Philips HTP5980K/93 User manual

DVD VIDEO PLAYER
Read your Quick Start Guide and/or User Manual first for quick tips
that make using your Philips product more enjoyable.
Register your product and get support
at www.philips.com/welcome
DVD VIDEO PLAYER DVP5980K
01_dvp5980K_93_eng2.indd 101_dvp5980K_93_eng2.indd 1 2007-06-25 11:08:45 AM2007-06-25 11:08:45 AM

2
O: Indicates that this toxic or hazardous substance contained in all of the homogeneous
materials for this part is below the limit requirement in SJ/T11363 – 2006.
X: Indicates that this toxic or hazardous substance contained in at least one of the
homogeneous materials used for this part is above the limit requirement in SJ/T11363 - 2006.
Environmental Protection Use Period
This logo refers to the period ( 10 years ) during which the toxic or hazardous substances or elements
contained in electronic information products will not leak or mutate so that the use of these [substances or
elements] will not result in any severe environmental pollution, any bodily injury or damage to any assets.
This logo refers to the period ( 5 years ) during which the toxic or hazardous substances or elements
contained in the battery will not leak or mutate so that the use of these [substances or elements] will not
result in any severe environmental pollution, any bodily injury or damage to any assets.
Environmental Protection Use Period
Battery labeling logo
OOO O O O
XOO O O O
XOO O O O
XOO O O O
XOO O O O
01_dvp5980K_93_eng2.indd 201_dvp5980K_93_eng2.indd 2 2007-06-25 11:08:53 AM2007-06-25 11:08:53 AM

English
3
This product incorporates copyright protection
technology that is protected by method claims of
certain U.S. patents and other intellectual property
rights owned by Macrovision Corporation and other
rights owners. Use of this copyright protection
technology must be authorized by Macrovision
Corporation, and is intended for home and other
limited viewing uses only unless otherwise authorized
by Macrovision Corporation. Reverse engineering or
disassembly is prohibited.
Index
English ------------------------------------------6
--------------------------------- 56
01_dvp5980K_93_eng2.indd 301_dvp5980K_93_eng2.indd 3 2007-06-25 11:08:54 AM2007-06-25 11:08:54 AM

4
LASER
Type Semiconductor laser
InGaAlP (DVD)
AIGaAs (CD)
Wave length 658 nm (DVD)
790 nm (CD)
Output Power 7.0 mW (DVD)
10.0 mW (VCD/CD)
Beam divergence 60 degrees
General Information
Environmental Information
All unnecessary packaging has been
omitted. The packaging has been made
easy to separate into two materials;
cardboard (box) and polyethylene (bags,
protective foam sheet).
Your DVD player consists of materials
which can be recycled and reused if
disassembled by a specialised company.
Please observe the local regulations
regarding the disposal of packaging
materials, exhausted batteries and old
equipment.
Laser Safety
This unit employs a laser. Due to possible
eye injury, only a qualied service person
should remove the cover or attempt to
service this device.
NOTE:
Pictures shown maybe different
between countries.
CAUTION:
WARNING LOCATION: ON THE
BACKPLATE OF THE SET
NEVER MAKE OR CHANGE
CONNECTIONS WITH THE
POWER SWITCHED ON.
For Customer Use:
Read carefully the information located at
the bottom or rear of your DVD Video
player and enter below the Serial No.
Retain this information for future
reference.
Model No. DVP 5980K
Serial No. ___________________
Specications are subject to change without
notice. Trademarks are the property of
Koninklijke Philips Electronics N.V. or their
respective owners.
Windows Media and the Windows logo
are trademarks, or registered
trademarks of Microsoft Corporation
in the United States and/or other
countries.
Manufactured under license from
Dolby Laboratories, Dolby
and the double-D symbol are
trademarks of Dolby Laboratories.
logo.indd 1 2006-03-21 10:25:36 AM
DivX Ultra Certied products: DivX,
DivX Ultra Certied, and associated
logos are trademarks of DivX, Inc. and
are used under license.
logo.indd 1 2006-03-21 10:25:36 AM
HDMI, and HDMI logo and
High-Denition Multimedia Interface
are trademarks or registered
trademarks of HDMI licensing LLC.
logo.indd 1 2006-03-21 10:25:36 AM
Manufactured under license under U.S.
Patent #: 5,451,942 & other U.S. and
worldwide patents issued & pending. DTS
and DTS Digital Out are registered
trademarks and the DTS logos and
Symbol are trademarks of DTS, Inc. ©
1996-2007 DTS, Inc. All Rights Reserved.
01_dvp5980K_93_eng2.indd 401_dvp5980K_93_eng2.indd 4 2007-06-25 11:08:54 AM2007-06-25 11:08:54 AM

