Philips Sonicare For Kids HX6322/04 User manual

Sonicare For Kids
rechargeable
sonic toothbrush
4235_020_9980_1_DFU-BS_A6_v1.indd 1 18/12/15 13:46

4235_020_9980_1_DFU-BS_A6_v1.indd 2 18/12/15 13:46

1
2
3
4
5
6
7
8 9
1
4235_020_9980_1_DFU-BS_A6_v1.indd 3 18/12/15 13:46

4235_020_9980_1_DFU-BS_A6_v1.indd 4 18/12/15 13:46

English 6
Nederlands 19
Deutsch 33
Ελληνικα 47
Español 61
Français 75
Italiano 90
Português 104
4235_020_9980_1_DFU-BS_A6_v1.indd 5 18/12/15 13:46

English
6
Introduction
Congratulations on your purchase and welcome to Philips! To fully
benet from the support that Philips oers, register your product at
www.philips.com/welcome.
You and your child now own a Sonicare connected toothbrush.
The Bluetooth connected toothbrush interacts with a fun brushing
mobile device application to keep your child engaged while learning
proper brushing techniques.
General description (Fig. 1)
1 Hygienic travel cap
2 Brush head
3 Handle with soft grip
4 Power on/o button with battery charge indicator
5 Removable panel with replaceable stickers
6 Brushing mode button with mode lights
7 Charger
8 Panel
9 Sticker
Important safety information
Read this important information carefully
before you use the device and save it for
future reference.
Danger
-Keep the charger away from water.
Do not place or store it over or near water
contained in a bathtub, washbasin, sink
etc.
4235_020_9980_1_DFU-BS_A6_v1.indd 6 18/12/15 13:46

English 7
Do not immerse the charger in water or
any other liquid. After cleaning, make sure
the charger is completely dry before you
connect it to the mains.
-This appliance is not a toy. Check brush
heads regularly for cracks. Cracked brush
heads may present a choking hazard.
Warning
-The mains cord cannot be replaced.
If the mains cord is damaged, discard the
charger.
-Always have the charger replaced with
one of the original type in order to avoid a
hazard.
-Do not use the charger outdoors or near
heated surfaces.
-If the appliance is damaged in any
way (brush head, toothbrush handle or
charger), stop using it. This appliance
contains no serviceable parts. If the
appliance is damaged, contact the
Consumer Care Centre in your country
(see chapter ‘Guarantee and support').
4235_020_9980_1_DFU-BS_A6_v1.indd 7 18/12/15 13:46

English
8
-This appliance can be used by children
aged from 8 years and above and by
persons with reduced physical, sensory or
mental capabilities or lack of experience
and knowledge if they have been given
supervision or instruction concerning use
of the appliance in a safe way and if they
understand the hazards involved.Children
shall not play with the appliance. Cleaning
and user maintenance shall not be made
by children unless they are older than
8 and supervised.
Caution
-Do not clean the brush head, the handle
or the charger in the dishwasher.
-If you have had oral or gum surgery in the
previous 2 months, consult your dentist
before you use the toothbrush.
-Consult your dentist if excessive bleeding
occurs after using this toothbrush or if
bleeding continues to occur after 1 week
of use. Also consult your dentist if you
experience discomfort or pain when you
use the Philips Sonicare.
4235_020_9980_1_DFU-BS_A6_v1.indd 8 18/12/15 13:46

English 9
-The Philips Sonicare toothbrush
complies with the safety standards for
electromagnetic devices. If you have a
pacemaker or other implanted device,
contact your physician or the device
manufacturer of the implanted device
prior to use.
-If you have medical concerns, consult
your doctor before you use the Philips
Sonicare.
-This appliance has only been designed for
cleaning teeth, gums and tongue. Do not
use it for any other purpose. Stop using
the appliance and contact your doctor if
you experience any discomfort or pain.
-The Philips Sonicare toothbrush is a
personal care device and is not intended
for use on multiple patients in a dental
practice or institution.
-Stop using a brush head with crushed
or bent bristles. Replace the brush head
every 3 months or sooner if signs of wear
appear. Do not use other brush heads
than the ones recommended by the
manufacturer.
4235_020_9980_1_DFU-BS_A6_v1.indd 9 18/12/15 13:46

