Philips Sonicare DiamondClean 9000 User manual

HX9913
9000
DiamondClean

4
3
5
6
8
12
14
13
11
10
7
9
1
2
1

English 6
Français 27
Türkçe 50
ﺔﻴﺑﺮﻌﻟﺍ 71

English
6English
Introduction
Congratulations on your new Philips Sonicare power toothbrush! Superior
plaque removal, whiter teeth and healthier gums are at your fingertips. Using
Sonicare’s combination of gentle sonic technology and clinically developed
and proven features, you can be confident that you’re getting the very best
clean, every time. Further support and product registration are available to you
at: www.philips.com/welcome.
Welcome to the Philips Sonicare family!
Important safety information
Only use the product for its intended purpose. Read this important
information carefully before you use the product and its batteries and
accessories, and save it for future reference. Misuse can lead to hazards or
serious injuries.
Any serious incident that has occurred in relation to this device should be
reported to Philips (www.philips.com/support) and to the competent
authority of the member state in which the user and / or patient is established.
Note: The accessories and features of different models vary. For example, some
models come with a sanitizer or are equipped with Bluetooth or BrushSync.
Warnings
- Keep the USB wall adapter and charging base away from water.
- Do not immerse the USB wall adapter or charging base in water or any
other liquid.
- After cleaning, make sure the charger is completely dry before you connect
it to the wall socket.
- This appliance can be used by children and persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved. Cleaning and user
maintenance shall not be made by children without supervision.
- Children shall not play with the appliance.
- Only use original Philips accessories or consumables. Only use brush heads
recommended by Philips Sonicare. Only use the charger provided with the
product. If supplied, only use the original USB cable and USB power supply
unit.
- This appliance contains no user-serviceable parts. If the appliance is
damaged, stop using it and contact the Consumer Care Center in your
country (see 'Warranty and support'). If the cord is damaged, replace the
charger and/or sanitizer with a new one.
- Do not use the charger outdoors or near heated surfaces.

7
English
- Do not clean any part of the product in the dishwasher.
- This appliance has only been designed for cleaning teeth, gums and
tongue.
- Stop using the appliance and consult your dentist/doctor if excessive
bleeding occurs after use, if bleeding continues to occur after 1 week of use
or if you experience discomfort or pain.
- If you have had oral or gum surgery in the previous 2 months, consult your
dentist before you use this appliance.
- If you have a pacemaker or other implanted device, contact your doctor or
the manufacturer of the implanted device prior to use.
- If you have medical concerns, consult your doctor before you use this
appliance.
- This appliance is a personal care device and is not intended for use on
multiple patients in a dental practice or institution.
- Stop using a brush head with crushed or bent bristles. Replace the brush
head every 3 months or sooner if signs of wear appear.
- If your toothpaste contains peroxide, baking soda or bicarbonate (common
in whitening toothpastes), thoroughly clean the brush head with soap and
water after each use. This prevents possible cracking of the plastic.
- Avoid direct contact with products that contain essential oils or coconut oil.
Contact may result in bristles dislodging.
- Use by children should be supervised by an adult.
- To charge the battery, only use the USB wall adapter, charging base and
charging travel case provided with the product: TCAXXXX, CBAXXXX. Do
not use an extension cord.
- Charge and use the product at a temperature between 5°C and 40°C
(41°F and 104°F).
- Keep product and batteries away from fire and do not expose them to
direct sunlight or high temperatures.
- If the product becomes abnormally hot or smelly, changes color or if
charging takes longer than usual, stop using and charging the product and
contact Philips.
- Do not place products and their batteries in microwave ovens or on
induction cookers.
- Do not open, modify, pierce, damage or dismantle the product or battery
to prevent batteries from heating up or releasing toxic or hazardous
substances. Do not short-circuit, overcharge or reverse charge batteries.
- If batteries are damaged or leaking, avoid contact with the skin or eyes. If
this occurs, immediately rinse well with water and seek medical care.

