Philips AJ4200/05 User manual

Clock Radio
Register your product and get support at
www.philips.com/welcome
AJ4200
EN User manual

m
g
f
h
i
j
k
l
o
n
c
d
e
b
a
1
23

EN1 Important
Safety
aRead these instructions.
bKeep these instructions.
cHeed all warnings.
dFollow all instructions.
eDo not use this apparatus near water.
fClean only with dry cloth.
gDo not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
hDo not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
iProtect the power cord from being walked on or pinched,
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
jOnly use attachments/accessories specified by the
manufacturer.
kUse only with the cart, stand, tripod, bracket, or
table specified by the manufacturer or sold with the
apparatus.When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury
from tip-over.

lUnplug this apparatus during lightning storms or when
unused for long periods of time.
mRefer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
nApparatus shall not be exposed to dripping or splashing.
oDo not place any sources of danger on the apparatus (e.g.
liquid filled objects, lighted candles).
pThis product may contain lead and mercury. Disposal of
these materials may be regulated due to environmental
considerations. For disposal or recycling information, please
contact your local authorities or the Electronic Industries
Alliance: www.eiae.org.
qWhere the plug is used as the disconnect device, the
disconnect device shall remain readily operable.
C Warning
Never remove the casing of this apparatus.•
Never lubricate any part of this apparatus.•
Never place this apparatus on other electrical equipment.•
Keep this apparatus away from direct sunlight, naked flames or•
heat.
Ensure that you always have easy access to the power cord, plug
•
or adaptor to disconnect the apparatus from the power.

Notice
This product complies with the radio interference
requirements of the European Community.
This product complies with the requirements of the following
directives and guidelines: 2004/108/EC + 2006/95/EC
Any changes or modifications made to this device that are not
expressly approved by Philips Consumer Lifestyle may void the
user’s authority to operate the equipment.
Recycling
Your product is designed and manufactured with high
quality materials and components, which can be recycled
and reused.
When you see the crossed-out wheel bin symbol attached
to a product, it means the product is covered by the
European Directive 2002/96/EC:
Never dispose of your product with other household
waste. Please inform yourself about the local rules on the separate
collection of electrical and electronic products.The correct
disposal of your old product helps prevent potentially negative
consequences on the environment and human health.
Environmental information
All unnecessary packaging has been omitted.We have tried to
make the packaging easy to separate into three materials: cardboard
(box), polystyrene foam (buffer) and polyethylene (bags, protective
foam sheet.)
Your system consists of materials which can be recycled and reused
if disassembled by a specialized company. Please observe the local
regulations regarding the disposal of packaging materials, exhausted
batteries and old equipment.

D Note
The type plate is located on the bottom of the apparatus.•

2 Your clock radio
Congratulations on your purchase, and welcome to Philips! To fully
benefit from the support that Philips offers, register your product at
www.philips.com/welcome.
Introduction
With this clock radio with mobile phone charger, you can:
enjoy the FM radio
•
know the time•
wake up to favourite radio tone•
set two alarms to ring at different time•
charge a mobile phone of major brands.•
What’s in the box
Check and identify the contents of your package:
Main unit
•
AC power adapter•
User manual•
Quick start guide•
Compatibility sheet•
Overview of the main unit (See 1)
aSLEEP/ALARM RESET
Set sleep timer.•
Reset alarm setting.•
bWEEKDAY/WEEKEND ALARM
Switch between weekday alarm and weekend alarm.
•

cPRESET
Select a preset radio station.
•
dALARM 1
Set the alarm timer.
•
View the alarm time.•
Turn on/off the alarm.•
eREPEAT ALARM/BRIGHTNESS CONTROL
Repeat the alarm.
•
Adjust the display brightness.•
fSET TIME/AUTO SCAN
Set the time and date.•
Scan radio stations.•
gPRESS TO OPEN
Press to open the compartment.•
hRADIO ON/OFF
Switch radio on or off.
•
iTUNING+/-
Tune to a radio station.
•
Adjust time and date.•
Select time format.•
jALARM 2 BUZZ/RADIO
Select alarm tone for alarm 2.•
kALARM 1 BUZZ/RADIO
Select alarm tone for alarm 1.•

lVOL
Adjust volume.
•
mALARM 2
Set the alarm timer.
•
View the alarm time.•
Turn on/off the alarm.•
nUSB charging socket
oDC IN jack

