Philips SPF3402S/G7 User manual

Philips Digital PhotoFrame
EN-i
Copyright
Copyright
No part of this publication may be reproduced, transmitted,
transcribed, stored in a retrieval system or translated into
any language or computer language, in any form or by any
means, electronic, mechanical, magnetic, optical, chemical,
manual or otherwise, without the prior written permission of
the company.
Disclaimer
The company makes no representations or warranties,
either expressed or implied, with respect to the contents
hereof and specifically disclaims any warranties,
merchantability or fitness for any particular purpose. Further,
the company reserves the right to revise this publication and
to make changes from time to time in the contents hereof
without obligation to notify any person of such revision or
changes.
Safety Instructions
Before operating the PhotoFrame, carefully read and follow the
instructions below. Retain this User Manual for future reference.
• Read the safety and operating instructions carefully before
using the product. All warnings on the product and in the
operating instructions should be observed.
• Do not place this product under direct sunlight or near heat
sources, such as in a closed car under sunlight or near a stove.
The outer casing of this product may become deformed and
the sophisticated sensors inside may become damaged due
to excessive heat.
• Do not use this product near water, in the rain or allow any
liquid to get inside this product. Water and moisture may cause
short-circuit to the electronic components and lead to
malfunctions.

EN-ii
Philips Digital PhotoFrame
Safety Instructions
• Do not use this product near strong electromagnetic sources,
such as a microwave oven. The electromagnetic interference
may cause this product to malfunction.
• Do not drop or apply shock/vibration to this product. Strong
impacts may damage the components inside.
• Do not insert objects other than compatible memory cards
into the memory card slots of this product. The metal
contacts inside the slot can easily become damaged by
foreign objects.
• Do not use an unknown power adapter other than the one
supplied with the PhotoFrame. Connecting this product to
an unknown power adapter is very dangerous and may lead
to fire or explosion.
• Do not cut, bend, modify, place heavy objects, or step on
the power adapter cord. Otherwise the external insulation
may be damaged and result in short-circuit or fire.
• If there are strange odors or heat emitting from this product
or any signs of malfunction, disconnect the PhotoFrame from
the power immediately and contact your dealer for inspection
or service.
• Use a smooth, soft cloth to clean the surface of the screen.
Do not use liquid cleaners or glass cleaners.
• Do not attempt to disassemble or modify this product. There
are no user serviceable parts inside this product, and any
unauthorized modifications will void the warranty.
• Although the LCD panel is made with high-precision
technology and has effective pixels of 99.99% or more, black
dots or bright points of light (red, blue or green) may appear
constantly on the LCD panel. This is a structural property of
the LCD panel and is not a malfunction.

Philips Digital PhotoFrame
EN-iii
Key features……………………………………………………..
What’s in the box……………………………………………….
Overview………………………………………………………….
Right view………………………………………………….....
Rear view ………………………………………………….....
Operating the PhotoFrame…………………………………...
Using the control buttons……………………………………
Using the remote control (8" and 10" models only)
……….…….….................................
Getting started ………………………………………………….
Step 1:Using the adjustable back stand …………………..
Step 2: Connecting to power………………………………..
Step 3: First usage…………………………………………...
Step 4:Basic setup…………………………………………....
Selecting a language……………………………………...
Setting the date and time…………………………………
Step 5: Copying photos to internal memory………………
Step 6: Connecting the PhotoFrame to a computer …….
Step 7: Replacing the paper mat………………..…………
Using the main menu ………………… …………………......
Managing photos …………………… ……………………......
Manually copying photos to the internal memory ………..
Tagging photos to an album…………………………………
Removing photos from an album…………………………
Managing photos by using the TIMELINE album………
Creating a new album ………………………………………
Modifying an album…………………………………………
Deleting an album……………………………………………
Using other options in the PHOTO ALBUMS menu……...
Deleting photos……………………………… ……………...
Table of contents
Table of contents
1
2
3
3
4
5
6
10
10
11
11
11
11
12
13
14
16
17
17
19
21
22
23
24
24
24
24
7
9

Philips Digital PhotoFrame
EN-iv
Table of contents
Rotating photos………………………………… …………….....
Applying photo effects……………………………………….......
Viewing photos…………………………………………...............
Running a slideshow by using the TIMELINE album ….........
Using Smart Energy Saver™……………………………….......
Using CLOCK (EZ Access button)………………………….....
Selecting a clock skin…………………………………………....
Switching between Clock view and Slideshow view……… ...
Using SCRAPBOOK……………………………………………...
Using SETTINGS………………………………………………....
Date and Time page………………………………………….....
General Settings page……………………………………….....
Information page………………………………………………...
Frequently asked questions …………………………………...
Regulation and compliance………………………………….....
Recycling………………………………………………...................
Appendix ………………………………………………………......
Specifications………………………………………………….....
25
25
25
27
28
29
29
30
30
31
32
33
34
34
35
37
36
37

EN-1
Philips Digital PhotoFrame
Dear Customer:
Thank you for bringing our Philips Digital PhotoFrame into
your home. Now you will be able to view your growing digital
picture library in stunning clarity and share great memories
with friends and family.
To get the most out of your new Philips product, please
read through this entire User Manual before use.
Key features
Key features
This PhotoFrame is equipped with the following features:
&lear and bright display.
Enables you to display photos that are stored on the
internal memory, a memory card or a USB flash drive.
Allows you to select a preferred power-saving option for
the PhotoFrame using the Smart Energy Saver™ feature.
Allows you to use albums to manage and sort your
photos easily.
Allows you to display photos in slideshow using various
kinds of templates available in S&5APB22K.
Multi-language 2n-Screen Display 2SDmenus.
&lock and &alendar functions.

