Philips SELECON PLPROFILE4 MKII Instruction Manual

Philips Selecon Offices
The material in this manual is for information purposes only and is subject to change without notice. Philips
Selecon assumes no responsibility for any errors or omissions which may appear in this manual. For comments and
suggestions regarding corrections and/or updates to this manual, please visit the Philips Selecon web site at
www.seleconlight.com or contact your nearest Philips Selecon office.
El contenido de este manual es solamente para información y está sujeto a cambios sin previo aviso. Philips
Selecon no asume responsabilidad por errores o omisiones que puedan aparecer. Cualquier comentario, sugerencia
o corrección con respecto a este manual, favor de dirijirlo a la oficina de Philips Selecon más cercana.
Der Inhalt dieses Handbuches ist nur für Informationszwecke gedacht, Aenderungen sind vorbehalten. Philips
Selecon uebernimmt keine Verantwortung für Fehler oder Irrtuemer, die in diesem Handbuch auftreten. Für
Bemerkungen und Verbesserungsvorschlaege oder Vorschlaege in Bezug auf Korrekturen und/oder
Aktualisierungen in diesem Handbuch, moechten wir Sie bitten, Kontakt mit der naechsten Philips Selecon-
Niederlassung aufzunehmen.
Le matériel décrit dans ce manuel est pour information seulement et est sujet à changements sans préavis. La
compagnie Philips Selecon n'assume aucune responsibilité sur toute erreur ou ommission inscrite dans ce manuel.
Pour tous commentaires ou suggestions concernant des corrections et/ou les mises à jour de ce manuel, veuillez s'il
vous plait contacter le bureau de Philips Selecon le plus proche.
Note: Information contained in this document may not be duplicated in full or in part by any person without prior written
approval of Philips Selecon. Its sole purpose is to provide the user with conceptual information on the equipment mentioned. The
use of this document for all other purposes is specifically prohibited.
Document Number: 02.9694.4010 0
Version as of: 07 December 2012
PLPROFILE4 LED Luminaire Installation & User’s Manual
©2012 Philips Group. All rights reserved.
Philips Selecon - Dallas
10911 Petal Street
Dallas, TX 75238
Tel: [phone]
Fax: [phone]
Philips Selecon - Auckland
19-21 Kawana Street
Northcote, Auckland 0627
New Zealand
Tel: [phone]
Fax: [phone]
Philips Selecon - New York
267 5th Ave, 4th Floor
New York, NY 10016
Tel: [phone]
Fax: [phone]
Philips Selecon - Europe
Rondweg zuid 85
Winterswijk 7102 JD
The Netherlands
Tel: [phone]
Philips Selecon - Asia Limited
Unit C, 14/F, Roxy Industrial Centre
No. 41-49 Kwai Cheong Road
Kwai Chung, N.T., Hong Kong
Tel: [phone]
Fax: [phone]
Website:
www.seleconlight.com

