Philips AJL700/37B User manual

DVD Kitchen Radio AJL700
with LCD-TV
Quick Start Guide
Preparation
Connect it
Mount it
Use it
This Guide shows you:
•basic installation setup
•how to install your unit
•how to play a DVD
•how you can watch TV on
the unit
For detailed operation of all the features, please also read the
User manual.
4
3
2
1
What’s in the box
DISC
AV
PROGERASE/WRITE
SHUFFLE
CLOCKSETCLOCKSET PICTURE
VOL
Kitchen DVD/TV/CD AJL 700
Clock Radio
Quick Start Guide
Preparation
Connect it
Mount it
Use it
This guide shows you:
•basic installation setup
•how to install your unit
•how to play a DVD
•how you can watchTV on
the unit
For detailed operation of all the features, please also read the
User guide.
4
3
2
1
FRONT
Use1/4"
drill
Recommendeddepth of cabinet
atthe rear to allow for connections
DC
VIDEO
IN
AUDIO
L
IN
R
TV
ANT
AM
FM
Mount it
Aska friend to help you mount the unit as it is quite heavy.
A
•Cutthe template to fit inside the cabinet.
•Alignthe template border marked "FRONT"
alongthe front edge of your cabinet.
•Useadhesive tape to fix the template.
•Drill1/4 inch holes (size X.X mm diameter,X
inch),asmar ked Xon the template.
•Removethe template when you finishdrilling.
B
Usingthe spacers
Onthe spacers, there are 4 pairs of notch length
options.Dependingon the thickness of you cabi-
netbottom (with/ without an overhang),these
notchlengths correspond to the 4 notch height in
thespace holders, and allow youto adjust to the
bestheight to help you mount the unit.
•Measurethe height of the cabinet bottom
and/overhang.
•Turn the spacercounterclockwise to determine
whichof the 4 heights is most suitable:High ••
Low
•Insertthe spacers accordingly.
C
•Manuallyfasten the 4screws down into the
spacerholder holes to mount your set.If the
overhangis more than 1 1/4 inch,use longer
screws(not included).
Tip
–Use a nail to start each drill hole.
–Hold your drill firmly at 90o with the cabinet bottom and drill holes at
lowspeed.
–Clear wood shavings.
Tip
Topr event damage to your set, do not use an electric drill
tosecure screws when mounting!
–Hold the unit horizontally when installing it,since the CD tray may
openif the unit is shaken.
–Use the cable manager to manage excess powercord length.
C
Template
A
H
L
Spacer
L(Low) L••H(4 heights)
Arrow
B
AJL 700
DVD Kitchen Radio
with LCD-TV
THANKYOU FOR CHOOSING PHILIPS!
NEED HELP FAST?
Readyour Quick-Start guide and/or owner'smanual first for quick tips
thatmake using your Philips product more enjoyable. If you have read
yourinstructions and still need assistance,
youmay access our online help at www.p4c.philips.com
orcall 1-888-PHILIPS(744-5477) while with your
product.
User manual
Manuel d'utilisation
Manual del usuario
DVD Kitchen Radio
with LCD-TV
Remote control
with 2xAA batteries
4 x spacers
Quick start guide Mounting
template
User manual
8 x screws 12V DC adapter
with bracket
AM antenna
FM antenna
What else you'll need
These tools (not included) will help you mount the unit as described in part 3 Mount it, and on the
template.
Preparation
For best performance, install the unit as far as
possible from sources of noise and interference
(e.g. fridges, microwaves, fluorescent lamps)
aFind a mounting location near a wall outlet.
bUse the mounting template to test the design and
thickness your kitchen cabinet bottom.
cDecide whether you want to connect the unit with
other audio/ visual equipment. ( See Bbelow)
Connect it
A
Connect the following supplied
accessories to the respective jacks on
the rear of the unit :
•12V DC power adapter
•For radio reception,connect the
AM and FM antennas.
B
Other connections (cables not included)
•For TV reception on the unit, plug
the supplied L-shaped adapter into
TV ANT as shown.Then connect a
TV antenna/CATV cable (not sup-
plied)..
•For use with VCR or other audio/video appliances,
connect the composite cable and match the colors
of the cinches (AUDIO IN L/R,VIDEO IN) on
the unit.
