Philips sensiflex HX2225 User manual

sensiflex
dental center HX2225

2

ENGLISH 4
DEUTSCH 10
FRANÇAIS 17
NEDERLANDS 24
ESPAÑOL 30
ITALIANO 37
PORTUGUÊS 43
HX2225
3

Important
◗If the mains cord of this appliance is damaged,
it must always be replaced by Philips or a
service centre authorised by Philips,in order
to avoid hazardous situations.
◗The mains plug of the charging unit meets the
latest European standards.The plug is safe,
although the standard UK shaver socket holes
may be slightly too wide for the pins of the
plug.Make sure a proper connection is made.
◗When you use the Massage Jet for the first
time or when you have not been using it for a
long time,it is necessary to set the volume
control to its maximum setting to start the
water flowing to the jet tip.If the water
doesn't flow out after 10 seconds,put the jet
tip nozzle in your mouth and suck it shortly.
Taking optimal care of your teeth
Healthy teeth are to be treasured,which is logical,
for we want them to last a lifetime.Healthy gums
play an important role.By massaging with the
Massage Jet you keep your gums healthy.
Proper dental care is essential.By brushing only,
you may not remove all remaining food particles.
This may cause caries.By using the Massage Jet,
you are able to remove all remaining food
particles.Even hard to reach places,such as
between your teeth,can be cleaned.
ENGLISH4

Preparing the Massage Jet for use
Mounting the base unit to the wall
C1Mount the base unit to the wall,using
2 screws (3.5x30mm) and 2 wall plugs (S5)
(not included).
To drill the holes in the right places,you can use
the drilling stencil on the last page of these
directions for use.
Do not allow the base unit to come into contact
with water.
2Push excess mains cord into the storage
space in the back of the base unit.
Using the Massage Jet
When you use the Massage Jet for the first time
or when you have not been using it for a couple
of days:
C1Click the jet tip onto the appliance.
C2Remove the water reservoir from the base
unit.
ENGLISH 5

C3Fill the water reservoir with water.
4Put the water reservoir back onto the
base unit.Press it home properly.
C5Press the power button to switch the
Massage Jet on.
C6Push the slide on the handgrip upwards to
make the water start running.
When you use the Massage Jet for the first time,
let the appliance run until the water reservoir is
completely empty.Refill the water reservoir.
Tip:You may add mouthwash for extra freshness
to the water.After using mouthwash,fill the water
reservoir with clean,unmixed water and pump all
the water out of the appliance and into the
washbasin.
How to use the Massage Jet
C1You can adjust the water volume by
turning the control ring.
Tip:we advise you to use a low water volume
setting while you are getting accustomed to the
oral water jet and when you are troubled by gum
inflammation.
ENGLISH6

C2Bend over the washbasin and hold the jet
tip close to your teeth.
C3Press the power button to switch the
Massage Jet on.
C4Push the switch slide upwards to start the
water running.
C5Guide the water jet along the front and
the back sides of the teeth and along the
gums,and direct it especially at the spaces
between the teeth to remove any
remaining food particles.
BMake sure the water jet is at straight angles to
the teeth.
BDo not direct the water jet at the gums in such
way that the jet penetrates beneath the gum line.
◗You can switch the water supply off with the
switch slide before changing the position of
the jet tip in your mouth.
C6Adjust the water volume by turning the
control ring.
ENGLISH 7

◗Tip:We advise you to use a low water volume
setting while you are getting accustomed to
the Massage Jet and when you are troubled by
gum inflammation.
7After cleaning,lower the water volume for
gum massage.
C8Guide the water over your teeth and
gums.
After using the Massage Jet
C1Remove the jet tip and put it in the
storage compartment.
C2Put the handgrip back into its holder.
Tip:You can obtain extra or replacement jet tips
at your nearest Philips Service Centre.
Cleaning the Massage Jet
1Remove the mains plug from the wall
socket.
2Clean the appliance with a damp cloth (if
necessary with some detergent).
ENGLISH8

Do not use abrasive or aggressive cleaners
scourers,alcohol,acetone,etc.
3Clean the storage compartment,the
handgrip holder,the insert container and
the water reservoir in hot soapy water.
4Rinse them under a running tap.
◗The storage compartment,the handgrip
holder and the water reservoir may also be
cleaned in a dishwasher.
Guarantee & service
If you need information or if you have a problem,
please visit the PhilipsWeb site at
www.philips.com or contact the Philips Customer
Care Centre in your country (you will find its
phone number in the worldwide guarantee
leaflet).If there is no Customer Care Centre in
your country,turn to your local Philips dealer or
contact the Service Department of Philips
Domestic Appliances and Personal Care BV.
Extra tips about the Massage Jet (for replacement
or extension) are available as an option at Philips
Service Centres.
ENGLISH 9

Wichtig
◗Wenn das Netzkabel defekt oder beschädigt
ist,muss es von Philips oder von einer durch
Philips autorisiertenWerkstatt ersetzt
werden,um Gefährdungen auszuschließen.
◗Der Netzstecker entspricht den neuesten
europäischen Normen.Obwohl die üblichen
Rasierersteckdosen imVereinigten Königreich
(UK) für diesen Stecker ein wenig zu weit
sind,ist der Netzstecker sicher.Lassen Sie sich
gfs.eine passende Steckdose ablegen.
◗Wenn Sie die Munddusche zum ersten Mal
benutzen,so füllen Sie den Behälter mit
Wasser und stellen Sie den
Geschwindigkeitsregler auf die maximale
Position.Schalten Sie das Gerät ein.Sollte im
Laufe von 10 Sekunden noch keinWasser
austreten,so saugen Sie kurz an der Düse.
Verfahren Sie auf die gleicheWeise,wenn Sie
die Düse bzw.das Gerät längere Zeit nicht
benutzt haben.
Die optimale Zahnpflege
Gesunde Zähne sind von hohemWert,denn Sie
sollen uns ein Leben lang erhalten bleiben.Zur
Erhaltung der Zähne ist gesundes Zahnfleisch
wichtig.Durch die Massage mit der Munddusche
halten Sie Ihr Zahnfleisch gesund.
Es ist wichtig,die Zähne richtig zu pflegen.Durch
bloßes Bürsten der Zähne können nicht alle
Speisereste zwischen den Zähnen entfernt
werden,und es entsteht Karies.Mit der
DEUTSCH10