1
PLPROFILE4 LED Luminaires Installation & User’s Manual
IMPORTANT INFORMATION
Warnings and Notices
Additional Resources for DMX512
For more information on installing DMX512 control systems, the following publication is available for purchase
from the United States Institute for Theatre Technology (USITT), "Recommended Practice for DMX512: A Guide
for Users and Installers, 2nd edition" (ISBN: 9780955703522). USITT Contact Information:
USITT
315 South Crouse Avenue, Suite 200
Syracuse, NY 13210-1844
Phone: [phone] or 1.315.463.6463
www.usitt.org
Philips Selecon Limited Three-Year Warranty
Philips Selecon offers a three-year limited warranty of its luminaires against defects in materials or workmanship
from the date of delivery. A copy of Philips Selecon three-year limited warranty containing specific terms and
conditions can be obtained from the Philips Selecon web site at www.seleconlight.com or by contacting your local
Philips Selecon office.
PLPROFILE4 LED Luminaire’s powerful LED engine offers exceptional performance and life. Under normal
operating conditions, our LED engine has a life expectancy in excess of 50,000 hours, however under worst case
operating conditions with the luminaire set to continuous full output it is possible that a small percentage of LED’s
may require replacement sooner. The Philips Selecon three-year limited warranty includes our guarantee against
premature failure of the LED engine.
When using electrical equipment, basic safety precautions should always be followed including the following:
a. READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
b. Do not use outdoors.
c. Do not mount near gas or electric heaters.
d. Equipment should be mounted in locations and at heights where it will not readily be subjected to
tampering by unauthorized personnel.
e. The use of accessory equipment not recommended by the manufacturer may cause an unsafe
condition.
f. Do not use this equipment for other than intended use.
g. Refer service to qualified personnel.
SAVE THESE INSTRUCTIONS.
WARNING: You must have access to a main circuit breaker or other power disconnect device
before installing any wiring. Be sure that power is disconnected by removing fuses or turning the
main circuit breaker off before installation. Installing the device with power on may expose you to
dangerous voltages and damage the device. A qualified electrician must perform this installation.
WARNING: Refer to National Electrical Code® and local codes for cable specifications. Failure to
use proper cable can result in damage to equipment or danger to personnel.
WARNING: This equipment is intended for installation in accordance with the National Electric
Code® and local regulations. It is also intended for installation in indoor applications only. Before
any electrical work is performed, disconnect power at the circuit breaker or remove the fuse to avoid
shock or damage to the control. It is recommended that a qualified electrician perform this
installation.

Installation & User’s Manual PLPROFILE4 LED Luminaires
2TABLE OF CONTENTS
TABLE OF CONTENTS
Philips Selecon Offices........................................................................................................ Inside Front Cover
IMPORTANT INFORMATION
Warnings and Notices...................................................................................................................................... 1
Additional Resources for DMX512................................................................................................................. 1
Philips Selecon Limited Three-Year Warranty............................................................................................... 1
TABLE OF CONTENTS
PREFACE
About this Manual .................................................................................................................................................. 4
Product Descriptions............................................................................................................................................... 4
PLPROFILE4 LED Luminaire........................................................................................................................ 4
Accessories............................................................................................................................................................. 5
PLPROFILE4 LED Luminaire Clamps........................................................................................................... 5
PLPROFILE4 LED Luminaire Lenses............................................................................................................ 5
PLPROFILE4 LED Luminaire Lens Accessories........................................................................................... 5
PLPROFILE4 LED Luminaire AC Input Power Cables................................................................................. 5
PLPROFILE4 LED Luminaire Wireless DMX512 Receivers........................................................................ 5
PLPROFILE4 LED Luminaire Wireless DMX512 Transmitters ................................................................... 6
PLPROFILE4 LED Luminaire Software Uploader Cable.............................................................................. 6
PLPROFILE4 LED LUMINAIRE OVERVIEW
PLPROFILE4 LED Luminaire Components.......................................................................................................... 7
Luminaire Components................................................................................................................................... 7
LCD Display / Menu....................................................................................................................................... 7
INSTALLATION AND SET UP
Top Box Connections ............................................................................................................................................. 8
Power Requirements............................................................................................................................................... 9
Connecting Power................................................................................................................................................. 10
Connecting to the DMX512 Network................................................................................................................... 10
Mounting .............................................................................................................................................................. 11
Using Supplied C-Clamp............................................................................................................................... 11
Safety Cable Use ........................................................................................................................................... 12
Pan and Tilt Adjustments...................................................................................................................................... 12
Pan Adjustment ............................................................................................................................................. 12
Tilt Adjustment.............................................................................................................................................. 12
FOCUS AND BEAM ADJUSTMENTS
Lens Tube Removal and Installation.................................................................................................................... 13
Zoom and Focus Adjustments (Zoomspot Models) ............................................................................................. 14
Beam Shutter Operation ....................................................................................................................................... 15
Gobo/Iris Access Panel......................................................................................................................................... 15
OPERATION AND PROGRAMMING
LCD Menu Operation........................................................................................................................................... 17
LCD Menu System............................................................................................................................................... 17
Menu Structure.............................................................................................................................................. 19
Security................................................................................................................................................................. 21
Passwords...................................................................................................................................................... 21
Security Levels.............................................................................................................................................. 22
Locking Fixture............................................................................................................................................. 22

