. It blinks when the handset is
out of range or is searching for a base.
Battery symbol indicating 3 different battery levels.
The ringer volume is set to zero.
The keypad is locked.
There is an external incoming call, an external call is connected or an external call is held.
There is an internal incoming call, an internal call is connected or an internal call is held.
The loudspeaker is ON.
Alarm clock is activated.
SMS reception is activated. It blinks when the memory for SMS is full.
Telephone answering machine (TAM) is activated. It blinks when the memory for answer-
ing machine messages is full.
Do not Disturb mode is activated.
There are new SMS messages received. The number of new SMS messages received is
also displayed on the left of the icon.
There are new missed calls. The number of new missed calls is also displayed on the left of
the icon.
There are new voicemail messages received. The number of new voicemail messages
received is also displayed on the left of the icon.
There are new answering machine messages received. The number of new messages
received is also displayed on the left of the icon.
If you have not subscribed to Caller Line Identification service, there will not be any alerts for the
new events except for new messages recorded on the answering machine. Hence, no missed call,
SMS, or voicemail event icons will appear in the middle of the handset screen.

9
EN
Your SE735
Overview of the base station
Base station keys
cPage handset.
Long press to start registration procedure.
oShort press to turn the answering machine On/Off.
vIncrease speaker volume during message playback.
Reduce speaker volume during message playback.
xDelete current message during message playback.
Long press to delete all messages when TAM is in stand-by mode
(unread messages will not be deleted).
pPlay phone messages (the first recorded will be played first).
Stop message playback.
lGo to previous message if pressed within 1 second of current
message playback.
Replay current message if pressed after 1 second of current
message playback.
rSkip to the next message during message playback.
Paging key
Volume keys
Time
Message number
Delete key
Next message key
SIM card tray
Answer Machine
On/Off key
Previous message/
Replay message key
Play/Stop key

10
EN Your SE735
Main features of your SE735
The following is an overview of the menu options that are available in your SE735. For detailed explanation of
the menu options, please refer to the corresponding sections in this User Guide.
LCD Message counter Displays current time when the answering machine is switched off
or in stand-by mode.
Displays date & time of recording and message number during
playback.
Blinking: Indicates number of new messages.
Steady: Indicates number of old messages.
2 bars flashing: Indicates that there is no more memory left.
Indicates the volume level (L0 - L9) when vis pressed.
Indicates the current message number during playback.
Menu To Page
SMS Setup, write/read SMS, etc. 33
PHONEBOOK Add, edit, manage phonebook entries and copy phonebook
entries from SIM card.
26
CLOCK &
ALARM
Set date and time, alarm, alarm tone and Do not Disturb
mode.
41
PERSONAL SET Set Handset tone, Wallpaper, View Foto Pic, Contrast, Handset
name, Auto Pick-up/Hang-up, Languages, Babysit mode,
Backlight time and Theme Colour.
43
ADVANCED
SET
Set Recall time, Dial mode, Call barring, Baby call mode,
Register/Unregister handset, Select Base, Change PIN, Reset
phone, Auto prefix, Conference mode and Demo mode.
49
NET. SERVICE Set Call forwarding, Voice mail, Call back and Caller ID. 55
GAMES Play games 58
ANSWER
MACHINE
Setup, play, delete phone messages, record memo, etc. 59

11
EN
Your SE735
Menu navigation
The basic steps of navigating through the menus and options are as follows:
Task Action Illustration
Enter main menu/menu options Choose MENU by pressing the key
directly below it (left soft key m)
• Go to a specific menu/option
• Confirm your selection
1. Press :key to scroll to your
desired menu/option
2. Choose SELECT by pressing the
key directly below it (left soft
key m)
In this example, the alarm is On
Once.
• To change your selection.
• To confirm your selection.
• Return to previous menu
level or stand-by screen
1. Press :key to scroll to your
desired option
2. Choose SELECT by pressing the
key directly below it (left soft
key m)
3. Choose BACK by pressing the
key directly below it (right soft
key >)
Philips 1
08-08 18:00
m>
:
MENU REDIAL
m>
:
1
2
Off
On Once
On Daily
SELECT BACK
m>
:
Alarm


1
23

12
EN Connect
The location of your base station can have an effect on the range and performance of your SE735 (see TIP
below).
Connecting the Base Station
1. Place the base station in a central location near the telephone line socket and electricity sockets.
2. Connect the line cord and the power cable to the proper connector at the back of the base station.
3. Connect the other end of the line cord to the telephone line socket and the other end of the power cable
to the electricity socket.
Connect the
power supply A
Connect
the line cord to
the line socket B
2.
BA
1.
The line adaptor may not be attached to the line cord. In this case, you have to connect the line
adaptor to the line cord first before plugging the line cord to the line socket.
TIP Avoid placing the base station too close to large metal objects such as filing cabinets, radiators or
electrical appliances. This can impair the range and sound quality. Buildings with thick internal and
external walls may impair transmission of signals to and from the base.
WARNING The base station does not have an ON/OFF switch. Power is applied when the power
adaptor is plugged into the unit and connected to the electricity socket. The only way to power
down the unit is to unplug the power adaptor from the electricity socket. Therefore, ensure that the
electricity socket is easily accessible.
The power adaptor and telephone line cord have to be connected correctly, as incorrect
connection could damage the unit.
Always use the telephone line cord supplied with the unit. Otherwise, you may not get a dial tone.