3 Get started
E Tip
Use of controls or adjustments or performance of procedures•
other than herein may result in hazardous radiation exposure or
other unsafe operation.
Always follow the instructions in this chapter in sequence.
If you contact Philips, you will be asked for the model and serial
number of this apparatus.The model number and serial number are
on the bottom of the apparatus.Write the numbers here:
Model No. __________________________
Serial No. ___________________________
Connect power (See 2)
E Caution
Risk of product damage! Ensure that the power supply•
voltage corresponds to the voltage printed on the
back or the underside of the apparatus.
Risk of electric shock! When you unplug the AC•
power cord, always pull the plug from the socket.
Never pull the cord.
Before connecting the AC power cord, ensure you•
have completed all other connections.
1Connect the power adapter to
the• DC IN jack on the rear of the main unit
the power socket.•

Adjust the volume level
1Tur n VOL to increase/decrease the volume level.
Adjust display brightness
1Press REPEAT ALARM/BRIGHTNESS CONTROL repeatedly to
select different brightness levels of the display.
Set time and date
1Press RADIO ON/OFF repeatedly to turn off radio.
2Press and hold SET TIME/AUTO SCAN for 2 seconds.
Year digits begin to blink.»
3Press TUNING+/- to set year.
4Press SET TIME/AUTO SCAN to confirm.
5Repeat steps 3-4 to set the month.
6Repeat steps 3-4 to set the date.
7Repeat steps 3-4 to set the hour
8Repeat steps 3-4 to set minute.
Time format begins to blink.»
9Repeat steps 3-4 to select 12 hour or 24 hour format.

4 Listen to radio
Tune to a radio station
1Press RADIO ON/OFF repeatedly to turn on radio.
2Press TUNING+/- repeatedly to tune to a radio station.
Program radio stations automatically
D Note
You can program a maximum of 20 preset radio stations•
1Press RADIO ON/OFF repeatedly to turn on radio.
2Press and hold SET TIME/AUTO SCAN for 2 seconds.
All available stations are programmed in the order of»
waveband reception strength.
The first programed radio station broadcasts automatically.»
To interrupt scan, press»SET TIME/AUTO SCAN.
Program radio stations manully
D Note
You can program a maximum of 20 preset radio stations.•
1Press RADIO ON/OFF repeatedly to turn on radio.
2Press TUNING+/- repeatedly to tune to a radio station.
3Press and hold PRESET for 2 seconds.
“CH“ begins to blink.»
4Press PRESET repeatedly to select a preset number.
5Press and hold PRESET for 2 seconds to confirm.
6Repeat steps 2-5 to program more stations.

E Tip
To overwrite a programmed station, program another station in•
its place.
Select a preset radio station
1Press RADIO ON/OFF repeatedly to turn on radio.
2Press PRESET to select a radio station.

5 Set the alarm timer
You can set two separate alarms. For the alarm tone, you can select
the FM radio, or the buzzer.
1Before you start, ensure that the time is set correctly.
2Press and hold ALARM 1/ALARM 2 for two seconds.
»AL1 or AL2 is displayed and the hour digits and days begin
to blink.
3Switch ALARM 1 BUZZ/RADIO or ALARM 2 BUZZ/RADIO
to buzz or radio to select alarm sound for alarm 1 and 2
respectively.
4Press TUNING+/- repeatedly to set the hour.
»appears and AL1 or AL2 begins to blink.
5Press ALARM 1/ALARM 2 to confirm.
The minute digits begin to blink.»
6Press TUNING+/- to set the minute.
7Press ALARM 1/ALARM 2 to confirm.
The weekdays begin to blink.»
8Press WEEKDAY/WEEKEND ALARM to select whether to ring
alarm on weekdays or at weekend.
9Press ALARM 1/ALARM 2 to confirm.
»AL1 or AL2 is displayed.
The apparatus turns on automatically at the set time and»
rings with radio or buzz.
Turn on/off the alarm timer
D Note
Ensure that you already set the alarms successfully.•
1Press ALARM 1 or ALARM 2 to turn on or off the alarm timer.