3
PLPROFILE4 LED Luminaires Installation & User’s Manual
Presets................................................................................................................................................................... 22
Presets Types................................................................................................................................................. 22
Editing Preset Names.................................................................................................................................... 23
Settings................................................................................................................................................................. 23
DMX CONTROL
16-Bit Mode.......................................................................................................................................................... 25
8-Bit Mode............................................................................................................................................................ 27
DMX 3-Channel (3-Chan) Mode ......................................................................................................................... 29
Lighting Console Settings for Preset White......................................................................................................... 30
PLPROFILE4 LED Luminaire DMX Timing Channel Detail............................................................................. 30
CLEANING AND CARE
Special Cleaning and Care Instructions................................................................................................................ 36
Lens Cleaning....................................................................................................................................................... 36
Front Lens (Exterior)..................................................................................................................................... 36
Front Lens (Interior)...................................................................................................................................... 36
Service and Maintenance...................................................................................................................................... 38
TROUBLESHOOTING
Troubleshooting Guide......................................................................................................................................... 39
TECHNICAL SPECIFICATIONS
PLPROFILE4 LED Luminaire Common Specifications..................................................................................... 40
PLPROFILE4 LED Luminaire Dimensions......................................................................................................... 41

Installation & User’s Manual PLPROFILE4 LED Luminaires
4PREFACE
PREFACE
1. About this Manual
The document provides installation and operation instructions for the following products:
• PLPROFILE4 LED Luminaires (refer to "Product Descriptions" for individual product models).
Please read all instructions before installing or using this product. Retain this manual for future reference. Additional
product information and descriptions may be downloaded at www.seleconlight.com
2. Product Descriptions
This manual covers the following PLPROFILE4 LED Luminaire models:
PLPROFILE4 LED Luminaire
Notes:
1) All PLPROFILE4 LED Luminaires are universal voltage (100 - 240VAC).
2) *User-specified AC input connector at time of ordering (GR - Edison / GP - Grounded Stagepin / GTL -
Twistlock).
3) Product accessories can be found in "Accessories" on page 5.
Part Number Description
PLPF4-03 PLPROFILE4 LED Luminaire Engine Only (without lens tube), Black, with C-Clamp, Top Box, Top Box
Bolt, Safety Cable and PowerCon AC Input Connector
PLPF4-01-14 PLPROFILE4 LED Luminaire LED Engine, Black, with Axial Ellipsoidal 14-degree Fixed Beam Lens
(SPX14LT), C-Clamp, Top Box, Top Box Bolt, Safety Cable and AC Input Cable (PC1XX*)
PLPF4-01-19 PLPROFILE4 LED Luminaire LED Engine, Black, with Axial Ellipsoidal 19-degree Fixed Beam Lens
(SPX19LT), C-Clamp, Top Box, Top Box Bolt, Safety Cable and AC Input Cable (PC1XX*)
PLPF4-01-26 PLPROFILE4 LED Luminaire LED Engine, Black, with Axial Ellipsoidal 26-degree Fixed Beam Lens
(SPX26LT), C-Clamp, Top Box, Top Box Bolt, Safety Cable and AC Input Cable (PC1XX*)
PLPF4-01-36 PLPROFILE4 LED Luminaire LED Engine, Black, with Axial Ellipsoidal 36-degree Fixed Beam Lens
(SPX36LT), C-Clamp, Top Box, Top Box Bolt, Safety Cable and AC Input Cable (PC1XX*)
PLPF4-01-50 PLPROFILE4 LED Luminaire LED Engine, Black, with Axial Ellipsoidal 50-degree Fixed Beam Lens
(SPX50LT), C-Clamp, Top Box, Top Box Bolt, Safety Cable and AC Input Cable (PC1XX*)
PLPF4-03-1535 PLPROFILE4 LED Luminaire LED Engine, Black, with Axial Ellipsoidal 15-degree to 35-degree Zoomspot Lens (SPX1535LT), C-Clamp, Top Box, Top Box Bolt, Safety Cable and AC Input Cable
(PC1XX*)
PLPF4-03-2550 PLPROFILE4 LED Luminaire LED Engine, Black, with Axial Ellipsoidal 25-degree to 50-degree Zoomspot Lens (SPX2550LT), C-Clamp, Top Box, Top Box Bolt, Safety Cable and AC Input Cable
(PC1XX*)

