ServiceManual
Philips Domestic Appliances and Personal Care
Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands © Copyright reserved Subject to modification
Shaver
HQ9170
QUASAR
06/09
PRODUCT INFORMATION
General:
- Rechargeably / Mains operation
- World-wide automatic voltage selection
- Electronic on/off button
- Washable
Safety information
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
TECHNICAL INFORMATION
- Voltage : 100 - 240 Volt / 50- 60 Hz
- Motor voltage : 3,6 Volt
- Shaving heads : HQ9 - 4222 036 11150
- Battery : Li-ion
- Display : Multi-purpose LCD
- SAP coding : HQ9170
Shaving Performance:
If customers complain about poor shaving performance
of the triple-track shaving heads, replacing the driving
unit is recommended.
HQ9170
2-3
Disassembly:
- Remove shaving unit, to prevent damaging during
repairing.
- Remove the two screws (A) on the backside of the shaver.
- Remove the three screws (B) from the innerhousing.
- Remove the mains from the motor by turning and pulling
the wires out of the motor.
- Remove the two screws (C) for the hairchamber.
- Bent the sideflaps outside and remove the hairchamber.
Think by placing this sideflaps on the nocks.
- Remove driving unit.
DISASSEMBLY- AND RE-ASSEMBLY ADVICE
- Remove the trimmer from the hairchamber by pushing the
black nock by a small screwdriver inside the spring, to the
inside.
REPAIR INSTRUCTION
- No specific issues
OPTIONAL (accessories)
- Pouch : 4222 036 11560
- Stand : 4222 036 11030
- Car cord : 4222 036 08920
- Washing machine Jet clean II : 4222 036 14000
11
2
1
2
Pos Service code Description
1
2
3
4
5
6
7
8
4222 036 11420
4222 036 11030
4222 036 04080
4222 036 04090
4222 036 05110
4222 036 03870
4222 036 04850
4222 036 05120
4222 036 04040
4222 036 03810
4222 036 11100
4222 036 11110
4222 036 02770
4222 036 11150
4222 036 11170
Housing shell assy
Stand
Power plug EUR
Power plug GBR
Power plug Can/Tw/Ven
Power plug JAP
Power plug KOR
Power plug AUS/NZ
Power plug PRC
Power plug MEX
Protection cap Quasar
Bracket assy
Brush
Shaving head 9-series
Power supply
Pos Service code Description
9
10
11
12
13
14
15
16
17
18
A
B
C
4222 036 11220
4222 036 11230
4222 036 11400
4222 036 11250
4222 036 11270
4222 036 11280
4222 036 11290
4222 036 11300
4222 036 11310
4222 036 11440
4822 502 14545
4222 036 11480
4222 036 11490
4222 036 11560
4222 036 10860
Holder assy
Contour following pin
Sidegrip assy
Driving unit 3,6 V
Trimmer assy
Spacer Li-ion A
Li-ion battery
Inlet connector BB
Cover assy
Cover shell
Screw
Screw (BBM)
Screw
Pouch
Clock
PARTS LIST
HQ9170
3-3
EXPLODED VIEW
C
2
4
5
6
8
7
10
12
13
16
15
17
18
14
A
B
9
11
1
3