If the alarm timer is turned on,»AL1 or AL2 appears.
If the alarm timer is turned off,»disappears.
Repeat alarm
1When the alarm rings, press REPEAT ALARM/BRIGHTNESS
CONTROL.
The alarm repeats ringing minutes later.»
E Tip
You can press• TUNING+/- to adjust interval (5-15 minutes) to
repeat alarm.
Reset alarm
1When the alarm rings, press SLEEP/ALARM RESET.
The alarm stops but the alarm settings remain.»
Stop alarm ring
1When the alarm rings, press the corresponding ALARM 1 or
ALARM 2.
The alarm stops but the alarm settings remain.»
View the alarm settings
1Press ALARM 1 or ALARM 2 to view the alarming setting time.
[»AL1]or [AL2] appears.

6 Other features
Set the sleep timer
You can set the clock radio to turn off automatically after a certain
period of time.
1Press SLEEP/ALARM RESET repeatedly to select time (in
minutes).
The apparatus turns off automatically after the set period of»
time.
To turn off the sleep timer:
1Press SLEEP/ALARM RESET repeatedly until [OFF] (off)
appears or press RADIO ON/OFF.
»is displayed when sleep timer is on and disappears when
it is off.
Charge a mobile phone (See 3)
D Note
The accompanied charging adapters do not support all types of•
mobile phones. Refer to the appended compatibility sheet to see
if your phone is supported.
1Press PRESS TO OPEN to open the compartment.
2Select a charger adapter that matches your mobile phone.
3Take out the cable with a connector.
4Connect the charger adapter to .
the connector or the USB charging cable (not supplied)•
your mobile phone.•
After charging finishes,
1Disconnect the device from the charge adapter.

2Disconnect the charger adapter and save it in the compartment.
(See 3)

7 Product information
D Tip
Product information is subject to change without prior notice.•
Specifications
Tuner (FM)
Tuning Range 87.5 - 108MHz
Tuning grid 50KHz
Sensitivity
- Mono, 26dB S/N Ratio <22 dBf
Search Selectivity >28dBf
Total Harmonic Distortion <3%
Signal to Noise Ratio >50dB

General information
Power adapter Model: AS150-065-AF Philips
Input: 100-240V~50/60 Hz, 0.7A
Output: 6.5V DC, 2.3A
Operation Power Consumption 20W
Standby Power Consumption 0.5W
Dimensions
- Main Unit (W x H x D) 180 x 50 x 133 mm
Weight
- With Packing
- Main Unit
0.725 kg
0.435 kg

8 Troubleshooting
E Caution
Never remove the casing of this apparatus.•
To keep the warranty valid, never try to repair the system yourself.
If you encounter problems when using this apparatus, check the
following points before requesting service. If the problem remains
unsolved, go to the Philips web site (www.philips.com/support).
When you contact Philips, ensure that your apparatus is nearby and
the model number and serial number are available.
No power
Ensure that the AC power plug of the apparatus is connected•
properly.
Ensure that there is power at the AC outlet.•
No sound
Adjust the volume.•
No response from the apparatus
Disconnect and reconnect the AC power plug, then turn on the•
apparatus again.
Use a ball pen to press the reset button on the rear of the•
apparatus to restore factory settings.This operation resets all
settings except the clock.
Poor radio reception
Increase the distance between the apparatus and your TV or•
VCR.
Fully extend the antenna.•
Connect an outdoor antenna instead.•
Timer does not work
Set the clock correctly.•
Switch on the timer.•
Clock/timer setting erased
