Philips S5000 series User manual

series S5000

19
18
22
26
20
25
27
21
23 24
4
3
5
9
8
10
11
13
12
14
17
1
2
7
6
16
15
1

S5000 series
ENGLISH 4
DANSK 36
DEUTSCH 69
 105
ESPAÑOL 143
SUOMI 179
FRANÇAIS 211
ITALIANO 245
NEDERLANDS 279
NORSK 313
PORTUGUÊS 344
SVENSKA 379
TÜRKÇE 411

4
Introduction
Congratulations on your purchase and welcome to

offers, register your product at www.philips.com/
welcome.
General description (Fig. 1)
1 Protection cap for nose trimmer attachment

2 Click-on nose trimmer attachment

3 Comb for beard styler attachment

4 Click-on beard styler attachment

5 Click-on trimmer attachment

6 Protection cap for shaving unit

7 Click-on shaving unit
8 On/off button
 
10 Handle
11 Socket for small plug
12 Battery charge indicator with 1 light
13 Battery charge indicator with 3 lights
14 Travel lock symbol
15 Replacement reminder
16 Cleaning reminder
17 Cleaning cartridge for SmartClean system
 
19 Cap of SmartClean system
20 On/off button
21 Battery symbol
22 Cleaning symbol
ENGLISH

23 Replacement symbol
24 Ready symbol
25 Adapter
26 Small plug
 
Note:The accessories supplied may vary for different
products.The box shows the accessories that have been
supplied with your appliance.
Important safety information
Read this important information carefully before you
use the appliance and its accessories and save it for
future reference.The accessories supplied may vary
for different products.
Danger
- Keep the adapter dry.
Warning
- The adapter contains a transformer. Do not cut
off the adapter to replace it with another plug,
as this causes a hazardous situation.
- This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use
of the appliance in a safe way and understand the
hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not
be made by children without supervision.
- Always unplug the shaver before you clean it
under the tap.
- Always check the appliance before you use it.
Do not use the appliance if it is damaged, as this
may cause injury. Always replace a damaged part
with one of the original type.
ENGLISH 5

Caution
- Never immerse the cleaning system or the
charging stand in water and do not rinse it under
the tap.
- Never immerse the shaver in water. Do not use
the shaver in the bath or in the shower.
- Never use water hotter than 80°C to rinse the
shaver.
- Only use this appliance for its intended purpose as
shown in the user manual.
- For hygienic reasons, the appliance should only be
used by one person.
- Do not use the adapter in or near wall sockets
that contain or have contained an electric air
freshener to prevent irreparable damage to the
adapter
- Never use compressed air, scouring pads, abrasive
cleaning agents or aggressive liquids such as petrol
or acetone to clean the appliance.
- If your shaver comes with a cleaning system,

(cartridge or bottle, depending on the type of

- Always place the cleaning system on a stable, level
and horizontal surface to prevent leakage.
- If your cleaning system uses a cleaning cartridge,
always make sure that the cartridge compartment
is closed before you use the cleaning system to
clean or charge the shaver.
- When the cleaning system is ready for use, do not

- Water may drip from the socket at the bottom
of the shaver when you rinse it.This is normal
and not dangerous because all electronics are
enclosed in a sealed power unit inside the shaver.
ENGLISH6


- This Philips appliance complies with all applicable
standards and regulations regarding exposure to

General
- This shaver can be safely cleaned under the tap.
- The appliance is suitable for mains voltages ranging
from 100 to 240 volts.
- The adapter transforms 100-240 volts to a safe
low voltage of less than 24 volts.
- 
The display
Charging
Battery charge indicator with 3 lights
- Charging takes approx. 1 hour
- 
appliance is connected to the mains, the lights of
the battery charge indicator light up one after the
other continuously.When the appliance contains
enough energy for one shave, the bottom light of

- If you leave the appliance connected to the
mains, the charging process continues.To indicate



continuously, and so on until the appliance is fully
charged.
ENGLISH 7

Battery charge indicator with 1 light
- Charging takes approx. 1 hour.
- 
appliance does not contain enough energy for one


slowly, the appliance contains enough energy for
one shave.
- If you leave the appliance connected to the mains,
the charging process continues.To indicate that
the appliance is charging, the battery charge

Battery fully charged
Note:You can also use this appliance directly from the
mains.
Note:When the battery is full, the display switches off
automatically after 30 minutes.
When the battery is fully charged, all lights of the
battery charge indicator light up continuously.
- Battery charge indicator with 3 lights
- Battery charge indicator with 1 light
ENGLISH8