5
Language Code
01_dvp5980K_93_eng2.indd 501_dvp5980K_93_eng2.indd 5 2007-06-25 11:08:55 AM2007-06-25 11:08:55 AM

English
6
Contents
Care and Safety Information
Setup......................................................................................................................................................................... 8
Cleaning discs.........................................................................................................................................................8
General Information
Accessories supplied............................................................................................................................................9
Region codes .......................................................................................................................................................... 9
Connections
Connecting to television ........................................................................................................10
Using Composite Video jacks (CVBS) ..........................................................................................................10
Using Component Video jacks (Y Pb Pr) .....................................................................................................10
Connecting the power cord ................................................................................................... 11
Optional connections
Connecting to a stereo system..............................................................................................12
Stereo system has right/ left Audio In jacks................................................................................................12
Connecting to a digital AV receiver .....................................................................................12
Receiver has a PCM, Dolby Digital or MPEG decoder ............................................................................12
Connecting a USB Flash Drive or USB mass storage device ...........................................13
Using USB port....................................................................................................................................................13
HDMI connections
Connecting to a HDMI or DVI TV ........................................................................................14
Connecting to an Analog or Digital AV Receiver...............................................................15
Connecting to a HDMI/DVI TV via a HDMI Repeater.......................................................15
Product Overview
Front and Rear Panels ............................................................................................................16
Remote Control.......................................................................................................................17
Getting Started
Step 1: Inserting Batteries.....................................................................................................18
Using the remote control to operate the system .....................................................................................18
Step 2: Finding your viewing channel ...................................................................................18
Step 3: Setting up Progressive Scan feature .......................................................................19
Step 4: Selecting the matching color system......................................................................20
Step 5: Setting the language..................................................................................................21
On-screen display (OSD) language................................................................................................................21
Audio, Subtitle and Disc menu languages.....................................................................................................21
Playback from Disc
Playable discs ...........................................................................................................................22
Supported formats ............................................................................................................................................22
Playback Features
Starting disc playback.............................................................................................................23
Basic playback controls ..........................................................................................................23
Pausing playback ..................................................................................................................................................23
Selecting title/chapter/track.............................................................................................................................23
Stopping playback................................................................................................................................................23
Operations for video playback ..............................................................................................24
Using the Disc Menu..........................................................................................................................................24
Zooming in............................................................................................................................................................24
Resuming playback from the last stopped point ........................................................................................24
Slow Motion .........................................................................................................................................................24
Forward / Reverse Searching...........................................................................................................................24
Viewing the disc playback information ......................................................................... 25~27
Using the OSD menu .........................................................................................................................................25
Title/Chapter/Track selection.........................................................................................................................25
Time Search..........................................................................................................................................................25
Audio / Subtitle....................................................................................................................................................25
Angle.......................................................................................................................................................................25
Time Display.........................................................................................................................................................26
Repeat ....................................................................................................................................................................26
01_dvp5980K_93_eng2.indd 601_dvp5980K_93_eng2.indd 6 2007-06-25 11:08:55 AM2007-06-25 11:08:55 AM