English
10
-If your toothpaste contains peroxide,
baking soda or bicarbonate (common in
whitening toothpastes), thoroughly clean
the brush head with soap and water after
each use. This prevents possible cracking
of the plastic.
-Do not charge your phone or tablet in the
bathroom.
Electromagnetic elds (EMF)
This Philips appliance complies with all applicable standards and
regulations regarding exposure to electromagnetic elds.
Preparing for use
Applying the replaceable panel
The Sonicare For Kids comes with 1 replaceable panel.
1 Remove the adhesive backing from the panel.
2 Apply the panel to the white section on the front of the handle
(Fig. 2).
Note: Make sure you line up the cut-out areas on the panel with
the buttons on the front of the handle.
3 Apply your favorite sticker to the panel as shown on the sticker
sheet (Fig. 3).
Reapplying a panel that has been removed
1 Rinse the panel in warm water; you may also use a mild detergent
to clean it.
2 Let the panel air dry.
3 Reapply the panel to the white section on the front of the handle.
4235_020_9980_1_DFU-BS_A6_v1.indd 10 18/12/15 13:46

English 11
Attaching the brush head
1 Align the brush head so the bristles point in the same direction as
the front of the handle (Fig. 4).
2 Firmly press the brush head down onto the metal shaft until it stops.
Note: There is a small gap between the brush head and the
handle.
Charging your Sonicare
1 Plug the charger into an electrical outlet.
2 Place the handle on the charger (Fig. 5).
The battery charge indicator in the power on/o button ashes and
the handle beeps twice to indicate that the toothbrush is charging.
Battery low
If the battery charge of your Sonicare is low, you hear three beeps
and the battery charge indicator ashes rapidly for 1 minute after the
brushing cycle.
Battery fully charged
When the Sonicare is fully charged, the battery charge indicator stops
ashing and remains on for 10 seconds before it turns o.
To keep the battery fully charged at all times, you may keep your
Sonicare on the charger when not in use. It takes at least 24 hours to
fully charge the battery.
Note: When the battery charge is depleted, the handle will emit 2 sets of
5 beeps at the end of a brushing session or when a new brushing session
is attempted. The new brushing session does not begin. The green LED
will also flash fast until the handle goes to sleep.
4235_020_9980_1_DFU-BS_A6_v1.indd 11 18/12/15 13:46

English
12
Bluetooth connectivity
Before you start the connectivity procedure, make sure your mobile
device runs on Bluetooth 4.0 or higher.
Note: For the latest information on device compatibility, please
visit the App Store or Google Play.
Connecting your toothbrush
1 Download the Philips Sonicare For Kids app from the App Store or
Google Play.
2 Conrm Bluetooth is switched on on your mobile device before
you open the app. Check the settings on your mobile device to
turn on Bluetooth.
3 To connect the toothbrush to the app, turn on the toothbrush by
pressing either the power on/o button or the brushing mode
button. Make sure the toothbrush is not on the charger when you
turn it on.
4 Open the Philips Sonicare For Kids app.
5 Follow the app instructions displayed on your mobile device.
The app automatically connects with the toothbrush. If the
toothbrush does not connect, follow the troubleshooting steps
provided in the app.
6 Keep your mobile device close to your toothbrush when you use
your toothbrush. Make sure your mobile device is safe in a dry
place.
Using the appliance
Brushing instructions
1 Wet the bristles and apply a small amount of toothpaste.
2 Place the toothbrush bristles against the teeth at a slight angle
(45 degrees), where the teeth and the gumline meet. This is to
ensure that the whole tooth surface is brushed (Fig. 6).
4235_020_9980_1_DFU-BS_A6_v1.indd 12 18/12/15 13:46

English 13
3 Press the power on/o button to turn on the Sonicare.
4 Apply light pressure to maximize Sonicare’s eectiveness and let
the Sonicare toothbrush do the brushing for you. Do not scrub
(Fig. 7).
5 Maintain light pressure and gently brush the outer and inner
surfaces of all top and bottom teeth while you keep the
toothbrush at an angle such that the toothbrush bristles touch the
area where the teeth and the gumline meet.
6 The inner and outer surfaces of the upper and lower back teeth
are hard to reach. Spend time brushing these areas, apply light
pressure and maintain the angle of the toothbrush bristles to the
gumline (Fig. 8).
7 Brush the chewing surfaces of all the upper and lower teeth.
8 While you maintain the angle of the bristles to the gumline,
gently move the brush head slowly across the teeth in a small
back and forth motion so the longer bristles reach between the
teeth. Continue this motion throughout the brushing cycle (Fig. 9).
Note: To make sure your child brushes evenly throughout the
mouth, divide the mouth into 4 sections using the KidPacer feature
(see chapter "Features").
9 Begin brushing in section 1 (outside top teeth). A short series of
tunes indicate it is time to move to section 2 (inside top teeth).
At the next series of tunes, move to section 3 (outside bottom
teeth). The next series of tunes indicate it is time to move to
section 4 (inside bottom teeth). The toothbrush will automatically
turn o at end of the brushing cycle (Fig. 10).
Your Sonicare is safe to use on:
-Braces (brush heads wear out sooner when used on braces)
-Dental restorations (llings, crowns, veneers)
4235_020_9980_1_DFU-BS_A6_v1.indd 13 18/12/15 13:46