Accessories 5
PLPROFILE4 LED Luminaires Installation & User’s Manual
3. Accessories
Contact your Authorized Philips Selecon Dealer for price and availability of all accessories for PLPROFILE4 LED
Luminaires. Additional information can be found on the Philips Selecon web site at www.seleconlight.com
(information also found on the Philips Strand Lighting web site at www.strandlighting.com).
PLPROFILE4 LED Luminaire Clamps
PLPROFILE4 LED Luminaire Lenses
PLPROFILE4 LED Luminaire Lens Accessories
PLPROFILE4 LED Luminaire AC Input Power Cables
PLPROFILE4 LED Luminaire Wireless DMX512 Receivers
Part Number Description
SC Selecon Molded Yoke Rated C-Clamp
MC Mega Claw, Black Anodized
Part Number Description
SPX14LT SPX Axial Ellipsoidal 14-degree Fixed Beam Lens Tube Only
SPX19LT SPX Axial Ellipsoidal 19-degree Fixed Beam Lens Tube Only
SPX26LT SPX Axial Ellipsoidal 26-degree Fixed Beam Lens Tube Only
SPX36LT SPX Axial Ellipsoidal 36-degree Fixed Beam Lens Tube Only
SPX50LT SPX Axial Ellipsoidal 50-degree Fixed Beam Lens Tube Only
SPX1535LT SPX Axial Ellipsoidal 15-degree to 35-degree Zoomspot Lens Tube Only
SPX2550LT SPX Axial Ellipsoidal 25-degree to 50-degree Zoomspot Lens Tube Only
Part Number Description
20IRIS 20-Leaf SPX Iris
SPXGHB SPX Gobo Holder, Size B, For Metal Gobos
SPXGHGB SPX Gobo Holder, Size B, For Glass Gobos
19PACCF SPX Color Frame, Spare
19PACSMFB SPX Lens Safety, Mesh
19SPXCF SPX Replacement Color Frame, 6-1/4” Square, Black
Part Number Description
PC1BE PL Series Luminaire AC Power Input Cable (39 inches / 1 meter), PowerCon without AC connector
(bare end)
PC1GP PL Series Luminaire AC Power Input Cable (39 inches / 1 meter), PowerCon with Stagepin Connector
PC1GTL PL Series Luminaire AC Power Input Cable (39 inches / 1 meter), PowerCon with Twistlock
Connector
PC1GR PL Series Luminaire AC Power Input Cable (39 inches / 1 meter), PowerCon with Edison Connector
PC3PC PL Series Luminaire Interconnection Cable (2.5 meter), PowerCon Male to PowerCon Female for
interconnection between units
Part Number Description
PL1WDMX03 W-DMX Wireless DMX512 Receiver (Wireless Solutions) Black
PL1LDMX03 Lumen Radio Wireless DMX512 Receiver Black
PL1SDMX03 City Theatrical Wireless DMX512 Receiver Black

Installation & User’s Manual PLPROFILE4 LED Luminaires
6PREFACE
PLPROFILE4 LED Luminaire Wireless DMX512 Transmitters
PLPROFILE4 LED Luminaire Software Uploader Cable
Part Number Description
PL1WDMXTR W-DMX Wireless DMX512 (Wireless Solutions) Transmitter
PL1LDMXTR Lumen Radio Wireless DMX512 Transmitter
PL1SDMXTR City Theatrical Wireless DMX512 Transmitter
Part Number Description
PLUPLD USB Luminaire Software Programming Kit (for updating or reloading luminaire software only) -
includes USB to DMX Dongle, Uploader Program, and Carry Bag