English
7
Contents
Repeat A-B............................................................................................................................................................26
Preview...................................................................................................................................................................27
Viewing Audio CD playback information ............................................................................27
Disc Go To / Track Go To / Track Selection ..............................................................................................27
Repeat ....................................................................................................................................................................27
Special DVD Features.............................................................................................................28
Playing a Title .......................................................................................................................................................28
Changing the Audio Language .........................................................................................................................28
Subtitles .................................................................................................................................................................28
Special VCD and SVCD Feature ...........................................................................................28
Playback Control (PBC) ....................................................................................................................................28
Playing a DivX®disc.................................................................................................................29
USB mass storage device .......................................................................................................30
Compatibility of USB device............................................................................................................................30
Playing from USB ash drive or USB memory card reader.............................................31
Playing MP3/WMA/JPEG Picture CD............................................................................ 32~33
General Operation.............................................................................................................................................32
Playback selection...............................................................................................................................................32
Repeat ....................................................................................................................................................................32
Playback with multi-angles (JPEG)..................................................................................................................33
Preview Function (JPEG)...................................................................................................................................33
Zoom picture (JPEG) .........................................................................................................................................33
Playing MP3/WMA music and JPEG picture simultaneously...................................................................33
Karaoke Operations
Playing Karaoke discs..............................................................................................................34
General Operation.............................................................................................................................................34
Vocal .......................................................................................................................................................................34
Karaoke menu......................................................................................................................................................34
DVD Menu Options
Using the General setup menu....................................................................................... 35~36
Locking/Unlocking the disc for viewing........................................................................................................35
OSD Language .....................................................................................................................................................35
Sleep .......................................................................................................................................................................36
Lip Sync..................................................................................................................................................................36
Volume ...................................................................................................................................................................36
DivX®VOD registration code.........................................................................................................................36
Using the Audio setup menu .......................................................................................... 37~39
Analog Output .....................................................................................................................................................37
Digital Audio Setup .....................................................................................................................................37~38
Sound Mode..........................................................................................................................................................39
CD Upsampling....................................................................................................................................................39
Night Mode - turning on/off.............................................................................................................................39
Using the Video setup menu...........................................................................................40~44
TV Type .................................................................................................................................................................40
Setting the TV Display.......................................................................................................................................40
Progressive............................................................................................................................................................41
Picture Setting.............................................................................................................................................. 41~42
HD JPEG................................................................................................................................................................42
HDMI Video Setup .....................................................................................................................................43~44
Using the Preference setup menu .................................................................................45~48
Subtitle/Audio/Disc Menu.................................................................................................................................45
Parental..................................................................................................................................................................45
PBC .........................................................................................................................................................................46
MP3/JPEG Menu...................................................................................................................................................46
Changing the Password .....................................................................................................................................47
Setting the DivX®subtitle font........................................................................................................................47
Restoring to the original settings ...................................................................................................................48
Others
Software upgrade....................................................................................................................49
Troubleshooting ............................................................................................................... 50~52
Specications ...........................................................................................................................53
Frequently Asked Questions (USB) .....................................................................................54
Glossary ....................................................................................................................................55
01_dvp5980K_93_eng2.indd 701_dvp5980K_93_eng2.indd 7 2007-06-25 11:08:56 AM2007-06-25 11:08:56 AM

English
8
Care and Safety Information
DANGER!
High voltage! Do not open the
device. You run the risk of getting
an electric shock.
The machine does not contain any
user-serviceable parts. Please leave
all maintenance work to qualied
personnel.
Setup
Finding a suitable location
– Place the set on a at, hard and stable
surface. Do not place the set on a
carpet.
– Do not put any equipment or heavy
objects on top of the set.
– Do not position the set on top of
other equipment that might heat it up
(such as receiver or amplier).
– Do not put anything under the set
(such as CDs, magazines).
– Install this unit near the AC outlet and
where the AC power plug can be
reached easily.
Space for ventilation
– Place the apparatus in a location with
adequate ventilation to prevent
internal heat build up. Allow at least
10 cm (4.0”) clearance from the rear
and the top of the set and 5cm (2.0”)
from the left and right to prevent
overheating.
10cm (4.0") 10cm (4.0")
5cm (2.0")
5cm (2.0")
Avoid high temperatures, moisture,
water and dust
– Apparatus shall not be exposed to
dripping or splashing.
– Do not place any sources of danger
on the apparatus (such as liquid lled
objects, lighted candles).
Cleaning discs
Some problems occur because the disc
inside the player is dirty (frozen picture,
sound disruptions, picture distortions).
To avoid these problems, discs should be
cleaned on a regular basis.
To clean a disc, use a micro bre cleaning
cloth and wipe the disc from the center
to the edge in a straight line.
CAUTION!
Do not use solvents such as benzene,
thinner, commercially available cleaners,
or anti-static sprays intended for analog
discs. Since the optical unit (laser) of the
DVD player operates at a higher power
than regular DVD or CD players,
cleaning CDs intended for DVD or CD
players may damage the optical unit
(laser). Therefore, refrain from using a
cleaning CD.
01_dvp5980K_93_eng2.indd 801_dvp5980K_93_eng2.indd 8 2007-06-25 11:08:56 AM2007-06-25 11:08:56 AM