13
EN
Install
Install battery
Your SE735 is supplied with 2 rechargeable batteries allowing approximately up to 12 hours of talk-time and
up to 168 hours stand-by time. Before using the handset, the batteries have to be installed and fully charged.
1. Slide out the battery cover.
2. Place the batteries as indicated and replace the cover.
Charge battery
1. Place the handset on the charging cradle of the base station. A beep is emitted if the handset is placed
correctly.
2. A charging animation on the handset indicates that the battery is charging.
3. Leave it there until the batteries are fully charged (at least 24 hours).
4. The handset is fully charged when the charging animation stops and is displayed.
Low battery warning
The battery level is shown at the top left of the handset screen. When the battery level becomes low, an
empty battery icon is displayed on the screen.
If the battery level becomes exceedingly low, the phone automatically switches off and any function in progress
will not be saved.
Philips 1
08-08
MENU
18:00
REDIAL
The handset must be charged for at least 24 hours before using it for the first time.

14
EN Install
Out of range warning
The indoor and outdoor range of the phone is up to 50 metres and 300 metres respectively. When the
handset moves beyond operation range, the antenna icon will blink.
Attach/Remove belt clip
A belt clip allows you to carry your handset on your belt.
1. To attach the belt clip to your handset, fit the tabs on the belt clip into the slots at the back of the handset
and push into place.
2. To remove the belt clip, simply pull the clip away from the handset.
Configure your SE735
Before you use your SE735, you need to configure it according to the country of use. After charging it for a few
minutes, the word WELCOME appears in various languages. Follow these steps to configure your phone:
1. Scroll :to the word WELCOME in your preferred language and press mSELECT.
2. Scroll :to your country.
3. Press mSELECT to confirm your selection.
4. Scroll :to your operator (if necessary).
5. Press mSELECT again to confirm your selection.
6. The default line settings and menu language for the selected country will be automatically configured.
Set date and time
1. Press mMENU.
2. Scroll :to Clock & Alarm and press mSELECT.
You cannot make outgoing calls or receive incoming calls without first defining your country
selection.
Depending on your country, the WELCOME screen may not appear. In this case, you are not
required to select your country/operator/language settings.

15
EN
Install
3. Press mSELECT to enter Set Date/Time.
4. Enter current time (HH:MM) and current date (DD/MM/YY) and press mOK.
Now, you are ready to use your phone.
Basic operations of your SE735
Make a call
Enter the phone number (maximum 20 digits) and press r to dial the number.
For details, please refer to "Make a call" on page 21.
Answer or end a call
Press r key to answer a call.
Press e key to end a call.
For details, please refer to "Answer a call" on page 21 and "End a call" on page 22.
Switch the handset on/off
Press and holdekey for 3 seconds to switch off the handset in stand-by mode.
Short press e key to switch on the handset again.j
Keypad lock/unlock
Press and hold *key for 2 seconds to lock or unlock the keypad in stand-by mode.
Paging
The paging feature enables you to locate a missing handset if the handset is in range and contains charged
batteries.
Short press ckey on the base. The handset starts to ring.
Once retrieved, press any key on the handset to end the paging.
Stand-by mode
If the handset is not used for 30 seconds in settings mode, review mode, edit mode, etc. it will automatically
return to stand-by mode. It will also return to stand-by mode automatically when the handset is placed back on
the base station.
WARNING If your phone is connected to an ISDN line through an adaptor, the date & time may
be updated after each call. The availability of date & time update is dependent on your network
provider. Please check the date & time settings in your ISDN system or contact your network
provider.

16
EN Install
Screen and keypad backlight
The backlight remains on for 20 seconds after each activation such as an incoming call, key presses, lifting up
the handset off the base station, etc. The colour of the LCD and keypad backlight is WHITE.
For setup details, please refer to "Backlight time" on page 48.
Event LED
The event LED on your handset blinks when there is a new message recorded on your telephone answering
machine. If you have subscribed to Caller Line Identification, the event LED also blinks when there is a new call,
a new SMS or a new voice mail message.
Default settings
Ringer Volume Medium
Earpiece Volume Volume 3
Speaker Volume Volume 3
Key Beep On
Wallpaper
Contrast Level 2
Auto Pick-up Off
Auto Hang-up On
Babysit mode Off
Alarm clock Off
Barring mode Off
SMS reception On
Master PIN 0000
Answering Machine
Answer Mode Answ. & Record
Ring delay 5
Outgoing Messages Predefined for Answ. & Record mode
Base station screening On with default speakerphone level
Handset screening Off
Base speaker Level 5
Remote access Deactivated

