Philips HQ7890/22 User manual

HQ7895, HQ7890

1 2 3 4
56 7 8
9 10 11 12
13 14 15 16
17 18 19 20

HQ7895, HQ7890
ENGLISH 6
DANSK 18
DEUTSCH 30
ESPAÑOL 44
SUOMI 57
FRANÇAIS 69
NEDERLANDS 82
NORSK 95
 107
SVENSKA 120
ITALIANO 132

6
Introduction
Congratulations on your purchase and welcome to Philips! To fully benet
from the support that Philips offers, register your product at
www.philips.com/welcome.
Important
Read this user manual carefully before you use the shaver and the
Jet Clean system. Save the user manual for future reference.
Danger
- Make sure the adapter does not get wet (Fig. 1).
Warning
- Be careful with hot water.Always check if the water is not too hot,
to prevent your hands from getting burnt.
- The adapter contains a transformer. Do not cut off the adapter to
replace it with another plug, as this causes a hazardous situation.
- The shaver and the Jet Clean system are not intended for use by
persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliances by a
person responsible for their safety.
- Children should be supervised to ensure that they do not play with
the shaver and the Jet Clean system.
Caution
- Do not use the shaver or the Jet Clean system if it is damaged.
- Do not immerse the shaver in water (Fig. 2).
- This shaver is not suitable for shaving in the shower.
- Charge, use and store the shaver at a temperature between 5°C and
35°C.
- Water may leak from the socket at the bottom of the shaver when
you rinse it.This is normal and not dangerous because all electronics
are enclosed in a sealed power unit inside the shaver (Fig. 3).
- Always put the protection cap on the shaver to protect the shaving
heads when you are travelling.
ENGLISH

- The shaver, the Jet Clean system and the other accessories are not
dishwasher-proof.
- Only use the adapter supplied.
- If the adapter is damaged, always have it replaced with one of the
original type in order to avoid a hazard.
- Only use the Jet Clean systemwith the original HQ200 cleaning uid.
- Do not immerse the Jet Clean system in water nor rinse it under the
tap. (Fig. 4)
- Use and store the Jet Clean system at a temperature between 5°C
and 35°C.
- Always place the Jet Clean system on a stable, level and horizontal
surface to prevent leakage.
- Always place the Jet Clean system on a uid-resistant surface.
- When the Jet Clean system is ready for use, do not move it to prevent
leakage of cleaning uid.
- The Jet Clean system thoroughly cleans but does not disinfect your
shaver, therefore do not share the shaver with others.
Compliance with standards
- The shaver complies with the internationally approved IEC safety
regulations and can be safely cleaned under the tap (Fig. 5).
- The shaver and the Jet Clean system comply with all standards
regarding electromagnetic elds (EMF). If handled properly and
according to the instructions in this user manual, the appliances are
safe to use based on scientic evidence available today.
General
- The adapter transforms 100-240 volts to a safe low voltage of less
than 24 volts.
ENGLISH 7

Charging
Make sure the shaver is switched off before you charge it.
Charging takes approx. 1 hour.
You can also shave without charging by connecting the shaver to the mains.
A fully charged shaver has a cordless shaving time of up to 55 minutes.
1 Chargetheshaverwhenthebottomlightashesorange.
Charge indications
Charging
- When you start charging the empty shaver, the bottom light ashes
orange.When the battery contains enough power for one shave, the
middle charging light starts ashing green (Fig. 6).
Battery fully charged
- When the battery is fully charged, the top charging light lights up
green continuously.
Battery low
- When the battery is almost empty i.e. when there are only 5 or less
shaving minutes left, the bottom charging light starts to ash orange.
When you switch off the shaver, this light still ashes orange a few times.
Charging with the adapter
1 Puttheapplianceplugintheshaver(Fig.7).
2 Puttheadapterinthewallsocket.
3 Remove the adapter from the wall socket and pull the appliance
plugoutoftheshaverwhenthebatteryisfullycharged.
Charging in the Jet Clean system
1 Place the shaver in the holder and completely push down the lever
tolocktheshaverintoplace(Fig.8).
,ThecharginglightontheJetCleansystemashestoindicatethat
theshaverischarging.
,Whenthecharginglightlightsupcontinuously(afterapprox.1
hour),theshaverisfullycharged(Fig.9).
ENGLISH8