PLPROFILE4 LED Luminaire Components 7
PLPROFILE4 LED Luminaires Installation & User’s Manual
PLPROFILE4 LED LUMINAIRE OVERVIEW
1. PLPROFILE4 LED Luminaire Components
Luminaire Components
LCD Display / Menu
Note: For Menu operation and programming details, refer to "LCD Menu Operation" on page 17.
Lens Tube
(depends on
LED Engine Assembly
Yoke Assembly
Yoke Locking Handle
Individual (positionable)
Shutter (4 each)
LCD Display / Menu
(see detail below)
Accessory Holder
(with lens tubes
Front View of Luminaire
Side Views of Luminaire
with latching door)
Cooling / Exhaust Vent
C-Clamp Top Box
(Power and DMX connections)
model purchased)
Note: For top box connections,
refer to "Connecting Power" on
page 10 and "Connecting to the
DMX512 Network" on page 10.
LCD Display
(Menu System)
Preset / Intensity /
Menu Access Buttons
Function / Select
(Menu System) Buttons
Rear of Luminaire

Installation & User’s Manual PLPROFILE4 LED Luminaires
8INSTALLATION AND SET UP
INSTALLATION AND SET UP
1. Top Box Connections
All PLPROFILE4 LED Luminaires are supplied with a "Top Box" for AC Input/Output and DMX512 Input/Output
Connections. Figure 1 shows the AC and DMX512 Input and Output (Thru) Connections.
Figure 1: PLPROFILE4 LED Luminaire Top Box Connections
DMX512 Output/Thru
DMX512 Input
AC (Power) Output
AC (Power) Input
Multi-Conductor Connector
(Top Box to Fixture Connection)
(Grey PowerCon Connector)
(Blue PowerCon Connector)

Power Requirements 9
PLPROFILE4 LED Luminaires Installation & User’s Manual
2. Power Requirements
WARNING! The PLPROFILE4 LED Luminaire should be connected to a constant circuit or a relay device. It
should never be connected to a dimmer or circuit controlled by a dimmer.
The PLPROFILE4 LED Luminaire operates on 100 to 240 volts AC (+/- 10%, auto-ranging). The luminaire contains
an auto-ranging power supply. Each luminaire can draw up to 600 Watts. Note, the values in Table 1 are averaged and
for reference only.
WARNING! *These figures are based on the Maximum Allowable Input Current of 20 Amps (and the maximum
power supply limit of 600 Watts). Do not overload circuits!
IMPORTANT AC POWER CONNECTION NOTES:
a. When using the daisy-chain connection method, ONLY connect
PLPROFILE4 LED Luminaires to AC Output Connection of
PLPROFILE4 LED Luminaires. DO NOT CONNECT OTHER TYPES
OF LUMINAIRES OR DEVICES!
b. Use only use approved cable types.
c. Do not overload circuits!
d. Do not connect PLPROFILE4 LED Luminaires to dimmed circuits.
e. The MAXIMUM allowable number of PLPROFILE4 LED Luminaires
which can be 'daisy-chained' on one power feed are listed in Table 1,
above. DO NOT EXCEED!
Table 1: PLPROFILE4 LED Luminaire Voltage vs. Current
Voltage
(AC) Total Current (A)
Maximum
number of
units that can
be linked
together*
Voltage
(AC) Total Current (A)
Maximum
number of
units that can
be linked
together*
100 6.0 3 180 3.3 6
110 5.5 3 190 3.2 6
120 5.0 4 200 3.0 6
130 4.6 4 210 2.9 6
140 4.3 4 220 2.7 7
150 4.0 5 230 2.6 7
160 3.8 5 240 2.5 8
170 3.5 5