Carefully open the packing box and ensure that
you have the following items.
1. Digital PhotoFrame x 1
2. AC power adapter x 1
3. Remote control x 1
(8" and 10" models only)
4. Quick Start Guide x 1
5. User Manual x 1
6. Registration Card x 1
7. Warranty Card x 1
8. Hook and loop tape for remote control x 1
• Actual product appearance may vary from the illustrations
shown in this User Manual.
• Available accessories may vary depending on the area where
you purchased the PhotoFrame.
• The remote control is not included in the 7" models.
Philips Digital PhotoFrame
What’s in the box
What’s in the box
EN-2
User Manual Registration Card Warranty Card
1
5 6 7 8
23 4
Hook and loop tape

Description
No.
Adjustable back stand
Power button
Press the Power button to turn on/off the PhotoFrame.
USB port
Allows for a USB flash drive.
Play back photos stored on the inserted drive
Copy photos from the inserted drive to the PhotoFrame.
Mini USB port
Allows you to connect the PhotoFrame to a computer to
manage the files on the internal memory of the PhotoFrame.
Memory card slot
Allows for an SD™/SDHC™, MultiMediaCard™ (MMC),
Memory Stick™ (MS), Memory Stick PRO™ (MS PRO),
Memory Stick Duo™ (MS Duo) memory card.
Play back photos stored on the inserted card
Copy photos from the inserted card to the PhotoFrame.
1
2
3
4
5
6
7
Power jack
Connect one end of the AC power adapter into the power
jack and the other end into a power outlet.
Recommended Remote control storage
Use the hook and loop tape included to store your remote control
1
2
3
4
5
6
7
Philips Digital PhotoFrame
Overview
Right view
Right View EN-3

1
1
2
2
3
3
4
4
5
5
66
7
8
9
Description
No.
MENU button
See "Using the control buttons" on page 6 for details.
EZ Access button
See "Using the control buttons" on page 6 for details.
ESC button (ESCAPE button)
See "Using the control buttons" on page 6 for details.
Scroll wheel/OK button
See "Using the control buttons" on page 6 for details.
Kensington® security slot
You can attach an anti-theft Kensington® lock and cable
to this slot to help prevent possible theft.
Philips Digital PhotoFrame
Rear view
Rear View EN-4

EN-5
6
7
8
9
EZ Lock System
You can use the EZ Lock Screws to lock or unlock the
wooden frame.
Description
No.
Wall mount hole (for landscape wall mounting)
Allows you to hang the PhotoFrame horizontally on a wall.
Wall mount hole (for portrait wall mounting)
Allows you to hang the PhotoFrame vertically on a wall.
Operating the PhotoFrame
Operating the PhotoFrame
Philips Digital PhotoFrame
You can use the control buttons on the back or the supplied
remote control to operate the photo frame
• In this user manual, instructions or examples provided are based
upon operation with the remote control. To know how to use the
control buttons, refer to "Using the control buttons" on page 6 for
details.
• The remote control is supplied with the 8" and 10" models only.
Recommended Remote control storage
Use the hook and loop tape included to store your remote control.

Operating the PhotoFrame
Philips Digital PhotoFrame
EN-6
Using the control buttons
1
2
3
4
Description
No. Icon
ESC
MENU
ESC button (ESCAPE button)
Cancels current operation and/or returns to
the previous page
Scroll wheel/ OK button
• Press this button to enter or confirm your
operation/selection.
• Scroll this button to the left to select the
previous item.
• Scroll this button to the right to select the
next item.
MENU button
Displays the pop-up menu.
EZ Access button
Switches between Clock view and Slideshow
view
OK

EN-7 Operating the PhotoFrame
Philips Digital PhotoFrame
Using the remote control (8" and 10"
models only)
Place the hook and loop tape on back of the PhotoFrame for
remote storage
hook and loop tape1
hook and loop tape2

• Please remove the plastic strip under the battery before using the
remote control for the first time.
• The remote control is supplied with the 8" and 10" models only.
• Use only the specified battery type.
• The batteries are highly flammable, keep away from excessive heat
or moisture.
ON/OFF
EZ Access button
ESC (Escape)
RIGHT
MENU
LEFT
“OK”

EN-9 Getting started
Philips Digital PhotoFrame
Getting started
Step 1: Using the adjustable back stand
1. Gently pop out the back stand as shown below.
2. To place the PhotoFrame horizontally or vertically, you can rotate
the back stand by aligning the triangle mark with the rounded
points (1 or 2).

