Philips DVP3800/55 User manual

TABLE OF CONTENTS
Page
Version 1.4
Service Manual
PHILIPS
GB
©
All rights reserved. No part of this publication may be reproduced, stored in aretrieval system or
transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise
without the prior permission of Philips.
CLASS 1
LASER PRODUCT
Service
DVD Player
Copyright 2011 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
Published by LLL - 1202BU AVM Printed in The Netherlands Subject to modification
3141 785 36984
DVP3800(X)
DVP3800/55
This service manual is for DVP3800
second generation model, which is different from the
first generation DVP3800 model.
For second generation model, the serial number begins
with KX 2Axxxxxxxxxx
Specification............................................................................1-2
Safety Instruction,Warning & Notes........................................1-3
Mechanical and Dismantling Instruction..................................2-1
Software Upgrades..................................................................3-1
Trouble Shooting ....................................................................4-1
Wiring Diagram........................................................................5-1
Electrical Diagram and Print-layout.........................................6-1
Mechanical Exploded View.....................................................7-1
Revision List............................................................................8-1
Second Generation
DVP3800/96/98
DVP3800/93
DVP3800/79
DVP3800X/77

Note
Specifications are subject to change without notice
•
DVD region code Countries
Playable media
Disc
DVD, DVD-Video, VCD, SVCD, Audio CD
DVD+R/+RW, DVD-R/-RW, DVD+R/-R DL (Dual
Layer), CD-R/-RW (Maximum number of files: 648)
File
Video: .avi, .divx, .mp4, .xvid
Audio: .mp3, .wma
Picture: .jpg, .jpeg
Video
Signal system: PAL, NTSC
Composite video output: 1 Vp-p (75 Ohm)
Component video output: 0.7 Vp-p (75 Ohm)
Audio
2-channel analog output
Audio Front L&R : 2 Vrms (47k Ohm)
Digital output: 0.5 Vp-p (75 Ohm)
Coaxial
Sampling frequency:
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Specifications For DVP3800/55
1-2
Latin America

MP3: 8 kHz, 11 kHz, 12 kHz, 16 kHz, 22 kHz, 24 kHz, 32
kHz, 44.1 kHz, 48 kHz
WMA: 44.1 kHz, 48 kHz
Constant bit rate:
MP3: 8 kbps - 320 kbps
WMA: 64 kbps - 192 kbps
Main unit
Dimensions (W x H x D): 360 x 42 x 209 (mm)
Net Weight: 1.44 kg
Power
Power supply rating: 110 - 240 V, 50/60 Hz
Power consumption: < 8 W
Power consumption in standby mode: < 0.3 W
Accessories supplied
Remote control and one battery
AC Power cord
User Manual
Laser specification
Type: Semiconductor laser InGaAIP (DVD), AIGaAs (CD)
Wave length: 658 nm (DVD), 790 nm (CD)
Output Power: 7.0 mW (DVD), 10.0 mW (VCD/CD)
Beam divergence: 60 degrees
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
~
~
1-3
•Power Plug Adapter

Note
Specifications are subject to change without notice.
•
DVD region code Countries
Asia Pacific, Taiwan, Korea
Playable media
• Disc
DVD, DVD-Video, VCD, SVCD, Audio CD•
DVD+R/+RW, DVD-R/-RW, DVD+R/-R DL (Dual Layer),•
CD-R/-RW (Maximum number of files: 648)
• File
Video: .avi, .divx, .mp4, .xvid•
Audio: .mp3, .wma•
Picture: .jpg, .jpeg•
Video
Signal system: PAL, NTSC•
Composite video output: 1 Vp-p (75 Ohm)•
Component video output: 0.7 Vp-p (75 Ohm)•
Audio
2-channel analog output•
Audio Front L&R : 2 Vrms (47k Ohm)•
Digital output: 0.5 Vp-p (75 Ohm)•
Coaxial•
Sampling frequency:•
MP3: 8 kHz, 11 kHz, 12 kHz, 16 kHz, 22 kHz, 24 kHz, 32 kHz, 44.1 kHz, 48 kHz•
WMA: 44.1 kHz, 48 kHz•
Constant bit rate:•
MP3: 8 kbps - 320 kbps•
WMA: 64 kbps - 192 kbps•
Main unit
Dimensions (W x H x D): 360 x 42 x 209 (mm)•
Net Weight: 1.35 kg•
Specifications for DVP3800/96
1-4

Power
Power supply rating: 110–240 V~, 50/60 Hz•
Power consumption: < 8 W•
Power consumption in standby mode: < 0.3 W•
Accessories supplied
Remote control and one battery•
Audio/Video cables•
User Manual•
Laser specification
Type: Semiconductor laser InGaAIP (DVD), AIGaAs (CD)•
Wave length: 658 nm (DVD), 790 nm (CD)•
Output Power: 7.0 mW (DVD), 10.0 mW (VCD/CD)•
Beam divergence: 60 degrees•
1-5