Installation & User’s Manual PLPROFILE4 LED Luminaires
10 INSTALLATION AND SET UP
3. Connecting Power
Note: Refer to Figure 1 on page 8 for AC Input and Output connections.
If the unit is supplied with an AC input cable, Table 2 describes how to connect power to your PLPROFILE4 LED
Luminaire . Field wiring of the PLPROFILE4 LED Luminaire is straight forward. A total of 3 wires/conductors need
to be brought to the unit. The following wiring scheme is required:
Table 2: PLPROFILE4 LED Luminaire AC Input Connections
4. Connecting to the DMX512 Network
Note: Refer to Figure 1 on page 8 for DMX512 Input and Output/Thru connections.
Basic DMX512 installation consists of connecting multiple PLPROFILE4 LED Luminaires together (up to 30
luminaires) in "daisy-chain" fashion. A cable runs from the control console (or DMX512 control source) to the DMX
connector on the first PLPROFILE4 LED Luminaire. Another cable runs from the other DMX connector on the first
unit to a DMX connector on the next PLPROFILE4 LED Luminaire (or DMX512 device to be controlled).
Note: For more information on DMX512 networking and systems, refer to "Additional Resources for DMX512" on
page 1. For PLPROFILE4 LED Luminaire DMX Mapping, refer to "DMX CONTROL" on page 25.
Figure 2: Connecting DMX512
Wire Color Purpose
Brown Main / Line (120 to 240VAC)
Blue Neutral
Green/Yellow Ground
Neutral Main /
Ground / Earth
Line
AC Input Connector
(on back of unit)
DMX512
DMX512 (out from first
to second luminaire) DMX512 (out to the next luminaire or
DMX512 controlled device)
PLPROFILE4 LED Luminaires
DMX512 Connections
Note: Remaining pins on each connector are not used.
DMX512 Signal XLR Pin
Common (Drain) 1
DMX512 - 2
DMX512 + 3
(from console or
control device)

Mounting 11
PLPROFILE4 LED Luminaires Installation & User’s Manual
5. Mounting
WARNING! Before attempting any installation or service, disconnect all power at power source. Dimming the
luminaire does not disconnect power. Installation and service should only be performed by a trained and qualified
professional.
Using Supplied C-Clamp
As illustrated in Figure 3 on page 11, at yoke assembly, thread clamp mounting bolt (with washer installed) through
center clamp mounting hole at top of yoke, through Top Box Assembly, and thread bolt into C-Clamp. Securely
tighten bolt (by hand) into clamp (but do not overtighten).
Figure 3: Luminaire Mounting
To mount on a telescopic stand, reverse the yoke under the luminaire and bolt to stand. Please note luminaire
orientation (see note in Figure 3).
Note: After installing Clamp and Top Box assembly, connect luminaire cable assembly to Top Box Assembly before
mounting luminaire. Please note that the cable connector is keyed.
Yoke Assembly
Center Clamp Mounting Hole
Luminaire Cooling Vents
NOTE: To allow for proper cooling, make sure
luminaire head is orientated as shown (with
cooling vents pointed upwards).
Top Box Assembly
C-Clamp
Flat Washer
C-Clamp Bolt
Top Box Assembly
Luminaire Cable
Assembly

Installation & User’s Manual PLPROFILE4 LED Luminaires
12 INSTALLATION AND SET UP
Safety Cable Use
The supplied safety cable MUST always be used when rigging luminaires on bars, truss, etc. (as shown in Figure 4).
FOR LUMINAIRE, the supplied safety cable is recommended for all hanging installation and may be required by
national and local codes. Loop safety cable through luminaire yoke assembly as shown and attach to structure. FOR
LENS TUBE, attach a safety cable (sold separately) to lens tube anchor point and to yoke assembly. You should
always consult and follow all local and national codes and regulations for mounting and installation of luminaire.
WARNING! If your luminaire is equipment with the eyelet as indicated in Figure 4, DO NOT attach safety cable to
this eyelet on luminaire body. This eyelet feature was included for another purpose other than the safety cable and
will be removed from future production models.
6. Pan and Tilt Adjustments
Pan Adjustment
The pan adjustment of a PLPROFILE4 LED Luminaire is achieved by loosening the yoke bolt of the securing clamp
attached to the luminaire's yoke assembly. Loosen the bolt, set the luminaire to the desired position and retighten.
Tilt Adjustment
PLPROFILE4 LED Luminaires offer variable tilt settings. The unit can be set at a specific angle (in relation to its
mounting position) or at an angle between 0 to 90 degrees. When the yoke is in the position shown in Figure 4, you
have full range access to shutters the gate etc. If you flip the yoke over some access is reduced but the over all volume
the luminaire takes up is reduced. This is particularly useful in tightly hung lighting positions or in theatres with low
grids.
Figure 4: Luminaire Tilt Adjustment
To adjust and set tilt angle of the luminaire:
Step 1. Mount luminaire in desired location (see "Mounting" on page 11 for more information).
Step 2. Loosen, but do not remove, T-Handle Tilt Locks at base of yoke assembly as shown in Figure 4.
Step 3. Position luminaire to desired tilt position.
Step 4. Retighten T-Handle Tilt Locks to set position.
Yoke Assembly
Cooling Vents (see note below)
T-Handle Tilt Lock
NOTE: To allow for proper cooling, make
sure luminaire head is orientated as shown
(with cooling vents pointed upwards).
(one on each side)
Safety Cable
Sliding Yoke Assembly
NOT a safety cable
attachment point.
SAFETY CABLE: FOR LUMINAIRE, the supplied safety cable is
recommended for all hanging installation and may be required by
national and local codes. Loop safety cable through luminaire yoke
assembly as shown and attach to structure. FOR LENS TUBE, attach a
safety cable (sold separately) to lens tube anchor point and to yoke
assembly.
(supplied with
luminaire)
Safety Cable
(sold separately)