2
Electric drill Ta pe measure Scissors
Sellotape Screwdriver Safety goggles
324xxx LC/JW-0449
W
1
a
Template
b
To reduce the risk of fire,
do not place any heating or
cooking apparatus beneath
this unit.
2
FMANT AMANT
VIDEO INAUDIO INRL
TVANT DC-12V
FM ANT AM ANT
VIDEO INAUDIO INRL
TV ANT DC-12V
VIDEO (Yellow)
AUDIO-L (White)
AUDIO-R (Red)
FM AM DC
L-shape adapter
antenna
AJL 700 QUG 3/14/2005 19:43 Page 1

Mount it
Ask a friend to help out. An extra hand to hold the unit makes mounting easier and
quicker.
A
•Cut the template to fit inside the cabinet.
•Align the template border marked "FRONT" along the
front edge of your cabinet.
•Use adhesive tape to fix the template.
•Drill 1/4 inch holes, as marked Xon the template.
•Remove the template when you finish drilling.
B
Using the spacers
On the spacers, there are 4 pairs of notch length
options. Depending on the thickness of you cabinet bot-
tom (with/ without an overhang), these notch lengths
correspond to the 4 notch height in the space holders,
and allow you to adjust to the best height to help you
mount the unit.
•Measure the height of the cabinet bottom and/over-
hang.
•Tu rn the spacer counterclockwise to determine
which of the 4 heights is most suitable: Low • •
High. Align to the arrow indication.
•Insert the spacers accordingly.
3
Template
A
Tip
– Clean the bottom of the cabinet surface and also empty your cabinet before mounting.
– Place the unit in a clean, safe place when drilling to avoid wood shavings dropping into the
ventilation slots.
– Use a nail to start each drill hole.
– Drill from the bottom upwards if you do not have enough room inside the cabinet.
– Hold your drill firmly at 90owith the cabinet bottom and drill holes at low speed.
– Clear wood shavings.
C
•Manually fasten the 4long screws down into the spacer holder holes to mount your set. Start
screwing at opposite corners of the unit for better support.
D
Using the adapter bracket
Find a suitable place to mount the adaptor bracket.
1Use 2 small screws (supplied) to mount the bracket.
2Insert the adapter into the bracket as shown.
3Use the adapter bracket to wrap and secure the
power cord so that excess cord does not hang
down.
C
Tip
To prevent damage to your
set, do not use an electric
drill to secure screws when
mounting!
– If the overhang is more than 1 1/4 inch, use
longer screws (not included).
Use it
For full details, please read and follow the instructions inside the User manual.
A
Power supply
•Connect the power plug to the wall outlet.
•Press POWER (or STANDBY.ON) to switch on.
B
Using the TV screen
1Press PUSH at the bottom the set to release the TV panel. .
2Pull down the panel (maximum 115º).
3Tu rn around the panel to find the screen.
4Adjust the screen to a suitable angle (maximum 270º).
C
How to play a DVD /CD
•Select DVD source.
•Insert a DVD/CD.
•Press PLAY/PAUSE to start disc playback.
4
POWER
DISC
AV
PROGERASE/WRITE
SHUFFLE
CLOCKSETCLOCKSET PICTURE
Insert a12cm disc
D
How to watch TV on the unit
1Press TV once or more to select TV or CATV mode .
2In CATV, press ENTER on the remote control selects
HRC, IRC, STD or AUTO mode.
3The first time you use the TV, press and hold AUTO
PROG /RADIO PROG on the set until the channel
number starts running.
•Available channels are programmed.
4Use the Numeric Keypad (0-9) on the remote con-
trol to select the channel number directly.
DISC
AV
PROGERASE/WRITE
SHUFFLE
E
Improve radio reception
Position the antenna as far as possible from a TV,VCR or radiation source.
FM:
Keep the FM antenna as horizontal as possible . Fix the antenna’s end to
the wall.
AM:
Position vertically. If necessary, use 2 small screws (supplied) to fix the
antenna to a flat, hard and stable place.
AM
Tip
– Swivel with care to avoid breakage. Screen rotates a maximum
2700only.
H
L
Spacer
L (Low)
L••H (4 heights)
Arrow
B
PUSH
115
270 maximum
maximum
4
1
23
AJL 700 QUG 3/14/2005 19:43 Page 2