English
9
General Information
Accessories supplied
ALL
4
Region
U.S.A. and
Canada regions
U.K and
Europe regions
Asia Pacic,
Taiwan, Korea
Australia,
New Zealand,
Latin America
Russia and
India regions
China, Calcos Islands,
Walls and Futuna
Islands
ALL
ALL
5
6
Discs that can
be played
ALL
1
ALL
ALL
2
3
Remote
control and
two AAA
batteries
Region codes
This DVD player is designed to support
the Region Management System. Check
the regional code number on the disc
package. If the number does not match
the player’s region number (see table
below), the player may be unable to
playback the disc.
Tips:
– It may not be possible to play CD-R/RW
or DVD-R/RW in all cases due to the type of
disc or condition of the recording.
– If you are having trouble playing a certain
disc, remove the disc and try a different one.
Improper formatted disc will not played on
this DVD player.
Composite
video cable
(yellow) and
audio cables
(white, red)
01_dvp5980K_93_eng2.indd 901_dvp5980K_93_eng2.indd 9 2007-06-25 11:08:56 AM2007-06-25 11:08:56 AM

English
10
Connections
TIPS: Before making or changing any connections, make sure that all the devices are disconnected
from the power outlet.
Connecting to television
IMPORTANT!
– The progressive scan video quality
is only possible when using Y Pb Pr
and a progressive scan television is
required.
Using Component Video jacks
(Y Pb Pr)
AUse the component video cables (red/
blue/green) to connect the DVD player’s
Y Pb Pr jacks to the component video
input jacks (or labeled as Y Pb Pr) on the
television (cable not supplied).
BTo hear sound of this DVD player
through your television, use the audio
cables (white/red) to connect AUDIO
OUT (L/R) jacks of the DVD player to
the corresponding AUDIO IN jacks on
the television (cable supplied).
CProceed to page 19 for detailed
progressive scan setup.
IMPORTANT!
– You only need to make one video
connection from the following
options, depending on the
capabilities of your television.
– Connect the DVD player directly
to the television.
Using Composite Video jacks
(CVBS)
AUse the composite video cable (yellow)
to connect the DVD player’s TV OUT
(CVBS) jack to the video input jack (or
labeled as A/V In, Video In, Composite or
Baseband) on the television (cable
supplied).
BTo hear sound of this DVD player
through your television, use the audio
cables (white/red) to connect
AUDIO OUT (L/R) jacks of the DVD
player to the corresponding AUDIO IN
jacks on the television (cable supplied).
AUDIO OUT
DIGITAL
OUT
TV OUT
COAXIAL
COMPONENT VIDEO OUT
HDMI OUT
AUDIO
IN
V (Pr/Cr)
U (Pb/Cb)
Y
S-VIDEO
IN
VIDEO IN
COMPONENT
VIDEO IN
AUDIO
OUT
V(Pr/Cr)
U(Pb/Cb)
Y
S-VIDEO
IN
VIDEOIN
COMPONENT
VIDEOIN
12
AUDIO OUT
DIGITAL
OUT
TV OUT
COAXIAL
COMPONENT VIDEO OUT
HDMI OUT
AUDIO
IN
V (Pr/Cr)
U (Pb/Cb)
Y
S-VIDEO
IN
VIDEO IN
COMPONENT
VIDEO IN
AUDIO
OUT
V(Pr/Cr)
U(Pb/Cb)
Y
S-VIDEO
IN
VIDEOIN
COMPONENT
VIDEOIN
2
1
01_dvp5980K_93_eng2.indd 1001_dvp5980K_93_eng2.indd 10 2007-06-25 11:08:57 AM2007-06-25 11:08:57 AM