Lens Tube Removal and Installation 13
PLPROFILE4 LED Luminaires Installation & User’s Manual
FOCUS AND BEAM ADJUSTMENTS
1. Lens Tube Removal and Installation
It is easy and quick to change to the lens tubes on a PLPROFILE4 LED Luminaire. Fixed beam and zoom lens tubes
are interchangeable.
To remove and install lens tubes:
Step 1. Loosen (but do not remove) move lens knob(s) towards front of lens tube assembly. See "Zoom and Focus
Adjustments (Zoomspot Models)" on page 14 for more information.
Step 2. As illustrated Figure 5, side lens tube locking catch forward.
Figure 5: Lens Tube Assembly Removal - Lens Locking Catch
Step 3. Lift lens tube assembly up and away from light engine assembly.
Figure 6: Lens Tube Assembly Removal
Step 4. To install perform process in reverse.
CAUTION: Ensure the lens tube locking catch is fully engaged and safety cable is attached before putting fixture
into use. For safety cable attachment, refer to "Safety Cable Use" on page 12 for more information.
Lens Tube Assembly
Lens Tube Lock
1
2

Installation & User’s Manual PLPROFILE4 LED Luminaires
14 FOCUS AND BEAM ADJUSTMENTS
2. Zoom and Focus Adjustments (Zoomspot Models)
Note: Fixed Beam Angle models have hard/soft focus adjustment only.
To adjust zoom/beam angle and focus:
Step 1. Make sure all frame shutters are open (out of beam path). See "Beam Shutter Operation" on page 15 for
more information.
Step 2. As shown in Figure 7, loosen Zoom Adjustment Knob and set beam angle as desired.
Step 3. Hand-tighten Zoom Adjustment Knob to lock position.
Step 4. Loosen Focus Adjustment Knob.
Step 5. Move Focus Adjustment Knob along forward (or back) until beam focus is set as desired.
Step 6. Hand-tighten Focus Adjustment Knob to lock position.
Figure 7: Zoom and Focus Adjustment Knobs
Lens Tube Assembly
Zoom Adjustment Knob
Shutter (4 ea.)
Focus Adjustment Knob

Beam Shutter Operation 15
PLPROFILE4 LED Luminaires Installation & User’s Manual
3. Beam Shutter Operation
Each PLPROFILE4 LED Luminaire is equipped with four independent shutters (as shown in Figure 8) to block or
shape light as desired. After the luminaire is installed and positioned, move the shutters in or out as required. Use the
shutter lock to lock-in the shutter settings.
Figure 8: PLPROFILE4 LED Luminaire Beam Shutters
4. Gobo/Iris Access Panel
Each PLPROFILE4 LED Luminaire is capable of holding two gobo holders, each containing one "B" sized glass or
steel gobo. PLPROFILE4 LED Luminaire are not supplied gobo holders or an iris. These items can be purchased
from your local Authorized Dealer. For more information, refer to "PLPROFILE4 LED Luminaire Lens Accessories"
on page 5.
To install or change a gobo:
Step 1. As shown in Figure 9 on page 16, loosen, but do not remove, two retaining screws that secure gobo/iris
access panel. Slide open gobo/iris access panel.
Step 2. Install gobo into gobo holder in desired orientation.
Step 3. Slide gobo holder into luminaire gobo slot.
Step 4. Close gobo access door. Make sure gobo holder handle fits inside one of two slots in gobo access panel.
Beam Shutters
(4 Each)
Front View
Move beam shutters
in and out as desired.
Shutter Lock
See Detail
Shutter Lock Detail
Shutter Lock

