Philips HQ7180 User manual

ServiceManual
Philips Domestic Appliances and Personal Care
Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands © Copyright reserved Subject to modification
Shaver
HQ7180
06/10
PRODUCT INFORMATION
General:
- Mains/rechargeable operation
- World-wide automatic voltage selection
- Electronic on/off switch
- Washable
Safety information
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
TECHNICAL INFORMATION
- Voltage : 100 - 240 Volt / 50 - 60 Hz
- Motor voltage : 1,2 Volt
- Shaving heads : HQ8 - 4222 036 05820
- SAP coding : HQ7180
DISASSEMBLY- AND RE-ASSEMBLY ADVICE
Disassembly:
- Remove shaving unit, to prevent damaging during
repairing.
- Remove the 2 screws (A) out of the hairchamber.
- Remove the hairchamber from the body.
- Remove the 2 screws (B) on the backside of the shaver.
- Remove the cover.
- Remove the side grips.
- Remove the housing by bending the hooks with a
screwdriver.
- Take out the basic body.
REPAIR INSTRUCTION
- No specific issues
OPTIONAL (accessories)
- Car cord : 4222 036 08920
- Pouch : 4222 036 14160

HQ7180
EXPLODED VIEW & PARTS LIST
3
7
B
11
10
12
1
2
4
5
8
9
6A
Pos Service code Description
1
2
3
4222 036 12600
4222 036 12610
4222 036 04080
4222 036 04090
4222 036 04020
4222 036 04000
4222 036 04030
4222 036 04040
4222 036 08930
4222 036 06800
Protection cap Cheetah
Bracket-assy
Power plug EUR
Power plug GBR
Power plug AUS
Power plug KOR
Power plug MEX
Power plug PRC
Power plug JAP
Power plug Can/Tw/Ven
Pos Service code Description
4
5
6
7
8
9
10
11
12
4222 036 05820
4222 036 12990
4222 036 12640
4222 036 12810
4222 036 12570
4222 036 12550
4222 036 02770
4222 036 12220
4222 036 12740
4222 036 11480
Shaving heads
Holder-assy
Hairchamber
Basic body
Grip left & right
Housing-assy
Brush
Trimmer assy
Back shell assy
Screw