English
11
Connections (continued)
TIPS: Before making or changing any connections, make sure that all the devices are disconnected
from the power outlet.
Connecting the power cord
After everything is connected
properly, plug in the AC power cord
to the power outlet.
Never make or change any connections
with the power switched on.
When no disc is loaded, press
STANDBY-ON on the DVD player
front panel.
‘NO DISC’ may appear on the
display panel.
DIGITAL
OUT
TV OUT
COAXIAL
COMPONENT VIDEO OUT
HDMI OUT
01_dvp5980K_93_eng2.indd 1101_dvp5980K_93_eng2.indd 11 2007-06-25 11:08:58 AM2007-06-25 11:08:58 AM

English
12
Connecting to a stereo
system
Receiver has a PCM, Dolby Digital
or MPEG decoder
ASelect one of the video connections
(CVBS VIDEO IN or COMPONENT
VIDEO IN) depending on the options
available on your television.
BConnect the COAXIAL jack of the DVD
player to the corresponding Digital Audio
In jack on your receiver (cable not
supplied).
CSet the DVD player’s digital output to
PCM-Only or ALL depending on the
capabilities of your receiver (see page 38
{ Digital Output }).
Tip:
– If the audio format of the Digital Output
does not match the capabilities of your
receiver, the receiver will produce a strong,
distorted sound or no sound at all.
Stereo system has right/ left Audio
In jacks
ASelect one of the video connections
(CVBS VIDEO IN or COMPONENT
VIDEO IN) depending on the options
available on your television.
BUse the audio cables (white/red) to
connect AUDIO OUT (L/R) jacks of the
DVD Player to the corresponding
AUDIO IN jacks on the stereo system
(cable supplied).
Connecting to a digital AV
receiver
Optional connections
TIPS: Before making or changing any connections, make sure that all the devices are disconnected
from the power outlet.
AUDIO OUT
DIGITAL
OUT
TV OUT
COAXIAL
COMPONENT VIDEO OUT
HDMI OUT
AUDIO
IN
STEREO
DIGITAL
AUDIO OUT
DIGITAL
OUT
TV OUT
COAXIAL
COMPONENT VIDEO OUT
HDMI OUT
AUDIO
IN
DIGITAL
AV Receiver
01_dvp5980K_93_eng2.indd 1201_dvp5980K_93_eng2.indd 12 2007-06-25 11:08:59 AM2007-06-25 11:08:59 AM

English
13
Optional connections (continued)
TIPS: Before making or changing any connections, make sure that all the devices are disconnected
from the power outlet.
Connecting a USB Flash Drive or
USB mass storage device
Using USB port
You can only view the content of
following supported USB devices through
this DVD player.
AConnect the supported USB device
directly to the USB port on the front
panel (as shown on the above
illustration).
BPress USB button on the remote
control in order to view the les stored
in the supported USB device.
CStop the playback before removing the
supported USB device from the USB
port.
USB extension cable
(Optional accessory - not supplied)
Tips:
– The USB port supports playback of JPEG/
MP3/WMA les.
– Not all Portable audio/video players and
Digital cameras are supported.
– While connected to a card reader, only
one card can be read at the same time.
– If non-supported USB device is plugged in,
‘Device Not Supported’ will be displayed.
– If the USB device does not t into the USB
port, a USB extension cable is required.
– The format FAT16, FAT32 can be
supported by USB and not NTFS.
01_dvp5980K_93_eng2.indd 1301_dvp5980K_93_eng2.indd 13 2007-06-25 11:08:59 AM2007-06-25 11:08:59 AM

English
14
AUDIO OUT
DIGITAL
OUT
TV OUT
COAXIAL
COMPONENT VIDEO OUT
HDMI OUT
HDMIIN
HDMI IN
HDTV / DVI TV
HDMI connections
TIPS: Before making or changing any connections, make sure that all the devices are disconnected
from the power outlet.
Connecting to a HDMI or
DVI TV
IMPORTANT!
– HDMI connects untouched and
uncompressed digital transmission
for the highest and crispest sound or
image quality.
– It has plug and play capability
using only one HDMI cable for both
audio / video output.
AUse a HDMI cable (not supplied) to
connect the DVD player’s HDMI OUT
to HDMI IN on the HDMI TV.
To hear sound via TV only,
BSet the DVD player’s { HDMI Audio
Setup – On } for HDMI connection (see
Digital Audio Setup – HDMI Audio Setup
for detail).
TIPS: Before making or changing any connections, make sure that all the devices are disconnected
from the power outlet.
OR
IMPORTANT!
– If your TV has a DVI IN jack, you
need a HDMI-DVI adapter cable to
connect the HDMI OUT jack on the
DVD player.
– This HDMI-DVI cable has only
video output capability.
AUse a HDMI-DVI cable (not supplied) to
connect the DVD player’s HDMI OUT
to DVI IN on the DVI TV.
Tip:
– To hear sound from the DVD player, use
one of the audio connection on next page as
there will be no audio output for DVI TV.
01_dvp5980K_93_eng2.indd 1401_dvp5980K_93_eng2.indd 14 2007-06-25 11:08:59 AM2007-06-25 11:08:59 AM