English
14
Brushing modes
The Sonicare automatically starts in the default Gentle mode.
1 Press the brushing mode button to toggle between modes (Fig. 11).
The green mode light indicates the selected mode.
-Gentle mode: Full power mode designed for older/independent
brushers. When in Gentle mode, the brushing cycle is set at
2 minutes.
-Extra Gentle mode: Reduced power mode used for training and
introducing younger children to the sonic experience. When in
Extra Gentle mode, the brushing cycle is initially set at 1 minute
and slowly progresses to 2 minutes over time to help young
children reach the dentist recommended 2 minutes of brushing
cycle.
To manually set the brushing cycle to 2 minutes in Extra Gentle mode,
place the handle on the charger and hold down the mode button for
2 seconds. You hear a single beep to indicate the brushing cycle is set
to 2 minutes.
To manually re-set the brushing cycle to 1 minute in Extra Gentle
mode, place the handle on the charger and hold down the mode
button for 2 seconds. You hear a double beep to indicate the
brushing cycle is set to 1 minute.
Features
KidPacer
The Sonicare For Kids uses a short series of tunes to alert the brusher
to move to the next brushing quadrant of the mouth and concludes
the brushing cycle with a congratulatory tune before it automatically
turns o. This ensures that the child’s teeth get a thorough, overall
clean (see “Brushing instructions”).
Note: Instruct your child to brush until they hear the congratulatory
tune and the toothbrush turns o.
4235_020_9980_1_DFU-BS_A6_v1.indd 14 18/12/15 13:46

English 15
Easy-start
The Easy-start feature gently increases the power over the rst
14 brushings to help you get used to the brushing with the Philips
Sonicare. The Sonicare For Kids comes with the Easy-start feature
activated.
Note: Each of the rst 14 brushings must be at least 1 minute in length
to properly advance through the Easy-start ramp-up cycle.
Activating or deactivating the Easy-start feature
1 Place the handle on the charger.
To activate Easy-start:Press and hold the power on/o button for
2 seconds. You hear 2 beeps to indicate that the Easy-start feature
has been activated.To deactivate Easy-start:Press and hold the
power on/o button for 2 seconds. You hear 1 beep to indicate that
the Easy-start feature has been deactivated.
Note: Using the Easy-start feature beyond the initial ramp-up period
is not recommended and reduces Philips Sonicare eectiveness in
removing plaque.
Cleaning
Warning: Do not clean brush heads, handle, charger, charger
cover or replaceable panel in the dishwasher.
Toothbrush handle
1 Remove the brush head and rinse the metal shaft area with warm
water. Make sure you remove any residual toothpaste (Fig. 12).
Caution: Do not push on the rubber seal on the metal shaft
with sharp objects, as this may cause damage.
2 Wipe the entire surface of the handle with a damp cloth.
4235_020_9980_1_DFU-BS_A6_v1.indd 15 18/12/15 13:46

English
16
Brush head
1 Rinse the brush head and bristles after each use (Fig. 13).
2 Remove the brush head from the handle and rinse the brush head
connection with warm water at least once a week.
Charger
1 Unplug the charger before you clean it.
2 Wipe the surface of the charger with a damp cloth. Make sure you
remove any toothpaste or other residue from the charger surfaces.
Storage
If you are not going to use the Sonicare for an extended period of
time, unplug the charger from the electrical outlet, clean it and store it
in a cool and dry place away from direct sunlight.
Replacement
Brush head
-Replace Sonicare brush heads every 3 months to achieve optimal
results.
-Use only Sonicare For Kids replacement brush heads.
Recycling
-This symbol means that this product shall not be disposed of with
normal household waste (2012/19/EU) (Fig. 18).
-This symbol means that this product contains a built-in
rechargeable battery which shall not be disposed of with normal
household waste (Fig. 19) (2006/66/EC). We strongly advise you
to take your product to an ocial collection point or a Philips
service centre to have a professional remove the rechargeable
battery.
4235_020_9980_1_DFU-BS_A6_v1.indd 16 18/12/15 13:46