2 Movetheleverupwardsuntilitdoesnotgoanyfurther(1)and
removetheshaverfromtheJetCleansystem(2).(Fig.10)
,Thecharginglightgoesout.
Using the shaver
Shaving
1 Presstheon/offbuttononcetoswitchontheshaver.
2 Move the shaving heads over your skin in circular
movements(Fig.11).
- Shaving on a dry face gives the best results.
- Your skin may need 2 or 3 weeks to get accustomed to the Philips
shaving system.
Note: Do not make straight movements.
3 Presstheon/offbuttononcetoswitchofftheshaver.
4 Cleantheshaver(seechapter‘Cleaningandmaintenance’).
5 Puttheprotectioncapontheshavereverytimeyouhaveusedit,
topreventdamage(Fig.12).
Trimming
You can use the trimmer to groom your sideburns and moustache.
1 Pushtheslidedownwardstoopenthetrimmer(Fig.13).
Note:You can activate the trimmer while the motor is running.
2 Closethetrimmer(‘click’)(Fig.14).
ENGLISH 9

Cleaning and maintenance
The best and most hygienic way to clean the shaver is in the Jet Clean
system.You can also clean the shaver by rinsing it under the tap or with
the brush supplied.
Regular cleaning guarantees better shaving performance.
Note:Water may leak from the socket at the bottom of the shaver when you
rinse it.This is normal and not dangerous.
Cleaning the shaver in the Jet Clean system supplied
Preparing the Jet Clean system for use
Fill the cleaning chamber before rst use and when the cleaning light
ashes to indicate that the uid level is too low. When the uid level
drops below the minimum level, the cleaning light ashes with intervals
and the holder returns to its starting position.
If you use the Jet Clean system to clean the shaver every day, rell the
cleaning chamber approx. every 15 days.
1 Simultaneously press the release buttons on both sides of the
cleaningchamber(1)andlifttheJetCleansystemoffthecleaning
chamber(2)(Fig.15).
The cleaning chamber remains behind.
2 Unscrew the dosing cap from the bottle with HQ200 Cleaning
Fluidandremovetheairtightseal.
3 FillthecleaningchamberwithcleaninguiduptotheMAX
indication(Fig.16).
4 PlacetheJetCleansystembackontothecleaningchamber(Fig.17).
Make sure the release buttons snap back into place.
5 Put the appliance plug in the Jet Clean system and put the adapter
inthewallsocket(Fig.18).
,Theholderautomaticallymovestothehighestposition.
The Jet Clean system is now ready for use.
ENGLISH10

Using the Jet Clean system
1 Place the shaver in the holder and completely push down the lever
tolocktheshaverintoplace.
,ThecharginglightontheJetCleansystemashestoindicatethat
theshaverisbeingcharged.
2 Pressthestartbuttontostartthecleaningprogram.(Fig.19)
The cleaning light starts ashing and the shaver is automatically lowered
into the cleaning uid.
,Duringthecleaningprogram,whichtakesapprox.1hour,the
cleaninglightashescontinuously.
,Duringtherstphaseofthecleaningprogram,theshaver
automatically switches on and off several times and is put in
differentpositions.
,Duringthesecondphaseofthecleaningprogram,theshaveris
placedinthedryingposition.Itstaysinthispositionuntiltheend
oftheprogram.Thecleaninglightlightsupcontinuously.
,Afterthecleaningprogram,theshaverautomaticallyreturnstoits
startingpositionandstartscharging.ThecharginglightontheJet
Cleansystemashes.
Note: If you press the start button or open the lever during cleaning, the
cleaning program is aborted and reset. In this case, the cleaning light stops
ashing and the holder returns to its starting position.
Note: If the adapter is removed from the wall socket during cleaning, the
cleaning program is aborted.The holder remains in its current position.When
the adapter is put back into the wall socket, the holder moves to the highest
position.
Note: If the uid volume in the cleaning chamber drops below the minimum
level during the cleaning program, the program is aborted.The cleaning
light ashes with intervals and the holder returns to its starting position.
Cleaning the Jet Clean system
The cleaning chamber is not dishwasher-proof.
Clean the cleaning chamber every two weeks.
ENGLISH 11