English
15
HDMI connections (continued)
TIPS: Before making or changing any connections, make sure that all the devices are disconnected
from the power outlet.
AUDIO OUT
DIGITAL
OUT
TV OUT
COAXIAL
COMPONENT VIDEO OUT
HDMI OUT
HDMI IN
HDMI
IN
OUT
Connecting to a HDMI/DVI
TV via a HDMI Repeater
AUse a HDMI cable (not supplied) to
connect the DVD player’s HDMI OUT
to HDMI IN on the HDMI repeater.
BUse another cable (not supplied) to
connect HDMI OUT of the HDMI
repeater to the HDMI/DVI IN on a
HDMI/DVI TV.
CSet the DVD player’s { HDMI Audio
Setup – On } for HDMI connection (see
Digital Audio Setup – HDMI Audio Setup
for detail).
Tips:
– During HDMI connection, the DVD player
will turn into HDMI mode automatically.
– Proceed to page 43-44 for detailed HDMI
Video setup.
AUDIO OUT
DIGITAL
OUT
TV OUT
COAXIAL
COMPONENT VIDEO OUT
HDMI OUT
AUDIO
IN
DIGITAL
AV Receiver
OR
A
B
Connecting to an Analog or
Digital AV Receiver
Use a HDMI cable (not supplied) or
HDMI-DVI cable (not supplied) to
connect the DVD player’s HDMI OUT
to HDMI/DVI IN on the HDTV or DVI
TV.
To hear sound via AUDIO OUT
(L/R),
AUse the audio cables (white/red) to
connect AUDIO OUT (L/R) of the DVD
Player to the AV receiver Audio In (cable
supplied).
Set the DVD player’s { HDMI Audio
Setup – Off } (see page 38).
OR
To hear sound via Coaxial/Digital
Out,
BConnect the COAXIAL Digital Out of
the DVD player to the Digital Audio In
on the AV receiver (cable not supplied).
Set the DVD player’s { Digital Output –
ALL } and { HDMI Audio Setup – Off }
(see page 38).
01_dvp5980K_93_eng2.indd 1501_dvp5980K_93_eng2.indd 15 2007-06-25 11:08:59 AM2007-06-25 11:08:59 AM

English
16
Product Overview
Front and Rear Panels
STANDBY-ON 2
– Turns on the player or switches
to standby mode
Disc Tray
OPEN/CLOSE ç
– Opens or closes the disc tray.
Display panel
– Shows information about the
current status of the DVD player.
USB Port
– Input of the supported USB device
STOP
– Stops playback
PLAY/PAUSE u
– Starts or pauses playback.
HD UPSCALE
– Set HDMI output, switches the
resolution to ‘480p’, ‘720p(60Hz)’,
‘1080i(60Hz)’, ‘1080p(60Hz)’,
‘576p’, ‘720p(50Hz)’,
‘1080i(50Hz)’, ‘1080p(50Hz)’.
IR Sensor
– Point the remote control towards
this sensor
AUDIO OUT
DIGITAL
OUT
TV OUT
COAXIAL
COMPONENT VIDEO OUT
HDMI OUT
Mains ~(AC Power Cord)
– Connect to a standard AC outlet
HDMI OUT
– Connect to HDMI compatible
device (example: LCD/Projector/
Plasma/Projection TV, HDTV or
receiver)
TV OUT (CVBS)
– Connect to CVBS Video input of a
television
Y Pb Pr (Component Video Out)
– Connect to YPbPr input of a
television
AUDIO OUT (Left/Right)
– Connect to AUDIO inputs of an
amplier, receiver or stereo
system
COAXIAL (Digital audio out)
– Connect to coaxial AUDIO input
of a digital audio equipment
MIC
– For connecting microphone.
Level
– Microphone volume control.
01_dvp5980K_93_eng2.indd 1601_dvp5980K_93_eng2.indd 16 2007-06-25 11:09:00 AM2007-06-25 11:09:00 AM