Battery low
When the battery is almost empty, the battery

- Battery charge indicator with 3 lights
- Battery charge indicator with 1 light
Remaining battery capacity
Battery charge indicator with 3 lights
- The remaining battery capacity is indicated by the
lights of the battery charge indicator that light up
continuously.
Cleaning reminder
For optimal shaving performance, we advise you to
clean the shaver after every use.
- When you switch off the shaver, the cleaning

shaver.
ENGLISH 9

Travel lock
You can lock the shaver when you are going to
travel.The travel lock prevents the shaver from being
switched on by accident.
Activating the travel lock
1 Press the on/off button for 3 seconds to enter
the travel lock mode.
- While you activate the travel lock, the travel lock
symbol lights up continuously.When the travel

Deactivating the travel lock
1 Press the on/off button for 3 seconds.
- 
continuously.
The shaver is now ready for use again.
Replacing shaving heads
For maximum shaving performance, we advise you
to replace the shaving heads every two years.
- The appliance is equipped with a replacement
reminder which reminds you to replace the
shaving heads.The replacement reminder lights up
white continuously.
Note:After replacing the shaving heads, you need to
reset the replacement reminder by pressing the on/off
button for 7 seconds.
3 sec.
ENGLISH10


- The appliance is equipped with aTurbo or Turbo+
setting.This setting is intended for quicker and
more intense shaving and makes hard-to-reach
areas easier to shave.
Activating theTurbo setting
1 To activate theTurbo setting, press the Turbo
button once.
Deactivating theTurbo setting
1 To deactivate theTurbo setting, simply press
the Turbo button once again.
Charging
Charging takes approx. 1 hour.
Note:You can also use this appliance directly from the
mains.

time and when the display indicates that the battery
is almost empty.
Charging with the adapter
1 Insert the small plug into the appliance and put
the adapter in the wall socket.
ENGLISH 11

Charging in the SmartClean system

1 Put the small plug in the SmartClean system.
2 Put the adapter in the wall socket.
3 Press down the top cap to be able to place the
shaver in the holder (‘click’).
4 Hold the shaver upside down above the holder.
Make sure the front of the shaver points
towards the SmartClean system.
5 Place the shaver in the holder, tilt the shaver
backwards and press down the top cap to
connect the shaver (‘click’).
- 
shaver is charging.
Using the shaver
Switching the appliance on and off
1 To switch on the appliance, press the on/off
button once.
2 To switch off the appliance, press the on/off
button once.
- Battery charge indicator with 3 lights:The display
lights up for a few seconds to show the remaining
battery status.
ENGLISH12

Shaving
Skin adaptation period

expect and your skin may even become slightly
irritated.This is normal.Your skin and beard need
time to adapt to any new shaving system.
We advise you to shave regularly (at least 3 times

allow your skin to adapt to the new shaver.
Note:You can also use the shaver directly from the mains.
1 Switch on the appliance.
2 Move the shaving heads over your skin in
circular movements.
Note: Do not make straight movements.
3 Clean the shaver after use (see chapter
‘Cleaning and maintenance’).

The appliance is equipped with aTurbo or Turbo+
setting for easy shaving of hard-to reach areas.
1 Switch on the shaver.
2 Press the Turbo button once to switch on the
Turbo setting if you want to shave hard-to-
reach areas more quickly.
3 Move the shaving heads over your skin in
circular movements.
Note: Do not make straight movements.
4 To deactivate theTurbo setting simply press
the Turbo button once.
ENGLISH 13

Using the click-on attachments
Note:The accessories supplied may vary for different
products.The box shows the accessories that have been
supplied with your appliance.
Removing or attaching the click-on
attachments
1 Make sure the appliance is switched off.
2 Pull the attachment straight off the appliance.
Note: Do not twist the attachment while you pull it off
the appliance.
3 Insert the lug of the attachment into the slot
in the top of the appliance.Then press down
the attachment to attach it to the appliance
(‘click’).
Using the trimmer attachment
You can use the trimmer attachment to groom
your sideburns and moustache.
1 Make sure the appliance is switched off.
2 Insert the lug of the attachment into the slot
in the top of the shaver.Then press down
the trimmer attachment to attach it to the
appliance (‘click’).
3 Switch on the appliance.
4 You can now start trimming.
5 Clean the attachment after use (see chapter
‘Cleaning and maintenance’).
ENGLISH14

