Philips QG3030 User manual

ServiceManual
Philips Consumer Lifestyle
Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification
Beard Trimmer - Personal Grooming Set
QG3030
10/10
PRODUCT INFORMATION
General:
- Comb adapt to the contours of the face.
- 9 settings of the comb.
- Nose attachment.
- Charging indication. (LED on power plug)
- No oiling required.
Safety
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
TECHNICAL INFORMATION
- Power system : Rechargeable
- Batteries : 1 x AA NiMh
- Charging period : 10 hours
- Capacity : up to 35 minutes
- SAP Coding : QG3030
DISASSEMBLY- AND RE-ASSEMBLY ADVISE
- No specific issues.
REPAIR INSTRUCTION
- No specific issues.
OPTIONAL (accessories)
- No specific issues.
NOTES :
*In order to guarantee the longest possible working
life of the battery :
- do not charge for more than 24 hours
- do not keep the charging unit permanently
plugged in
- discharge the battery completely once a year by
letting the motor run until it stops
*If the battery is empty and the consumer wants to
trim his beard, the trimmer has to be charged for
at least 3 hours to have enough power for one trim
(10 min.)
*The appliance should be charged again, when not
used for a long period

QG3030
PARTS LIST & EXPLODED VIEW
12
4
3
Pos Service code Description
1
2
3
4
4203 035 73080
4203 035 73120
4222 036 02770
4203 030 75011
4203 030 75021
4203 030 75031
4203 030 02841
4203 030 02211
Comb
Nose trimmer
Brush
Power plug Europa
Power plug United Kingdom
Power plug Australië/New Zealand
Power plug Brasil
Power plug Argentina