1 Simultaneously press the buttons on both sides of the Jet Clean
system(1)andlifttheJetCleansystemoffthecleaningchamber
(2).(Fig.20)
The cleaning chamber remains behind.
2 Pouranyremainingcleaninguidoutofthecleaning
chamber.(Fig.21)
You can simply pour the cleaning uid down the sink.
3 Rinsethecleaningchamberunderthetap(Fig.22).
4 PlacetheJetCleansystembackontothecleaningchamber(Fig.23).
Make sure the release buttons snap back into place.
5 CleantheJetCleansystemwithamoistcloth.
Cleaning the shaver under the tap
Becarefulwithhotwater.Alwayscheckifthewaterisnottoohot,to
preventyourhandsfromgettingburnt.
1 Switchofftheshaver,removetheadapterfromthewallsocketand
pulltheapplianceplugoutoftheshaver.
2 Pressthereleasebuttontoopentheshavingunit(Fig.24).
3 Rinse the hair chamber and the inside of the shaving unit under a
hottapforsometime(Fig.25).
4 Rinse the outside of the shaving unit under a hot tap for some
time(Fig.26).
5 Closetheshavingunitandshakeoffexcesswater.
Neverdrytheshavingunitwithatowelortissue,asthismaydamage
theshavingheads.
6 Open the shaving unit again and leave it open to let the shaver dry
completely(Fig.27).
You can also clean the hair chamber without water with the brush supplied.
ENGLISH12

Extra-thorough cleaning method
1 Switchofftheshaver,removetheadapterfromthewallsocketand
pulltheapplianceplugoutoftheshaver.
2 Opentheshavingunit,turnthelockanticlockwise(1)andremove
theretainingframe(2)(Fig.28).
3 Cleanthecuttersandguardswiththebrushsupplied(Fig.29).
Note: Do not clean more than one cutter and guard at a time, since they are
all matching sets. If you accidentally mix up the cutters and guards, it may
take several weeks before optimal shaving performance is restored.
4 Puttheshavingheadsbackintotheshavingunit.Puttheretaining
framebackintotheshavingunitandturnthelockclockwise(Fig.30).
5 Closetheshavingunit.
Cleaning the trimmer
Clean the trimmer every time you have used it.
1 Switchofftheshaver,removetheadapterfromthewallsocketand
pulltheapplianceplugoutoftheshaver.
2 Cleanthetrimmerwiththebrushsupplied(Fig.31).
3 Lubricate the trimmer teeth with a drop of sewing machine oil
everysixmonths(Fig.32).
Storage
There are two ways to store the shaver:
- put the protection cap on the shaver to prevent damage (Fig. 12).
- store the shaver in the Jet Clean system (Fig. 33).
Replacement
For optimal shaving performance, we advise you to replace the shaving
heads every 2 years.
Replace damaged or worn shaving heads with HQ8 Philips Shaving
Heads only.
ENGLISH 13

Note: Do not mix up the cutters and the guards to guarantee optimal
shaving performance.
1 Switchofftheshaver,removetheadapterfromthewallsocketand
pulltheapplianceplugoutoftheshaver.
2 Pressthereleasebuttontoopentheshavingunit.
3 Turnthelockanticlockwise(1)andremovetheretainingframe
(2)(Fig.28).
4 Removetheshavingheadsandplacenewonesintheshavingunit.
Put the retaining frame back into the shaving unit and turn the lock
clockwise(Fig.34).
Makesurethattheprojectionsoftheshavingheadstexactlyinto
therecesses.
5 Closetheshavingunit.
Accessories
The following accessories are available:
- HQ8 Philips Shaving Heads.
- HQ110 Philips Shaving Head Cleaning Spray.
- HQ8010 Car Cord.
- HQ200 Philips Cleaning Fluid.
Environment
- Do not throw away the shaver and the Jet Clean system with the
normal household waste at the end of their life, but hand them in at
an ofcial collection point for recycling. By doing this, you help to
preserve the environment (Fig. 35).
- The built-in rechargeable shaver battery contains substances that may
pollute the environment.Always remove the battery before you
discard and hand in the shaver at an ofcial collection point. Dispose
of the battery at an ofcial collection point for batteries. If you have
trouble removing the battery, you can also take the shaver to a Philips
service centre.The staff of this centre will remove the battery for you
and will dispose of it in an environmentally safe way (Fig. 36).
ENGLISH14