Note
Specifications are subject to change without notice.
•
DVD region code Countries
Asia Pacific, Taiwan, Korea
Playable media
• Disc
DVD, DVD-Video, VCD, SVCD, Audio CD•
DVD+R/+RW, DVD-R/-RW, DVD+R/-R DL (Dual Layer),•
CD-R/-RW (Maximum number of files: 648)
• File
Video: .avi, .divx, .mp4, .xvid•
Audio: .mp3, .wma•
Picture: .jpg, .jpeg•
Video
Signal system: PAL, NTSC•
Composite video output: 1 Vp-p (75 Ohm)•
Component video output: 0.7 Vp-p (75 Ohm)•
Audio
2-channel analog output•
Audio Front L&R : 2 Vrms (47k Ohm)•
Digital output: 0.5 Vp-p (75 Ohm)•
Coaxial•
Sampling frequency:•
MP3: 8 kHz, 11 kHz, 12 kHz, 16 kHz, 22 kHz, 24 kHz, 32 kHz, 44.1 kHz, 48 kHz•
WMA: 44.1 kHz, 48 kHz•
Constant bit rate:•
MP3: 8 kbps - 320 kbps•
WMA: 64 kbps - 192 kbps•
Main unit
Dimensions (W x H x D): 360 x 42 x 209 (mm)•
Net Weight: 1.34 kg•
Specifications for DVP3800/98
1-6

Power
Power supply rating: 110–240 V~, 50/60 Hz•
Power consumption: < 8 W•
Power consumption in standby mode: < 0.3 W•
Accessories supplied
Remote control and one battery•
Power cord•
Audio/Video cables•
User Manual•
Laser specification
Type: Semiconductor laser InGaAIP (DVD), AIGaAs (CD)•
Wave length: 658 nm (DVD), 790 nm (CD)•
Output Power: 7.0 mW (DVD), 10.0 mW (VCD/CD)•
Beam divergence: 60 degrees•
1-7

Note
Specifications are subject to change without
•
notice
DVD region code Countries
Playable media
• Disc
DVD, DVD-Video, VCD, SVCD, Audio CD•
DVD+R/+RW, DVD-R/-RW, DVD+R/-R DL
(Dual Layer), CD-R/-RW (Maximum number
•
of files: 648)
• File
Video: .avi, .divx, .mp4, .xvid•
Audio: .mp3, .wma•
Picture: .jpg, .jpeg•
Video
Signal system: PAL, NTSC•
Composite video output: 1 Vp-p (75 ohm)•
Audio
2-channel analog output•
Audio Front L&R : 2 Vrms (47k Ohm)•
Digital output: 0.5 Vp-p (75 ohm)•
Coaxial•
Sampling frequency:•
MP3: 8 kHz, 11 kHz, 12 kHz, 16 kHz,
22 kHz, 24 kHz, 32 kHz, 44.1 kHz, 48 kHz
•
WMA: 44.1 kHz, 48 kHz•
Constant bit rate:•
MP3: 8 kbps - 320 kbps•
WMA: 64 kbps - 192 kbps•
Main unit
Dimensions (W x H x D): 360 x 42 x 209 (mm)•
Net Weight: 1.31 kg•
Power
Power supply rating: 110–240 V~, 50/60 Hz•
Power consumption: < 8 W•
Power consumption in standby mode: < 0.3 W•
Accessories supplied
Remote control and one battery•
Specifications For DVP3800/93
China
•
Laser specification
Type: Semiconductor laser InGaAIP (DVD),
AIGaAs (CD)
•
Wave length: 658 nm (DVD), 790 nm (CD)•
Output Power:
7.0 mW (DVD), 10.0 mW (VCD/CD)
•
Beam divergence: 60 degrees•
SG
Q
1-8

Note
Specifications are subject to change without notice.
•
DVD region code Countries
Australia, New Zealand
Playable media
• Disc
DVD, DVD-Video, VCD, SVCD, Audio CD•
DVD+R/+RW, DVD-R/-RW, DVD+R/-R DL (Dual Layer),•
CD-R/-RW (Maximum number of files: 648)
• File
Video: .avi, .divx, .mp4 (MPEG-4 Part 2), .xvid•
Audio: .mp3, .wma•
Picture: .jpg, .jpeg•
Video
Signal system: PAL, NTSC•
Composite video output: 1 Vp-p (75 Ohm)•
Component video output: 0.7 Vp-p (75 Ohm)•
Audio
2-channel analog output•
AUDIO OUT L&R : 2 Vrms (47k Ohm)•
Digital output: 0.5 Vp-p (75 Ohm)•
Coaxial•
Sampling frequency:•
MP3: 8 kHz, 11 kHz, 12 kHz, 16 kHz, 22 kHz, 24 kHz, 32 kHz, 44.1 kHz, 48 kHz•
WMA: 44.1 kHz, 48 kHz•
Constant bit rate:•
MP3: 8 kbps - 320 kbps•
WMA: 64 kbps - 192 kbps•
Main unit
Dimensions (W x H x D): 360 x 42 x 209 (mm)•
Net Weight: 1.35 kg•
1-9
DVP3800/79 Specification

Power
Power supply rating: 230–240 V~, 50 Hz•
Power consumption: < 8 W•
Power consumption in standby mode: < 0.3 W•
Accessories supplied
Remote control and one battery•
Audio/Video cables•
User Manual•
Laser specification
Type: Semiconductor laser InGaAIP (DVD), AIGaAs (CD)•
Wave length: 658 nm (DVD), 790 nm (CD)•
Output Power: 7.0 mW (DVD), 10.0 mW (VCD/CD)•
Beam divergence: 60 degrees•
1-10