Installation & User’s Manual PLPROFILE4 LED Luminaires
16 FOCUS AND BEAM ADJUSTMENTS
Step 5. Hand tighten gobo access panel retaining screws.
Figure 9: PLPROFILE4 LED Luminaire Gobo Holder and Gobo Installation
Gobo / Iris Access Panel
Detail
Gobo
Area
Gobo Holder
Panel Retaining Screw
(2 Each)
See Detail

LCD Menu Operation 17
PLPROFILE4 LED Luminaires Installation & User’s Manual
OPERATION AND PROGRAMMING
1. LCD Menu Operation
The PLPROFILE4 LED Luminaire’s LCD Display and Menu System provides local control for accessing all the
fixture’s status information, menu options, and settings.
Note: If there are multiple luminaires in a system, changes would need to be made at each LCD Menu as desired.
Upon power up, the LCD will display the main screen showing the product type/name. If DMX is enabled, the
programmed address will appear after power up.
Figure 10: LCD Display and Menu System
2. LCD Menu System
The LCD Display Menu system consists of several categories. Use the four arrow buttons as required (refer to Figure
10) to access and make changes to the menu items. When the desired menu item is reached, press [OK] to display the
menu options. Use navigation and [OK] buttons to view status and configure the LCD Menu as required.
Up/Down/Left/Right Arrow Buttons -
Navigates menu system and used for
Escape Button -
Enters menu options.
OK (Enter) Button -
Accesses details, activates
a field, or enters a setting
depending on the current menu item.
selecting and setting options.
Navigates (backs up)
PRESET Button -
Allows the recall of
LCD Display -
Displays all menu parameters and
option settings. Also displays DMX512
address (DMX models only).
stored presets.
INTENSITY Button -
Allows the customization of current
intensity (light output). Note, using
the LEFT and RIGHT arrow buttons
you can select each RGBW
channel individually and change
their intensity using the UP and
DOWN arrows.
one menu level.

Installation & User’s Manual PLPROFILE4 LED Luminaires
18 OPERATION AND PROGRAMMING
Note: Depending on the security settings, certain menu items may be password protected. You must have the set
PassPIN in order to access these items. Locked items will have a "Key" icon displayed next to them.
To navigate and access menu settings/selections:
Step 1. At Main Menu, press [ESC] / [MENU] button once. A small window will appear over Main Menu with sub-
menu categories:
a. Save as Preset
b. Edit a Preset
c. Color Mix
d. Fan Control
e. Settings
f. Lock Fixture
g. Enter Password
h. LED Status
Step 2. Press [OK] at desired menu item to access and make changes.
Step 3. Make changes as desired.
Note: For complete menu structure and available options, see "Menu Structure (continued)" on page 20.
Note: When DMX512 signal is present, Edit Preset and Color Mix options will not appear in menu structure.
To navigate fixture status menus:
Step 1. At Main Menu, press LEFT or RIGHT arrow button once. Main menu screen will change to fixture status
screen will appear as follows (note, depending on which arrow button is pressed, status screens may appear
in reverse order):
a. DMX Address (note, if fixture is UNLOCKED, hit [OK] to change DMX address)
b. Fixture Hours (displays fixture operating hours since last reset)
c. Fixture Power (displays Max Power Limit setting (in watts), Present Power consumed by fixture (in
watts), and Hours of Use)
d. Fixture Status (displays current operational temperature, LED status, and fan speed setting)
Step 2. Press LEFT or RIGHT arrow buttons to scroll through status screens.
Step 3. Press [ESC] at anytime to access menu settings. See "To navigate and access menu settings/selections:" on
page 18.