Removing the rechargeable shaver battery
Onlyremovethebatteryifitiscompletelyempty.
1 Remove the adapter from the wall socket and pull the appliance
plugoutoftheshaver.
2 Let the shaver run until it stops and undo the two screws in the
backoftheshaver(Fig.37).
3 Undothetwoscrewsinthehairchamber(Fig.38).
4 Undothethreescrewsinthepowerunit(Fig.39).
5 Bendthe4hooksaside(1)totakeoutthepowerunit(2)(Fig.40).
Be careful, the hooks are very sharp.
6 Removethepowerunitcoverwithascrewdriver(Fig.41).
7 Removetherechargeablebattery.
Be careful, the battery strips are very sharp.
Do not connect the shaver to the mains again after you have removed
thebattery.
Guarantee and service
If you need service or information or if you have a problem, please visit
the Philips website at www.philips.com or contact the Philips Consumer
Care Centre in your country (you nd its phone number in the worldwide
guarantee leaet). If there is no Consumer Care Centre in your country,
go to your local Philips dealer.
Guarantee restrictions
The shaving heads (cutters and guards) are not covered by the terms of
the international guarantee because they are subject to wear.
ENGLISH 15

Troubleshooting
Problem Solution
The shaver
does not shave
as well as it
used to.
The Jet Clean system may not have cleaned the shaver
properly because the cleaning uid in the cleaning
chamber is soiled or the cleaning uid level is too low.
Clean the shaver thoroughly before you continue
shaving. If necessary, clean and rell the cleaning
chamber (see chapter ‘Cleaning and maintenance’).
The shaving heads may be damaged or worn.
Replace the shaving heads (see chapter
‘Replacement’).
Long hairs may obstruct the shaving heads. Clean
the cutters and guards with the brush supplied
(see chapter ‘Cleaning and maintenance’).
The shaver
does not work
when I press
the on/off
button.
The battery may be empty. Recharge the battery
(see chapter ‘Charging’) or connect the shaver to
the mains.
The shaver may not be connected to the mains. Put
the appliance plug in the shaver and put the adapter
in the wall socket.
The shaving unit
has come off
the shaver.
The shaving unit was not placed correctly. Put the
shaving unit back onto the shaver by inserting the
hinge into the slot in the rim of the hair chamber.
Then push the shaving unit home until it locks into
place (‘click’).
ENGLISH16

Problem Solution
The shaver is
not entirely
clean after I
clean it in the
Jet Clean system.
The cleaning uid in the cleaning chamber may be
soiled. Empty and rinse the cleaning chamber.
The cleaning uid level may be too low. If the uid
volume in the cleaning chamber drops below the
minimum level during the cleaning program, the
program aborts. The cleaning light ashes with
intervals and the holder returns to its starting
position. Rell the cleaning chamber with cleaning
uid up to the MAX indication
(see chapter ‘Cleaning and maintenance’).
You may have used another cleaning uid than the
original Philips cleaning uid. Only use Philips HQ200
Cleaning Fluid.
The Jet Clean
system does
not work when
I press the on/
off button.
The Jet Clean system may not be connected to the
mains. Put the appliance plug in the Jet Clean system
and put the adapter in the wall socket.
You have not placed the shaver in the Jet Clean system
properly. Make sure you push down the lever
completely to lock the shaver into place.
ENGLISH 17