3. Pull out the back stand and adjust accordingly to the preferred
viewing angle.
• It is recommended to place the PhotoFrame horizontally, because
this direction provides the best viewing and operating experience.
• By using the wall mount holes, you can hang the PhotoFrame
horizontally or vertically on the wall.
Step 2: Connecting to power
1. Place the PhotoFrame on a flat surface.
2. Connect the power adapter as below (1), and press the Power
button to turn on the PhotoFrame (2)
• Power systems and plug types may vary depending on your country/region.
• To turn off the PhotoFrame, press the Power button.
Getting started
Philips Digital PhotoFrame
EN-10

EN-11
Step 3: First usage
To help you get the most out of your PhotoFrame, we installed a
video tutorial that automatically starts playing when you first turn
on your unit. To cancel the looping video and start playing your
own photos, press any of the buttons on the back. Follow the
five-step process to familiarize yourself with how the control
buttons work. This simple process is automatically disabled
after the first use. You can turn on the tutorial by going into
SETTINGS.
Step 4: Basic setup
Select a language and set the date and time during the first use
of the PhotoFrame.
Selecting a language
Getting started
Philips Digital PhotoFrame
1. In the main menu, press or to select SETTINGS ,
and then press "OK"
2. Press The General Settings page appears.
3. Press "OK", press to go to Language, and then press "OK" again.
4. Press or to select a language you wish to use, and
then press "OK"
5. Press "ESC" to exit
Setting the date and time
1. In the main menu, press or to select SETTINGS ,
and then press "OK". The Date and Time page appears.

To copy all photos contained on the inserted memory card (or
USB flash drive), select the check mark and press “OK”.
To view photos without copying them to the PhotoFrame,
select the cross mark and press “OK”. The PhotoFrame
will start playing back the photos automatically from the
inserted memory card or USB flash drive.
Getting started
Philips Digital PhotoFrame
EN-12
When inserting a memory card or a USB flash drive, you will be
asked to copy all photos to the internal memory.
If “Smart Copy” is set to “Resize” under “General Settings”, photos will be
resized to the screen resolution when copied to the internal memory to
optimize the storage capacity. Please keep a copy of the original photos on
your memory card or USB flash drive.
2. Press“OK” to highlight the Year field, press or to select
a year, and then press“OK” to confirm the setting
3. Press to move to move to the Month field, press“OK” to
highlight the Month field, press or to select a month,
and the press "OK" to confirm the setting.
4. Repeat Step 3 for the remaining fields, including Date, Hour,
Minute, Mode, On Screen Clock, Current Time Zone and
Second Time Zone.
5. Press “ESC” to exit
"Smart Copy" is designed

EN-13Getting started
Philips Digital PhotoFrame
• Do not remove the memory card/USB flash drive before the copy
process is completed.
• If the files you wish to copy from the memory card/USB flash drive
already exists on the internal memory of the PhotoFrame, the files
will be overwritten when you select to proceed.
Step 6: Connecting the PhotoFrame
to a computer
You can connect the PhotoFrame to a computer using a mini USB
cable (to be purchased separately) to easily manage the files on
the internal memory of the PhotoFrame.
1. Start the computer and turn on the PhotoFrame.
2. Connect the smaller end of the USB cable to the mini USB port
of the PhotoFrame.
3. Connect the other end of the USB cable to a USB port on the
computer, making sure the connectors are fully inserted.
4. Once connected, the PhotoFrame will enter PC transfer mode
automatically.
5. When the computer has detected the PhotoFrame, the
PhotoFrame will appear in “My Computer” as “removable disk”.
6. Now you can freely transfer the files on the PhotoFrame as you
would on other disk drive.
Compatible memory card formats :
1Maximum capacity
SD/SDHC
MultiMediaCard(MMC)
Memory Stick(MS)
Mcmory Stick PRO(MS PRO)
Memory Stick Duo(MS Duo)
USB flash drive
32GB
1GB
4GB
2GB
2GB
16GB
Memory card format
• Maximum capacity specification listed above are subject to change
without prior notice

Getting started
Philips Digital PhotoFrame
EN-14
• You can copy photos from the computer to the PhotoFrame, and
vice versa.
• The files on the memory cards and USB flash drive cannot be
viewed/edited via USB connection.
Step 7: Replacing the paper mat
Your PhotoFrame may come with one or more bonus paper mats
depending on your purchased model. You can replace the existing
paper mat with the one supplied (if available). Follow the
instructions below to replace the supplied paper mat.
1. On a flat table, place the PhotoFrame facing down on top of a
soft towel. Be careful not to scratch the unit.
2. Twist the EZ Lock Screws on the back of the PhotoFrame to
the “UNLOCK” position, then carefully lift up the core unit from
the wood frame.

EN-15Getting started
Philips Digital PhotoFrame
3. Remove the existing paper mat.
4. Install the supplied bonus paper mat.
5. Install the PhotoFrame to the wooden frame, and secure the
PhotoFrame by tightening the EZ Lock Screws to the “LOCK”
position.