8English
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable standards and regulations
regarding exposure to electromagnetic fields.
Radio Equipment Directive
Hereby, Philips declares that electric toothbrushes equipped with a radio
frequency interface (Bluetooth® or NFC) are in compliance with Directive
2014/53/EU.
- The Bluetooth radio frequency interface in applicable products operates at
2.4 GHz.
- The maximum radio frequency power of products equipped with Bluetooth
is 3 dBm.
- The NFC radio frequency interface in applicable products operates at 13.56
MHz.
- The maximum radio frequency power of products equipped with NFC is
30.16 dBm.
The full text of the EU declaration of conformity is available at the following
internet address: www.philips.com/support
Note: The features of different models may vary. Some models may not be
equipped with Bluetooth or NFC.
Intended Use
DiamondClean series power toothbrushes are intended to remove adherent
plaque and food debris from the teeth to reduce tooth decay and improve and
maintain oral health. DiamondClean series power toothbrushes are intended
for consumer home use.

9
English
Your Philips Sonicare (Fig. 1)
1 Hygienic travel cap
2 Smart brush heads*
3 Handle (HX991W, HX991B)
4 Power on/off button
5 Intensity light
6 Mode/intensity button
7 Modes
8 Brush head replacement reminder light
9 Battery indication
10 Charging glass
11 Charging stand
12 Charging base (100-240 V~, 50/60 Hz, 1.3W or 0.05 A)
13 (Charging) travel case (4.75-5.25 Vdc, 1.5 W)*
14 USB wall adapter*(100-240V~ 50/60Hz, 3.5W)
* Note: The content of the box may vary based on the model purchased.
The following symbols may appear on the product or package.
Read Operator’s Manual.
Detachable Power Supply Part:The "xxxxxx" indicates the model
number of the approved chargers to be used.
Consult instructions for use

10 English
Sonicare app – Getting Started
The Sonicare app pairs with your toothbrush to provide you a connected
experience. By connecting your toothbrush to your Sonicare app account, you
will be able to:
- Easily review your progress report for ways to improve your brushing
routine
- Receive personalized tips and recommendations for managing your oral
health
To start using the Sonicare app:
1Download the Sonicare app to your phone
2Open the app and follow the guided steps
3Pair your toothbrush with the app
4Create your account
5Complete firmware update, if prompted, to access the latest improvements
and features.
6Brush regularly
You are ready to start your connected experience. Be sure to brush regularly.
You can receive updates to help improve your oral healthcare.
Note: Make sure your phone’s Bluetooth is turned on when using the app.
Your toothbrush uses the Bluetooth connection to transfer your brushing data
to the app. If you have questions about why your brushing data is collected, be
sure to review the Sonicare Privacy Statement, available throughout the app
setup process.
Sonicare app – Track and improve your oral health care
Your Sonicare power toothbrush is equipped with smart sensors to provide
you with feedback about your brushing habits, including:
- Daily brushing sessions
- Time spent during each brushing session
- Applied brushing pressure
- Brush head replacement reminder (based on actual use)
The Sonicare app collects the data provided by the smart sensors and tracks
your brushing habits over time.
Note: This feature only works with Philips Sonicare smart brush heads with
BrushSync technology.
Each of the features available in the app are designed to help you understand
your brushing habits and provide you with simple recommendations for
improving and maintaining your oral health. You will receive personalized
brushing information in the Sonicare app.

11
English
Brush heads
To see what type of brush head you have, check the label at the bottom of the
brush head. The symbol at the bottom of the brush head indicates that it is a
smart brush head, equipped with the BrushSync technology.
Note: The content of the box may vary based on the model purchased.
Brush head
name
Premium Plaque
Defense Premium White Premium Gum Care
Brush head label C3 W3 G3
Benefit Plaque removal Plaque and stain
removal Healthier gums
To explore our full range of brush heads, go to
www.philips.com/toothbrush-heads for more information.
Using your Philips Sonicare
Brushing instructions
1Push the brush head firmly onto the handle. Wet the bristles and apply
toothpaste.
Note: It is normal to see a slight gap between the brush head and the
handle. This allows the brush head to vibrate properly.

