Philips DVD623AT User manual

DVD 623
DVD AT AT623
Philips DVD-Video Player
Movies & Music
PICTURE QUALITY
• Component video output: highest quality video connection
• Digital Zoom with Perfect Still
SOUND QUALITY
• Digital coaxial and optical outputs:
highest quality audio connection
•96kHz/24bits audio DAC for high quality audio output
•3D sound: surround sound for stereo systems
GREAT CONVENIENCE
•Plays DVD-Video/VCD/SVCD/MP3-CD/HDCDR-RW/CD audio
•Picture-CD: View Camera Photo CDs
•Enhanced Parental Control with 120 Disc Lock
•5 Disc Resume
•High Quality Mirror Finish
COMPONENT
VIDEO OUTPUT

DVD623
DVD AT AT
623
Playback system
• DVD-Video
• Video CD (VCD)
• SVCD
• MP3-CD1
• CD (CD-R and CD-RW)1
• DVD+RW
Optical read-out system
• Laser type Semiconductor AlGaAs
• Numerical Aperture 0.60 (DVD)
0.45 (VCD/SVCD/CD)
• Wavelength 650 nm (DVD)
780 nm (VCD/SVCD/CD)
DVD disc format
• Medium Optical disc
• Diameter 12 cm (8 cm)
• Playing time One layer 2.15 h2
(12cm) Dual layer 4 h2
Two side, 4.30 h2
single layer
Two side, 8 h2
dual layer
TV standard PAL NTSC
50 Hz 60Hz
• Number of lines 625 525
• Playback Multi standard (PAL/ NTSC)
Video format
• Digital compression MPEG 2 for DVD, SVCD
MPEG 1 forVCD
DVD 50Hz 60Hz
Horiz. resolution 720 pixels 720 pixels
Vertical resolution 576 lines 480 lines
VCD 50Hz 60Hz
Horiz. resolution 352 pixels 352 pixels
Vertical resolution 288 lines 240 lines
Video performance
• Video output 1Vpp into 75 ohm
Audio format
• Digital Mpeg/Dolby Compressed Digital,
Digital/ PCM 16, 20, 24 bits
fs, 44.1, 48, 96 kHz
MP3 (ISO 9660) 24, 32, 56, 64, 96, 112
,128, 256 kbps &
variable bit rate
fs, 16, 22.05, 24, 32,
44.1, 48 kHz
• Analog sound stereo
• Dolby surround compatible downmix from Dolby
Digital multi-channel sound
• 3D sound for virtual 5.1 channel sound on 2
speakers
DVD-Video player
General functionality
• Stop/ play / pause
• Fast forward/ backward
• Step forward
• Slow motion
• Title/ chapter/ track select
• Skip next/ skip previous
• Repeat (Chapter/ title/all) or (Track/ all)
• A-B repeat
• Scan
• Zoom
• 3D sound
• Screen saver
• Resume (5 discs) after stop
• Parental control and disc lock (80 disc)
• ProgrammingTitles / chapters or track with
Favorite Track Selection (FTS)
DVD functionality
• Multi-angle selection
• Audio selection (1 out of max. 8 languages)
• Subtitles selection (1 out of max. 32 languages)
• Aspect ratio conversion
(16:9, 4:3 letterbox, 4:3 Pan Scan)
• Disc Menu support (title menu and root menu)
Video CD functionality
• Playback control forVCD 2.0 discs
SVCD functionality
• Playback control as per SVCD standard
• Audio Selection (1 out of max. 4 languages)
MP3 functionality
• Time display (Track)
• Album and track selection
• Repeat (disc / album / track)
• Nested directory levels supported to 8 levels
• Max. album numbers possible is 32
• Max. MP3 Tracks Programmable is 96
• Max. Number of Tracks 999
Technical specifications DVD 623AT
• S-Video output Y: 1Vpp into 75 Ohm
• Component Video output
Y 1Vpp into 75 Ohm
CR0.7Vpp into 75 Ohm
CB0.7Vpp into 75 Ohm
C: 0.3Vpp into75 Ohm
Audio performance (typical)
• D/A converter 24 bits
• Signal-noise (1kHz) >95 dB
• Dynamic Range (1kHz) >80 dB
• Crosstalk (1kHz) >90 dB
• Distortion/noise (1kHz) >80 dB
Connection
• Component Video out Cinch (Red/Green/Blue)
Mini DIN 4-pins
•
• Video output S-Video output Cinch (yellow)
• Audio L+R Output Cinch (white/ red)
• Digital Output 1 coaxial, 1 optical
IEC958 for CDDA/LPCM
IEC1937 for MPEG 1/2,
AC-3
Power supply
• Power inlet 110V, 60 Hz
• Power usage Approx. 20 watt
Product
• Dimension 17 x 2.9 x 11.3 inches
(w x h x d)
• Weight Approx. 6.6 lbs
Carton
• Dimension
UPC 0 37849 92185 2
20.6 x 7.16 x 15 inches
(w x h x d)
• Weight Approx. 9.9 lbs
Package contents
• DVD-video player
• Universal Remote control with batteries
• User's manual
• Audio cable
• Video cable
1 Only Applicable for Single session finalised disc.
2 Typical playing time for movie with 2 spoken
languages and 3 subtitle languages.
Dolby and the double-D symbol are trademarks of Dolby
Laboratories Licensing Corporation.
Printed in USA
© 2002 Philips Consumer Electronics
A Division of Philips Electronics North America Corp.
http://www.philips.com