English 17
-Follow your country’s rules for the separate collection of
electrical and electronic products and rechargeable batteries.
Correct disposal helps prevent negative consequences for the
environment and human health.
Removing the rechargeable battery
Warning: Only remove the rechargeable battery when you
discard the appliance. Make sure the battery is completely
empty when you remove it.
To remove the rechargeable battery, you need a at-head (standard)
screwdriver.Observe basic safety precautions when you follow the
procedure outlined below. Be sure to protect your eyes, hands,
ngers, and the surface on which you work.
1 To deplete the rechargeable battery of any charge, remove the
handle from the charger, turn on the Philips Sonicare and let it run
until it stops. Repeat this step until you can no longer turn on the
Philips Sonicare.
2 Insert a screwdriver into the slot located in the bottom of the
handle and turn counterclockwise until you see a gap between the
bottom cap and the handle (Fig. 14).
3 Insert the screwdriver into the gap and pry the bottom cap out of
the handle (Fig. 15).
4 Hold the handle upside down and push down on the shaft to
release the internal components of the handle (Fig. 16).
5 Insert the screwdriver under the circuit board, next to the battery
connections, and twist to break the connections. Remove the
circuit board and pry the battery from the plastic carrier (Fig. 17).
The rechargeable battery can now be recycled or disposed of and the
rest of the product discarded appropriately.
4235_020_9980_1_DFU-BS_A6_v1.indd 17 18/12/15 13:46

English
18
Guarantee and support
If you need information or support, please visit www.philips.com/
support or read the separate worldwide guarantee leaet.
Guarantee restrictions
The terms of the international guarantee do not cover the following:
-Brush heads.
-Damage caused by use of unauthorised replacement parts.
-Damage caused by misuse, abuse, neglect, alterations or
unauthorised repair.
-Normal wear and tear, including chips, scratches, abrasions,
discolouration or fading.
-Replaceable stickers
-Replaceable panels
4235_020_9980_1_DFU-BS_A6_v1.indd 18 18/12/15 13:46

Nederlands 19
Introductie
Gefeliciteerd met uw aankoop en welkom bij Philips! Registreer uw
product op www.philips.com/welcome om optimaal gebruik te
kunnen maken van de door Philips geboden ondersteuning.
U en uw kind zijn nu in het bezit van een Sonicare-tandenborstel
met connectiviteit. Deze tandenborstel is voorzien van Bluetooth
en kan verbinding maken met een leuke borstelapp voor mobiele
apparaten. Hiermee kunt u uw kind bezighouden terwijl het de juiste
poetstechnieken leert.
Algemene beschrijving (g. 1)
1 Hygiënisch beschermkapje
2 Opzetborstel
3 Handvat met zacht greepgedeelte
4 Aan-uitknop met oplaadlampje
5 Verwijderbaar frontje met verwisselbare stickers
6 Knop voor poetsstand met moduslampjes
7 Oplader
8 Frontje
9 Sticker
Belangrijke veiligheidsinformatie
Lees deze belangrijke informatie zorgvuldig
door voordat u het apparaat gaat gebruiken.
Bewaar deze informatie om deze indien
nodig later te kunnen raadplegen.
Gevaar
-Houd de oplader uit de buurt van water.
Plaats de oplader niet in de buurt van
of boven een bad, wasbak, gootsteen
enzovoort.
4235_020_9980_1_DFU-BS_A6_v1.indd 19 18/12/15 13:46

Nederlands
20
Dompel de oplader nooit in water of
een andere vloeistof. Controleer na het
schoonmaken of de oplader helemaal
droog is, voordat u deze weer aansluit op
het stopcontact.
-Dit apparaat is geen speelgoed. Controleer
de opzetborstels regelmatig op barsten.
Gebarsten opzetborstels kunnen
verstikkingsgevaar met zich meebrengen.
Waarschuwing
-Het netsnoer kan niet worden vervangen.
Als het netsnoer beschadigd is, dankt u de
oplader af.
-Vervang de oplader altijd door een
origineel exemplaar van hetzelfde type
om gevaar te voorkomen.
-Gebruik de oplader niet buitenshuis of in
de buurt van hete oppervlakken.
-Stop het gebruik van het apparaat
als het op enige wijze beschadigd is
(de opzetborstel, het handvat van de
tandenborstel of de oplader). Dit apparaat
bevat geen repareerbare onderdelen.
Als het apparaat beschadigd is, neemt u
contact op met het Consumer Care Centre
in uw land (zie hoofdstuk 'Garantie en
ondersteuning').
4235_020_9980_1_DFU-BS_A6_v1.indd 20 18/12/15 13:46
