Philips BVP080 User guide

Classified
Smart Bright Solar Flood Light
BVP080 Mounting instruction
Remote Controller Function:
Torque 2.5NM
M6 Screw
M8 Screw
Torque8NM
M6 Screw

Classified
Auto(Wake up):, Luminaire will light on dusk to dawn(max 12Hours) per default lighting profile
3H: Luminaire will light on 3 hours per default lighting profile and then turn off
5H: Luminaire will light on 5 hours per default lighting profile and then turn off
8H: Luminaire will light on 8 hours per default lighting profile and then turn off
Dim Down: Light output from 100% to 10%, every step 10%
(Note: It will exit dim mode after 2Hours for previous Auto mode)
Dim Up: Light output from 10% to 100%, every step 10%
On/OFF(For Indoor Use Purpose): Luminaire Light On/OFF per remote controller, light on with 100% light
output
Notes :
• Before using the product connect solar panel cable to luminaire to active luminaire with factory default working mode
Auto, and then use the functions of the remote control
• To go into Sleep mode (Stay for storage purpose), press OFF key, wake up by press Auto key
• LED indication on luminaire: Green on (Charging), Green Flash(Battery Low Capacity,<30%)
Application NOTES:
• Install the solar panel on open roof or wall facing towards Sun. The tilt angle can be adjusted.
• There shall not be any light source over the solar panel at night, as it may interfere with the operations of solar flood light.
• Charge the product under Sunlight for 8 hours before first use.
• After installation, the working modes can be set from infrared remote controller.
• This product does not need any external electrical connection. It works 100% on solar energy.
• Detection of duck/dawn is based on light intensity falling on solar panel.
• The battery backup will reduce if the ambient temperature is < 0 degree Celsius.
• When battery low capacity (<30%), light output will dim down to 15% to extend running time.
• The light source of this luminaire is not replaceable; when the light source reaches its end of life the whole luminaire shall
be replace.
• The products can be stored up to 6 months. In case it is required to store more than 6 months, it is must to re-charge the
product in bright daylight. Otherwise, it may affect the battery lifetime performance.
• Lighting profile from dusk to dawn(Max 12Hours)，applicable for 3H/5H/8H working mode.
• The operating position is universal.
• Suitable for indoor and outdoor use.
Period 1 Period 2 Period 3 Period 4 Period 5 Period 6
20% Light output
for 1hr
100% Light output
for 30min
40% Light output
for 1hr
20% Light output
for 1.5hr
10% Light output
for 2hr
5% Light output
for 6hr