12 English
2Place the toothbrush bristles against the teeth at a slight angle (45
degrees), apply light pressure to make the bristles reach the gumline or
slightly beneath the gumline.
Note: Keep the center of the brush head in contact with the teeth at all
times.
3Press the power on/off button to turn on the Philips Sonicare.
45°
4Apply light pressure to maximize Philips Sonicare’s effectiveness and let the
Philips Sonicare toothbrush do the brushing for you. Gently move the brush
head slowly across the teeth in a small back and forth motion so the longer
bristles reach between your teeth. Continue this motion throughout the
brushing cycle.
Note: Different modes are available (see 'Brushing modes').
5To clean the inside surfaces of the front teeth, tilt the brush handle semi-
upright and make several vertical overlapping brushing strokes on each
tooth.

13
English
Note:
- A change in vibration from the handle alerts you when you apply too
much pressure (see 'Pressure sensor').
- Your Philips Sonicare toothbrush is safe to use on braces, dental
modifications and dental restorations (fillings, crowns, veneers)
- Do not use your power toothbrush in the shower.
BrushSync technology
BrushSync technology enables your brush heads to communicate with your
handle using a microchip. The symbol at the bottom of the brush head
indicates that it is equipped with the BrushSync technology. This enables the
following features:
- Brush head mode pairing
- Brush head replacement reminder
Brushing modes
Your power toothbrush is equipped with 4 different modes: clean, white+,
gum health and deep clean+.
Based on the smart brush head you use, the optimal mode and intensity will be
selected automatically by the BrushSync technology.
To manually change the mode, press the mode/intensity button while the
toothbrush is off with the brush head attached.

14 English
* Note:
- All brush heads work with each mode.
- When the Philips Sonicare toothbrush is used in clinical studies, it must be
used at high intensity, with the EasyStart feature turned off.
Brush head mode pairing
Brush heads with BrushSync technology are equipped with a microchip which
communicates to the handle and automatically pairs it with the recommended
mode and intensity.
Note:If you change modes/intensity, the brush head will remember the last
used setting. If you wish to brush with the recommended setting, you can find
the recommended mode/intensity in the following table.
Clean and Deep
Clean+
White+ Gum health
Benefit Plaque removal Plaque and
surface stains
removal
Plaque removal
and gum
massage
Recommended
brush head
Premium Plaque
Defense (C3) Premium White (W3) Premium Gum Care (G3)
Recommended
intensity level
3 3 3
Total brushing
time
Clean: 2 minutes
Deep Clean+: 3
minutes*
2 minutes and 40
seconds 3 minutes and 20 seconds

15
English
Clean and Deep
Clean+
White+ Gum health
How to brush Clean: Brush each
segment for 20
seconds
1
2
3
4
5
6
Deep Clean+:
Brush each
segment for 30
seconds*
1
2
3
4
5
6
Brush each
segment for 20
seconds,
1
2
3
4
5
6
then brush
segments 7 and 8
for 20 seconds
each.
7
8
Brush each
segment for 20
seconds,
1
2
3
4
5
6
then brush
segments 7, 8, 9
and 10 for 20
seconds each.
7
8
10
9
*Note: When brushing with the Philips Home+ app in 'Deep Clean+' mode, the
brushing time will be 3 minutes.
Intensity settings
Your power toothbrush comes with 3 different intensity settings:
- low intensity (one bar)
- medium intensity (two bars)
- high intensity (three bars)
When attached to the handle, the smart brush head will automatically select
the recommended intensity. To manually change the intensity, turn on the
handle and press the mode/intensity button.

