DVD Video and Picture Recorder
Record electronic pictures
and camcorder tapes on
DVD and play them on TV.
Best Picture
• i.LINK digital connection: For perfect recording from digital camcorders
• Progressive Scan output: For razor-sharp picture output
• Component Video Inputs: For the best analog recording input
Best Sound
• 2-channel Dolby Digital audio recording: For digital quality stereo sound
• 24-bit digital-to-analog conversion: For top quality sound
Great Convenience
• Over 3600 pictures on DVD!
• PCMCIA media slot: For your memory card
• Fast transfer from memory card to DVD: No cables, no software installation
• Up to 6 hours video recording
• Index Picture Screen: For visual Table Of Contents
• Favorite Scene Selection: For easy editing of your home movies
• Multibrand Remote
• Fit to space
• Digital Photo and music manager: For simple user interface
Favorite
Scene Selection

77
77
DVDR
DVDR
DVD Video Picture Recorder
Standard product information
Disc types Playback Recording
DVD+RW ••
DVD+R ••
Picture DVD ••
Picture CD •—
DVD-R/-RW, video mode •—
DVD-Video •—
Video CD, Super VCD •—
Audio CD •—
MP3 CD •—
CD-R/RW •—
Video Format
Digital compression DVD, SVCD: MPEG2
VCD: MPEG1
Mode Rec. Resolution Bit rate (bit/s)
time Video Audio
(Mbit/s) (kbit/s)
M1 60’ D1 9.72M 384k
M2 120' D1 5.07M 256k
M2.5 150’ D1 4.06M 256k
M3 180' _D1 3.38M 256k
M4 240’ _D1 2.54M 256k
M6 360’ _D1 1.70M 256k
Resolution H x V (pixels) 60Hz
Full D1 (DVD-Video) 7201x 480
Half D1 3602x 480
SIF (VCD) 352 x 240
1equivalent to 500 analog TV lines
2equivalent to 250 analog TV lines
TV Standard NTSC PAL/SECAM
Scan frequency 60Hz 50Hz
Number of lines 525 625
Playback ••
Recording ••
Internal tuner •—
Video Performance
DA Converter: 10 bit
AD Converter: 9 bit
Signal handling: Components
Video (CVBS) out: 1 Vpp into 75 ohm
S-video (Y/C) out: Y: 1 Vpp into 75 ohm
C: 0.286 1Vpp into 75 ohm
Component/Progressive
video out (YPBPR):Y: 1 Vpp into 75 ohm
PB: 0.7 Vpp into 75 ohm
PR: 0.7 Vpp into 75 ohm
Audio Format Playback Recording
Compressed digital
•Dolby Digital 5.1- 2-channel
(AC-3) channel* 16-bit, 48 kHz
•DTS, MPEG2 5.1-channel* —
•MPEG1, MP3 2-channel —
*6.1-channel compatible
Recording functions
•Safe Record
•One-Touch Record (OTR)
•Append
•Divide
•Erase
•Automatic/Manual Chapter Marker insertion
•Disc write protection
•Favorite Scene Selection
•Index Picture Screen for instant content overview
•Selectable Index Pictures
DVD/CD playback
•Fast Forward/Backward (3 speeds)
•Step Forward/Backward
•Slow (3 speeds)
•Direct Title/Track access
•Next/Previous Title/Track/Chapter
•Repeat (Chapter/Title/All) or (Track/All)
•A-B Repeat
•Shuffle
•Intro Scan
•Time Search
•Zoom (1.33x, 2x, 4x) with picture enhancement
•Auto Resume (20 discs)
Power Supply
Mains: polarised (IEC)
Power supply: 90..140 VAC (120 V nom)
50/60 Hz
Power consumption Operation 31 W
Low- 7 W
power
standby
Cabinet
Dimensions (W x H x D): 17.12 x 2.55 x 13.18 inches
Net Weight: 8.81 LB
Remote Control
•46-key remote control
Package Contents
•DVD Video Recorder
•Remote Control + batteries
•User Manual in English
•DVD+RW disc
•AC power cable
•Stereo audio cable
•Video cable
•S-video cable
•Coax digital audio cable
•Coax RF antenna cable
Philips Consumer Electronics
Data subject to change without notice
600669
Printed in U.S.A.
2002© Koninklijke Philips Electronics N.V.
All rights reserved
www.philips.com or AOL keyword: Philips
VCR Plus+ is trademarks of Gemstar Development Corp. – Dolby
Digital and the double-D symbol are trademarks of Dolby Laboratories
Licensing, Inc. DTS is a trademark of Digital Theater Systems, Inc. –
TruSurround, SRS and the symbol (l) are trademarks of SRS Labs, Inc.
SPDIF
•PCM 2-channel —
16/20/24 bit
48/96 kHz
Audio Performance
DA Converter: 24 bit
AD Converter: 16 bit
Signal/Noise (1kHz): 95 dB
Dynamic range (1kHz): 85 dB
Crosstalk (1kHz): 95 dB
Distortion/Noise (1kHz): 85 dB
Front Connections
Memory card slot: PCMCIA type II
i.LINK DV in: IEEE 1394 4-pin
S-video in: Hosiden 4-pin
Video in: Cinch (yellow)
Audio Left/Right in: Cinch (white/red)
Rear Connections
Component video in Cinch (green/blue/red)
Progressive Scan/Component
video out: Cinch (green/blue/red)
S-video in: Hosiden 4-pin
S-video out: Hosiden 4-pin
Video in: Cinch (yellow)
Video out: Cinch (yellow)
Audio L/R in (2x): Cinch (white/red)
Audio L/R out (2x): Cinch (white/red)
Digital audio out: Coaxial, Optical
RF antenna in: Coaxial 75 ohms (F type)
RF TV out: Coaxial 75 ohms (F type)
Mains: Standard (IEC type)
User Interface
OSD languages: English, French, Spanish
Electronic Program Guide
Timer programming:VCR Plus+/Manual
Number of events: 6; 1 year; daily/weekly
Digital Photo Manager
•PCMCIA slot compatible with Memory Stick,
Compact Flash, SD card, Smart Media, Micro Drive
•Recording on DVD+RW/+R
•Up to 3,600 pictures per DVD
•Two-way transfer between memory card and DVD
•Picture formats supported: EXIF-compliant JPEG
•Slide show
•Zoom (2 x. 4x, 6x)
•Rotate
General Functionality
•3D Sound
•Automatic Screen Saver
•Backup Presets & Timer Events: 1 year
•Backup Clock & Calendar: 5 hrs
•Time & Date Download
•Automatic Audio Recording Level Control