English
17
Product Overview (continued)
Remote Control
DISC MENU
– Enters or exits the disc
contents menu
– Switches on or off the
playback control mode (for
VCD 2.0 only)
OK
– Conrms an entry or
selection
RETURN/TITLE
– To go back to previous
menu/ show title menu
PREV í
– Skips to the previous title/
chapter/ track
– Press and hold to fast
backward
STOP
– Stops playback
uPLAY/PAUSE
– Starts or pauses playback
SUBTITLE/DISPLAY
– Selects a subtitle language of
the playing disc (DVD)
– Displays information on TV
screen during playback
ZOOM
– Enlarge a picture on the TV
screen
VOCAL
– Choose audio channels or
karaoke methods
KARAOKE
– To toggle between ‘Mic’,
‘Vol’, ‘Echo’ or ‘Key’
2
– To switch the DVD player
to standby mode or ON
OPEN/CLOSE ç
– Opens or closes the disc
tray
WX
– Cursor buttons for moving
to the left or right, do a fast
forward/reverse search.
ST
– Cursor buttons for moving
up/down, do a slow
forward/backward
SETUP
– Enters or exits the system
setup menu
NEXT ë
– Skips to the next title/
chapter/track
– Press and hold to fast
forward
USB
– Access the content of the
connected USB device and
exit from USB mode
Alphanumeric keypad
– Selects numbered items in
a menu
AUDIO
– Selects an audio language
(DVD/VCD) or an audio
channel
01_dvp5980K_93_eng2.indd 1701_dvp5980K_93_eng2.indd 17 2007-06-25 11:09:01 AM2007-06-25 11:09:01 AM

English
18
Step 1: Inserting Batteries
AOpen the battery compartment.
BInsert two batteries type R03 or AAA,
following the indications (+ –) inside the
compartment.
CClose the cover.
CAUTION!
– Remove batteries if they are
exhausted or if the remote is not to
be used for a long time.
– Do not use old and new or
different types of batteries in
combination.
– Batteries contain chemical
substances, so they should be
disposed of properly.
Using the remote control to
operate the system
AAim the remote control directly at the
remote sensor (IR) on the front panel.
BDo not put any objects between the
remote control and the DVD player
while operating the DVD player.
Step 2: Finding your viewing
channel
APress STANDBY-ON 2on the DVD
player to turn it on.
BTurn on the TV and set it to the correct
video-in channel. You should see the blue
DVD background screen.
Usually these channel are between the
lowest and highest channels and may
be called FRONT, A/V IN, VIDEO.
See your TV’s manual for more
details.
Or, you may go to channel 1 on your
TV, then press the Channel down
button repeatedly until you see the
Video In channel.
Or, the TV remote control may have
a button or turn that chooses
different video modes.
CIf you are using external equipment, (such
as audio system or receiver), turn it on
and select the appropriate input source
for the DVD player output. Refer to the
equipment user’s manual for detail.
Getting Started
01_dvp5980K_93_eng2.indd 1801_dvp5980K_93_eng2.indd 18 2007-06-25 11:09:01 AM2007-06-25 11:09:01 AM