Using the beard styler attachment
1 Make sure the appliance is switched off.
2 Insert the lug of the attachment into the slot
in the top of the appliance.Then press down
the attachment to attach it to the appliance
(‘click’).
Using the beard styler attachment with
comb
You can use the beard styler attachment with the

setting, but also at different length settings.You can
use it also to pre-trim any long hairs before shaving
to have a more comfortable shave.
The hair length settings on the beard styler
attachment correspond to the remaining hair length
after cutting and range from 1 to 5mm.
1 Slide the comb straight into the guiding
grooves on both sides of the attachment
(‘click’).
2 Press the length selector and then push it
to the left or right to select the desired hair
length setting.
3 Switch on the appliance.
4 You can now start styling your beard by
moving the attachment upwards with
gentle pressure making sure the front of
the comb is in full contact with the skin.
5 Clean the attachment after use (see chapter
‘Cleaning and maintenance’).
2
1
ENGLISH 15

Using the beard styler attachment without
comb
You can use the beard styler attachment without the
comb to contour your beard, moustache, sideburns
or neckline to a length of 0.5mm.
1 Pull the comb off the attachment.
Note: Grab the comb in the centre to pull it off the
attachment. Do not pull at the sides of the comb.
2 Switch on the appliance.
3 You can now start contouring your beard,
moustache, sideburns or neckline by moving
the styler downwards with gentle pressure
while holding it perpendicular to the skin.
4 Clean the attachment after use
(see chapter ‘Cleaning and maintenance’).
Using the nose trimmer attachment
You can use the nose trimmer attachment to trim
your nose hair.
Make sure your nostrils are clean.
1 Insert the lug of the attachment into the slot
in the top of the appliance.Then press down
the attachment to attach it to the appliance
(‘click’).
2 Switch on the appliance.
3 Carefully insert the attachment into one of
your nostrils.
Do not insert the attachment more than 0.5cm
into your nostrils.
ENGLISH16

4 Slowly move the attachment around to remove
all unwanted hairs in your nostrils.
5 Clean the attachment after use
(see chapter ‘Cleaning and maintenance’).
Trimming ear hair
You can use the nose trimmer attachment to trim
your ear hair. Make sure your outer ear channels are
clean and free from wax.
1 Insert the lug of the attachment into the slot
in the top of the appliance.Then press down
the attachment to attach it to the appliance
(‘click’).
2 Switch on the appliance.
3 Slowly move the attachment along the rim of
the ear to remove hairs that stick out beyond
the rim.
4 Insert the attachment into the outer ear
channel.
Do not insert the attachment more than 0.5cm
into your ear channel, as this could damage the
eardrum.
5 Slowly turn the attachment around to remove
all unwanted hairs from your outer ear
channel.
6 Clean the attachment after use (see chapter
‘Cleaning and maintenance’).
ENGLISH 17

Cleaning and maintenance
Note:The accessories supplied may vary for different
products.The box shows the accessories that have been
supplied with your appliance.
Cleaning the shaver in the SmartClean

Do not tilt the SmartClean system to prevent
leakage.
Note: Hold the SmartClean system while you prepare
it for use.
Note: If you clean the shaver in the SmartClean
system once a week, the SmartClean cartridge will last
approximately three months.
Preparing the SmartClean system for use
1 Put the small plug in the back of the
SmartClean system.
2 Put the adapter in the wall socket.
3 Press the button on the side of the SmartClean
system and lift the top part of the SmartClean
system.
4 Pull the seal off the cleaning cartridge.
5 Place the cleaning cartridge in the SmartClean
system.
1
2
ENGLISH18

6 Push the top part of the SmartClean system
back down (‘click’).
Using the SmartClean system
Always make sure to shake excess water off the
shaver before you place it in the SmartClean
system.
1 Press down the top cap to be able to place the
shaver in the holder (‘click’).
2 Hold the shaver upside down above the holder.
Make sure the front of the shaver points
towards the SmartClean system.
3 Place the shaver in the holder, tilt the shaver
backwards and press down the top cap to
connect the shaver (‘click’).
- 
the shaver is charging.
ENGLISH 19

4 Press the on/off button on the SmartClean
system to start the cleaning program.
- During the cleaning program (which takes approx.

- When the cleaning program has been completed,
the ready symbol lights up continuously.
- The battery symbol lights up continuously to
indicate that the shaver is fully charged.This takes
approx. 1 hour.
Note: If you press the on/off button of the SmartClean
system during the cleaning program, the program aborts.

Note: If you remove the adapter from the wall socket
during the cleaning program, the program aborts.
Note: 30 minutes after the charging phase has been
completed, the SmartClean system switches off
automatically.
5 To let the shaver dry, you can leave it in the
SmartClean system until your next shave.
You can also remove the shaver from the
SmartClean system, shake off excess water,
open the shaving unit and let the shaver air dry.
Replacing the cartridge of the SmartClean
System
Replace the cleaning cartridge when the


If you clean the shaver in the SmartClean system
once a week, the SmartClean cartridge will last
approximately three months.
ENGLISH20