17
EN
USB Connection
USB connection
Your SE735 is able to download melodies (maximum 20 KB, in MIDI format), wallpapers (128 x 160 pixels), as
well as portrait pictures for fotocall (96 x 64 pixels) from your PC to your handset via USB connection. There
are also a number of ring melodies, wallpaper and fotocall pictures pre-installed in your handset and the
installation CD.
Before you can download PC files to your handset, you need to install the Download Software.
Install USB download software
1. Insert the CD supplied with your SE735 into the CD ROM drive of your PC.
2. Follow the onscreen instructions to complete the installation of the PC Download Software and USB
driver.
3. During installation, the software will prompt you with dialogue boxes to accept or cancel the operations.
You should choose to accept each operation and continue with your installation.
4. You may need to restart your PC after software installation.
System requirements:
CPU Pentium II 350MHz equivalent or better
Operating System Microsoft Windows 2000, Microsoft Windows XP or Windows ME
RAM 64MB or more
Minimum Hard Disk Space 150MB
Connection USB Type 1.1 or higher
CD ROM 8x CD-ROM drive or faster
Screen 800 x 600 pixels or higher
Display 16 bit high colour or higher
If the installation program does not start automatically, browse the CD contents via Windows
Explorer and run the program by double clicking setup.exe.

18
EN USB Connection
Connect the handset to your PC
To connect the handset to your PC, plug one end of the USB jack into the USB socket at the bottom of the
handset, and then plug the other end of the USB jack to the USB port of your PC. When the USB cable is
connected, the screen will display Waiting for about 12 seconds. After that, it will display USB Connected.
Download melodies
There are 16 ring melodies pre-installed on your SE735. You can add an additional ring melody (maximum 20
KB) or replace it by downloading a new melody from your PC to your handset via USB connection
.
1. Launch Download Software by selecting Start > Programs > Download Software on your PC.
2. Click the Ringtone icon on the left of the windows to view the MIDI files that are available for use as ring
melodies on your handset.USB Connection.
USB connection can only be established when the handset is in stand-by mode and the backlight
is switched on. If the handset is in menu mode or goes into screensaver mode, press ekey or
any key to return to stand-by mode before you connect the handset to the PC.
Plug the USB jack into the
USB socket at the bottom of
the handset.
USB socket
When the handset is in USB Download mode, all handset keys will be locked until the USB cable
is removed from the handset.
When there is an incoming call during USB download, data transfer will stop. The handset will
only emit a beep tone and display External Call on the screen. The caller identity of your
correspondent will not be displayed. To answer the call, press r.

19
EN
USB Connection
3. Select the MIDI file you wish to download from the selection window and click the PLAY button to listen
to the MIDI file to make sure it is the correct ring melody you wish to download onto your handset.
4. Make sure that the handset is connected to the PC and click the Download button.
A progress bar is displayed to indicate the download progress.
5. When the download is completed, safely remove your handset from your PC.
Download wallpapers
There are 6 wallpapers pre-installed on your SE735. The 3rd wallpaper can be overwritten by downloading a
new wallpaper from your PC to your handset via USB connection. The 4th wallpaper is a blank wallpaper.
1. Launch Download Software by selecting Start > Programs > Download Software on your PC.
2. Click the Wallpaper icon on the left of the windows to view the picture files (BMP, JPG and GIF) that are
available for use as wallpaper on your handset.
3. Select the wallpaper you wish to download from the selection window.
Play button
Ringtone
icon Selection
window
Download
button
Progress
bar
window
Wallpaper
icon
Selection
window
Download
button
Progress
bar
Preview
window

20
EN USB Connection
4. The image will appear in the Image window and the actual size will be displayed.
You may resize the image in the Image window and select which part of the image to be used as
wallpaper. You can also preview the image in the Preview window to make sure this is how you would
like your wallpaper to appear on your handset.
5. Make sure that the handset is connected to the PC and click the Download button.
A progress bar is displayed to indicate the download progress.
6. When the download is completed, safely remove your handset from your PC.
Download photo IDs
There are 20 fotocall pictures pre-installed on your SE735. You can download and overwrite any existing
fotocall picture via USB connection.
1. Launch Download Software by selecting Start > Programs > Download Software on your PC.
2. Click the Fotocall icon on the left of the windows to view the photos that are available for use as fotocall
pictures on your handset.
3. Select the photo you wish to download from the selection window.
4. The photo will appear in the Image window and the actual size will be displayed.
You may resize the photo in the Image window and select which part of the photo to be used as fotocall
picture. You can also preview the photo in the Preview window to make sure this is how you would like
your fotocall picture to appear on your handset.
5. In the Picture selection box, select the position number (1 to 20) of the fotocall picture you wish to
overwrite on your handset. If you select 3, then the third fotocall picture on your handset will be replaced
with the new picture.
6. Make sure that the handset is connected to the PC and click the Download button.
A progress bar is displayed to indicate the download progress.
7. When the download is completed, remove your handset safely from your PC.
window
Fotocall
icon
Selection
window
Download
button
Progress
bar
Preview
window
selection box