English
19
Getting Started (continued)
Step 3: Setting up
Progressive Scan
feature
(for Progressive Scan TV only)
The progressive scan displays twice the
number of frames per seconds than
interlaced scanning (ordinary normal TV
system). With nearly double the number
of lines, progressive scan offers higher
picture resolution and quality.
Before you start...
– Ensure that you have connected this
DVD player to a progressive scan TV
using the Y Pb Pr connection (see page
10).
– Ensure that you have completed the
basic installation and setup.
ATurn on your TV and set to interlace
mode (refer to your TV user manual).
BPress STANDBY-ON 2on the
remote control to turn on the DVD
player.
CSelect the correct video-in channel.
 The DVD background menu appears.
DPress SETUP.
EPress Xto select { Video Setup Page }.
TV Type
TV Display
Progressive On
Picture Setting Off
Video Setup Page
HD JPEG
HDMI Video Setup
FPress ST repeatedly to select
{ Progressive }, then press X.
GSelect { On }, then press OK to conrm.
 The menu will appear on the TV.
ACTIVATING PROGRESSIVE SCAN:
1.ENSURE YOUR TV HAS PROGRESSIVE SCAN.
2.CONNECT USING YPBPR(GBR) VIDEO CABLE.
3.IF THERE IS A DISTORTED PICTURE,
WAIT 15 SECONDS FOR AUTO RECOVERY.
OK CANCEL
HPress Wto highlight { OK } and press
OK to conrm.
ITurn on your TV progressive scan mode
(refer to your TV user manual).
 The menu will appear on the TV.
CONFIRM AGAIN TO USE PROGRESSIVE
SCAN. IF PICTURE IS GOOD,
PRESS OK BUTTON ON REMOTE.
OK CANCEL
JPress Wto highlight { OK } and press
OK to conrm..
 The setup is now completed and you
can start enjoy the high quality
picture.
To deactivate Progressive Scan
manually:
 Wait for 15 seconds for the auto
recovery.
OR
APress OPEN/CLOSE çon the DVD
player to open the disc tray.
BPress numeric keypad ‘1’ on the
remote control for few seconds.
 The DVD background screen appears.
Tip:
– There are some progressive scan TVs and
High-Denition TVs that are not fully
compatible with this unit, resulting in the
unnatural picture when playing back a DVD
VIDEO disc in the progressive scan mode. In
such a case, turn off the progressive scan
feature on both the DVD player and your TV.
TIPS: The underlined option is the factory default setting.
Press Wto go back to previous menu item. Press SETUP to exit the menu item.
01_dvp5980K_93_eng2.indd 1901_dvp5980K_93_eng2.indd 19 2007-06-25 11:09:01 AM2007-06-25 11:09:01 AM

English
20
Getting Started (continued)
TIPS: The underlined option is the factory default setting.
Press Wto go back to previous menu item. Press SETUP to exit the menu item.
Step 4: Selecting the
matching color
system
The color system of the DVD player, disc
and TV should match in order for the
disc to play. Before changing the TV
system, determine the color system of
your TV.
TV Type
TV Display
Progressive
Picture Setting
Video Setup Page
HD JPEG
HDMI Video Setup
NTSC
PAL
Multi
APress SETUP.
BPress Xto select { Video Setup Page }.
CPress ST repeatedly to select
{ TV Type }, then press X.
DUse ST to select one of the options
below:
{ PAL }
Select this if the connected TV has the
PAL color system. It will change the
video signal of an NTSC disc and output
it to PAL format.
{ NTSC }
Select this if the connected TV has the
NTSC color system. It will change the
video signal of a PAL disc and output it to
NTSC format.
{ Multi }
Select this if the connected TV is
compatible with both NTSC and PAL
(multi-system). The output format will be
in accordance with the video signal of the
disc.
ESelect a setting and press OK.
 Follow the instructions show on the
TV to conrm the selection.
CHANGING PAL TO NTSC:
1.ENSURE THAT YOUR TV SUPPORTS
NTSC STANDARD.
2.IF THERE IS A DISTORTED PICTURE
DISPLAYED ON THE TV , WAIT 15
SECONDS FOR AUTO RECOVERY.
OK CANCEL
CONFIRM AGAIN TO USE NEW TV
TYPE SETTING.
OK CANCEL
FPress Wto highlight { OK } and press
OK to conrm.
To reset to previous TV color
system:
 Wait for 15 seconds for the auto
recovery.
OR
APress OPEN/CLOSE çon the DVD
player to open the disc tray.
BPress numeric keypad ‘3’ on the
remote control for few seconds.
 The DVD background menu appears.
Tips:
– Before changing the current TV colour
setting, ensure that your TV supports the
‘selected TV Type’ system.
– If there is no proper picture on your TV,
wait for 15 seconds for auto recovery.
01_dvp5980K_93_eng2.indd 2001_dvp5980K_93_eng2.indd 20 2007-06-25 11:09:01 AM2007-06-25 11:09:01 AM