16 English
While toothbrush is
ON, press this button
to change the
intensity setting
Features
- BrushPacer
- Pressure sensor
- Brush head replacement reminder
- EasyStart
BrushPacer
The BrushPacer features indicates when you have to move to the next section
of your teeth with a brief change in vibration.
The toothbrush turns off automatically at the end of the brushing session.
Pressure sensor
Your Philips Sonicare measures the pressure you apply while brushing to
protect your gums and teeth from damage.
If you apply too much pressure, the handle will change its vibration until you
reduce the pressure.
Note: The Pressure Sensor comes activated with your product. To deactivate
this feature, see 'Activating or deactivating features'.
Brush head replacement reminder
Over time, the handle will track the wear of your smart brush head by
measuring:
- The overall pressure you apply while brushing
- The total time you have brushed with your brush head
Once your brush head is no longer effective, the brush head replacement
reminder will blink amber and the handle will make a series of beeps and
tones.

17
English
Note: The brush head replacement reminder comes activated with your
product. To deactivate this feature, see 'Activating or deactivating features'.
EasyStart
The EasyStart feature gently increases the power of the handle over the first 14
brushings to help you get used to the brushing power of the Philips Sonicare.
The EasyStart feature works with all modes.
Note: The EasyStart feature comes deactivated with your product. To activate
EasyStart, see 'Activating or deactivating features'.
Charging and battery status
Charging on charger base
1Plug the cord of the charging base into an electrical outlet.
2Place the charging stand or the charging glass on the charging base.
3Place the handle on the charging stand or in the charging glass.

18 English
4The charger will charge your toothbrush until it is fully charged.
The handle is charging when the battery indication is blinking white. When the
handle is fully charged, the battery indication illuminates white for 30 seconds
and then turns off.
Note: Your handle comes pre-charged for first use. After first use, charge for at
least 24 hours.
Charging with the travel case*
*Note: The charging travel case may not be included depending on the model
purchased.
1Take the USB cable from the bottom of the charging travel case.
2Connect the charging travel case to 5V DC input power either from:
- The USB adapter provided
- a UL-listed or certified to ANSI/UL 60950-1 personal computer's
standard USB connector or,
- a UL-listed or certified to ANSI/UL 60950-1 LPS power supply with USB
output port or,
- a UL-listed or certified 1310 Class 2 power supply.
Important: The wall adapter must be a safe extra low voltage source,
compatible with the electrical ratings marked on the bottom of the
device.
3The travel case charges your toothbrush until your toothbrush is fully
charged.

19
English
Battery Status (handle on plugged in charger)
When the handle is placed on the charger or in the travel case, the battery
indication will communicate the battery level.
Battery status Battery indication
Charging Blinks in white
Full Illuminates white for 30 seconds and
then turns off.
Battery Status (when handle is not placed on charger)
When you turn on the handle, the battery light at the bottom of the handle
will indicate the status of the battery.
Battery status Battery indication Sound
Full Illuminated in white -
Partially full Blinks white -
Low Blinks amber The handle emits 3
beeps
Empty Blinks amber The handle emits 2 sets
of 5 beeps
Activating or deactivating features
You can activate or deactivate the following features of your toothbrush:
- EasyStart
- Brush head replacement reminder
- Pressure sensor

20 English
Step 1: Place the handle on the charging stand or in the
charging glass.
Step 2: Press and hold power button for:
Easy start Brush head
replacement
reminder
Pressure sensor
3 seconds Up to 5 seconds Up to 7 seconds
¯ ¯ ¯
Step 3: Let go power button when you hear
1 beep 1 beep and then
2 beeps 1 beep, 2 beeps and then 3 beeps
¯ ¯ ¯
If you see the battery indication blink white 2 times and hear 3
tones from low to high, then the feature has been activated.
OR
If you see battery indication blink white once and hear 3 tones
high to low, then the feature has been deactivated.