18
Introduktion
Tillykke med dit køb og velkommen til Philips! For at få fuldt udbytte
af den support, Philips tilbyder, skal du registrere dit produkt på
www.philips.com/welcome.
Vigtigt
Læs denne brugervejledning grundigt, før du tager shaveren og Jet
Clean-systemet i brug. Gem brugervejledningen til eventuel senere brug.
Fare
- Sørg for, at adapteren ikke bliver våd (g. 1).
Advarsel
- Vær forsigtig med varmt vand. Kontroller altid, at vandet ikke er for
varmt, så du ikke skolder dine hænder.
- Adapteren indeholder en transformer. Adapteren må ikke klippes af
og udskiftes med et andet stik, da dette vil forårsage en farlig situation.
- Shaveren og Jet Clean-systemet er ikke beregnet til at blive brugt af
personer (herunder børn) med nedsatte fysiske og mentale evner,
nedsat følesans eller manglende erfaring og viden, medmindre de er
blevet vejledt eller instrueret i apparatets anvendelse af en person,
der er ansvarlig for deres sikkerhed.
- Shaveren og Jet Clean-systemet bør holdes uden for børns
rækkevidde for at sikre, at de ikke kan komme til at lege med
apparaterne.
Forsigtig
- Brug ikke shaveren eller Jet Clean-systemet, hvis en af delene er
beskadiget.
- Kom aldrig shaveren ned i vand (g. 2).
- Denne shaver er ikke beregnet til brug i brusebadet.
- Shaveren skal oplades, anvendes og opbevares ved en temperatur
mellem 5°C og 35°C.
- Når shaveren rengøres, kan der dryppe lidt vand ud af stikket i
bunden. Dette er helt normalt og ganske ufarligt, da al elektronikken
er indkapslet i en forseglet motorenhed inde i shaveren (g. 3).
DANSK

- Sæt altid beskyttelseskappen på shaveren for at beskytte skærhovederne,
når du rejser.
- Shaveren, Jet Clean-systemet og det øvrige tilbehør tåler ikke
opvaskemaskine.
- Brug kun den medfølgende adapter.
- Hvis adapteren beskadiges, skal den altid udskiftes med en original
adapter af samme type for at undgå en farlig situation.
- Anvend kun Jet Clean-systemet med den originale HQ200-rensevæske.
- Jet Clean-systemet må ikke kommes ned i vand eller skylles under
vandhanen. (g. 4)
- Brug og anvend Jet Clean-systemet ved en temperatur mellem 5°C
og 35°C.
- Placer Jet Clean-systemet på et stabilt, plant og vandret underlag for
at undgå lækage.
- Placer altid Jet Clean-systemet på et underlag, som kan tåle at blive
vådt.
- For at undgå udsivende rensevæske må Jet Clean-systemet ikke
yttes, når det er klar til brug.
- Jet Clean-systemet renser din shaver meget grundigt, men desincerer
den ikke. Derfor bør du ikke dele shaveren med andre.
Overholdelse af standarder
- Produktet opfylder de internationalt godkendte IEC-sikkerhedsregler
og kan skylles under rindende vand uden risiko (g. 5).
- Shaveren og Jet Clean-systemet overholder alle standarder for
elektromagnetiske felter (EMF).Ved korrekt anvendelse i
overensstemmelse med instruktionerne i denne brugervejledning er
apparaterne sikre at anvende ifølge den videnskabelige viden, der er
tilgængelig i dag.
Generelt
- Adapteren omformer 100 - 240 Volt til en sikker lavspænding under
24Volt.
DANSK 19

Opladning
Sørg for, at shaveren er slukket, inden du starter opladningen.
En fuld opladning tager ca. 1 time.
Shaveren kan også anvendes uden opladning, blot den tilsluttet en stikkontakt.
En fuldt opladet shaver giver en ledningsfri brugstid på op til 55 minutter.
1 Opladshaveren,nårdennedersteindikatorblinkerorange.
Opladningsindikatorer
Opladning
- Når opladning af shaveren påbegyndes, blinker den nederste
opladeindikator orange. Så snart batterikapaciteten er høj nok til
én barbering, begynder den midterste opladeindikator at blinke
grønt (g. 6).
Batteri fuldt opladet
- Når batteriet er fuldt opladet, lyser den øverste opladeindikator
grønt konstant.
Lavt batteriniveau
- Når batteriet næsten er tomt - dvs. når der er 5 eller færre
barberingsminutter tilbage, begynder den nederste
opladeindikator at blinke orange.
Når du slukker for shaveren, blinker indikatoren orange et par gange.
Opladning med adapter
1 Sætapparatstikketindishaveren(g.7).
2 Slutadapterentilstikkontakten.
3 Nårshaverenerladetheltop,tagesadapterenudafstikkontakten
ogapparatstikketudafshaveren.
DANSK20
